1 2 3 4 5 6
End of programme when ...
... the indicator light End is on.
Terminating the programme
For programmes at h igh temperature:
– Cool washing: Select R inse/Freshen Up.
– Select Start/Pause.
For programmes at l ow temperature:
– Select Spin or <Drain.
– Select Start/Pause.
Change programme if ...
... you have mistakenly selec ted a wrong programme:
– Reselect programme.
– Select Start/Pause.
The new programme starts from th e beginning.
Cancel Programme
– Select Start/Pause.
– If required, top up wash ing (do not leave door open
for a long time – water from th e washing could run out
of the open door).
– Select Start/Pause.
Correct installation according
to separate installation instructions.
Checking the machine
– Ne ver switch on a dam aged machine!
– Inform your customer service!
Insert mains plug
With dry hands only!
Take hold of the plug only!
Turn on the tap
Dispenser II: Detergent for main wash, softener,
bleach, stain remover
Sorting and inserting the washing
Follow manufacturer’s care information!
According to the informatio n on the care labels.
According to type; colour; soiling and temperature.
Do not exceed maximum load. aPage 7
Follow important instruction s! aPage 6
Insert large and small items of washing!
Close the washing machine d oor. Do not jam items o f washing between the
washing machine door and rub ber seal.
Add detergent and care product
Dose according to:
amount of washing, soiling, w ater hardness (available from y our water utility
company) and manufactu rer’s instructions.
Pour liquid detergent in to corresponding dispenser and place in drum.
Caution when opening the dete rgent drawer while the appliance i s running!
Your washing machine
Congratulations – You have opted for a modern, high-quality
domestic appliance manufactured by Bosch. The washing machine is
distinguished by its economical consumption of w ater and energy.
Each appliance which leaves our factory is inspected tho roughly to
ensure that it functio ns properly and i s in perfect conditi on.
Further information on o ur products, accessories, spar e parts and
services can be found at: www.bosc h-home.com or contact our
customer service centres.
Intended use
Contents Page
ʋIntended use ........................................................................................ 1
ʋProgrammes ........................................................................................ 1
ʋSelecting and adjus ting a programme .............................. .............3
ʋWashing. ...........................................................................................3/ 4
ʋAfter washing..................... .................................................................. 4
ʋIndividual settings ................................ ...............................................5
ʋImportant information .................................................................. .......6
ʋOverview of programmes .................................................................. 7
ʋSafety instructions.............................................................................. .8
ʋConsumption values.................................................................... .......8
ʋCare........................................... ............................................................ 9
ʋInformation about th e indica tor lights ... ..........................................9
ʋMaintenance ...................................................................... ............... 10
ʋWhat to do if … ................................................................................. 11
Protection of the environment/Conservation tips
– Utilise the maximum amount of washing for the particular
programme.
– Wash normally s oiled washing without prewas h.
– Instead of the Cottons 90 °C programme, select
Cottons Eco 60 °C and Ec o+additional function.
Comparable cleaning resu lt with significantly lower e nergy
consumption.
– Measure d etergent according to the m anufacturer’s instructions
and water hardness.
– If the washing is th en dried in the tumble dryer, select spin speed
according to the instructions of the dryer manufacturer.
Preparation Before using your washing machine for the first time
wash once without any washi ng. aPage 9
Setting programmes
Spin speed * Programme selectorStart/
Pause
Programme selector for switching the machine
on and off and for selecting the p rogramme.
Can be rotated in either d irection.
Programmes
Detailled overview of programmes aPa ge 7
Spin speed can be selected in dividually irrespective of the
selected programme and p rogramme progress.
Cottons hard-wearing textiles
Cottons Eco hard-wearing textiles
!Mixed Load different types of washing
Rinse/
Freshen Up
extra rinse with spin;
for hand wash, for s tarching
or “refreshing” washing. aPage 6
Spin washing washed by hand;
extra spin with selectable spin sp eed
<Drain the rinsing water when Ri nse Hold
is activated (rinse stop = without final
spin)
Wool hand/machinewashable wool
Delicates/Silk for easy-care, washa ble textiles
Easy-Care for easy-care textiles
Additional functions and s pin speed
aIndividual settings, Page 5
  Select Start/Pause
Washing
1
2
Washing
Detergent drawers
with dispensers I,II,~Door handle
Dispenser ~:Fabric softener, starch
Dispenser I: Detergent for prewas h
ʋfor use in the household on ly,
ʋfor washing machine-wash able textiles and hand-
washable wool in wash li quor,
ʋto be operated with cold drinking water and
commercially available d etergents and care products
which are suitable for use in wa shing machines.
.
– F ollow the safety instruct ions on Page 8!
– Do not leave children un attended near the
washing machine!
– C hildren and uninstructed persons must not use
the washing machine!
– Ke ep pets away from th e washing machine!
Dilute viscous fabric softener and fabric co nditioner with water.
Prevents blockage of the overflow.
Individual settings
ʑSpin speed adepending on model
You can change the indica ted spin speed or select Rinse Hold (rinse stop = without fin al spin
cycle, washing remains in the water after the last rinse cycle). Effects d ependent on the
programme progress.
The maximum selectable spin s peed depends on the model and the set programme.
ʑAdditional functions aOverview o f programmes, Page 7
Eco+Extension of th e washing time for a more intensiv e washing of highly
soiled washing.
Prewash For heavily soiled wash ing. Prewash at 30 °C.
