Air-COOLED CONDENSiNG UNiTS
1/2-6 HP Indoor and Outdoor Models
Technical Guide
BNHTSTB
April 2008
Replaces BN-HTSTB, May 2004
www.thecoldstandard.com

2
B H T 030 L 6 C F
Model Compressor Application Equiv. HP Temp. Refrigerant Voltage Identier
B =
Bohn
H = Hermetic
S = Semi–herm.
Z = Scroll
T = Outdoor
N = Indoor
S = Beacon II™
Microprocessor
B = Bohnmizer
005 = 1/2 HP
008/009 = 3/4 HP
010, 011 = 1 HP
01* = 1–1/2 HP
02* = 2 HP
03* = 3 HP
04* = 4 HP
05* = 5 HP
060 = 6 HP
H = High
L = Low
M = Medium
E = Extra Low
X = Extended
Medium
2 = R–22
6 = R–404A/507
B = 208/230/1/60
C = 208/230/3/60
D = 460/3/60
G = 230/1/60
F = Stock
Table of Contents
Nomenclature................................................................................................................................................................................. 2
Features & Benets ........................................................................................................................................................................3
Options ..............................................................................................................................................................................................4
Hermetic Compressors ................................................................................................................................................................5
Performance Data ...............................................................................................................................................................5
Medium & High Temp., R–22 ................................................................................................................................5
Extended Temp., R–404A/507..............................................................................................................................6
Low Temp., R–404A/507.........................................................................................................................................7
Unit Specication Data......................................................................................................................................................7
Electrical Data.......................................................................................................................................................................8
Scroll Compressors ........................................................................................................................................................................9
Performance Data ...............................................................................................................................................................9
Medium Temp., R–404A/507 ................................................................................................................................9
Low Temp., R–404A/507...................................................................................................................................... 10
Medium Temp., R–22............................................................................................................................................ 11
Low Temp., R–22 .................................................................................................................................................... 12
Unit Specication Data................................................................................................................................................... 13
Electrical Data.................................................................................................................................................................... 13
Semi–hermetic Compressors.................................................................................................................................................. 14
Performance Data ............................................................................................................................................................ 14
High Temp., R–22 ................................................................................................................................................... 14
Medium Temp., R–404A/507 ............................................................................................................................. 15
Low Temp., R–404A/507...................................................................................................................................... 16
Unit Specication Data................................................................................................................................................... 17
Electrical Data.................................................................................................................................................................... 18
Medium Temp......................................................................................................................................................... 18
Low Temp. ................................................................................................................................................................ 19
Replacement Parts by InterLink™ .......................................................................................................................................... 19
Dimensional Drawings of Cabinet ..................................................................................................................................20-21
© 2008 Heatcraft Refrigeration Products LLC
Nomenclature
®
We have made a commitment to customer needs, innovation and environmental stewardship
and have dedicated ourselves to delivering energy-ecient choices that reduce costs, improve
bottom lines and enhance equipment performance and service life. The PSC motor is an Energy
Solutions® feature and is optimized to help you save money by increasing energy eciency.
MEA Accepted

3
Features & Benefits
Cabinet & Construction
Painted galvanized cabinets for superior strength and corrosion
protection including hoods for outdoor units
Heavy duty steel raised base with 1-1/2" legs
Fan guards and wiring conduit on indoor models
•
•
•
Serviceability
Suction service valves for hermetic and scroll compressors located
outside the cabinet for quick installations. Semi-hermetic compressor
models have a suction valve on the compressor and an access tting
on the suction line entering the cabinet. A receiver with fusible plug,
liquid shuto valve and charging port is also standard
Large electrical panel for ease of access
Prefabricated wiring harnesses for tight crimp connections and
consistent labeling
Unit stays on line if the hood is removed for servicing
Sight glass is easily viewable
•
•
•
•
•
Quality
All units completely leak tested in a helium environment and
bump tested and allowed to cycle o on the high and low pressure
control. Each unit will have a copy of the run data shipped inside
the electrical panel
Electrical circuits are completely checked for continuity
Piping is laid out to minimize stress and vibration and is pre-bent to
eliminate leaks
Encapsulated, auto-reset, high and low pressure controls to
eliminate leaks (standard on all high and medium temperature
models, adjustable low pressure control standard on low
temperature models)
•
•
•
•
Fans
Fans specically matched with motor and coil to attain maximum air
movement and cooling
•
Motors
Motors rated for 50 and 60 cycle application•
Compressor
Wide variety of compressors including: hermetic, semi-hermetic
and scroll. R-22 and R-404A/507 available for both medium and low
temperature applications
Spring-mounted compressors with vibration eliminators on all 1/2 - 6
HP semi-hermetic compressors
Discharge service valves on all compressors including hermetics
•
•
•
Options
Factory-installed Smart Defrost Kit™ (SDK)
Liquid and suction lters available as options
•
•
Typical Outdoor Hermetic Unit
Typical Outdoor Unit with throwaway liquid-line
lter and sight glass
Typical Outdoor Hermetic Unit with liquid lter drier
and sight glass

4
The Beacon II™ Refrigeration System is a preassembled, factory installed refrigeration
system featuring an integrated microcomputer based electronic control board.
The Beacon II™ Refrigeration System replaces the expansion valve, solenoid valve, room
thermostat, defrost control and timer. It comes factory preset thereby eliminating all
of the expensive and time consuming ne tuning and adjustments necessary for a good system installation. For
additional information, contact your Sales Representative.
The Bohnmizer®System
The Bohnmizer® system is a complete factory furnished commercial refrigeration split system designed to operate
properly regardless of climatic conditions. As the ambient temperature falls below 75°F, the head pressure is
allowed to decrease in direct relationship to the ambient.
The heart of the system is the Bohnmizer valve, whose design allows the proper amount of refrigerant to ow to
the evaporator irrespective of the valve inlet pressure. The Bohnmizer valve also responds very rapidly to changes
in suction temperature, which assures the maintenance of low superheat, regardless of the ambient temperature.
The Bohnmizer system concept results in operational energy savings, increased compressor life, reduced
refrigerant costs and less maintenance expense.
™
Options
Electrical options: Outdoor Indoor Stock
Smart Defrost Kit™ Option Option N/A
Dual pressure control (not available on Beacon II™) Option Option N/A
Adjustable low pressure control for medium temp. comp. Option Option N/A
Crankcase heater Standard N/A Standard
Fused disconnect / Non-fused disconnect Option Shipped loose N/A
Phase loss / low voltage monitor Option Option N/A
Fixed fan cycling — pressure or temperature (2 fan units)
(Pressure standard on Beacon II™) Option Option N/A
Air or electric defrost timer only Option Option 1/2-3 HP low temp.
Electric defrost with timer & contactors (040-060 models only) Option Option 4-6 HP low temp.
Beacon II™ Option Option N/A
Mechanical options:
Head pressure control ooding valve Standard Option Standard
Liquid line drier, sight glass Option Option Standard
Suction line lter Option Option N/A
Suction accumulator (standard on X6 models) Option Option N/A
Oil separator with discharge line check valve (D cabinet) Option Option N/A
Liquid line solenoid valve and pumpdown switch Option Option N/A
Replaceable core liquid line lter (D cabinet) Option Option N/A
Replaceable core suction line lter (D cabinet) Option Option N/A
Precharged refrigerant with line sets and wire harnesses Option Option N/A
Oversize receiver (D cabinet) Option Option N/A
Low ambient kit with heated and insulated receiver, TD relay Option N/A N/A
12" Extended legs for snowbelt operation Shipped loose Shipped loose Shipped loose

5
HERMETIC COMPRESSORS
Performance Data - Medium & High Temperature (R-22)
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
Hermetic Compressors
R-22 Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
40°F 30°F 25°F 20°F 15°F 10°F 0°F
BH*-005H2 ART82C1 7,470 5,640 5,090 4,610 4,170 3,740 2,940
BH*-008H2 RS64C2 10,690 8,990 8,080 7,310 6,610 5,850 4,540
BH*-010H2 RS70C1 11,360 10,100 8,620 7,730 6,840 6,070 4,280
BH*-015H2 CR18KQ – 14,580 12,910 11,350 9,910 8,100 5,650
BH*-020H2 CR24KQ 24,360 19,930 17,760 15,650 13,650 11,640 8,560
BH*-029M2 CR37KQ – 26,210 23,630 21,300 18,870 16,620 11,700
BH*-030H2 CR37KQ 41,190 33,300 29,500 25,830 22,330 19,040 13,210
BH*-040H2 CR53KQ 57,430 46,140 40,790 35,620 30,740 26,150 18,100
BH*-050H2 CRN-0500 64,770 52,240 46,250 40,490 35,010 29,860 20,740
R-22 Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
40°F 30°F 25°F 20°F 15°F 10°F 0°F
BH*-005H2 ART82C1 7,170 5,410 4,870 4,410 3,990 3,580 2,790
BH*-008H2 RS64C2 10,280 8,540 7,740 6,980 6,310 5,580 4,320
BH*-010H2 RS70C1 10,870 9,120 8,150 7,350 6,490 5,740 3,870
BH*-015H2 CR18KQ – 13,830 12,210 10,670 9,260 7,510 5,130
BH*-020H2 CR24KQ 23,190 18,980 16,910 14,900 12,990 11,090 8,150
BH*-029M2 CR37KQ – 25,100 22,780 20,270 17,880 15,450 10,900
BH*-030H2 CR37KQ 38,230 31,710 28,090 24,610 21,260 18,140 12,580
BH*-040H2 CR53KQ 54,690 43,950 38,840 33,930 29,270 24,920 17,240
BH*-050H2 CRN-0500 61,680 49,760 44,050 38,560 33,340 28,440 19,750
R-22 Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
40°F 30°F 25°F 20°F 15°F 10°F 0°F
BH*-005H2 ART82C1 6,850 5,200 4,680 4,430 3,990 3,410 –
BH*-008H2 RS64C2 9,850 8,160 7,400 6,660 5,970 5,310 –
BH*-010H2 RS70C1 10,380 8,690 7,820 6,910 6,140 5,410 –
BH*-015H2 CR18KQ – 13,070 11,500 10,000 8,600 6,890 4,410
BH*-020H2 CR24KQ 22,030 18,030 16,070 14,160 12,340 10,540 7,740
BH*-029M2 CR37KQ – 23,980 21,720 19,260 16,910 14,470 –
BH*-030H2 CR37KQ 37,270 30,130 26,690 23,380 20,200 17,220 11,950
BH*-040H2 CR53KQ 51,960 41,760 36,890 32,240 27,820 23,670 16,390
BH*-050H2 CRN-0500 58,600 47,270 41,850 36,630 31,680 27,020 18,760
R-22 Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
40°F 30°F 25°F 20°F 15°F 10°F 0°F
BH*-005H2 ART82C1 6,240 4,960 4,430 4,010 3,550 3,190 –
BH*-008H2 RS64C2 8,930 7,820 6,710 6,020 5,390 4,770 –
BH*-010H2 RS70C1 9,490 8,250 6,950 6,170 5,440 4,380 –
BH*-015H2 CR18KQ – 11,590 10,100 8,230 6,880 5,650 –
BH*-020H2 CR24KQ 19,770 16,180 14,410 12,680 11,000 9,400 6,490
BH*-029M2 CR37KQ – 21,750 19,600 17,030 14,730 12,520 –
BH*-030H2 CR37KQ 33,900 27,120 23,870 20,760 17,820 15,080 10,350
BH*-040H2 CR53KQ 48,390 38,470 33,780 29,320 25,120 21,230 14,550
BH*-050H2 CRN-0500 54,770 43,730 38,490 33,470 28,740 24,340 16,760

