Brandt BCD510USB User manual

TCO
MARQUE: BRANDT
REFERENCE: BCD510USB
CODIC: 1372823

EN INSTRUCTION MANUAL
FR MANUEL D’UTILISATION
NL GEBRUIKSAANWIJZING
ES MANUAL DE INSTRUCCIONES
IT MANUALE DI ISTRUZIONI
CZ NÁVOD K OBSLUZE
SK NÁVOD NA OBSLUHU
TR KULLANMA KILAVUZU
Portable radio/cassette/CD player with MP3/USB
Radio/cassette/CD portable compatible MP3 avec port USB
Portable radio/cassette/CD speler met MP3 en USB aansluiting
Radio portátil/cassette/reproductor CD con MP3 y puerto USB
Radioregistratore portatile con riproduzione CD/cassette/MP3/USB
Přenosné rádio / kazeta / CD přehrávačs MP3 a USB vstupem
Prenosné rádio / kazeta / CD prehrávačs MP3 a USB vstupom
Taşinabilir radyo/caset çalar/USB girişli ve MP3’lü CD çalar
BCD510USB

Mains supply
This equipment is designed to operate from a 230-240 Volt,50Hz AC mains supply. Other power sources may damage it.
Check that the voltage marked on the rating plate located on the bottom of the unit states 230V, the manufacturer will
NOT accept responsibility for damage or injury caused by connecting to the wrong voltage.
Symbols This equipment is double insulated and an
earth connection is not required.
This mark is applied to show the equipment
conforms to European safety and
electro-magnetic compatibility standards.
Dangerous voltage constituting a risk of electric
shock is present inside this equipment.
There are important operating and
maintenance instructions in the literature
accompanying this equipment.
Battery handling and usage
BATTERY WARNING: Only adults should handle the batteries. Do not allow a child to use this product unless the
Battery Compartment Cover is securely attached to the Battery Compartment in accordance with all product usage
instructions.
Follow the battery manufacturer’s safety and usage instructions.
Keep the batteries away from children and pets.
Insert the batteries observing the polarity marking inside the battery compartment. Failure to properly align the battery
polarity can cause damage. The battery compartments are located on the bottom of the product.
If electrolyte from the batteries gets onto your hands or into your eyes, wash with running tap water and seek medical
advice.
To prevent the risk of electrolyte leakage or explosions, never recharge non-rechargeable batteries.
Do not dispose of batteries in a fire as this constitutes an explosion hazard.
To protect the environment, use local recycling facilities for battery disposal.
The battery type used in this product is eight C size batteries. These batteries are located internally and are readily
accessible.
Remove the battery cover on the bottom of the product to remove the batteries.
These batteries must be disposed of at your local recycling point.
Risk of damage if batteries are incorrectly replac
This appliance is intended for domestic household use only and should not be used for any other purpose or in any
other application, such as for non domestic use or in a commercial environment.
The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers,
table-cloths, curtains, etc.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases,
shall be placed on the apparatus.
Ventilation
Allow at least a 10 cm gap all around the product.
This apparatus is not suitable for use in a tropical climate.
ed. Replace only with the same or equivalent type.
WARNING:
The mains plug shall be the main disconnect device and shall remain operable at all times.
To save power: switch off mains power or pull out the mains power plug when you are not using the equipment.
Never let anyone push objects into holes and ventilation slots.
Do not attempt to repair this product yourself, always get a qualified service agent carry out adjustments or repairs.
Never dispose of batteries in a fire, danger of explosion.
Class 1 laser product
This product contains a low power laser device. Invisible laser radiation when open and interlocks defeated.
Avoid exposure to beam.
To prevent direct exposure to laser beam, do not open the enclosure. Invisible laser radiation when opening.
Never stare directly into the laser beam.
EN-1

Notes on Discs
Handling Discs
Do not touch the play side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never
stick paper or tape on the disc.
Storing Discs
After playing, store the disc in its case. Do not expose the disc to direct sunlight or source of heat and never leave it in a
parked car exposed to direct sunlight.
Cleaning Discs
Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc
with a clean cloth. Wipe the disc from the centre out.
Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray
intended for older vinyl records.
EN-2

