Bosch SHPM78 Series User manual

QUICK START
& SAFETY GUIDE
DISHWASHER
SHP87P****, SHPM78****, SHP878****, SHPM88****,
SHX87P****, SHXM88****, SHXM78****, SHX878****,
SHVM88****, SHVM78****, SHV878****
TABLE OF CONTENTS
SAFETY INSTRUCTIONS .................... 2
GETTING STARTED ........................ 4
CYCLES AND OPTIONS..................... 6
EVERYDAY TIPS ........................... 8
STATEMENT OF LIMITED WARRANTY .......10

2 3
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE THESE INSTRUCTIONS
!
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE THESE INSTRUCTIONS
!
!
!
• To avoid oor damage and possible mold growth, do not allow wet areas to
remain around or under the dishwasher.
WARNING: CHILD SAFETY
• Keep detergents or rinsing agents out of the reach of children.
• To reduce risk of injury, do not allow children to play in or on the dishwasher.
• Do not allow children to handle or play near knives and sharp utensils.
• When children become old enough to operate the appliance, it is the
responsibility of the parents/legal guardians to ensure the
children are instructed in safe practices by qualied persons.
CAUTION
• When loading items to be washed:
• Locate sharp items so they are not likely to damage the door seal.
• Do not wash plastic items unless they are marked “dishwasher safe” or
the equivalent. Otherwise, check the manufacturer’s recommendations.
• Do not operate your dishwasher unless all enclosure panels are in place.
• Do not tamper with or override controls and interlocks.
• Dishes can be very hot immediately after cycle ends. Open the door slightly
and allow dishes to cool for a few minutes before unloading.
• This dishwasher is intended for use up to a maximum altitude of 13,000 ft
(4,000 meters) above sea level.
• Use only detergents or rinsing agents recommended for use in a dishwasher.
WARNING
• End of Life Disposal - Remove the dishwasher door to the washing compart-
ment when removing an old dishwasher from service or discarding.
NOTICE
• It is highly recommended for the end user to become familiar with the pro-
cedure to shut o the incoming water supply and the procedure to shut o
the incoming power supply. See the Installation Instructions or contact your
installer for more information.
CAUSES OF DAMAGE
• Detergent will destroy the water softening system! Never pour detergent
into the salt dispenser.
• To avoid oversudsing or clogging, do not overll the rinse aid dispenser.
Wipe up any spills with a damp cloth.
• Do not allow water to remain in your dishwasher systems through extended
periods of freezing temperatures. Freezing temperatures can damage the
water ll valve and potentially other components of your dishwasher.
• Never use steam cleaning products to clean your dishwasher. The manufac-
turer will not be responsible for the possible damages or consequences.
• Do not use harsh chemicals, bleach-based wipes, abrasive cleaners, scour-
ing pads (metal or plastic), or abrasive cloths/paper towels to clean your
dishwasher’s exterior door panel. These could damage your dishwasher’s
exterior door panel.
• Do not load the dishwasher with paper products, plastic bags, packing materi-
als or anything other than normal, dishwasher safe dishware and kitchenware.
This Quick Start and Safety Guide explains the basics of operating your dishwasher
and those safety measures that must be followed.
For complete product information refer to the Use and Care Manual available
online at www.bosch-home.com/us/service/get-support/owner-manuals.
Safety Denitions:
WARNING: This indicates that death or serious injuries may occur as a
result of non-observance of this warning.
CAUTION: This indicates that minor or moderate injuries may occur as a
result of non-observance of this warning.
NOTICE: This indicates that damage to the appliance or property may occur as a
result of non-compliance with this advisory.
WARNING: TIP OVER HAZARD!
Dishwasher must be installed immediately and secured with
mounting brackets to avoid tip over. A child can tip the dish-
washer and be seriously injured if the door is opened before it is
installed. (see Installation Guide for instructions)
WARNING: SAFE OPERATION
• Use this dishwasher only for its intended function, which is the washing of
household dishware and kitchenware rated as dishwasher safe.
