1 2 3 4 5 6
:- 90 Temp. °C VSelecting the tempe rature (:= cold)
1 - 24h Ready in Programme ends in ...
 - 1200* rpm Select the spin speed (* d epending on the model) or  (no final
spin, laundry soaks in the last rinsing water)
Status displays Programme progress displays
12ccc-0- Washing, Rinse, Spin, E nd
End of programme when ...
... the $Start/Pause flashes and -0- is d isplayed on the
display panel.
Changing the programme, if ...
... you have selected the wrong p rogramme by mistake:
– Reselect the programme.
– Sele ct $Start/Pause.
Interrupting the programme
Programmes at high temper atures:
– Cool washing: Selectc2Rinse/Freshen up.
Washing machine door rema ins locked.
– Sele ct Off.
– Select Spin or >Drain.
– Select $Start/Pause
Correct installation according to the
separate Installation instructions.
Checking the machine
– Never use a dama ged machine.
– Inform the after-sales servic e.
Connecting the mains
plug
Make sure your hands are dry .
Take hold of the plug only.
Turning the tap on
Compartment II: Detergent for the main wash, water softener,
bleach, stain remover
Sorting and loading laundry
Follow the manufacturer's c are information.
According to the informatio n on the care labels.
According to type, colour, soiling and temperature.
Do not exceed the maximum load –> page 7 .
Follow important instruc tions –> page 6.
Insert large and small items of laund ry.
Close the washing machine door. Ta ke care not to trap items of laun dry
between the washing machine doo r and the rubber seal.
Add detergent and care products
Measure accordingly:
Amount of laundry, soiling, water hardness ( ask your water supply
company) and manufacture r's instructions.
Pour liquid detergent into the appropriate dispenser and place in the drum.
Your washing machine
Congratulations äyou have o pted for a modern, hi gh-quality
domestic appliance man ufactured by Bosch. The washing machi ne
is distinguished by its economical water- and energy consump tion.
Each machine that leaves ou r factory is inspected tho roughly to
ensure that it functio ns properly and i s in perfect c ondition.
Further information: www.bosch-hom e.com
Environmentally friendly waste disposa l All packaging must be disposed of in accordance with
environmental guidelines.
This appliance is certified in accordance with European Directive
2002/96/EEC on waste electrical and electronic equipmen t
(WEEE).
This directive provides the framework for the EU-wide c ollection
and reuse of used appl iances.
Intended use
Contents Page
ʋIntended use ................................................... ....................................1
ʋProgrammes ...................................................................................... .1
ʋSetting and adjusting the programme . ..........................................3
ʋWashing ........................................................................................... 3/4
ʋAfter washing ..................................................................................... .4
ʋIndividual settings .................................... ..........................................5
ʋImportant information ........................ ............................................... 6
ʋOverview of programmes ................................................................ 7
ʋSafety instructions ................. ............................................................ 8
ʋConsumption values .........................................................................8
ʋCare ................................................................................................. ....9
ʋInformation on the display panel ....................................................9
ʋMaintenance ........................... ......................................................... 10
ʋWhat to do if.... ................................................................................. 11
Environmental protec tion/Conservation tips
– Always fill the washing machine w ith a maximum amount of
laundry for the relevant pr ogramme.
– Wash no rmally soiled laundry without a pre-wash.
– Instead of LFCottons 90°C, ch oose the programme
Cottons Eco 60 °C. Comparable c leaning result with
significantly lower energy con sumption.
– Measure th e detergent according to the manufacturer's
instructions and water hardness .
– If the laundr y is then dried in the tumb le dryer, select the spin
speed according to t he instructions of the drye r manufacturer.
Preparation Before washing for the first time
Wash once without any l aundry –> page 9.
Setting** and adjusting programmes
Display panel/
options buttons
Programme selector
Start/
Pause
$All buttons are sensitive,
they only need to be
touched gently! If the
options buttons are
touched for longer, the
setting options run
automatically!
Programmes
Detailed overview of programmes –> pa ge 7.
Temperature and spin speed c an be selected individually,
depending on the selected programme and programme
progress.
LFCottons
hard-wearing fabrics
Cottons Stains
Cottons Eco
Delicate/Silk delicate washable fabrics
/øWool hand-/machine-washable wool
IEasy-Care easy-care fabrics
KDark Load dark textiles
2Rinse/
Freshen up
with subsequent spin cycle; for h and-
washed items, starching or freshen up
items –> page 6.
Spin washing washed by han d
Gentle Spin washing washed by hand at reduced
spin speed
>Drain the rinsing water if  occurs
1Mixed Load different types of laundry
6Express 15´ short programme
$Sportswaer textiles made o f microfibres
VSkin Care hard-wearing fabrics
Additional functions and option s
buttons –> Individual settin gs, page 5.
Select $Start/Pause
Washing
1
2
Removing the washing
Open the washing machine door and remove the washing.
If (without final spin) is acti ve: Turn the programme
selector to >Drain or select the spin speed.
Select Start/Pause $.
– Remove any foreig n objects - risk of rusting.
– Leave the washing machine door and detergent
drawer open so that any residu al water can
evaporate.
Turning the tap off
Switching off
Turn the programme selector to Off .
