Bosch Benchmark Series User manual

SERVICE MANUAL
for
Benchmark Series
Built-in Wall Ovens
HBLP451LUC / HBLP451RUC
HBLP451UC
HBLP651LUC / HBLP651RUC
HBLP651UC
HBLP751UC
HBLP751UCC
HSLP751UCC
This manual contains information that is necessary for
servicing the following Bosch electric built-in wall ovens:
HBLP451LUC, HBLP51RUC, HBLP451UC,
HBLP651LUC, HBLP651RUC, HBLP651UC,
HBLP751UC, HBLP751UCC, HSLP751UCC
This manual is designed to be used by qualified service
personnel only. Due to the complexity and the risk of
high-voltage electrical shock, Bosch does not recommend
that customers service their own units.
This material is intended for the sole use of BSH
authorized persons and may contain confidential and
proprietary information. Any unauthorized review, use,
copying, disclosure, or distribution in any format is
prohibited.

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 2 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
TABLE OF CONTENTS
1Symbols Used in this Manual....................................................3
2Important Safety Information ....................................................4
2.1 Safety Before Servicing the Appliance..................................4
3General........................................................................................6
3.1 Recap of Functional/Technical Changes...............................6
3.2 Models...................................................................................6
3.2.1 Model Descriptions.........................................................6
3.2.2 Combination Ovens (Sets).............................................7
3.3 Data Plate..............................................................................7
3.4 Warranty................................................................................8
4Operation.....................................................................................9
4.1 Allowable Operating Range by Cooking Mode......................9
4.2 Heating Elements..................................................................9
4.2.1 Elements Used by Cooking Mode..................................9
4.2.2 Element Duty Cycles....................................................10
4.2.3 Setting Temperature Offsets........................................11
4.3 Self-clean ............................................................................12
4.4 Cooling Fan.........................................................................12
5Component Accessibility.........................................................13
5.1 Serviceable from the Front..................................................13
5.2Serviceable from the Side...................................................13
5.3 Serviceable from the Rear...................................................13
5.4 Serviceable from the Top....................................................13
5.4.1 Top Access: Non-combination Models.........................14
5.4.2 Top Access: Combination Models................................14
6Service and Repair...................................................................16
6.1 Bottom-Hinge Doors............................................................16
6.1.1 Removing and Reinstalling the Door............................16
6.1.2 Replacing the Hinges...................................................17
6.1.3 Replacing the 2-Pane Glass Pack ...............................18
6.2 Side-Hinge Doors................................................................19
6.2.1 Removing and Reinstalling the Door............................19
6.2.2 Aligning the Door..........................................................21
6.2.3 Replacing the Hinge Assembly....................................22
6.3 Door Latch/Motor Assembly................................................23
6.3.1 Replacing the Latch/Motor Assembly...........................23
6.4 Oven High Temperature Cutout (HTC)............................... 24
6.4.1 Resetting and Replacing the HTC............................... 24
6.5 Control Panel...................................................................... 25
6.5.1 Replacing the Front Panel Assembly........................... 26
6.5.2 Replacing the Display Module..................................... 26
6.6 Cavity Lights ....................................................................... 27
6.6.1 Replacing the Bulb ...................................................... 27
6.6.2 Replacing the Lamp Receptacle Assembly................. 28
6.7 Convection Fan, Ring Element and Motor.......................... 29
6.7.1 Replacing the Convection Fan Blade .......................... 29
6.7.2 Replacing the Ring Element........................................ 29
6.7.3 Replacing the Convection Fan Motor .......................... 30
6.8 Broil Element ...................................................................... 30
6.8.1 Replacing the Broil Element ........................................ 30
6.9 Bake Element ..................................................................... 31
6.9.1 Replacing the Bake Element ....................................... 31
6.10 Temperature Sensor........................................................... 31
6.11 Control Module (Relay Board) and Daughter Board........... 31
6.11.1 Replacing the Control Module or Daughter Board....... 32
6.12 Cooling Fan ........................................................................ 32
6.12.1 Replacing the Cooling Fan .......................................... 33
6.13 Hinge Receivers ................................................................. 33
6.13.1 Replacing the Hinge Receivers (bottom-hinge)........... 33
7Troubleshooting....................................................................... 35
7.1 Error Codes ........................................................................ 35
7.2 Service Mode...................................................................... 39
7.2.1 Accessing Service Mode ............................................. 39
7.2.2 Setting the Option Code.............................................. 39
7.3Fault Trees.......................................................................... 40
7.5 Wiring Diagrams and Schematics....................................... 44
7.5.1 Wire Color Key ............................................................ 44
7.5.2 Strip Diagrams............................................................. 44
8Additional References............................................................. 45
8.1 QuickFinder ........................................................................ 45
8.2 Technical Support............................................................... 45