SReduced Ironing Special spin sequence with subsequent fluffin g. Gentle final spin
at reduced spin speed . Residual moisture of the washing slightly
increased.
Aqua Plus Increased water level. Additiona l rinse cycle. Longer programm e
duration. For areas with very soft wate r or for further improvement
of the rinsing result.
ʑ
 Start/Pause
For starting or interrupting the programme.
ʑSignal
1 step
to right
2. Set volume for ...
1. Activate setting
mode for signal
volume
set to Â1 step
to right
select and
hold +release
... Button signals ... Information signals
set to Âset volume **set volume **
direct
** If required, select repeatedly
Blind mode *
ON–OFF
Optional:
ON–OFF set to Â* Long signal – function on.
Short signal – function off .
1 step
to right Eco+

Important information
Before using your washing machine for the first time
Do not put an y washing in th e washing machine ! Turn the ta p on. Pour into dispenser II:
– appro x. 1 litre of water,
– d etergent (dosage acco rding to manufacture r’s instructions for lig ht soiling and accordin g to
degree of wate r hardness).
– Set pr ogramme selector t o Easy-Care 60 ° C and sele ct Start/Pause.
At the end of the programme set the programme selector to Off.
Protecting the washing and the machine
– When dosing al l detergents, cleaning aids and cleani ng agents, always follow
the manufacturer's instruct ions.
– Empty pockets. Remove m etal parts (paper clip s, etc.).
– Wash delicates in the net/ bag (tights, curtains, underwired bras).
– Close zips, button up c overs.
– Brush sand out of pocke ts and collars.
– Remove curtain fittings o r include in the ne t/bag.
Insert laundry
Insert large and sma ll items of washing !
Do not jam item s of washing bet ween the washing machine door and rubber seal.
Washing with different degrees of soiling
Wash new items separat ely.
Light Do not prewash.
If required, pretreat stains. Select Eco+additional function.
Heavy Load less washing. Prew ash.
If required, pretreat stains. Select Eco+additional function.
Soaking Load washing of the same colour.
Pour soaking agent/d etergent into dispenser II according to the manufac turer’s instructions. Set
programme selector to Cottons 3 0 °C and select Start/Pause. Aft er approx. 10 m inutes
select Start/Pause to stop the programme. Afte r the required soaking time reselect
Start/Pause if the pr ogramme is to be co ntinued or change th e programme.
Starching Washing should not be treated with fabric softener.
Liquid starch can be used in all wash progra mmes. Pour starch into the fabric softener
dispenser ~according to manufacturer’s specif ications (if required cl ean beforehand).
Dyeing/Bleaching
Dye in household quanti ties only. Salt may attack stainless steel! Observe spe cifications of the
dye manufacturer! D o not bleach washing i n the washing m achine!
Refreshing Program me Rinse/Freshen Up.
For items of washing which were stored awa y or not used for a prolonged period, to remove
odours and crea ses which were c aused by folding a nd storage.
Use finishing agent for a “fresh” fragrance .
Emergency re lease e.g. if powe r failure occurs
The programme continues running when the power supply is restored.
If the washing is still to be remo ved, the door can b e opened as described below:
Risk of scalding!
Detergent solution and wa shing may be hot. If required, leave to
cool down.
Do not reach into the drum in case it is still rotating.
Do not open the door if yo u can still see water thro ugh the glass.
1. Set programme sel ector to Off, pull out t he mains plug.
2. Drain the wat er. aPage 10
3. Pull down emergenc y release with a tool and release.
Door can then be o pened.
Additional
functions
3
Door
Control panel
Status
displays
Switching off
Turn the programme selector to O ff.
Turn off tap
Not required for Aqua-Stop m odels. aInformation,
Installation Instructions
Remove the washing
Open washing machine door and remove washing.
If Rinse Hold (rinse stop = without final spin) active:
Set programme selector to <Drain o r Spin.
Select Start/Pause.
– Remove any fore ign objects – risk of rustin g.
– Leave detergent drawer and do or open so that
residual water can evaporate.
(* depending on model)
Emergency lock release
Detergent-solution pump
Drainage hose
Do not switch on the wash ing machine until you
have read these instructions and the separate
Installation/Maintenance instructions !

7
Overview of programmes aObserve table of consumption values on Page 8 and in structions on Page 6!
Programmes °C max. Type Additonal functions; information
Cottons 30, 40, 60, 90 °C 7 kg * Hard-wearing textiles, heat-resistant textiles
made of cotton or linen Eco+,Prewash, SRedu ced Ironing,Aqua Plus
Cottons Eco 40, 60 °C
Easy-Care 30, 40, 60 ° C
3.5 kg *
Easy-care textiles made of cotton, linen, synthetic fibres or blended fabrics Eco+,Prewash, SRedu ced Ironing,Aqua Plus
!Mixed Load 30 °C Textiles made of co tton or easy-care textiles Eco+,Prewash, SReduced Ironing,Aqua Plus
Different types of washing can be washed together
Delicates/Silk 30 °C
2 kg
For delicate, washable textiles, e.g. made of s ilk, satin, synthetic fibres or blended fabrics (e.g. curtains) Eco+,Prewash, SRedu ced Ironing,Aqua Plus
No spin cycle between the rinse cycles
Wool cold, 30 °C Hand or machine-washable wool or rich-wool
textiles
Especially gentle wash programme to prevent shrinkage, longer programme pauses (textiles rest in w ash liquor)
Additional programmes Rinse/Freshen Up, Spin, <Drain
The programmes are time-controlled for lightl y soiledtex tiles. If textiles are heavily soiled, reduce the load or select additional function, e.g. Eco+.
