Bosch Wis28441gb User manual

1 2 3 4 5 6

Select $Start/Pause

:c–90 °C Temp. (°C) Select the temperature (:= cold)

c–1400 * rpm ()cSelect the spin speed (* depending on model) or (rinse stop =

without final spin, the washing remains in the water after the last

rinse cycle).

1 – 24 h Ready in () Programme ends in ...

Status displays Programme progress displays:

1üüüücü-¯-Washing, Rinse, Spin, programme duration or end (-¯-)

Programme selectorDisplay panel/

Option buttons

Start/

Pause

Additional functions

Sorting and inserting the washing

Follow manufacturer’s care information!

According to the information on the care labels.

According to type; colour; soiling and temperature.

Do not exceed maximum load. aPage 7

Follow important instructions. aPage 6

Insert large and small items of washing!

Close the washing machine door.

Do not jam items of washing between the washing machine door and rubber seal.

Add detergent and care product

Dose according to:

amount of washing, soiling, water hardness (available from your water utility company) and

manufacturer’s instructions.

For models without insert for liquid detergent:

Pour liquid detergent into corresponding dispenser and place in drum.

Caution when opening the detergent drawer while the appliance is running!

Important information

Before using your washing machine for the first time

Do not put any washing in the washing machine! Turn the tap on. Pour into dispenser II:

–Approx. 1 litre water.

– Detergent (dosage according to manufacturer’s instructions for light soiling and according to degree of water

hardness).

– Set programme selector to IEasy-Care 60 °C and select $Start/Pause.

At the end of the programme set the programme selector to Off.

Protecting the washing and the machine

– When dosing all detergents, cleaning aids and cleaning agents, always follow the manufacturer's instructions.

– Empty pockets.

– Remove metal parts (paper clips, etc.).

– Wash delicates in the net/bag (tights, curtains, underwired bras).

– Close zips, button up covers.

– Brush sand out of pockets and collars.

– Remove curtain fittings or include in the net/bag.

Insert laundry

Insert large and small items of washing!

Do not jam items of washing between the washing machine door and rubber seal.

Washing with different degrees of soiling

Wash new items separately.

Light Do not prewash.

If required, pretreat stains. Select Eco+additional function.

Heavy Load less washing. Select programme with Prewash.

If required, pretreat stains. Select Eco+additional function.

Soaking Load washing of the same colour.

Pour soaking agent/detergent into dispenser II according to the manufacturer’s instructions. Set programme selector to

LcCottons 30 °C andselect $Start/Pause. After approx. 10 minutes select $Start/Pause to stop the programme.

After the required soaking time reselect $Start/Pause if the programme is to be continued or change the programme.

Starching Washing should not be treated with fabric softener.

Liquid starch can be used in all wash programmes. Pour starch into the fabric softener dispenser ~according

to manufacturer’s specifications (if required clean beforehand).

Dyeing/Bleaching

Dye in household quantities only. Salt may attack stainless steel! Observe specifications of the dye manufacturer!

Do not bleach washing in the washing machine!

Emergency release e.g. if power failure occurs

The programme continues running when the power supply is restored.

If the washing is still to be removed, the door can be opened as described below:

Risk of scalding!

Detergent solution and washing may be hot. If required, leave to cool down.

Do not reach into the drum in case it is still rotating.

Do not open the door if you can still see water through the glass.

1. Set programme selector to Off, pull out the mains plug.

2. Removing base strip asee separate installation instructions.

3. Drain the water. aPage 10

4. Pull down emergency release with a tool and release.

Door can then be opened.

5. Attaching base strip asee separate installation instructions.

Insert for liquid detergent (depending on model) aPage 9

Dispenser II: Detergent for main wash,

water softener, bleach, stain remover

Your washing machine Intended use

Contents Page

ʔIntended use ...........................................................................................................................1

ʔProgrammes........................................................................................................................... 1

ʔSelecting and adjusting a programme............................................................................. 3

ʔWashing...............................................................................................................................3/4

ʔAfter washing ......................................................................................................................... 4

ʔIndividual settings.................................................................................................................. 5

ʋImportant information ..........................................................................................................6

ʔEmergency lock release ......................................................................................................6

ʔOverview of programmes ....................................................................................................7

ʔSafety instructions................................................................................................................. 8

ʔConsumption values .............................................................................................................8

ʔInsert for liquid detergent.................................................................................................... 9

ʔCare .......................................................................................................................................... 9

ʔInformation on the display panel .......................................................................................9

ʔInformation on blockage................................................................................................... 10

ʔWhat to do if …..................................................................................................................... 11

Protection of the environment/Conservation tips

– Utilise the maximum amount of washing for the particular programme.

– Wash normally soiled washing without prewash.

Comparable cleaning result with significantly lower energy consumption.

– The selectable temperatures apply to the care labels on the textiles. The

temperatures in the machine may deviate from this so that you get the optimum mix

of energy-saving and washing results.

– Measure detergent according to the manufacturer’s instructions and water

hardness.

– If the washing is then dried in the tumble dryer, select spin speed according to the

instructions of the dryer manufacturer.

Preparation Before using your washing machine for the first time

wash once without any washing. aPage 6

Setting programmes 1

Washing

Dispenser ~:Fabric softener, starch

Dispenser I: Detergent for prewash

ʔfor use in the household only,

ʔfor washing machine-washable textiles and hand-washable wool in

wash liquor,

ʔto be operated with cold drinking water and commercially available

detergents and care products which are suitable for use in washing

machines.

– Do not leave children unattended near the washing machine!

– Children and uninstructed persons must not use the washing

machine!

– Keep pets away from the washing machine!

– Switch on washing machine only with base strip attached

Dilute viscous fabric softener and fabric conditioner with water.

Prevents blockage of the overflow.

Detergent drawers

with dispensers I, II, ~Fascia

Door handle

Emergency lock release

Door

Correct installation according to separate

installation instructions.

Checking the machine

– Never switch on a damaged machine!

– Inform your customer service!

Insert mains plug

– With dry hands only!

– Take hold of the plug only!

Turn on the tap

Additional functions and option buttons

aIndividual settings, Page 5

Washing

End of programme when ...

... -¯-is indicated on the display panel.

Terminating the programme

For programmes at high temperature:

–Cool washing: select 2Rinse.

–Select $Start/Pause.

For programmes at low temperature:

–Select Spin or >Drain.

–Select $Start/Pause.

Change programme if ...

... you have mistakenly selected a wrong programme:

– Reselect programme.

– Select $Start/Pause.

The new programme starts from the beginning.

Cancel Programme

–Select $Start/Pause.

– If required, top up washing (do not leave door open for a long time –

water from the washing could run out of the open door).

– Select $Start/Pause.

Individual settings

ʑOption buttons

You can change the spin speed and temperature beforehand and while the selected programme is running.

Effects dependent on the programme progress.

ʑTemp.°C

You can change the indicated washing temperature. The maximum washing temperature which can be selected

depends on the set programme.

