Brandywine NTA-100 User manual

MANUAL P/N 900000012 REV F
1
User Guide
Network Time Adapter
Model NTA-100
P/N 001-0076
Revision F
May 2005
Brandywine Communications
2230 South Fairview Street
Santa Ana, CA 92704
[phone]
[phone]
http://www.brandywinecomm.com

MANUAL P/N 900000012 REV F
2
Revision History
REVISION DATE COMMENTS
NC 03-27-03 Original release of NTA-100 user guide.
A 09-02-04 Revision of entire user guide.
B 12-01-04 Revised reference section of the user guide.
C 12-09-04 Revised time section of the user guide.
D 03-11-05 Revised reference section of the user guide.
E 04-29-05 Added the UDP port used by IPSetup and AutoUpdate.
F 05-25-05 Added defaulting memory to factory default settings section.

MANUAL P/N 900000012 REV F
3
Safety Warnings
WARNING: This unit contains lethal AC voltages. Disconnect the unit from
the AC supply before removing the cover.
WARNING:
The lightning flash with an arrowhead inside of an equilateral triangle is intended to alert the
user to the presence of un-insulated “dangerous voltage” within the product’s enclosure. The
“dangerous voltage” may be of sufficient magnitude to constitute as a risk of electrical shock
to people. Do not attempt to repair the unit without first unplugging it.
CAUTION:
The exclamation point inside of an equilateral triangle is intended to alert the user to the
presence of important operation and maintenance instructions in the user guide. This unit
should only be repaired by qualified personnel. Several board assemblies contain static
sensitive devices. Appropriate procedures must be used when handling these board
assemblies.

MANUAL P/N 900000012 REV F
4
Table of Contents
1 Introduction..................................................................................................................................5
2 Specifications ..............................................................................................................................6
2.1 Technical ............................................................................................................................6
2.2 LED Indicators ....................................................................................................................7
2.3 Connections........................................................................................................................8
2.3.1 Power.............................................................................................................................8
2.3.2 Ethernet..........................................................................................................................8
2.3.3 Antenna..........................................................................................................................8
2.3.4 Ethernet and Antenna Connections Example.................................................................8
2.3.5 Output ............................................................................................................................8
3 Unpacking and Installation ..........................................................................................................9
3.1 Unpacking...........................................................................................................................9
3.2 Installation ..........................................................................................................................9
3.2.1 IPSetup.exe..................................................................................................................10
3.2.2 Web Browser................................................................................................................11
3.2.3 Latest Version of Java Software...................................................................................11
3.2.4 Mounting.......................................................................................................................11
4 Configuration.............................................................................................................................12
4.1 Setup ................................................................................................................................12
4.1.1 System .........................................................................................................................12
4.1.2 IP Address....................................................................................................................13
4.2 Time..................................................................................................................................14
4.2.1 Serial Output (TOD) .....................................................................................................15
4.2.2 Time Zone Settings ......................................................................................................16
4.2.3 Daylight Saving Time ...................................................................................................17
4.2.4 Daylight Saving Time (Advanced) ................................................................................17
4.3 Password..........................................................................................................................18
4.3.1 Password......................................................................................................................18
4.4 Reference .........................................................................................................................19
4.4.1 Reference.....................................................................................................................20
4.4.2 Reference Status..........................................................................................................21
4.4.2.1 Open Satellite Status...........................................................................................22
4.4.2.2 GPS Settings .......................................................................................................23
4.4.3 Reference Settings.......................................................................................................26
4.5 Help ..................................................................................................................................27
5 Uploading Firmware ..................................................................................................................28
6 Defaulting Memory to Factory Default Settings .........................................................................30
7 Drawings ...................................................................................................................................31
8 Wall Mount Template Sheet ......................................................................................................34

MANUAL P/N 900000012 REV F
5
1 Introduction
The Network Time Adapter (NTA-100) is used as a Network Time Protocol (NTP) client. When the
NTA-100 has been fully configured, the NTA-100 receives its time from the NTP Time Server and
distributes this time via the serial port to wall displays or other serial devices.

