Faithfull FPPAUBC4AMP User manual

IMPORTANT: Read this manual and safety guide and ensure
you fully understand its operations before using this battery
charger. Please retain this manual for future reference.
FPP AUBC4AMP
Instruction Manual
Battery Charger
12 Volt / 4 Amp / 48 Watt

PERSONAL PRECAUTIONS
IMPORTANT INSTRUCTIONS FOR YOUR SAFTEY
To help reduce the risk of injury, it is important you read and understand the operation
of this equipment and all the relevant safety precautions that must be observed along
with any warnings and instructions issued by the battery manufacturer.
BATTERY TYPES
This battery charger is designed specically for charging automotive lead-acid batteries only.
Not suitable for AGM or EFB batteries mainly used with start/stop technology.
Do not use this charger with dry-cell, NiCd, NiMH , Li-ion or Li-ion polymer batteries commonly
used in home appliances such as, radios, toys, torches etc. These batteries may burst and
cause injury to persons and damage to property.
LEAD ACID BATTERIES MAJOR RISKS
■Explosives Gases
Working with or in the vicinity of Lead-Acid batteries is a dangerous environment as batteries will
generate explosive Hydrogen gases when in normal operation or when being charged.
■Electric Shocks
Exposed terminals, even on disconnected batteries, present an electrical shock hazard.
Accidental shorting of terminals or cables can result in severe electrical arcing, causing burns,
electric shock and resulting in the ignition of explosive gases if present.
ALWAYS wear the correct Personal
Protective Equipment.
ALWAYS wear complete eye protection,
indirect vent goggles conforming to
EN166:1B (3,4,9).
ALWAYS wear rubber acid resistant
gloves.
ALWAYS remove rings, watches and
dangling jewellery when working with or
near batteries. Metal jewellery can act as
a conductor and cause a shock or burn if
in contact with the battery terminals.
ALWAYS stay away from a charging
battery when possible.
ALWAYS keep other people away from a
battery. If they are not wearing the correct
Personal Protective Equipment.
ALWAYS avoid direct contact with battery
acid, or surface corrosion on the battery
casing or its terminals.
ALWAYS have plenty of fresh water and
soap nearby in case battery acid comes
in to contact with your eyes, skin or
clothing. If battery acid contacts skin or
clothing, wash immediately with soap and
water.
EYE CONTACT If the electrolyte is
splashed into an eye, immediately force
the eye open and ood it with clean,
cool water for at least 15 minutes. SEEK
MEDICAL ATTENTION IMMEDIATLY.
ALWAYS use extreme caution if you are
handling electrolyte and keep an acid
neutralizing solution, such as baking soda
readily available.
2
Maintenance
All repairs should only be carried out by
qualied service personnel. Do not open
exterior casing of the Work Light, as there are
no user serviceable parts inside. Opening or
visible attempts to open or repair a Work Light
may void any guarantee and/or cause damage
to the product or personal injury.
Never attempt to open the
battery pack, under abusive conditions
liquid may be ejected from the battery,
if accidental contact occurs ush the
affected area with water. If the liquid
comes into contact with the eyes ush
with water and seek medical help.
Liquid ejected from batteries may
cause irritation or burns.
This product contains an internal Li-ion
battery pack formulated from
environmentally sensitive materials.
This product must be disposed of
properly with due care for the
environment. Please return this product
to your local dealer or to your local
recycling station where batteries will be
recycled or disposed of properly.
Never attempt to incinerate
batteries as they may leak or explode.