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 3 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
1 SYMBOLS USED IN THIS MANUAL
WARNING – this symbol alerts you to dangers that may
result in bodily injury or death
CAUTION – this symbol alerts you to actions that may
result in damage to the product or property

NOTICE – this symbol alerts you to important information
and/or service tips.
VIDEO – this symbol indicates there is related service
video available for viewing on QuickFinder
!
!

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 4 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
2 IMPORTANT SAFETY INFORMATION
Before starting to service an appliance, familiarize yourself with all
safety information and precautions included in this manual.
2.1 Safety Before Servicing the Appliance
WARNING
Use of replacement parts…
Use only authorized replacement parts for this appliance. Use of
unauthorized substitutions may cause non-compliance with safety
standards set for home appliances, will void the warranty, and may
create safety hazards resulting in damage, bodily injury, or death.
!
WARNING
Electrical hazards…
Before servicing the appliance, remove electrical power by
either disconnecting the power cord from the wall receptacle
or by putting the circuit breaker in the OFF position.
If tests must be conducted while the appliance is live, always
use a residual-current-operated circuit breaker. The
protective conductor connection must not exceed the
recommended values.
When repairs are complete, perform a function test in
accordance with the appropriate regulations.
Do not, under any circumstances, cut or remove the separate
ground wire or the third (ground) prong from the power cord
plug.
Improper grounding or reverse polarization will cause
malfunction, which can damage the appliance and create an
electrical shock hazard. Make sure the circuit is properly
grounded and polarized in accordance with applicable local
codes and ordinances. Receptacle replacement shall be in
accordance with the National Electric Code.
!
WARNING
Sharp components…
This appliance has sheet metal parts and components which may
have sharp edges. Avoid injury by handling parts with care and using
adequate protective measures, such as wearing gloves.
!
WARNING
Before disassembly, removal, or installation of any
component…
Turn off electrical power by removing the power cord from
the electrical outlet or putting the circuit breaker in the OFF
position.
Be sure the entire appliance has cooled to a safe
temperature.
!

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 5 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
WARNING
Clean-up hazards…
Do not allow any cleaning or polishing solutions/compounds,
disinfectants, or bleaches to remain in contact with the stainless steel
surfaces for long periods, or after clean-up. These may contain
chemicals or materials which could release harmful inhalants and
may cause damage to the appliance. After cleaning or polishing,
always rinse the cleaning/polishing materials with clear water and
wipe dry with a clean, soft, non-abrasive cloth.
!
WARNING
Prior to returning appliance to service, confirm that…
All electrical connections are correct and secure
All safety grounds (internal and external) are correctly and
securely connected
All panels and components are properly and securely
reassembled.
!