ʑ(rpm=Spin speed, revolutions per minute)/(Rinse stop = without final

spin)

You can change the indicated spin speed or select (rinse stop = without final spin cycle, washing remains in the

water after the last rinse cycle).

The selectable maximum spin speed depends on the model and the selected programme.

ʑReady in

The respective programme duration is displayed by selecting the programme. The programme start can be delayed

before the programme begins. The (Ready in) time can be set in hour steps up to maximum 24h.

Keep pressing the (Ready in) button until the required number of hours is indicated (h=hour). Select $Start/

Pause. Settings cannot be made when the programme has started.

ʑAdditional functions aOverview of programmes, Page 7

Eco+Energy-optimised washing by reducing the temperature while achieving a consistent

washing result.

The washing temperature is lower than the selected temperature. For special hygiene

requirements, the āAllergy+ programme is recommended.

Prewash 7For heavily soiled washing. Prewash at 30 °C.

Reduced Ironing SSpecial spin sequence with subsequent fluffing. Gentle final spin at reduced spin speed.

Residual moisture of the washing slightly increased.

Aqua Plus =Increased water level. Additional rinse cycle. Longer programme duration.

For areas with very soft water or for further improvement of the rinsing result.

ʑ$Start/Pause

For starting or interrupting the programme.

ʑSignal

2. Set volume for ...

set to Â1 step to right select and

hold +1 step to right

set to Âdirect

... Button signals ... Information

set volume * 1 step to right set volume *

* If required,

select repeatedly

1. Activatesetting mode

for signal volume

release

If the Option buttons are touched for

longer, the selected options will run

automatically!

Programmes

For detailled overview of programmes aPage 7.

Temperature and spin speed can be selected individually irrespective of the

selected programme and programme progress.

LcCottons hard-wearing textiles

Cottons hard-wearing textiles

IEasy-Care for easy-care textiles

/Mixed Load differenttypes of washing

Delicates/Silk for easy-care, washable textiles

OWool :hand/machinewashable textiles

2Rinse with subsequent spin cycle

Spin extra spin with variable spin speed

>Drain the rinsing water when is activated

(rinse stop = without final spin)

Gentle Spin washing washed by hand;

gentler spin cycle

@Super Quick extra short programme

?cPower Wash hard-wearing textiles

ā÷Allergy+ Hard-wearing fabrics;

longer washing and rinsing at a higher water level

for particularly sensitive skin

ZSportswear textiles made of microfibres

cDark Wash dark textiles

Switching off

Turn the programme selector to Off.

Turn off tap

Not required for Aqua-Stop models.

aInformation, Installation Instructions

Remove the washing

Open washing machine door and remove washing.

If (rinse stop = without final spin) active: Set programme selector

to >Drain or Spin. Select $Start/Pause.

– Remove any foreign objects – risk of rusting.

– Leave detergent drawer and door open so that residual

water can evaporate.

Congratulations – You have opted for a modern, high-quality domestic appliance

manufactured by Bosch. The washing machine is distinguished by its economical

consumption of water and energy.

Each appliance which leaves our factory is inspected thoroughly to ensure that

it functions properly and is in perfect condition.

Further information on our products, accessories, spare parts and services can be found

at: www.bosch-home.com or contact our customer service centres.

Programme selector for switching

the machine on and off and for

selecting the programme.

Can be rotated in either direction.

Detergent-solution pump

Drainage hose

www.devicemanuals.eu/

Overview of programmes aObserve table of consumption values on Page 8 and instructions on Page 6!

The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load or select additional function, e.g. Eco+.

When washing at maximum load using programmes marked with *, always select Eco+additional function. Irrespective of the type of washing, IEasy-Care 40 °C at max.

selectable spin speed is best suited as a short programme.Programmes without Prewash – pour detergent into dispenser II, programmes with Prewash – divide detergent between

dispensers I and II.

Programmes °C max. Type of washing Additonal functions; information

LcCottons :– 90 °C

7 kg * Hard-wearing textiles, heat-resistant textiles made

of cotton or linen Eco+,7cPrewash,SReduced Ironing,Aqua Plus =Cottons :– 60 °C

ā÷Allergy+ :– 60 °C Eco+,7cPrewash,SReduced Ironing,Aqua Plus =Especially suitable for increased hygienic demands or particularly sensitive skin

on account of prolonged washing at a defined temperature, with a higher water

level and longer rinsing cycle

?cPower Wash :–60 °C 5 kg Hardwearing textiles made of cotton or blended fabrics Time-controlled programme, short programme for normally soiled washing

IEasy-Care :– 60 °C

3.5 kg *

Easy-care textiles made of cotton, linen, synthetic fibres or

blended fabrics Eco+,7cPrewash,SReduced Ironing,Aqua Plus =/Mixed Load :– 40 °C Textiles made of cotton or easy-care textiles Eco+,7cPrewash,SReduced Ironing,Aqua Plus =Different types of washing can be washed together

cDark Wash :–40 °C Dark textiles made of cotton and dark easy-care textiles Eco+,7cPrewash,SReduced Ironing,Aqua Plus =Reduced rinse and final spin cycle

Delicates/Silk :– 40 °C

2 kg

For delicate, washable textiles, e.g. made of silk, satin,

synthetic fibres or blended fabrics Eco+,7cPrewash,SReduced Ironing,Aqua Plus =No spin cycle between the rinse cycles

ZSportswear :– 40 °C Textiles for outdoor wear Eco+,7cPrewash,SReduced Ironing,Aqua Plus =OWool ::– 40 °C Hand or machine-washable wool or rich-wool textiles Especially gentle wash programme to prevent shrinkage, longer programme

pauses (textiles rest in wash liquor)

@Super Quick :– 40 °C Easy-care textiles made of cotton, linen, synthetic fibres or

blended fabrics

Short programme approx. 15 minutes,

suitable for lightly soiled washing

Additional

programmes 2Rinse,Spin,>Drain

9401 / 9000958471

*958471* WIS28441GB

Robert Bosch Hausgeräte GmbH

Carl-Wery-Str. 34

81739 München/Deutschland

Safety instructions

– Read and follow the operating and installation instructions and all other information enclosed with the washing

machine.

– Retain documents for subsequent use.

Risk of electric shock – Never pull out the mains plug by tugging the power cord!

– Insert/pull out the mains plug with dry hands only.

Danger to life On redundant appliances:

– Pull out the mains plug!

– Sever the power cord and discard together with the plug.

– Destroy the lock on the washing-machine door. This will prevent children from

locking themselves in and suffocating.

Risk of suffocation – Keep packaging, plastic film and packaging parts out of the reach of children.

Risk of poisioning – Keep detergents and care products out of the reach of children.

Risk of explosion – Caused by detergents containing solvents, e.g. stain remover/items of washing

pretreated with solvent naphtha may result in an explosion after being loaded into

the washing machine.

Before hand thoroughly rinse items of washing by hand.