• DISHWASHER MUST BE ELECTRONICALLY GROUNDED. See Installation
Guide for instructions.
• The sharp points and edges of knives and other sharp utensils can cause
serious injury. Load knives and other sharp utensils with edges down.
• To avoid risk of injury, always use caution when opening the door during or
following a wash cycle as hot water or steam may escape. Do not fully open
the door until water noises have stopped and steam has subsided.
• Misuse of the dishwasher can result in serious injury or death. Do not use
the dishwasher in any way not covered in the Use and Care Manual or for
any purpose other than those explained in the following pages.
• Never use harsh chemicals to clean your dishwasher. Some bleach-based
products can damage your dishwasher and may present health hazards!
• Use caution when removing parts for cleaning as some debris may be sharp.
• Do not abuse, sit or stand on the door or dish racks of the dishwasher.
• RISK OF EXPLOSION - Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been used for two weeks
or more. Hydrogen gas is explosive. Before using a dishwasher that is
connected to a hot water system that has been unused for two weeks or
longer, turn on all hot water faucets and let the water ow from each for
several minutes. This will release any accumulated hydrogen gas. As the
gas is explosive, do not smoke or use an open ame during this time.
• RISK OF EXPLOSION - When cleaning your dishwasher with any cleaning
agent, remove all cookware, utensils or any foreign material from inside.
Some cleaning agents are highly acidic and/or caustic alkaline, which
can cause Hydrogen gas to form if aluminum material is also inside the
dishwasher tub. Hydrogen gas is explosive. Refer to the Care and
Maintenance section of the dishwasher Use and Care manual for
instructions on how to properly clean your dishwasher.

4 5
GETTING STARTED
Upper rack
Lower Rack
Load pots and pans and other large
items upside down.
Load plates and bowls in lower
rack leaning inward.
For small plates, glasses and cups.
Small cups t on cup shelf.
The cup shelf also serves as
stemware support.
3rd rack Cutlery basket
LOADING TIPS FOR OPTIMAL CLEANING
Scrape
o
food,
but
do not
rinse.
Use rinse
aid
for better
drying.
Adjust
upper rack
as needed
for large
items.
PUSH
USAGE TIPS FOR BEST RESULTS
Do not
place
objects in
detergent
tray or
block it with
dishes
WARNING
• Load sharp items (knives, skewers, etc.) pointing down. Failure to do so may
result in injury.
• To avoid risk of injury, always use caution when opening the door during or
following a wash cycle as hot water or steam may escape. Do not fully open
the door until water noises have stopped and steam has subsided.
!
ADD DETERGENT
Use detergent tabs, fresh powdered detergent or liquid detergent. For the Glass
cycle, use 1 -1.75 Tbsp. of detergent or use detergent tabs with glassware
protection.
Tip: dispenser lid should slide closed easily.
1.75 Tbsp. (25 ml)
3 Tbsp. max.
1 Tbsp. (15 ml)
TO CLOSE THE COVER
CLICK
DETERGENT AMOUNTS
LAY TABS FLAT

6 7
CYCLES AND OPTIONS
Cycles level of
dirt
what it does examples of
dishes
Heavy baked-on/
greasy
dishes
longer cycle and
higher temperature
baked-on lasagna
casserole
Auto not
baked-on
adjusts time and
intensity automatically
by soil sensing
everyday load
Normal not baked-
on
cycle to save energy
and water
everyday load
Glass** light more gentle cycle for
sensitive dishes
delicate dishes
and glasses
Eco** light lowers temperature
and increases cycle
length to save energy
delicate dishes
and glasses
Express** light reduces overall wash
time to 30 minutes.
glasses and
dessert dishes
Speed60** fresh, not
dried on
1 hour cycle which
includes drying
everyday load
Rinse fresh, not
dried on
quick rinse, using
less water than hand
rinsing
everyday load,
to use between
cycles
Options level of
dirt
what it does examples
of dishes
Delay any allows you to delay the
start of the cycle up to
24 hours.