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 6 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
CLASS
HB=built-in oven
HS=built-in steam oven
S
IZE
L=30”
N=27”
E=24” *
* Canada
only
SERIES
5=500
8= 800
P=Benchmark
C
AVITY TYPE
3=Single:
thermal
4=Single:
EU convection
5=Double:
thermal/thermal
6=Double:
EU convec/thermal
or EU convec both
C
OLOR
5=SS
6=Blk
V
ARIANT
1=2014 launch
C
OUNTRY
UC = US/Canada
H B L P4 5 1 L U C
DOOR HINGE POSITION *
L = Left side hinges
R = Right side hinges
* Absence of R/L indicates
model with bottom hinges
Figure 1Model number nomenclature
3 GENERAL
There are eight Benchmark Series 30” models in various
configurations included in the 2014 Bosch built-in wall oven product
line. All models feature Euro-convection (convection fan and ring
element) and TFT full-color displays with touch controls. The lineup
includes models with bottom-hinge doors, right or left side-swing
doors, and two field-assembled combination models, one with a 240V
Microwave Speed Oven and another with a Steam Convection Oven.
Stainless steel is the only finish offered on Benchmark models, which
have control panels and door skins made of grade 439 stainless steel
(magnetic).
The wall ovens are designed to be installed flush with cabinetry.
3.1 Recap of Functional/Technical Changes
Cooling fan: now operates with a variable speed protocol.
Hall effect sensor has been eliminated, and thermal limiter
(HTC) has been added.
Power supply: now located on the control module (relay
board) rather than as a separate component.
Control module: CM controls oven operation only. The user
interface software and operation is separate. The controls are
connected via Dbus.
User interface: TFT-based display with capacitive touch panel
managed by a separate touch control module (TCM).
Daughter board (double ovens only): populated with relays to
operate the lower oven.
Ventilation: air flows up through each door, then back out
over each door as air exits the appliance; some air is pulled
into the unit at the lower vent area under the appliance.
Lighting: Soft lighting is standard on all models. Double oven
lighting is not independent – lights operate concurrently.
Temperature control: now a two-point control for all modes
rather than a PID control for all modes.
Hinges: Models with bottom hinge soft-close doors and
models with side-hinge doors are available.
3.2 Models
The model number structure for the 2014 wall ovens appears below.
3.2.1 Model Descriptions
HBLP451UC 30” Single oven with Euro-convection, bottom hinges
HBLP451LUC 30” Single oven with Euro-convection, left-side hinges
HBLP451RUC 30” Single oven with Euro-convection, right-side hinges
HBLP651UC 30” Double oven with Euro-convection both cavities,
bottom hinges

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 7 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 3 QuickFinder screen shot
Figure 4Data plate locations
HBLP651LUC 30” Double oven with Euro-convection both cavities,
left-side hinges
HBLP651RUC 30” Double oven with Euro-convection both cavities,
right-side hinges
HBLP751UC 30” Combination oven with 240V speed microwave and
Euro-convection oven (components are HMC80251UC
and HBLP751UCC)
HSLP751UC 30” Combination oven with steam convection oven and
Euro-convection oven (components of this model are
HSLP451UC and HBLP451UCC)
3.2.2 Combination Ovens (Sets)
The 2014 combination ovens (sets) are shipped together as individual
components, and are assembled at the customer’s home during
installation.
Although the combination ovens are sold using the combination
model SKU, the service documentation for the sets can be found
linked to the component models rather than the combination
model SKU.For example, the Benchmark series combination with
microwave speed oven is sold as HBLP751UC, but the service
documentation can be found in QuickFinder,linked to its components:
HBLP751UCC (wall oven) and HMC80251UC (microwave speed
oven). There is no service documentation linked to HBLP751UC, but
a cross-reference will appear in QuickFinder when HBLP8751UC is
entered (see Figure 3).
3.3 Data Plate
On bottom hinge models, the data plate reflecting model number and
FD number is located on the left side trim. On side hinge models, the
data plate is located on the side trim, opposite the door hinge.
NOTICE
Be prepared to provide the complete Model Number and FD
number printed on the data plate of the unit when contacting Bosch
Customer Support or Technical Support for assistance.
Figure 2Combination ovens (sets) ready to be shipped

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 8 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
The first 4 positions of the FD number reflect the year/month the
product was built. FD numbers that begin with 94 were built in 2014;
95 = 2015; 96 = 2016, etc. An FD of 9404 indicates the oven was built
in April 2014.
3.4 Warranty
The product is warranted to be free from defects in materials and
workmanship for a period of 365 days from date of purchase.
Bosch will have no responsibility or liability for repairs or work
performed by a non-authorized servicer.
Find the complete Statement of Limited Product Warranty in the
product’s Use and Care Manual.