OVERVIEW
Top and Front View Rear View
1. AUX IN socket
To connect an external device
2. VOLUME +/–
To adjust the volume level
3. FUNCTION selector
To select AUX/USB/CD,TAPE/OFF or RADIO
source
4. BASS
To turn the bass enhancement on/off
5. Cassette recorder buttons
: starts recording.
: starts playback.
/ : fast winds / rewinds the tape
: stops the tape; open the cassette
compartment
: interrupts recording or playback.
6. CD door
7. Handle
8. BAND selector
To select FM ST. or FM waveband.
9. TUNING control
10. Display
11.
12.
13. /
14.
15. / CD / USB
16. USB port
17. Battery compartment cover
18. AC INPUT ~
19. Telescopic Aerial
To adjust FM reception
EN-3
12345679
10
11 12 13 14 15
16
8
19 17 18

USING BATTERIES (not supplied)
The unit can be powered by the batteries alone.
1. Remove the battery compartment cover.
2. Insert eight C size batteries with the + and – marks correctly aligned.
3. Replace the battery compartment cover.
CONNECTING AC POWER
1. Connect the supplied power cord to the AC INPUT socket on the unit and to the wall socket.
2. To switch off the unit completely, discon
If the unit is idle for 15 minutes, it will automatically switch to Power Saving mode.
Press the PLAY/PAUSE button to resume.
nect the power cord from the wall socket.
CD/MP3 PLAYER
PLAYING A DISC
You can play commercially available audio CDs:
CD-Recordable (CD-R)
CD-Rewritable (CD-RW)
MP3 -CD
1. Set the power switchto the ON position.
2. Set the FUNCTION selector to the AUX/USB/CD mode.
3. Press on the top of the unit to open the CD compartment.
4. Place a CD with the printed side facing up.
5. Press again to close the CD compartment.
The player scans the CD and the total number of tracks shows on the display.
PLAYING MUSIC FILES FROM USB
1. Insert a USB memory into the USB port .
2. Set the FUNCTION selector to the AUX/USB/CD mode.
The player scans the USB device and the total number of tracks shows on the display.
3. In CD mode, press and hold / CD / USB to switch from CD to USB mode.
GENERAL OPRATION
1. Press / CD / USB. Play starts from the first track.
2. Adjust the desired volume by turning VOLUME control.
3. To pause, press / CD / USB. To resume, press it again.
4. To stop, press .
5. For mp3 files with folders,
- Press to skip forward by 10 tracks.
- Press and hold to show the current folder, the current folder name will flash on the display, and
then press repeatedly to select the desired folder.
EN-4

SELECTING A TRACK
During play, press / repeatedly until the desired track number appears in the display.
SEARCHING FOR A PASSAGE WITHIN A TRACK
1. During play, press and hold / .
yThe sound is muted whilst searching is in progress.
2. When you reach the passage you want, release the button and play continues.
NOTE: When search reaches the end of the last track, the CD stops.
SELECTING PLAY MODES
Repeat play
You can repeat a track, an MP3 album, a disc or a program.
yREPEAT: Repeat a track.
yREPEAT ALBUM: Repeat an album.
yREPEAT ALL: Repeat an entire CD/program.
During play, press repeatedly to select the repeat mode you want.
To stop repeat play, press repeatedly until the repeat icon is disappeared.
Shuffle play
You can play all tracks in random order.
During play, press repeatedly until the display shows "RANDOM".
To stop shuffle play, press the button again, the "RANDOM" icon is disappeared.
PROGRAM PLAY
You can programme up to 32 tracks to play in your desired order.
1. Press in stop mode.
y"P01" and "PROG" flashes on the display.
2. Press / to select the desired track.
3. Press to register the selected track.
4. Repeat step 2 and 3 to program all the desired tracks.
5. Press / CD / USB to play programmed tracks.
6. In stop mode, press / repeatedly to browse stored tracks.
7. To cancel the program play, press twice. "PROG" disappears on the display.
LISTENING TO RADIO
1. Set the FUNCTION selector to the RADIO mode.
2. Set the BAND Selector to the desired waveband: FM or FM ST. (STEREO).
3. Turn the TUNING control to tune in a radio station.
yIf the BAND selector is set to FM ST. and you have tuned in to an FM stereo station, the FM ST. indicator
light will illuminate.
4. Turn the VOLUME control to set the desired listening level.
5. To turn off the radio function, move the FUNCTION selector to any other position.
NOTE: To improve FM reception, extend, incline or turn the telescopic aerial for best reception.
EN-5

