BOSSCO Whipmix B-127 User manual
2
YEARS
WARRANTY
ON MOTOR
WATT
300
INSTRUCTION MANUAL
Please read all instructions carefully before using*
6MONTHS
EXTENDED
WARRANTY
ON REGISTRATION
B-127
Wh m
2
Being the inventors of Hand Blender in India in 1985, BOSS Hand Blender enable
the users to quickly blend larger quanty of ingredients. It is ergonomically
designed for a beer grip along with powerful motor, which consumes very less
power, to offer you the best of services. Make tasty shakes or whip cream or a
dip for any dish that you are planning to cook for your family with much ease.
Thank you for choosing BOSS Hand Blender, of which you are now the proud
owner.
Please read and follow all the instrucons given in this user manual carefully,
prior to using your BOSS Hand Blender, to get the best result and trouble free
operaon.
With Best Wishes,
Dear Customer,
3
Know Your Appliance
6. Eject Button
1. Speed Selector
3. Beater Sticks
4. Main Body
5. Turbo Button
2. Dough Hooks
Technical Specification :
HOUSEHOLD ELECTRIC KITCHEN MACHINES- SAFETY REQUIREMENTS; HAND-HELD BLENDER,
RATED INPUT POWER 100 WATTS UP TO AND INCLUDING 450 WATTS, RATED VOLTAGE 230 V,
CLASS OF APPLIANCE: CLASS II, INSULATION CLASS F, DEGREE OF PROTECTION IPX0.
Switch
Power Supply
Motor
Hand
Blender
M
Circuit Diagram for Hand Blender
1
6
5
4
2
3
USE
Blend
Mix
Stir
Knead
SPEED
Mixing Guide
Refer to the following Mixing Guide for speed selections.
FUNCTION
Medium
Low
High
Beat
Whip
To combine liquids, fold in dry ingredient and whipped cream
Mix dough
To prepare sauces, gravies, puddings
To prepare batters and mixtures
To cream butter and sugar and make mixtures and icing
To whip light and fluffy mixtures & cream
Important
3. Do not touch moving parts. Don't let rotang aachments touch the mains plug.
Please read the following instrucons carefully before using the Hand Mixer.
6. Do not use outdoors. Do not let cord hang over edge of table or counter, or touch hot surfaces.
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilies, or lack of experience and knowledge, unless they have been given supervision
or instrucon concerning use of the appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the appliance.
7. Do not place on or near a hot gas, electric burner, in a heated oven other inflammable materials (such
as benzene, paint thinner, sprays, etc.)
1. To protect the device against electrical shock, do not immerse cord, plugs or appliance in water or
other liquid.
9. Avoid contact from the moving parts. Keep hands, hair, clothing and other utensils away from beaters
during operaon to prevent injury and/or damage to the hand mixer.
5. The use of accessory aachments not recommended by the appliance manufacturer may cause
injuries.
8. Do not leave the appliance unaended when switched on. To disconnect, remove plug from wall
outlet.
4. Do not operate any appliance with a damaged cord or plug or aer the appliance malfuncons or has
been damaged in any manner. Return appliance to the nearest authorized service facility or call our
customer service number for informaon on examinaon, repair, or adjustment.
2. Unplug from outlet before cleaning or aaching or detaching beaters and dough hooks. Allow cooling
before pung on or taking off parts.
4
Convenient Features Of Your Hand Mixer
6 Variable Speeds with Turbo Eject Buon
Assembly & Usage :
5
3. Set the speed selector to your desired speed. There are 6 speed settings to be selected.
When kneading yeast dough, suggesting to select the speed selector by lower speed
and then by higher speed to achieve the best results. The mixer will run at the highest
speed when pressing turbo button.
1. Insert the stem of the beater or dough hook into one of the mounting holes in the motor
unit.
• NOTE: Beaters can be inserted in either socket, as the beaters are identical. For dough
hooks, the one with washer can only be inserted into the bigger socket and the other
one can only be inserted into smaller one. The two dough hooks cannot be inserted in
reverse.
4. The max operation time per time shall be less than 5 minutes. Minimum 20 minutes rest
time must be maintained between continuous two cycles.
5. When mixing is complete, turn the speed selector to “0” setting,
press eject button and unplug the cord from power outlet.
• Please don't let the unit come in contact with acid food.
Warning: Make sure that the Hand Mixer is switched off and unplugged.
• WARNING: Do not stick knife, metal spoons, fork and so on into bowl while operating.
2. Ensure that the unit is at the “0” setting. Push and turn the beater or dough hook until it
locks into place and then plug in the power source.
Hints for Optimum Result :
• When working with liquids, use a low speed in order to avoid splashing onto the
mixer and firmly hold the liquid container.
• During operation you may rotate the bowl with hand to achieve the best results.
• Do not over-beat. Be careful that you only mix/blend mixtures until recommended in
your recipe.
• Refrigerated ingredients, such as butter etc, should be brought at room temperature
before mixing begins.
• Temperature of ingredients and their texture variation, vary the required mixing time
and results.
• Use beaters for mixing, beating, whipping and creaming liquids and mixtures.
• Use dough hooks for mixing and kneading dough.
AUTHORISED SERVICE CENTRE
For Gujarat, Maharashtra & West Bengal : 9167681234
To Register Your Complaint, Simply Send Hi on Whatsapp
24 7
Hubli 0836-2284897 / 9845277503
Banglore 080 41249187 / 41138318
Delhi 011-23847057 / 9811206109
Gulbarga 9741734070 / 9480162059
Ajmer 0145-2421785/2423650
9982347880
Belgaum 9986224792
Bhilwara 01482-224586 / 9414112586
Bhopal 0755 - 4282097 Raipur 0771-2533284 / 9425510814
Rudrapur 9837049123
Sambalpur 0663-2400042 / 9338025787
Udaipur 0294-2422075
Indore 0731-2534689 / 4969975
Kota 0744 - 2390532 / 9460056594
Jaipur 0141-2622483
Jodhpur 0291-2435266 / 9414129574
Hyderabad 040-35841992 / 9347020195
Other Cies
Care & Maintenance of BOSS Hand Mixer
• Detach the beaters from the Hand Mixer and store them carefully. Do
not store the Hand Mixer in a location exposed to high
temperature/humidity or direct sunlight.
• Unplug electric cord from electrical outlet before cleaning.
• Wash the beaters and dough hooks in hot soapy water after each use.
Rinse thoroughly and dry.
• Wipe the Hand Mixer body clean with a dry cloth.
WARNING: Never immerse the mixer body or power cord into water for
cleaning.