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 9 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
4 OPERATION
This section includes basic information about how the Benchmark
Series wall ovens operate.
4.1 Allowable Operating Range by Cooking
Mode
Table 1 reflects the minimum and maximum temperature for each
cooking mode.
Cooking Mode
Models
Min
Max
Default
Bake
All
100°F 550°F 350°F
Broil (Low 450°F /
High 550°F)
450°F 550°F High
Roast 100°F 550°F 325°F
Warm
140°F
225°F
170°F
Sabbath 100°F 425°F N/A
Self-Cleaning 2
hours
4 hours 3 hours
Proof Dough 85°F 125°F 100°F
Convection Bake
100°F
550°F
325°F
Convection Broil 450°F 550°F High
Convection Roast
100°F
550°F
325°F
Frozen Foods
(Speed Convection) 100°F 550°F 400°F
Pizza
100°F
550°F
400°F
Multi-Rack
Convection 100°F 550°F 325°F
Fast Preheat N/A N/A
N/A for Broil,
Conv Broil,
Proof Dough
or Warm
Cooking Mode Models Min Max Default
Convection
Conversion N/A N/A
Auto Temp
Reduction by
25°F
Auto Probe All (upper only
on dbl ovens)
100°F 200°F N/A
EcoChef
TM
100°F
550°F
325°F
4.2 Heating Elements
All ovens include an 8-pass 3800W broil element, 4-pass 2400W bake
element, and a 2000W convection (ring) element.
When the door is opened, all heating elements (and the convection
fan, if applicable) will be paused. When the door is closed, cycling will
continue.
4.2.1 Elements Used by Cooking Mode
The table below reflects the elements which are used for each
cooking mode.
Cooking Mode
Elements Used
Description
Bake
Broil, Bake
Upper and lower elements cycle to
maintain oven temperature.
Broil
Broil
Intense heat is radiated from the upper
element.
Roast
Broil, Bake
Upper and lower elements cycle to
maintain oven temperature; more intense
heat from the upper element is used than
the lower.
Table 1Allowable temperature range by cooking mode

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 10 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Cooking Mode Elements Used Description
Warm
Broil, Bake
Upper and lower elements cycle to
maintain a low oven temperature.
Proof Dough
Bake
Lower element is used to maintain a low
temperature.
Self-clean
Broil, Bake
Upper and lower elements cycle to
maintain oven temperature; more intense
heat from the upper element is used than
the lower.
Convection Bake
Broil, Bake,
Conv Fan
Upper and lower elements cycle to
maintain oven temp, and the heat is
circulated by the convection fan.
Convection Broil
Broil, Conv Fan
Intense heat is radiated from the upper
element and the convection fan circulates
the air.
Convection Roast
Broil, Bake,
Conv Fan
Upper and lower elements cycle to
maintain oven temperature and air is
circulated by the convection fan; more
intense heat from the upper element is
used than the lower.
Convection
Multi-rack
Conv Element,
Conv Fan
Heat is generated by the convection ring
element and circulated by the convection
fan.
Frozen Foods
Broil, Bake,
Conv Element,
Conv Fan
All elements and convection fan are used
to evenly distribute heat throughout
cavity. Preheat not required.
Pizza
Broil, Bake,
Conv Fan
Upper and lower elements cycle to
maintain oven temp, and the heat is
circulated by the convection fan.
Cooking Mode Elements Used Description
EcoChefTM Same as Convection Roast; meat probe monitors food temp
and controls oven accordingly.
4.2.2 Element Duty Cycles
A two-point control is used for all cooking modes. Tables 3-5 reflect
duty cycle times for each mode during Preheat, Fast Preheat and
Regulate.
Table 2Active elements by cooking mode
Table 3Element duty cycles during Preheat

