Bosch HBA43R1 0B Series User manual

[en] Instruction manual
Built-in oven
HBA43R1.0B

3
Table of contents [en]Instructionmanual
Important safety information.....................................................4
Causes of damage .............................................................................5
Your new oven ............................................................................6
Control panel .......................................................................................6
Buttons and display............................................................................6
Function selector.................................................................................6
Temperature selector .........................................................................6
Cooking compartment .......................................................................7
Your accessories ........................................................................7
Inserting accessories .........................................................................7
Optional accessories .........................................................................7
After-sales service products .............................................................9
Before using the oven for the first time....................................9
Setting the clock .................................................................................9
Heating up the oven...........................................................................9
Cleaning the accessories..................................................................9
Setting the oven..........................................................................9
Type of heating and temperature ....................................................9
Rapid heating ................................................................................... 10
Setting the time-setting options..............................................10
Timer .................................................................................................. 10
Cooking time .................................................................................... 10
End time............................................................................................. 11
Clock .................................................................................................. 11
Childproof lock .........................................................................11
Changing the basic settings ...................................................12
Cleaning system .......................................................................12
Before cleaning ................................................................................ 12
Making settings ................................................................................ 12
After cleaning.................................................................................... 12
Care and cleaning ....................................................................12
Cleaning agents ............................................................................... 13
Detaching and refitting the rails .................................................... 13
Detaching and attaching the oven door...................................... 13
Removing and installing the door panels ................................... 14
Troubleshooting .......................................................................15
Malfunction table.............................................................................. 15
Replacing the bulb in the oven ceiling light ............................... 15
Glass cover ....................................................................................... 15
After-sales service ...................................................................15
E number and FD number ............................................................. 15
Energy and environment tips..................................................16
Saving energy................................................................................... 16
Environmentally-friendly disposal.................................................. 16
Tested for you in our cooking studio .....................................16
Cakes and pastries ......................................................................... 16
Baking tips ........................................................................................ 18
Meat, poultry, fish.............................................................................18
Tips for roasting and grilling.......................................................... 21
Preprepared products..................................................................... 21
Special dishes .................................................................................. 22
Defrost................................................................................................ 22
Drying ................................................................................................. 23
Preserving ......................................................................................... 23
Acrylamide in foodstuffs .........................................................24
Test dishes ................................................................................25
Baking ................................................................................................ 25
Grilling ................................................................................................ 25
Produktinfo
Additional information on products, accessories, replacement
parts and services can be found at www.bosch-home.com and
in the online shop www.bosch-eshop.com

4
: Important safety information
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for
future use or for subsequent owners.
This appliance is only intended to be fully
fitted in a kitchen. Observe the special
installation instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance
if it has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused
by incorrect connection is not covered
under warranty.
This appliance is intended for domestic use
only. The appliance must only be used for
the preparation of food and drink. The
appliance must be supervised during
operation. Only use this appliance indoors.
This appliance is intended for use up to a
maximum height of 2000 metres above sea
level.
This appliance may be used by children
over the age of 8 years old and by persons
with reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around
the appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 8 years old and are
being supervised.
Keep children below the age of 8 years old
at a safe distance from the appliance and
power cable.
Always slide accessories into the cooking
compartment correctly. See "Description of
accessories in the instruction manual.
Risk of fire!
■Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off
the appliance and unplug it from the
mains or switch off the circuit breaker in
the fuse box.
Risk of fire!
■A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating
element and catch fire. Do not place
greaseproof paper loosely over
accessories during preheating. Always
weight down the greaseproof paper with a
dish or a baking tin. Only cover the
surface required with greaseproof paper.
Greaseproof paper must not protrude over
the accessories.
Risk of burns!
■The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with
care.
Risk of scalding!
■The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■When you open the appliance door, hot
steam may escape. Open the appliance
door with care. Keep children at a safe
distance.
Risk of scalding!
■Water in a hot cooking compartment may
create hot steam. Never pour water into
the hot cooking compartment.

5
Risk of injury!
Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out by one of our
trained after-sales engineers. If the
appliance is faulty, unplug the mains plug
or switch off the fuse in the fuse box.
Contact the after-sales service.
Risk of electric shock and serious injury!
■The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact
with hot parts of the appliance.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■When replacing the cooking compartment
bulb, the bulb socket contacts are live.
Before replacing the bulb, unplug the
appliance from the mains or switch off the
circuit breaker in the fuse box.
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of burns!
The appliance will become very hot on the
outside during the cleaning function. Never
touch the appliance door. Allow the
appliance to cool down. Keep children at a
safe distance.
Causes of damage
Caution!
■Accessories, foil, greaseproof paper or ovenware on the
cooking compartment floor: do not place accessories on the
cooking compartment floor. Do not cover the cooking
compartment floor with any sort of foil or greaseproof paper.
Do not place ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will cause heat
to accumulate. The baking and roasting times will no longer
be correct and the enamel will be damaged.
■Water in a hot cooking compartment: do not pour water into
the cooking compartment when it is hot. This will cause
steam. The temperature change can cause damage to the
enamel.
■Moist food: do not store moist food in the cooking
compartment when it is closed for prolonged periods This will
damage the enamel.
■Fruit juice: when baking particularly juicy fruit pies, do not
pack the baking tray too generously. Fruit juice dripping from
the baking tray leaves stains that cannot be removed. If
possible, use the deeper universal pan.
■Cooling with the appliance door open: only allow the cooking
compartment to cool when it is closed. Even if the appliance
door is only open a little, front panels of adjacent units could
be damaged over time.
■Very dirty door seal: If the door seal is very dirty, the
appliance door will no longer close properly when the
appliance is in use. The fronts of adjacent units could be
damaged.Always keep the door seal clean.
■Appliance door as a seat, shelf or worktop: Do not sit on the
appliance door, or place or hang anything on it. Do not place
any cookware or accessories on the appliance door.
■Inserting accessories: depending on the appliance model,
accessories can scratch the door panel when closing the
appliance door. Always insert the accessories into the
cooking compartment as far as they will go.
■Carrying the appliance: do not carry or hold the appliance by
the door handle. The door handle cannot support the weight
of the appliance and could break.