When washing at ma ximum load using programmes marked with *, always select Ec o+additional function.
Irrespective of the type of w ashing, Easy-Care 40 °C at max. selectable spin speed is best suited as a short p rogramme.
Programmes without Prewash – pour detergent into d ispenser II, programmes with Prewash – divide detergent b etween dispensers Iand II.
9204 / 9000762957 *762957* WIS24140GB
Robert Bosch Hausgeräte Gm bH
Carl-Wery-Str. 34
81739 München/Deutschl and
8
Safety instructions
– Read and follow th e operating and installation instructions and all other in formation
enclosed with the washing machine .
– Retain documents for s ubsequent use.
Risk of electric shock – Never pull out the mains plug by tugging the power cord!
– Insert/pull out th e mains plug with dry han ds only.
Danger to life On redundant appliance s:
– Pull out the mains pl ug!
– Sever the power cord and discard together with the plug.
– Destroy the lock on the w ashing-machine door. This will prevent
children from locking t hemselves in and suffocati ng.
Risk of suffocation – Keep packa ging, plastic film and packaging parts out of the reach
of children.
Risk of poisioning – Keep detergents and care products out of the reach of children.
Risk of explosion – Caused by detergen ts containing solvents, e.g. s tain remover/
items of washing pre treated with solvent naphtha m ay result in an
explosion after being load ed into the washing ma chine.
Before hand thoroughly rinse items of washing by han d.
Risk of injury – Washing machine door may become very hot.
– Caution wh en draining hot d etergent solution.
– Do not climb on the washing machine.
– Do not lean on the o pen washing machine door.
– Do not reach into the drum in case it is still rotating.
Consumption values
Programme Additonal function Load Current*** Water*** Programme
duration***
Cottons 30 °C* Eco+7 kg 0.55 kWh 75 l 2:12 h
Cottons 40 °C* Eco+7 kg 0.85 kWh 75 l 2:12 h
Cottons 60 °C* Eco+7 kg 1.50 kWh 75 l 2:12 h
Cottons 90 °C E co+7 kg 2.51 kWh 90 l 2:12 h
Easy-Care 40 °C* Eco+3.5 kg 0.55 kWh 55 l 1:12 h
Delicates/Silk 30 °C – 2.0 kg 0.20 kWh 39 l 0:40 h
Wool 30 °C – 2.0 kg 0.20 kWh 40 l 0:36 h
* Programme setting for test according to currently valid European standard 60456.
Information about comparability te sts:
To test the test programmes, wash indicated lo ad, with Eco Plus additional func tion
and at maximum selectable spin s peed.
Programme Additonal function Load Annual energy
consumption
Annual water
consumption
Cottons Eco 40 °C/60 °C Eco+** 7/3.5 kg 218 kWh 10560 l
** Programme setting for testing and energ y labelling according to directive 2010/30/EU w ith cold
water (15 °C).
*** The values deviate from the indicate d values depending on water p ressure, water hardness,
water inlet temperature, room tempe rature, type and amount of washing and degree of soiling,
utilised detergent, fluctuations in the m ains voltage and selected additio nal functions.
9
Insert for liquid detergent depending on model
Position insert for dosin g liquid detergent:
– Com pletely remove detergent drawer. aPage 10
– Push insert forwards .
Do not use insert (push upwards):
– For gel-lik e detergents and washing powders,
– For progra mmes with Prewash.
Care
ʑMachine housing, control panel
– Remove dete rgent residue immediately.
– Wipe with a soft, damp cloth.
– Do not clean the appliance with a water jet.
Clean the detergen t drawer ...
... if it contains detergent or fabric softener res idue.
1. Pull out, depress in sert, take out drawer all the way.
2. Take out insert: using your finger, pres s insert upwards.
3. Clean detergent d ispenser and insert with water an d a brush and dry.
4. Attach insert a nd lock into pos ition (push cylinder on to guide pin).
5. Slide in the deterge nt dispenser.
Leave detergent drawer open so that residua l water can evaporate.
ʑDrum
Leave washing mac hine door open so that the drum c an dry out.
Use chlorine-free cleaning ag ent, not steel wool.
ʑDescaling No wa shing in the machine!
Not required if d etergent dosed correctly. Ho wever, if this does o ccur, follow the instru ctions
of the descaling agent ma nufacturer. Suitable descalers can be purchased on our website
or from customer service.
Information about the indicator lights dep ending on model
A signal sounds and the indicator lamps for spin s peed and status displays flash:
¤
¤
¤
¤
¤
¤
¤
¤
¤
Close the washing
machine door
properly;
washing may
be caught.
¤
¤
¤
¤
¤
¤
¤
¤
¤
Turn on tap fully, supply
hose kinked/jammed;
clean filter aPage 1 0,
water pressure too low.
¤
¤
¤
¤
¤
¤
¤
¤
¤
Drain pump blocked;
clean drain pump.
aPage 10
Drainage hose/outlet
pipe blocked; clean
drainage hose on the
siphon. aPage 10
¤
¤
¤
¤
¤
¤
¤
¤
¤
Water in the base
pan, appliance
leaking. Call
customer service!