6
HERMETIC COMPRESSORS
Performance Data - Extended Temperature (R-404A/507)
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
R-404A/507
Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
30°F 25°F 20°F 0°F -10°F -20°F -25°F
BH*008X6 RS55C2E 8,490 8,050 7,480 4,260 2,350 1,750 1,130
BH*009X6 RS64C2E 9,710 9,090 8,310 5,220 4,130 3,240 2,400
BH*010X6 RS70C1E 10,060 9,300 8,660 5,540 4,080 2,750 2,050
BH*015X6 CS10K6E 16,430 15,090 13,550 7,910 5,280 3,610 2,970
BH*020X6 CS12K6E 18,590 17,000 15,420 9,110 6,330 4,030 3,270
BH*025X6 CS14K6E 20,150 18,630 17,270 10,900 8,050 5,740 4,760
BH*030X6 CS18K6E 29,490 27,030 24,550 14,390 10,600 7,380 6,180
BH*032X6 CS20K6E 32,420 29,620 26,840 15,930 12,200 8,780 7,000
BH*040X6 CS27K6E 43,970 39,510 35,150 20,560 14,980 11,830 8,690
BH*050X6 CS33K6E 44,600 43,160 39,300 24,160 17,610 13,500 11,700
R-404A/507
Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
30°F 25°F 20°F 0°F -10°F -20°F -25°F
BH*008X6 RS55C2E 8,010 7,590 7,060 4,020 2,220 1,650 1,070
BH*009X6 RS64C2E 9,170 8,580 7,850 4,920 3,900 3,060 2,260
BH*010X6 RS70C1E 9,400 8,850 8,170 5,120 3,770 2,610 1,820
BH*015X6 CS10K6E 15,400 13,960 12,800 7,220 5,060 3,330 2,630
BH*020X6 CS12K6E 17,490 16,000 14,470 8,370 5,830 3,860 2,830
BH*025X6 CS14K6E 18,920 17,490 16,250 10,090 7,530 5,230 4,330
BH*030X6 CS18K6E 27,840 25,490 23,130 13,480 9,710 6,750 5,620
BH*032X6 CS20K6E 30,530 27,890 25,240 14,800 11,200 7,930 6,220
BH*040X6 CS27K6E 41,480 37,270 33,160 19,400 14,130 11,160 8,200
BH*050X6 CS33K6E 42,300 41,000 37,180 22,370 17,300 12,700 10,900
R-404A/507
Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
30°F 25°F 20°F 0°F -10°F -20°F -25°F
BH*008X6 RS55C2E 7,530 7,130 6,640 3,780 2,090 1,550 1,010
BH*009X6 RS64C2E 8,620 8,060 7,380 4,630 3,660 2,870 2,130
BH*010X6 RS70C1E 8,790 8,290 7,680 4,760 3,430 2,230 1,570
BH*015X6 CS10K6E 14,210 13,150 11,780 6,660 4,580 2,930 2,270
BH*020X6 CS12K6E 16,410 14,990 13,380 7,700 5,280 3,420 2,420
BH*025X6 CS14K6E 17,730 16,390 15,220 9,390 6,950 4,770 3,930
BH*030X6 CS18K6E 26,190 23,970 21,800 12,570 8,880 6,120 5,110
BH*032X6 CS20K6E 28,600 26,160 23,750 13,740 10,300 7,050 5,370
BH*040X6 CS27K6E 38,980 35,030 31,180 18,240 13,290 10,500 7,700
BH*050X6 CS33K6E 39,800 38,760 34,810 20,760 16,200 11,800 10,000
R-404A/507
Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
30°F 25°F 20°F 0°F -10°F -20°F -25°F
BH*008X6 RS55C2E 6,150 5,900 5,520 2,730 2,050 1,620 1,190
BH*009X6 RS64C2E 7,370 6,840 6,300 4,070 3,000 2,380 1,750
BH*010X6 RS70C1E 7,700 7,140 6,590 4,080 3,010 1,680 –
BH*015X6 CS10K6E 12,150 11,110 10,030 5,410 3,650 2,140 1,540
BH*020X6 CS12K6E 14,270 12,980 11,550 6,460 4,410 2,580 1,660
BH*025X6 CS14K6E 15,430 14,450 13,230 8,100 5,760 3,860 2,990
BH*030X6 CS18K6E 23,000 21,020 18,970 10,810 7,100 4,940 4,140
BH*032X6 CS20K6E 24,840 22,790 20,580 11,490 8,260 5,270 3,630
BH*040X6 CS27K6E 35,150 31,240 27,520 15,210 11,290 8,920 6,550
BH*050X6 CS33K6E 35,200 34,060 30,530 19,000 14,100 10,400 9,010

7
Model Fig. ++ Compressor Connections (ID) Receiver 90% Full
Lbs.
Fan(s) Dimensions Net Wt.
Lbs.
Sound
Data dBA†
Liquid Suction D (In.) W (In.) H (In.)
BH*005H2 A ART82C1 3/8 1/2 6.0 1 28.25 23.75 17.25 187 67
BH*008H2 A RS64C2 3/8 1/2 6.0 1 28.25 23.75 17.25 141 68
BH*010H2 A RS70C1 3/8 5/8 6.0 1 28.25 23.75 17.25 136 68
BH*015H2 B CR18KQ 3/8 5/8 10.0 2 28.25 37.75 17.25 189 71
BH*020H2 B CR24KQ 3/8 7/8 10.0 2 28.25 37.75 17.25 193 72
BH*029M2 C CR37KQ 1/2 7/8 16.0 2 28.25 37.75 19.25 214 72
BH*030H2 D CR37KQ 1/2 7/8 22.0 1 30.25 42.50 29.75 281 73
BH*040H2 D CR53KQ 1/2 1-1/8 22.0 1 30.25 42.50 29.75 299 73
BH*050H2 D CRN-0500 1/2 1-1/8 22.0 1 30.25 42.50 29.75 310 75
BH*008X6 A RS55C2E 3/8 1/2 5.5 1 28.25 23.75 17.25 135 68
BH*009X6 A RS64C2E 3/8 5/8 5.5 1 28.25 23.75 17.25 144 68
BH*010X6 A RS70C1E 3/8 5/8 5.5 1 28.25 23.75 17.25 138 68
BH*015X6 B CS10K6E 3/8 5/8 9.0 2 28.25 37.75 17.25 193 71
BH*020X6 B CS12K6E 3/8 7/8 9.0 2 28.25 37.75 17.25 203 73
BH*025X6 B CS14K6E 3/8 7/8 9.0 2 28.25 37.75 17.25 208 74
BH*030X6 D CS18K6E 1/2 7/8 20.0 1 30.25 42.50 29.75 290 73
BH*032X6 D CS20K6E 1/2 7/8 20.0 1 30.25 42.50 29.75 275 76
BH*040X6 D CS27K6E 1/2 1-1/8 20.0 1 30.25 42.50 29.75 281 73
BH*050X6 D CS33K6E 1/2 1-1/8 20.0 1 30.25 42.50 29.75 313 73
BH*011L6 A CF04K6E 3/8 5/8 5.5 1 28.25 23.75 17.25 139 73
BH*014L6 A CF06K6E 3/8 5/8 5.5 1 28.25 23.75 17.25 170 73
BH*019L6 B CF06K6E 3/8 5/8 9.0 2 28.25 37.75 17.25 200 69
BH*025L6 B CF09K6E 3/8 7/8 9.0 2 28.25 37.75 17.25 222 76
BH*031L6 C CF12K6E 1/2 7/8 14.0 2 28.25 37.75 19.75 223 77
HERMETIC COMPRESSORS
Performance Data - Low Temperature (R-404A/507)
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™ ++ = See Dimensional Drawings for details
†= Estimated sound pressure values are 10 feet from the unit. For estimating sound pressure from the unit at dierent distances, deduct the following from the unit
values: 20 feet, deduct 6 dBA for 40 feet, deduct 12 dBA for 80 feet, deduct 18 dBA. This data is typical of “free eld” conditions for horizontal air cooled condensing
units at the outlet of the discharge air. The actual sound measurements may vary depending on the condensing unit installation. Factors such as reecting walls,
background noise and mounting conditions may have a signicant inuence on this data.
R-404A/507
Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
BH*011L6 CF04K6E 7,030 6,240 5,370 3,850 3,330 2,630
BH*014L6 CF06K6E 10,500 9,380 7,830 6,090 4,890 4,080
BH*019L6 CF06K6E 12,100 10,180 8,910 6,580 5,530 4,570
BH*025L6 CF09K6E 15,550 14,500 12,700 9,000 7,560 6,230
BH*031L6 CF12K6E 18,840 17,800 15,140 11,540 9,790 8,070
R-404A/507
Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
BH*011L6 CF04K6E 6,840 5,750 4,920 3,650 3,020 2,360
BH*014L6 CF06K6E 9,900 8,840 7,750 5,670 4,710 3,680
BH*019L6 CF06K6E 11,400 10,100 8,750 6,040 5,030 4,150
BH*025L6 CF09K6E 15,400 13,700 12,000 8,300 6,950 5,750
BH*031L6 CF12K6E 17,690 16,800 14,360 10,910 9,170 7,470
R-404A/507
Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
BH*011L6 CF04K6E 6,310 5,170 4,460 3,300 2,660 2,070
BH*014L6 CF06K6E 9,310 8,280 7,280 5,280 4,350 3,510
BH*019L6 CF06K6E 10,700 9,430 8,170 5,810 4,570 3,700
BH*025L6 CF09K6E 14,500 12,800 11,200 8,130 6,410 5,220
BH*031L6 CF12K6E 17,600 15,090 13,410 10,700 9,040 7,320
R-404A/507
Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
BH*011L6 CF04K6E 5,240 4,450 3,620 2,630 2,100 –
BH*014L6 CF06K6E 8,310 7,340 6,420 4,580 3,730 2,990
BH*019L6 CF06K6E 9,330 8,170 7,040 4,920 3,980 3,090
BH*025L6 CF09K6E 12,700 11,400 9,900 7,030 5,760 4,590
BH*031L6 CF12K6E 15,700 14,000 12,400 9,250 7,690 6,100
HERMETIC COMPRESSORS - Unit Specifications