Washing
Detergent drawer with
compartments I,II,~Washing machine
door
Compartment ~: Fabric softener, starch
Compartment I: Dete rgent for pre-wash
ʋfor domestic use only,
ʋfor machine-washable fabrics an d hand-washable wool
in detergent solution,
ʋto be operated with cold drinking water and commer-
cially available detergents a nd care products which are
suitable for use in washing m achines.
ʋwhen determining the dosage of all washing p owders,
additives and cleanin g agents, you must follow the
manufacturer's instructions.
– Do no t leave children unattended near the
washing machine.
– The washing mach ine is not to be used by
children or persons n ot familiar with the
operating instructions.
– Keep pets away from the washin g machine.
Dilute thick fabric softener and fabric conditioner with water.
This prevents blockages.
Individual settings
ʑOptions buttons
The spin speed and temperature can be ch anged before and during the selected programme
runs. The effects depend on t he programme progress.
Temp. in °C VYou can change the d isplayed washing temperat ure. The maximum washing te mperature
that can be selected depends on the programme that has been set.
Ready in The respective programme duratio n is displayed by selecting the programm e. The
programme start can be delayed before the programme begins. The Ready i n- time can be
set in hour- steps up to a maximum of 24 hours. Press the Ready in-butto n repeatedly
until the required number of hours is displayed (h = hour). Select Start/Pause $.
rpmc(Spin speed in rpm/no final spin)
You can change the d isplayed spin speed. The m aximum selectable spin speed depends on
the model and on whic h programme is currently selec ted.
ʑAdditional function –> and overview o f programmes, s ee page 7
Intensive Extension of the washing time for a more intensive washing of hig hly
soiled washing or 6.5 kg of cottons and coloureds.
Prewash For heavily soiled, hard-wearing washing, e.g. made of cotton or linen.
Prewash at 30 °C.
ʑ$Start/Pause
For starting or interrupting the programme.
ʑSignal
2. Setting the
volume for ...
1. Activating the mode
for setting the signal
volume
Set to •1 step, the
display panel
lights up
press and hold+1 step, release
Button signals Information signals
Set to •
Setting the
volume*
Setting the
volume*
1 step
direct
* you may need to s elect
the function several times.
Important information
Protecting the laundr y and the machine
– Empty pockets.
– Look out for m etal items (paperclips, etc.).
– Wash d elicates in a laundry bag (tights, curtains, underwir ed bras).
– Fasten zips , do up any buttons.
– Brush san d out of pockets and col lars.
– Remove c urtain fittings or place in the laundry b ag.
Laundry with varying degrees of soiling
Wash new items of cloth ing separately.
light Do not pre-wash. If requir ed,
Pre-treat any stains a s necessary. Choose th e Intensive additional
function.
heavy Do not load as m uch laundry. Choose the cP rewash additional
function.
Soaking Load laundry of the same colour
Pour soaking agent/detergent into compartment II in accordance w ith the manufacturer's
instructions. Turn the programme selector to LFCottons 30 °C and select se $Start/
Pause. After approx. 10 minutes, press $Start/Pa use. to pause the programme. O nce the
required soaking time has elapsed, select $Start/Pause. again to continue the programme,
or select a different programme .
Starching Laundry must n ot be treated with fabric softener
Starching is possible in a ll wash programmes if liquid starch is used. Pour the starch in
accordance with the manufacturer's instructions into fabric softener compartment ~(rinse
first if necessary).
Dyeing/bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel.
Always follow the dye ma nufacturer's instructions! Do not use the washing ma chine for
bleaching clothes!
Freshen up Use programme Rinse/Fr eshen up
For items, that have been tucked away or stored for a period of time, to rem ove creases
caused by folding and s torage and to eliminate odo urs. Use fabric conditioner for “ fresh?
smell.
Additional
functions
3
Drum
Control panel
Service flap
Programme selector for
switching the machine on
and off and for selecting
the programme. Can be
turned in either direction.

7
Overview of programmes –> Refer to the table of consumption values on page 8 and notes on page 6.
Programmes °C
(:= cold)max. Type of laundry Additional functions; information
LFCottons :- 90 °C
6.5 kg* Hard-wearing fabrics, heat-resistant fabrics madeo f
cotton or linen
Intensive ,Prewash Cottons Stains :- 60 °C
Cottons Eco** :- 60 °C VSkin Care :- 60 °C
Intensive ,Prewash ;
for particularly sensitive skin, prolonged washing at selected tempera- ture, higher water level, additional rinse cycle
IEasy-Care :- 60 °C
3 kg*
Easy-care fabrics made of cotton, linen, syn thetic fibres or blended fabrics Intensive ,Prewash 1Mixed Load :- 40 °C Fabrics made of cotton or easy-care fa brics Intensive ,Prewash ;
different types of laundry can be washed together
KDark Load :- 40 °C Dark textiles made of cotton and dark easy-care tex-
tilies
Intensive ,Prewash ;
reduced rinse and final spin cycles
Delicate/Silk :- 30 °C
2 kg
For delicate, washable fabrics, e.g. made of silk, satin, synthetic fibres or blended fabrics (e.g. cur- tains)
Intensive ,Prewash ;
No spin between rinse cycles
/Wool øøøc:- 40 °C Handäor machine-washable fabrics made of wool or
containing wool
Particularly gentle wash programme to prevent shrinkage of laundry. Longer programme breaks (fabrics rest in the detergent solution)
$Sportswear øøøc:- 40 °C Textiles made of microfibres Intensive ,Prewas h 6Express 15´ :- 40 °C Easy-care fabrics made of cotton, l inen, synthetic
fibres or blended fabrics
Short programme, approx. 15 minutes, suitable for refreshing
Additional programmes 2Rinse/ Freshen up, cSpin ,cGentle Spin, >Drain
The programmes are time-controlled for lightly soiled textiles. If tex tiles are heavily soiled, reduce the load or select additional functions, e.g. Intens ive.