DO NOT put your face near to the battery
or position your face directly above the
battery when removing the ller caps.
DO NOT touch both battery terminals with
your bare hands at the same time.
DO NOT expose the charger to rain,
snow, water, gas, oil, etc.
DO NOT use the charger in damp or wet
conditions.
DO NOT operate the charger if it has
received a sharp blow, been dropped or
damaged in any way.
DO NOT operate the charger with a
damaged power cable or plug. These
should be replaced immediately.
DO NOT block the air holes at the top
or bottom of the charger or place the
charger on a vehicle seat.
DO NOT place a battery on top of the
charger.
DO NOT operate the charger with the
crocodile clips joined together (shorted).
DO NOT use this charger on board a
boat. Move the battery to dry land before
charging using this charger. Charging a
battery on board a boat oating in water
requires a charger specially designed to
marine charging standards.
DO NOT lay tools or other metal objects
on top of a battery.
DO NOT put ammable material on,
under or near the charger.
DO NOT use the charger near petroleum
or other spirits that can produce
ammable vapours.
DO NOT overll the battery, battery acid
expands during charge. After charging is
complete ll to the level specied by the
battery manufacturer.
DO NOT attempt to recharge sealed
maintenance free batteries that have a
battery condition indicator, a light or bright
coloured dot that indicates a low water
level. These types of batteries need to be
replaced and should not be recharged or
jump started.
DO NOT attempt to charge a frozen
battery, in very cold weather conditions a
discharged battery may freeze.
DO NOT overcharge batteries, non-
automatic (manual) battery charger
models can overcharge a battery if left
connected for an extended period of time,
resulting in loss of water and creation of
hydrogen gas.
ALWAYS follow the manufacturer’s
instructions when charging a battery
without removable caps (low maintenance
battery).
ALWAYS determine the battery voltage
by referring to the vehicle or equipment
owner’s manual and make sure it
matches the DC output voltage shown on
the charger nameplate.
ALWAYS ensure the polarity of the
charger and the battery match to avoid
damage to the battery and charger.
ALWAYS locate the power cable so that
it cannot be stepped on, present a trip
hazard or be subjected to damage or
stress.
ALWAYS keep the charger’s DC and AC
cables away from any exposed moving
parts of the vehicle including fan belts, fan
blade and alternator.
ALWAYS avoid the radiator cooling fan.
Automatic fans on some cars may start
up without the engine running. With no
prior warning.
OPERATING PRECAUTIONS
3

ALWAYS disconnect the charger before
starting the engine, this charger does not
have an engine starting feature.
ALWAYS use insulated/non-conducting
tools to remove cell caps or when
disconnecting a battery.
ALWAYS keep ames, matches, lighters,
cigarettes or other ignition sources away
from the battery.
ALWAYS make sure the chargers
crocodile clips make good contact with
the battery terminals, twist or rock them
back and forth several times to ensure a
good contact is achieved.
ALWAYS ensure the second crocodile
clip connection is made away from the
battery. See Operating Instructions
(Page 6 Step 3).
ALWAYS plug the charger into an
electrical outlet after all connections have
been made. See Operating Instructions
(Page 6 Step 1).
ALWAYS remove the ground terminal
(negative terminal connected to the cars
frame) from the battery rst. If the battery
is to be removed from the vehicle for
charging.
ALWAYS exercise caution when using
metal tools on or near a battery. A metal
tool touching both battery terminals
simultaneously or a positive terminal and
a metal car part will create a short circuit
that will spark, possibly causing a battery
explosion. Do not drop a metal tool on to
a battery.
ALWAYS add distilled water to each cell
until the battery acid covers the plates
before connecting the charger this helps
to purge excess gas from the battery.
ALWAYS ensure the area is well
ventilated before and during the charging
process. Never charge in an enclosed or
restricted area.
ALWAYS locate the charger as far away
from the battery as the DC cables permit.
ALWAYS follow other manufacturer’s
recommendations in conjunction with your
chargers instructions.
ALWAYS read all instructions and
caution markings on: (1) charger, (2)
battery, (3) any related product being
used in the charging process. Follow the
recommended rate of charge and any
other instructions provided.
4

ADDITIONAL INFORMATION
MODEL TYPES some chargers offer
a dual rate of charge which is marked
clearly on their front panel. Use the
high rate setting for normal charging
and the low rate for slow or overnight
charging of automobile batteries.
AC POWER FAILURE the battery
will not discharge back through the
charger if the AC power is turned off.
NEW DRY CHARGED BATTERIES
require a conditioning charge after
being lled with electrolyte. Follow
the battery manufacturer’s charging
instructions.
Incorrect use or tampering with this
product may result in a risk of electrical
shock or a re hazard. Which could result
in death, a serious injury, shock or burns.
DO NOT attempt to operate a battery
charger if it appears to be damaged in
any way.
DO NOT use the charger in damp or wet
conditions.
DO NOT expose the charger to rain,
snow, water, gas, oil, etc.
DO NOT modify any part of this charger
or its circuitry.
DO NOT use on 110 volt power supplies
this charger is for use on a nominal 240
volt circuit.
DO NOT use this charger to supply low-
voltage power for applications other than
battery charging. It is not intended or
designed for such use.
DO NOT use this charger with a fuse
of the incorrect rating the BS approved
plug should be tted with 3amp fuse for
charging applications.
ALWAYS disconnect the charger from the
wall socket by removing the plug, do not
pull on the power cord.
ALWAYS inspect the AC and DC cables
for any breaks or splits in their insulation
at regular intervals.
ELECTRICAL SAFETY
MAINTENANCE
■ALWAYS unplug the charger from
the mains outlet before attempting any
maintenance or cleaning.
■ALWAYS take this charger to a
qualied service engineer when a
repair or service is required. Incorrect
carried out repairs may result in a risk
of electric shock or re.
5
