Boca Flasher AC-100 User manual

Installation Manual
AC-100
WARNING: DO NOT ATTEMPT TO INSTALL OR USE THE
AC100 FIXTURE WITHOUT READING THE INSTALLATION
INSTRUCTIONS AND SAFETY LABELS COMPLETELY.
FAILURE TO ADHERE TO THESE INSTRUCTIONS COULD RESULT IN SERIOUS
INJURY OR PROPERTY DAMAGE.
DO NOT MODIFY, ALTER OR ATTEMPT TO SERVICE THE AC100.
DOING SO WILL VOID THE WARRANTY.

Installation Instructions
AC100
Introduction:
The Boca AC100 is designed for low power applications where energy consumption and size are the main concerns. It can be specied with
either 18, 36, 52, or 72 LED’s per linear foot, depending on the housing that’s chosen and the light output required. It oers seamless LED
conguration, easy installation, and vibrant solid color. The AC100 can be used with any magnetic low voltage dimmer and is available in
dierent housings for dierent uses, including underwater installations where IP68 is required.
Maintenance:
CLEANING Dry and Damp (IP65) Rated Fixtures: To clean surface use a soft damp cloth.
Wet (IP68) Rated Fixtures: To clean surface use a soft cloth with mild soap and water.
STORAGE Store in a dry, well-ventilated area when product is not in use.
Keep the electrical cord away from heated surfaces when in use or not in use.
If cord shows signs of damage do not use, return product to manufacturer.
Electrical Specifications:
1. Input Voltage: 24 VDC or 24 VAC (See layout drawings for spec.)
2. Total linear ft per 20A breaker: Single Row - 175ft ; Double Row - 90ft; Triple Row-56ft;
Four Rows - 45ft;
3. Total linear ft per 15A breaker: Single Row- 146ft; Double Row - 65ft; Triple Row - 48ft;
Four Rows - 32ft Input Current: 90mA RMS per linear foot, per row.
Solid Color Dimmable LED Light Strips
Fixtures must be installed by a
qualied and licensed electrician in
accordance with all national, state and
local electrical codes and regulations.
If any part of this manual does
not meet the necessary codes and
regulations, contact the factory for
more information before attempting
to install.
Model Dependent
Max temp: 55C
Min. temp: -40C
DAMP LISTING
IP65
WET LISTING
IP68
Turn Power Off At Circuit Breaker Before Beginning Installation!
INCLUDED IN THIS PACKAGE:
OR
Tube
Underwater Tube
Mounting Brackets
(2 brackets per xture)
Remote Transformers
(If ordered)
12 3
PAGE 2 OF 6
AC100 Fixtures
(In lengths shown on job specic drawings)
OR
For Underwater Tube For Tube
4Distribution Box
(If ordered)
5Distribution Box
(If ordered)
Cables shown are interior
Cables shown are interior
Cables shown are interior
6Job Specic Drawings
AC100

2. INSTALL FIXTURES INTO CLIPS
Installation Instructions
AC100
PAGE 3 OF 6
1. INSTALL CLIPS INTO SUBSTRATE
OR
Push Fixture down with slightly rm pressure.
1a
OR
1b Screw Information:
1. Screws not provided by
Boca Flasher.
2. For Tube Boca Flasher recommends
wide washer at head Philips #6
screw for the tube. For underwater
tube, Boca Flasher recommends
Philips #8 screw. (not to exceed .330”)
3. Length of screw will vary depending
on mounting surface.
4. For outdoor installations,
installer should use a screw with
weatherproof coating.
2a Clip will securely snap into place.
2b
OR
OR
snap!
▶
▶
OR
▶
▶
3. CONNECT FIXTURES TOGETHER FOR TUBE ONLY
(AS SHOWN ON JOB SPECIFIC DRAWINGS) NOTE: Underwater Tube ships connected.
Connect Male and Female connectors
in order shown on job
specic drawings.
3a 3b
Coupler
Push together until
you hear a “Click”.
3c
click!
▶
▶

4a CONNECT FIXTURES TO POWER
Installation Instructions
AC100
PAGE 4 OF 6
4b CONNECT FIXTURES TO POWER WITH DINNING SYSTEM

Installation Instructions
AC100
IMPORTANT SAFETY REMINDERS:
We are constantly improving our fixtures and reserve the right to change options and specifications. Additional information &
details at www.bocaflasher.com. For specific requirements, contact your Boca Flasher sales representative. Boca Flasher, Inc. 508
S. Military Trail, Deerfield Beach, Florida 33442 USA Phone: [phone] Fax: [phone] © 2017 Boca Flasher, Inc. All rights
reserved. All names and trademarks are property of their respective owners. REV 06-2017
DAMP LISTING
IP65
WET LISTING
IP68
1. DANGER:
To reduce the risk of electric shock, always unplug the AC100 from electrical outlet before
cleaning. Cut breaker if outlet is not available.
2. To reduce the risk of burns, re, electric shock or injury to persons:
• Use the AC100 only for its intended use as described in these instructions.
• Do not use attachments not recommended by Boca Flasher.
• Never operate the AC100 if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water. If the seal appears
to be damaged/broken/torn return the AC100 to a service center for examination or repair.
• Keep cord away from heated surfaces.
• Never drop or insert any object into any opening.
• Do not operate where aerosol (spray) products are being used or where oxygen is
being administered.
3. WARNING:
Do not attempt to install or use the AC100 without reading the installation instructions
and safety labels. Failure to adhere to these instructions could result in serious injury or
property damage.
4. Do not modify, alter or attempt to service the AC100:
Doing so will void the warranty.
5. Do not use sharp tools near or on the xture lens:
Doing so will result in property damage and void the warranty.
Boca Flasher, Inc.
508 S. Military Trail nDeerfield Beach, Florida n33442 USA
Phone: [phone] nFax: 561-982-8323
www.bocaflasher.com
