Bossard BST-BC-2830 User manual

Operating instructions
Single charger BST-BC-2830(-USA)
NOTE
In case of doubt, the original German version of the operang instrucons applies.

- 2 -
1 Basic informaon
1.1 Purpose of this document 3
1.2 Intended use 3
1.2.1 Improper use 3
1.3 Warranty and liability 4
1.4 Structure of the warnings 4
1.5 Copyright 5
2 Basic safety informaon
2.1 Informaon contained in this document 6
2.2 Owner responsibilies 6
2.2.1 Personnel responsibilies 6
2.2.2 Personnel training 6
2.3 Electrical hazards 7
2.3.1 Basic safety measures (must always be observed!) 7
2.3.2 Observing the line voltage 9
2.4 Structural modicaons 9
2.5 Cleaning and disposal of the device 9
3 Start-up and use
3.1 Operaon 10
4 Technical data
4.1 Dimensions 11
4.2 Addional characteriscs 11
CE Declaraon of conformity
PAGE
3
PAGE
6
PAGE
10
PAGE
11
PAGE
12
Table of contents

- 3 -
1 Basic informaon
1.1 Purpose of this document
This information has been written with the intention of being read, understood and
adhered to in all aspects by those who bear responsibility for this battery charger.
The information contained in this document is important for avoiding workplace mishaps
and ensuring problem-free operation. If, despite this, problems are encountered, then
please contact us; we would be pleased to help you.
1.2 Intended use
The tool may only used to charge matching Bossard SmartTool batteries as specified in
this manual.
NOTICE
Intended use includes the following:
• Observing all information in the operating instructions and
• complying with the inspection and maintenance tasks.
The quick charger serves to recharge the following Bossard SmartTool batteries:
Arcle no. Arcle descripon
BST-LB-1825 Li-Ion baery 18 V / 2.5 Ah
BST-LB-1850 Li-Ion baery 18 V / 5.0 Ah
1.2.1 Improper use
We bear no liability for damage or operating problems resulting from noncompliance with
these operating instructions or improper use.

- 4 -
1.3 Warranty and liability
Warranty and liability claims for personal and property damage are excluded if they occur
as the result of one or more of the following:
• Unintended usage of the ossard SmartTool charger
• Improper installation, placement into service, operation and maintenance of the device
• Operation of the device in case of defective safety equipment or improperly mounted
or non-functional safety and protection equipment
• Failure to comply with the information contained in this document regarding transport,
storage, installation, placement into service, operation, and maintenance of the device
• Unauthorized structural modifications of the device
• Improperly performed repair work
• Catastrophic events beyond human control and acts of God
1.4 Structure of the warnings
The warnings are structured as follows:
DANGER
Indicates an immediate dangerous situaon that can lead to serious or even
deadly injuries and/or that could seriously damage or even destroy the tool.
WARNING
Indicates a potenally dangerous situaon that can lead to serious injuries
and/or damage to the tool.
NOTE
Important and useful informaon on using this tool.

- 5 -
1.5 Copyright
This document is intended only for the owner and personnel authorized to operate the
tool. It contains the relevant rules and information, which may not be
• duplicated
• distributed or
• otherwise shared, either in whole or in part
The copyright for these operating instructions remains with
HS-Technik GmbH / Bossard AG.
Address of the manufacturer: Address of the distributor:
Bossard AG
Steinhauserstrasse 70
CH-6301 Zug
Phone: [phone]
Fax: [phone]
E-Mail: [e-mail]
Internet: www.bossard.com
HS-Technik GmbH
Im Martelacker 12
D-79588 Efringen-Kirchen
Phone: [phone] - 91 11-0
Fax: [phone] - 91 11-90
E-Mail: [email protected]m
Internet: www.hs-technik.com

- 6 -
2 Basic safety informaon
2.1 Informaon contained in this document
A basic prerequisite for safety-compliant handling and problem-free operation is
knowledge of the basic safety information and safety regulations. Also be sure to observe
all local rules and regulations.
2.2 Owner responsibilies
The owner is obligated to only allow persons who are familiar with basic work safety
and accident prevention rules and who have been briefed on proper workplace handling
to work at this workplace. The safety-conscious work of personnel must be verified at
regular intervals.
2.2.1 Personnel responsibilies
All persons who are tasked with working at this workplace are obligated, before beginning
with work, to observe the basic regulations covering work safety and accident prevention.
2.2.2 Personnel training
Only personnel that have been trained and briefed in advance may work at this workplace.
Personnel responsibilities for installation, placement into service, operation, maintenance
and repair must be clearly defined.
Personnel still to be trained may only work at this workplace under the supervision of
someone who is trained and experienced.
WARNING
The device is designed using state-of-the-art technology and according to
recognized safety standards.
Nonetheless, operating the device can entail the risk of life-threatening injury
to the user, third parties or property.

- 7 -
WARNING
The workplace is only to be used
• for intended purposes
• if it is in proper and safe working condion.
2.3 Electrical hazards
DANGER
Only allow work to be carried out by electrical specialist. Regularly check the
electrical equipment. Rectify loose connections immediately.
2.3.1 Basic safety measures (must always be observed!)
a) Keep your work area in good condition. A disorderly work area can result in an
accident.
b) Take environmental factors into account. Do not expose the charger station to rain.
Do not use the charger station in a humid or wet environment. Ensure that there is
sufficient illumination. Do not use the charger station in the proximity of flammable
liquids or gases.
c ) Keep children away. Do not allow other persons to touch the device or cable; keep
them away from your work area.
d) Use the correct device. Do not use the charger station for purposes and work for
which it was not intended.
e) Do not misuse the cable. Do not pull the plug out of the power socket by the cable.
Protect the cable against heat, oil and sharp edges.
f) Maintain your device with care. Keep your charger station clean in order to work
better and more safely. Regularly inspect the cable and, in case of damage, have it
replaced by a qualified expert. Keep the device dry and free of oil and grease.
g) Pull out the main power plug, when not in use and before maintenance.