6
Your new oven
Here you will learn about your new oven. The control panel and
the individual operating controls are explained. You will find
information on the cooking compartment and the accessories.
Control panel
Here, you will see an overview of the control panel. All of the
symbols never appear in the display at the same time.
Depending on the appliance model, individual details may
differ.
Control knobs
The control knobs are retractable. To lock it in or out, press the
control knob in the off position.
Buttons
The sensors are located under the individual buttons. They
must not be pressed too firmly. Only touch the corresponding
symbol.
Buttons and display
You can use the buttons to set various additional functions. On
the display, you can read the values that you have set.
The time-setting option that is currently selected in the display
is indicated by brackets [ ] around the corresponding symbol.
Exception: For the clock, the 0symbol only lights up if the time
is being changed.
Function selector
Use the function selector to set the type of heating.
When you make settings, the oven light in the cooking
compartment switches on.
Temperature selector
Use the temperature selector to set the temperature, grill
setting or cleaning setting.
When the oven is heating, the tsymbol lights up in the
display. It goes out during pauses in the heating.
)XQFWLRQVHOHFWRU
%XWWRQVDQGGLVSOD\
7HPSHUDWXUHVHOHFWRU
Button Use
cRapid heating Heats up the oven particularly
quickly.
uCleaning system Starts the cleaning system for the
self-cleaning surfaces in the cook-
ing compartment.
0Time-setting options Selects the timer U, cooking
time r, end time pand clock 0.
DChildproof lock Locks and unlocks oven functions.
A
@
Minus
Plus
Decreases the set values.
Increases the set values.
Setting Use
ÛOff position The oven switches off.
<3D hot air* For cakes and pastries on one to
three levels. The fan distributes the
heat from the heating ring in the
back panel evenly around the
cooking compartment.
* Type of heating used to determine the energy efficiency class
in accordance with EN50304.
%Top/bottom heating For cakes, bakes and lean joints of
meat (e.g. beef or game) on one
level. Heat is emitted evenly from
the top and bottom.
7Hot air grilling For roasting meat, poultry and
whole fish. The grill element and
the fan switch on and off alter-
nately. The fan causes the hot air
to circulate around the dish.
(Grill, large area For grilling steaks, sausages,
bread and pieces of fish. The
whole area below the grill heating
element becomes hot.
$Bottom heating For preserving, browning and final
baking stage. The heat is emitted
from below.
^Oven light Switches on the oven light.
Setting Meaning
ÚOff position The oven does not heat up.
50-270 Temperature
range
The temperature in the cooking
compartment in °C.
I, II, III Grill settings The grill settings for "Grill, large
area" (.
I = setting 1, low
II = setting 2, medium
III = setting 3, high
sCleaning setting The setting for the cleaning sys-
tem.
Setting Use
* Type of heating used to determine the energy efficiency class
in accordance with EN50304.

7
Cooking compartment
The oven light is located in the cooking compartment. A cooling
fan protects the oven from overheating.
Oven light
During operation, the oven light in the cooking compartment is
on. The ^setting on the function selector can be used to
switch on the light without heating the oven.
Cooling fan
The cooling fan switches on and off as required. The hot air
escapes above the door. Caution: do not cover the ventilation
slots. Otherwise the oven will overheat.
So that the cooking compartment cools down more quickly
after operation, the cooling fan continues to run for a certain
period afterwards.
Your accessories
The accessories supplied with your appliance are suitable for
making many meals. Ensure that you always insert the
accessories into the cooking compartment the right way round.
There is also a selection of optional accessories, with which
you can improve on some of your favourite dishes, or simply to
make working with your oven more convenient.
Inserting accessories
You can insert the accessories into the cooking compartment
at 5 different levels. Always insert them as far as they will go so
that the accessories do not touch the door panel.
The accessories can be pulled out approximately halfway until
they lock in place. This allows dishes to be removed easily.
When sliding the accessories into the cooking compartment,
ensure that the indentation is at the back. They can only lock in
place from this position.
With the pull-out rails at level 2, you can pull the accessories
out further.
Depending on the appliance equipment, the pull-out rails lock
into place when they are pulled out fully. This makes it easier
for you to place the accessories on top. To unlock, push the
pull-out rails back into the cooking compartment with a certain
amount of force.
Note: The accessories may deform when they become hot.
Once they cool down again, they regain their original shape.
This does not affect their operation.
You can buy accessories from the after-sales service, from
specialist retailers or online. Please specify the HEZ number.
Optional accessories
You can purchase optional accessories from the after-sales
service or specialist retailers. You will find a comprehensive
range of products for your oven in our brochures and on the
Internet. The availability of optional accessories and the option
for ordering these online varies from country to country. Please
see the sales brochures for more details.
Not all optional accessories are suitable for every appliance.
When purchasing, please always quote the exact designation
(E-no.) of your appliance.





Wire rack
For ovenware, cake tins, joints,
grilled items and frozen meals.
Insert the wire rack with the open
side facing the oven door and the
curvature pointing downwards ¾.
Insert grid
For roasting.
Place the wire insert in the universal
pan with the legs facing downwards.
This ensures that dripping fat and
meat juices are collected.
Universal pan
For moist cakes, pastries, frozen
meals and large roasts. It can also
be used to catch dripping fat when
you are grilling directly on the wire
rack.
Slide in the universal pan with the
sloping edge facing the oven door.
Optional accessories HEZ number Use
Wire rack HEZ334000 For ovenware, cake dishes, joints, grilled items and frozen
meals.
Enamel baking tray HEZ331003 For cakes and biscuits.
Push the baking tray into the oven with the sloping edge facing
towards the oven door.
universal pan HEZ332003 For moist cakes, baked items, frozen meals and large joints. It
can also be used to catch dripping fat when grilling directly on
the wire rack.
Slide the universal pan into the oven with the sloping edge fac-
ing the oven door.

