Bosch SHX78CM4 User manual

en Installation Instructions
fr Notice d’installation
es Instrucciones de instalación
Customer Service:
1-800-944-2904
These instructions are intended
for use by qualified installers only

2

3
Safety Definitions
This indicates that damage to the appliance or property may occur as a
result of non-compliance with this advisory.
NOTICE
This indicates that death or serious injuries may occur as a result
of non-observance of this warning.
WARNING
!
Note: This alerts you to important information and/or tips.
Table of Contents
Safety Instructions ........................................4
Avoiding General Hazards ..................................5
Tools & Materials .........................................6
Enclosure Requirements ...................................9
Electrical Connections ....................................14
Installation of Mounting Brackets ............................17
Positioning the Dishwasher ................................19
Securing the Dishwasher ..................................23
Water Inlet Connection....................................24
Drain Connection ........................................25
Attaching the Toe Panel...................................29
Custom Door Panel ......................................32
Customer Service........................................33
This indicates that minor or moderate injuries may occur as a
result of non-observance of this warning.
CAUTION
!

4
To avoid possible injury or property damage, OBSERVE ALL WARNINGS
AND CAUTIONS.
WARNING:
These instructions are intended for use by qualified installers only. The
dishwasher must be installed by a qualified service technician or installer.
• In addition to these instructions, the dishwasher shall be installed to
meet all electrical and plumbing codes and ordinances (both national
and local).
Read these installation instructions completely and follow them carefully.
They will save you time and eort and help to ensure safety and optimum
dishwasher performance.
IMPORTANT
• The dishwasher drain hose must be installed with a portion of it at least
33″ (84 cm) o the cabinet floor; otherwise the dishwasher may not
drain properly.
• This dishwasher is intended for indoor residential use only, and should
not be used in commercial food service establishments.
• This dishwasher is designed to be enclosed on the top and both sides
by cabinetry.
• NEW INSTALLATION - If the dishwasher is a new installation, ensure all
connections are properly made before the dishwasher is moved into
place.
• REPLACEMENT - If the dishwasher is replacing another dishwasher,
check the existing dishwasher connections for compatibility with the
new dishwasher, and replace parts as necessary.
• This appliance has been found to be in compliance with CAN/CSA-C22.2
No. 167/UL 749. It is the responsibility of the owner and the installer
to determine if additional requirements and standards apply in specific
installations.
• Not for outdoor use.
Important Safety Instructions:
Please READ and SAVE this information

5
Avoiding General Hazards
To reduce the risk of electric shock, fire, or injury to persons, the installer
must ensure that the dishwasher is completely enclosed at the time of
installation.
Do not use the dishwasher until it is completely installed. When opening the
door on an uninstalled dishwasher, carefully open the door while supporting
the rear of the unit. Failure to follow this warning can cause the dishwasher
to tip over and result in serious injury.
Before installing the supplied counter top mounting brackets, decide which
method will be used to secure the dishwasher into its opening. Once these
mounting brackets are installed on the dishwasher, removing them is dif-
ficult and will damage the mounting brackets and the dishwasher.
In some conditions, hydrogen gas can form in a hot water system that
has not been used for weeks. Hydrogen gas is explosive. Before filling a
dishwasher from a system that has been o for weeks, run the water from
a nearby faucet in a well ventilated area until there is no sound or evidence
of gas.
Removing any cover or pulling the dishwasher from the cabinet can expose
hot water connections, electrical power and sharp edges or points. Handle
with care.
Proposition 65 Warning:
This product may contain a chemical known to the State of California, which
can cause cancer or reproductive harm. Therefore, the packaging of your
product may bear the following label as required by California:
Inspect the Dishwasher
After unpacking the dishwasher and prior to installation, thoroughly inspect
the dishwasher for possible freight or cosmetic damage. Report any damage
immediately. Cosmetic defects must be reported within 30 days of installation.
NOTE: Do not discard any bags or items that come with the original package
until after the entire installation has been completed.
WARNING
STATE OF CALIFORNIA PROPOSITION 65 WARNING:
WARNING
Cancer and Reprodutive Harm - www.P65Warnings.ca.gov

6
Elbow connection with 3/4” female hose threads on one end and fits
your water supply line (copper tubing, compression fitting, or braided
hose) on the other.
Hot Water Supply Line - Minimum 3/8″O.D. copper tubing or metal
braided dishwasher supply line.
Only needed if house water supply line is not sucient.
Shut-o valve and fittings appropriate for hot water supply line
(copper tubing/compression fitting, or braided hose).
Tools and Materials Needed

