BridgIoT Geasy MK6 User manual

GEASY
INSTRUCTION MANUAL
Models: Mk6
Date: January 21,2020
Email: support bridgiot.co.za

Contents
Contents 1
Warranty 2
About Geasy 3
ImproperUsage ..................................... 3
Safety During Installation & Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Exclusion of Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Physical Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Specifications................................. 4
Installation procedure steps 5
Apply All Safety Measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Electrical Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operation 9
Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Safety........................................... 9
User Responsibilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
DeviceStatus....................................... 10
Temperature Control & Scheduling . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Burst/leak Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
User Interface ...................................... 11
Company Contact Details 17
Page 1of 17

Warranty
1. We, BridgIoT (RF) (Pty) Ltd, warrant to you that, for a 6-month period from the date
of purchase, the Geasy (from here on referred to as the “good”) will be free of any
defect.
2.If any defect in the good is discovered by you within a 6-month period from the
date of purchase, you can return the good to us or to one of our duly authorised
service agents. A good returned under this warranty must be presented to us in
its original packaging together with all accessories. We will then, at your option:
a) repair or replace the good; or
b) refund to you the price paid by you for the good.
3.If within three months after repair, the failure, defect or unsafe feature has not
been remedied, or a further failure, defect or unsafe feature is discovered, the
supplier must:
a) replace the good; or
b) refund to the consumer the price paid by the consumer for the goods.
4. We will refuse the return of any good which has been:
a) partially or wholly disassembled;
b) physically altered;
c) damaged;
d) used in a manner contrary to any instructions provided by us; or
e) permanently installed or attached and/or combined with other goods or
property in any way.
5. We will not:
a) repair the good where the defect or damage to the good is found to be a
direct result of your negligence, recklessness or malicious behaviour; and/or
b) be liable for damage caused to the good as a result of wear and tear unless
such damage manifests itself:
i. within 6months from the date of purchase (where the good has been
used for normal family, personal or household purposes); or
ii. 6months from the date of purchase (where the good has been used for
commercial or professional purposes).
6. Where we issue a refund under this warranty, we will deduct the charges we are
allowed to deduct under the Consumer Protection Act, No 68 of 2008.
7. Please note that our normal warranty does not cover any natural disasters, for
example; flooding, lightning, earthquakes, etc.
Page 2of 17

About Geasy
Geasy is suitable for installation on electric water heaters (geysers). When installing the
Geasy be sure to follow the appropriate instructions of each particular manufacturer for
all other components as well.
Installation, maintenance and dismantling may only be performed by trained personnel
in accordance with this instruction manual and safety instructions.
Use the Geasy only after first thoroughly reading and understanding this instruction
manual and the safety instructions. In the event of any ambiguities regarding the
installation and operation, consult trained personnel or contact our offices.
Improper Usage
The Geasy must not be operated in the following environments:
1. Outdoors.
2.In damp conditions.
3.In rooms in which the operation of electrical and electronic components may be
dangerous.
Safety During Installation & Use
Please take note of the following when installing, conducting maintenance or using your
Geasy:
1. Risk of death by electrocution.
2. Risk of fire due to short circuit.
3. All work on an open Geasy must be performed with the mains supply
disconnected.
4. All safety regulations apply when working on the mains supply.
5. Before connecting the Geasy, make sure that the power supply matches the
specifications on the type plate.
6. Factory labels and markings may not be altered, removed or rendered unreadable.
7. Make sure that all devices which are connected to the Geasy conform to the
technical specifications of the Geasy.
Page 3of 17

Exclusion of Liability
The manufacturer cannot monitor, or be held responsible, for compliance to this manual
or the conditions and methods during installation and operation. Improper installation
of the system may result in damage to the property and/or in bodily injury.
Therefore, we assume no responsibility for loss, damage or costs which result from or
are in any way related to incorrect installation, improper operation, incorrect execution
of installation work and incorrect usage and maintenance.
The manufacturer reserves the right to make changes to the product, technical data or
assembly and operating instructions without prior notice.
Physical Properties
Mass ~1kg
Enclosure Allbro IP66 Enlec (ENL2021509C)
Dimensions: 200 x150 x90 mm
Technical Specifications
Make BridgIoT (RF) (Pty) Ltd
Model Geasy MK6
Power Supply DIN RAIL input:
100 -240 VAC (50-60 Hz)
25 A (25 mA + LOAD)
Battery input:
9-12 VDC
420 mA
Temperature Range 0-70 °C
Page 4of 17

Installation Procedure Steps
A summary of the installation steps are as follows:
1. Apply all safety measures.
2. Complete all electrical connections.
3. Complete all sensor connections.
4. Set up the controller and all settings via the web-app.
Apply All Safety Measures
1. Switch offcircuit breaker of geyser at the main distribution board (DB).
2. Switch offthe isolator switch in the roof. The isolator disconnects the live and
neutral so that - should someone accidentally switch on the main supply or the
circuit breaker fails - there will be no power at the geyser.
3. Test with a multimeter that there is no current on the wires.
Electrical Installation Instructions
Included below is a schematic diagram of how the different components of the system
should be installed, where after step-by-step instructions are given.
Page 5of 17