CASSETTE OPERATION
PLAYING A CASSETTE
1. Set the FUNCTION selector to the TAPE mode.
2. Press to open the cassette door.
3. Insert a recorded cassette and close the cassette door.
4. Press to start playback.
5. To interrupt playback, press . To resume playback, press again.
6. Press or to fast wind or rewind the tape.
7. To stop the tape, press .
yThe buttons are automatically released at the end of the tape except if PAUSE ( ) has been activated.
RECORDING
General information
yRecording is permissible in so far as copyright or other rights of third parties are not infringed.
yThis deck is not suitable for recording on CHROME (IEC II) or METAL (IEC IV) type cassettes. For recording, use
NORMAL type cassettes (IEC I) on which the tabs have not been broken.
yThe best recording level is set automatically. Altering the VOL and BASS controls will not affect the recording in
progress.
yAt the very beginning and end of the tape, no recording will take place during the 7 seconds, when the leader tape
passes the recorder heads.
yTo protect a tape from accidental erasure, have the tape in front of you and break out
the left tab. Recording on this side is no longer possible. To record over this side
again, cover the tabs with a piece of adhesive tape.
Recording from the radio
1. Tune in to the desired radio station (see ‘LISTENING TO RADIO’).
2. Press to open the cassette door.
3. Insert a suitable cassette into the cassette deck and close the cassette door.
4. Press to start recording.
5. To interrupt recording, press . To resume recording, press again.
6. To stop recording, press .
AUX IN
To play music from personal player,
1. Set the FUNCTION selector to the AUX/USB/CD mode.
2. Connect your audio player to AUX IN jack with a cable (not included).
3. Set the audio player to play. The sound from the player will be heard through the speakers of this unit.
4. Turn the VOLUME control of this unit as desired.
EN-6

MAINTENANCE
CARE OF THE CABINET
If the cabinet becomes dusty, wipe it with a soft dry dust cloth. Do not use any wax, polish sprays, or abrasive cleaners
on the cabinet.
CAUTION: Never allow any water or other liquids to get inside the unit while cleaning.
TAPE DECK MAINTENANCE
To ensure quality recording and playback of the tape deck, clean parts A, B and C as
shown, after approx. 50 hours of operation or on average once a month. Use a cotton
bud slightly moistened with alcohol or a special head cleaning fluid to clean the deck.
1. Open the cassette door by pressing .
2. Press and clean the rubber pressure roller C.
3. Press and clean the magnetic heads A and the capstan B.
4. After cleaning, press .
NOTE: Cleaning of the heads can also be done by playing a cleaning cassette through once.
SPECIFICATIONS
Power AC 230-240V~ 50Hz, 15W
Dimensions
FM frequency 230(W) x 231(H) x 161(L) mm 88-108 MHz
Weight 2.3 kg
EN-7

TROUBLESHOOTING
If you have any of the problems listed below please use this troubleshooting guide to try and solve them. A little time
spent in this way may save you to the inconvenience of returning your equipment.
PROBLEMS POSSIBLE CAUSE POSSIBLE SOLUTION
No sound/power Volume not adjusted;
Power cord not securely connected;
Batteries dead / incorrectly inserted.
yAdjust the VOLUME control.
yConnect the AC power cord properly.
yInsert (fresh) batteries correctly.
Display does not
function properly / No
reaction to operation of
any of the controls
Electrostatic discharge. Switch off and unplug the unit. Reconnect after a
few seconds.
Poor cassette sound
quality Dust and dirt on the heads, etc. Use of incompatible cassette types
(METAL or CHROME).
yClean deck parts etc. ( see ‘MAINTENANCE’).
yOnly use NORMAL (IECI) for recording.
Recording does not
work. Cassette tab(s) may be broken. Apply a piece of adhesive tape over the missing tab space.
No disc indication. No CD inserted.
CD badly scratched or dirty.
Laser lens steamed up.
CD-R is blank or the disc is not
finalised.
yInsert a CD, CD-R, MP3 or CD-RW.
yReplace / clean CD (see ‘MAINTENANCE’).
yWait until lens has cleared.
yUse a finalised CD-R.
CD/MP3 playback does
not work. CD/MP3 badly scratched / dirty. Laser lens steamed up.
yReplace / clean CD (see ‘MAINTENANCE’).
yWait until lens has adjusted to room
temperature.
The CD skips tracks. CD damaged or dirty.
Program is active.
yReplace or clean CD.
yQuit program mode.
We apologise for any inconvenience caused by minor inconsistencies in the instructions, which may occur as a result of
appliance improvement and development.
Kesa Electricals © UK: EC1N 6TE 17-01-2013
EN-8