Wire Cutter Needle Nose Pliers
Pliers
Wire Stripper
ø1/16 in
(2 mm)
Adjustable Wrench (x2) Tape Measure
Drill Hole Saw
Flat Screwdriver Level Phillips Screwdriver

7
Materials Supplied
Screw Clamp (for drain hose)
Power Cord
Mounting Brackets
Mounting Bracket Screws Ø 4x13 mm
D
E
B
A
C
Installation Guide for Fully Integrated Door Panel
Vapor Barrier
(included with some models)
For fully integrated models only:

8
Toe Panel Kits
(Model Dependent; your dishwasher is supplied with one of the toe panel
kits shown below)
Slotted Toe Panel
2 - Screws Ø 4x16 mm
Non-Slotted Toe Panel
2- Screws Ø 4.2x12.7 mm
Toe Panel Mounting Brackets (used with non-
slotted toe panel shown above)
G
H
I
J
K
LPlastic Toe Panel
MSlotted Toe Panel (used with Plastic Toe Panel)
H4 - Screws Ø 4x16 mm
2 - Screws Ø 4x16 mm
H

9
Enclosure Requirements
To Avoid Scalding or Electrical Shock Hazard!
Make sure the water supply and electrical supply are shut o
before installation or service.
To Avoid Electrical Shock/Fire Hazard!
Do not allow the electrical and supply lines to touch.
Note: This dishwasher is designed to be enclosed on the top, back and
both sides by standard residential kitchen cabinetry.
• Select a location as close to the sink as possible for easy access to
water supply and drain lines.
• For proper dishwasher operation and appearance, ensure that the
enclosure is square and has the dimensions shown.
• If the dishwasher is to be installed in a corner, ensure that there is
adequate clearance to open the door as shown.
min 34"
(864 mm)
min 24"
(610 mm)
235/8"- 241/4"
(600 - 616 mm)
1





2
WARNING
!

10
• After locating the proper place for your dishwasher, create required
openings in your cabinets in order to allow for water, drain and
electrical lines on the appropriate side.
• The holes should be cut within the 7 x 2.5" area shown.
• If the opening is made through wood, sand it smooth.
• If the opening is made through metal, use the Edge Protector with
Power Cord clips Kit SMZEPCC1UC.
7"
(177.8 mm)
3
Scan here for video instructions on
preparing the cabinetry

11
• Certain dishwasher models include a plastic protective barrier. If the
dishwasher came with this part, remove it from the back of the unit.
• Clean and dry the underside of the counter where the dishwasher will
be installed.
• Peel o half of the backing and stick the barrier in place. Do not leave
a gap between the barrier and the edge of the countertop.
• After it is in place, remove the other half of the backing and attach firmly
in the place.
1
2
3
4
Scan here for video instructions on
installing the vapor barrier

12
• Pull the drain hose out of the packaging base as shown.
• Set toe panel aside for later use.
1
2
b
a
5
• Attach elbow joint to dishwasher as shown. Do not overtighten.
• Attach hot water line to elbow. Use two wrenches to tighten to avoid
putting stress on the water inlet valve.
Note: For a easier access to the hot water inlet connection, tip unit slightly
forward with someone holding the front side of the unit.
6

13
• Remove the hose clip at the back of the dishwasher as shown. The
hose clip may be used later to hold the drain hose inside your cabinet.
7
Avoid cross-threading! It will cause leaks. After attaching hose, temporarily
hook up the water supply then turn on water to check for leaks.
NOTICE
DO NOT tip the dishwasher too far forward! This could cause
serious injury or death. Always have an adult hold the front side if
the unit is tipped.
WARNING
!
Scan here for video instructions on
installing the water inlet valve

14
Electrical Connection
Avoid Electrical Shock Hazard!
Do not work on an energized circuit. Doing so could result in
serious injury or death. Only qualified electricians should perform
electrical work. Do not attempt any work on the dishwasher
electric supply circuit until you are certain the circuit is de-
energized.
To avoid possible injury or property damage, care should be exer-
cised when the dishwasher is installed or removed to reduce the
likelihood of damage to the power cord.
Avoid Fire Hazard!
Make sure electrical work is properly installed and checked by
qualified electricians.
Make sure there are no loose electrical connections. Make sure
all electrical connections are properly made.
Loose and improperly installed electrical connections can
result in overheating!
To avoid risk of fire, observe the following precautions:
Wall Socket Connections:
Only use the provided power cord for wall socket connections.
DO NOT attach an extension cord or any type of modified cord or
adapter with this appliance.
DO NOT cut or splice the power cord.
DO NOT alter the power cord in any way.
Permanent Wire Connections (in addition to the warnings above):
Only use the junction box power cord, sold as Accessory kit
#SMZPCJB1UC.
Carefully review the terminal block installation instructions.
DO NOT remove, alter or bypass the terminal block.
WARNING
!

