Breville WC10 Quick guide

Breville is a registered trademark of Breville Pty. Ltd.
ABN 98 000 092 928
© Copyright. Breville Pty. Ltd. 2003
Due to continual improvements in design or otherwise,
the product you purchase may differ slightly from
the one illustrated in this booklet.
Breville Customer Service Centre
Australian Customers
✉Breville Customer Service Centre
Locked Bag 2000
Botany NSW 2019
AUSTRALIA
☎Customer Service: 1300 139 798
Fax [phone]
Email Customer Service [e-mail]
New Zealand Customers
✉Breville Customer Service Centre
Private Bag 94411
Greenmount
AUCKLAND, NEW ZEALAND
☎Customer Service: 09 271 3980
Fax [phone]
Email Customer Service [e-mail]
www.breville.com.au
PRINTED ON
RECYCLED PAPER
Model WC10/WC15
Issue 1/03
INSTRUCTIONS FOR USE
AND RECIPE BOOK
Chill Out
Rapid wine chiller
Model WC10/WC15

Page
Breville recommends safety first 4
Know your Breville Wine Chiller 5
Operating Your Breville Wine Chiller 6
The unique 'Chill Cells' 7
Using Ice 7
Using the Timer 7
Using the Manual Feature 7
Battery Operation 7
Recommended Chilling Times 8
Care and Cleaning 9
Rapid Wine Chiller
CONTENTS
Congratulations
on your purchase of your new Breville Wine Chiller
2

45
••Do not immerse the motor base, plug or
cord in water or any other liquid.
••Always use the appliance on a dry,
level surface.
••Always switch the appliance to 'OFF',
switch the power off at the power outlet
and then remove the plug when the
appliance is not being used and
before cleaning.
••Do not place your hands in the Wine
Chiller while the chiller is operating.
••Do not place hands in the Wine Chiller
unless the unit is switched off and
disconnected from the power outlet.
••Handle 'Chill Cells' with care as
prolonged contact could cause freezer
burn. Use a cloth or hold by the plastic
part of the 'Chill Cells' when holding.
••Regularly inspect the supply cord, plug
and actual appliance for any damage. If
found damaged in anyway, immediately
cease use of the appliance and return the
entire appliance to the nearest authorised
Breville service centre for examination,
replacement or repair.
••Do not leave the appliance unattended
when in use. Young children or infirm
persons should be supervised to ensure
that they do not play with or misuse
the appliance.
••Do not let the cord hang over the edge of
a table or counter, touch hot surfaces or
become knotted.
••Do not place this appliance on or near a
hot gas or electric burner, or where it
could touch a heated oven.
••This appliance is for household use only.
Do not use this appliance for anything
other than its intended use.
••Do not start the timer until you have filled
the container with water.
••Use only the AC adaptor provided with
this appliance.
••Ensure that the water does not overflow
from the rim of the wine chiller.
••Do not allow the internal components of
the Wine Chiller to get wet at any time.
••Do not allow any objects to block the
pump outlets.
BREVILLE RECOMMENDS SAFETY FIRST
We at Breville are very safety conscious. We design and manufacture consumer products with
the safety of you, our valued customer foremost in mind. In addition we ask that you exercise a
degree of care when using any electrical appliance and adhere to the following precautions:
IMPORTANT SAFEGUARDS, READ ALL INSTRUCTIONS BEFORE
OPERATING AND SAVE FOR FUTURE REFERENCE
KNOW YOUR BREVILLE WINE CHILLER
Stylish Stainless Steel Rim
Agitating Cover
Positioned in the base of the Wine Chiller,
the agitating cover is designed to circulate
water around the bottle and 'Chill Cells'.
Manual Setting
For continuous chilling of beverages, turn
the dial to the manual setting and the Wine
Chiller will continue to chill the bottles.
15 minute timer with Automatic Off
Easy to operate 15 minute timer with auto
off enables you to chill beverages to the
correct temperature - bottle after bottle.
Removable Cord
The Wine Chiller is designed to be taken to
the table once your beverages are chilled.
Simply remove the cord and the Wine
Chiller can be used as an ice bucket.
Battery Operation
Designed for use outdoors,
simply insert 7 AA batteries
Three unique 'Chill Cells'
Perfectly shaped to stack in the freezer using
minimal space, the 'Chill Cells' ensure
beverages are chilled quickly and efficiently
without the use of ice.

THE UNIQUELY DESIGNED
‘CHILL CELLS’
Your Breville Wine Chiller comes with three
specially designed ‘Chill Cells’ to enable you
to chill wine in minutes.
The ‘Chill Cells’ are filled with special gel
which is a safe, food grade material able to
freeze and hold temperature very efficiently.
If you damage or lose your ‘Chill Cells’,
please contact the Breville Customer Care
Centre to order a replacement.
USING ICE
The Breville Wine Chiller has been designed
to be used with the ‘Chill Cells’ or ice cubes.
Simply place two trays of ice cubes into the
Wine Chiller before adding the water to chill
then switch on.
USING THE TIMER
Your Wine Chiller features a 15 minute timer
designed for optimal chilling of beverages.
If you need to reduce the time selected on
the timer, simply turn the timer dial in an
anti-clockwise direction until the desired
time is reached.
USING THE MANUAL FEATURE
For chilling beverages without the timer,
simply turn the control dial to the left. To
stop chilling slowly turn the control dial to
the OFF position.
BATTERY OPERATION
Your Wine Chiller is designed to be battery
operated. This is perfect to be able to chill
bottles of wine while at a picnic or BBQ.
Simply insert seven (7) AA size batteries
into the base of the Wine Chiller.
The Wine Chiller should last 3 hours
using battery operation.
OPERATING YOUR BREVILLE WINE CHILLER cont’d
7
BEFORE FIRST USE
Remove all promotional labels and place the
specially designed ‘Chill Cells’ into the
freezer for a minimum of 8 hours to freeze.
1. Place the Wine Chiller on a flat, dry
surface and ensure that the unit is
unplugged and the control dial is set to
the ‘OFF’ position.
2. Remove the ‘Chill Cells’ from the freezer
and place around the inside of the Wine
Chiller (see Fig 1).
3. Place the bottle to be chilled into the
Wine Chiller.
4. Using a jug, pour in cold tap water into
the Wine Chiller until just covering the
‘Chill Cells’.
5. Plug the AC adaptor into a 230/240v AC
power outlet and turn the power ‘ON’
6. To chill a single bottle, set the Timer
by turning the control dial to the
desired setting. (refer recommended
times on page 8)
7. Once the first bottle is chilled, the Breville
Wine Chiller is ready to chill the next bottle
to perfection. Simply remove the first
bottle, and replace with the next room-
temperature bottle ready for chilling.
8. When you have finished chilling, turn the
appliance OFF at the power outlet and
remove the adaptor from the rear of the
motor base.
9. Your Breville Wine Chiller can now be
taken to the table to be used as an ice
bucket to keep the beverages chilled.
10.Once you have finished using the Wine
Chiller, pour out the water. Remove the
‘Chill Cells’, drain and dry thoroughly
then stack them back in the freezer for
next time.
11.Finally, allow the unit to dry thoroughly.
OPERATING YOUR BREVILLE WINE CHILLER
6
Always keep the 'Chill Cells'
in the freezer as they will
always be ready to chill
wine for unexpected guests.
When not using the battery
feature, do not store the Wine
Chiller with batteries located
inside as they may leak.
Your ‘Chill Cells’ can also
be used to keep food or
beverages cool in an esky.
Simply place the frozen
‘Chill Cells’ into the esky
instead of ice.
Fig 1

Before cleaning, ensure the Wine Chiller is
switched OFF at the power outlet and then
remove the adaptor.
To clean, simply wipe the inside and
outside of the Wine Chiller with a clean
damp cloth. Once clean, ensure the
appliance is dry thoroughly.
REMOVING AND CLEANING THE
AGITATING COVER.
During chilling, a price label or packaging
label may peel off the bottle and may
become lodged in the agitating cover.
To remove, simply lift out the agitating
cover, remove the debris and wipe clean with
a damp cloth.
Please ensure that once any debris has
been removed that the agitating cover is
replaced.
CARE AND CLEANING
9
8
RECOMMENDED CHILLING TIMES
TIP: The Wine Chiller has also been designed to chill bottles of soft drink as well as beer.
OPERATING YOUR BREVILLE WINE CHILLER cont’d
ALWAYS SWITCH OFF AND THEN UNPLUG THE APPLIANCE WHEN NOT IN
USE OR STORING.
Never immerse the motor
base, cord or adaptor in
water or any other liquid.
Consecutive bottles can
be chilled quickly using
the existing water. A
second bottle can be
chilled in minutes.
Ideal drinking CHILLING TIMES
BEVERAGE temperature Warm Day Start Cool Day Start
(approx) Room Temp 25°C Room Temp 20°C
Sparkling Wine, 7 - 9°C 13 minutes 10 minutes
Champagne,
Dessert Wine
Dry Whites – 10 – 12°C 9.5 minutes 7.5 minutes
Sauvignon Blanc,
Semillon, Riesling,
(excluding Chardonnay)
Chardonnay, Rosé, Verdelho 13 - 14°C 7.5 minutes 4 minutes
Light Red Wines – 15 - 16°C 6 minutes 3 minutes
Pinot Noir, Gamey
Full Bodied Reds – 17 - 18°C 5 minutes 3 minutes
Shiraz, Grenache,
Cabernet Sauvingnon,
Merlot

NOTES
11
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
10
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
_____________________________________________________________________________________________________
NOTES