8
Wire insert HEZ324000 For roasting. Always place the wire rack in the universal pan.
This ensures that dripping fat and meat juices are collected.
Grill tray HEZ325000 Use for grilling in place of the wire rack or as a splatter guard,
so that the oven does not become as dirty as it otherwise
might. Only use the grill tray in the universal pan.
Grilling on the grill tray: only use at shelf position 1, 2 and 3.
Using the grill tray as a splatter guard: insert the universal pan
with the grill tray under the wire rack.
Pizza tray HEZ317000 Ideal for pizza, frozen products or large round cakes. You can
use the pizza tray instead of the universal pan. Place the bak-
ing tray on the wire rack and proceed according to the details
in the tables.
Bakestone HEZ327000 The bakestone is perfect for preparing home-made bread,
bread rolls and pizzas which require a crispy base. The
bakestone must always be preheated to the recommended
temperature.
Enamel baking tray with non-stick coating HEZ331011 Cakes and biscuits can be removed more easily from the bak-
ing tray. Push the baking tray into the oven with the sloping
edge facing towards the oven door.
Universal pan with non-stick coating HEZ332011 Moist cakes, baked items, frozen meals and large joints can be
removed more easily from the universal pan. Slide the univer-
sal pan into the oven with the sloping edge facing the oven
door.
Profi extra-deep pan with wire insert HEZ333003 Ideally suited for preparing large amounts.
Lid for the Profi extra-deep pan HEZ333001 The lid converts the Profi extra-deep pan into the Profi roasting
dish.
Glass roasting dish HEZ915001 The glass roasting dish is suitable for stews and bakes that are
cooked in the oven. It is ideally suited to automatic pro-
grammes or automatic roasting.
Telescopic shelves
2-level HEZ338250 The pull-out rails fitted at positions 2 and 3 allow you to pull
accessories out further without them tipping.
3-level HEZ338352 The pull-out rails fitted at positions 1, 2 and 3 allow you to pull
accessories out further without them tipping.
The 3-level pull-out is not suitable for appliances that have a
rotary spit.
3-level complete pull-out HEZ338356 The pull-out rails fitted at positions 1, 2 and 3 allow you to pull
accessories out fully without them tipping.
The 3-level complete pull-out is not suitable for appliances that
have a rotary spit.
3-level complete pull-out with stop function HEZ338357 The pull-out rails fitted at positions 1, 2 and 3 allow you to pull
accessories out fully without them tipping. The pull-out rails
lock in position allowing accessories to be easily placed on
top.
The 3-level complete pull-out with stop function is not suitable
for appliances that have a rotary spit.
Self-cleaning side walls
Appliance with an oven light HEZ339020 You can retrofit side walls so that the cooking compartment
automatically cleans itself during operation.
Appliances with an oven light and automatic
roasting
HEZ339020 You can retrofit side walls so that the cooking compartment
automatically cleans itself during operation.
Self-cleaning oven ceiling and side walls
Appliances with one oven light and a folding
grill element
HEZ329020 You can retrofit the ceiling and side walls so that the cooking
compartment automatically cleans itself during operation.
Appliances with two oven lights and a folding
grill element
HEZ329022 You can retrofit the ceiling and side walls so that the cooking
compartment automatically cleans itself during operation.
Appliances with one oven light, a folding grill
element and a meat thermometer
HEZ329027 You can retrofit the ceiling and side walls so that the cooking
compartment automatically cleans itself during operation.
Steam filter HEZ329000 You can retrofit this to your oven. The steam filter filters out
grease particles from the exhaust air, thereby reducing odours.
Only for appliances with a 6, 7 or 8 as the second digit in the
E-no.(e.g. HBA38B750)
System steamer HEZ24D300 For a gentler preparation of vegetables and fish.
Optional accessories HEZ number Use

9
After-sales service products
You can obtain suitable care and cleaning agents and other
accessories for your domestic appliances from the after-sales
service, specialist retailers or (in some countries) online via the
eShop. Please specify the relevant product number.
Before using the oven for the first time
In this section, you can find out what you must do before using
your oven to prepare food for the first time. First read the
section on Safety information.
Setting the clock
After the appliance has been connected, the 0symbol and
four zeros flash in the display. Set the clock.
1. Press the 0button.
The clock in the display shows 12:00. The time symbols light
up and the brackets are around 0.
2. Use the @or Abutton to set the clock.
After a few seconds, the time that has been set is adopted.
Heating up the oven
To remove the new cooker smell, heat up the oven when it is
empty and closed. An hour of Top/bottom heating %at
240 °C is ideal for this purpose. Ensure that no packaging
remnants have been left in the cooking compartment.
Keep the kitchen ventilated the whole time the oven is on.
1. Use the function selector to set Top/bottom heating %.
2. Set the temperature selector to 240 °C.
After an hour, switch off the oven. To do so, turn the function
selector to the off position.
Cleaning the accessories
Before you use the accessories for the first time, clean them
thoroughly with hot soapy water and a soft dish cloth.
Setting the oven
There are various ways in which you can set your oven. Here
we will explain how you can select the desired type of heating
and temperature or grill setting. You can select the oven
cooking time and end time for your dish. Please refer to the
section on Setting the time-setting options.
Type of heating and temperature
Example in the picture: %Top/bottom heating at 190 °C.
1. The function selector is used to set the type of heating.
2. Set the temperature or grill setting using the temperature
selector.
The oven begins to heat up.
Switching off the oven
Turn the function selector to the off position.
Changing the settings
The type of heating and temperature or grill setting can be
changed at any time using their respective selectors.
Cleaning cloths for stainless-steel surfaces Product no. 311134 Reduces the build-up of dirt. Impregnated with a special oil for
perfect maintenance of your appliance's stainless-steel sur-
faces.
Oven and grill cleaning gel Product no. 463582 For cleaning the cooking compartment. The gel is odourless.
Microfibre cloth with honeycomb structure Product no. 460770 Especially suitable for cleaning delicate surfaces, such
as glass, glass ceramic, stainless steel or aluminium. The
microfibre cloth removes liquid and grease deposits in one go.
Door lock Product no. 612594 To prevent children from opening the oven door. The locks on
different types of appliance door are screwed in differently.
See the information sheet supplied with the door lock.

10
Rapid heating
With rapid heating, your oven reaches the temperature selected
particularly quickly.
Use rapid heating when temperatures above 100 °C are
selected. The following types of heating are suitable:
■<3D hot air
■%Top/bottom heating
To ensure an even cooking result, do not place your dish in the
cooking compartment until rapid heating is complete.
1. Set the type of heating and temperature.
2. Press the cbutton.
The csymbol lights up in the display. The oven begins to
heat up.
The rapid heating process is complete
A signal sounds. The csymbol in the display goes out. Put
your dish in the oven.
Cancelling rapid heating
Press the cbutton. The csymbol in the display goes out.
Setting the time-setting options
Your oven has various time-setting options. You can use the 0
button to call up the menu and switch between the individual
functions. All the time symbols are lit when you can make
settings. The brackets [ ] show you which time-setting option
you have currently selected. A time-setting option which has
already been set can be changed directly with the @or A
button when the relevant time symbol is in brackets.
Timer
You can use the timer as a kitchen timer. It runs independently
of the oven. The timer has its own signal. In this way, you can
tell whether it is the timer or a cooking time which has elapsed.
1. Press the 0button once.
The time symbols light up in the display and the brackets are
around U.
2. Use the @or Abutton to set the timer duration.
Default value for @button = 10 minutes
Default value for Abutton = 5 minutes
After a few seconds, the time setting is adopted. The timer
starts. The [U] symbol lights up in the display and the timer
duration counts down. The other time symbols go out.
The timer duration has elapsed
A signal sounds. 00:00 is shown in the display. Use the 0
button to switch off the timer.
Changing the timer duration
Use the @or Abutton to change the timer duration. After a few
seconds, the change is adopted.
Cancelling the timer duration
Use the Abutton to reset the timer duration to 00:00. The
change will be adopted after a few seconds. The timer is
switched off.
Checking the time settings
If several time-setting options are set, the relevant symbols are
illuminated on the display. The symbol for the time-setting
option that is visible in the display is shown in brackets.
To call up the Utimer, rcooking time, pend time or 0
clock, press the 0button repeatedly until the brackets are
around the relevant symbol. The display shows the value for a
few seconds.
Cooking time
The cooking time for your dish can be set on the oven. When
the cooking time has elapsed, the oven switches itself off
automatically. This means that you do not have to interrupt
other work to switch off the oven. The cooking time cannot be
accidentally exceeded.
Example in the picture: cooking time 45 minutes.
1. Use the function selector to set the type of heating.
2. Set the temperature or grill setting using the temperature
selector.
3. Press the 0button twice.
00:00 is shown in the display. The time symbols light up and
the brackets are around r.
4. Use the @or Abutton to set the cooking time.
Default value for @button = 30 minutes
Default value for Abutton = 10 minutes
The oven will start up after a few seconds. The cooking time
counts down in the display and the [r] symbol lights up. The
other time symbols go out.
The cooking time has elapsed
A signal sounds. The oven stops heating. 00:00 is shown in the
display. Press the 0button. You can set a new cooking time
using the @or Abutton. Or press the 0button twice and turn
the function selector to the off position. The oven switches off.
Changing the cooking time
Use the @or Abutton to change the cooking time. After a few
seconds, the change is adopted. If the timer has been set,
press the 0button beforehand.
Cancelling the cooking time
Use the Abutton to reset the cooking time to 00:00. After a few
seconds, the change is adopted. The cooking time is
cancelled. If the timer has been set, press the 0button
beforehand.