Risk of injury – Washing machine door may become very hot.

– Caution when draining hot detergent solution.

– Do not climb on the washing machine.

– Do not lean on the open washing machine door.

– Do not reach into the drum in case it is still rotating.

Consumption values

Programme Additonal

function Load Current** Water** Programme

duration**

LcCottons 20 °C -7 kg 0,21 kWh 77 l 1@h

LcCottons 40 °C* Eco+7 kg 0,78 kWh 77 l 2@h

LcCottons 60 °C -7 kg 1,30 kWh 77 l 1Bh

LcCottons 90 °C -7 kg 2,26 kWh 90 l 2 h

IEasy-Care 40 °C* Eco+3,5 kg 0,58 kWh 57 l 1@h

Delicates/Silk 30 °C -2 kg 0,17 kWh 30 l Bh

OWool :30 °C -2 kg 0,20 kWh 40 l Bh

*Programme setting for test according to currently valid European standard 60456.

Information about comparability tests:

To test the test programmes, wash indicated load, with Eco+additional function and at maximum selectable spin

speed.

Programme Additonal

function Load Annual energy

consumption

Annual water

consumption

Cottons ~Eco+** 7/3.5 kg 220 kWh 11000 l

** Programme setting for testing and energy labelling according to directive 2010/30/EU with cold water (15 °C).

***The values may deviate from the stated values depending on water pressure and hardness, room temperature, type and

amount of laundry, detergents used, fluctuations in the mains voltage and selected additional functions.

Insert for liquid detergent depending on model

Position insert for dosing liquid detergent:

–Completely remove detergent drawer. aPage 10

– Push insert forwards.

Do not use insert (push upwards):

– For gel-like detergents and washing powders,

–For programmes with 7cPrewash or (Ready in) option.

Care

ʑMachine housing, control panel

– Remove detergent residue immediately.

– Wipe with a soft, damp cloth.

– Do not clean the appliance with a water jet.

Clean the detergent drawer ...

... if it contains detergent or fabric softener residue.

1. Pull out, depress insert, take out drawer all the way.

2. Take out insert: using your finger, press insert upwards.

3. Clean detergent dispenser and insert with water and a brush and dry.

4. Attach insert and lock into position (push cylinder onto guide pin).

5. Slide in the detergent dispenser.

Leave detergent drawer open so that residual water can evaporate.

ʑDrum

Leave washing machine door open so that the drum can dry out.

Use chlorine-free cleaning agent, not steel wool.

ʑDescaling No washing in the machine!

Not required if detergent dosed correctly. However, if this does occur, follow the instructions of the descaling agent

manufacturer. Suitable descalers can be purchased on our website or from customer service.

Information on the display panel depending on model

¨:³±Close the washing machine door properly; washing may be caught.

¨:³Å,ÉTurn on tap fully, supply hose kinked/jammed; clean filter aPage 10, water pressure too low.

¨:³µDrain pump blocked; clean drain pump. aPage 10

Drainage hose/outlet pipe blocked; clean drainage hose on the siphon. aPage 10

¨:´Water in the base pan, appliance leaking. Call customer service!

¨:,´,Motor fault. Call customer service. aInstallation Instructions

Other displays Switch off appliance, wait 5 seconds and switch on again. If the display is indicated again,

call customer service. aInstallation Instructions

–Risk of electric shock! Pull out the mains plug!

–Risk of explosion! No solvents!

Maintenance

Detergent-solution pump

Set programme selector to Off , pull out the mains plug.

1. Take the drainage hose out of the holder.

Remove sealing cap, allow detergent solution to flow out.

Put the closing cap back on the hose.

2. Carefully unscrew the pump cover (residual water).

3. Clean the interior, pump cover thread and pump housing

(fan impeller in the detergent-solution pump must rotate).

4. Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

To prevent unused detergent from flowing into the outlet during the next wash:

Pour 1 litre of water into dispenser II and start the >Drain programme.

Drainage hose on the siphon

Set programme selector to Off, pull out the mains plug.

1. Loosen hose clip, carefully remove drainage hose (residual water).

2. Clean drainage hose and siphon spigot.

3. Re-attach drainage hose and secure connection point with hose clip.

Filter in the water inlet hose

Risk of electric shock!

Do not immerse Aqua-Stop safety device in water (contains electric valve).

Release water pressure in the supply hose:

1. Turn off the tap!

2. Select any programme (except Spin/>Drain).

3. Select $Start/Pause. Leave programme for approx. 40 seconds.

4. Turn the programme selector to Off. Pull out the mains plug.

Clean the filter:

5. Disconnect the hose from the water tap.

Clean filter with small brush.

and/or for standard and Aqua-Secure models:

remove hose from the rear of the appliance,

take out filter with pliers and clean.

6. Connect the hose and check for leaks.

Risk of scalding!

– Allow detergent solution to cool down!

– Turn off the tap!

What to do if …

ʑWater is running out. – Correctly attach/replace drainage hose.

– Tighten screw-fitting on the supply hose.

ʑWater not flowing in.

Detergent not washed in.

–$Start/Pause not selected?

– Tap not open?

– Filter blocked? Clean the filter. aPage 10

– Supply hose kinked or jammed?

ʑWashing-machine door cannot

be opened.

–Safety function active. Stop programme? aPage 4

–(rinse stop = without final spin) selected? aPage 3, 4

–Can be opened via emergency release only? aPage 6

ʑProgramme does not start. –$Start/Pause or (Ready in) time selected?

– Door closed?

ʑDetergent solution is not drained. –(rinse stop = without final spin) selected? aPage 3, 4

–Clean the drain pump. aPage 10

– Clean outlet pipe and/or drainage hose.

ʑWater not visible in the drum. – Not a fault – water below the visible area.

ʑSpin result not satisfactory,

washing wet/too damp.

– Not a fault – unbalanced load detection system has stopped the spin cycle,

washing unevenly distributed.

Distribute small and large items of washing in the drum.

–SReduced Ironing selected? aPage 5

–Too low speed selected? aPage 5

ʑThe programme duration

changes during the wash cycle.

– Not a fault – the programme sequence is optimised for the particular wash process.

This may result in changes to the programme duration in the display field.

ʑSpin cycle actuated several

times.

– Not a fault – unbalanced load detection system adjusts imbalance.

ʑResidual water in the dispenser

for care product ~.

– Not a fault – effect of the care product not impaired.

–If required, clean insert. aPage 9

ʑOdour formation in the washing

machine.

–Run LcCottons 90 °C programme without washing. Use standard detergent.

ʑFoam is coming out of the

detergent drawer.

–Too much detergent used?

Mix 1 tablespoon of fabric softener with ½ litre of water and pour into dispenser II

(not for outdoor, sports and down-filled textiles!).

– Reduce detergent dosage for the next wash cycle.

ʑLoud noise formation, vibrations

and “Wandering” during spin

cycle.

–Appliance feet fixed? Secure appliance feet. aInstallation Instructions

–Transportation protection devices removed?