8
HERMETIC COMPRESSORS
Electrical Data
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
Per UL and NEC, RLA values have been calculated by dividing the Maximum Continuous Current (MCC) by 1.56.
^ Power supplied by customer.
† Consult factory for 50 HZ applications.
Model
Number Part Number Power Supply Compressor Fan Motor MCA MOPD Evap.
Fan
Amps
Defrost
Heater
Amps
Volts Ph Hz†RLA LRA Qty. HP FLA Air Elec. Air Elec.
BH*005H2B ART82C1-CAV 208-230 1 60 5.9 30.0 1 1/15 0.5 15.0 20 15 20 8 15
BH*008H2B RS64C2-CAV 208-230 1 60 6.9 37.0 1 1/15 0.5 15.0 20 15 20 8 15
BH*010H2B RS70C1-PFV 208-230 1 60 6.3 34.2 1 1/15 0.5 15.0 20 15 20 7 15
BH*010H2C RS70C1-TFC 208-230 3 60 4.2 31.0 1 1/15 0.5 15.0 20 15 20 8.6 15
BH*015H2B CR18KQ-PFV 208-230 1 60 8.1 41.0 2 1/15 1.0 15.0 24 15 25 6 19
BH*015H2C CR18KQ-TF5 208-230 3 60 4.9 40.0 2 1/15 1.0 15.0 24 15 20 7 19
BH*015H2D CR18KQ-TFD 460 3 60 2.8 23.0 2 1/15 1.0 15.0 20 15 20 ^ ^
BH*020H2B CR24KQ-PFV 208-230 1 60 12.2 70.5 2 1/15 1.0 20.0 29 25 30 6 23
BH*020H2C CR24KQ-TF5 208-230 3 60 6.7 40.0 2 1/15 1.0 15.0 24 15 25 9 19
BH*020H2D CR24KQ-TFD 460 3 60 3.6 28.0 2 1/15 1.0 15.0 20 15 20 ^ ^
BH*029M2B CR37KQ-PFV 208-230 1 60 16.7 100.3 2 1/15 1.0 21.8 38 35 50 12 30
BH*029M2C CR37KQ-TF5 208-230 3 60 9.9 85.0 2 1/15 1.0 15.0 38 20 40 12 30
BH*029M2D CR37KQ-TFD 460 3 60 5.0 39.0 2 1/15 1.0 15.0 15 15 25 ^ ^
BH*030H2B CR37KQ-PFV 208-230 1 60 16.7 100.3 1 1/3 3.5 24.3 38 40 50 12 30
BH*030H2C CR37KQ-TF5 208-230 3 60 9.9 85.0 1 1/3 3.5 20.0 38 25 40 12 30
BH*030H2D CR37KQ-TFD 460 3 60 5.0 39.0 1 1/3 1.9 15.0 24 15 25 ^ ^
BH*040H2B CR53KQ-PFV 208-230 1 60 26.0 140.0 1 1/3 3.5 36.0 48.0 50 60 12 35
BH*040H2C CR53KQ-TF5 208-230 3 60 16.3 107.0 1 1/3 3.5 23.9 38 40 50 12 30
BH*040H2D CR53KQ-TFD 460 3 60 8.1 55.0 1 1/3 1.9 15.0 29 15 30 11 23
BH*050H2B CRN5-0500-PFV 208-230 1 60 30.8 142.0 1 1/3 3.5 42.0 59 50 60 12 47
BH*050H2C CRN5-0500-TF5 208-230 3 60 19.2 130.0 1 1/3 3.5 28.0 40 45 50 12 30
BH*050H2D CRN5-0500-TFD 460 3 60 8.7 65.0 1 1/3 1.9 15.0 29 20 30 10 23
BH*008X6B RS55C2E-CAV 208-230 1 60 5.4 40.0 1 1/15 0.5 15.0 20 15 20 8 15
BH*009X6B RS64C2E-CAV 208-230 1 60 6.9 37.0 1 1/15 0.5 15.0 20 15 20 7 15
BH*010X6B RS70C1E-PFV 208-230 1 60 6.3 34.2 1 1/15 0.5 15.0 20 15 20 7 15
BH*010X6C RS70C1E-TFC 208-230 3 60 4.2 31.0 1 1/15 0.5 15.0 20 15 20 8.6 15
BH*015X6B CS10K6E-PFV 208-230 1 60 9.8 56.0 2 1/15 1.0 15.0 24 20 25 6 19
BH*015X6C CS10K6E-TF5 208-230 3 60 6.7 51.0 2 1/15 1.0 15.0 20 15 20 7 15
BH*020X6B CS12K6E-PFV 208-230 1 60 9.8 56.0 2 1/15 1.0 15.0 24 20 25 6 19
BH*020X6C CS12K6E-TF5 208-230 3 60 6.7 51.0 2 1/15 1.0 15.0 24 15 25 9 19
BH*025X6B CS14K6E-PFV 208-230 1 60 11.2 61.0 2 1/15 1.0 15.0 29 25 30 6 23
BH*025X6C CS14K6E-TF5 208-230 3 60 8.2 55.0 2 1/15 1.0 15.0 24 15 25 9 19
BH*025X6D CS14K6E-TFD 460 3 60 4.2 28.0 2 1/15 1.0 15.0 20 15 20 ^ ^
BH*030X6B CS18K6E-PFV 208-230 1 60 14.4 82.0 1 1/3 3.5 21.0 38 35 45 12 30
BH*030X6C CS18K6E-TF5 208-230 3 60 9.4 65.5 1 1/3 3.5 15.0 29 20 30 7 23
BH*030X6D CS18K6E-TFD 460 3 60 3.9 33.0 1 1/3 1.9 15.0 24 15 25 ^ ^
BH*032X6B CS20K6E-PFV 208-230 1 60 16.7 96.0 1 1/3 3.5 24.0 38 40 50 12 30
BH*032X6C CS20K6E-TF5 208-230 3 60 10.3 75.0 1 1/3 3.5 20.0 29 25 30 7 23
BH*032X6D CS20K6E-TFD 460 3 60 4.6 40.0 1 1/3 1.9 15.0 24 15 25 ^ ^
BH*040X6B CS27K6E-PFV 208-230 1 60 21.5 121.0 1 1/3 3.5 30.3 44 50 60 12 35
BH*040X6C CS27K6E-TF5 208-230 3 60 13.7 105.0 1 1/3 3.5 20.7 38 30 45 12 30
BH*040X6D CS27K6E-TFD 460 3 60 7.6 52.0 1 1/3 1.9 15.0 29 15 30 11 23
BH*050X6B CS33K6E-PFV 208-230 1 60 27.6 125.0 1 1/3 3.5 38.0 59 50 60 12 47
BH*050X6C CS33K6E-TF5 208-230 3 60 16.8 102.0 1 1/3 3.5 24.5 38 40 50 12 30
BH*050X6D CS33K6E-TFD 460 3 60 8.8 48.0 1 1/3 1.9 15.0 29 20 30 10 23
BH*011L6B CF04K6E-PFV 208-230 1 60 8.6 59.2 1 1/15 0.5 15.0 20.0 15 25 7 15
BH*011L6C CF04K6E-TF5 200-230 3 60 3.9 52.0 1 1/15 0.5 15.0 20.0 15 20 8 15
BH*014L6B CF06K6E-PFV 208-230 1 60 10.3 59.2 1 1/15 0.5 15.0 20.0 20 25 4 15
BH*014L6C CF06K6E-TF5 200-230 3 60 6.3 52.0 1 1/15 0.5 15.0 24.0 15 25 9 19
BH*025L6B CF09K6E-PFV 208-230 1 60 15.0 87.0 2 1/15 1.0 20.0 29.0 30 40 6 23
BH*025L6C CF09K6E-TF5 200-230 3 60 9.2 72.2 2 1/15 1.0 15.0 21.0 20 25 7 15
BH*031L6B CF12K6E-PFV 208-230 1 60 17.0 105.0 2 1/15 1.0 22.3 37.5 35 50 12 30
BH*031L6C CF12K6E-TF5 200-230 3 60 10.7 85.0 2 1/15 1.0 15.0 28.8 25 30 7 23
BH*031L6D CF12K6E-TFD 460 3 60 5.3 42.0 2 1/15 1.0 15.0 23.8 15 25 ^ ^

