Body Craft T1000AC User manual

T1000AC / T800DC / T400DC
Console Options
16” SmartTouch
10” SmartTouch
9” LCD

Congratulations and Welcome to the BODYCRAFT Family
Thank you for selecting a BODYCRAFT Treadmill. Your choice reflects a wise
investment in you and your facility. We hope you use it for many healthy years!
Purchaser’s Reference Information:
IT IS IMPERATIVE THAT YOU FILL IN THE FOLLOWING
INFORMATION AND REFER TO IT SHOULD THE NEED
FOR SERVICE ARISE.
Product Name: TXXXXX Console
Serial Number: T _ _ _ _ _ _ _ _ _ _ _ _
Proof of purchase must be supplied to validate warranty and the product must have been
registered with BODYCRAFT via online at www.bodycraft.com or by calling 800-990-5556 or
740-965-2442 M-F 9 a.m. - 5 p.m. EST.
BODYCRAFT offers a complete array of high-quality fitness equipment. Please refer to our
website at www.bodycraft.com to view more ways to enhance your lifestyle.
Your BODYCRAFT machine has all the quality and design elements to make your workout
extremely efficient and comfortable. Your new Treadmill is a serious cardio machine that will
keep you motivated, challenged and within reach of your fitness goals. Strength &
cardiovascular training is vital for all ages which will provide an effective workout, producing
results that will encourage you to reach your fitness goals and maintain the body you have
always wanted. Spending 15 to 30 minutes a day, three times a week, is all you need to start
seeing the benefits of a regular exercise program.
As a premium exercise equipment manufacturer, we are committed to your complete
satisfaction. If you have questions, suggestions or find missing or damaged parts, we
guarantee your complete satisfaction through our authorized dealer network or by contacting
us directly. Please call your local dealer or BODYCRAFT.
BODYCRAFT (a division of Recreation Supply, Inc.)
7699 Green Meadows Dr.
Lewis Center, OH 43035
Phone: [phone] am - 5 pm EST Email: [e-mail]
Proof of purchase must be supplied to validate warranty and the product must have been
registered with BODYCRAFT via online at www.bodycraft.com or by calling 800-990-5556 or
740-965-2442 M-F 9 a.m. - 5 p.m. EST.
1

TABLE OF CONTENTS
Console Operation Instructions ..…………………................................….………… 3
16” Smart Touch Console Operation Instructions ..…………………..... Pages 4 - 18
10” Smart Touch Console Operation Instructions .……………………. Pages 4 - 18
9” LCD Console Operation Instructions .………………………………. Pages 19 - 23
Exploded View - Consoles ………………………….…………………………………. 24
Product Warranty .………………………..………………………........… Pages 25 - 26
- Product Warranty ..…………………………………………………………………. 25
- Warranty Registration ..…………………………………………………………… 28
Energy Saving function: These treadmill consoles are equipped with power saving
function. This means after 10 minutes of inactivity; the treadmill will automatically
power off. Press any key on the dash board to wake up the console from power save
mode.
For easy to read complete assembly
step-by-step in full color go directly to
www.bodycraft.com/treadmills-qr.html
2

CONSOLE OPERATION INSTRUCTIONS
Please read the console operation instructions thoroughly and get familiar with the console layout.
Practice using this console before you start to get a better understanding of the functions. Below are the
console layout and detailed operation instructions.
At Installation: The console needs to be paired with the treadmill product model correctly to ensure
smooth operation. When the console is powered on the first time, it needs to be calibrated. Please
follow the message window prompts to calibrate before use.
To power up the treadmill, locate the power cord attached to the front of the treadmill and plug it into a
Dedicated 120V/15A home use (Commercial use upgrade to 120V/20A) grounded wall outlet. Turn on the
power switch to wake up the treadmill and go into the idle mode.
Always turn off the treadmill after hours when not in use.
16” SmartTouch
10” SmartTouch
9” LCD
3

16” & 10” SmartTouch Screen Layout:
Device Ports
Touchscreen Display
The display is equipped with a capacitive touchscreen technology, and it is more responsive than a resistive
screen. Because of this, the capacitive screen can be controlled with very light touches of a finger. Capacitive
touchscreens can only be touched with a finger and will not respond to touches with a regular stylus, gloves or
most other objects.
USB port:
Charge your device up to 1amp or update console software. (Device not included.) It also be used for
media (music & video) playing.
CSAFE port x 2:
One for charging 3rd party compatible devices (not included). One for communicating with 3rd party
compatible devices such as transmitting workout data.
Headphone Jack:
Standard 3.5mm audio jack used to connect headphones to the console during media playback.
HDMI Input & Ethernet port & WIFI:
Video, internet connections.
Bluetooth & ANT+ connectivity:
Connect with Bluetooth & ANT+ heart rate straps as well as Bluetooth headphone & speaker audio
devices.
(Note: Your media device compatibility with the USB & CSAFE charging will depend on the brand and
4