Programmes without Pre-wash - a dd detergent to compartment II, programmes with Prewash - distribute the d etergent between compartments Iand II.
*When washing the maximum load for programmes marked wi th *, always select the Intensive additiona l function.
Regardless of the type of washing, IEasy-Care 40 °C with maximum spi n speed is the best short programme for the jo b.
** The Cottons Eco 60°C,1100 r pmprogrammei s recommended for normal use.
Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München / Deu tschland
WAE22463AU 9000 583 016
0511
8
Safety instructions
– Read the instruction manual and installation instructions and all other in formation enclosed
with the washing machin e and act accordingly.
– Retain the documents for subsequent use.
Risk of electric shock – Never pull the cable to disconnect the mains plug.
– Never insert/disconnect the ma ins plug with damp hands.
Danger to life For worn-out appliances:
– Disconnect the m ains plug.
– Sever the m ains cable and discard alon g with the plug.
– Destroy the lock on the washing machine door. This w ill prevent
children from locking themsel ves in and risking their lives.
Danger of suffocation – Keep packaging, film and packaging parts out of the reach of
children.
Risk of poisoning – Keep detergents and care produ cts out of the reach of children.
Risk of explosion – Items of laundry pretreated with cleaning agents containing
solvents, e.g. stain remover/cleaning s olvent may cause an
explosion after being loaded into the washing m achine.
Rinse items of laundry th oroughly by hand beforeha nd.
Risk of injury – The wa shing machine door can become v ery hot.
– Be careful when dra ining hot detergent solution.
– Do no t climb onto the washing machine.
– Do not lean on the open washing machine door.
– Do no t reach into the d rum if it is still rotating.
– B e careful when opening the deterge nt drawer while the m achine
is in operation.
Consumption values
Programme Additional
function Load Electricity consumption** Water** Programme
duration**
LFC ottons 40 °C Intensive 6.5 kg 0,65 kWh 56 l 3:04 h
Cottons Eco 60 °C* Intensive 6.5 kg 1,19 kWh 47 l 2:36 h
LFC ottons 90 °C Intensive 6.5 kg 2,00 kWh 66 l 2:51 h
IEasy-Care 40 °C Intensive 3 kg 0.55 kWh 50 l 1:24 h
IEasy-Care 40 °C -3 kg 0.54 kWh 40 l 0:55 h
1Mixed Load 3 0 °C -3 kg 0.32 kW h 35 l 0:44 h
Delicate/Silk 30 °C -2 kg 0.25 kWh 38 l 0:32 h
/ccWool 30 °C -2 kg 0.15 kWh 34 l 0:40 h
* Programme setting with maximum spin speed for testing according to or in accordance with A S/NZS 2040.2
and AS/NZS 6400.
Note on comparative tests: test th e test programme with maximum load, Intensive additional fun ction selected, maxi-
mum spin speed.
Ashort programme which c an be used for coloured items is IEasy-Care 40 °C ,without th e In tensivea dditional
function selected and set to maximum spin speed.
** The values deviate from the indicated values depending on w ater pressure, hardness, and inlet temperature, ambient
temperature, type, amount and soiling of the laundry, deter gent used, fluctuations in the power supply and selected
additional functions.
8
9
Care
Before washing for the first time
Do not load any laundry into th e machine. Turn on the tap.
Add the following to compartment II:
– approx. 1 litr e water
– detergent ( dosage according to the manufacturer's instructions fo r light soiling and the
appropriate degree of water hardnes s)
Set the programme selector to Easy-Care I60 °C and se lect $Start/Pause. At the en d of
the programme, turn the programme selector to Off.
Machine housing, control panel
– Remove detergent residue immediately.
– Wipe away w ith a soft, damp cloth.
– Do not clean with a jet of water.
Cleaning the detergent drawer ...
... if it contains detergent or fabric softener res idues.
1. Pull out, press insert down, remove drawer completely .
2. Open the cover.
3. Clean the detergent dispenser tray and insert with water and a brush
and dry it.
4. Attach the insert and engage (connect the cylinder to the guide pin).
5. Push in the deterge nt drawer.
Leave the detergent drawer op en so that any residual water c an
evaporate.
Drum
Leave the washing machine doo r open so that the drum can dry out.
Rust stains - use chlorine-free c leaning agent, not steel wool.
Descaling Ensure t here is no laundry in the machine
Descale the appliance according to th e descaler manufacturer's instructions. This sh ould not
be necessary if the correct dosag e of detergent is used.
Information on the display panel depending on model
F:16 Close the washing machine door properly; laundry may be caught.
F:17 Open the tap completely, supply hose kinked or t rapped;
Clean the filter –> page 10, Water pressure too low.
F:18 Detergent solution pump bloc ked; Clean the detergent solution p ump –> page 10.
Drainage hose/waste pipe blocke d; Clean the drainage hose at the siphon –> page 10.
F:21 Motor fault. Call customer service.
F:23 Water in the base pan, appliance le aking. Call customer service!