9
SCROLL COMPRESSORS
Performance Data - Medium Temperature (R-404A/507)
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
R-404A/507
Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
35°F 30°F 25°F 20°F 10°F 0°F -5°F
BZ*020M6 ZS15K4E 22,630 21,160 19,690 18,210 15,340 12,640 11,390
BZ*025M6 ZS19K4E 26,730 25,070 23,390 21,700 18,380 15,230 13,750
BZ*030M6 ZS21K4E 32,760 30,580 28,360 26,170 21,900 17,950 16,140
BZ*035M6 ZS26K4E 39,310 36,730 34,130 31,560 26,540 21,850 19,690
BZ*045M6 ZS30K4E 46,490 43,050 39,760 36,560 30,480 24,890 22,310
BZ*055M6 ZS38K4E 53,990 50,410 46,970 43,530 36,770 30,380 27,400
BZ*060M6 ZS45K4E 61,960 58,120 54,430 50,680 43,160 35,890 32,490
R-404A/507
Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
35°F 30°F 25°F 20°F 10°F 0°F -5°F
BZ*020M6 ZS15K4E 21,760 20,350 18,930 17,510 14,750 12,150 10,950
BZ*025M6 ZS19K4E 25,700 24,110 22,490 20,870 17,670 14,640 11,790
BZ*030M6 ZS21K4E 31,500 29,400 27,270 25,160 21,060 17,260 15,520
BZ*035M6 ZS26K4E 37,800 35,320 32,820 30,350 25,520 21,010 18,930
BZ*045M6 ZS30K4E 44,700 41,390 38,230 35,150 29,310 23,930 21,450
BZ*055M6 ZS38K4E 51,910 48,470 45,160 41,860 35,360 29,210 26,350
BZ*060M6 ZS45K4E 59,580 55,880 52,340 48,730 41,500 34,510 31,240
R-404A/507
Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
35°F 30°F 25°F 20°F 10°F 0°F -5°F
BZ*020M6 ZS15K4E 20,890 19,540 18,170 16,810 14,160 11,660 10,510
BZ*025M6 ZS19K4E 24,670 23,150 21,590 20,040 16,960 14,050 12,690
BZ*030M6 ZS21K4E 30,240 28,220 26,180 24,150 20,220 16,570 14,900
BZ*035M6 ZS26K4E 36,290 33,910 31,510 29,140 24,500 20,170 18,170
BZ*045M6 ZS30K4E 42,910 39,730 36,700 33,740 28,140 22,970 20,590
BZ*055M6 ZS38K4E 49,830 46,530 43,350 40,190 33,950 28,040 25,300
BZ*060M6 ZS45K4E 57,200 53,640 50,250 46,780 39,840 33,130 29,990
R-404A/507
Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
35°F 30°F 25°F 20°F 10°F 0°F -5°F
BZ*020M6 ZS15K4E 19,150 17,910 16,660 15,410 12,980 10,690 9,640
BZ*025M6 ZS19K4E 22,620 21,220 19,760 18,370 15,550 14,190 11,630
BZ*030M6 ZS21K4E 27,720 25,870 24,000 22,140 18,530 15,190 13,660
BZ*035M6 ZS26K4E 33,260 31,080 28,880 26,710 22,460 18,490 16,660
BZ*045M6 ZS30K4E 39,340 36,420 33,640 30,930 25,790 21,060 18,880
BZ*055M6 ZS38K4E 45,680 42,650 39,740 36,840 31,120 25,700 23,190
BZ*060M6 ZS45K4E - 49,170 46,060 42,880 36,520 30,370 27,490

10
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
NOTE: The ZF compressor comes with liquid injection.
SCROLL COMPRESSORS
Performance Data - Low Temperature (R-404A/507)
R-404A/507
Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BZ*020L6 ZF06K4E 11,970 9,920 8,940 8,010 7,130 6,310 4,900
BZ*025L6 ZF08K4E 14,880 12,320 11,120 9,960 8,890 7,900 6,230
BZ*030L6 ZF09K4E 16,540 13,730 12,400 11,130 9,930 8,840 6,980
BZ*035L6 ZF11K4E 19,800 16,490 14,910 13,420 12,000 10,710 8,530
BZ*045L6 ZF13K4E 24,720 20,360 18,300 16,410 14,570 12,840 9,800
BZ*055L6 ZF15K4E 29,950 24,730 22,260 20,010 17,820 15,800 12,440
BZ*060L6 ZF18K4E 36,360 30,140 27,160 24,330 21,680 19,240 15,100
R-404A/507
Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BZ*020L6 ZF06K4E 11,510 9,540 8,600 7,700 6,860 6,070 4,710
BZ*025L6 ZF08K4E 14,310 11,850 10,690 9,580 8,550 7,600 5,990
BZ*030L6 ZF09K4E 15,900 13,200 11,920 10,700 9,550 8,500 6,710
BZ*035L6 ZF11K4E 19,040 15,860 14,340 12,900 11,540 10,300 8,200
BZ*045L6 ZF13K4E 23,740 19,490 17,590 15,690 13,880 12,210 9,360
BZ*055L6 ZF15K4E 28,870 23,820 21,550 19,260 17,390 15,160 11,910
BZ*060L6 ZF18K4E 34,960 28,970 26,120 23,390 20,850 18,500 14,520
R-404A/507
Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BZ*020L6 ZF06K4E 11,050 9,160 8,260 7,390 6,590 5,830 4,520
BZ*025L6 ZF08K4E 13,740 11,380 10,260 9,200 8,210 7,300 5,750
BZ*030L6 ZF09K4E 15,260 12,670 11,440 10,270 9,170 8,160 6,440
BZ*035L6 ZF11K4E 18,280 15,230 13,770 12,380 11,080 9,890 7,870
BZ*045L6 ZF13K4E 22,780 18,740 16,770 14,910 13,180 11,780 8,890
BZ*055L6 ZF15K4E 27,800 23,060 20,700 18,490 16,980 14,770 11,390
BZ*060L6 ZF18K4E 33,560 27,810 25,080 22,450 20,010 17,760 13,950
R-404A/507
Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BZ*020L6 ZF06K4E 10,130 8,400 7,570 6,780 6,040 5,340 4,140
BZ*025L6 ZF08K4E 12,590 10,430 9,410 8,430 7,520 6,690 5,270
BZ*030L6 ZF09K4E 13,990 11,620 10,490 9,420 8,400 7,480 5,900
BZ*035L6 ZF11K4E 16,760 13,960 12,620 11,350 10,160 9,060 7,220
BZ*045L6 ZF13K4E 20,980 16,960 15,120 13,390 11,790 10,910 8,460
BZ*055L6 ZF15K4E 25,790 21,200 19,030 16,980 15,100 14,000 10,340
BZ*060L6 ZF18K4E 30,770 25,490 22,990 20,580 18,340 16,270 12,780

11
SCROLL COMPRESSORS
Performance Data - Medium Temperature (R-22)
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
R-22 Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
35°F 30°F 25°F 20°F 10°F
BZ*020M6 ZS15K4E 22,080 20,420 18,800 17,220 14,260
BZ*025M6 ZS19K4E 26,080 24,190 22,340 20,530 17,090
BZ*030M6 ZS21K4E 31,970 29,490 27,080 24,750 20,360
BZ*035M6 ZS26K4E 38,930 35,820 32,830 29,970 24,520
BZ*045M6 ZS30K4E 45,920 42,010 38,300 34,810 28,450
BZ*055M6 ZS38K4E 54,050 49,950 45,960 42,100 34,600
BZ*060M6 ZS45K4E 63,670 58,960 54,320 49,800 41,190
R-22 Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
35°F 30°F 25°F 20°F 10°F
BZ*020M6 ZS15K4E 21,230 19,630 18,080 16,560 13,710
BZ*025M6 ZS19K4E 25,080 23,260 21,480 19,740 16,430
BZ*030M6 ZS21K4E 30,740 28,360 26,040 23,800 19,580
BZ*035M6 ZS26K4E 37,430 34,440 31,570 28,820 23,580
BZ*045M6 ZS30K4E 44,150 40,390 36,830 33,470 27,360
BZ*055M6 ZS38K4E 51,970 48,030 44,190 40,480 33,270
BZ*060M6 ZS45K4E 61,220 56,690 52,230 47,880 39,610
R-22 Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
35°F 30°F 25°F 20°F 10°F
BZ*020M6 ZS15K4E 20,380 18,850 17,360 15,900 13,160
BZ*025M6 ZS19K4E 24,080 22,330 20,620 18,950 15,770
BZ*030M6 ZS21K4E 29,510 27,230 25,000 22,850 18,800
BZ*035M6 ZS26K4E 35,930 33,060 30,310 27,670 22,640
BZ*045M6 ZS30K4E 42,380 38,770 35,360 32,130 26,270
BZ*055M6 ZS38K4E 49,890 46,110 42,420 38,860 31,940
BZ*060M6 ZS45K4E 58,770 54,420 50,140 45,970 38,030
R-22 Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
35°F 30°F 25°F 20°F 10°F
BZ*020M6 ZS15K4E 19,530 18,060 16,630 15,240 12,610
BZ*025M6 ZS19K4E 23,070 21,400 19,760 18,160 15,120
BZ*030M6 ZS21K4E 28,280 26,090 23,960 21,900 18,010
BZ*035M6 ZS26K4E 34,440 31,690 29,040 26,510 21,690
BZ*045M6 ZS30K4E 40,620 37,160 33,880 30,790 25,170
BZ*055M6 ZS38K4E 47,810 44,190 40,660 37,240 30,610
BZ*060M6 ZS45K4E 56,320 52,160 48,050 44,050 36,440

12
SCROLL COMPRESSORS
Performance Data - Low Temperature (R-22)
R-22 Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BZ*020L6 ZF06K4E 11,610 9,400 8,380 7,450 6,590 5,840 4,590
BZ*025L6 ZF08K4E 14,560 11,800 10,540 9,380 8,310 7,340 5,780
BZ*030L6 ZF09K4E 15,940 13,070 11,750 10,500 9,340 8,260 6,460
BZ*035L6 ZF11K4E 19,310 15,870 14,270 12,760 11,360 10,080 7,900
BZ*045L6 ZF13K4E 23,490 19,140 17,140 15,280 13,560 12,000 9,400
BZ*055L6 ZF15K4E 28,800 23,490 21,050 18,770 16,360 14,750 11,550
BZ*060L6 ZF18K4E 33,800 27,550 24,670 21,970 19,480 17,220 13,440
R-22 Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BZ*020L6 ZF06K4E 11,060 8,950 7,980 7,090 6,280 5,560 4,370
BZ*025L6 ZF08K4E 13,870 11,240 10,040 8,930 7,910 6,990 5,500
BZ*030L6 ZF09K4E 15,180 12,450 11,190 10,000 8,890 7,870 6,150
BZ*035L6 ZF11K4E 18,390 15,110 13,590 12,150 10,820 9,600 7,520
BZ*045L6 ZF13K4E 22,370 18,230 16,320 14,550 12,910 11,430 8,950
BZ*055L6 ZF15K4E 27,430 22,370 20,050 17,880 15,580 14,050 11,000
BZ*060L6 ZF18K4E 32,190 26,240 23,490 20,920 18,550 16,400 12,800
R-22 Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BZ*020L6 ZF06K4E 10,840 8,770 7,820 6,950 6,150 5,450 4,280
BZ*025L6 ZF08K4E 13,590 11,020 9,840 8,750 7,750 6,850 5,390
BZ*030L6 ZF09K4E 14,880 12,200 10,970 9,800 8,710 7,710 6,030
BZ*035L6 ZF11K4E 18,020 14,810 13,320 11,910 10,600 9,410 7,370
BZ*045L6 ZF13K4E 21,920 17,870 15,990 14,260 12,650 11,200 8,770
BZ*055L6 ZF15K4E 26,880 21,920 19,650 17,520 15,270 13,770 10,780
BZ*060L6 ZF18K4E 31,550 25,720 23,020 20,500 18,180 16,070 12,540
R-22 Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BZ*020L6 ZF06K4E 10,290 8,320 7,420 6,590 5,840 5,170 4,060
BZ*025L6 ZF08K4E 12,900 10,450 9,340 8,310 7,360 6,500 5,120
BZ*030L6 ZF09K4E 14,120 11,580 10,410 9,300 8,270 7,320 5,720
BZ*035L6 ZF11K4E 17,100 14,050 12,640 11,300 10,060 8,930 6,990
BZ*045L6 ZF13K4E 20,800 16,950 15,180 13,530 12,010 10,630 8,320
BZ*055L6 ZF15K4E 25,510 20,800 18,650 16,630 14,490 13,070 10,230
BZ*060L6 ZF18K4E 29,940 24,400 21,850 19,460 17,250 15,250 11,900
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
NOTE: The ZF compressor comes with liquid injection.