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 11 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 5 Touch panel / Display
4.2.3 Setting Temperature Offsets
In some cases, it may be necessary to adjust the oven temperature if
the customer reports that food is consistently under- or over-cooked,
even though the oven is operating normally. Temperature Offsets can
be entered by the customer from the Settings menu to raise or lower
the cavity temperature during operation in Bake, Roast, Convection
Bake, Convection Roast, and Convection Multi-rack modes. The
allowable Offset range is from 0°F to +/- 35°F (or 0°C to +/-19°C).
After accessing the Settings menu, the soft keys beneath the display
are used for navigation and editing.
1. Press Settings to access the Settings menu (from stand-by mode
only)
2. Scroll through the list of menu items using the center soft key, until
8 Temperature Offset is highlighted.
3. Press the soft key labeled Enter to edit the current setting.
4. Press (-) or (+) then enter the numeric value of the offset.
5. Press the soft key labeled Enter to save the current setting.
(Valid offset values are saved when the display changes from edit
mode back to display mode.)
6. Press Oven Clear/Off to exit the Settings menu.
Example: A +25° offset will result in a cavity temperature of 350°
when the cooking temperature is set to 325° for any of the cooking
modes affected by the Offset. Similarly, a -25° offset will result in a
cavity temperature of 300° when the cooking temperature is set to
325°.
For double ovens, a temperature offset may be set for each oven.
Table 5Element duty cycles during Regulate
Table 4Element duty cycles during Fast Preheat

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 12 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
The adjusted temperature cannot be less than the minimum allowable
temperature for the cooking mode, nor higher than the maximum for
the cooking mode. See Allowable Operating Range by Cooking Mode
section.
4.3 Self-clean
In a double oven, if Self-clean is running in one cavity, the second
cavity will be disabled until the cycle finishes.
4.4 Cooling Fan
The cooling fan is used to maintain allowable temperatures on internal
components and customer-accessible surfaces.
During Preheat, the fan speed will increase based on cavity
temperature until the final speed is reached at the conclusion of
Preheat. Throughout the Regulate phase of the cooking cycle, the fan
speed will remain constant.
During Self-clean, the cooling fan will run at high speed immediately
after the self-clean cycle begins, regardless of temperature. The fan
will remain at this speed for the entire self-clean cycle.
The cooling fan will run until the cavity temperature is cooler than
491°F (255°C). Once that temperature is reached, the fan will run for
an additional 15 minutes, even if the oven is off. If the cavity
temperature never exceeded 491°F (255°C) during operation, the fan
would not have run at all.
When any of the following errors occur, the cooling fan will operate at
100% until the error is cleared: E101/E201, E002/E302, E303,
E104/E204. See the Error Code Table for more information about
these error codes.

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 13 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 6Service panel with Service Guide (wire diagram) attached to the inside of the panel.
5 COMPONENT ACCESSIBILITY
5.1 Serviceable from the Front
Front panel (service assembly includes skin, touch pad, touch
control module (TCM))
Display module
Switches
Door
Door latch/motor assembly
Resettable High Temperature Cutout (HTC) *
Cavity Light Receptacles
Convection fan blade
Convection ring element **
Temperature sensor
Smoke eliminator (catalyst)
Broil reflector and element **
* If it is not possible to service the resettable HTC through the latch plate
opening, see the Resetting and Replacing the HTC section.
** If the broil or convection ring element wires are too short to service from
the front, access to the rear of the oven will be required.
5.2 Serviceable from the Side
With the unit pulled completely away from the back wall and the side
housing panel(s) and trim removed, the following components are
serviceable…
Hinge receivers
Meat probe receptacle
5.3 Serviceable from the Rear
With the unit pulled completely out of the cutout and the back housing
panel(s) removed, the following components can be serviced from the
rear…
Convection fan motor
Convection ring element *
Broil element *
Bake element
Cooling fan
* If the broil or convection ring element wires are too short to service from the
front, access to the rear of the oven will be required.
5.4 Serviceable from the Top
There is a service panel located on the top front housing cover. With
the service panel open, there is limited access to the top front plenum
area. The control module is accessible for troubleshooting purposes.