MANUAL P/N 900000012 REV F
6
2Specifications
2.1 Technical
•Unit Numbers
oModel Number: NTA-100
oPart Number: 001-0076
•Physical Characteristics
oSize: 5.25” x 5.38” x 1.12” (W x L x H)
oWeight: typically 1 lb
oPower: 85-264 VAC
50/60 Hz
•Synchronization
oSource: NTP Version 3
oSynchronization Accuracy: typically ±20 milliseconds
•Serial Outputs
oConnection: RJ-12
oOutput: ASCII serial
oLevel: RS232 and RS422 transmit only
•Bits
oAccuracy: typically ±20 milliseconds
oBaud Rate: 1200 - 19200
•Network Connections
oConnection: RJ-45 connection to a 10/100 Base-T network
oInterface Standards: NTP Version 3 [RFC 1305] - SNTP (RFC 2030)
Ethernet/IEEE 802.3
UDP/IP
ICMP
•Environment (Operation and Storage)
oTemperature: 0°C to +50°C
oHumidity: up to 95% RH (non-condensing)
oEMC: CE compliant

MANUAL P/N 900000012 REV F
7
2.2 LED Indicators
The table below describes each LED indicator on the front panel of the NTA-100.
LED COLOR ACTIVITY COMMENT
OFF NTA-100 does not have power.POWER GREEN
ON NTA-100 has power.
OFF No link exists between the NTA-100 10/100 Base-T port and network. LINK GREEN
ON The link between the NTA-100 10/100 Base-T port and network is good.
OFF Link is operating at 10 Mbps.SPEED GREEN
ON Link is operating at 100 Mbps.
OFF The NTA-100 has not acquired valid time yet.VALID
TIME
GREEN
ON The NTA-100 has acquired valid time.

MANUAL P/N 900000012 REV F
8
2.3 Connections
2.3.1 Power
Insert the power cord of the NTA-100 into an electrical socket to power up the unit. The Power LED
indicator will illuminate green.
2.3.2 Ethernet
Connect one end of an Ethernet cable to the NTA-100 Ethernet port. Connect the other end of the
Ethernet cable to a hub. Both the Link and Speed LED indicators will illuminate green.
2.3.3 Antenna
The NTA-100 can receive time from the GPS through the Antenna BNC connector. To receive time
from the GPS, connect the cable to the NTA-100 Antenna BNC connector.
2.3.4 Ethernet and Antenna Connections Example
2.3.5 Output
Connect the NTA-100 Output port to another serial device such as a display. The RJ-12 connector is
used for the Output port. The RJ-12 connector has two outputs, RS232 and RS422. RS232
transmits data using pin 2, whereas RS422 transmits data ‘A’ using pin 5 and transmits data ‘B’ using
pin 6. Furthermore, one RS232 receiver may be connected to the NTA-100, whereas up to ten
RS422 receivers may be connected (in parallel) to the NTA-100.
NTA-100
Serial Cable
Display
(12:34)
NTA-100
Hub
Network
Time Serve
r
LAN Hub
Example
NTA-100GM with
GPS
(
server
)

MANUAL P/N 900000012 REV F
9
3Unpacking and Installation
3.1 Unpacking
Remove the NTA-100 from the shipping carton. The following items should be included in the
shipment:
•1 NTA-100
•1 user guide
•1 wall mount template sheet
3.2 Installation
The NTA-100 is shipped with a label that indicates the IP address stored in the unit. The default
settings are:
•IP Address: 192.168.1.1
•Subnet Mask: 255.255.255.0
•Gateway: 0.0.0.0
To set the network address, the user may use either IPSetup.exe or a web browser. The two
processes are described below.