any
Half Load light reduces water
consumption
small load,
mostly top
rack
Delicate light reduces cycle length
and temperature
glasses
Sanitize any increases cycle length
and temperature for
disinfection
cutting
boards,
bottles
Crystal Dry any provides oustanding
drying results using
innovative zeolite
technology
no delicate
dishes
Eco** any reduces water and
energy consumption;
cycle time is increased.
everyday
dishes
Extra Scrub** heavy increases pressure
and temperature in
the lower rack for
intensive cleaning
everyday
dishes or pots
and pans,
no delicate
dishes
* Use buttons A, B, and C to change the settings. See next page for
directions.
** Depending on the model
Cycles Options
ABC*Reset 3 seconds

8 9
FREQUENTLY ASKED QUESTIONS
Q: Why is food left on dishes?
A: It is possible the dishes do not have adequate clearance between them.
Also, be sure nothing is blocking spray arm and that the lter is clean. Select an
intensive cleaning cycle.
Q: Why does the cycle run a long time?
A: 1. Sensors in the dishwasher automatically increase the cycle time to ensure a
good wash when heavy soil is detected.
2. Incoming water may not be hot enough and dishwasher has to heat it.
Q: Why is E:XX (X can be any number) displayed?
A: This is an error code. For example E:22 ndicates there is water in the sump
because the lter is blocked or needs cleaning. See the Use and Care Manual
for a list of error codes.
To access the full Use and Care Manual, go to:
www.bosch-home.com/us/service/get-support/owner-manuals.
MAINTENANCE TIPS
Clean surfaces with damp cloth and mild soap.
NOTICE:Do not use abrasives or bleach based cleaners. Do not use stainless
steel cleaner on black stainless or anti-nger print surfaces.
Clean the lter 3-12 times a year, depending on usage.
1. Unscrew the Large Object Trap as illustrated and remove the entire lter
system.
2. Remove the micro-lter from the ne lter, rinse the lters under running
water clean with a soft brush.
3. Reinstall the lter system in reverse sequence, align arrows.
1
2
START YOUR DISHWASHER
1. Press the On/O button.
2. Select a cycle and option if desired.
3. Press Start.
ADJUSTING THE SETTINGS
1. Press the On/O button. Hold down button A (see pages 6-7) and press
Start until the display shows š:‹x (x can be any number).
2. Release both buttons. The LED for the button A ashes and the digital
display shows the factory set value. Press A to choose the setting.
3. Press buttons B or C (up or down) to change the setting.
4. Press Start button to save the setting.
Setting Factory setting Description
§-Rinse Aid
§:‹‹-§:‹‡
§:‹† Dispenses the amount of rinse aid,
which aects drying (see above).
š-Intensive drying
š:‹‹-š:‹‚
š:‹‹/ o Improved drying for glasses and
plastic, by increasing the tempera-
ture and length.
›-Beep at cycle
end
›:‹‹-›:‹„
›:‹ƒ Adjust the sound level of the signal
beep at the end of the cycle. Or turn
o (›:‹‹).
‚ -Info light
‚:‹‹-‚:‹‚
‚:‹‚ / on Light projected on the oor to signal
active wash cycle. Set to on or o.
˜-Auto power o
˜:‹‹-˜:‹ƒ
˜:‹‚/ o after
one minute
Unit turns itself o after cycle is com-
plete, either after 1 minute, ˜:‹‚ or
after 2 hours, ˜:‹ƒ.
max
vent
air
ADD RINSE AID
This dishwasher is designed to be used
with rinse aid, which enhances drying
results and shine.
• Add rinse aid before rst use and when
the Add Rinse Aid indicator light on the
control panel illuminates.
• Lift tab to open the rinse aid reservoir
and add liquid rinse aid into the oval
until it is full, avoiding air vent. Wipe up
any excess rinse aid that may puddle.
Tip: Remove lid of rinse aid bottle for easier pouring.
The amount of rinse aid dispensed can be set in 6 levels. Only change the
setting if streaks remain on the dishes (lower the amount), or if dishes are not
getting dry enough (increase the amount).

