Our products are designed to meet the highest
standards of quality, functionality and design.
We hope you enjoy your new Gillette shaver
powered by Braun.
Warning
Your shaving system is provided with a special
cord set, which has an integrated Safety Extra
Low Voltage power supply. Do not exchange or
tamper with any part of it, otherwise there is risk
of an electric shock.
To prevent the cleaning fluid from leaking, ensure
that the Clean&Renew station is placed on a flat
surface. When a cleaning cartridge is installed,
do not tip, move suddenly or transport the
station in any way as cleaning fluid might spill
out of the cartridge. Do not place the station
inside a mirror cabinet, nor place it on a polished
or lacquered surface.
The cleaning cartridge contains a highly
flammable liquid so keep it away from sources
of ignition. Do not expose to direct sunlight and
cigarette smoking nor store it over a radiator.
Keep it out of reach of children.
Do not refill the cartridge and use only original
Braun refill cartridges.
Description
Clean&Renew station
1Cleaning fluid display
2Lift button for cartridge exchange
3Station-to-shaver contacts
4«start cleaning» button
5Cleaning program diodes
6Station power socket
7Cleaning cartridge
Shaver
8Foil & Cutter cassette
9Cassette release button
0Shaver head «lock» switch
qPop-out long hair trimmer
wOn/off switch
eReset button
rShaver display
tShaver-to-station contacts
zShaver power socket
uTravel case
iSpecial cord set
STOPSTOP
English
5673363_760cc_China_S4-18.indd 125673363_760cc_China_S4-18.indd 12 12.04.2007 11:14:06 Uhr12.04.2007 11:14:06 Uhr

13
Before shaving
Prior to first use you must connect the shaver to
an electrical outlet using the special cord set i
or alternatively proceed as below:
Installing the Clean&Renew station
• Using the special cord set i, connect the
station power socket 6to an electrical outlet.
• Press the lift button 2to open the housing.
• Hold the cleaning cartridge 7down on a flat,
stable surface (e.g. table).
• Carefully remove the lid from the cartridge.
• Slide the cartridge into the base of the station
as far as it will go.
• Slowly close the housing by pushing it down
until it locks.
The cleaning fluid display 1will show how much
fluid is in the cartridge:
«high» up to 30 cleaning cycles available
«low» up to 7 cleaning cycles remaining
«empty» new cartridge required
Charging and cleaning the shaver
Insert the shaver head down into the cleaning
station. (The contacts ton the back of the
shaver will align with the contacts 3in the
cleaning station).
If required, the Clean&Renew station will now
charge the shaver. The hygiene status of the
shaver will also be analyzed and one of the
following cleaning program diodes 5will light
up:
«clean» shaver is clean
«eco» short economical cleaning required
«normal» normal level of cleaning required
«intensive» high intensive cleaning required