¤
¤
¤
¤
¤
¤
¤
¤
¤
or ¤
¤
¤
¤
¤
¤
¤
¤
¤
or ¤
¤
¤
¤
¤
¤
¤
¤
¤
Motor fault. Call
customer service!
Other displays: Switch off a ppliance, wait 5 secon ds and switch on a gain.
If the display is indicated a gain, call customer serv ice. aInstallation Instructions
–Risk of electric shock ! Pull out the mains plug!
–Risk of explosion! No solvents!
10
Maintenance
Detergent-solu tion pump
Set programme selector to Off, pull o ut the mains plug.
1. Take the drainage h ose out of the holder.
Remove sealing cap, allow detergent s olution to flow out.
Put the closing cap ba ck on the hose.
2. Carefully unscrew the pump cover (residual wate r).
3. Clean the in terior, pump cover threa d and pump housing
(fan impeller in the d etergent-solution pump must rotate).
4. Reinsert and screw on pump cover.
Handle is upright. Insert the dra in hose into the holder.
To prevent unused detergent fro m flowing into the outlet during th e next wash:
Pour 1 litre of water into dispen ser II and start the <Drain pr ogramme.
Drainage hose on the siphon
Set programme selector to Off, pull o ut the mains plug.
1. Loosen hose clip, car efully remove drainage hose (residual wa ter).
2. Clean drainage ho se and siphon spigot.
3. Re-attach drainage h ose and secure connection poin t with hose clip.
Filter in the water inlet hose
Risk of electric shock!
Do not immerse Aqua- Stop safety device in water (contains electric valve) .
Release water pressure in the supply hose:
1. Turn off the tap!
2. Select any programme (except Spin/<Drain) .
3. Select Start/Pause . Leave programme for approx. 40 seco nds.
4. Turn the programme selector to Off. Pull out the mains plug!
Clean the filter:
5. Disconnect the hose fro m the water tap.
Clean filter with small bru sh.
and/or for standard and Aqua-Secure models:
Remove hose from the rear of th e appliance.
Take out filter with p liers and clean.
6. Connect the h ose and check for leaks.
–Risk of scalding!
Allow detergent solution to cool dow n!
– Turn o ff the tap!
11
What to do if …
ʑWater is running out. – Correctly a ttach/replace drainage ho se.
– Ti ghten screw-fitting on t he supply hose.
ʑWater not flowing in.
Detergent not washed in.
–Start/Pause not selected?
– Tap not open?
–Filter blocked? Clean t he filter. aPage 10
– Su pply hose kinked or jammed?
ʑWashing-machine doo r
cannot be opened.
– Safe ty function active. Stop programme? aPage 4
–Rinse Hold (without final spin) selected? aPage 3 , 4
– Ca n be opened via em ergency release only? aPage 6
ʑProgramme does not start . – Start/Pause not selected ?
– Do or closed?
ʑDetergent solution is no t
drained.
–Rinse Hold (without final spin) selected? aPag e 3, 4
– Clean the dra in pump. aPage 10
– Cl ean outlet pipe and/o r drainage hose.
ʑWater not visible i n the
drum.
– No t a fault – water below the visible area.
ʑSpin result not satisfa ctory,
washing wet/too damp :
– No t a fault – unbalanced load dete ction system has stopped the s pin
cycle, washing unevenly distributed.
Distribute small and large items of washing in the drum.
–SReduced Ironing is selecte d? aPage 5
– To o low speed selected? aPage 5
ʑThe programme du ration
changes during the wash
cycle.
– Not a fault – the programme sequence is optimised for the particular
wash process. This may result in ch anges to the programme duration
in the display field.
ʑSpin cycle actuated severa l
times.
– Not a fault – unba lanced load detection system adjusts imb alance.
ʑResidual water in the
dispenser for care
product ~.
– Not a fault – effect of the care product no t impaired.
– If required, clean insert. aPag e 9
ʑOdour formation i n the
washing machine.
– Run Cott ons 90 °C programme without washing.
Use standard detergent.
ʑFoam is coming o ut of the
detergent drawer.
– To o much detergent use d?
Mix 1 tablespoon of fabric softener with ½ litre of water and pour into
dispenser II (not for outdoor, s ports and down-filled t extiles!).
– Re duce detergent dosag e for the next wash cycle.
ʑLoud noise formation,
vibrations and “Wandering”
during spin cycle.
– Appl iance feet fixed?
Secure appliance feet . aInstallation Inst ructions
– Transpo rtation protection devices removed?
Remove transportation prote ction devices. aInstallation Instructi ons
ʑNoises during spin
and drain cycles.
– Clean the dra in pump. aPage 10
ʑIndicator lights do not
function while the
appliance is running.
– Power failure ?
– Fu se tripped? Switch o n/replace fuse.
– If the fault occurs repeatedl y, call customer service.
ʑThe programme tak es
longer than usual.
– Not a fault – unba lanced load detection system adjusts imb alance
by repeatedly distributing the wash ing.
– Not a fault – foam detection system a ctive – a rinse cycle is
switched on.
ʑDetergent residue on the
washing.
–Occasionally phosphate-free de tergents contain water-insoluble
residue.
– Select Rin se/Freshen Up or brush t he laundry after washing.
ʑIn the pause sta tus
Start/Pause flashes very
quickly and a s ignal
sounds.
– Wa ter level too high. W ashing cannot be re loaded.
Immediately close washing machine door.
– Select S tart/Pause to continue the progr amme.