–Risk of electric shock.
Disconnect the mains plug.
–Risk of explosion. No solvents .
10
Maintenance
Detergent solution pump
Turn the pr ogramme selector to Off and disconnect the mains plug.
1. Open and remove the service flap.
2. For models with a drainage hose: Remove the drainage hose from the
retainer and pull it from the h ousing. Remove the container.
Remove the sealing cap, al low the detergent solution to flow out.
Replace the sealing cap and place the drainage hose in the ret ainer.
2* For models wi thout a drainage hose: Carefully unscrew the p ump cover
until the detergent solution begins to flow ou t. When the service flap is
half full, close the pump cover a nd empty the service flap. Repeat th e
above steps until all the detergent solution has completely drained out.
3. Carefully unscrew the pump cover (residual wate r).
4. Clean the interior, pump c over thread and pump housing (the im peller in
the detergent solution pu mp must rotate).
5. Replace the pump cover and screw it tightly.
6. Place the service flap bac k on and close.
To prevent unused detergent from flowing stra ight into the drain during the next wash:
Pour 1 litre of water into compartment II and start the >Drain prog ramme.
Drainage hose at the siphon
Turn the programme selector to Off and disconnect the mains plug.
1. Loosen the hose clamp , carefully remove the drainage hos e
(residual water).
2. Clean the drainage hose and siphon connecting piece.
3. Reattach the dra inage hose and secure the connection with the hose
clamp.
Filter in the water supply
Reduce the water pressure in the supply hose:
1. Turn off the tap.
2. Select any programme (except Spin/>Drain).
3. Select $Start/Pause. Let the programme run for approximately 40
seconds.
4. Turn the programme selector to Off. Disconnect the mains plug .
5. Disconnect the hose fro m the tap.
6. Clean the filter using a small brush.
7. Depending on model, remove hose from rear of the
appliance and clean filter.
8. Connect the h ose and check for leaks.
–Risk of scalding. Allow the
detergent solution to cool do wn.
– Turn off the tap.
11
What to do if ...
ʑWater is leaking out. – Attach/replace the drain age hose correctly.
– Tighten the screw con nection of the supply hose.
ʑNo water supply.
Detergent not dispensed.
– Is $Start/Pause not se lected?
– Tap not tu rned on?
– Filter blocked? Clean the filter –> page 10.
– Supply hose kinked or trapped?
ʑWashing machine door
cannot be opened.
– Safety function active . Wait approx. 2 minutes.
–c(without fina l spin) selected ? –> page 4.
ʑProgramme does not
start.
–$Start/Pause or Ready in selected?
– Washing machine door clo sed?
ʑDetergent solution is not
drained.
– - - - - (witho ut final spin) selected? – > page 4.
– Clean the detergent solution pump –> page 10.
– Clean the waste pipe an d/or drainage hose.
ʑWater not visible in the
drum.
– Not a fault - w ater below the visible are a.
ʑUnsatisfactory spin
result.
Laundry wet/too damp.
– No t afau lt - the unbalanced-load detection system has cancelled
the spin cycle because of uneven distribution of the laundry.
Distribute small and l arge items of laundry ev enly inside the drum.
– Speed selected too low? –> page 5.
ʑThe programme duration
changes during the wa sh
cycle.
– Not a fault – the programm e sequence is optimised for the
particular wash process. Th is may result in ch anges to the
programme duration in the display field.
ʑSpin cycle performed
several times.
– Not a fault - unbalanced load detectio n system adjusts the
imbalance.
ʑResidual water in the
compartment for care
products.
– Not a fault - the action of the care product is not affected.
– Clean the insert if necessary –> page 9.
ʑOdour formation in the
washing machine.
– Run programme Cottons Stains 90 °C without lau ndry. Use
standard detergent.
ʑStatus display³þflashes.
Foam may be coming
out of the detergent
drawer.
–Too much detergent used? Mix 1 tablespoon of fabric s oftener
with ½ litre of water and pour into dispenser II (not for outdoor
and down-filled textiles!).
– Reduce the detergent d osage for the next wash cycle.
ʑIntense noise formation,
vibrations and
“wandering” during the
spin cycle.
– Are the appliance feet fixed?
Secure the appliance feet –> Insta llation instructions.
– Transportation safety d evices removed?
Remove the transportation s afety devices –> Installation
instructions.
ʑNoises during spin an d
drain cycles.
– Clean detergent-solution pump –> page 10.
ʑDisplay panel/indicator
lamps do not function
during operation.
– Power cut?
– Fuses triggered? R eset/change the fuses.
– If the fault occu rs repeatedly, call the a fter-sales service.
ʑProgramme sequence
longer than usual.
– Not a fault - unbalanced load detectio n system adjusts
imbalance by repeatedly dist ributing the laundry.
– Not a fault - foam detection system active - add s an additional
rinse cycle.
ʑDetergent residues on
the laundry.
– Occ asionally, phosphate-free detergents contain water- insoluble
residues.
– Select 2R inse/Freshen up or brush the laundry after w ashing.
If you cannot correc t a fault yourself (switchi ng on/off) or a repair is required:
– Turn the programme sele ctor to Off and remove the ma ins plug from the s ocket.
– Turn o ff the water sup ply and call the after-sales servic e –> Installation inst ructions.
Washing machine
en Instruction manu al

1 2
:- 90 Temp. °C VSelecting the temperature (:1 - 24h Ready in Programme ends in ...
