Boston Acoustics GTA-1005 User manual

Compact Chassis Design
Q-Tune™ Circuitry for Bass Up Front™
High- and Low-level inputs
IMS™ (Integral Mounting System)
SST™ (Symmetrical Signal Topology)
Adjustable Highpass/Lowpass Crossovers
Optional GTA-RSL Remote Gain

BOSTON GTA
HIGH PERFORMANCE MOBILE AMPLIFIERS
Setting a new standard in value for high performance amplification, Boston’s new GTA amplifiers capture the best design, performance
and features from our acclaimed line of GT Reference amplifiers. GTA amplifiers feature front-mounted controls and connections,
Q-Tune™ for optimum system tuning, dedicated speaker level inputs for simple integration, as well as our new IMS™ (Integral Mounting
System) which reduces the overall amplifier footprint. With six models ranging from 50-Watts x 2 all the way up to a mono 800-Watt
amplifier, GTA can drive any speaker, any system and any configuration. So, whether you are building a system for stealth or show,
with stunning looks, an aggressive feature set, and crisp clean power—GTA Amplifiers are the right choice.
PERFORMANCE
• High efficiency Class AB, Class D, and Hybrid amplifier designs
• Six different models including monoblocks, two-channel, four-channel and a
full-system five channel solution
• Boston’s Q-Tune™ circuitry for Bass Up Front™, fully adjustable on monoblock models
• SST™ (Symmetrical Signal Topology) system uses balanced asymmetrical inputs
for noise cancellation
• Fully adjustable and selectable Lowpass/Highpass crossovers on all models
• Wrap-around heatsink design for ample cooling in multiple mounting positions
INSTALLATION
• Compact chassis allows for placement flexibility
• Dedicated High- (speaker level) and Low- (RCA) level inputs
• Optimal angled speaker and power blocks for easy wire connections
• All input/output connections are located on one side of the amplifier to ease installation
and wire management
• IMS™ (Integral Mounting System) reduces the amplifier footprint
• Recessed control panel for clean installation and concealed wire management
• Optional GTA-RSL remote gain for controlling the subwoofer volume from the drivers seat
Boston Acoustics, Inc. 300 Jubilee Drive, Peabody, MA 01960
T: 978-538-5000 F: 978-538-5100 W: bostonacoustics.com
©2009 Boston Acoustics, Inc. Covered by patents issued and pending. All Rights Reserved. Bass Up Front, IMS, Q-Tune, and SST are trademarks and Boston,
Boston Acoustics, the B/A ellipse symbol, are registered trademarks of Boston Acoustics, Inc. All specifications are subject to change.
MODEL # OF CH. RATED POWER* LOWPASS HIGHPASS THD+N DIMENSIONS
GTA-502 2 50w x 2 @ 4 / 160w x 1 @ 4 50-200Hz 50-200Hz 0.05% 9⁄” x 2⁄” x 8 ⁄”
GTA-802 2 80w x 2 @ 4 / 260w x 1 @ 4 50-200Hz 50-200Hz 0.05% 11¾” x 2⁄” x 8⁄”
GTA-504 4 50w x 4 @ 4 / 160w x 2 @ 4 50-200Hz 50-200Hz 0.05% 14⁄” x 2⁄” x 8⁄”
GTA-400m 1 400w x 1 @ 2 50-150Hz 10-50Hz 0.05% 10⁄” x 2⁄” x 8⁄”
GTA-800m 1 800w x 1 @ 2 50-150Hz 10-50Hz 0.05% 12½” x 2⁄” x 8⁄”
GTA-1005 5 50w x 4 @ 4 / 160w x 2 @ 4 50-200Hz 50-200Hz 0.05% 21¼” x 2⁄” x 8⁄”
400w x 1 @ 2 50-150Hz 10-50Hz
*CEA-2006-A Specifications