11
Checking the time settings
If several time-setting options are set, the relevant symbols are
illuminated on the display. The symbol for the time-setting
option that is visible in the display is shown in brackets.
To call up the Utimer, rcooking time, pend time or 0
clock, press the 0button repeatedly until the brackets are
around the relevant symbol. The display shows the value for a
few seconds.
End time
You can change the time at which you wish your dish to be
ready. The oven starts automatically and finishes at the desired
time. You can, for example, put your dish in the cooking
compartment in the morning and set the cooking time so that it
is ready at lunch time.
Ensure that food is not left in the cooking compartment for too
long as it may spoil.
Example in the picture: it is 10:30 am, the cooking time is
45 minutes and the oven is required to finish cooking at
12:30 pm.
1. Adjust the function selector.
2. Set the temperature selector.
3. Press the 0button twice.
4. Use the @or Abutton to set the cooking time.
5. Press the 0button.
The brackets are around p. The time when the dish will be
ready is displayed.
6. Use the @or Abutton to set a later end time.
After a few seconds, the oven adopts the settings and switches
to standby position. The time at which the dish will be ready is
shown in the display and the psymbol is in brackets. The U
and 0symbols go out. When the oven starts, you can see the
cooking time counting down in the display and the rsymbol is
in brackets. The psymbol goes out.
The cooking time has elapsed
A signal sounds. The oven stops heating. 00:00 is shown in the
display. Press the 0button. You can set a new cooking time
using the @or Abutton. Or press the 0button twice and turn
the function selector to the off position. The oven switches off.
Changing the end time
Use the @or Abutton to change the end time. After a few
seconds, the change is adopted. If the timer has been set, first
press the 0button twice. Do not change the end time if the
cooking time has already started to elapse. The cooking result
would no longer be correct.
Cancelling the end time
Use the Abutton to reset the end time to the current time. After
a few seconds, the change is adopted. The oven starts. If the
timer has been set, first press the 0button twice.
Checking the time settings
If several time-setting options are set, the relevant symbols are
illuminated on the display. The symbol for the time-setting
option that is visible in the display is shown in brackets.
To call up the Utimer, rcooking time, pend time or 0
clock, press the 0button repeatedly until the brackets are
around the relevant symbol. The display shows the value for a
few seconds.
Clock
After the appliance is connected or following a power cut, the
0symbol and four zeros flash in the display. Set the clock.
1. Press the 0button.
The clock in the display shows 12:00. The time symbols light
up and the brackets are around 0.
2. Use the @or Abutton to set the clock.
After a few seconds, the time that has been set is adopted.
Changing the clock
No other time-setting option should have been set.
1. Press the 0button four times.
The time symbols light up in the display and the brackets are
around 0.
2. Use the @or Abutton to change the clock.
After a few seconds, the time that has been set is adopted.
Hiding the clock
You can hide the clock. For more information, please refer to
the section Changing the basic settings.
Childproof lock
The oven has a childproof lock to prevent children from
switching it on by accident.
The oven will not respond to any settings.You can still set the
clock and the timer when the childproof lock is activated.
If the type of heating and temperature or grill setting are set, the
childproof lock interrupts the heater element.
Note: If a hob is connected, it will not be affected by the
childproof lock on the oven.
Activating the childproof lock
No cooking time or end time should be set.
Press and hold the Dbutton for approx. four seconds.
The Dsymbol appears in the display. The childproof lock is
activated.
Deactivating the childproof lock
Press and hold the Dbutton for approx. four seconds.
The Dsymbol goes out in the display. The childproof lock is
deactivated.