 - 1200* rpm Select the spin speed (* depending on the model) or 
spin, laundry soaks in the last rinsing water)
Status displays Programme progress displays
12ccc-0- Washing, Rinse, Spin, End $$c2>$Correct installation according to the
separate Installation instructions.
Checking the machine
– Never use a damaged machine.
– Inform the after-sales service.
Connecting the mains
plug
Make sure your hands are dry.
Take hold of the plug only.
Turning the tap on
Compartment II: Detergent for the main wash, water softener,
bleach, stain remover
Close the washing machine door. Take care not to trap
Pour liquid detergent into the appropriate dispense
Your washing machine
Congratulations äyou have opted for a modern, high-quality
domestic appliance manufactured by Bosch. The washing machine
is distinguished by its economical water- and energy consumption.
Each machine that leaves our factory is inspected thoroughly to
ensure that it functions properly and is in perfect condition.
Further information: www.bosch-home.com
Environmentally friendly waste disposal All packaging must be disposed of in accordance with
environmental guidelines.
This appliance is certified in accordance with European Directive
2002/96/EEC on waste electrical and electronic equipment
(WEEE).
This directive provides the framework for the EU-wide collection
and reuse of used appliances.
Intended use
Contents Page
ʋIntended use .......................................................................................1
ʋProgrammes .......................................................................................1
ʋSetting and adjusting the programme ...........................................3
ʋWashing ...........................................................................................3/4
ʋAfter washing ......................................................................................4
ʋIndividual settings ..............................................................................5
ʋImportant information ....................................................................... 6
ʋOverview of programmes ................................................................7
ʋSafety instructions .............................................................................8
ʋConsumption values .........................................................................8
ʋCare .....................................................................................................9
ʋInformation on the display panel ....................................................9
ʋMaintenance .................................................................................... 10
ʋWhat to do if... .................................................................................. 11
Environmental protection/Conservation tips
– Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
– Wash normally soiled laundry without a pre-wash.
– Instead of LFCottons 90°C, choose the programme
Cottons Eco 60 °C. Comparable cleaning result with
significantly lower energy consumption.
– Measure the detergent according to the manufacturer's
instructions and water hardness.
– If the laundry is then dried in the tumble dryer, select the spin
speed according to the instructions of the dryer manufacturer.
Preparation
Display panel/
options buttons
Start/
Pause
$Programmes
Detailed overview of programmes –> page 7.
Temperature and spin speed can be selected individually,
depending on the selected programme and programme
progress.
LFCottons
hard-wearing fabrics
Cottons Stains
Cottons Eco
Delicate/Silk delicate washable fabrics
/øWool hand-/machine-washable wool
IEasy-Care easy-care fabrics
KDark Load dark textiles
2Rinse/
Freshen up
with subsequent spin cycle; for hand-
washed items, starching or freshen up
items –> page 6.
Spin washing washed by hand
Gentle Spin washing washed by hand at reduced
spin speed
>Drain the rinsing water if  occurs
1Mixed Load different types of laundry
6Express 15´ short programme
$Sportswaer textiles made of microfibres
VSkin Care hard-wearing fabrics $>$~Compartment ~: Fabric softener, starch
Compartment I: Detergent for pre-wash
ʋfor domestic use only,
ʋfor machine-washable fabrics and hand-washable wool
in detergent solution,
ʋto be operated with cold drinking water and commer-
cially available detergents and care products which are
suitable for use in washing machines.
ʋwhen determining the dosage of all washing powders,
additives and cleaning agents, you must follow the
manufacturer's instructions.
– Do not leave children unattended near the
washing machine.
– The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
– Keep pets away from the washing machine.
ʑV$cʑʑ$ʑcLF$$$~
Additional
functions

3 4
:VSelecting the temperature (:= cold)

 Select the spin speed (* depending on the model) or  (no final
spin, laundry soaks in the last rinsing water)
Programme progress displays
12cccWashing, Rinse, Spin, End
End of programme when ...
... the $Start/Pause flashes and -0- is displayed on the
display panel.
Changing the programme, if ...
... you have selected the wrong programme by mistake:
– Reselect the programme.
– Select $Start/Pause.
Interrupting the programme
Programmes at high temperatures:
– Cool washing: Selectc2Rinse/Freshen up.
Washing machine door remains locked.
– Select Off.
– Select Spin or >Drain.
– Select $Start/Pause
Sorting and loading laundry
Follow the manufacturer's care information.
According to the information on the care labels.
According to type, colour, soiling and temperature.
Do not exceed the maximum load –> page 7.
Follow important instructions –> page 6.
Insert large and small items of laundry.
Close the washing machine door. Take care not to trap items of laundry
between the washing machine door and the rubber seal.
Add detergent and care products
Measure accordingly:
Amount of laundry, soiling, water hardness (ask your water supply
company) and manufacturer's instructions.
Pour liquid detergent into the appropriate dispenser and place in the drum.
äʋʋʋʋʋʋʋʋʋʋʋʋʋʋLFBefore washing for the first time
Wash once without any laundry –> page 9.
Setting** and adjusting programmes
Programme selector
$All buttons are sensitive,
they only need to be
touched gently! If the
options buttons are
touched for longer, the
setting options run
automatically!
LF/øIK2>

16$VAdditional functions and options
buttons –> Individual settings, page 5.