13
SCROLL COMPRESSORS - Electrical Data
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
Per UL and NEC, RLA values have been calculated by dividing the Maximum Continuous Current (MCC) by 1.56.
^ Power supplied by customer.
† Consult factory for 50 HZ applications.
SCROLL COMPRESSORS
Unit Specifications
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
++ = See Dimensional Drawings for details. †= Estimated sound pressure values are 10 feet from the unit. For estimating sound pressure from the unit at dierent
distances, deduct the following from the unit values: 20 feet, deduct 6 dBA for 40 feet, deduct 12 dBA for 80 feet, deduct 18 dBA. This data is typical of “free eld”
conditions for horizontal air cooled condensing units at the outlet of the discharge air. The actual sound measurements may vary depending on the condensing
unit installation. Factors such as reecting walls, background noise and mounting conditions may have a signicant inuence on this data.
Model
Number Part Number
Power Supply Compressor Fan Motor MCA MOPD Evap.
Fan
Amps
Defrost
Heater
Amps
Volts Ph Hz†RLA LRA Qty. HP FLA Air Elec. Air Elec.
BZ*020M6B ZS15K4E-PFV 208-230 1 60 12.2 61.0 2 1/15 1.0 20 38 25 40 12 30
BZ*020M6C ZS15K4E-TF5 208-230 3 60 8.3 55.0 2 1/15 1.0 15 24 15 25 9 19
BZ*020M6D ZS15K4E-TFD 460 3 60 3.8 27.0 2 1/15 1.0 15 24 15 25 ^ ^
BZ*025M6B ZS19K4E-PFV 208-230 1 60 14.7 73.0 2 1/15 1.0 20 38 30 45 12 30
BZ*025M6C ZS19K4E-TF5 208-230 3 60 8.7 63.0 2 1/15 1.0 15 29 20 30 11 23
BZ*025M6D ZS19K4E-TFD 460 3 60 4.5 31.0 2 1/15 1.0 15 24 15 25 ^ ^
BZ*030M6B ZS21K4E-PFV 208-230 1 60 14.7 88.0 1 1/3 3.5 22 38 35 45 12 30
BZ*030M6C ZS21K4E-TF5 208-230 3 60 9.9 77.0 1 1/3 3.5 20 38 25 40 12 30
BZ*030M6D ZS21K4E-TFD 460 3 60 5.1 39.0 1 1/3 1.9 15 24 15 25 ^ ^
BZ*035M6B ZS26K4E-PFV 208-230 1 60 18.6 109.0 1 1/3 3.5 27 39 45 50 12 30
BZ*035M6C ZS26K4E-TF5 208-230 3 60 12.2 88.0 1 1/3 3.5 20 38 30 40 12 30
BZ*035M6D ZS26K4E-TFD 460 3 60 6.4 44.0 1 1/3 1.9 15 24 15 25 ^ ^
BZ*045M6B ZS30K4E-PFV 208-230 1 60 24.0 129.0 1 1/3 3.5 34 59 50 60 11 47
BZ*045M6C ZS30K4E-TF5 208-230 3 60 13.5 99.0 1 1/3 3.5 20 44 30 45 12 35
BZ*045M6D ZS30K4E-TFD 460 3 60 7.4 49.5 1 1/3 1.9 15 29 15 30 11 23
BZ*055M6B ZS38K4E-PFV 208-230 1 60 28.8 169.0 1 1/3 3.5 40 59 50 60 12 47
BZ*055M6C ZS38K4E-TF5 208-230 3 60 19.2 123.0 1 1/3 3.5 28 44 45 50 12 35
BZ*055M6D ZS38K4E-TFD 460 3 60 8.7 62.0 1 1/3 1.9 15 29 20 30 10 23
BZ*060M6C ZS45K4E-TF5 208-230 3 60 21.5 156.0 1 1/3 3.5 30 44 50 60 12 35
BZ*060M6D ZS45K4E-TFD 460 3 60 8.3 70.0 1 1/3 1.9 15 29 20 30 10.6 23
BZ*020L6B ZF06K4E-PFV 208-230 1 60 12.2 61.0 2 1/15 1.0 20 38 25 40 12 30
BZ*020L6C ZF06K4E-TF5 208-230 3 60 8.3 55.0 2 1/15 1.0 15 24 15 25 9 19
BZ*020L6D ZF06K4E-TFD 460 3 60 3.8 27.0 2 1/15 1.0 15 24 15 25 ^ ^
BZ*025L6B ZF08K4E-PFV 208-230 1 60 14.7 73.0 2 1/15 1.0 20 38 30 45 12 30
BZ*025L6C ZF08K4E-TF5 208-230 3 60 8.7 63.0 2 1/15 1.0 15 29 20 30 11 23
BZ*025L6D ZF08K4E-TFD 460 3 60 4.5 31.0 2 1/15 1.0 15 24 15 25 ^ ^
BZ*030L6B ZF09K4E-PFV 208-230 1 60 14.7 88.0 2 1/15 1.0 20 38 30 45 12 30
BZ*030L6C ZF09K4E-TF5 208-230 3 60 9.9 77.0 2 1/15 1.0 15 24 20 25 6 19
BZ*030L6D ZF09K4E-TFD 460 3 60 5.1 39.0 2 1/15 1.0 15 15 15 15 ^ ^
BZ*035L6B ZF11K4E-PFV 208-230 1 60 18.6 109.0 2 1/15 1.0 24 38 40 50 12 30
BZ*035L6C ZF11K4E-TF5 208-230 3 60 12.2 88.0 2 1/15 1.0 20 29 25 30 6 23
BZ*035L6D ZF11K4E-TFD 460 3 60 6.4 44.0 2 1/15 1.0 15 15 15 15 ^ ^
BZ*045L6B ZF13K4E-PFV 208-230 1 60 24.0 129.0 1 1/3 3.5 34 45 50 60 11 30
BZ*045L6C ZF13K4E-TF5 208-230 3 60 13.5 99.0 1 1/3 3.5 20 38 30 40 11 30
BZ*045L6D ZF13K4E-TFD 460 3 60 7.4 49.5 1 1/3 1.9 15 24 15 25 9 19
BZ*055L6B ZF15K4E-PFV 208-230 1 60 28.8 169.0 1 1/3 3.5 40 50 50 60 10 30
BZ*055L6C ZF15K4E-TF5 208-230 3 60 19.2 123.0 1 1/3 3.5 28 40 45 50 10 30
BZ*055L6D ZF15K4E-TFD 460 3 60 8.7 62.0 1 1/3 1.9 15 24 20 25 8 19
BZ*060L6C ZF18K4E-TF5 208-230 3 60 21.5 156.0 1 1/3 3.5 30 44 50 60 12 35
BZ*060L6D ZF18K4E-TFD 460 3 60 8.3 70.0 1 1/3 1.9 15 29 20 30 11 23
Model Fig. ++ Compressor Connections (ID) Receiver 90% Full
Lbs.
Fan(s) Dimensions Net Wt.
Lbs.
Sound
Data dBA†
Liquid Suction D (In.) W (In.) H (In.)
BZ*020M6 C ZS15K4E 1/2 7/8 14 2 28.25 37.75 19.75 209 71
BZ*025M6 C ZS19K4E 1/2 7/8 14 2 28.25 37.75 19.75 218 73
BZ*030M6 D ZS21K4E 1/2 7/8 20 1 30.25 42.5 29.75 287 72
BZ*035M6 D ZS26K4E 1/2 7/8 20 1 30.25 42.5 29.75 290 74
BZ*045M6 D ZS30K4E 1/2 1-1/8 20 1 30.25 42.5 29.75 317 73
BZ*055M6 D ZS38K4E 1/2 1-1/8 20 1 30.25 42.5 29.75 317 74
BZ*060M6 D ZS45K43 1/2 1-1/8 20 1 30.25 42.5 29.75 317 76
BZ*020L6 C ZF06K4E 1/2 7/8 14 2 28.25 37.75 19.75 209 71
BZ*025L6 C ZF08K4E 1/2 7/8 14 2 28.25 37.75 19.75 218 73
BZ*030L6 C ZF09K4E 1/2 7/8 14 2 28.25 37.75 19.75 218 71
BZ*035L6 C ZF11K4E 1/2 7/8 14 2 28.25 37.75 19.75 217 73
BZ*045L6 D ZF13K4E 1/2 1-1/8 20 1 30.25 42.5 29.75 307 73
BZ*055L6 D ZF15K4E 1/2 1-1/8 20 1 30.25 42.5 29.75 313 74
BZ*060L6 D ZF18K4E 1/2 1-1/8 20 1 30.25 42.5 29.75 317 76