Remove transportation protection devices. aInstallation Instructions

ʑNoises during spin and drain

cycles.

–Clean the drain pump. aPage 10

ʑDisplay panel/indicator lights do

not function while the appliance

is running.

– Power failure?

– Fuse tripped? Switch on/replace fuse.

– If the fault occurs repeatedly, call customer service.

ʑThe programme takes longer

than usual.

– Not a fault – unbalanced load detection system adjusts imbalance by repeatedly

distributing the washing.

– Not a fault – foam detection system active – a rinse cycle is switched on.

ʑDetergent residue on the

washing.

– Occasionally phosphate-free detergents contain water-insoluble residue.

– Select 2Rinse or brush the laundry after washing.

ʑIn the pause status

$Start/Pause flashes very

quickly and a signal sounds.

– Water level too high. Washing cannot be reloaded.

Immediately close washing machine door.

– Select $Start/Pause to continue the programme.

If a fault cannot be rectified (switching the machine on and off) or a repair is required:

–Set programme selector to Off and pull out the mains plug.

–Turn off the tap and call customer service. aInstallation Instructions

en operating instructions

Washing machine

WIS28441GB

Observe the safety instructions on page 8

Read these instructions and the separate installation instructions before

operating the washing machine

www.devicemanuals.eu/

is does occur, follow the instructions of the descaling agent

www.devicemanuals.eu/

is does occur, follow the instructions of the descaling agent

manufacturer. Suitable descalers can be purchased on our website or from customer service.

www.devicemanuals.eu/

manufacturer. Suitable descalers can be purchased on our website or from customer service.

www.devicemanuals.eu/

Information on the display panel

www.devicemanuals.eu/

Information on the display panel

depending on model

www.devicemanuals.eu/

depending on model

www.devicemanuals.eu/

Close the washing machine door properly; washing may

www.devicemanuals.eu/

Close the washing machine door properly; washing may

be caught.

www.devicemanuals.eu/

be caught.

ilter

www.devicemanuals.eu/

ilter

www.devicemanuals.eu/

Page 10

www.devicemanuals.eu/

Page 10

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Drainage hose on the siphon

www.devicemanuals.eu/

Drainage hose on the siphon

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

1 2

:c–90 °C Temp. (°C)

Select the temperature (:

c–1400 * rpm ()c

Select the spin speed (* depending on model) or without final spin, the washing remains in the water afte

rinse cycle).

1 – 24 h Ready in (

) Programme ends in ...

Status displays Programme progress displays:

1üüüücü-¯-

Washing, Rinse, Spin, programme duration or end ( ¯Programme selector

Display panel/

Option buttons

Start/

Pause

Additional functions

aaI$Lc$$$~aaa

Insert for liquid detergent (depending on model) aPage 9

Dispenser II: Detergent for main wash,

water softener, bleach, stain remover

Your washing machine Intended use

Contents Page

ʔIntended use........................................................................................................................... 1

ʔProgrammes........................................................................................................................... 1

ʔSelecting and adjusting a programme ............................................................................. 3

ʔWashing...............................................................................................................................3/4

ʔAfter washing ......................................................................................................................... 4

ʔIndividual settings.................................................................................................................. 5

ʋImportant information .......................................................................................................... 6

ʔEmergency lock release ...................................................................................................... 6

ʔOverview of programmes .................................................................................................... 7

ʔSafety instructions................................................................................................................. 8

ʔConsumption values ............................................................................................................. 8

ʔInsert for liquid detergent.................................................................................................... 9

ʔCare .......................................................................................................................................... 9

ʔInformation on the display panel .......................................................................................9

ʔInformation on blockage................................................................................................... 10

ʔWhat to do if …..................................................................................................................... 11

Protection of the environment/Conservation tips

– Utilise the maximum amount of washing for the particular programme.

– Wash normally soiled washing without prewash.

Comparable cleaning result with significantly lower energy consumption.

– The selectable temperatures apply to the care labels on the textiles. The

temperatures in the machine may deviate from this so that you get the optimum mix

of energy-saving and washing results.

– Measure detergent according to the manufacturer’s instructions and water

hardness.

– If the washing is then dried in the tumble dryer, select spin speed according to the

instructions of the dryer manufacturer.

Preparation

Dispenser ~:Fabric softener, starch

Dispenser I: Detergent for prewash

ʔfor use in the household only,

ʔfor washing machine-washable textiles and hand-washable wool in

wash liquor,

ʔto be operated with cold drinking water and commercially available

detergents and care products which are suitable for use in washing

machines.

– Do not leave children unattended near the washing machine!

– Children and uninstructed persons must not use the washing

machine!

– Keep pets away from the washing machine!

– Switch on washing machine only with base strip attached

Correct installation according to separate

installation instructions.

Checking the machine

– Never switch on a damaged machine!

– Inform your customer service!

Insert mains plug

– With dry hands only!

– Take hold of the plug only!

Turn on the tap

a¯2$>$$$$ʑʑʑʑ$ʑaā7S=ʑ$ʑÂÂ

Programmes

For detailled overview of programmes aPage 7.

Temperature and spin speed can be selected individually irrespective of the

selected programme and programme progress.

LcCottons hard-wearing textiles

Cottons hard-wearing textiles

IEasy-Care for easy-care textiles

/Mixed Load different types of washing

Delicates/Silk for easy-care, washable textiles

OWool :hand/machinewashable textiles

2Rinse with subsequent spin cycle

Spin extra spin with variable spin speed

>Drain the rinsing water when is activated

(rinse stop = without final spin)

Gentle Spin washing washed by hand;

gentler spin cycle

@Super Quick extra short programme

?cPower Wash hard-wearing textiles

ā÷Allergy+ Hard-wearing fabrics;

longer washing and rinsing at a higher water level

for particularly sensitive skin

ZSportswear textiles made of microfibres

cDark Wash dark textiles

a>$

Congratulations – You have opted for a modern, high-quality domestic appliance

manufactured by Bosch. The washing machine is distinguished by its economical

consumption of water and energy.

Each appliance which leaves our factory is inspected thoroughly to ensure that

it functions properly and is in perfect condition.

