Brandt DFS1010W User manual

Reviewing the section on troubleshooting Tips
will help you to solve some common problems
by yourself .
Dear Customer,
Please carefully read thi s manual before using the
dish washer, it will help you use and maintain the
dishwasher properly.
Pass it on to any sub sequent owner of the appl iance.
This ma nual con tains sections on safety In stru ctions,
Operating Instru ctions, In stallatio n Instruc tions an d
Trou bleshoo ting Tips, etc.
The manufacture r, following a policy of con stant
dev elopment and updating of the product, may
make modifications without giving prior notice.
This user ma nual shall also be got from the
manufac turer or responsible vendor.
Keep this manual for future referenc e.
If you can not solv e the problems by yourself ,
please ask for the help of professional technicians.
1) Safety Instructions....................................1-4
2) Quick user guide..........................................5
3) Operating Instructions.................................6
4) Prior to first time use....................................7
5) Preparing and loading dishes.....................12
6) Starting a washing program.......................14
7) Maintenance and cleaning..........................16
8) Installation Instruction...............................18
9) Troubleshooting Tips.................................21
Loading the baskets according to En50242
Control Panel....................................................6
Dishwasher Features.........................................6
A.Water Softener...............................................7
B.Loading the Salt int o the Softener....................8
C.Filling t he Rinse Aid Dispenser........................8
D.Function of Detergent.....................................9
Recommendations for loading and unloading
the dishwasher.... ............................................12
Standard loading pattern..................................13
Wash Cycle Table............................................14
Turning on the Appliance..................................14
Changing the Program mid-cycle......................15
At the end of the Wash Cycle.............................15
Filter System...................................................16
Caring for the Dishwasher.................................17
Positioning the Appliance.................................18
About Power Connection..................................18
Water connection.............................................19
Start of dishwasher..........................................20
Before calling for service..................................21
Error codes ....................................................22
Technical information.......................................23

This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be done by children
without supervision.(For EN60335-1)
Packaging material could be dangerous for children!
This appliance is for indoor household use only.
To protect against the risk of electrical shock,
do not immerse the unit, cord or plug in water or
other liquid.
Please unplug before cleaning and performing
maintenance on the appliance.
Use a soft cloth moistened with mild soap, and then
use a dry cloth to wipe it again.
When using your dishwasher,
follow the precautions listed below:

This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the
risk of an electric shock by providing a path of least
resistance of electric current. This appliance is
equipped with an earthing conductor plug.
The plug must be plugged into an appropriate outlet
that is installed and earthed in accordance with all
local codes and ordinances.
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded.
Do not modify the plug provided with the appliance;
If it does not fit the outlet.
Have a proper outlet installed by a qualified electrician.
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;

2)Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points
down or placed in a horizontal position.
Check that the detergent powder is empty after
completion of the wash cycle.
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent.
For check the
manufacturer's recommendations.
Use only detergent and rinse agents recommended for
use in an automatic dishwasher.
The door should not be left open, since this could increase
the risk of tripping.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
During installation, the power supply must not be
excessively or dangerously bent or flattened.
Do not tamper with controls.
The maximum number of place settings to be washed
is 10.
The maximum permissible inlet water pressure is 1MPa.
The minimum permissible inlet water pressure is 0.04MPa.
facing
“ ”
unmarked plastic items not so marked,
Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
The appliance needs to be connected to the main water
valve using new hose sets. Old sets should not be reused.
3

4
This appliance's packaging materials are recyclable.
Dispose of the packaging into a suitable waste
collection container to recycle it.
It is prohibited to dispose of this appliance as
household waste.
Correct Disposal of this product: this symbol on the
product or in its packing indicates that this product
may not be treated as household waste. Instead,
it should be taken to the appropriate waste collection
point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative
consequences for the environment and human health,
which could otherwise be caused by the inappropriate
waste handling of this product.
For more detailed information about the recycling of
this product, please contact your local council your
household waste disposal service, or the shop where
you purchased the product.
For disposing of package and the appliance please
go to a recycling centre. Therefore cut off the power
supply cable and make the door closing device
unusable.
Cardboard packaging is manufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences
for the environment and human health, which could
otherwise be caused by inappropriate waste handling
of this product.
For more detailed information about recycling of this
product, please contact your local city office and your
household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately
for special treatment is necessary.