If a fault cannot b e rectified (switching the machine on and off) o r a repair is required:
– Se t programme selector to O ff and pull out the m ains plug.
– Tu rn off the tap and call c ustomer service . aInstallation Instructions
Washing machine
en Instruction manu al

1 2 <Correct installation according
to separate installation instructions.
Checking the machine
– Never switch on a damaged machine!
– Inform your customer service!
Insert mains plug
With dry hands only!
Take hold of the plug only!
Turn on the tap
Dispenser II: Detergent for main wash, softener,
bleach, stain remover
aa
Close the washing machine door. Do not jam items of
amount of washing, soiling, water hardness (availab
Caution when opening the detergent drawer while the
Your washing machine
Congratulations – You have opted for a modern, high-quality
domestic appliance manufactured by Bosch. The washing machine is
distinguished by its economical consumption of water and energy.
Each appliance which leaves our factory is inspected thoroughly to
ensure that it functions properly and is in perfect condition.
Further information on our products, accessories, spare parts and
services can be found at: www.bosch-home.com or contact our
customer service centres.
Intended use
Contents Page
ʋIntended use ........................................................................................1
ʋProgrammes ........................................................................................1
ʋSelecting and adjusting a programme ...........................................3
ʋWashing............................................................................................3/4
ʋAfter washing.......................................................................................4
ʋIndividual settings ...............................................................................5
ʋImportant information.........................................................................6
ʋOverview of programmes..................................................................7
ʋSafety instructions...............................................................................8
ʋConsumption values...........................................................................8
ʋCare.......................................................................................................9
ʋInformation about the indicator lights .............................................9
ʋMaintenance ..................................................................................... 10
ʋWhat to do if … ................................................................................. 11
Protection of the environment/Conservation tips
– Utilise the maximum amount of washing for the particular
programme.
– Wash normally soiled washing without prewash.
– Instead of the Cottons 90 °C programme, select
Cottons Eco 60 °C and Eco+additional function.
Comparable cleaning result with significantly lower energy
consumption.
– Measure detergent according to the manufacturer’s instructions
and water hardness.
– If the washing is then dried in the tumble dryer, select spin speed
according to the instructions of the dryer manufacturer.
Preparation a
Spin speed * Programme selectorStart/
Pause
Programme selector for switching the machine
on and off and for selecting the programme.
Can be rotated in either direction.
Programmes
Detailled overview of programmes aPage 7
Spin speed can be selected individually irrespective of the
selected programme and programme progress.
Cottons hard-wearing textiles
Cottons Eco hard-wearing textiles
!Mixed Load different types of washing
Rinse/
Freshen Up
extra rinse with spin;
for hand wash, for starching
or “refreshing” washing. aPage 6
Spin washing washed by hand;
extra spin with selectable spin speed
<Drain the rinsing water when Rinse Hold
is activated (rinse stop = without final
spin)
Wool hand/machinewashable wool
Delicates/Silk for easy-care, washable textiles
Easy-Care for easy-care textiles
a

~Dispenser ~:Fabric softener, starch
Dispenser I: Detergent for prewash
ʋfor use in the household only,
ʋfor washing machine-washable textiles and hand-
washable wool in wash liquor,
ʋto be operated with cold drinking water and
commercially available detergents and care products
which are suitable for use in washing machines.
.
– Follow the safety instructions on Page 8!
– Do not leave children unattended near the
washing machine!
– Children and uninstructed persons must not use
the washing machine!
– Keep pets away from the washing machine!
ʑaʑaSʑ

ʑ
ÂÂÂ
~a
Additional
functions
Status
displays
a<(* depending on model)
Do not switch on the washing machine until you
have read these instructions and the separate
Installation/Maintenance instructions!

3 4
End of programme when ...
... the indicator light End is on.
Terminating the programme
For programmes at high temperature:
– Cool washing: Select Rinse/Freshen Up.
– Select Start/Pause.
For programmes at low temperature:
– Select Spin or <Drain.
– Select Start/Pause.
Change programme if ...
... you have mistakenly selected a wrong programme:
– Reselect programme.
– Select Start/Pause.
The new programme starts from the beginning.
Cancel Programme
– Select Start/Pause.
– If required, top up washing (do not leave door open
for a long time – water from the washing could run out
of the open door).
– Select Start/Pause.
Sorting and inserting the washing
Follow manufacturer’s care information!
According to the information on the care labels.
According to type; colour; soiling and temperature.
Do not exceed maximum load. aPage 7
Follow important instructions! aPage 6
Insert large and small items of washing!
Close the washing machine door. Do not jam items of washing between the
washing machine door and rubber seal.
Add detergent and care product
Dose according to:
amount of washing, soiling, water hardness (available from your water utility
company) and manufacturer’s instructions.
Pour liquid detergent into corresponding dispenser and place in drum.
Caution when opening the detergent drawer while the appliance is running!
ʋʋʋʋʋʋʋʋʋʋʋʋʋʋBefore using your washing machine for the first time
wash once without any washing. aPage 9
Setting programmes
Programme selector
Programme selector for switching the machine
on and off and for selecting the programme.
Can be rotated in either direction.
a!a<Additional functions and spin speed
aIndividual settings, Page 5
  Select Start/Pause
Washing
1
2
Washing
Detergent drawers
with dispensers I,II,~Door handle
~ʋʋʋ
Dilute viscous fabric softener and fabric conditioner with water.
Prevents blockage of the overflow.