Select $Start/Pause
Washing
1
2
Removing the washing
Open the washing machine door and remove the washing.
If (without final spin) is active: Turn the programme
selector to >Drain or select the spin speed.
Select Start/Pause $.
– Remove any foreign objects - risk of rusting.
– Leave the washing machine door and detergent
drawer open so that any residual water can
evaporate.
Turning the tap off
Switching off
Turn the programme selector to Off.
Washing
Detergent drawer with
compartments I,II,~Washing machine
door
~ʋʋʋʋ
Dilute thick fabric softener and fabric conditioner with water.
This prevents blockages.
ʑV$cʑʑ$ʑcLF$$$~3
Drum
Control panel
Service flap
Programme selector for
switching the machine on
and off and for selecting
the programme. Can be
turned in either direction.

56
:V:
  
12ccc$is displayed on the
$c2>$
äʋʋʋʋʋʋʋʋʋʋʋʋʋʋLF$LF/øIK2>

16$V$g.
>$– Leave the washing machine door and detergent
~~ʋʋʋʋIndividual settings
ʑOptions buttons
The spin speed and temperature can be changed before and during the selected programme
runs. The effects depend on the programme progress.
Temp. in °C VYou can change the displayed washing temperature. The maximum washing temperature
that can be selected depends on the programme that has been set.
Ready in The respective programme duration is displayed by selecting the programme. The
programme start can be delayed before the programme begins. The Ready in- time can be
set in hour- steps up to a maximum of 24 hours. Press the Ready in-button repeatedly
until the required number of hours is displayed (h = hour). Select Start/Pause $.
rpmc(Spin speed in rpm/no final spin)
You can change the displayed spin speed. The maximum selectable spin speed depends on
the model and on which programme is currently selected.
ʑAdditional function –> and overview of programmes, see page 7
Intensive Extension of the washing time for a more intensive washing of highly
soiled washing or 6.5 kg of cottons and coloureds.
Prewash For heavily soiled, hard-wearing washing, e.g. made of cotton or linen.
Prewash at 30 °C.
ʑ$Start/Pause
For starting or interrupting the programme.
ʑSignal
2. Setting the
volume for ...
1. Activating the mode
for setting the signal
volume
Set to •1 step, the
display panel
lights up
press and hold+1 step, release
Button signals Information signals
Set to •
Setting the
volume*
Setting the
volume*
1 step
direct
* you may need to select
the function several times.
Important information
Protecting the laundry and the machine
– Empty pockets.
– Look out for metal items (paperclips, etc.).
– Wash delicates in a laundry bag (tights, curtains, underwired bras).
– Fasten zips, do up any buttons.
– Brush sand out of pockets and collars.
– Remove curtain fittings or place in the laundry bag.
Laundry with varying degrees of soiling
Wash new items of clothing separately.
light Do not pre-wash. If required,
Pre-treat any stains as necessary. Choose the Intensive additional
function.
heavy Do not load as much laundry. Choose the cPrewash additional
function.
Soaking Load laundry of the same colour
Pour soaking agent/detergent into compartment II in accordance with the manufacturer's
instructions. Turn the programme selector to LFCottons 30 °C and select se $Start/
Pause. After approx. 10 minutes, press $Start/Pause. to pause the programme. Once the
required soaking time has elapsed, select $Start/Pause. again to continue the programme,
or select a different programme.
Starching Laundry must not be treated with fabric softener
Starching is possible in all wash programmes if liquid starch is used. Pour the starch in
accordance with the manufacturer's instructions into fabric softener compartment ~(rinse
first if necessary).
Dyeing/bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel.
Always follow the dye manufacturer's instructions! Do not use the washing machine for
bleaching clothes!
Freshen up Use programme Rinse/Freshen up
For items, that have been tucked away or stored for a period of time, to remove creases
caused by folding and storage and to eliminate odours. Use fabric conditioner for “fresh?
smell.

7
Overview of programmes –> Refer to the table of consumption values on page 8 and notes on page 6.
Programmes °C
(:= cold)max. Type of laundry Additional functions; information
LFCottons :- 90 °C
6.5 kg* Hard-wearing fabrics, heat-resistant fabrics made of
cotton or linen
Intensive ,Prewash Cottons Stains :- 60 °C
Cottons Eco** :- 60 °C VSkin Care :- 60 °C
Intensive ,Prewash ; for particularly sensitive skin, prolonged washing at selected tempera- ture, higher water level, additional rinse cycle
IEasy-Care :- 60 °C
3 kg*
Easy-care fabrics made of cotton, linen, synthetic fibres or blended fabrics Intensive ,Prewash 1Mixed Load :- 40 °C Fabrics made of cotton or easy-care fabrics Intensive ,Prewash ;
different types of laundry can be washed together
KDark Load :- 40 °C Dark textiles made of cotton and dark easy-care tex-
tilies
Intensive ,Prewash ; reduced rinse and final spin cycles
Delicate/Silk :- 30 °C
2 kg
For delicate, washable fabrics, e.g. made of silk, satin, synthetic fibres or blended fabrics (e.g. cur- tains)
Intensive ,Prewash ; No spin between rinse cycles
/Wool øøøc:- 40 °C Handäor machine-washable fabrics made of wool or
containing wool
Particularly gentle wash programme to prevent shrinkage of laundry. Longer programme breaks (fabrics rest in the detergent solution)
$Sportswear øøøc:- 40 °C Textiles made of microfibres Intensive ,Prewash 6Express 15´ :- 40 °C Easy-care fabrics made of cotton, linen, synthetic
fibres or blended fabrics
Short programme, approx. 15 minutes, suitable for refreshing
Additional programmes 2Rinse/ Freshen up, cSpin ,cGentle Spin, >Drain
The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load or select additional functions, e.g. Intensive .