14
SEMI-HERMETIC COMPRESSORS
Performance Data - Medium and High Temperature (R-22)
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
R-22 Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
40°F 30°F 25°F 20°F 10°F 0°F
BS*005H2 HAG-0050 5,630 4,710 4,280 3,640 2,830 –
BS*008H2 KAN-0075 8,840 7,310 6,630 5,990 4,430 –
BS*008M2 KAE-0075 – – 7,510 6,780 5,510 4,250
BS*010H2 KAR-0100 12,410 10,260 9,260 8,300 6,570 –
BS*010M2 KAM-0100 – – 9,580 8,630 6,840 5,140
BS*015H2 KAG-0150 16,340 13,350 12,230 11,000 8,770 –
BS*020H2 ERA-0200 21,310 15,900 13,700 11,500 7,220 –
BS*020M2 KAK-0200 – – 16,530 14,910 11,970 9,500
BS*021M2 ERC-0200 – – 17,640 16,010 13,000 10,430
BS*029M2 ERF-0310 – – 24,720 22,400 18,200 14,760
BS*030H2 ERF-0310 35,640 29,630 26,800 24,130 19,380 –
BS*030M2 3RA-0310 – – 32,290 29,330 23,910 19,430
BS*040H2 NRB-0400 49,860 41,700 37,830 34,160 25,000 –
BS*050H2 NRA-0500 56,500 47,720 43,310 39,360 29,700 –
BS*050M2 NRM-0500 – – 51,590 46,900 38,280 31,150
R-22 Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
40°F 30°F 25°F 20°F 10°F 0°F
BS*005H2 HAG-0050 5,380 4,500 4,080 3,470 2,690 –
BS*008H2 KAN-0075 8,520 7,030 6,370 5,750 4,230 –
BS*008M2 KAE-0075 – – 7,190 6,470 5,250 4,270
BS*010H2 KAR-0100 11,910 9,850 8,890 7,970 6,310 –
BS*010M2 KAM-0100 – – 9,240 8,310 6,570 4,910
BS*015H2 KAG-0150 15,690 12,820 11,740 10,560 8,420 –
BS*020H2 ERA-0200 19,300 15,000 12,900 10,800 6,540 –
BS*020M2 KAK-0200 – – 15,870 14,310 11,490 9,120
BS*021M2 ERC-0200 – – 16,930 15,370 12,480 10,010
BS*029M2 ERF-0310 – – 23,850 21,610 17,530 14,200
BS*030H2 ERF-0310 34,210 28,450 25,720 23,160 18,600 –
BS*030M2 3RA-0310 – – 31,000 28,150 22,950 18,660
BS*040H2 NRB-0400 48,150 40,240 36,480 32,810 23,900 –
BS*050H2 NRA-0500 54,570 45,950 41,820 37,850 28,400 –
BS*050M2 NRM-0500 – – 49,530 45,020 36,750 29,910
R-22 Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
40°F 30°F 25°F 20°F 10°F 0°F
BS*005H2 HAG-0050 4,920 4,080 3,700 3,160 2,440 –
BS*008H2 KAN-0075 7,860 6,470 5,860 5,280 3,840 –
BS*008M2 KAE-0075 – – 6,480 5,860 4,760 3,840
BS*010H2 KAR-0100 10,920 9,030 8,150 7,300 5,780 –
BS*010M2 KAM-0100 – – 8,530 7,670 6,030 4,430
BS*015H2 KAG-0150 14,380 11,750 10,760 9,680 7,720 –
BS*020H2 ERA-0200 17,200 13,400 11,500 9,540 5,510 –
BS*020M2 KAK-0200 – – 14,550 13,120 10,530 8,360
BS*021M2 ERC-0200 – – 15,520 14,090 11,440 9,180
BS*029M2 ERF-0310 – – 22,150 20,040 16,210 13,080
BS*030H2 ERF-0310 31,370 26,070 23,580 21,240 17,050 –
BS*030M2 3RA-0310 – – 28,420 25,810 21,040 17,100
BS*040H2 NRB-0400 44,540 37,140 33,660 30,330 21,900 –
BS*050H2 NRA-0500 50,440 42,210 38,540 34,690 26,100 –
BS*050M2 NRM-0500 – – 45,400 41,270 33,690 27,420
R-22 Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
40°F 30°F 25°F 20°F 10°F 0°F
BS*005H2 HAG-0050 5,930 4,920 4,470 3,810 2,970 –
BS*008H2 KAN-0075 9,110 7,630 6,900 6,230 4,640 –
BS*008M2 KAE-0075 – – 7,850 7,110 5,770 4,420
BS*010H2 KAR-0100 12,910 10,670 9,630 8,630 6,830 –
BS*010M2 KAM-0100 – – 9,920 8,950 7,110 5,370
BS*015H2 KAG-0150 16,990 13,880 12,720 11,440 9,120 –
BS*020H2 ERA-0200 22,270 16,800 14,500 12,300 7,970 –
BS*020M2 KAK-0200 – – 17,190 15,510 12,450 9,880
BS*021M2 ERC-0200 – – 18,350 16,650 13,520 10,850
BS*029M2 ERF-0310 – – 25,570 23,190 18,860 15,330
BS*030H2 ERF-0310 37,070 30,820 27,870 25,100 20,160 –
BS*030M2 3RA-0310 – – 33,580 30,500 24,870 20,210
BS*040H2 NRB-0400 51,530 43,040 39,170 35,390 26,300 –
BS*050H2 NRA-0500 58,700 49,500 44,950 40,860 31,000 –
BS*050M2 NRM-0500 – – 53,650 48,780 39,810 32,400

15
SEMI-HERMETIC COMPRESSORS
Performance Data - Medium Temperature (R-404A/507)
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
R-404A/507
Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
25°F 20°F 15°F 10°F 5°F 0°F -5°F
BS*010M6 KAR-010E 9,680 8,730 7,930 7,260 6,500 5,890 5,000
BS*020M6 KAK-020E 16,890 15,110 13,590 12,260 11,070 9,940 8,690
BS*021M6 ERC-021E 19,930 17,400 15,800 14,300 12,800 11,840 10,220
BS*030M6 ERF-031E 30,880 28,310 25,730 23,180 20,690 18,260 15,950
BS*040M6 NRB-040E 40,810 37,350 33,810 30,250 26,730 23,250 19,900
R-404A/507
Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
25°F 20°F 15°F 10°F 5°F 0°F -5°F
BS*010M6 KAR-010E 9,140 8,300 7,600 6,870 6,150 5,550 4,730
BS*020M6 KAK-020E 16,240 14,530 13,070 11,790 10,640 9,560 8,360
BS*021M6 ERC-021E 18,850 16,500 14,900 13,500 12,700 11,140 9,580
BS*030M6 ERF-031E 29,690 27,220 24,740 22,290 19,890 17,560 15,340
BS*040M6 NRB-040E 39,240 35,910 32,510 29,090 25,700 22,360 19,130
R-404A/507
Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
25°F 20°F 15°F 10°F 5°F 0°F -5°F
BS*010M6 KAR-010E 8,680 7,950 7,110 6,410 5,780 5,220 4,450
BS*020M6 KAK-020E 15,590 13,950 12,550 11,320 10,210 9,180 8,030
BS*021M6 ERC-021E 17,840 16,280 14,870 13,440 11,970 10,450 8,940
BS*030M6 ERF-031E 28,500 26,130 23,750 21,400 19,090 16,860 14,730
BS*040M6 NRB-040E 37,670 34,470 31,210 27,930 24,670 21,470 18,360
R-404A/507
Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
25°F 20°F 15°F 10°F 5°F 0°F -5°F
BS*010M6 KAR-010E 7,740 7,000 6,350 5,720 5,120 4,600 3,900
BS*020M6 KAK-020E 14,290 12,790 11,500 10,380 9,360 8,410 7,360
BS*021M6 ERC-021E 15,840 14,610 12,600 11,850 10,470 9,180 7,770
BS*030M6 ERF-031E 26,130 23,950 21,770 19,620 17,500 15,450 13,500
BS*040M6 NRB-040E 34,530 31,600 28,610 25,600 22,620 19,680 16,830

16
SEMI-HERMETIC COMPRESSORS
Performance Data - Low Temperature (R-404A/507)
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
^ NRD1-040E Compressor is Single Phase & uses R-404A only.
^^ Uses R-404A & 507 in 3 phase model.
R-404A/507
Model Compressor Capacity BTUH @ 90°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BS*010L6 KAJ-010E 7,770 6,990 6,240 4,830 4,190 3,610 2,640
BS*015L6 KAL-015E 11,780 10,600 9,470 7,340 6,370 5,500 4,020
BS*020L6 EAD-020E 13,780 12,290 10,860 8,260 7,120 6,100 4,470
BS*021L6 EAV-021E 15,120 13,660 12,200 9,420 8,140 6,980 5,160
BS*027L6 3AB-031E 17,670 15,860 14,110 10,870 9,420 8,100 5,940
BS*030L6 LAH-032E 22,600 20,320 18,090 13,810 11,830 9,970 6,780
BS*030E6 LAC-032E – – – 16,780 14,570 12,540 9,010
BS*040L6 NRD-040E^
NRD-032E^^ 29,660 26,750 23,910 18,490 15,980 13,640 9,480
R-404A/507
Model Compressor Capacity BTUH @ 95°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BS*010L6 KAJ-010E 7,220 6,480 5,790 4,520 3,940 3,390 2,440
BS*015L6 KAL-015E 10,960 9,930 8,920 6,990 6,110 5,300 3,930
BS*020L6 EAD-020E 12,530 11,160 9,870 7,520 6,490 5,560 3,980
BS*021L6 EAV-021E 13,920 12,600 11,280 8,780 7,610 6,520 4,590
BS*027L6 3AB-031E 16,640 14,890 13,210 10,100 8,710 7,450 5,420
BS*030L6 LAH-032E 21,310 19,100 16,930 12,800 10,880 9,100 6,040
BS*030E6 LAC-032E – – – 15,700 13,550 11,580 8,270
BS*040L6 NRD-040E^
NRD-032E^^ 28,090 25,280 22,530 17,300 14,860 12,590 8,630
R-404A/507
Model Compressor Capacity BTUH @ 100°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BS*010L6 KAJ-010E 6,900 6,180 5,470 4,160 3,570 3,030 2,150
BS*015L6 KAL-015E 10,520 9,460 8,410 6,440 5,540 4,700 3,300
BS*020L6 EAD-020E 12,140 10,730 9,400 6,970 5,920 4,980 3,530
BS*021L6 EAV-021E 13,390 12,110 10,810 8,260 7,060 5,940 4,050
BS*027L6 3AB-031E 15,620 13,940 12,320 9,330 8,000 6,800 4,900
BS*030L6 LAH-032E 20,020 17,890 15,790 11,790 9,940 8,230 5,300
BS*030E6 LAC-032E – – – 14,630 12,530 10,640 7,540
BS*040L6 NRD-040E^
NRD-032E^^ 26,520 23,810 21,160 16,100 13,750 11,560 7,720
R-404A/507
Model Compressor Capacity BTUH @ 110°F Ambient Suction Temperature
0°F -10°F -15°F -20°F -25°F -30°F -40°F
BS*010L6 KAJ-010E 6,040 5,370 4,720 3,510 2960 2,470 1,660
BS*015L6 KAL-015E 9,290 8,320 7,370 5,560 4,710 3,930 2,580
BS*020L6 EAD-020E 10,510 9,210 7,950 6,000 4,720 3,880 2,610
BS*021L6 EAV-021E 11,670 10,570 9,450 7,130 5,990 4,900 2,950
BS*027L6 3AB-031E 13,590 12,040 10,540 7,800 6,590 5,520 3,870
BS*030L6 LAH-032E 17,480 15,490 13,530 9,800 8,080 6,490 3,750
BS*030E6 LAC-032E – – – 12,510 10,510 8,760 6,090
BS*040L6 NRD-040E^
NRD-032E^^ 23,410 20,900 18,440 13,740 11,550 9,500 5,880