MANUAL P/N 900000012 REV F
10
3.2.1 IPSetup.exe
To setup the network address using the IP Setup program, follow the steps given below. Please note
that IPSetup uses a local broadcast on UDP port 20034.
1. Download the IP Setup program from the NetBurner website located at
http://www.netburner.com/support/downloads.html .
2. Double click on the IPSetup.exe icon and the NetBurner IPSetup screen will be displayed.
3. Verify that the “Select a Unit” displays the current MAC and IP address of the NTA-100
connected to the network.
4. Click on the NTA-100 that needs to be configured. Please note that the NTA-100 is
identified by SB72.
5. Enter the NDK Settings (IP, Network Mask, GateWay, and DNS).
6. To transfer the NDK Settings to the selected NTA-100, click the Set Æbutton.
7. Wait 15 seconds for the NDK Settings to be loaded into the NTA-100 and for the NTA-100
to restart.
8. Verify that the NTA-100 has the correct NDK Settings and is connected to the network by
clicking the Search Again button.
9. To exit the IP Setup program, click the Close button.
10. Open a web browser, type the IP address of the NTA-100 in the Address bar, and press
<Enter>. For example, type 192.168.1.1 or http://192.168.1.1 and press <Enter>.
11. The Setup screen will be displayed.
12. Configure the NTA-100. For more information on NTA-100 configuration, refer to the
Configuration section of the user guide.

MANUAL P/N 900000012 REV F
11
3.2.2 Web Browser
To setup the network address using the web browser, follow the steps given below.
1. Connect one end of an Ethernet cable to the NTA-100 Output port.
2. Connect the other end of the Ethernet cable to a hub.
3. Open a web browser, type the IP address of the NTA-100 in the Address bar, and press
<Enter>. For example, type 192.168.1.1 or http://192.168.1.1 and press <Enter>.
4. The Setup screen will be displayed.
5. Configure the NTA-100. For more information on NTA-100 configuration, refer to the
Configuration section of the user guide.
3.2.3 Latest Version of Java Software
To properly control and monitor the NTA-100 via a web browser based interface, Java software must
be installed on your computer. To obtain the Java software, follow the steps given below.
1. Go to http://www.sun.com/ .
2. Click on the Downloads link.
3. Click on the Java & Technologies link.
4. Click on the Java 2 Platform, Standard Edition link.
5. Click on the Download J2SE SDK link.
6. Complete the installation process.
Please note that the oldest acceptable Java software version number is 1.4.2_05. To check the Java
software version number installed on your computer, follow the steps given below.
1. Go to ‘Start’.
2. Go to ‘Control Panel’.
3. Go to ‘Add or Remove Programs’.
4. Scroll through the ‘Currently installed programs’ list.
5. Locate the ‘Java 2 Runtime Environment, SE’ program.
6. The version number follows the program’s name in step 5.
3.2.4 Mounting
The NTA-100 may be either mounted on a tabletop or wall. To mount the unit on a wall, use the wall
mount template sheet provided. Insert two or four #6 screws into the wall on the 5” centers, as
shown in the wall mount template sheet. The NTA-100 has slotted mounting holes on its rear panel
that should be placed over the screws. Now slide the NTA-100 down so that the screws engage with
the mounting holes on the rear panel of the NTA-100.

MANUAL P/N 900000012 REV F
12
4Configuration
Please note that the unit will automatically reboot when a serious error or lock up occurs. This allows
the unit to reset and run instead of locking up.
4.1 Setup
The Setup tab consists of two sections, the System and IP Address. This tab allows you to modify
setup information for the Network Time Adapter. Please note that the Class C Network is being used
therefore valid IP addresses are between 192.0.0.0 to 223.255.255.0. To save all modifications
made to the Setup screen, click the Submit button. To undo all modifications made to the Setup
screen, click the Reset button.
4.1.1 System
The System section consists of two fields, the Version and Unit Location. The Version refers to the
version number of the firmware. The Unit Location refers to the location of the unit. A maximum of
127 characters may be entered in the Unit Location field. Entering apostrophes (‘) in the Unit
Location field is not recommended.