- 8 -
h) Inspect your device for damage. Before using the charger station, the protective
equipment or damaged parts must be tested to ensure problem-free functionality
according to their intended purpose. Check whether moving parts function properly
and determine whether or not they jam, whether any parts are broken, whether all
other parts are flawless, are correctly installed and whether all factors that could
influence operation of the device are OK. Damaged protection equipment, switches
and other parts should be properly repaired or replaced by a customer service center.
i) Protect yourself against electric shock. Avoid any body contact with grounded parts,
e.g. pipes, radiators, stoves, refrigerators.
j) Replacement parts. For repair and maintenance, only original replacement parts
obtained from the manufacturer may be used.
DANGER
Do not open baeries or the baery charger, and protect them against jolts,
heat and re. Do not toss used baeries in a re or dispose of them in regular
garbage.
k) Defective batteries. Do not use the battery charger with any defective batteries and
vice versa.
l) Symbols. Observe the symbols marked on the power rating plate of the battery
charger.
m) Dismantling. Do not disassemble either the battery or the battery charger.
WARNING
Protect the baery charger against metal objects, as there is a risk of short
circuing. The venlaon slits on the baery charger must also be protected
against metal and/or metal shavings.

- 9 -
2.3.2 Observing the line voltage
DANGER
Adhere to the correct line voltage. Using a higher voltage than is specied can
lead to serious injuries of the operator and cause damage to the device itself.
In case of doubt, do not connect the device and rst verify the line voltage.
2.4 Structural modicaons
No changes, extensions or modicaons may be carried out on the device without
the approval of the manufacturer. All modicaons require wrien conrmaon.
2.5 Cleaning and disposal of the device
Handle and dispose of the substances and materials ulized in a proper manner, espe-
cially when cleaning with solvents.

- 10 -
3 Start-up and use
NOTICE
Only use the charger station in dry rooms. All ventilation slits must be
unobstructed. Place the device as far away as possible from exposure to heat
and solar energy, as an ambient temperature of more than 35° C can lead to
substantially longer charging times.
NOTICE
Prior to connecting the device, the specifications on the type plate concerning
line voltage, frequency and current consumption must be observed. Once the
main power cable has been inserted in the power socket, the charger station
is operationally ready. Nothing else needs to be switched on.
3.1 Operaon
LED le Descripon
Shows, that the charger is connected to the power.
Charger defecve. Don´t charge other baeries on this charger because they could be dam-
aged or defecve aer charging. Change the charger or let it repair by a professional. Don´t
open the casing by yourself because you could get an electrical shock.
LED right Descripon
Baery is to hot or cold. Preferably charge the baery at room temperature.
Baery is damaged. Remove the baerie and give it to the repair staon or change it. A
baery may only be repaired by professionals. Please don´t open the casing by yourself
because you could get an electrical shock.
Baery is in charge.
Baery is charged (full).
WARNUNG
When charging two baeries consecuvely, it is recommended to allow the
charger to cool down between charges. There is no OEM concern with the
charger remaining plugged and a fully charged baery residing in the charger
following full charge levels. If the baery is fully charged on the charger, no
charging current ows; result, the charging process has stopped.

- 11 -
4 Technical data
Descripon BST-BC-2830 BST-BC-2830-USA
Connecon 220 - 240 V / 50 - 60 Hz 110 V / 50 - 60 Hz
Charging current 3 A
Output max. 28VDC
Charging me 25 - 80 min
Switch-o criteria ∆U, temperature termination
4.1 Dimensions
Descripon BST-BC-2830 and BST-BC-2830-USA
Size (W × H × D) 85.5 × 106.8 × 152.5 mm
Weight ca. 0.5 kg
4.2 Addional characteriscs
• Quick charger for 18 V Li-Ion baery pack
• Baery defect detecon
• Baery surge protecon
• Microprocessor-controlled charging
Charging me depending on the capacity of the baery
• Automac voltage detecon

CE Declaraon of conformity
We, the manufacturer, hereby declare that the named tool complies with the essenal
protecon requirements of the listed EU direcves regarding design and construcon type.
The prerequisite for this is the intended use of the tool as well as compliance with the
installaon and commissioning instrucons.
If the product or its accessories are modied without our consent, this declaraon be-
comes invalid.
Tool descripon: Quick charger for charging HS-Technik 18 V Li-Ion baeries
Type designaon: HST-PR-2830 & HST-PR-2830USA
BST-BC-2830 & BST-BC-2830-USA
Manufacturer: HS-Technik GmbH
Im Martelacker 12
D-79588 Efringen-Kirchen
Direcves: 2014/35/EU
2014/30/EU
2011/65/EG
Applied standards: EN 60335-2-29:2004+A2:2010
EN 60335-1:2012
EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 50581:2012
HS-Technik GmbH
Im Martelacker 12, D-79588 Efringen-Kirchen January 2020
Florian Hanke
CEO

- 13 -
Notes

- 14 -
Notes

- 15 -
Notes

03-2021
www.bossard.com
Technical data without guarantee. Design suggesons are non-binding. Subject to changes.