Programmes without Pre-wash - add detergent to compartment II, programmes with Prewash - distribute the detergent between compartments Iand II.
*When washing the maximum load for programmes marked with *, always select the Intensive additional function.
Regardless of the type of washing,IEasy-Care 40 °C with maximum spin speed is the best short programme for the job.
** The Cottons Eco 60°C,1100 rpmprogramme is recommended for normal use.
Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München / Deutschland
WAE22463AU 9000 583 016
0511
8
Safety instructions
– Read the instruction manual and installation instructions and all other information enclosed
with the washing machine and act accordingly.
– Retain the documents for subsequent use.
Risk of electric shock – Never pull the cable to disconnect the mains plug.
– Never insert/disconnect the mains plug with damp hands.
Danger to life For worn-out appliances:
– Disconnect the mains plug.
– Sever the mains cable and discard along with the plug.
– Destroy the lock on the washing machine door. This will prevent
children from locking themselves in and risking their lives.
Danger of suffocation – Keep packaging, film and packaging parts out of the reach of
children.
Risk of poisoning – Keep detergents and care products out of the reach of children.
Risk of explosion – Items of laundry pretreated with cleaning agents containing
solvents, e.g. stain remover/cleaning solvent may cause an
explosion after being loaded into the washing machine.
Rinse items of laundry thoroughly by hand beforehand.
Risk of injury – The washing machine door can become very hot.
– Be careful when draining hot detergent solution.
– Do not climb onto the washing machine.
– Do not lean on the open washing machine door.
– Do not reach into the drum if it is still rotating.
– Be careful when opening the detergent drawer while the machine
is in operation.
Consumption values
Programme Additional
function Load Electricity consumption** Water** Programme duration**
LFCottons 40 °C Intensive 6.5 kg 0,65 kWh 56 l 3:04 h
Cottons Eco 60 °C* Intensive 6.5 kg 1,19 kWh 47 l 2:36 h
LFCottons 90 °C Intensive 6.5 kg 2,00 kWh 66 l 2:51 h
IEasy-Care 40 °C Intensive 3 kg 0.55 kWh 50 l 1:24 h
IEasy-Care 40 °C -3 kg 0.54 kWh 40 l 0:55 h
1Mixed Load 30 °C -3 kg 0.32 kWh 35 l 0:44 h
Delicate/Silk 30 °C -2 kg 0.25 kWh 38 l 0:32 h
/ccWool 30 °C -2 kg 0.15 kWh 34 l 0:40 h
* Programme setting with maximum spin speed for testing according to or in accordance with AS/NZS 2040.2
and AS/NZS 6400.
Note on comparative tests: test the test programme with maximum load, Intensive additional function selected, maxi-
mum spin speed.
Ashort programme which can be used for coloured items is IEasy-Care 40 °C, without the Intensive additional
function selected and set to maximum spin speed.
** The values deviate from the indicated values depending on water pressure, hardness, and inlet temperature, ambient
temperature, type, amount and soiling of the laundry, detergent used, fluctuations in the power supply and selected
additional functions.
8
I$
>>$ʑʑ$ʑcʑ$ʑʑʑʑʑʑʑʑ³þʑʑʑʑʑ2

:LF:::V:I:1:K::/øøøc:ä$øøøc:6:2cc>I
LFLFII1/ccI
9
Care
Before washing for the first time
Do not load any laundry into the machine. Turn on the tap.
Add the following to compartment II:
– approx. 1 litre water
– detergent (dosage according to the manufacturer's instructions for light soiling and the
appropriate degree of water hardness)
Set the programme selector to Easy-Care I60 °C and select $Start/Pause. At the end of
the programme, turn the programme selector to Off.
Machine housing, control panel
– Remove detergent residue immediately.
– Wipe away with a soft, damp cloth.
– Do not clean with a jet of water.
Cleaning the detergent drawer ...
... if it contains detergent or fabric softener residues.
1. Pull out, press insert down, remove drawer completely.
2. Open the cover.
3. Clean the detergent dispenser tray and insert with water and a brush
and dry it.
4. Attach the insert and engage (connect the cylinder to the guide pin).
5. Push in the detergent drawer.
Leave the detergent drawer open so that any residual water can
evaporate.
Drum
Leave the washing machine door open so that the drum can dry out.
Rust stains - use chlorine-free cleaning agent, not steel wool.
Descaling Ensure there is no laundry in the machine
Descale the appliance according to the descaler manufacturer's instructions. This should not
be necessary if the correct dosage of detergent is used.
Information on the display panel depending on model
F:16 Close the washing machine door properly; laundry may be caught.
F:17 Open the tap completely, supply hose kinked or trapped;
Clean the filter –> page 10, Water pressure too low.
F:18 Detergent solution pump blocked; Clean the detergent solution pump –> page 10.
Drainage hose/waste pipe blocked; Clean the drainage hose at the siphon –> page 10.
F:21 Motor fault. Call customer service.