MANUAL P/N 900000012 REV F
13
4.1.2 IP Address
The IP Address section consists of two radio buttons, the DHCP Enable and DHCP Disable and
three fields, the Device IP Address, Device Subnet Mask, and Device Gateway. If the DHCP Enable
radio button is selected, the NTA-100 will retrieve its configurations from the DHCP server. If the
DHCP Disable radio button is selected, the user must manually enter the configurations for the
device.
The Device IP Address is a 32-bit number that identifies the device on an IP network. The Device
Subnet Mask is a 32-bit number that enables the user to define sub-networks. The Device Gateway
is a 32-bit number used as the point of entrance from one network to another.
The default Device IP Address is 192.168.1.1, the default Device Subnet Mask is 255.255.255.0, and
the default Device Gateway is 0.0.0.0.

MANUAL P/N 900000012 REV F
14
4.2 Time
The Time tab consists of four sections, the Serial Output (TOD), Time Zone Settings, Daylight Saving
Time, and Daylight Saving Time (Advanced). This tab allows you to modify the time settings for the
Network Time Adapter. To save all modifications made to the Time screen, click the Submit button.
To undo all modifications made to the Time screen, click the Reset button.

MANUAL P/N 900000012 REV F
15
4.2.1 Serial Output (TOD)
The Serial Output (TOD) consists of one field, the Format, four combo boxes, the Baud, Data Bits,
Stop Bits, and Parity, and one check box, the Serial Output. The Format refers to the format of the
time outputted from the Network Time Adapter when the serial port is being used. The table below
lists the characters and descriptions used in the Format field. The Baud refers to the number of bits
transmitted per second. The Data Bits and Stop Bits follow RS232 standard. The Parity enables the
user to check the validity of the data by using either odd or even parity checking. The Serial Output
allows the user to disable the serial output when the unit is not locked.
CHARACTER DESCRIPTION
%A AM/PM
%C Carriage return (ASCII 13)
%D Day of the month
%H 24 hour format
%h 12 hour format
%L Shows locked, 1 = locked, 0 = not locked
%M Minutes
%m Number of the month
%N Full name of the month
%n 3 character name of the month
%O 3 digit day of the year starting at 0
%o 3 digit day of the year starting at 1
%R Line feed (ASCII 10)
%S Seconds
%W Full day of the week
%w 3 character day of the week
%X Any hexadecimal value (%X20 = ASCII space)
%y 2 digit year (2004 = 04)
%Y 4 digit year (2004 = 2004)
%% % symbol

MANUAL P/N 900000012 REV F
16
4.2.2 Time Zone Settings
The Time Zone Settings consists of two fields, the Time Zone text field and Time Zone combo box.
The Time Zone text field allows the user to enter the Standard Time offset from the Universal Time.
The Time Zone combo box allows the user to select either hour or minute. The table below lists all
time zones and their Standard Time offsets from the Universal Time.
TIME ZONE STANDARD TIME OFFSET FROM
UNIVERSAL TIME
Eniwetok (Marshall Islands) -12
Samoa (Polynesian Islands) -11
Hawaii -10
Alaska -9
Pacific Time -8
Mountain Time -7
Central Time -6
Eastern Time -5
Atlantic Time -4
Brazilia (Brazil) -3
Mid-Atlantic -2
Azores (Azores Islands) -1
Rome (Italy) 1
Israel 2
Moscow (Russia) 3
Baku (Azerbaijan) 4
New Delhi (India) 5
Dhakar (Jordan) 6
Bangkok (Thailand) 7
Hong Kong 8
Tokyo (Japan) 9
Sydney (Australia) 10
Magadan (Russia) 11
Wellington (New Zealand) 12

MANUAL P/N 900000012 REV F
17
4.2.3 Daylight Saving Time
The Daylight Saving Time consists of the “automatically adjust clock for daylight saving changes”
check box. If the user clicks the check box, the system will automatically adjust the time of the
Network Time Adapter when daylight saving time occurs. If the user does not click on the check box,
the system will not automatically adjust the time of the Network Time Adapter when daylight saving
time occurs.
4.2.4 Daylight Saving Time (Advanced)
The Daylight Saving Time (Advanced) consists of three fields, the Daylight saving offset (DSTO),
Daylight saving start, and Daylight saving stop. The Daylight saving offset is a number that is added
to or subtracted from the time zone setting. The Daylight saving offset entered by the user may be
either in hours or minutes.
The Daylight saving start allows the user to add the daylight saving offset to the time the daylight
saving should start. The user must enter the daylight saving start time, the occurrence of the specific
day, the day of the week, and the month that the daylight saving should start. Note that the 24 hour
standard is used (e.g. 1:00 p.m. will be written as 13:00). For example, Pacific Standard Time adds
an hour at 02:00 on the first Sunday of April.
The Daylight saving stop allows the user to subtract the daylight saving offset from the time the
daylight saving should stop. The user must enter the daylight saving stop time, the occurrence of the
specific day, the day of the week, and the month that the daylight saving should stop. Note that the
24 hour standard is used (e.g. 1:00 p.m. will be written as 13:00). For example, Pacific Standard
Time subtracts an hour at 02:00 on the last Sunday of October.
Please note that the daylight saving start time and daylight saving stop time must be in 24 hour
format. For example, if daylight saving start time and daylight saving stop time are at 1:00 pm, the
user must enter 13:00.

MANUAL P/N 900000012 REV F
18
4.3 Password
The Password tab consists of one section, the Password. This tab allows you to change the user
name and password for the system. To save all modifications made to the Password screen, click
the Submit button. To undo all modifications made to the Password screen, click the Reset button.
IMPORTANT INFORMATION:
The default user name and password for the system is BRANDYWINE and the user must
always enter a user name and password when submitting changes to the system.
4.3.1 Password
The Password consists of four fields, the New User Name, Old Password, New Password, and
Confirm New Password. The new password must be less than 31 characters and cannot contain any
asterisks. Moreover, the system is case sensitive.

MANUAL P/N 900000012 REV F
19
4.4 Reference
The Reference tab consists of three sections, the Reference, Reference Status, and Reference
Settings. This tab allows you to modify the reference for the Network Time Adapter. Please note
that while the Network Time Adapter is acquiring time from the references the Valid Time LED
indicator will be extinguished. Once the Network Time Adapter has acquired time from the reference
the Valid Time LED indicator will illuminate green. To save all modifications made to the Reference
screen, click the Submit button. To undo all modifications made to the Reference screen, click the
Reset button.

MANUAL P/N 900000012 REV F
20
4.4.1 Reference
The Reference consists of two fields, the Select reference and Reference Stable. The Select
reference allows the user to select one of the three references to acquire time from. The three
references used by the system are NTP Time Server, Serial Port Input, and GPS (model NTA-
100GM only).
The NTP Time Server reference uses the Network Time Protocol to synchronize the internal clocks of
a computer to the reference’s time. The stratum level may vary depending on the current reference
setting. To use this reference the NTP Server Address Pool must be setup.
The Serial Port Input reference continuously receives an update every second. The stratum level for
this reference is 2.
The serial time format is [STS][DOW][%x20][DAY]/[MONTH]/[YEAR][%x20%x20][HOUR]:[MINUTE]:[SECOND][0x0D] . The
table below lists the data and descriptions used.
DATA DESCRIPTION
STX Start of the message %x02 and this character acts as the 1PPS timing
mark
%W Day of the week written as three letters: Sun, Mon, Tue, Wed, Thu,
Fri, and Sat
%x20 Space character
%D Two digit number of the day (01 - 31)
%x2F Slash character '/'
%m Two digit number of the month (01 - 12)
%x2F Slash character '/'
%Y Two digit number of the year (00 - 99)
%X20 Space character
%x20 Space character
%H Two digit number of the hour (00 - 23)
%x3A Colon character ':'
%M Two digit number of the minute (00 - 59)
%x3A Colon character ':'
%S Two digit number of the second (00 – 59)
%x0D End of message – carriage return