15
Dishwasher Electrical Rating Volts Hertz Amperes Watts
120 60 12 1,440
(max)
Electrical Supply
The customer has the responsibility of ensuring that the dishwasher electri-
cal installation is in compliance with all national and local electrical codes
and ordinances. The dishwasher is designed for an electrical supply of
120V, 60 Hz, AC, connected to a dishwasher-dedicated, properly grounded
electrical circuit with a fuse or breaker rated for 15 or 20 amps.
Grounding Instructions
The dishwasher must be properly grounded before operating. This appli-
ance must be connected to a grounded metal permanent wiring system
or an equipment grounding conductor must be run with the circuit con-
ductors and connected to the equipment grounding terminal or lead on
the dishwasher.
Do NOT use an extension cord.
Make sure that the dishwasher is connected to a suitable ground in
compliance with all local codes or, in the absence of a local code, with
the NATIONAL ELECTRICAL CODE in the United States or the CANADIAN
ELECTRIC CODE C22.1-latest edition in Canada as well as any provincial/
state or municipal or local codes that apply.
Note: Installations requiring hard wiring and terminal block - The
accessory terminal block/junction box model, SMZPCJB1UC, designed
for permanent wire connection, is not included but can be ordered
through Customer Service by calling 1-800-944-2904. Follow the
instructions included with the kit.

16
Strap
A
l
te
rn
at
e
c
a
b
l
e rout
i
ng
8
• Plug the end of the supply cord into the back of the dishwasher. Be
sure it goes through the strap on either the right or left side of the
dishwasher.
• The outlet for the power supply cord should be located in a cabinet or
wall adjacent to the dishwasher cabinet.
• Do not plug dishwasher in until all the steps of installation are
complete.
Note: Only use the included power cord. If cord is missing order kit
SMZPC002UC through Customer Service.
Note: If clips are required for the power cord use the Edge Protector with
Power Cord clips Kit SMZEPCC1UC.

17
Installation of Mounting Brackets
Avoid Tip Over Hazard!
Do not use the dishwasher until it is completely installed.
When opening the door on an uninstalled dishwasher,
carefully open the door while supporting the rear of the unit.
Failure to follow this warning can result in serious injury.
WARNING
!
Note: Before installing the supplied counter top mounting brackets,
decide which method of securing the dishwasher into its enclosure will
be used.
Once the mounting brackets are installed on the dishwasher, removing
them is dicult and will damage the mounting brackets and the
dishwasher.
If you have a Fully Integrated Panel, do not attach mounting brackets until
after attaching the panel to the door.
Scan here for video instructions on
the mounting brackets

18
• Side Mount is used for counter tops made of marble, granite, or other
very hard materials that cannot be easily drilled.
• Grasp mounting bracket (D) with pliers and fold bracket at the perforation
over onto itself as shown in 10a.
• Slip bracket flange through side slots in frame as shown in 10b.
• Using pliers, bend side flanges down as shown in 9c and 9d so the
bracket will not slip out of slot in frame. Do not attach to cabinet yet.
10
• Top Mount is used for counter tops made of wood or other materials
that can be easily drilled.If you have solid surface, marble, granite, or
other very hard counter tops, skip to step 10 now.
• If insulation is covering the area in 9a, fold it back.
• Orient the mounting brackets (D) for top mounting as shown in 9b.
• Using pliers, bend side flanges down as shown in 9c and 9d so the
bracket will not slip out of slot in frame. Do not attach to cabinet yet.
9

19
• If your sink is to the right side of where you are installing the
dishwasher, you will need to reposition the hoses and power cord
behind the dishwasher before installing.
• To do so, unhook the strap that the hoses are running through
on the back of the dishwasher base and position them per your
requirements.
• If your sink is to the left side, leave the hoses and power cord as they
came.
Positioning the Dishwasher
11
Scan here for video instructions on the
hoses and power cord

20
• Position the hoses and power cord so they run through the strap on
the appropriate side.
• Be sure to snap the strap back in place to secure the hoses as shown.
12
Be sure to pull the hoses all the way into the adjacent cabinet while
pushing the dishwasher in. Otherwise, the hoses can fold, kink or break,
potentially causing obstructions or leaks.
NOTICE