ʑaʑaSʑ

ʑ
ÂÂÂ
~a
3
Door
Control panel
Switching off
Turn the programme selector to Off.
Turn off tap
Not required for Aqua-Stop models. aInformation,
Installation Instructions
Remove the washing
Open washing machine door and remove washing.
If Rinse Hold (rinse stop = without final spin) active:
Set programme selector to <Drain or Spin.
Select Start/Pause.
– Remove any foreign objects – risk of rusting.
– Leave detergent drawer and door open so that
residual water can evaporate.
Emergency lock release
Detergent-solution pump
Drainage hose

56
<out
aa
ʋʋʋʋʋʋʋʋʋʋʋʋʋʋaa!a<a

~~ʋʋʋIndividual settings
ʑSpin speed adepending on model
You can change the indicated spin speed or select Rinse Hold (rinse stop = without final spin
cycle, washing remains in the water after the last rinse cycle). Effects dependent on the
programme progress.
The maximum selectable spin speed depends on the model and the set programme.
ʑAdditional functions aOverview of programmes, Page 7
Eco+Extension of the washing time for a more intensive washing of highly
soiled washing.
Prewash For heavily soiled washing. Prewash at 30 °C.
SReduced Ironing Special spin sequence with subsequent fluffing. Gentle final spin
at reduced spin speed. Residual moisture of the washing slightly
increased.
Aqua Plus Increased water level. Additional rinse cycle. Longer programme
duration. For areas with very soft water or for further improvement
of the rinsing result.
ʑ
 Start/Pause
For starting or interrupting the programme.
ʑSignal
1 step
to right
2. Set volume for ...
1. Activate setting
mode for signal
volume
set to Â1 step
to right
select and
hold +release
... Button signals ... Information signals
set to Âset volume **set volume **
direct
** If required, select repeatedly
Blind mode *
ON–OFF
Optional:
ON–OFF set to Â* Long signal – function on.
Short signal – function off.
1 step
to right Eco+

Important information
Before using your washing machine for the first time
Do not put any washing in the washing machine! Turn the tap on. Pour into dispenser II:
– approx. 1 litre of water,
– detergent (dosage according to manufacturer’s instructions for light soiling and according to
degree of water hardness).
– Set programme selector to Easy-Care 60 °C and select Start/Pause.
At the end of the programme set the programme selector to Off.
Protecting the washing and the machine
– When dosing all detergents, cleaning aids and cleaning agents, always follow
the manufacturer's instructions.
– Empty pockets. Remove metal parts (paper clips, etc.).
– Wash delicates in the net/bag (tights, curtains, underwired bras).
– Close zips, button up covers.
– Brush sand out of pockets and collars.
– Remove curtain fittings or include in the net/bag.
Insert laundry
Insert large and small items of washing!
Do not jam items of washing between the washing machine door and rubber seal.
Washing with different degrees of soiling
Wash new items separately.
Light Do not prewash.
If required, pretreat stains. Select Eco+additional function.
Heavy Load less washing. Prewash.
If required, pretreat stains. Select Eco+additional function.
Soaking Load washing of the same colour.
Pour soaking agent/detergent into dispenser II according to the manufacturer’s instructions. Set
programme selector to Cottons 30 °C and select Start/Pause. After approx. 10 minutes
select Start/Pause to stop the programme. After the required soaking time reselect
Start/Pause if the programme is to be continued or change the programme.
Starching Washing should not be treated with fabric softener.
Liquid starch can be used in all wash programmes. Pour starch into the fabric softener
dispenser ~according to manufacturer’s specifications (if required clean beforehand).
Dyeing/Bleaching
Dye in household quantities only. Salt may attack stainless steel! Observe specifications of the
dye manufacturer! Do not bleach washing in the washing machine!
Refreshing Programme Rinse/Freshen Up.
For items of washing which were stored away or not used for a prolonged period, to remove
odours and creases which were caused by folding and storage.
Use finishing agent for a “fresh” fragrance.
Emergency release e.g. if power failure occurs
The programme continues running when the power supply is restored.
If the washing is still to be removed, the door can be opened as described below:
Risk of scalding!
Detergent solution and washing may be hot. If required, leave to
cool down.
Do not reach into the drum in case it is still rotating.
Do not open the door if you can still see water through the glass.
1. Set programme selector to Off, pull out the mains plug.
2. Drain the water. aPage 10
3. Pull down emergency release with a tool and release.
Door can then be opened.
a<– Leave detergent drawer and door open so that

7
Overview of programmes aObserve table of consumption values on Page 8 and instructions on Page 6!
Programmes °C max. Type Additonal functions; information
Cottons 30, 40, 60, 90 °C 7 kg * Hard-wearing textiles, heat-resistant textiles
made of cotton or linen Eco+,Prewash, SReduced Ironing,Aqua Plus
Cottons Eco 40, 60 °C
Easy-Care 30, 40, 60 °C
3.5 kg *
Easy-care textiles made of cotton, linen, synthetic fibres or blended fabrics Eco+,Prewash, SReduced Ironing,Aqua Plus
!Mixed Load 30 °C Textiles made of cotton or easy-care textiles Eco+,Prewash, SReduced Ironing,Aqua Plus
Different types of washing can be washed together
Delicates/Silk 30 °C
2 kg
For delicate, washable textiles, e.g. made of silk, satin, synthetic fibres or blended fabrics (e.g. curtains) Eco+,Prewash, SReduced Ironing,Aqua Plus
No spin cycle between the rinse cycles
Wool cold, 30 °C Hand or machine-washable wool or rich-wool
textiles
Especially gentle wash programme to prevent shrinkage, longer programme pauses (textiles rest in wash liquor)
Additional programmes Rinse/Freshen Up, Spin, <Drain
The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load or select additional function, e.g. Eco+.