12
Changing the basic settings
Your oven has various basic settings. These settings can be
customised to suit your requirements.
No other time-setting option should have been set.
1. Press and hold the 0button for approx. 4 seconds.
The current basic setting for the clock display is shown in the
display, e.g. c1 1 for selection 1.
2. Use the @or Abutton to change the basic setting.
3. Confirm by pressing the 0button.
The next basic setting appears in the display. You can scroll
through all levels with the 0button and change the setting
with the @or Abutton.
4. To finish, press and hold the 0button for approx. 4 seconds.
All basic settings are applied.
You may change the basic settings at any time.
Cleaning system
The cleaning system regenerates the self-cleaning surfaces in
the cooking compartment.
The back wall, ceiling and side walls of the cooking
compartment are coated with a highly porous ceramic layer.
This coating absorbs and disintegrates splashes from baking
and roasting while the oven is in operation. If these self-
cleaning surfaces no longer clean themselves adequately, they
can be regenerated with the cleaning system.
Before cleaning
Remove accessories and cookware from the cooking
compartment.
Cleaning the cooking compartment floor
Before you set the cleaning system, clean the surfaces in the
cooking compartment that are not self-cleaning. Otherwise,
stains will develop that it is not possible to remove.
Use a dish cloth and hot soapy water or a vinegar solution. If
there are heavy deposits of dirt, use a stainless steel scouring
pad or oven cleaner. Only use when the cooking compartment
is cold. Never treat the self-cleaning surfaces with a scouring
pad or oven cleaner.
Making settings
Cleaning takes approximately one hour.
1. Set the function selector to <3D hot air.
2. Set the temperature selector to s.
3. Press theubutton.
The usymbol lights up in the display. The time at which the
cleaning will end appears and the psymbol is in brackets.
Cleaning will start after a few seconds. You will see the time
counting down and the rsymbol will be in brackets. The p
symbol goes out.
Cleaning is finished
A signal sounds. The oven stops heating. 00:00 is shown in the
display. Press the 0button twice and turn the function selector
to the off position. The oven switches off.
Cancelling cleaning
Press the ubutton and turn the function selector to the off
position. The oven switches off.
Setting a later end time
You can delay the time at which the cleaning programme is due
to finish. For instance, you can set the cleaning programme to
run at night so that you can use your oven during the day.
Make the settings as described in steps 1 to 3. Before cleaning
starts, use the @or Abutton to set a later end time.
The oven switches to standby. The display shows the time at
which the cleaning will finish and the psymbol is in brackets.
When cleaning starts, you can see the time counting down in
the display and the rsymbol is in brackets. The psymbol
goes out.
After cleaning
When the cooking compartment has cooled down completely,
wipe the salt residues off the self-cleaning surfaces with a
damp cloth.
Care and cleaning
With good care and cleaning, your oven will remain clean and
fully-functioning for a long time to come. Here we will explain
how to maintain and clean your oven correctly.
Notes
■Slight differences in the colours on the front of the oven are
caused by the use of different materials, such as glass,
plastic and metal.
■Shadows on the door panel which look like streaks, are
caused by reflections made by the oven light.
■Enamel is baked on at very high temperatures. This can
cause some slight colour variations. This is normal and does
not affect their function. The edges of thin trays cannot be
completely enamelled. As a result, these edges can be
rough. This will not impair the anti-corrosion protection.
Basic setting Selection 1 Selection 2 Selection 3
c1 Clock display always* only with
the 0but-
ton
-
c2 Signal duration
upon completion of
a cooking time or
timer period
approx.
10 seconds
approx.
2 minutes*
approx.
5 minutes
c3 Waiting time until a
setting is applied
approx.
2 seconds
approx.
5 seconds*
approx.
10 seconds
* Factory setting

13
Cleaning agents
To ensure that the different surfaces are not damaged by using
the wrong type of cleaning agent, observe the information in the
table. Do not use
■harsh or abrasive cleaning agents,
■cleaning agents with a high concentration of alcohol,
■hard scouring pads or sponges,
■high-pressure cleaners or steam cleaners.
Wash new sponge cloths thoroughly before use.
Cleaning the self-cleaning surfaces in the cooking
compartment
The back wall, ceiling and side walls of the cooking
compartment are coated with a highly porous ceramic layer.
This coating absorbs and disintegrates splashes from baking
and roasting while the oven is in operation. The higher the
temperature and the longer the oven is in operation, the better
the result will be.
Never treat the self-cleaning surfaces with oven cleaner.
If the self-cleaning surfaces no longer clean sufficiently, they
can be regenerated with the cleaning system. For more
information, please see the Cleaning system section.
Light discolouration of the coating does not affect automatic
self-cleaning.
Caution!
■Never use abrasive cleaning agents. You will scratch or
destroy the highly porous coating.
■Never treat the ceramic coating with oven cleaner. If oven
cleaner accidentally gets onto it, remove it immediately with a
sponge and plenty of water.
Cleaning the cooking compartment floor
Use a dish cloth and hot soapy water or a vinegar solution.
If there are heavy deposits of dirt, use a stainless steel scouring
pad or oven cleaner. Only use when the cooking compartment
is cold. Never treat the self-cleaning surfaces with a scouring
pad or oven cleaner.
Detaching and refitting the rails
The rails can be removed for cleaning. The oven must have
cooled down.
Detaching the rails
1. Lift up the front of the rail
2. and unhook it (figure A).
3. Then pull the whole rail forward
4. and remove it (Fig. B).
Clean the rails with cleaning agent and a sponge. For stubborn
deposits of dirt, use a brush.
Refitting the rails
1. First insert the rail into the rear socket, press it to the back
slightly (figure A),
2. and then hook it into the front socket (figure B).
The rails only fit on the right or the left side. Ensure that, as
shown in figure B, levels 1 and 2 are below and levels 3, 4 and
5 are above. The pull-out rail must be pulled out forwards.
Detaching and attaching the oven door
For cleaning purposes and to remove the door panels, you can
detach the oven door.
The oven door hinges each have a locking lever. When the
locking levers are closed (figure A), the oven door is secured in
place. It cannot be detached. When the locking levers are open
in order to detach the oven door (Fig. B), the hinges are locked.
They cannot snap shut.
Area Cleaning agents
Control panel Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth. Do not use glass cleaners or glass
scrapers.
Stainless steel Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth. Remove traces of limescale, grease,
starch and albumin (e.g. egg white) immedi-
ately. Corrosion can form under such resi-
dues.
Special stainless steel cleaning products
suitable for hot surfaces are available from
our after-sales service or from specialist
retailers. Apply a very thin layer of the
cleaning product with a soft cloth.
Door panels Glass cleaner:
Clean with a soft cloth. Do not use a glass
scraper.
Glass cover for
the oven light
Hot soapy water:
Clean with a dish cloth.
Seal
Do not remove.
Hot soapy water:
Clean with a dish cloth. Do not scour.
Rails Hot soapy water:
Soak and clean with a dish cloth or brush.
Telescopic
shelves
Hot soapy water:
Clean with a dish cloth or a brush.
Do not remove the lubricant while the pull-
out rails are pulled out – it is best to clean
them when they are inserted. Do not soak
or clean in the dishwasher.
Accessories Hot soapy water:
Soak and clean with a dish cloth or brush.


%


$
%
$

14
: Risk of injury!
Whenever the hinges are not locked, they snap shut with great
force. Ensure that the locking levers are always fully closed or,
when detaching the oven door, fully open.
Detaching the door
1. Open the oven door fully.
2. Fold up the two locking levers on the left and right (figure A).
3. Close the oven door as far as the limit stop. With both hands,
grip the door on the left and right-hand sides. Close the door
a little further and pull it out (figure B).
Attaching the door
Reattach the oven door in the reverse sequence to removal.
1. When attaching the oven door, ensure that both hinges are
inserted straight into the opening (figure A).
2. The notch on the hinge must engage on both sides (figure B).
3. Fold back both locking levers (figure C). Close the oven
door.
: Risk of injury!
If the oven door falls out accidentally or a hinge snaps shut, do
not reach into the hinge. Call the aftersales service.
Removing and installing the door panels
To facilitate cleaning, you can remove the glass panels from the
oven door.
Removal
1. Detach the oven door and lay it on a cloth with the handle
facing down.
2. Pull off the cover at the top of the oven door. Press in the
tabs on the left and right using your fingers (fig. A).
3. Lift the top panel up and pull it out (fig. B).
4. Lift the panel up and pull it out (fig. C).
Clean the panels with glass cleaner and a soft cloth.
: Risk of injury!
Scratched glass in the appliance door may develop into a
crack. Do not use a glass scraper, sharp or abrasive cleaning
aids or detergents.
Installation
During installation, make sure that the lettering "top right" is
upside down at the bottom left.
1. Insert the panel at an angle towards the back (fig. A).
2. Insert the top panel at an angle towards the back into the
brackets. The smooth surface must face outwards. (fig. B).
3. Put the cover back in place and press on it.
4. Attach the oven door.
Do not use the oven again until the panels have been
correctly installed.
%$
%$
%
$
&
%$
&
%
$