Further information on our products, accessories, spare parts and services can be found

at: www.bosch-home.com or contact our customer service centres.

www.devicemanuals.eu/

www.devicemanuals.eu/www.devicemanuals.eu/

www.devicemanuals.eu/

Temperature and spin speed can be selected individually irrespective of the

www.devicemanuals.eu/

Temperature and spin speed can be selected individually irrespective of the

www.devicemanuals.eu/

hard-wearing textiles

www.devicemanuals.eu/

hard-wearing textiles

www.devicemanuals.eu/

hard-wearing textiles

www.devicemanuals.eu/

hard-wearing textiles

www.devicemanuals.eu/

for easy-care textiles

www.devicemanuals.eu/

for easy-care textiles

www.devicemanuals.eu/

different types of washing

www.devicemanuals.eu/

different types of washing

www.devicemanuals.eu/

for easy-care, washable textiles

www.devicemanuals.eu/

for easy-care, washable textiles

www.devicemanuals.eu/

hand/machinewashable textiles

www.devicemanuals.eu/

hand/machinewashable textiles

www.devicemanuals.eu/

with subsequent spin cycle

www.devicemanuals.eu/

with subsequent spin cycle

www.devicemanuals.eu/

extra spin with variable spin speed

www.devicemanuals.eu/

extra spin with variable spin speed

www.devicemanuals.eu/

Drain

www.devicemanuals.eu/

Drain

www.devicemanuals.eu/



www.devicemanuals.eu/



Gentle Spin

www.devicemanuals.eu/

Gentle Spin

www.devicemanuals.eu/

Super Quick

www.devicemanuals.eu/

Super Quick

www.devicemanuals.eu/

Power Wash

www.devicemanuals.eu/

Power Wash

www.devicemanuals.eu/

ā÷

www.devicemanuals.eu/

ā÷

www.devicemanuals.eu/

3 4

Select $Start/Pause

:cSelect the temperature (

:= cold)

ccSelect the spin speed (* depending on model) or

(rinse stop =

without final spin, the washing remains in the water after the last

rinse cycle).

) Programme ends in ...

Status displays Programme progress displays:

1üüüücü¯Washing, Rinse, Spin, programme duration or end (

-¯-)

Programme selector

Sorting and inserting the washing

Follow manufacturer’s care information!

According to the information on the care labels.

According to type; colour; soiling and temperature.

Do not exceed maximum load. aPage 7

Follow important instructions. aPage 6

Insert large and small items of washing!

Close the washing machine door.

Do not jam items of washing between the washing machine door and rubber seal.

Add detergent and care product

Dose according to:

amount of washing, soiling, water hardness (available from your water utility company) and

manufacturer’s instructions.

For models without insert for liquid detergent:

Pour liquid detergent into corresponding dispenser and place in drum.

Caution when opening the detergent drawer while the appliance is running!

I$Lc$$$~aaa

aʔʔʔʔʔʔʋʔʔʔʔʔʔʔʔʔ

Before using your washing machine for the first time

wash once without any washing. aPage 6

Setting programmes 1

Washing

~ʔʔʔ

Dilute viscous fabric softener and fabric conditioner with water.

Prevents blockage of the overflow.

Detergent drawers

with dispensers I, II, ~Fascia

Door handle

Emergency lock release

Door

Additional functions and option buttons

aIndividual settings, Page 5

Washing

End of programme when ...

... -¯-is indicated on the display panel.

Terminating the programme

For programmes at high temperature:

–Cool washing: select 2Rinse.

–Select $Start/Pause.

For programmes at low temperature:

–Select Spin or >Drain.

–Select $Start/Pause.

Change programme if ...

... you have mistakenly selected a wrong programme:

– Reselect programme.

– Select $Start/Pause.

The new programme starts from the beginning.

Cancel Programme

–Select $Start/Pause.

– If required, top up washing (do not leave door open for a long time –

water from the washing could run out of the open door).

– Select $Start/Pause.

ʑʑʑʑ$ʑaā7S=ʑ$ʑÂÂ

If the Option buttons are touched for

longer, the selected options will run

automatically!

aLcI/O:2>@?cā÷Zc

Switching off

Turn the programme selector to Off.

Turn off tap

Not required for Aqua-Stop models.

aInformation, Installation Instructions

Remove the washing

Open washing machine door and remove washing.

If (rinse stop = without final spin) active: Set programme selector

to >Drain or Spin. Select $Start/Pause.

– Remove any foreign objects – risk of rusting.

– Leave detergent drawer and door open so that residual

water can evaporate.

Programme selector for switching

the machine on and off and for

selecting the programme.

Can be rotated in either direction.

Detergent-solution pump

Drainage hose

www.devicemanuals.eu/

5 6

$:c:cc1üüüücü¯¯aa

Important information

Before using your washing machine for the first time

Do not put any washing in the washing machine! Turn the tap on. Pour into dispenser II:

–Approx. 1 litre water.

– Detergent (dosage according to manufacturer’s instructions for light soiling and according to degree of water

hardness).

– Set programme selector to IEasy-Care 60 °C and select $Start/Pause.

At the end of the programme set the programme selector to Off.

Protecting the washing and the machine

– When dosing all detergents, cleaning aids and cleaning agents, always follow the manufacturer's instructions.

– Empty pockets.

– Remove metal parts (paper clips, etc.).

– Wash delicates in the net/bag (tights, curtains, underwired bras).

– Close zips, button up covers.

– Brush sand out of pockets and collars.

– Remove curtain fittings or include in the net/bag.

Insert laundry

Insert large and small items of washing!

Do not jam items of washing between the washing machine door and rubber seal.

Washing with different degrees of soiling

Wash new items separately.

Light Do not prewash.

If required, pretreat stains. Select Eco+additional function.

Heavy Load less washing. Select programme with Prewash.

If required, pretreat stains. Select Eco+additional function.

Soaking Load washing of the same colour.

Pour soaking agent/detergent into dispenser II according to the manufacturer’s instructions. Set programme selector to

LcCottons 30 °C and select $Start/Pause. After approx. 10 minutes select $Start/Pause to stop the programme.

After the required soaking time reselect $Start/Pause if the programme is to be continued or change the programme.

Starching Washing should not be treated with fabric softener.

Liquid starch can be used in all wash programmes. Pour starch into the fabric softener dispenser ~according

to manufacturer’s specifications (if required clean beforehand).

Dyeing/Bleaching

Dye in household quantities only. Salt may attack stainless steel! Observe specifications of the dye manufacturer!

Do not bleach washing in the washing machine!

Emergency release e.g. if power failure occurs

The programme continues running when the power supply is restored.

If the washing is still to be removed, the door can be opened as described below:

Risk of scalding!

Detergent solution and washing may be hot. If required, leave to cool down.

Do not reach into the drum in case it is still rotating.

Do not open the door if you can still see water through the glass.

1. Set programme selector to Off, pull out the mains plug.

2. Removing base strip asee separate installation instructions.

3. Drain the water. aPage 10

4. Pull down emergency release with a tool and release.

Door can then be opened.

5. Attaching base strip asee separate installation instructions.

aʔʔʔʔʔʔʋʔʔʔʔʔʔʔʔʔa~ʔʔʔ~a¯2$>$$$$

Individual settings

ʑOption buttons

You can change the spin speed and temperature beforehand and while the selected programme is running.

Effects dependent on the programme progress.

ʑTemp.°C

You can change the indicated washing temperature. The maximum washing temperature which can be selected

depends on the set programme.

ʑ(rpm=Spin speed, revolutions per minute)/(Rinse stop = without final

spin)

You can change the indicated spin speed or select (rinse stop = without final spin cycle, washing remains in the

water after the last rinse cycle).

The selectable maximum spin speed depends on the model and the selected programme.