When washing at maximum load using programmes marked with *, always select Eco+additional function.
Irrespective of the type of washing, Easy-Care 40 °C at max. selectable spin speed is best suited as a short programme.
Programmes without Prewash – pour detergent into dispenser II, programmes with Prewash – divide detergent between dispensers Iand II.
9204 / 9000762957 *762957* WIS24140GB
Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München/Deutschland
8
Safety instructions
– Read and follow the operating and installation instructions and all other information
enclosed with the washing machine.
– Retain documents for subsequent use.
Risk of electric shock – Never pull out the mains plug by tugging the power cord!
– Insert/pull out the mains plug with dry hands only.
Danger to life On redundant appliances:
– Pull out the mains plug!
– Sever the power cord and discard together with the plug.
– Destroy the lock on the washing-machine door. This will prevent
children from locking themselves in and suffocating.
Risk of suffocation – Keep packaging, plastic film and packaging parts out of the reach
of children.
Risk of poisioning – Keep detergents and care products out of the reach of children.
Risk of explosion – Caused by detergents containing solvents, e.g. stain remover/
items of washing pretreated with solvent naphtha may result in an
explosion after being loaded into the washing machine.
Before hand thoroughly rinse items of washing by hand.
Risk of injury – Washing machine door may become very hot.
– Caution when draining hot detergent solution.
– Do not climb on the washing machine.
– Do not lean on the open washing machine door.
– Do not reach into the drum in case it is still rotating.
Consumption values
Programme Additonal function Load Current*** Water*** Programme
duration***
Cottons 30 °C* Eco+7 kg 0.55 kWh 75 l 2:12 h
Cottons 40 °C* Eco+7 kg 0.85 kWh 75 l 2:12 h
Cottons 60 °C* Eco+7 kg 1.50 kWh 75 l 2:12 h
Cottons 90 °C Eco+7 kg 2.51 kWh 90 l 2:12 h
Easy-Care 40 °C* Eco+3.5 kg 0.55 kWh 55 l 1:12 h
Delicates/Silk 30 °C – 2.0 kg 0.20 kWh 39 l 0:40 h
Wool 30 °C – 2.0 kg 0.20 kWh 40 l 0:36 h
* Programme setting for test according to currently valid European standard 60456.
Information about comparability tests:
To test the test programmes, wash indicated load, with Eco Plus additional function
and at maximum selectable spin speed.
Programme Additonal function Load Annual energy
consumption
Annual water
consumption
Cottons Eco 40 °C/60 °C Eco+** 7/3.5 kg 218 kWh 10560 l
** Programme setting for testing and energy labelling according to directive 2010/30/EU with cold
water (15 °C).
*** The values deviate from the indicated values depending on water pressure, water hardness,
water inlet temperature, room temperature, type and amount of washing and degree of soiling,
utilised detergent, fluctuations in the mains voltage and selected additional functions.
aʑʑʑaaaa
<<ʑʑaʑaaaʑʑaaʑʑSaaʑʑʑ~aʑʑʑaaʑaʑʑʑʑa

aSS!SS<

9
Insert for liquid detergent depending on model
Position insert for dosing liquid detergent:
– Completely remove detergent drawer. aPage 10
– Push insert forwards.
Do not use insert (push upwards):
– For gel-like detergents and washing powders,
– For programmes with Prewash.
Care
ʑMachine housing, control panel
– Remove detergent residue immediately.
– Wipe with a soft, damp cloth.
– Do not clean the appliance with a water jet.
Clean the detergent drawer ...
... if it contains detergent or fabric softener residue.
1. Pull out, depress insert, take out drawer all the way.
2. Take out insert: using your finger, press insert upwards.
3. Clean detergent dispenser and insert with water and a brush and dry.
4. Attach insert and lock into position (push cylinder onto guide pin).
5. Slide in the detergent dispenser.
Leave detergent drawer open so that residual water can evaporate.
ʑDrum
Leave washing machine door open so that the drum can dry out.
Use chlorine-free cleaning agent, not steel wool.
ʑDescaling No washing in the machine!
Not required if detergent dosed correctly. However, if this does occur, follow the instructions
of the descaling agent manufacturer. Suitable descalers can be purchased on our website
or from customer service.
Information about the indicator lights depending on model
A signal sounds and the indicator lamps for spin speed and status displays flash:
¤
¤
¤
¤
¤
¤
¤
¤
¤
Close the washing
machine door
properly;
washing may
be caught.
¤
¤
¤
¤
¤
¤
¤
¤
¤
Turn on tap fully, supply
hose kinked/jammed;
clean filter aPage 10,
water pressure too low.
¤
¤
¤
¤
¤
¤
¤
¤
¤
Drain pump blocked;
clean drain pump.
aPage 10
Drainage hose/outlet
pipe blocked; clean
drainage hose on the
siphon. aPage 10
¤
¤
¤
¤
¤
¤
¤
¤
¤
Water in the base
pan, appliance
leaking. Call
customer service!
