BONTEC MWS-001BK User manual

Assembly Instructions for Mobile Workstation
Thanks for choosing our product. This stand ideally works as mobile podium,
lectern and laptop workstation. The height of stand can be easily adjusted.
The integrated wheels provide ease of movement.
Model: MWS-001BK

Safety Warning: If you do not understand these directions, or have any
doubts about the safety of the installation, please call a qualied contractor.
Check carefully to make sure there are no missing or defective parts. Never
use defective parts. Improper installation may cause damage or serious injury.
Do not use this product for any purpose that is not explicitly specied in this
manual. We can not be liable for damage or injury caused by incorrect
mounting, incorrect assembly, or incorrect use.
Required Tools: Phillips screw driver.
Supplied Parts
Long Square Tube
A (X2) B (X2)
Short Square Tube
C (X4)
Wheel
D (X1)
Tube Connector
Tube Connector Cover
E (X1) F (X4)
M6 Socket Plate
G (X2)
Pole Set
H (X4)
Plastic Sleeve
I (X1)
Connecting Tube
J (X2)
Plastic Knob
K (X2)
Shelf Support
L (X1)
Shelf
M (X1)
Top Plate Right Connecting Plate
N (X1) O (X1)
Left Connecting Plate M6 Nut
P (X4)
1

Q (X2)
Lever
R (X2)
Soft Pad
S (X8)
M6x60 Allen Head Bolt
T (X12)
M6x10 Allen Head Bolt
M4X6 Countersink Bolt
U (X4)
M5x6 Grub Screw
V (X2)
M6 Washer
W (X2)
5/32 in (4mm)
Medium Allen Key
M-B (X1)
3/32 in (2.5mm)
Small Allen Key
M-A (X1)
13/64 in (5mm)
Large Allen Key
M-C (X1) M-D (X1)
Wrench
Step 1
M-D
C
A
C
B
Turn this nut to adjust
the height of wheel.
2

Step 2
F
S
D
Front
hole for
connecting
the Pole Set(G)
A
B
M-C
Note: The short square tube[B]
should be on the same side as
the screw hole for pole set[G].
Step 3
G
H
Note: Adding plastic sleeves to
prevent pulling out the inner
poles from outer poles.
3

Step 4
Step 5
G
TI
M-B
Note: Make sure both of the poles
are at the same height
M-B
G
K
T
4

Step 6
Front
E
Note: The Shelf Supports,facing
Them To The Long Square Tube
T
V
M-A
V
T
M-B
5

Step 7
Step 8
J
U
L
6

Step 9
Step 10
N
O
P
M-D
M
M-B
T
T
7

Step 11
Step 12
Q
W
R
8

Step 13
tilt 40°
Q
Tilt Adjustment
1. Slightly loosen the both levers [Q].
2. Tilt the top plate to your desired angle.
3.Re-tighten the both levers [Q] to
secure the height in place.
Height Adjustment
1. Slightly loosen the both knobs [J].
2. You may need two persons for assistance
with this step. One person holds the both
upper poles to adjust the height. The
other person tightens the both knobs to
secure the height.
Note: Please remove all items from
the shelf prior to adjusting the height.
9
J

Step 13
10