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 14 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
1
2
1 – RH service slide
2 – RH locking screw
Figure 7Location of RH rail locking screw on combo oven
Figure 8Top view of wall oven and microwave conduit/feeder wire connection in junction box.
The following components are located in the front area of the top
plenum, and it may be possible to service them through the service
panel without removing the top front and/or rear housing cover(s)…
Control module (relay board)
Daughter board (double ovens only)
Terminal block
5.4.1 Top Access: Non-combination Models
To reach the service panel, remove the screws securing the side trim
to the cabinetry, and slide the oven out of the cutout ~8-9 inches.
For unrestricted access to the top front plenum area, remove the
screws securing the side trim pieces to the cabinetry, then slide the
oven out of the cutout approximately ~16 inches, and remove the top
front housing cover completely.
5.4.2 Top Access: Combination Models
To reach the service panel on an HBLP751UCC or HSLP751UCC
oven, follow the steps below...
1. Remove the screws securing the right
and left side trim pieces to the
cabinetry.
2. Carefully slide the combination oven
out of the cutout ~8-9 inches.
3. Remove the locking screw from
the right and left service slides (see
Figure 7).
4. Carefully slide the microwave or
steam oven to the rear ~7 inches; the
service access panel will be
accessible.
If unrestricted access to the top plenum area of the traditional wall
oven, the speed microwave or steam convection oven will need to be
removed.
Note that the length of the conduit/feeder wires which connect the
microwave or steam oven to the oven beneath it are ~5’ long. If there
is a work table nearby, it may not be necessary to disconnect the
feeder wires from the terminal block located in the oven-mounted
junction box on the top of the oven housing.
 CAUTION
When servicing the standard wall oven component of an
HBLP751UC or HSLP751UC combination oven, only the top front
service access panel will be accessible without removing the
microwave oven or steam oven.
If additional access to the top area of the oven is required, the
microwave or steam oven component must be removed. To safely
remove and reinstall the microwave or speed oven, two people
are required.

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 15 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 9Removing screws securing microwave to universal brackets on top of wall oven.
Speed Oven Microwave
Wall Oven
Universal Brackets
To remove the microwave speed oven or steam convection oven…
1. Remove power to the combination oven.
2. Remove the screws securing the right and left side trim pieces to
the cabinetry.
3. Carefully slide the combination unit completely out of the cabinet
cutout.
4. Disconnect the feeder wires from the terminal block: only
necessary if a work table is not nearby, and the 5’ length of
conduit/wire will not be sufficient.
5. Remove the front decorative trim that is secured to the universal
brackets with two screws.
6. Remove the six screws which secure the microwave to the right
and left universal brackets.
7. Disconnect the speed microwave/steam convection feeder wires
at the terminal block in the oven-mounted junction box if the 5’
conduit/feeder wire length will not be sufficient.
8. Position a person on each side of the unit and carefully lift the
microwave or steam oven off of the universal brackets, and set
aside.
9. Remove the housing cover panels as required for service.