ʑReady in

The respective programme duration is displayed by selecting the programme. The programme start can be delayed

before the programme begins. The (Ready in) time can be set in hour steps up to maximum 24h.

Keep pressing the (Ready in) button until the required number of hours is indicated (h=hour). Select $Start/

Pause. Settings cannot be made when the programme has started.

ʑAdditional functions aOverview of programmes, Page 7

Eco+Energy-optimised washing by reducing the temperature while achieving a consistent

washing result.

The washing temperature is lower than the selected temperature. For special hygiene

requirements, the āAllergy+ programme is recommended.

Prewash 7For heavily soiled washing. Prewash at 30 °C.

Reduced Ironing SSpecial spin sequence with subsequent fluffing. Gentle final spin at reduced spin speed.

Residual moisture of the washing slightly increased.

Aqua Plus =Increased water level. Additional rinse cycle. Longer programme duration.

For areas with very soft water or for further improvement of the rinsing result.

ʑ$Start/Pause

For starting or interrupting the programme.

ʑSignal

2. Set volume for ...

set to Â1 step to right select and

hold +1 step to right

set to Âdirect

... Button signals ... Information

set volume * 1 step to right set volume *

* If required,

select repeatedly

1. Activate setting mode

for signal volume

release

aLcI/O:2>@?cā÷Zc a>$

www.devicemanuals.eu/

– Remove metal parts (paper clips, etc.).

www.devicemanuals.eu/

– Remove metal parts (paper clips, etc.).

www.devicemanuals.eu/

– Remove metal parts (paper clips, etc.).

www.devicemanuals.eu/

– Remove metal parts (paper clips, etc.).

www.devicemanuals.eu/

– Remove metal parts (paper clips, etc.).

www.devicemanuals.eu/

– Remove metal parts (paper clips, etc.).

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

www.devicemanuals.eu/

– Wash delicates in the net/bag (tights, curtains, underwired bras).

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

www.devicemanuals.eu/

– Close zips, button up covers.

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

www.devicemanuals.eu/

– Brush sand out of pockets and collars.

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

– Remove curtain fittings or include in the net/bag.

www.devicemanuals.eu/

Insert laundry

www.devicemanuals.eu/

Insert laundry

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

www.devicemanuals.eu/

Insert large and small items of washing!

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

o not jam items of washing between the washing machine door and rubber seal.

www.devicemanuals.eu/

Washing with different degrees of soiling

www.devicemanuals.eu/

Washing with different degrees of soiling

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Light

www.devicemanuals.eu/

Special spin sequence with subsequent fluffing. Gentle final spin at reduced spin speed.

www.devicemanuals.eu/

Special spin sequence with subsequent fluffing. Gentle final spin at reduced spin speed.

For areas with very soft water or for further improvement of the rinsing result.

www.devicemanuals.eu/

For areas with very soft water or for further improvement of the rinsing result.

www.devicemanuals.eu/

and

www.devicemanuals.eu/

and

www.devicemanuals.eu/

1 step to right

www.devicemanuals.eu/

1 step to right

Overview of programmes aObserve table of consumption values on Page 8 and instructions on Page 6!

The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load or select additional function, e.g. Eco+.

When washing at maximum load using programmes marked with *, always select Eco+additional function. Irrespective of the type of washing, IEasy-Care 40 °C at max.

selectable spin speed is best suited as a short programme.Programmes without Prewash – pour detergent into dispenser II, programmes with Prewash – divide detergent between

dispensers I and II.

Programmes °C max. Type of washing Additonal functions; information

LcCottons :– 90 °C

7 kg * Hard-wearing textiles, heat-resistant textiles made

of cotton or linen Eco+,7cPrewash,SReduced Ironing,Aqua Plus =Cottons :– 60 °C

ā÷Allergy+ :– 60 °C Eco+,7cPrewash,SReduced Ironing,Aqua Plus =Especially suitable for increased hygienic demands or particularly sensitive skin

on account of prolonged washing at a defined temperature, with a higher water

level and longer rinsing cycle

?cPower Wash :– 60 °C 5 kg Hardwearing textiles made of cotton or blended fabrics Time-controlled programme, short programme for normally soiled washing

IEasy-Care :– 60 °C

3.5 kg *

Easy-care textiles made of cotton, linen, synthetic fibres or

cDark Wash :– 40 °C Dark textiles made of cotton and dark easy-care textiles Eco+,7cPrewash,SReduced Ironing,Aqua Plus =Reduced rinse and final spin cycle

Delicates/Silk :– 40 °C

2 kg

For delicate, washable textiles, e.g. made of silk, satin,

synthetic fibres or blended fabrics Eco+,7cPrewash,SReduced Ironing,Aqua Plus =No spin cycle between the rinse cycles

pauses (textiles rest in wash liquor)

@Super Quick :– 40 °C Easy-care textiles made of cotton, linen, synthetic fibres or

blended fabrics

Short programme approx. 15 minutes,

suitable for lightly soiled washing

Additional

programmes 2Rinse,Spin,>Drain

9401 / 9000958471

*958471* WIS28441GB

Robert Bosch Hausgeräte GmbH

Carl-Wery-Str. 34

81739 München/Deutschland

Safety instructions

– Read and follow the operating and installation instructions and all other information enclosed with the washing

machine.

– Retain documents for subsequent use.

Risk of electric shock – Never pull out the mains plug by tugging the power cord!

– Insert/pull out the mains plug with dry hands only.

Danger to life On redundant appliances:

– Pull out the mains plug!

– Sever the power cord and discard together with the plug.

– Destroy the lock on the washing-machine door. This will prevent children from

locking themselves in and suffocating.

Risk of suffocation – Keep packaging, plastic film and packaging parts out of the reach of children.

Risk of poisioning – Keep detergents and care products out of the reach of children.

Risk of explosion – Caused by detergents containing solvents, e.g. stain remover/items of washing

pretreated with solvent naphtha may result in an explosion after being loaded into

the washing machine.

Before hand thoroughly rinse items of washing by hand.

Risk of injury – Washing machine door may become very hot.

– Caution when draining hot detergent solution.

– Do not climb on the washing machine.

– Do not lean on the open washing machine door.

– Do not reach into the drum in case it is still rotating.

Consumption values

Programme Additonal

function Load Current** Water** Programme

duration**

LcCottons 20 °C -7 kg 0,21 kWh 77 l 1@h

LcCottons 40 °C* Eco+7 kg 0,78 kWh 77 l 2@h

LcCottons 60 °C -7 kg 1,30 kWh 77 l 1Bh

LcCottons 90 °C -7 kg 2,26 kWh 90 l 2 h

IEasy-Care 40 °C* Eco+3,5 kg 0,58 kWh 57 l 1@h

Delicates/Silk 30 °C -2 kg 0,17 kWh 30 l Bh

OWool :30 °C -2 kg 0,20 kWh 40 l Bh

*Programme setting for test according to currently valid European standard 60456.