Physical Keys
● Quick Start key: Pressing this physical key or on-screen Quick Start key during idle mode before
you select a program will activate the Quick Start program immediately with default user values. Or
pressing this key during the program set-up after a program is selected will start the selected
program.
● Stop/Pause key: Press this physical key or on-screen Stop key during exercise to pause the
treadmill. Press this key or on-screen Stop key during Cool Down mode to end cool-down and enter
workout summary mode.
● Speed & Incline keys: There are 2 sets of +, - keys (on screen & handrails) for each Speed &
Incline. Use these keys to adjust the Speed & Incline settings during exercise.
● Speed & Incline quick keys: Press these quick keys to rapidly change the Speed or Incline settings
during exercise. For your convenience, you may press and hold the “Custom” key to save the current
speed/incline setting into the key as a new custom quick key.
● Safety key: This key is designed for the emergency stop during exercise. Pulling this key will stop
the treadmill immediately. The incline will stay where it is. Re-attach this key and adjust the incline
setting back to 0% to resume treadmill operation.
5

Touch Screen Navigation
Home Screen
Home Screen is where you can log in to see your workout data or select from various program
options to begin a workout or get into
various engineering settings to make
the console more user-friendly.
● User Login: To get into user
setting, build a custom workout
program and track a user
Workout.
● Quick Start: To start a workout
with a default setting right away.
● Classics: To get into 6 preset
Classic programs: Goal,
Random Incline, Hill, Walk, Run
& Sprint.
● Intervals: There are 4 interval programs inside this category: Incline, Speed, HIIT & Custom
Intervals.
● Races: There are 3 distance goal programs inside this category: 5K, 10K & Half Marathon.
● Fitness Tests: There are 9 popular fitness test protocols: Bruce, Gerkin, WFI, PEB, Army, Navy,
Marine, Air Force & Coast Guard.
● HRCs: There are 4 heart rate control programs: Target HR, HR interval, Fat Burn & Cardio.
● Virtual Scenes: This category comes with 4 beautiful scenic landscape videos to make your
exercise more interesting.
● Setting: Select the initial console setting such as System setting, Bluetooth, Wireless & Language
setting to make this console function properly.
● FITNESS App Sync Button: Press this button on the home screen to sync with the RunFit
App and track you workout.
● The “i“ Information Button: When this button is lit up, you may press this button to learn about
this series of treadmill designs.
Program Selection & Setting Desired Values
Touch the desired program category, it will open the program selection screen under each category. Then
touch the desired program to open program setting screen. Fill in the necessary values to finish the
program
6
→

Exercise Screen
Some programs will start with a 3-minute Warm Up. The time will count down and speed & incline default
at a lower rate & grade. You may adjust
them during this period.
After Warm Up or as soon as the SKIP
button is pressed to begin a program, the
exercise screen will start in some programs.
● Data displays: Time, Pulse, Mets, Calories, Distance, Pace, Elevation Gain on the top and Incline
%, as well as Speed mph/kph on the
bottom.
● STOP button: To pause the exercise.
● Speed & Incline +/- keys: To adjust
speed & incline settings.
● Profile display: There are 3 different profile displays available: Speed (Blue profile), Incline (red
profile) & 400m/0.25mile lap display with
a lap counter. Speed & Incline profiles
will be displayed according to program
default as well as speed/incline
adjustment during exercise. Touch the
desired profile on the screen to switch.
7

Cool Down Screen
After program time is achieved a three minute Cool Down mode will begin. As with Warm Up mode, the
speed and incline will default to a lower rate
and grade. You may adjust these values as
desired.
● Media: Swipe the media tab to
open the media selection.
8
Pause Screen
During exercise, you may press the STOP key to pause the treadmill for up to 10 minutes. The treadmill
speed will stop, and incline will stay, and
data will stop accumulating. You may
press Continue to resume back to
previous activity or Cool Down to end the
program and enter Cool Down. If no key is
pressed within 10 minutes, the console will
reset and go back to idle mode.
For safety reasons, if you step off the
treadmill for 20 seconds, the treadmill
will automatically pause as well.

Workout Summary Screen
When Cool Down period ends, or when the Skip button is pressed during Cool Down, the program will
end and enter a summary review screen. There are
4 pages of summary for you to review. Swipe the
screen to see the next page.
If the “Save As Favorite” option is available, you
may save this program into your favorite programs
by pressing the “Save As Favorite” button and
follow on-screen instruction to save it.
NOTE: During fitness test programs, the Test
result will be displayed instead of Flights Climbed.
9