10 11
STATEMENT OF LIMITED PRODUCT WARRANTY
What this Warranty Covers & Who it Applies to:
The limited warranty provided by BSH Home Appliances Corporation(BSH) in this Statement
of Limited Product Warranty applies only to the Bosch® dishwasher (“Product”)sold to you,
the rst using purchaser, provided that the Product was purchased:
• For your normal, household(non-commercial) use, and has in fact at all times only been
used for normal household purposes;
• New at retail (not a display, “as is”, or previously returned model), and not for resale, or
commercial use.
• Within the United States or Canada, and has at all times remained within the country of
original purchase.
The warranties stated herein apply to the original purchaser of the product warranted herein
and to each succeeding owner of the product purchased for ordinary home use during the
term of the warranty.
Please make sure to return your registration card; while not necessary to eectuate warranty
coverage, it is the best way for BSH to notify you in the unlikely event of a safety notice or
product recall.
How Long the Warranty Lasts
BSH warrants that the Product is free from defects in materials and workmanship for a period
of three hundred sixty ve (365) days from the date of purchase. The foregoing timeline
begins to run upon the date of purchase, and shall not be stalled, tolled, extended, or sus-
pended, for any reason whatsoever. This Product is also warranted to be free from cosmetic
defects in material and workmanship (such as scratches of stainless steel, paint/porcelain
blemishes, chip, dents, or other damage to the nish) of the Product, for a period of thirty (30)
days from the date of purchase or closing date for new construction. This cosmetic warranty
excludes slight color variations due to inherent dierences in painted and porcelain parts, as
well as dierences caused by kitchen lighting, product location, or other similar factors. This
cosmetic warranty specically excludes any display, oor, “As Is”, or “B” stock appliances.
Repair/Replace as Your Exclusive Remedy
During this warranty period, Bosch or one of its authorized service providers will repair your
Product without charge to you (subject to certain limitations stated herein) if your Product
proves to have been manufactured with a defect in materials or workmanship. If reasonable
attempts to repair the Product have been made without success, then Bosch will replace
your Product (upgraded models may be available to you, in Bosch’s sole discretion, for an
additional charge). All removed parts and components shall become the property of Bosch at
its sole option. All replaced and/or repaired parts shall assume the identity of the original part
for purposes of this warranty and this warranty shall not be extended with respect to such
parts. Bosch’s sole liability and responsibility hereunder is to repair manufacturer-defective
Product only, using a Bosch authorized service provider during normal business hours. For
safety and property damage concerns, Bosch highly recommends that you do not attempt to
repair the Product yourself, or use an un-authorized servicer; Bosch will have no responsibility
or liability for repairs or work performed by a non-authorized servicer. If you choose to have
someone other than an authorized service provider work on your Product, THIS WARRANTY
WILL AUTOMATICALLY BECOME NULL AND VOID. Authorized service providers are those
persons or companies that have been specially trained on Bosch products, and who possess,
in Bosch’s opinion, a superior reputation for customer service and technical ability (note that
they are independent entities and are not agents, partners, aliates or representatives of
Bosch). Notwithstanding the foregoing, Bosch will not incur any liability, or have responsibil-
ity, for the Product if it is located in a remote area (more than 100 miles from an authorized
service provider) or is reasonably inaccessible, hazardous, threatening, or treacherous locale,
surroundings, or environment; in any such event, if you request, Bosch would still pay for
labor and parts and ship the parts to the nearest authorized service provider, but you would
still be fully liable and responsible for any travel time or other special charges by the service
company, assuming they agree to make the service call.
Out of Warranty Product
BSH is under no obligation, at law or otherwise, to provide you with any concessions, includ-
ing repairs, pro-rates, or Product replacement, once this warranty has expired.
Warranty Exclusions
The warranty coverage described herein excludes all defects or damage that is not the direct
fault of Bosch, including without limitation, one or more of the following:
• Use of the Product in anything other than its normal, customary and intended manner
(including without limitation, any form of commercial use, use or storage of an indoor
product outdoors, use of the Product in conjunction with air or water-going vessels).