17
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
++ = See Dimensional Drawings for details.
†= Estimated sound pressure values are 10 feet from the unit. For estimating sound pressure from the unit at
dierent distances, deduct the following from the unit values: 20 feet, deduct 6 dBA for 40 feet, deduct 12 dBA
for 80 feet, deduct 18 dBA. This data is typical of “free eld” conditions for horizontal air cooled condensing units
at the outlet of the discharge air. The actual sound measurements may vary depending on the condensing unit
installation. Factors such as reecting walls, background noise and mounting conditions may have a signicant
inuence on this data.
SEMI-HERMETIC COMPRESSORS
Unit Specifications
Model Fig. ++ Compressor Connections (ID) Receiver 90% Full
Lbs.
Fan(s) Dimensions Net Wt.
Lbs.
Sound
Data dBA†
Liquid Suction D (In.) W (In.) H (In.)
BS*005H2 A HAG-0050 3/8 1/2 6.0 1 28.25 23.75 17.25 161 66
BS*008H2 A KAN-0075 3/8 5/8 6.0 1 28.25 23.75 17.25 180 66
BS*008M2 A KAE-0075 3/8 5/8 6.0 1 28.25 23.75 17.25 180 66
BS*010H2 A KAR-0100 3/8 5/8 6.0 1 28.25 23.75 17.25 175 66
BS*010M2 A KAM-0100 3/8 5/8 6.0 1 28.25 23.75 17.25 178 66
BS*015H2 B KAG-0150 3/8 7/8 10.0 2 28.25 37.75 17.25 221 69
BS*020H2 B ERA-0200 3/8 7/8 10.0 2 28.25 37.75 17.25 293 69
BS*020M2 B KAK-0200 3/8 7/8 10.0 2 28.25 37.75 17.25 189 69
BS*021M2 B ERC-0200 3/8 7/8 10.0 2 28.25 37.75 17.25 301 69
BS*029M2 C ERF-0310 1/2 7/8 16.0 2 28.25 37.75 19.75 391 69
BS*030H2 D ERF-0310 1/2 7/8 22.0 1 30.25 42.5 29.75 385 70
BS*030M2 D 3RA-0310 1/2 7/8 22.0 1 30.25 42.5 29.75 397 71
BS*040H2 D NRB-0400 1/2 1-1/8 22.0 1 30.25 42.5 29.75 460 71
BS*050H2 D NRA-0500 1/2 1-1/8 22.0 1 30.25 42.5 29.75 462 71
BS*050M2 D NRM-0500 1/2 1-1/8 22.0 1 30.25 42.5 29.75 462 71
BS*010M6 A KAR-010E 3/8 5/8 5.5 1 28.25 23.75 17.25 178 67
BS*020M6 B KAK-020E 3/8 7/8 9.0 2 28.25 37.75 17.25 189 69
BS*021M6 B ERC-021E 3/8 7/8 9.0 2 28.25 37.75 17.25 301 70
BS*030M6 D ERF-031E 1/2 7/8 20.0 1 30.25 42.5 29.75 397 71
BS*040M6 D NRB-040E 1/2 1-1/8 20.0 1 30.25 42.5 29.75 460 73
BS*010L6 A KAJ-010E 3/8 5/8 5.5 1 28.25 23.75 17.25 178 67
BS*015L6 B KAL-015E 3/8 7/8 9.0 2 28.25 37.75 17.25 225 69
BS*020L6 B EAD-020E 3/8 7/8 9.0 2 28.25 37.75 17.25 291 70
BS*021L6 B EAV-021E 3/8 7/8 9.0 2 28.25 37.75 17.25 301 70
BS*027L6 C 3AB-031E 1/2 7/8 14.0 2 28.25 37.75 19.75 391 71
BS*030L6 C LAH-032E 1/2 7/8 14.0 2 28.25 37.75 19.75 357 71
BS*030E6 C LAC-032E 1/2 7/8 14.0 2 28.25 37.75 19.75 391 71
BS*040L6 D NRD-032/040E 1/2 1-1/8 20.0 1 30.25 42.5 29.75 457 73

18
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
^ Power supplied by customer.
† Consult factory for 50 HZ applications.
SEMI-HERMETIC COMPRESSORS
Electrical Data - Medium and High Temperature
Model
Number Part Number Power Supply Compressor Fan Motor MCA MOPD Evap.
Fan
Amps
Defrost
Heater
Amps
Volts Ph Hz†RLA LRA Qty. HP FLA Air Elec. Air Elec.
BS*005H2B HAG2-0050-CAV 208-230 1 60 3.6 22.0 1 1/15 0.5 15 20 15 20 9 15
BS*005H2C HAG1-0050-TAC 208-230 3 60 2.1 13.0 1 1/15 0.5 15 20 15 20 9.5 15
BS*008H2B KAN2-0075-CAV 208-230 1 60 5.4 36.0 1 1/15 0.5 15 20 15 20 8 15
BS*008H2C KAN1-0075-TAC 208-230 3 60 3.1 19.9 1 1/15 0.5 15 20 15 20 9 15
BS*008M2B KAE2-0075-CAV 208-230 1 60 4.9 36.0 1 1/15 0.5 15 20 15 20 8 15
BS*008M2C KAE1-0075-TAC 208-230 3 60 3.0 19.9 1 1/15 0.5 15 20 15 20 9 15
BS*010H2B KAR2-0100-CAV 208-230 1 60 6.6 40.0 1 1/15 0.5 15 20 15 20 7 15
BS*010H2C KAR1-0100-TAC 208-230 3 60 3.8 27.0 1 1/15 0.5 15 20 15 20 9 15
BS*010M2B KAM2-0100-CAV 208-230 1 60 6.7 40.0 1 1/15 0.5 15 20 15 20 7 15
BS*010M2C KAM1-0100-TAC 208-230 3 60 4.0 27.0 1 1/15 0.5 15 20 15 20 9 15
BS*015H2B KAGB-0150-CAV 208-230 1 60 8.6 55.0 2 1/15 1.0 15 24 20 25 9 19
BS*015H2C KAGA-0150-TAC 208-230 3 60 4.9 35.5 2 1/15 1.0 15 20 15 20 8 15
BS*015H2D KAGA-0150-TAD 460 3 60 2.2 18.2 2 1/15 1.0 15 20 15 20 ^ ^
BS*020H2G ERA2-0200-CAB 230 1 60 9.3 58.0 2 1/15 1.0 15 24 20 25 6 19
BS*020H2C ERA1-0200-TAC 208-230 3 60 5.9 46.0 2 1/15 1.0 15 24 15 25 9 19
BS*020H2D ERA1-0200-TAD 460 3 60 3.1 46.0 2 1/15 1.0 15 20 15 20 ^ ^
BS*020M2B KAKB-0200-CAV 208-230 1 60 9.5 55.0 2 1/15 1.0 15 24 20 25 6 19
BS*020M2C KAKA-0200-TAC 208-230 3 60 6.1 50.0 2 1/15 1.0 15 24 15 25 9 19
BS*021M2G ERC2-0200-CAB 230 1 60 9.7 58.0 2 1/15 1.0 15 24 20 25 6 19
BS*021M2C ERC1-0200-TAC 208-230 3 60 6.1 46.0 2 1/15 1.0 15 24 15 25 9 19
BS*021M2D ERC1-0200-TAD 460 3 60 3.3 23.0 2 1/15 1.0 15 20 15 20 ^ ^
BS*029M2G ERF2-0310-CAB 230 1 60 15.6 86.0 2 1/15 1.0 21 38 35 45 12 30
BS*029M2C ERF1-0311-TAC 208-230 3 60 11.2 82.0 2 1/15 1.0 15 29 25 35 12 23
BS*029M2D ERFI-0311-TAD 460 3 60 5.2 41.0 2 1/15 1.0 15 15 15 25 ^ ^
BS*030H2G ERF2-0310-CAB 230 1 60 15.6 86.0 1 1/3 3.5 23 38 35 50 12 30
BS*030H2C ERF1-0311-TAC 208-230 3 60 11.2 82.0 1 1/3 3.5 20 38 25 40 12 30
BS*030H2D ERF1-0311-TAD 460 3 60 5.2 41.0 1 1/3 1.9 15 24 15 25 ^ ^
BS*030M2G 3RA2-0310-CAB 230 1 60 16.0 86.0 1 1/3 3.5 24 38 35 50 12 30
BS*030M2C 3RA1-0311-TAC 208-230 3 60 12.7 82.0 1 1/3 3.5 20 38 30 40 12 30
BS*030M2D 3RA1-0311-TAD 460 3 60 5.6 41.0 1 1/3 1.9 15 24 15 25 ^ ^
BS*040H2C NRB2-0400-TFC 208-230 3 60 19.6 141.0 1 1/3 3.5 28 40 45 50 12 30
BS*040H2D NRB2-0400-TFD 460 3 60 10.1 62.5 1 1/3 1.9 15 29 20 35 12 23
BS*050H2C NRA3-0500-TFC 208-230 3 60 17.2 141.0 1 1/3 3.5 25 38 40 50 12 30
BS*050H2D NRA3-0500-TFD 460 3 60 8.7 62.5 1 1/3 1.9 15 29 20 35 12 23
BS*050M2C NRM1-0500-TFC 208-230 3 60 21.8 141.0 1 1/3 3.5 31 43 50 60 12 32
BS*050M2D NRM1-0500-TFD 460 3 60 10.8 62.5 1 1/3 1.9 15 29 25 35 12 23
BS*010M6B KARB-010E-CAV 208-230 1 60 6.4 40.0 1 1/15 0.5 15 20 15 20 7 15
BS*010M6C KARA-010E-TAC 208-230 3 60 3.8 27.0 1 1/15 0.5 15 20 15 20 9 15
BS*020M6B KAKB-021E-CAV 208-230 1 60 9.1 55.0 2 1/15 1.0 15 24 20 25 6 19
BS*020M6C KAKA-020E-TAC 208-230 3 60 5.8 50.0 2 1/15 1.0 15 24 15 25 9 19
BS*021M6C ERCA-021E-TAC 208-230 3 60 7.9 46.0 2 1/15 1.0 15 24 15 25 9 19
BS*021M6D ERCA-020E-TAD 460 3 60 3.1 23.0 2 1/15 1.0 15 20 15 20 ^ ^
BS*030M6G ERFB-031E-CAB 230 1 60 15.3 86.0 1 1/3 3.5 23 38 35 45 12 30
BS*030M6C ERFA-031E-TAC 208-230 3 60 11.2 82.0 1 1/3 3.5 20 38 25 40 12 30
BS*030M6D ERFA-031E-TAD 460 3 60 5.2 41.0 1 1/3 1.9 15 24 15 25 ^ ^
BS*040M6C NRB2-040E-TFC 208-230 3 60 19.6 141.0 1 1/3 3.5 28 40 45 50 12 30
BS*040M6D NRB2-040E-TFD 460 3 60 8.1 62.5 1 1/3 1.9 15 29 20 35 12 23