For detailed operating method read the co rresponding conte nt on the instruction manual.
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a program
Running the dishwasher
To lo ad the baske ts, ref er to t he sec tion en titled L oa ding th e D ish wash er Bas kets .“ ”
Switch on the appliance
Switch off the appliance
Turn off the water tap,
unload the baskets
Warning : w ait a few mi nutes (about 15 m inute s) before unlo ading the di shwas her to avoid
hand ling the dishes and utensils wh ile the y are s till hot and m ore s usceptible to break.
The dishes will al so dry bette r. First start u nload ing th e lowe r bask ed.
Changing the program
Add forgotten dishes in the
dishwasher.
If the appliance is switched
off during a wash cycle.
Open the do or care fully.
Hot st eam m ay esc ape
when the do or is op en ed!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the Start/Pause Button to stop washing , Then press programme button after 3 seconds,
the program will cancel.
3. Turn the selector to select a new program.
4. .Press the Start/Pause Button, the dishwasher will run after 10 seconds.
1.Press the Start/Pause Button to stop the washing.
2.Open the door a little .
3.After the spray arms stop working, you can open the door completely.
4.Add forgotten dishes.
5.Close the door
6.Press the Start/Pause Button, the dishwasher will run after 10 seconds.
Turn on the water tap and press the Start/Pause Button. The machine will start working
after about 10 seconds.
Close the door, press the program button until the selected program indicator lights up.
( See the section entitled Operation instruction )“ ”
Press the On/Off button to switch on the appliance, Open the door.
When the working cycle has finished, the buzzer of the dishwasher will sound 8 times, then stop.
Turn off the appliance using the On/Off Button.
Since the appliance is standing by, it will power off automaticly after 30 minutes without any operation.
With each wash cycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
Fill the detergent dispenser

before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
Back ViewFron t view
1
2
3
4
5
7
611
8
Lower basket
Salt co ntainer
Dispenser
Cup shelf
Spray a rms
Filter assembly
Inlet pipe connector
Drain pipeUpper basket
Cutlery rack
1
Inner pipe
5
6
7
8
9
10
11
3
2
4
9
10
1.On/Off Button: Turn on/off the power supply.
3.Delay Button : Press the button to add delay time.
2.Program Button : Pres s the button to select a
wash Program.
8.Display screen: Show the time
and the state(running state, delay time etc )
remaining
Rinse Aid in dica tor:
Indicates when the dispenser needs to be refilled.
Add salt indicator:
Indi cates when t he dispenser needs to be refilled.
Faucet indicator :
Shows that the faucet has not been opened.
Dela y time ,Remain time ,or e rror codes indicator:
4.Halflo adB utton:Pr ess the button to select half load
function,after having selected the wash program.
6.Start /Pause butto n: To start the selected
was hing program or to pau se the washi ng program
when the machine is working.
5. Extra Drying : Press the button to select Extra Drying
function,The response indicator wi ll blink.
7.Child lock button: Press 3 and 4 buttons simultaneo
usly to lock the appliance and to prevent
children from accidentally changing the
dishwasher cycle or starting the dishwasher.

The water softener must be set manually, using the water hardness dial.
The water softener is des igned to rem ove minerals and salts from the water, which woul d have
a detrimental or adverse effect on the operation of the app liance.
The more minerals there are, the harde r your water is
The softener sho uld be adjusted according to the hard ness of the water in your area. Your local Water Author ity
can advise you on the hardne ss of the water in your ar ea.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the hardness of
the water used. This is intended to op timise and customise the level o f salt consumption.
WATER SOFTENER
The hardness of the wa ter varies from place to plac e. If hard water is used in the dishwasher, deposits will
form on the dishes and utensils.
The appliance is equipped with a special softener that uses a salt container specifically des igned to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardness of your water supply.
If your model does not have any water softener, you may skip this section.
Clark: British degree
fH: French degree
dH: German degree
dH=1.25 Clarke=1.78 fH=0.178mmol/l
1
The manufactory setting: H3 (EN 50242)
Before using your dishwasher for the first time:
A. Set the water sof tener
B. Add 1.5Kg dishwasher salt and then full fill the salt con tainer with water
C. Fill the rinse aid dispenser
D. Fill in detergent
Please follow the steps below for adjustment in salt consumption.
1. Switch on the appliance;
2. Press th e S tart/ Pause b utto n for mo re th an 5 seconds to start the water
softener s ettin g mode (to be done within 60 se conds after the a ppliance is s witc hed on;
3. Press th e Start/ Pause button to select the proper setting dep ending o n the ha rdne ss
of you r lo cal water, the settings will change in t he fo llowing
se que nce : H1 ->H 2->H 3-> H4- >H5 ->H6;
4. To end the s etti ng mode , eit her press the O n/Off but ton o r wa it 5 seco nds .
dH mmol/l
0~90~5 0~0.94 H1 0
10-20 6-11 1.0-2 .0 H2 9
21- 3012-17 2.1-3 .0 H3 12
H4 20
fH
0~6
7-14
15- 21
Clarke
WATER H ARD NE SS
Selector Po si ti on Salt consumption
(gram/cycl e)
18-22 31-40 22-28 3.1-4.0
41- 6023-34 4.1-6 .0 H5 30
H6 60
29- 42
35-55 61-98 43-69 6.1-9.8

1. The salt container must only be refil led when the salt warning light in the control panel comes on.
Depending on how well the salt dissolves, the salt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the con trol panel (for some Models),you can estimate when to fill
the salt into the softener by the cycles that the dishwasher has run.
2. I f sal t ha s spilled , run a s oak or quick program to remove it.
Always use salt intended for dishwasher use.
The salt contain er is located beneath the lower basket and should be filled as explained
in the foll owing:
Warning!
Only use salt specif ically designe d for ! Every other type o fdishwashers use
salt not specifically desig ned fo r , especially table salt, wil ldishwasher use
damage the water softener. In case of damages caused by the use of unsuitable
salt the ma nufacturer does not give any wa rranty nor is liable for any damages caused.
Only fil l with salt just before starting one of the complete washing programs.
This will prevent any grains of salt or salty wate r, which ma y have been spilled,
remaining on the bottom of the machine for any period of time, which may cause
corrosion.
with water, It is normal for a small amount of water to
come out of the salt container.
Fill the salt container to its ma ximum limit
AAfter the low er basket has been removed, unscrew and remove the cap from the salt container.
BPlace the end of the funnel (supplied) into the hole and about 1.5kg of dishwasher salt.
poo r in
C
DAfter filling the container , screw back the cap tightly.
EThe salt warning light will stop being after the sa lt contain er has be en fi ll ed with sa lt .
FImm ediat ely after filling the salt into the salt container, a washing program should be started
program Other wise the filter system, pump or ot her important parts of the machine may be damaged
by salty water. This is out of warranty.
(We su ggest to use a short
).
The rinse aid is released during the final rinse to prevent w ater from forming droplets on your dishes, which can
leave spots and streaks. It also im proves drying by allowing water to roll off the dishes. Your dishwasher is
designed to use liquid rinse aids. The rinse aid dispenser is located inside,on the door and next to the deter gent dispenser.
To fill the dispenser, open the cap and pour the rinse aid into th e dispenser until the level indicator turns completely
black. The volume of the rinse aid container is about 110ml.
Rinse Aid Dispenser
Function of Rinse Aid
Warning!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances
(e.g. Dishwasher cleani ng agent, liq uid dete rgent). This woul d damage the appliance .
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, a sp ot and streak free drying.

To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Careful ly pou r i n the ri nse-aid into it s d isp enser, whils t avo id in g i t t o overfl ow.
Replace the cap by inserting it aligned with "open " arrow and turning it to the closed (right) arrow.
Adjusting Rinse Aid Dispenser
The rinse aid dispenser has six or four set tings. Always st art with the dispe nser
set on "4". If spot s and poor drying are a problem, incre ase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are no t drying properly o r show spots, adjust the dial t o the next
high er lever until your dishes are spot-free. The recom mended setting is "4".
(Factory value is "4".)
Increase the dose if there are drops of wate r o r lime spots on the di shes after washing.
Reduce it if there are sticky whitis h stains on your dish es o r a bluish film on glassware or
knife blad es.
1
2
3
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated b elow.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
When to Refill the Rinse Aid Dispenser
Un less the rins e-aid warning light o n th e control panel is on, yo u ca n always est ima te the amount from t he color
of the optical level indicator "C "located next to the cap. When t he r inse-aid con tain er is full , the ind icator
wi ll be fully dark. T he size of th e dark dot decre ases as the rinse-aid diminishes . You should nev er let
the rinse aid le vel be le ss than 1/4 full.
during the next wash. Don't forget to re place the cap before you close the dishwasher door.
Clean up any spilled rinse a id w ith an absor bent cloth to avoid excessive foaming
The chemical ingredients that c ompose the detergent are necessary to remove, crush and dispense all dirt out of
the dishwasher. Most of the commercial qua lity d etergents are suitabl e for this purpose.
" "
Proper Use of Detergent
Use only det ergent specifically made for . Keep your detergent fresh and dry.dishwasher use
Don't put powdered detergent into the dispenser u ntil you are r eady to wash dishes.
Warning!

Amount of Detergent to Use
Based on their chem ical com position, deterge nts can be split in two basic types:
Detergent tablets of diffe rent brands disso lve at different speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
prog rams. Therefore please use long programs wh en usin g detergent t ablets, to
ensure the complete rem oval of detergent residuals.
The dispenser must be re filled before the start of each wash cycle f ollowing the instructions
provided in t he w ash cycle table . Your dis hwasher uses less de tergent and rinse aid than
Conventiona l dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Alway s add the
detergent just be fore star ting the dish was her, otherwise it could get damp and w ill not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
co nventional, alkaline detergents w ith caustic components
low al kaline co ncentrated detergen ts with natural enzymes
Normally new pulver ised detergent is with out phosphate. T hus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better resu lts. Detergents without chlorine do only bleach a little. S tron g and coloured spots will not
be removed completely. In this case please choose a program with a higher temperature.
°
Detergents
There are 3 sorts of d etergents
1.With phosphate and with chlorine
2.With phosphate and without chlorine
3.Withou t phosphate and without chlorine
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: pr ess release button. T he lid will spring open.
De terge nt tabl et
De terge nt pow der
Push latch to open
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.

Fill the detergent dispenser with detergen t.
The mar king indicates the dosing levels , as
illustrate d on the righ t:
Place the main wa sh cycle detergent here.
Place the pre- was h cycle d etergen t here.
Plea se observe the manufact urers dosing and storage
Rec ommendations as stated on the detergent packagi ng.
Close the lid a nd press on it until it locks into place.
If the dishes are heavily soiled, place an additiona l
detergent do se in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phas e.
A
B
Filling the detergent dispenser A B
You information about the amount of detergent for th e single programme on page 14.
will find
Be aware that depending on the soiling of wate r, setting may be different.
Please observe the manufacturer's recommendations on the detergent packaging.

Cutlery with wooden, horn china or
mother-of-pearl handles
Plast ic items that are not heat resistant
Older cutlery with glued parts that are not
temperature resistant
Bonded cutlery ite ms or dishes
Pewt er or copper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types of glasses can become
dull after a large number of washes
Silver and aluminum parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are of limited suitability
Dishes and items of cutlery must not lie inside one another, or cover each oth er.
The upper basket is designed to ho ld m ore delicate and lighter dishware such as glas ses , coffee
and tea cups
Long bladed knives stored in an upright position are a potential haza rd!
Long and/or sharp items of cut lery such as carving knives must be positi oned
horizontally in the upper basket.
Please do not ove rload your dishwasher. T his is important for good results and for
reasonab le consumption of energy.
To avoid damage, gla sses should not touch one an other.
Load large a nd difficult t o clean items in the lower basket.
Load hollow items suc h as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep base.
Consider buying utensils which are identified as dishwasher-proof.
Use a mild detergent that i s described as 'kind to dishes'. If necessary, seek further
information from the detergent manufacturers.
For particular items, select a program w ith
To prevent damage, do not take gla ss and c utlery out of the dishwasher immediately
after the programme has ended.
the lowes t po ssible te mpe rature.
(For best performance of the dishwasher, follow the se loading guide lines.
Features and appearance of baske ts and cutlery ba skets may vary from your model.)
Scrape off any larg e amounts of leftover food. Soften remnants of burnt food in pans.
It is not necess ary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots /pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensils are placed in the way that the spray arms can rotate freely during washing.
Very sm all items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the uppe r basket into the lower basket, we recommend that you
empty the lower basket first, follow ed b y th e upper basket.