Information about comparability tests:

To test the test programmes, wash indicated load, with Eco+additional function and at maximum selectable spin

speed.

Programme Additonal

function Load Annual energy

consumption

Annual water

consumption

Cottons ~Eco+** 7/3.5 kg 220 kWh 11000 l

** Programme setting for testing and energy labelling according to directive 2010/30/EU with cold water (15 °C).

***The values may deviate from the stated values depending on water pressure and hardness, room temperature, type and

amount of laundry, detergents used, fluctuations in the mains voltage and selected additional functions.

a7cʑʑʑ¨³±¨³ÅÉa¨³µaa¨´¨´aa

www.devicemanuals.eu/

The programmes are time-controlled for lightly soiled te

www.devicemanuals.eu/

The programmes are time-controlled for lightly soiled te

xtiles. If textiles are heavily soiled, reduce the load or select additional function, e.g.

www.devicemanuals.eu/

xtiles. If textiles are heavily soiled, reduce the load or select additional function, e.g.

When washing at maximum load using programmes marked

www.devicemanuals.eu/

When washing at maximum load using programmes marked

with *, always select

www.devicemanuals.eu/

with *, always select

Programmes without Prewash – pour detergent into dispense

www.devicemanuals.eu/

Programmes without Prewash – pour detergent into dispense

– 40 °C Hand or machine-washable wool or rich-wool textiles

www.devicemanuals.eu/

– 40 °C Hand or machine-washable wool or rich-wool textiles

Easy-care textiles made of cotton, linen, synthetic fibres or

www.devicemanuals.eu/

Easy-care textiles made of cotton, linen, synthetic fibres or

blended fabrics

www.devicemanuals.eu/

blended fabrics

www.devicemanuals.eu/

9401 / 9000958471

www.devicemanuals.eu/

9401 / 9000958471

*958471*

www.devicemanuals.eu/

*958471*

www.devicemanuals.eu/

– Keep detergents and care products out of the reach of children.

www.devicemanuals.eu/

– Keep detergents and care products out of the reach of children.

www.devicemanuals.eu/

– Keep detergents and care products out of the reach of children.

www.devicemanuals.eu/

– Keep detergents and care products out of the reach of children.

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

www.devicemanuals.eu/

Risk of explosion

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Risk of injury

www.devicemanuals.eu/

Consumption values

www.devicemanuals.eu/

Consumption values

Insert for liquid detergent depending on model

Position insert for dosing liquid detergent:

–Completely remove detergent drawer. aPage 10

– Push insert forwards.

Do not use insert (push upwards):

– For gel-like detergents and washing powders,

–For programmes with 7cPrewash or (Ready in) option.

Care

ʑMachine housing, control panel

– Remove detergent residue immediately.

– Wipe with a soft, damp cloth.

– Do not clean the appliance with a water jet.

Clean the detergent drawer ...

... if it contains detergent or fabric softener residue.

1. Pull out, depress insert, take out drawer all the way.

2. Take out insert: using your finger, press insert upwards.

3. Clean detergent dispenser and insert with water and a brush and dry.

4. Attach insert and lock into position (push cylinder onto guide pin).

5. Slide in the detergent dispenser.

Leave detergent drawer open so that residual water can evaporate.

ʑDrum

Leave washing machine door open so that the drum can dry out.

Use chlorine-free cleaning agent, not steel wool.

ʑDescaling No washing in the machine!

Not required if detergent dosed correctly. However, if this does occur, follow the instructions of the descaling agent

manufacturer. Suitable descalers can be purchased on our website or from customer service.

Information on the display panel depending on model

¨:³±Close the washing machine door properly; washing may be caught.

¨:³Å,ÉTurn on tap fully, supply hose kinked/jammed; clean filter aPage 10, water pressure too low.

¨:³µDrain pump blocked; clean drain pump. aPage 10

Drainage hose/outlet pipe blocked; clean drainage hose on the siphon. aPage 10

¨:´Water in the base pan, appliance leaking. Call customer service!

¨:,´,Motor fault. Call customer service. aInstallation Instructions

Other displays Switch off appliance, wait 5 seconds and switch on again. If the display is indicated again,

call customer service. aInstallation Instructions

–Risk of electric shock! Pull out the mains plug!

–Risk of explosion! No solvents!

Maintenance

Detergent-solution pump

Set programme selector to Off , pull out the mains plug.

1. Take the drainage hose out of the holder.

Remove sealing cap, allow detergent solution to flow out.

Put the closing cap back on the hose.

2. Carefully unscrew the pump cover (residual water).

3. Clean the interior, pump cover thread and pump housing

(fan impeller in the detergent-solution pump must rotate).

4. Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

To prevent unused detergent from flowing into the outlet during the next wash:

Pour 1 litre of water into dispenser II and start the >Drain programme.

Drainage hose on the siphon

Set programme selector to Off, pull out the mains plug.

1. Loosen hose clip, carefully remove drainage hose (residual water).

2. Clean drainage hose and siphon spigot.

3. Re-attach drainage hose and secure connection point with hose clip.

Filter in the water inlet hose

Risk of electric shock!

Do not immerse Aqua-Stop safety device in water (contains electric valve).

Release water pressure in the supply hose:

1. Turn off the tap!

2. Select any programme (except Spin/>Drain).

3. Select $Start/Pause. Leave programme for approx. 40 seconds.

4. Turn the programme selector to Off. Pull out the mains plug.

Clean the filter:

5. Disconnect the hose from the water tap.

Clean filter with small brush.

and/or for standard and Aqua-Secure models:

remove hose from the rear of the appliance,

take out filter with pliers and clean.

6. Connect the hose and check for leaks.

Risk of scalding!

– Allow detergent solution to cool down!

– Turn off the tap!

ʑʑ$aʑaaaʑ$ʑaaʑʑSaaʑʑʑ~aʑLcʑʑaaʑaʑʑʑ2ʑ$$a

www.devicemanuals.eu/

is does occur, follow the instructions of the descaling agent

www.devicemanuals.eu/

is does occur, follow the instructions of the descaling agent

manufacturer. Suitable descalers can be purchased on our website or from customer service.

www.devicemanuals.eu/

manufacturer. Suitable descalers can be purchased on our website or from customer service.

www.devicemanuals.eu/

Information on the display panel

www.devicemanuals.eu/

Information on the display panel

depending on model

www.devicemanuals.eu/

depending on model

www.devicemanuals.eu/

Close the washing machine door properly; washing may

www.devicemanuals.eu/

Close the washing machine door properly; washing may

be caught.

www.devicemanuals.eu/

be caught.

ilter

www.devicemanuals.eu/

ilter

www.devicemanuals.eu/

Page 10

www.devicemanuals.eu/

Page 10

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

www.devicemanuals.eu/

Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

www.devicemanuals.eu/

To prevent unused detergent from flowing into the outlet during the next wash:

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Pour 1 litre of water into dispenser

www.devicemanuals.eu/

Drainage hose on the siphon

www.devicemanuals.eu/

Drainage hose on the siphon

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

Set programme selector to

www.devicemanuals.eu/

What to do if …

ʑWater is running out. – Correctly attach/replace drainage hose.