15
Troubleshooting
Malfunctions often have simple explanations. Refer to the table
before calling the after-sales service as you may be able to
remedy the fault yourself.
Malfunction table
If a dish does not turn out as well as you had hoped, refer to
the section Tested for you in our cooking studio, where you will
find plenty of cooking tips and notes.
Error messages
If an error message with “appears, press the 0button. The
message disappears. A time function that has been set is
cleared. If the error message does not disappear, please
contact the after-sales service.
You can take remedial action yourself if the following error
message is displayed.
: Risk of electric shock!
Incorrect repairs are dangerous. Repairs may only be carried
out by one of our trained after-sales engineers.
Replacing the bulb in the oven ceiling light
If the bulb in the oven light fails, it must be replaced. Heat-
resistant, 40 watt spare bulbs can be obtained from our after-
sales service or a specialist retailer. Only use these bulbs.
: Risk of electric shock!
Switch off the circuit breaker in the fuse box.
1. Place a tea towel in the oven when it is cold to prevent
damage.
2. Unscrew the glass cover by turning it anti-clockwise.
3. Replace the bulb with one of the same type.
4. Screw the glass cover back in.
5. Remove the tea towel and switch on the circuit breaker.
Glass cover
You must replace a damaged glass cover. Suitable glass
covers may be obtained from the after-sales service. Please
specify the E number and FD number of your appliance.
After-sales service
Our after-sales service is there for you if your appliance needs
to be repaired. We will always find the right solution in order to
avoid unnecessary visits from a service technician.
E number and FD number
When calling us, please give the product number (E no.) and
the production number (FD no.) so that we can provide you with
the correct advice. The rating plate containing these numbers
can be found on the right-hand side of the oven door. You can
make a note of the numbers of your appliance and the
telephone number of the after-sales service in the space below
to save time should it be required.
Please note that there will be a fee for a visit by a service
technician in the event of a malfunction, even during the
warranty period.
Please find the contact data of all countries in the enclosed
customer service list.
To book an engineer visit and product advice
Rely on the professionalism of the manufacturer. You can
therefore be sure that the repair is carried out by trained service
technicians who carry original spare parts for your appliances.
Problem Possible cause Remedy/information
The oven does
not work.
The circuit
breaker is
defective.
Look in the fuse box and
check that the circuit
breaker is in working order.
Power cut Check whether the kitchen
light or other kitchen appli-
ances are working.
0and zeros
flash in the dis-
play.
Power cut Reset the clock.
The oven does
not heat up.
There is dust on
the contacts.
Turn the control knobs back
and forth several times.
Error message Possible cause Remedy/information
“‹‚‚ A button was
depressed for
too long or is
covered up.
Press all buttons individu-
ally. Check whether any but-
tons are jammed, covered
up or soiled.
E no. FD no.
After-sales service O
GB 0344 892 8979
Calls charged at local or mobile rate.
IE 01450 2655
0.03 € per minute at peak. Off peak 0.0088 € per
minute.

16
Energy and environment tips
Here you can find tips on how to save energy when baking and
roasting and how to dispose of your appliance properly.
Saving energy
■Only preheat the oven if this is specified in the recipe or in
the operating instruction tables.
■Use dark, black lacquered or enamelled baking tins. They
absorb the heat particularly well.
■Open the oven door as infrequently as possible while you are
cooking, baking or roasting.
■It is best to bake several cakes one after the other. The oven
is still warm. This reduces the baking time for the second
cake. You can also place two loaf tins next to each other.
■For longer cooking times, you can switch the oven off
10 minutes before the end of the cooking time and use the
residual heat to finish cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly manner.
Tested for you in our cooking studio
Here you will find a selection of dishes and the ideal settings for
them. We will show you which type of heating and which
temperature are best suited for your dish. You can find
information about suitable accessories and the height at which
they should be inserted. There are also tips about cookware
and preparation methods.
Notes
■Whether you should preheat or place food into a cold oven, is
indicated in the respective tables.
Do not line the accessories with greaseproof paper until after
they have been preheated.
■The times specified in the tables are guidelines only. They will
depend on the quality and composition of the food.
■Use the accessories supplied. Additional accessories may be
obtained as special accessories from specialist retailers or
from the after-sales service.
Before using the oven, remove any unnecessary accessories
and ovenware from the cooking compartment.
■Always use oven gloves when taking hot accessories or
ovenware out of the cooking compartment.
Cakes and pastries
Baking on one level
When baking cakes, the best results can be achieved using %
Top/bottom heating.
When baking with :3D hot air, use the following shelf heights
for the accessory:
■Cakes in tins: level 2
■Cakes on trays: level 3
Baking on two or more levels
Use : 3D hot air.
Baking on 2 levels
■Wire rack or universal pan at shelf position 3
■Wire rack at shelf position 1.
Baking on 3 levels:
■Wire rack at shelf position 5
■Universal pan at shelf position 3
■Wire rack at shelf position 1.
Baking trays that are placed in the oven at the same time will
not necessarily be ready at the same time.
The tables show numerous suggestions for your dishes.
If you have 2 small, round cake tins, place them on one level
next to each other on the wire rack.
If you have 4 small, round cake tins, place 2 next to each other
on each wire rack. Slide in the wire racks one above the other.
If you are baking with 3 loaf tins at the same time, place these
on the wire racks as indicated in the picture.
Baking tins
It is best to use dark-coloured metal baking tins.
Baking times are increased when light-coloured baking tins
made of thin metal or glass dishes are used, and cakes do not
brown so evenly.
If you wish to use silicone baking tins, use the information and
recipes provided by the manufacturer as a guide. Silicone
baking tins are often smaller than normal tins. The amount of
mixture and recipe instructions may differ.
Tables
The tables show the ideal type of heating for the various cakes
and pastries. The temperature and baking time depend on the
amount and composition of the mixture. This is why
temperature ranges are given in the tables. You should try the
lower temperature first, since a lower temperature results in
more even browning. You can increase the temperature next
time if necessary.
Additional information can be found in the Baking tips section
following the tables.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning used
electrical and electronic appliances (waste electrical
and electronic equipment - WEEE). The guideline
determines the framework for the return and recycling
of used appliances as applicable throughout the EU.