The upper basket is designed to hold m ore delicate
and lighter dishware such as glasses, coffee and
tea cups and saucers, as well as plates, small bowls
and shallow pans (as long as they are not too di rty).
Positi on the dishe s and cookware so that they w ill
not get moved by the spray of water.
Pots, serving bowls, etc, must alw ays be placed top down.
Deep pots should be slanted to allow water to flow out.
Please be reminded that:
The Botto m Basket features fo lding spikes so that larger or more pots and pans can be loaded.
Th e he ight of the u ppe r rac k ca n be eas ily adjus ted to
accommodate talle r dishes in either the upper and lowe r
ra ck. The height of the upper basket can be adjusted
by pl acing the wheels on d ifferent height of therails.
They do not nest together.
Silverware is placed with the male face up.
Long utensils in the middle.
For bett er s tack ing o f cu ps, t he s helv es c an b e
folded down as show in the p icture below.
WARNING!
Do not let any item extend through bottom.
Always load sharp utensils with the sharp
pointing down!
We suggest that you place large items and the most
difficult to clean i tems
pans, lids, servi ng dishe s an d b owls, as shown
in the figu re below. It is preferable to place serving
dishes and lids on the side of the racks in order to
avoid blocking the rotatio n of the top s pray arm.
in to t he lower basket: such as
pots,
The maximum diameter advis ed for plates in front o f
the detergen t dis penser is of 1 9 cm, this not to
hamper the open ing of it
For a top quality cleaning, place the silverware in the basket making sure that:
Cutlery should be placed in the cutlery rack separatelyfrom each other in the appropriate positions, and do
make sure the utensils do not nest together, this maycause bad performance.
For better stacking of pots and pans, the spikes can be
folded do wn as show in the picture .
below

*EN 50242 : This program is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 10 setti ng
Position Upper baske t: lowest position
Rinse aid setting: 6
PI:0.49W; P :0.45W.
o
Left-on m ode duration: Power will be cut off automatically after program finished for 30 minutes.
Means : Rinse-aid dispenser needs to be filled.
( )
Intensive
Normal
(* E N 50242)
Rapid
Glass
3/22g
3/22g
3/22g
20g
3/22g
25g
90 Min
Soa k
For normally soiled loads,
such as , plates,glasses
and lightly soiled pans.
pots
For heaviest soi led crockery,
and nor mally soiled pots
pans dishes etc wi th dried
on soiling.
、
、
For lightly soiled loads that
do not need excellent drying
efficiency.
A shorter wash for lightly
soiled loads and quick wash.
For lightly soi led cr ocker y
and glass
Wash (45 )
Rinse
Rinse (55 )
℃
℃
(50 )℃
175
192
165
30
1.1
0.75
1.4
0.7
16.5
13
9
10
Wash(65 )
Rinse
Rinse (65 )
Drying
℃
℃
90 11.5
1.15
Pre-w ash
wash( 40 )
Rinse
Rinse(60 )
Drying
℃
℃
125
0.75 13.5
Prewas h 50
Wash 65
Rinse
Rinse
Rinse 70
Drying
（℃ ）
（℃）
（℃）
Prewas h(45 )
Wash (55 )
Rinse
Rinse (65 )
Drying
℃
℃
℃
Prewas h
Wash (45 )
Rinse(65 )
Drying
℃
℃
This is standard progr amm e, it is
suitable to clean norm ally soiled
tableware and it is the m ost efficient
programme in terms of its combi ned
ener gy a nd w ater con su mpti on f or
that type of tableware.
A shorter wash for lightly
soiled loads that do not
need dryi ng.
Prewas h
15 0.02 3 .5
Starting a cycle wash
Draw out the lower and upper basket, load the dishes and push them back.
It is load the lower basket first, then the upper one (see the section entitled
Loading the Dishwasher ).
Pour in the detergent (see the section entitled Sal t, Detergent and Rinse Aid ) .
Insert the plug into the socket. The power supply is 220-240 VAC /50 HZ, the specification
of the socket is 10A 250VAC. Make sure that the water supply is turned on to full pressure.
Close the door, press the On/Off button to switch on the machine.
Press the program button , the wash program will be changed as foll ows direction:
. Then press t he Start/Pause button
recommended to
tur n on t he
dishwasher will start its cycle.
“ ”
“ ”
Intensive->Normal->ECO->Glass ->Rapid ;->90 Min ->Soak
If a program is selected, the response light will
1
2
3
4
5