19
SEMI-HERMETIC COMPRESSORS
Electrical Data - Low Temperature
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
^ Power supplied by customer.
† Consult factory for 50 HZ applications.
NOTE: Per UL and NEC, RLA values have been calculated by dividing the Maximum Continuous Current (MCC) by 1.56
Model
Number Part Number Power Supply Compressor Fan Motor MCA MOPD Evap.
Fan
Amps
Defrost
Heater
Amps
Volts Ph Hz†RLA LRA Qty. HP FLA Air Elec. Air Elec.
BS*010L6B KAJB-010E-CAV 208-230 1 60 6.2 40.0 1 1/15 0.5 15 20 15 20 8 15
BS*010L6C KAJA-011E-TAC 208-230 3 60 4.1 27.0 1 1/15 0.5 15 20 15 20 9 15
BS*015L6B KALB-015E-CAV 208-230 1 60 8.9 55.0 2 1/15 1.0 15 24 20 25 8 19
BS*015L6C KALA-016E-TAC 208-230 3 60 6.0 50.0 2 1/15 1.0 15 20 15 20 7.6 15
BS*015L6D KALA-016E-TAD 460 3 60 3.1 25.0 2 1/15 1.0 15 20 15 20 9 15
BS*020L6G EADB-021E-CAB 230 1 60 9.0 58.0 2 1/15 1.0 15 24 20 25 4 19
BS*020L6C EADA-020E-TAC 208-230 3 60 6.1 46.0 2 1/15 1.0 15 20 15 20 7 15
BS*021L6B EAVB-021E-CAV 208-230 1 60 13.2 102.0 2 1/15 1.0 20 29 30 30 4 23
BS*021L6C EAVA-021E-TAC 208-230 3 60 6.6 50.0 2 1/15 1.0 15 20 15 20 7 15
BS*021L6D EAVA-021E-TAD 460 3 60 2.9 26.6 2 1/15 1.0 15 20 15 20 9 15
BS*027L6G 3ABB-032E-CAB 230 1 60 13.2 86.0 2 1/15 1.0 20 38 30 40 12 30
BS*027L6C 3ABA-031E-TAC 208-230 3 60 9.0 82.0 2 1/15 1.0 15 24 20 25 8 19
BS*027L6D 3ABA-031E-TAD 460 3 60 4.6 41.0 2 1/15 1.0 15 15 15 15 ^ ^
BS*030L6G LAHB-032E-CAB 230 1 60 15.0 105.0 2 1/15 1.0 20 38 30 45 12 30
BS*030L6C LAHA-032E-TAC 208-230 3 60 11.5 112.0 2 1/15 1.0 20 29 25 35 12 23
BS*030L6D LAHA-032E-TAD 460 3 60 5.4 56.0 2 1/15 1.0 15 15 15 15 ^ ^
BS*030E6G LACB-032E-CAB 230 1 60 13.9 105.0 2 1/15 1.0 20 38 30 40 12 30
BS*030E6C LACA-032E-TAC 208-230 3 60 11.5 112.0 2 1/15 1.0 15 29 25 35 12 23
BS*030E6D LACA-032E-TAD 460 3 60 5.4 56.0 2 1/15 1.0 15 15 15 15 ^ ^
BS*040L6G NRD1-040E-CFB 230 1 60 24.9 115.0 1 1/3 3.5 35 44 50 60 10 30
BS*040L6C NRD1-032E-TFC 208-230 3 60 14.6 82.0 1 1/3 3.5 22 38 35 45 12 30
BS*040L6D NRD1-032E-TFD 460 3 60 7.6 41.0 1 1/3 1.9 15 24 15 25 9 19
Replacement Parts List
Model PSC Motor Fan Blade
A, B, C Cabinet 25309101, 230/1 22901601, 14"
D Cabinet 25309001, 230/1
25309002, 460/1 7173156, 22"
Commercial Refrigeration Parts
Right source. Right parts. Right now.
InterLink™ is your link to a complete line of dependable and certied commercial
refrigeration parts, accessories and innovative electronic controls for all Bohn
equipment. At InterLink, we provide our wholesalers with a comprehensive
selection of product solutions and innovative technologies for the installed
customer base. And every product is built to ensure the same high performance
standards with which all Heatcraft brands are built — backed by a dedicated team
to serve every customer need, delivering at the best lead times in the industry.
Dependable. Versatile. Courteous.
Finally, one simple source for all your replacement needs from a name you can trust.
www.interlinkparts.com
800.686.7278

20
1/2, 3/4 AND 1HP
1-1/2 AND 2HP
3HP - ALTERNATE CABINET
3, 4, 5 AND 6HP
AIR
FLOW
AIR
FLOW
AIR
FLOW
AIR
FLOW
SUCTION
LIQUID
LIQUID SUCTION
LIQUID
LIQUID
SUCTION
FRONT VIEW
A
B
C
D
OUTDOOR INDOOR
FRONT VIEW
POWER CONNECTIONS:
(1) 7/8 & (1) 1-1/8
POWER CONNECTIONS:
(1) 7/8 & (1) 1-1/8
POWER CONNECTIONS:
(2) 7/8, (1) 1-3/8 & (1) 1-3/4
POWER CONNECTIONS:
(2) 7/8, (1) 1-3/8 & (1) 1-3/4
7/16 DIA HOLE
TYP 4 PLCS
7/16 DIA HOLE
TYP 4 PLCS
SUCTION
28-1/4 23-3/4
17-1/4
3
1-7/8
4-1/16
2-3/4
21-1/8 CL
2-3/8
2-9/16
1-3/4
4-9/16
21-1/8 CL
2-9/16
2-3/8
1-3/4
4-9/16
28-1/4
28-1/4
2-5/8
1-11/16
4-9/16
21-1/8 CL
23-1/8 CL
2-5/8
2-9/16
2-9/16
2-1/16
4-9/16
30-1/4
1-7/8
4-1/16
3
2-3/4
37-3/4
17-1/4
3-1/4 3-13/16 4-15/16 5-1/4
1-15/16
2-1/4
3-11/16
37-3/4
19-3/4
42-1/2
29-3/4
3-1/4 3-13/16 4-15/16 5-1/4
1-15/16
2-1/4
3-11/16
24-1/4 CL
25-1/8
38-1/4 CL
39-1/8
38-1/4 CL
39-1/8
43 CL
43-7/8
LEFT VIEW
1/2, 3/4 AND 1HP
1-1/2 AND 2HP
3HP - ALTERNATE CABINET
3, 4, 5 AND 6HP
AIR
FLOW
AIR
FLOW
AIR
FLOW
AIR
FLOW
SUCTION
LIQUID
LIQUID SUCTION
LIQUID
LIQUID
SUCTION
FRONT VIEW
A
B
C
D
OUTDOOR INDOOR
FRONT VIEW
POWER CONNECTIONS:
(1) 7/8 & (1) 1-1/8
POWER CONNECTIONS:
(1) 7/8 & (1) 1-1/8
POWER CONNECTIONS:
(2) 7/8, (1) 1-3/8 & (1) 1-3/4
POWER CONNECTIONS:
(2) 7/8, (1) 1-3/8 & (1) 1-3/4
7/16 DIA HOLE
TYP 4 PLCS
7/16 DIA HOLE
TYP 4 PLCS
SUCTION
28-1/4 23-3/4
17-1/4
3
1-7/8
4-1/16
2-3/4
21-1/8 CL
2-3/8
2-9/16
1-3/4
4-9/16
21-1/8 CL
2-9/16
2-3/8
1-3/4
4-9/16
28-1/4
28-1/4
2-5/8
1-11/16
4-9/16
21-1/8 CL
23-1/8 CL
2-5/8
2-9/16
2-9/16
2-1/16
4-9/16
30-1/4
1-7/8
4-1/16
3
2-3/4
37-3/4
17-1/4
3-1/4 3-13/16 4-15/16 5-1/4
1-15/16
2-1/4
3-11/16
37-3/4
19-3/4
42-1/2
29-3/4
3-1/4 3-13/16 4-15/16 5-1/4
1-15/16
2-1/4
3-11/16
24-1/4 CL
25-1/8
38-1/4 CL
39-1/8
38-1/4 CL
39-1/8
43 CL
43-7/8
LEFT VIEW
Dimensional Drawings
AA
BB
CC
DD
OUTDOOR