17
Food Dish Shelf
position
Type of
heating
Temperature
in °C
Time
in minutes
Victoria sandwich Wire rack + 2 x Ø 20 cm tins 2 %170-180 20-25
Wire rack + 2 x Ø 20 cm tins 3 :*160-180 20-25
Light fruit cake Wire rack + high Ø 20 cm tin 2 %160-170 80-90
Wire rack + high Ø 20 cm tin 2 :*150-160 80-90
Rich fruit cake Wire rack + Ø 23 cm high round tin or 20 cm
square tin
2:*130-140 180-190
Fruit crumble Wire rack + flat glass dish 2 %180-190 40-45
Wire rack + flat glass dish 3 :*160-170 40-45
Sponge cake (fatless) Wire rack + baking tin (dark coated) 2 %*170-180 30-35
Wire rack + baking tin (dark coated) 2 :*160-170 30-40
Swiss roll Universal pan + swiss roll tin 2 %*190-200 10-12
Wire rack + swiss roll tin 3 :*170-180 10-12
Tart Universal pan + Ø 20 cm plate or pie tin 1 %200-210 50-60
Wire rack + Ø 20 cm plate or pie tin 3 :*180-190 50-60
Quiche Wire rack + quiche tin (dark coated) 1 %190-200 45-50
Wire rack + quiche tin (dark coated) 3 :*180-190 40-45
(White) Bread Wire rack + loaf tin (1 x 900 g or 2 x 450 g) 1 %200-210 30-35
Wire rack + loaf tin (1 x 900 g or 2 x 450 g) 3 :*190-200 25-30
Scones Universal pan 3 %190-200 15-20
Universal pan 3 :*180-190 15-20
Biscuits Universal pan 3 %160-170 15-20
Universal pan 3 :*160-170 15-20
Small cakes Wire rack + 12-cup tin 3 %*160-170 15-20
Wire rack + 12-cup tin 3 :*150-160 15-20
Jam tarts Wire rack + 12-cup tin 2 %200-210 15-20
Wire rack + 12-cup tin 2 :*180-190 15-20
Meringues Universal pan 3 :*80-90 100-150
Pavlova Universal pan 3 :** 150** + 100 100-150
Soufflé Wire rack + 1,2 l soufflé dish 2 %170-180 45-50
Wire rack + 1,2 l soufflé dish 2 :*160-170 45-50
Pie Wire rack + pie dish 1 %190-200 45-55
Wire rack + pie dish 3 :*180-190 45-50
Yorkshire pudding Universal pan + 12-cup tin 2 %*200-210 20-25
Universal pan + 12-cup tin 3 :*190-200 15-20
Jacket potatoes Universal pan 3 :*160-170 60-70
Pizza (homemade) Universal pan 2 %210-220 25-30
Universal pan 3 :*210-220 20-25
* Preheat.
** Preheat at higher temperature, then reduce and insert food.
Food Dish Shelf
position
Type of
heating
Temperature
in °C
Time
in minutes
Victoria sandwich, 2 levels 2 wire racks + 4 x Ø 20 cm tins 3+1 :*160-170 30-35
Scones, 2 levels Universal pan + wire rack with baking tray 3+1 :*170-180 20-25
Biscuits, 2 levels Universal pan + wire rack with baking tray 3+1 :*150-160 20-25
Biscuits, 3 levels Universal pan + 2 wire racks with baking trays 5+3+1 :*140-150 25-35
Small cakes, 2 levels 2 wire racks + 2 x 12-cup tins 3+1 :*150-160 25-30
Meringues, 2 levels Universal pan + wire rack with baking tray 3+1 :*80-90 100-150
* Preheat.

18
Baking tips
Meat, poultry, fish
Ovenware
The universal pan with insert wire rack is suitable for large
roasts. You may also use any heat-resistant ovenware.
Glass ovenware is the most suitable. Ensure that the lid of the
roasting dish fits well and closes properly.
Add a little more liquid when using enamelled roasting dishes.
With roasting dishes made of stainless steel, browning is not so
intense and the meat may be somewhat less well cooked.
Increase the cooking times.
Always place the ovenware in the centre of the wire rack.
Place hot glass ovenware on a dry mat after cooking. The glass
could crack if placed on a cold or wet surface.
Roasting
The information in the table applies to food placed in a cold
oven and for meat taken directly from the refrigerator.
The joints of meat should weigh between 500 g and 2 kg.
Ensure that you always use the lower temperature, if the weight
of the joint you wish to roast is high.
If there are several pieces of meat, calculate the roasting time
using the weight of the heaviest piece of meat. The individual
pieces of meat should be approximately the same size.
Meat
When using the %Top/bottom heating and 4 Circulated air
grilling types of heating, turn the pieces of meat halfway
through the cooking time.
When the roast is ready, turn off the oven and allow it to rest for
10 minutes. This allows better distribution of the meat juices.
When roasting joints of pork with a rind, make cuts in the rind
crossways and if it is to be turned, first place the joint with the
rind side down in the dish.
Jacket potatoes, 2 levels 2 wire racks 3+1 :*160-170 60-75
(White) Bread, 2 levels 2 wire racks + loaf tins (2 x 900 g or 4 x
450 g)
3+1 :*180-190 35-40
Pizza (homemade),
2 levels
Universal pan + wire rack with baking tray 3+1 :*180-190 40-45
Food Dish Shelf
position
Type of
heating
Temperature
in °C
Time
in minutes
* Preheat.
You wish to bake according to your own
recipe.
Use similar items in the baking tables as a guide.
How to establish whether sponge cake
is baked through.
Approximately 10 minutes before the end of the baking time specified in the recipe, stick
a cocktail stick into the cake at the highest point. If the cocktail stick comes out clean,
the cake is ready.
The cake collapses. Use less fluid next time or set the oven temperature 10 degrees lower. Observe the
specified mixing times in the recipe.
The cake has risen in the middle but is
lower around the edge.
Do not grease the sides of the springform cake tin. After baking, loosen the cake care-
fully with a knife.
The cake goes too dark on top. Place it lower in the oven, select a lower temperature and bake the cake for a little
longer.
The cake is too dry. When it is done, make small holes in the cake using a cocktail stick. Then drizzle fruit
juice or an alcoholic beverage over it. Next time, select a temperature 10 degrees higher
and reduce the baking time.
The bread or cake (e.g. cheesecake)
looks good, but is soggy on the inside
(sticky, streaked with water).
Use slightly less fluid next time and bake for slightly longer at a lower temperature. For
cakes with a moist topping, bake the base first. Sprinkle it with almonds or bread crumbs
and then place the topping on top. Please follow the recipe and baking times.
The cake is unevenly browned. Select a slightly lower temperature to ensure that the cake is baked more evenly. Bake
delicate pastries on one level using %Top/bottom heating. Protruding greaseproof
paper can affect the air circulation. For this reason, always cut greaseproof paper to fit
the baking tray.
The bottom of a fruit cake is too light. Place the cake one level lower the next time.
The fruit juice overflows. Next time, use the deeper universal pan, if you have one.
Small baked items made out of yeast
dough stick to one another when bak-
ing.
There should be a gap of approx. 2 cm around each item. This gives enough space for
the baked items to expand well and turn brown on all sides.
You were baking on several levels. The
items on the top baking tray are darker
than that on the bottom baking tray.
Always use :3D hot air to bake on more than one level. Baking trays that are placed in
the oven at the same time will not necessarily be ready at the same time.
Condensation forms when you bake
moist cakes.
Baking may result in the formation of water vapour, which escapes above the door. The
steam may settle and form water droplets on the control panel or on the fronts of adja-
cent units. This is a natural process.

19
Food Dish Shelf
position
Type of
heating
Temperature
in °C
Time, min. per
500 g + add.
time
Beef
Slow roast joint Universal pan with wire insert 1 :130-140 40 + 40
Top side, top rump Universal pan with wire insert 1 :160-170 30 + 25
Lamb
Leg Universal pan with wire insert 1 :160-170 30 + 25
Shoulder (bone in) Universal pan with wire insert 1 :160-170 25 + 20
Shoulder (boned and rolled) Universal pan with wire insert 1 :170-180 25 + 25
Rack of lamb Universal pan with wire insert 1 :180-190 25 + 25
Pork
Roast joint Universal pan with wire insert 1 :180-190 35 + 35
Loin joint Universal pan with wire insert 1 :170-180 30 + 30
Belly Universal pan with wire insert 1 :160-170 30 + 25
Gammon joint Universal pan with wire insert 1 :160-170 30 + 30
Poultry
Chicken Universal pan with wire insert 1 :170-180 25 + 25
Chicken, portion (200-250 g each) Universal pan with wire insert 1 :190-200 20 + 25
Chicken, quarter (450 g each) Universal pan with wire insert 1 :180-190 20 + 25
Duck Universal pan with wire insert 1 :180-190 20 + 20
Turkey, crown Universal pan with wire insert 1 :160-170 15 + 15
Turkey, whole (up to 12 kg) Universal pan with wire insert 1 :160-170 12 + 12
Casserole
Diced meat (beef, pork, lamb) Wire rack + glass roasting dish
with lid
2:140 120-150 (total
time)
Braising steaks Wire rack + glass roasting dish
with lid
2:140 120-150 (total
time)
Chicken Wire rack + glass roasting dish
with lid
2:140 60-90
Complete meal
With beef Wire rack + universal pan with
wire insert
4+1 :160, then 200
(yorkshire pud-
ding)
weight of meat
(see table
above) + 15-25
for yorkshire
pudding
With chicken Wire rack + universal pan with
wire insert
4+1 :180 weight of
chicken (see
table above)
Food Dish Shelf
position
Type of
heating
Temperature
in °C
Time, min. per
500 g + add.
time
Beef
Top side, top rump Universal pan with wire insert 2 %200-220 25 + 25
Lamb
Leg Universal pan with wire insert 1 4150-170 30 + 35
Rack of lamb Universal pan with wire insert 1 4180-200 25 + 25
Pork
Roast joint Universal pan with wire insert 1 4180-200 35 + 40
Loin joint Universal pan with wire insert 2 %190-210 25 + 50
Belly Universal pan with wire insert 1 4220-240 25 + 40

20
Grilling
When grilling, preheat the oven for approx. 3 minutes, before
putting the food in.
Always grill with the oven door closed.
As far as possible, the pieces of food you are grilling should be
of equal thickness. This will allow them to brown evenly and
remain succulent and juicy.
Turn grilled items after the specified time.
Whole fish does not need to be turned. Place the whole fish in
the oven in the swimming position with the dorsal fin pointing
upwards. Placing a scored potato or a small oven-proof
container in the stomach cavity of the fish will provide stability.
Do not add salt to steaks until they have been grilled.
Place the food to be grilled directly on the wire rack. If you are
grilling a single piece, the best results are achieved by placing
it in the centre of the wire rack.
The universal pan should also be inserted underneath. To
prevent a high degree of smoke from forming, do not insert the
pan higher than level 3. The meat juices are collected in the
pan and the oven is kept cleaner.
Do not insert the baking tray or universal pan at level 4 or 5.
The high heat distorts it and the cooking compartment can be
damaged when removing it.
The grill element switches on and off continually. This is normal.
The grill setting determines how frequently this will happen.
Poultry
Chicken Universal pan with wire insert 1 4200-220 25 + 15
Chicken, portion (200-250 g each) Universal pan with wire insert 3 4210-230 25 + 25
Chicken, quarter (450 g each) Universal pan with wire insert 2 4220-240 20 + 25
Duck Universal pan with wire insert 1 4190-210 20 + 20
Food Dish Shelf
position
Type of
heating
Temperature
in °C
Time, min. per
500 g + add.
time
Food Dish Shelf posi-
tion
Type of
heating
Grill setting Time
in minutes
Beef
Steaks, height 2-3 cm Wire rack + universal pan 5+3 (3 1. side 4-5,
2. side 4-5
Burgers, height 1-2 cm Wire rack + universal pan 5+3 (3 1. side 6-8,
2. side 4-6
Lamb
Steaks, height 2-3 cm Wire rack + universal pan 5+3 (3 1. side 6-7,
2. side 6-7
Chops, height 2-3 cm Wire rack + universal pan 5+3 (3 1. side 5-6,
2. side 5-6
Pork
Steaks, height 1-2 cm Wire rack + universal pan 5+3 (3 1. side 6-7,
2. side 6-7
Chops, height 2-3 cm Wire rack + universal pan 4+3 (3 1. side 10-12,
2. side 9-10
Burgers, height 1-2 cm Wire rack + universal pan 5+3 (3 1. side 6-8,
2. side 4-6
Sausages, thickness 2-4 cm Wire rack + universal pan 4+3 (3 10-15, turn
occasionally
Gammon
Steaks, height 1-3 cm Wire rack + universal pan 5+3 (3 1. side 4-5,
2. side 3-4
Chicken
Drumsticks, 150 g each Wire rack + universal pan 3+2 (3 1. side 17,
2. side 8
Breast (boneless), 150 g each Wire rack + universal pan 3+2 (3 1. side 20,
2. side 10
Fish
Whole trout, 300 g each Wire rack + universal pan 2+1 (2 20-25
Fillets, 150 g each Wire rack + universal pan 4+3 (3 1. side 5-7,
2. side 5-7