– Tighten screw-fitting on the supply hose.

ʑWater not flowing in.

Detergent not washed in.

–$Start/Pause not selected?

– Tap not open?

– Filter blocked? Clean the filter. aPage 10

– Supply hose kinked or jammed?

ʑWashing-machine door cannot

be opened.

–Safety function active. Stop programme? aPage 4

–(rinse stop = without final spin) selected? aPage 3, 4

–Can be opened via emergency release only? aPage 6

ʑProgramme does not start. –$Start/Pause or (Ready in) time selected?

– Door closed?

ʑDetergent solution is not drained. –(rinse stop = without final spin) selected? aPage 3, 4

–Clean the drain pump. aPage 10

– Clean outlet pipe and/or drainage hose.

ʑWater not visible in the drum. – Not a fault – water below the visible area.

ʑSpin result not satisfactory,

washing wet/too damp.

– Not a fault – unbalanced load detection system has stopped the spin cycle,

washing unevenly distributed.

Distribute small and large items of washing in the drum.

–SReduced Ironing selected? aPage 5

–Too low speed selected? aPage 5

ʑThe programme duration

changes during the wash cycle.

– Not a fault – the programme sequence is optimised for the particular wash process.

This may result in changes to the programme duration in the display field.

ʑSpin cycle actuated several

times.

– Not a fault – unbalanced load detection system adjusts imbalance.

ʑResidual water in the dispenser

for care product ~.

– Not a fault – effect of the care product not impaired.

–If required, clean insert. aPage 9

ʑOdour formation in the washing

machine.

–Run LcCottons 90 °C programme without washing. Use standard detergent.

ʑFoam is coming out of the

detergent drawer.

–Too much detergent used?

Mix 1 tablespoon of fabric softener with ½ litre of water and pour into dispenser II

(not for outdoor, sports and down-filled textiles!).

– Reduce detergent dosage for the next wash cycle.

ʑLoud noise formation, vibrations

and “Wandering” during spin

cycle.

–Appliance feet fixed? Secure appliance feet. aInstallation Instructions

–Transportation protection devices removed?

Remove transportation protection devices. aInstallation Instructions

ʑNoises during spin and drain

cycles.

–Clean the drain pump. aPage 10

ʑDisplay panel/indicator lights do

not function while the appliance

is running.

– Power failure?

– Fuse tripped? Switch on/replace fuse.

– If the fault occurs repeatedly, call customer service.

ʑThe programme takes longer

than usual.

– Not a fault – unbalanced load detection system adjusts imbalance by repeatedly

distributing the washing.

– Not a fault – foam detection system active – a rinse cycle is switched on.

ʑDetergent residue on the

washing.

– Occasionally phosphate-free detergents contain water-insoluble residue.

– Select 2Rinse or brush the laundry after washing.

ʑIn the pause status

$Start/Pause flashes very

quickly and a signal sounds.

– Water level too high. Washing cannot be reloaded.

Immediately close washing machine door.

– Select $Start/Pause to continue the programme.

If a fault cannot be rectified (switching the machine on and off) or a repair is required:

–Set programme selector to Off and pull out the mains plug.

–Turn off the tap and call customer service. aInstallation Instructions

en operating instructions

Washing machine

WIS28441GB

Observe the safety instructions on page 8

Read these instructions and the separate installation instructions before

operating the washing machine

www.devicemanuals.eu/

programme without washing. Use standard detergent.

www.devicemanuals.eu/

programme without washing. Use standard detergent.

www.devicemanuals.eu/

programme without washing. Use standard detergent.

Mix 1 tablespoon of fabric softener with ½ litre of water and pour into dispenser

www.devicemanuals.eu/

Mix 1 tablespoon of fabric softener with ½ litre of water and pour into dispenser

www.devicemanuals.eu/

Mix 1 tablespoon of fabric softener with ½ litre of water and pour into dispenser

Installation Instructions

www.devicemanuals.eu/

Installation Instructions

www.devicemanuals.eu/

Installation Instructions

– If the fault occurs repeatedly, call customer service.

www.devicemanuals.eu/

– If the fault occurs repeatedly, call customer service.

www.devicemanuals.eu/

Table of contents

Other Bosch Washer manuals

Bosch

Bosch WIW28301GB Operating and maintenance instructions

Bosch

Bosch WAW32560GB Specification sheet

Bosch

Bosch WAV28KH1BY User manual

Bosch

Bosch WAT series Specification sheet

Bosch

Bosch WAE24166GB User manual

Bosch

Bosch WGG256Z0ES User manual

Bosch

Bosch Axxis WFL 2090 Installation guide

Bosch

Bosch WGG244A9GB User manual

Bosch

Bosch WAJ280A7SN User manual

Bosch

Bosch WAN series Specification sheet

Bosch

Bosch WAN2427YES User manual

Bosch

Bosch WAX32KH2BY User manual

Bosch

Bosch WAX32GH1GB User manual

Bosch

Bosch WGG254ZESN User manual

Bosch

Bosch WAJ280A2SN User manual

Bosch

Bosch WAU24T09GR User manual

Bosch

Bosch WLF20180OE Specification sheet

Bosch

Bosch WAK20260IN Specification sheet

Bosch

Bosch WGA2540XGC User manual

Bosch

Bosch WAJ20170SA Series User manual

Bosch

Bosch WAJ20069IN User manual

Bosch

Bosch Electronic Operating instructions

Bosch

Bosch WAE24280MY Specification sheet

Bosch

Bosch WGG244ZPGR User manual

Popular Washer manuals by other brands

Whirlpool

Whirlpool CAE2795FQ Use and care guide

Living & Co

Living & Co MFC100-U1501B/C14E-AU(5) user manual

Midea

Midea KL13TLE4M owner's manual

LG WM5000HWA Basic operation

Amana

Amana Speed Queen AWM190W2 Service manual

Samsung

Samsung WF219AN Fast track troubleshooting

Maytag

Maytag SAV-4 HD Use & care guide

LG T8503TEDT1 owner's manual

Whirlpool

Whirlpool 3358968 installation instructions

Whirlpool

Whirlpool WTW5800SG0 parts list

HERKULES

HERKULES G200 owner's manual

Maytag

Maytag MAH6700A Series technical information

Tricity Bendix

Tricity Bendix CAW 811 Operating and installation instructions

Whirlpool

Whirlpool CAM2752TQ0 parts list

Panasonic

Panasonic NA-148VG4 Operating instructions & installation instructions

AEG

AEG LAVAMAT 50500 operating instructions

Whirlpool

Whirlpool GHW9400P Dimension Guide

Montgomery Ward

Montgomery Ward MW-50-1102PS instruction manual

Bosch WIS28441GB User manual

Popular Washer manuals by other brands