• Any party’s willful misconduct, negligence, misuse, abuse, accidents, neglect, improper
operation, failure to maintain, improper or negligent installation, tampering, failure
to follow operating instructions, mishandling, unauthorized service (including self
performed “xing” or exploration of the appliance’s internal workings).
• Adjustment, alteration or modication of any kind.
• A failure to comply with any applicable state, local, city, or county electrical, plumbing
and/or building codes, regulations, or laws, including failure to install the product in
strict conformity with local re and building codes and regulations.
• Ordinary wear and tear, spills of food, liquid, grease accumulations, or other substances
that accumulate on, in, or around the Product.
• Any external, elemental and/or environmental forces and factors, including without
limitation, rain, wind, sand, oods, res, mud slides, freezing temperatures, excessive
moisture or extended exposure to humidity, lightning, power surges, structural failures
surrounding the appliance, and acts of God.
• Service calls to correct the installation of your refrigerator, to instruct you how to use
your refrigerator, to replace house fuses or correct house wiring or plumbing
• Removal and replacement of trim or decorative panels that interfere with servicing the product.
• Labor or parts installed by any non-designated service company during the full warranty
period, unless approved by Bosch before service is performed.
In no event shall BSH have any liability or responsibility whatsoever for damage to surround-
ing property, including cabinetry, oors, ceilings, and other structures or objects around the
Product. Also excluded from this warranty are Products on which the serial numbers have
been altered, defaced, or removed; service visits to teach you how to use the Product, or
visits where there is nothing wrong with the Product; correction of installation problems (you
are solely responsible for any structure and setting for the Product, including all electrical,
plumbing or other connecting facilities, for proper foundation/ooring, and for any alter-
ations including without limitation cabinetry, walls, oors, shelving, etc.); and resetting of
breakers or fuses.
TO THE EXTENT ALLOWED BY LAW, THIS WARRANTY SETS OUT YOUR EXCLUSIVE
REMEDIES WITH RESPECT TO PRODUCT, WHETHER THE CLAIM ARISES IN CONTRACT OR
TORT (INCLUDING STRICT LIABILITY, OR NEGLIGENCE) OR OTHERWISE. THIS WARRANTY
IS IN LIEU OF ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED.
ANY WARRANTY IMPLIED BY LAW, WHETHER FOR MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, OR OTHERWISE, SHALL BE EFFECTIVE ONLY FOR THE
PERIOD THAT THIS EXPRESS LIMITED WARRANTY IS EFFECTIVE. IN NO EVENT WILL THE
MANUFACTURER BE LIABLE FOR CONSEQUENTIAL, SPECIAL, INCIDENTAL, INDIRECT,
“BUSINESS LOSS”, AND/OR PUNITIVE DAMAGES, LOSSES, OR EXPENSES, INCLUDING
WITHOUT LIMITATION TIME AWAY FROM WORK, HOTELS AND/OR RESTAURANT MEALS,
REMODELLING EXPENSES IN EXCESS OF DIRECT DAMAGESWHICH ARE DEFINITIVELY
CAUSED EXCLUSIVELY BY BSH, OR OTHERWISE. SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, AND SOME
STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO
STATE.
No attempt to alter, modify or amend this warranty shall be eective unless authorized in
writing by an ocer of BSH.

12
1901 MAIN STREET, SUITE 600 IRVINE, CA 92614 // WWW.BOSCH-HOME.COM
@ 2017 BSH HOME APPLIANCES CORPORATION
9001495165 9910 640A MU
How to Obtain Warranty Service
To obtain warranty service for your product, you should contact Bosch Customer
Service at 1-800-944-2904.
:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
STATE OF CALIFORNIA PROPOSITION 65 WARNING:
WARNING
Proposition 65 Warning:
This product may contain a chemical known to the State of California, which can cause
cancer or reproductive harm. Therefore, the packaging of your product may bear the
following label as required by California:
