Bosch HBL5751UC User manual

Installation Manual
Built-In Combination Ovens
500/800/Benchmark™ Series
HBL5751UC, HBL8751UC, HBLP751UC, HSLP751UC

Table of Contents
Questions?
1-800-944-2904
www.bosch-home.com/us
We look forward to hearing from you!
This Bosch Appliance is made by
BSH Home Appliances Corporation
1901 Main Street, Suite 600
Irvine, CA 92614
Safety Definitions. . . . . . . . . . . . . . . . 1
Safety Information . . . . . . . . . . . . . . . 1
Appliance Handling Safety . . . . . . . . . . . . . 1
Unpacking the Oven . . . . . . . . . . . . . . . . . . 1
Safety Codes and Standards . . . . . . . . . . . 1
Electrical Safety . . . . . . . . . . . . . . . . . . . . . . 1
Related Equipment Safety . . . . . . . . . . . . . 2
Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Bosch Combination Ovens . . . . . . . 3
Preparation . . . . . . . . . . . . . . . . . . . . 4
Before You Begin . . . . . . . . . . . . . . . . . . . . . 4
Tools and Parts Needed . . . . . . . . . . . . . . . . 4
General Information . . . . . . . . . . . . . . . . . . . 4
Power Requirements . . . . . . . . . . . . . . . . . . . 4
For Best Installation . . . . . . . . . . . . . . . . . . . . 4
Cabinet Dimension Requirements . . 5
Combination Oven and Speed Microwave or
Steam Convection Oven 30” Traditional
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Removing Packaging . . . . . . . . . . . . 6
Packaging Bracket Removal (left and
right sides) . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Preparing Ovens . . . . . . . . . . . . . . . . . . . . . . 6
Installation . . . . . . . . . . . . . . . . . . . . . 7
Pre-Assembly of the Combination Oven . . 7
Parts Provided . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation with the Speed Microwave Oven 7
Installation with the Steam Convection Oven 8
Connecting the Speed Microwave Oven or
Steam Convection Oven Electrical Conduit
to the Lower Oven . . . . . . . . . . . . . . . . . . . . . 9
Electrical Installation . . . . . . . . . . . . . . . . . 10
Electrical Connection to Main Power Supply 10
Installing the Combination Oven into
the Wall Cabinet . . . . . . . . . . . . . . . . . . . . . 11
Remove Lower Oven Door Prior
to Installation . . . . . . . . . . . . . . . . . . . . . . . . 11
Correctly Lifting the Combination Oven . . . . 12
Lifting Recommendations . . . . . . . . . . . . . . 12
Installing the Oven into the Cabinet . . . . . . . 13
Re-Install the lower oven door: . . . . . . . . . . 14
Before Calling Service . . . . . . . . . . . . . . . . . 15

9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
9001080875 Rev A English 1
Safety Definitions
NOTICE: This indicates that damage to the appliance or
property may occur as a result of non-compliance with this
advisory.
Note: This alerts you to important information and/or tips.
Safety Information
IMPORTANT: SAVE THESE INSTRUCTIONS FOR THE
LOCAL INSPECTOR'S USE.
INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE
APPLIANCE AFTER INSTALLATION IS COMPLETE.
OWNER: PLEASE RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
Appliance Handling Safety
Do not lift appliance by door handle. Remove the lower
oven door for easier handling and installation. See
“Remove Lower Oven Door Prior to Installation” on
page 11.
Unit is heavy and requires at least three people or proper
equipment to move.
Hidden surfaces may have sharp edges. Use caution when
reaching behind or under appliance.
Unpacking the Oven
When unpacking the ovens during the installation, remove
all tape and packaging material and examine the oven for
any damage such as dents, broken door latches or cracks
in the door. Notify dealer immediately if oven is damaged.
Do not install if oven is damaged.
Safety Codes and Standards
This appliance complies with one or more of the following
Standards:
• UL 858, Household Electric Ranges
• UL 923, Microwave Cooking Appliances
• UL 507, The Standard for the Safety of Electric Fans
• CAN/CSA-C22.2 No. 113-M1984 Fans and Ventilators
It is the responsibility of the owner and the installer to
determine if additional requirements and/or standards
apply to specific installations.
Electrical Safety
Before you plug in an electrical cord, be sure all controls
are in the OFF position.
If required by the National Electrical Code (or Canadian
Electrical Code), this appliance must be installed on a
separate branch circuit.
Installer - show the owner the location of the circuit
breaker or fuse. Mark it for easy reference.
Important - Save these instructions for the local electrical
inspector's use.
9WARNING
This indicates that death or serious injuries may
occur as a result of non-observance of this warning.
9CAUTION
This indicates that minor or moderate injuries may
occur as a result of non-observance of this warning.
9WARNING
If the information in this manual is not followed
exactly, fire or shock may result causing property
damage or personal injury.
9WARNING
Do not repair or replace any part of the appliance
unless specifically recommended in the manuals.
Improper installation, service or maintenance can
cause injury or property damage. Refer to this
manual for guidance. All servicing should be done
by a qualified technician.

9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
9001080875 Rev A English 1
Safety Definitions
NOTICE: This indicates that damage to the appliance or
property may occur as a result of non-compliance with this
advisory.
Note: This alerts you to important information and/or tips.
Safety Information
IMPORTANT: SAVE THESE INSTRUCTIONS FOR THE
LOCAL INSPECTOR'S USE.
INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE
APPLIANCE AFTER INSTALLATION IS COMPLETE.
OWNER: PLEASE RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
Appliance Handling Safety
Do not lift appliance by door handle. Remove the lower
oven door for easier handling and installation. See
“Remove Lower Oven Door Prior to Installation” on
page 11.
Unit is heavy and requires at least three people or proper
equipment to move.
Hidden surfaces may have sharp edges. Use caution when
reaching behind or under appliance.
Unpacking the Oven
When unpacking the ovens during the installation, remove
all tape and packaging material and examine the oven for
any damage such as dents, broken door latches or cracks
in the door. Notify dealer immediately if oven is damaged.
Do not install if oven is damaged.
Safety Codes and Standards
This appliance complies with one or more of the following
Standards:
• UL 858, Household Electric Ranges
• UL 923, Microwave Cooking Appliances
• UL 507, The Standard for the Safety of Electric Fans
• CAN/CSA-C22.2 No. 113-M1984 Fans and Ventilators
It is the responsibility of the owner and the installer to
determine if additional requirements and/or standards
apply to specific installations.
Electrical Safety
Before you plug in an electrical cord, be sure all controls
are in the OFF position.
If required by the National Electrical Code (or Canadian
Electrical Code), this appliance must be installed on a
separate branch circuit.
Installer - show the owner the location of the circuit
breaker or fuse. Mark it for easy reference.
Important - Save these instructions for the local electrical
inspector's use.
9WARNING
This indicates that death or serious injuries may
occur as a result of non-observance of this warning.
9CAUTION
This indicates that minor or moderate injuries may
occur as a result of non-observance of this warning.
9WARNING
If the information in this manual is not followed
exactly, fire or shock may result causing property
damage or personal injury.
9WARNING
Do not repair or replace any part of the appliance
unless specifically recommended in the manuals.
Improper installation, service or maintenance can
cause injury or property damage. Refer to this
manual for guidance. All servicing should be done
by a qualified technician.

9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
English 2 9001080875 Rev A
Before installing, turn power OFF at the service panel. Lock
service panel to prevent power from being turned ON
accidentally.
Refer to data plate for more information. See "Data Plate"
under "Service" for data plate location.
Be sure your appliance is properly installed and grounded
by a qualified technician. Installation, electrical connections
and grounding must comply with all applicable codes.
Related Equipment Safety
Remove all tape and packaging before using the appliance.
Properly dispose of the packaging after unpacking the
appliance. Never allow children to play with packaging
material.
Never modify or alter the construction of the appliance. For
example, do not remove leveling legs, panels, wire covers
or anti-tip brackets/screws.
Transport
To avoid damage to the oven vent, use the transport
method shown in the picture below.
Support the bottom of the oven from side to side when
moving it into the installation location. Leave the unit
attached to the shipping pallet until it is in front of the
cabinet opening, ready to lift into place.

9001080875 Rev A English 3
Bosch Combination
Ovens
The HBL5751UC, HBL8751UC, HBLP751UC, and
HSLP751UC Bosch combination ovens are sold as sets,
each of which includes two built-in oven components: a
traditional wall oven (lower oven) and an upper oven that is
either a built in speed microwave oven or a steam
convection oven.
• For ease of installation and improved alignment,
the oven components are assembled together in
the customer’s home rather than at the factory.
• Each of the components are packed in separate
boxes, which are strapped together prior to
shipping.
• The combination ovens listed here are approved
for use in a single cutout, using a single power
connection.
• Each traditional oven component is designed with
an oven-mounted junction box on top, which is
used for connecting the upper oven power cable.
• The hardware required for mounting the speed
microwave or steam convection oven on top of the
traditional oven will be found inside the traditional
oven box.
• Each of the oven components has its own data
plate, reflecting the component model number, FD
number, etc.
The following table identifies each of the Bosch
combination oven SKUs and its two built-in
components. Only the Bosch combination oven
components in the configurations listed in the
table below are Agency-approved for use in a
single cutout, using a single power connection.
Other models cannot be substituted.
Combination Oven
SKU/Model
Bosch Combination Oven Components
Traditional Oven Model Speed Microwave Oven Model OR
Steam Convection Oven Model
HBL5751UC HBL5751UCC
500 Series Wall Oven HMC80251UC Speed Microwave Oven
HBL8751UC HBL8751UCC
800 Series Wall Oven HMC80251UC Speed Microwave Oven
HBLP751UC HBLP751UCC
Benchmark Series Wall Oven HMC80251UC Speed Microwave Oven
HSLP751UC HSLP751UCC
Benchmark Series Wall Oven HSLP451UC Steam Convection Oven

Combination Oven Pre-Assembly
English 4 9001080875 Rev A
Preparation
Before You Begin
Tools and Parts Needed
• Phillips-head screwdriver
• Star-head screwdriver (T20)
• Measuring tape
• Drill with bit (1/8")
•Gloves
General Information
Power Requirements
The outlet must be properly grounded in accordance with
all applicable codes.
For Best Installation
The oven can be difficult for two people to handle during
installation. It is recommended that three or more people
be available to assist with lifting the unit into place.
Removal of the lower oven door (to significantly reduce the
unit weight and to provide necessary hand holds) can be
cumbersome unless the detailed door removal instructions
are followed carefully. Do not attempt to remve the speed
microwave door or steam convection oven door.
Please take time to read and follow the instructions
provided for an improved installation experience.
Checklist
Use this checklist to verify that you have completed each
step of the installation process. This can help you avoid
mistakes.
___ 1. Before installing the oven, be sure to verify the
cabinet dimensions are correct and the required
electrical connections are present.
___ 2. Refer to additional information in this manual
regarding Safety, Cabinet Dimensions, Removing
Packaging, Electrical Installation, Testing the
Installation, and Customer Service.
___ 3. Remove the lower oven door to reduce the unit
weight and to provide access to handholds for
lifting. See “Remove Lower Oven Door Prior to
Installation” on page 11.
___ 4. Move the oven units into place in front of the
cabinet opening, leaving the bottom packaging on
the units to avoid damaging flooring.
___ 5. Remove the star-head (T-20 size) screws holding
the speed microwave oven or steam convection
oven to the base of its carton (using Star-head
screwdriver).
___ 6. Assemble the two units of the combination oven.
See “Pre-Assembly of the Combination Oven” on
page 7.
___ 7. Connect the power cable from the lower oven to
the junction box in the cabinet.
___ 8. Remove the star-head (T-20 size) screws holding
the lower oven to the base of its carton (using Star-
head screwdriver).
___ 9. Team-lift the unit directly into the cabinet cutout
taking care not to pinch fingers or scratch hands or
arms.
__ 10. Slide the unit all the way into place.
__11. Fasten the combination unit to the cabinetry
opening with the screws supplied (using Philips
screwdriver).
__ 12. Reinstall the oven door removed in step 3 above.
__ 13. Consult the complete installation instructions and
follow the remainder of the procedures listed,
including performing an operation test.
__ 14. INSTALLER - Leave the literature pack and the
accessories with the customer.

9001080875 Rev A English 5
Cabinet Dimension Requirements
It is good practice, when an oven is installed at the end of a
cabinet run, adjacent to a perpendicular wall, or cabinet
door, to allow at least 1/4” (6.4 mm) space between the
side of the oven and the wall/door.
For oven support, install 2x4s extending front to back flush
with the bottom and the sides of the opening. The
supporting base must be well secured to the floor/cabinet
and level.
Junction boxes can be located anywhere within reach of
the oven’s power cable.
The cabinet base must be flat and capable of supporting
the weight of the combination oven up to 429 lbs. (195 kg).
Combination Oven and Speed
Microwave or Steam Convection Oven
30” Traditional Installation
Combination Oven and Speed Microwave or
Steam Convection Oven 30” Flush Mount
Installation
Flush installation requires two side cleats to be attached
inside the cabinet frame, recessed from the
front.

Combination Oven Pre-Assembly
English 6 9001080875 Rev A
Removing Packaging
1. Cut straps on the outside of the boxes.
2. Remove the upper boxed unit of the combination oven.
3. Perform the following steps on both units of the
combination oven.
a. Remove the cardboard box by lifting it up and off
the unit.
b. Remove all top and side cardboard and foam
braces.
c. Place the unit (leaving it on the shipping base) in
front of the cabinet where it is to be installed.
d. Remove all accessories, racks, packing materials,
and literature from the oven cavities.
e. Unscrew unit from packaging brackets as shown in
“Packaging Bracket Removal.”
Note: The screws near the base mounting bracket of
each unit are all star-head (T-20 size). Only the one
screw that goes through the slotted hole in the
mounting bracket on the left and right sides of the unit
needs to be removed in order to lift the unit from the
mounting base (the screw circled and shown as “A” in
the following illustration.)
Packaging Bracket Removal (left and
right sides)
Note:
Actual brackets may look differently. The bracket remains
in the packaging base. The unit should stay on the
packaging base until ready to be lifted into cabinet cutout or
onto the lower oven.
Preparing Ovens
Place ovens in front of the cabinet where it is to be installed
so that they are in line with the cabinet cutout.
Check to be sure all packing materials have been removed
from the unit. Also remove the accessories, oven racks,
literature pack and any shipping materials from inside the
oven cavity (remove from both cavities for a double oven or
combination oven).
NOTICE
Remove one screw only from each bracket. This
will release the oven from the shipping base. Do
not remove any additional screws from the oven.

9001080875 Rev A English 7
Installation
Pre-Assembly of the
Combination Oven
Combination ovens require the units be assembled
together prior to installing the combination unit into the wall
cabinet.
Note: The installation procedures differ betweenthe speed
microwave oven and steam convection convectionoven
combination units. The parts contained in the square tube
parts box are common to both installations.
Parts Provided
Installation with the Speed Microwave
Oven
Note: Do not place the oven into the wall cabinet until after
mounting the speed microwave oven on it using the univer-
sal connector brackets.
1. Install both universal connector brackets on top of the
lower oven using six of the screws provided. Tighten
screws securely, but do not overtighten.
Note: The universal connector brackets are interchange-
able for the left and right sides of the oven. Be sure the
taller vertical edge of the bracket is positioned to the out-
side of the oven.
2. Install the decorative trim.
Universal connector
bracket (2)
(in parts box on top of
oven)
Screws (16)
(in red bag, inside parts
box on top of oven)
Oven Mounting Screws
8 screws are included to
secure the oven trim to the
cabinet. The screws are
located in a small plastic
bag affixed to the literature
pack bag.
Trim Piece
(in plastic bag on top of
oven)
Positionthedecorativetrim
piece so the flanges with
the holes in them face to
the rear of the oven.
Align the outer flanges with
the outside of the universal
brackets. Fasten with 1
screw each into the end
hole of the universal
bracket. Tighten screws
securely, but do not
overtighten.
Top View of Standard Wall Oven

English 8 9001080875 Rev A
3. Place the speed microwave oven unit on top of the
universal connector brackets and fasten in place using
three screws per side. Tighten the screws securely, but
do not overtighten.
Note: The existing screws in the speed microwave
oven base help with alignment. When lowering the
speed microwave into place on the universal connector
brackets, allow these screw heads to slide into the slots
as shown in the illustration below. The screw nearest
the front of the speed microwave should slide into the
base of the slope at the front of the bracket.
4. Continue to “Connecting the Speed Microwave Oven or
Steam Convection Oven Electrical Conduit to the
Lower Oven” on page 9.
Installation with the Steam Convection
Oven
Note: Do not place the oven into the wall cabinet until after
mounting the steam convection oven on it using the univer-
sal connector brackets.
1. Remove the six screws holding the combo service slide
assemblies (A in following illustration) to the support
brackets. Use a magnetic screwdriver bit to reach the
screws through the large holes in the tops of the slides.
2. The screw in position A (nearest the inside edge, near
control panel) must be moved to allow the universal
bracket to be postioned there. Remove the inside
screw (A) from the left support bracket and reinsert it
into the third hole (B) from the inside edge of the
support bracket. Repeat for the right support bracket.
3. Reattach the slide assemblies using the holes near the
inside edge of the support bracket. Align the slide
assembly parallel to the edge of the bracket and insert
the first screw in hole (C). Insert all three screws for
each slide assembly. Tighten the screws securely, but
do not overtighten.
Note: When the correct holes are used, the front of the
slide assembly will extend just past the edge of the support
bracket. The slide assembly will also be about 1/8” (3 mm)
from the inside edge of the support bracket.
4. Install the two universal connector brackets to the slide
assemblies using the screws provided. Tighten screws
securely, but do not overtighten.

9001080875 Rev A English 9
Note: The universal connector brackets are interchange-
able for the left and right sides of the oven. Be sure the
taller vertical edge of the bracket is positioned to the out-
side of the oven.
5. Install the decorative trim.
6. Place the steam convection oven unit on top of the
universal connector brackets and fasten in place using
two screws per side. Tighten the screws securely, but
do not overtighten.
Note: The existing screws in the steam convection
oven base help with alignment. When lowering the
steam convection oven into place on the universal
connector brackets, allow these screw heads to slide
into the slots as shown in the illustration below. The
screw nearest the front of the steam convection oven
should slide into the base of the slope at the front of the
bracket.
7. Continue to “Connecting the Speed Microwave Oven or
Steam Convection Oven Electrical Conduit to the
Lower Oven”.
Connecting the Speed Microwave Oven
or Steam Convection Oven Electrical
Conduit to the Lower Oven
Note: When installing the combination unit, the speed
microwave oven or steam convection oven power cable
must be properly attached to the oven-mounted junction
box. This must be done prior to supplying electric power to
the oven unit.
1. Remove the oven-mounted junction box cover (located
on the rear top of the oven - at arrow in the following
illustration).
Positionthe decorativetrim
piece so the flanges with
the holes in them face to
the rear of the oven.
Align the inner flanges with
the inside of the universal
brackets. Fasten with one
screw each into the end
hole of the universal
bracket. Tighten screws
securely, but do not
overtighten.
9WARNING
Check to be sure that no electric power has yet
been supplied to the oven.

English 10 9001080875 Rev A
2. Remove the cap from the conduit access hole in the
side of the oven-mounted junction box.
3. Guide the wires from the conduit cable (coming from
the speed microwave oven or steam convection oven -
at the arrow in the following illustration) through the
hole in the oven-mounted junction box. There are four
wires from a speed microwave oven or three wires from
a steam convection oven (no white wire from a steam
convection oven).
4. Snap the conduit connector into the hole by pressing it
in until it clicks into place.
5. Follow the wiring diagram label (at the arrow in
following illustration) and match and connect each wire
by color to the wires attached to the wiring block inside
the oven-mounted junction box. Push the bare end of
the wire until it is snug in the wiring block then tighten
down the retaining screw on each wire. Tighten
securely, but do not overtighten. See previous
illustration for finished appearance.
6. Replace the oven-mounted junction box cover and
tighten the two screws holding it in place. Tighten the
screws securely, but do not overtighten.
Electrical Installation
The assembled combination oven should be moved in front
of the cabinet opening and the power cable from the lower
oven should be connected to the cabinet junction box.
All model ovens on the front cover of this installation
instruction manual are dual rated, designed to be
connected to either 208 or 240V AC, 60 Hz, 4 wire, single-
phase power supply.
The electrical supply should be a 4-wire single-phase AC.
Install a suitable conduit box (not furnished). An
appropriately-sized, UL-listed conduit connector must be
used to correctly attach the conduit to the junction box.
Important: Local codes may vary; installation, electrical
connections and grounding must comply with all applicable
local codes.
If local codes permit grounding through the electrical
supply neutral, connect both the white neutral wire and the
green ground wire from the oven to the white neutral
electrical supply wire.
Electrical Connection to Main Power
Supply
The four-wire connection is preferred, but where local
codes permit, the three-wire connection is also acceptable.
Four-wire Connection
• Connect the red oven wire to the red electrical supply
wire (hot wire).
• Connect the black oven wire to the black electrical
supply wire (hot wire).
• Connect the white neutral oven wire to the white
neutral (not bare or green ground) electrical supply
wire.
• Connect the green ground oven wire to the bare or
green ground electrical supply wire.
Model Circuit Required
208V, 60 Hz 240V, 60 Hz
HBL5751UC,
HBL8751UC,
HBLP751UC,
HSLP751UC
40 AMP
power supply
junction box
red wires
green or bare
wire
green wire
UL listed
connector
black wires
white wires
cable from
oven

9001080875 Rev A English 11
Three-wire Connection
• Connect red wire from oven to red wire in junction box.
• Connect black wire from oven to black wire in junction
box.
• Connect both green ground wire and white wire from
oven to white, green or bare neutral wire in junction
box.
The conduit cable, where connected at the oven, swivels.
Rotate conduit cable upward (or downward) and direct
through hole prepared in cabinet to attach to the junction
box.
To maintain serviceability, the flex conduit must not be
shortened and should be routed to permit temporary
removal of the oven.
Installing the Combination
Oven into the Wall Cabinet
Remove Lower Oven Door Prior to
Installation
It is recommended to remove the traditional (lower) oven
door to help reduce the unit weight and provide easier
access to the handholds located inside the oven. Do not
remove speed microwave or steam convection oven doors.
power supply
junction box
red wires
white, bare, or
green wire
white wire
green wire
black wires
UL listed
connector
cable from
oven
NOTICE
Before installing the combination oven, be sure to
verify the cabinet dimensions and electrical
connections.
Check that the cabinet opening is level and plumb
for correct installation.
9WARNING
• The oven door is heavy and fragile. Use both
hands to remove the oven door. The door front
is glass. Handle carefully to avoid breaking.
• Grasp only the sides of the oven door. Do not
grasp the handle as it may swing in your hand
and cause damage or injury.
• Failure to grasp the oven door firmly and
properly could result in personal injury or
product damage.
• To avoid injury from hinge bracket snapping
closed, be sure that both levers are securely in
place before removing the door. Also, do not
force door open or closed - the hinge could be
damaged and injury could result.
• Do not lay removed door on sharp or pointed
objects as this could break the glass. Lay on a
flat, smooth surface, positioned so that the
door cannot fall over.
1. Be sure to read all
warnings and cautions
in the installation
manual regarding the
door removal before
attempting to remove
the door.
2. Open the door
completely.
3. Flip latch levers on
hinges all the way
down toward you.