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 16 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 10 Opening the hinge lever
6 SERVICE AND REPAIR
The HBLP451UC, HBLP651UC, HBLP751UCC and HSLP751UCC
doors are soft-close and have bottom hinges. The HBLP451LUC,
HBLP451RUC, HBLP651LUC and HBLP651RUC doors have side
hinges. The structure and servicing of each door type assembly and
its components are somewhat different. Refer to Section 6.1 for
bottom-hinge door service information and Section 6.2 for side-hinge
door service information.
On all double ovens, the Bosch logo is located on the upper oven
door skin.
6.1 Bottom-Hinge Doors
The serviceable parts of the soft-close door with bottom hinges
include the handle, endcaps, outer door glass/skin (service
assembly), hinges (service kit with one dampen hinge and one spring
hinge), 2-pane glass pack, porcelain-coated door liner, and the
various fasteners.
6.1.1 Removing and Reinstalling the Door
To remove the door…
1. Open door completely.
2. Flip right and left hinge levers back to open, as shown below; be
sure the levers are in the fully open position. (The RH and LH
hinges differ slightly, but operate in the same manner.)
CAUTION
Avoid injury when removing and replacing oven doors.
Be sure oven is cool enough for handling.
Position hinges properly (see Figure 5).
Grasp only by sides, not by the handle.
Do not force door open or closed.
Handle with care–the door weighs approximately 40 lb.
CAUTION
Sheet metal parts often have sharp edges. Avoid injury by
handling these parts with care.
Turn off the electrical power circuit to the oven at the main junction
box before servicing this unit.
For those checks requiring the use of electrical power, exercise
extreme care.
NOTICE
It may be necessary to use a tool, such as a screwdriver, to gently
pry the upper part of the lever away from the housing. Take care to
avoid scratching the porcelain.

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 17 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 13 Removing door liner screws
Figure 11 Position the hinge in the hinge slot
3. Partially close the oven door until it is open about 7” and catches
on the hinge-stop levers.
4. Using both hands, lift door upward and outward to disengage the
hinges from the hinge receiver slots.
5. Set the door aside on a protected flat surface.
To reinstall the door…
1. Hold the door firmly in both hands and position the hinges in the
hinge receivers, so that the slot in the base of the hinge (A)
engages with the hinge receiver (B).
2. Tilt the door inward and slide the hinges into place; the hinges
should catch and the door should remain in place.
3. Open door fully to expose the hinge levers and hinge receiver
slots.
4. Flip the right and left hinge levers forward until they are fully
closed.
5. Open and close the door carefully to confirm that the door is
installed correctly and securely, and does not appear to be askew
when closed.
6. Carefully close and open door several times to check operation.
6.1.2 Replacing the Hinges
The doors on Bosch Benchmark series ovens are soft-close, and
operate using one dampen hinge and one spring hinge. The hinges
are offered in service kits which include both the RH and LH hinges;
always replace hinges in pairs.
To access the hinges…
1. Remove the door as described in the Removing and Reinstalling
the Door section.
2. With the porcelain-coated door liner up, remove the two screws on
each side of the door liner.
3. Remove the screws along the bottom of the door assembly.
NOTICE
The dampen hinge has a cylinder inside which holds oil that acts as
the dampening fluid and causes the soft-close effect. The oil must be
in the bottom of the cylinder. If the door does not close softly, allow
the hinge time to recover in the vertical position (door closed) for 15-
30 minutes, then re-test door operation. See bulletin packed with
hinge kits for more information.
Figure 12 Closing hinge lever