If your model has broken remember function, the machine will go on to finish the selected
program .after the power cut
When the working cycle has fi nished, the buzzer of the dishwasher will soun d for 8 seconds, then stop. Turn off
the appliance using the ON/O FF button, shut off the wa ter supp ly and open the door of the dishwashe r.
Wait for a few minutes before unloading the dishwasher to avoid ha ndlin g the dishes and utensils while th ey
are still hot and more susceptible to break . They will also dry be tter.
Switching Off the Dishwasher
The program light is on but is not blinking,
1.Switch off the dishwasher by pressing the On/Off Button.
2.Turn off the water tap!
only in this case has the program en ded.
Open the door carefully.
Hot dishes are sensitive minutes before removing from
the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
shocks . Th e dis hes sho uld c ool down for around 15
Unloading the dishwasher
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
It is normal for the dishwasher to be wet inside.
If you open the door , the machine will pause. The program light will
stop blinking and the buzzer will mooing every minute unless you close the door . After
you close the door ,the machine will keep on working after 10 seconds.
dur ing a wash cycle
A forgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working, you can open the door
completely.
2
3
Open the door a little .
14
5
6
Press the Start/Pause Button to stop the washing.
Press t he Start/Pau se B utto n. The dishwasher w ill run
after 1 0 seconds.
It is dangerous to open the door mid-cycle,
as hot steam may scald you.
Changing the Program Mid-Cycle
Premise:
A running for a short time. Otherwise, the
detergent may have already be en released, and the appliance may have already drained the wash water.
If this is the case , the detergent dispenser must be refilled (see the section entitled " Loading the
Detergent " ).
running cycle can only be changed if it has only been
Press the Start/Pause button , the machine will pause, press the program button more than 3s then you
can change the program to the desired cycle setting (s ee the section entitled " Starting a wash cycle. . ." ).
1
2
When you press the Start/Pause button to pause during washing, the will
stop blinking and the dishwasher w ill mooing every minute unless you press the
Start/Paus e button to start.
run ning indicator

The filter prevents lar ger remnants of food or other objects from getting inside the pump.
The residues may block the filter, in this case t hey must be rem oved .
The filter system consists of a coarse filter,a flat (Main filter)
And a microfilt er(Fine filter).
Food and soil part icles trapped in this filter are pulverize d by a
special jet on the l ower spray arm and washed d own to d rain.
La rger ite ms, such as p ieces of bones o r glass, that could block
the drain are trapped in the coarse filter. To remove the items
caught by the filter, gently squeeze the tap on the top of this
filter and l ift out.
This filter holds soil and food residues in the sump a rea a nd
Prevents them from being redeposited on the dishes during wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filter assembly
The filter efficiently
For best performance and results, the filter must be cleaned re gularly. this reason, it is a good idea to
remove the larger food particl es trapped in the filter after each was h cycle by rinsing the semicircular filte r and
cup under running water. To remove th e filter device, pull the cup handle in the upward direction.
remo ves food particle s from the wa sh water, allowing it to be recycle d during the cycl e.
For
The dishw ash er m ust never b e used without the fi lters.
Impro per replacement of the filter may reduce the performance level of the appliance
and damage dishes and utensils.
1
2
Step 1 Turn the：filter counterclockwise,
Step 2 lift the filter assy up：
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.