English 12 9001080875 Rev A
Correctly Lifting the Combination Oven
Notice: DO NOT attempt to lift the unit by holding the oven
upper element.
There is a ridge across the top front of the lower oven
cavity. Lift by grasping this ridge with one hand while
placing the other hand on the back of the unit (for helpers
lifting from the sides of the unit). If a third helper is lifting
from the front, both hands should lift by holding this ridge
area.
Lifting Recommendations
Lift Locations (with lower oven door removed)
Lift points (1) on the front of the unit are for lifting from the
sides of the unit. Lift point (3) on the front of the unit is for a
third person to help lift the unit.
Lift point (2) on the back of the unit shows the location of
the opposite hand for the helpers lifting from the sides of
the unit. Adjust the location as needed to facilitate the lift.
Wear gloves, a long sleeved shirt, and avoid sharp edges
to reduce the risk of cuts or abrasions to the arms or hands.
4. Holding the door firmly
on both sides and
using both hands,
close the door gently
until it stops against
the latch levers, about
30º from the closed
position.
5. Carefully lift the door
up and out of the
hinge slots. Hold
firmly; the door is
heavy.
6. Place the door in a
convenient and stable
location until you are
ready to reinstall it.
Lay the door on a
towel or section of
protective foam
padding to avoid
damage to the door or
the floor.
9CAUTION
It is recommended to wear gloves and long sleeves
to protect hands and forearms from abrasion and
potential scratches during the lifting process. It is
also recommended to take off watches and jewelry
and to wear work shoes during installation for foot
protection.
9CAUTION
Three people or proper equipment are needed to
safely lift the combination oven into the cabinet
opening.

9001080875 Rev A English 13
Placing the Combination Oven Into the
Cabinet Opening
When lifting the combined unit into place, avoid grasping
the upper element to avoid damaging it. See the illustration
following for the correct lifting point. This illustration shows
a detailed view of the oven cavity. Note the location of the
ridge inside the top of the cavity. This is the area to grip
from the front when lifting the combined unit.
Installing the Oven into the Cabinet
1. Lift the combination oven unit into the cabinet cutout
without allowing the unit base to contact the flooring.
2. Guide the unit straight back into the cabinet cutout.
Note: Be careful not to crimp the flexible conduit
between the oven and the cabinet back wall. If
necessary, guide the flexible conduit into the wall or
cabinet access hole so it doesn’t prevent the unit from
being pushed all the way into the cabinet opening. The
oven should be straight and level, not crooked.
3. Push the unit straight in until the oven trim is flush with
the front of the cabinet trim.
4. Install supplied screws through tap holes in trim (4
screws).
9CAUTION
To avoid damage to the door do not lift, pull or push
the unit during installation by using any oven door
handle as a gripping point.

English 14 9001080875 Rev A
Re-Install the lower oven door:
1. Hold the door firmly in
both hands.
2. Hold the door at an
angle from the closed
position
(approximately 7
inches open at the
top).
3. Insert the hinges into
the slots.
You may need to rock
the door forward and
backward slightly to
seat the hinge feet.
The door should lower
about 3/4” and stop. If
not, the hinges have
not engaged properly
and the door could fall
if it is released.The
door may need to be
removed and re-
inserted until the
hinges sit correctly in
the slots.
4. Open door all the way
to expose hinges,
latch levers, and slots.
5. Push latch levers up
until they are locked
into the slots, flush
with front of the oven
body.
6. Close and open door
slowly to be sure it is
correctly and securely
in place. Door must be
straight, not crooked.

9001080875 Rev A English 15
Before Calling Service
See the Use and Care Manual for each unit of the
combination oven for troubleshooting information. Refer to
the Statement of Limited Warranty in the Use and Care
Manuals.
To reach a service representative, see the contact
information at the front of the Use and Care Manual.
Please be prepared with the information printed on your
product data plate when calling.
Data Plate
Each component of a combination oven has its own data
plate.
The data plate shows the model, FD number, and serial
number. Refer to the data plate when requesting service.
The data plate location varies based on the oven model.
Speed Microwave Oven Data Plate
Steam Convection Oven Data Plate
Lower Oven Data Plate
Note: The rating plates (A) are at the left hand side of
the door trim.