F:23 Water in the base pan, appliance leaking. Call customer service!
–Risk of electric shock.
Disconnect the mains plug.
–Risk of explosion. No solvents.
10
Maintenance
Detergent solution pump
Turn the programme selector to Off and disconnect the mains plug.
1. Open and remove the service flap.
2. For models with a drainage hose: Remove the drainage hose from the
retainer and pull it from the housing. Remove the container.
Remove the sealing cap, allow the detergent solution to flow out.
Replace the sealing cap and place the drainage hose in the retainer.
2* For models without a drainage hose: Carefully unscrew the pump cover
until the detergent solution begins to flow out. When the service flap is
half full, close the pump cover and empty the service flap. Repeat the
above steps until all the detergent solution has completely drained out.
3. Carefully unscrew the pump cover (residual water).
4. Clean the interior, pump cover thread and pump housing (the impeller in
the detergent solution pump must rotate).
5. Replace the pump cover and screw it tightly.
6. Place the service flap back on and close.
To prevent unused detergent from flowing straight into the drain during the next wash:
Pour 1 litre of water into compartment II and start the >Drain programme.
Drainage hose at the siphon
Turn the programme selector to Off and disconnect the mains plug.
1. Loosen the hose clamp, carefully remove the drainage hose
(residual water).
2. Clean the drainage hose and siphon connecting piece.
3. Reattach the drainage hose and secure the connection with the hose
clamp.
Filter in the water supply
Reduce the water pressure in the supply hose:
1. Turn off the tap.
2. Select any programme (except Spin/>Drain).
3. Select $Start/Pause. Let the programme run for approximately 40
seconds.
4. Turn the programme selector to Off. Disconnect the mains plug.
5. Disconnect the hose from the tap.
6. Clean the filter using a small brush.
7. Depending on model, remove hose from rear of the
appliance and clean filter.
8. Connect the hose and check for leaks.
–Risk of scalding. Allow the
detergent solution to cool down.
– Turn off the tap.
ʑʑ$ʑcʑ$ʑʑʑʑʑʑʑʑ³þʑʑʑʑʑ2

:LF:::V:I:1:K::/øøøc:ä$øøøc:6:2cc>I
LFLFII1/ccII$>>$
11
What to do if ...
ʑWater is leaking out. – Attach/replace the drainage hose correctly.
– Tighten the screw connection of the supply hose.
ʑNo water supply.
Detergent not dispensed.
– Is $Start/Pause not selected?
– Tap not turned on?
– Filter blocked? Clean the filter –> page 10.
– Supply hose kinked or trapped?
ʑWashing machine door
cannot be opened.
– Safety function active. Wait approx. 2 minutes.
–c(without final spin) selected? –> page 4.
ʑProgramme does not
start.
–$Start/Pause or Ready in selected?
– Washing machine door closed?
ʑDetergent solution is not
drained.
– - - - - (without final spin) selected? –> page 4.
– Clean the detergent solution pump –> page 10.
– Clean the waste pipe and/or drainage hose.
ʑWater not visible in the
drum.
– Not a fault - water below the visible area.
ʑUnsatisfactory spin
result.
Laundry wet/too damp.
– Not a fault - the unbalanced-load detection system has cancelled
the spin cycle because of uneven distribution of the laundry.
Distribute small and large items of laundry evenly inside the drum.
– Speed selected too low? –> page 5.
ʑThe programme duration
changes during the wash
cycle.
– Not a fault – the programme sequence is optimised for the
particular wash process. This may result in changes to the
programme duration in the display field.
ʑSpin cycle performed
several times.
– Not a fault - unbalanced load detection system adjusts the
imbalance.
ʑResidual water in the
compartment for care
products.
– Not a fault - the action of the care product is not affected.
– Clean the insert if necessary –> page 9.
ʑOdour formation in the
washing machine.
– Run programme Cottons Stains 90 °C without laundry. Use
standard detergent.
ʑStatus display³þflashes.
Foam may be coming
out of the detergent
drawer.
–Too much detergent used? Mix 1 tablespoon of fabric softener
with ½ litre of water and pour into dispenser II (not for outdoor
and down-filled textiles!).
– Reduce the detergent dosage for the next wash cycle.
ʑIntense noise formation,
vibrations and
“wandering” during the
spin cycle.
– Are the appliance feet fixed?
Secure the appliance feet –> Installation instructions.
– Transportation safety devices removed?
Remove the transportation safety devices –> Installation
instructions.
ʑNoises during spin and
drain cycles.
– Clean detergent-solution pump –> page 10.
ʑDisplay panel/indicator
lamps do not function
during operation.
– Power cut?
– Fuses triggered? Reset/change the fuses.
– If the fault occurs repeatedly, call the after-sales service.
ʑProgramme sequence
longer than usual.
– Not a fault - unbalanced load detection system adjusts
imbalance by repeatedly distributing the laundry.
– Not a fault - foam detection system active - adds an additional
rinse cycle.
ʑDetergent residues on
the laundry.
– Occasionally, phosphate-free detergents contain water-insoluble
residues.
– Select 2Rinse/Freshen up or brush the laundry after washing.
If you cannot correct a fault yourself (switching on/off) or a repair is required:
– Turn the programme selector to Off and remove the mains plug from the socket.
– Turn off the water supply and call the after-sales service –> Installation instructions.
Washing machine
en Instruction manual