The control pane l can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroug hly.
For the exterior, use a good appliance pol ish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
Warning
1 .Cut off the electrical power to the dishwasher at the supply source.
2. Turn off the water supply and disconnect the water inlet pipe from the water valve.
3. Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4. Reconnect the water inlet pipe t o the water valve.
5. Remove the filter at the bottom of the tub and use a spo nge to soak up water in the sump.
please take frost protection measures on the dishwasher in winter. Every fter washing cycles,
please operate as follows
time a
：
Cleaning the Filter
Cleaning the Door
To clean the coarse filter and the fine filter, use a cleaning brush. R eassemble the filter parts as show n in the figures
on the last page and reinsert the entire assembly in the dishwasher, positio ning it in its seat and pressing downwards.
When cleaning the filters, Otherwise, the filters could be
contorted and the performance of the dishwasher could be decreased.
do not knock them.
To clean the edge around the door, you
To avoid pene tration of water into the door lock and electrical components, do not
use a spray cleaner of any kind.
should only use a soft, ward and damp
cloth.
Never use a spray cleaner to clean t he door panel as it may dam age the door loc k
and electrical components.
Abrasive ag ents or some paper towels shou ld not be used because of the risk of
scratching or leaving spots on the stainl ess steel surface.
Cleaning the Spray Arms
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessary to clean the spray arms regularly for hard
wate r che micals w ill clog the spray arm jets a nd bearings.
- A fter each cycle, check for any deb ris in the filter to avo id future blo ckag e.
- By unscrewing the coarse filter, you can rem ove the filter system . Remove any food remnants and
clean the filters under runni ng water.
Remarks:
The entire filter assembly should be cleaned once a week.
To remove the lower spray arm, pull out the spray arm u pwa rd.
To remove the up per spray arm, hold the nut, rotate the arm
clockwise to remove it.
Wash the arms in soapy and warm water and use a soft brush to
clean the jets. Replace them after rinsing them thoroughly.

It is recommend that you run a wash cy cle with the
dishwasher empty and the n remove the plug from the
sock et, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
seals to last longer and prevent odours from forming
within the appliance.
If the appliance must be moved, try to keep it in the
vertical position. If absolutely necessary, it can be
positioned on its back.
One of the factors that cause odours to form in the
dishwasher the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
is rema ining food s trap ped in
Before cleaning or performing maintenance, always
remove the plug from the socket.
To cle an the exterior and rubber p arts of the di shw asher,
do not use solvents or abrasive cleaning products.
Only use a cloth w ith warm so apy water.
To rem ove spots or stains from the surface of the
interior, use a cloth dampened with water an a little
vinegar, or a cleaning pro duct made speci fically for
dishwashers.
Remove the Plug
No Solvents or Abrasive Cleaning
Moving the Appliance
Seals
After every wash, turn off the water supply to the
appliance and leave the door slightly open so that
moisture and odours are not trapped inside.
After Every Wash When not in Use for a lo ngTime
Ensure the voltage and frequency of the p ower being correspond s to
those on the rating plate.Only insert the plug into an electrical socket which is earthed
prop erly. If the electrical socket to which the a ppl iance must be connected is not
appropriate for the plug , replace the socket, rather than using a adaptors or t he like as
they could cause overheating an d burns.
Plea se look at th e rating label to know the rating voltage and connect the dishwasher to the appropr iate pow er suppl y.
Use the required fuse 10 amp , tim e delay fuse or circuit break er recommended and provide separate circuit serving
only this appliance.
Position the appliance in the desired location. The back should rest against the wall behind it, and the sides,
along the adj acent cabinets or walls. T he dishwasher is equipped with water supply and drain hoses that can
be positioned either to the righ t or the left sides to facilitate proper installation.
Once the appliance is positioned f or levelling, the height of the dishwashe r
level of the feet.
ma y be altered by adjusting the screwing
For personal safety:
Do not use an extension cord or an adapter plug
with this appliance.
Do not, under any circumstances, cut or remove
the earthing connection from the power cord.