¤
¤
¤
¤
¤
¤
¤
¤
¤
or ¤
¤
¤
¤
¤
¤
¤
¤
¤
or ¤
¤
¤
¤
¤
¤
¤
¤
¤
Motor fault. Call
customer service!
Other displays: Switch off appliance, wait 5 seconds and switch on again.
If the display is indicated again, call customer service. aInstallation Instructions
–Risk of electric shock! Pull out the mains plug!
–Risk of explosion! No solvents!
10
Maintenance
Detergent-solution pump
Set programme selector to Off, pull out the mains plug.
1. Take the drainage hose out of the holder.
Remove sealing cap, allow detergent solution to flow out.
Put the closing cap back on the hose.
2. Carefully unscrew the pump cover (residual water).
3. Clean the interior, pump cover thread and pump housing
(fan impeller in the detergent-solution pump must rotate).
4. Reinsert and screw on pump cover.
Handle is upright. Insert the drain hose into the holder.
To prevent unused detergent from flowing into the outlet during the next wash:
Pour 1 litre of water into dispenser II and start the <Drain programme.
Drainage hose on the siphon
Set programme selector to Off, pull out the mains plug.
1. Loosen hose clip, carefully remove drainage hose (residual water).
2. Clean drainage hose and siphon spigot.
3. Re-attach drainage hose and secure connection point with hose clip.
Filter in the water inlet hose
Risk of electric shock!
Do not immerse Aqua-Stop safety device in water (contains electric valve).
Release water pressure in the supply hose:
1. Turn off the tap!
2. Select any programme (except Spin/<Drain).
3. Select Start/Pause. Leave programme for approx. 40 seconds.
4. Turn the programme selector to Off. Pull out the mains plug!
Clean the filter:
5. Disconnect the hose from the water tap.
Clean filter with small brush.
and/or for standard and Aqua-Secure models:
Remove hose from the rear of the appliance.
Take out filter with pliers and clean.
6. Connect the hose and check for leaks.
–Risk of scalding!
Allow detergent solution to cool down!
– Turn off the tap!
ʑʑaʑaaaʑʑaaʑʑSaaʑʑʑ~aʑʑʑaaʑaʑʑʑʑa

aSS!SS<
aʑʑʑaaaa<<
11
What to do if …
ʑWater is running out. – Correctly attach/replace drainage hose.
– Tighten screw-fitting on the supply hose.
ʑWater not flowing in.
Detergent not washed in.
–Start/Pause not selected?
– Tap not open?
–Filter blocked? Clean the filter. aPage 10
– Supply hose kinked or jammed?
ʑWashing-machine door
cannot be opened.
– Safety function active. Stop programme? aPage 4
–Rinse Hold (without final spin) selected? aPage 3, 4
– Can be opened via emergency release only? aPage 6
ʑProgramme does not start. – Start/Pause not selected?
– Door closed?
ʑDetergent solution is not drained.
–Rinse Hold (without final spin) selected? aPage 3, 4
– Clean the drain pump. aPage 10
– Clean outlet pipe and/or drainage hose.
ʑWater not visible in the drum.
– Not a fault – water below the visible area.
ʑSpin result not satisfactory, washing wet/too damp:
– Not a fault – unbalanced load detection system has stopped the spin
cycle, washing unevenly distributed.
Distribute small and large items of washing in the drum.
–SReduced Ironing is selected? aPage 5
– Too low speed selected? aPage 5
ʑThe programme duration changes during the wash
cycle.
– Not a fault – the programme sequence is optimised for the particular
wash process. This may result in changes to the programme duration
in the display field.
ʑSpin cycle actuated several times.
– Not a fault – unbalanced load detection system adjusts imbalance.
ʑResidual water in the dispenser for care
product ~.
– Not a fault – effect of the care product not impaired.
– If required, clean insert. aPage 9
ʑOdour formation in the washing machine.
– Run Cottons 90 °C programme without washing.
Use standard detergent.
ʑFoam is coming out of the detergent drawer.
– Too much detergent used?
Mix 1 tablespoon of fabric softener with ½ litre of water and pour into
dispenser II (not for outdoor, sports and down-filled textiles!).
– Reduce detergent dosage for the next wash cycle.
ʑLoud noise formation, vibrations and “Wandering”
during spin cycle.
– Appliance feet fixed?
Secure appliance feet. aInstallation Instructions
– Transportation protection devices removed?
Remove transportation protection devices. aInstallation Instructions
ʑNoises during spin and drain cycles.
– Clean the drain pump. aPage 10
ʑIndicator lights do not function while the
appliance is running.
– Power failure?
– Fuse tripped? Switch on/replace fuse.
– If the fault occurs repeatedly, call customer service.
ʑThe programme takes longer than usual.
– Not a fault – unbalanced load detection system adjusts imbalance
by repeatedly distributing the washing.
– Not a fault – foam detection system active – a rinse cycle is
switched on.
ʑDetergent residue on the washing.
–Occasionally phosphate-free detergents contain water-insoluble
residue.
– Select Rinse/Freshen Up or brush the laundry after washing.
ʑIn the pause status Start/Pause flashes very
quickly and a signal
sounds.
– Water level too high. Washing cannot be reloaded.
Immediately close washing machine door.
– Select Start/Pause to continue the programme.
If a fault cannot be rectified (switching the machine on and off) or a repair is required:
– Set programme selector to Off and pull out the mains plug.
– Turn off the tap and call customer service. aInstallation Instructions
Washing machine
en Instruction manual