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 18 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 15 Location of screws securing hinges to inner support frame assembly
Figure 14 Removing inner support frame assembly
Figure 16 Removing door liner screws
4. Lift the liner away from the rest of the door assembly and set
aside.
5. Remove the screws at the top left and top right which secure
the handle to the door assembly.
6. Carefully lift the inner support frame with glass pack and
hinges away from the outer door glass/skin assembly and lay
flat on the work surface.
7. Lift the two pieces of insulation off the inner support frame
assembly and set aside.
8. Remove the screws on the upper right and lower left which
secure the hinges to the inner support frame.
9. Lift the inner support frame upwards to access the hinges.
10. Install new right and left hinges and reassemble the door.
11. Test operation of the door by fully opening and closing it
several times.
6.1.3 Replacing the 2-Pane Glass Pack
To access the glass pack…
1. Remove the door as described in the Removing and Reinstalling
the Door section.
2. With the porcelain-coated door liner up, remove the two screws on
each side of the door liner.
3. Remove the screws along the bottom of the door assembly.
4. Lift the liner away from the rest of the door assembly and set
aside.
5. Remove the screws at the top left and top right which secure the
handle to the door assembly.
6. Carefully lift the inner support frame with glass pack and hinges
away from the outer door glass/skin assembly and lay flat on the
work surface.
CAUTION
Wear protective gloves when disassembling the door. When replacing the
glass pack due to broken glass, exercise extra care to avoid injury from
broken glass.

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 19 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 19 Removing lower hinge assembly screws
7. Lift the two pieces of insulation off the inner support frame
assembly and set aside.
8. Remove the screws securing the right and left side door shields
and set shields aside.
9. Carefully lift the glass pack out of the inner support frame.
10. After removing and discarding all remnants of broken glass, install
the new glass pack assembly and reassemble the door.
11. Test operation of the door by fully opening and closing it several
times.
6.2 Side-Hinge Doors
The serviceable parts of the side-hinge door include the handle,
endcaps, outer door glass/skin (service assembly), side hinge
assembly, 2-pane glass pack, middle glass, porcelain-coated door
liner, latch receiver assembly, and the various fasteners.
6.2.1 Removing and Reinstalling the Door
To remove the door…
1. Open door fully.
2. Remove 3 Torx T-20 screws securing lower hinge to chassis (A);
do not remove the Phillips-head screw (B) – this controls the
door alignment cam.
Figure 17 Removing inner support frame assembly
Figure 18 Removing 2-pane glass pack
1
2
3
1 Door side shield
2 Inner support frame
3 Two-pane glass pack
CAUTION
Avoid injury when removing and replacing oven doors.
Be sure oven is cool enough for handling.
Grasp only by sides, not by the handle.
Do not force door open or closed.
Handle with care–the door weighs approximately 40 lb.

58300000181895 ARA EN A JUNE 2014 Service Manual for Bosch Benchmark Series Built-in Wall Ovens
Page 20 of 45
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 21 Side view of lower hinge and cavity front
3
1 – Hanging pin
2 – Alignment cam
3 – Cutouts on cavity front for upper/lower hanging pins
Figure 20 Removing upper hinge assembly screws
A– Three T-20 torx
screws secure upper
hinge to chassis
B – Phillips-head screw
Tip: The top
of the hinge
should be
parallel with
the bottom
edge of the
control
panel.
Tip: The
sides of
these T-20
screw slots
should be
visible when
the hinges
are properly
aligned.
Figure 22 Hinge position when reinstalling door
3. Remove 3 torx-head screws securing the upper hinge to chassis
(A); do not attempt to remove the Phillips-head screw (B).
4. Using both hands, carefully lift door slightly upward and outward to
disengage the hanging pins from the upper and lower key hole
cutouts in the cavity front.
5. Set the door aside on a protected flat surface.
To re-install the door…
1. Open and align the upper and lower hinges to approximately 135°
open.
2. Hold the door securely with both hands, and position the door on
the front frame of the chassis, guiding the hanging pin on the top
hinge into the keyhole on the front frame.
3. Position the top hinge fully against the front frame, then slide the
top hinge toward the side trim until both hinges rest against the
side trim. (The outermost edge of the hinge will also be flush with
the side of the control panel.)
4. Lift the weight off the hinges and loosely re-install the three torx
screws in the upper hinge (leave one or two turns left on each
screw).
5. Confirm that the upper hinge is parallel with the control panel and
tighten the three torx screws.
6. Confirm that the lower hinge is still in place, and release the door.