Power Installation
Step-by-step instructions are included below, followed by a photo of the Geasy PCB.
1. Remove the mains supply from the geyser's thermostat.
2.Install a new length of “twin and earth”cable between the Geasy controller and
the geysers thermostat, for the electrical supply of the geyser’s heating element.
a) Connect the earth wire to the right-hand side terminal for the geyser’s supply,
labelled ‘E’
Note: The Geyser must be earthed.
b) Connect the neutral wire to the right-hand side terminal labelled ‘N’.
c) Connect the live wire to the right-hand side terminal labelled ’L-out’.
d) Now, connect the earth, neutral and live wires to the appropriate terminals
on the geyser’s thermostat.
3. Use the electrical supply from the isolation switch to power the controller:
a) Connect the earth wire to the left most terminal, labelled ‘E’
Note: The Geyser must be earthed.
b) Connect the neutral wire to the terminal located second from left and labelled
‘N’.
c) Connect the live wire to the terminal located third from left and labelled ’L’.
Page 6of 17

Sensors Installation
1. Use self-fusing silicone tape to secure the temperature sensors' flat part onto the
piping. Ensure secure attachment.
2. Attach the “Inlet”temperature to the inlet pipe, near the water meter. Attach the
“Outlet near”onto the outlet pipe as close as possible to the geyser.
3. Allow the white flex wire to rest in the drip tray, ensuring that the flex wires do not
touch (the wire connects to the “Drip”connector on the PCB).
Page 7of 17

Inserting a Sim Card
If your Geasy was supplied with a Sim Card, we will already have inserted the Sim Card
and will keep it topped up with data. If your Geasy was not supplied with a Sim Card
please follow these instructions to install the Sim Card.
1. Switch offthe power supply to the device at the isolation switch.
2. Open the enclosure of the device. (The screws only require a quarter turn)
3. Locate the sim card holder.
4. Slide the sim tray open and lift the flap.
5. Slide the micro size sim card into the tray, with its pads facing downwards.
6. Close the flap and slide the slider back until it clicks, securing the sim card.
7. Close the enclosure, securing the screws.
8. Switch the power supply on again.
Device and User Linking
There are two ways of device linking. The first, for partner organisations, is through our
installer application which can be found here. The second method of device linking is
to contact us directly at support bridgiot.co.za, including your device ID found on the
outer surface of the device and the email address used to register your user profile.
Page 8of 17

Operation
Product Description
Geasy is a smart geyser controller that enables the management of an electric water
heater (EWH), commonly known as a geyser, through an online platform. Geasy has
internet connectivity whereby it sends information and receives instructions from the
BridgIoT (RF) (Pty) Ltd web-app. The Geasy is retrofitted to an existing EWH and offers
the following functionality:
1. Switching the EWH ON and OFF by switching the supply to the heating element.
Control through:
a) scheduling or;
b) real-time temperature control.
2. Measure power consumption.
3.Internet connectivity through a cellular connection.
4. Measuring up to 3temperatures:
a) water outlet temperature and/or;
b) water inlet temperature and/or;
c) ambient temperature.
5. Optional: Detect the presence of water in the drip tray.
Safety
Do not interfere with the device. If you have to open the enclosure of the device, for
whatever reason, only do so after switching offthe power supply at the isolation switch.
Only switch on the isolation switch after the enclosure has been closed.
User Responsibilities
The user may not use the device's sim card (if supplied by BridgIoT (RF) (Pty) Ltd) for
any other purposes if the sim card was provided with the device. The sim card must,
therefore, remain within the device. The user must immediately notify BridgIoT (RF)
(Pty) Ltd, or their service provider, if the sim card is lost/stolen.
Page 9of 17

Device Status
There are two LED lights indicating the status of the device. The number of times each
LED flashes per cycle indicates a state. These definitions are subject to change.
The green LED indicates the connectivity status of the device.
Single Flash Fully connected
Two flashes Partially connected
Three flashes Not connected
The red LED can indicate the state of the EWH.
Single Flash EWH supply is switched off(i.e, not heating)
Two flashes EWH supply is on, but not drawing power (i.e, not heating)
Three flashes EWH supply is on and drawing power (i.e, heating)
If your device loses connectivity to the online platform, for whatever reason, it will go
into a default state. The default state is an “Always on”state with a temperature set point
of 55 °C. The quality of the connectivity is dependent on the cellular service provider
(CSP) used for the device. If your device is experiencing consistent connectivity issues, it
might be necessary to change CSP.
To reset your device, switch offthe supply to the device by switching the EWH circuit
breaker offat the distribution board.
The only way of overriding the device is for an installer to electrically bypass the device.
Temperature Control & Scheduling
Heating scheduling is performed via the cloud, no scheduling information is stored
locally and thus your Geasy requires continuous internet connectivity.
Geasy can perform temperature control of the EWH based on the estimated internal
temperature. Geasy does not replace your standard thermostat, and can therefore not
heat the water higher than the thermostat is set at. This ensures the safe operation of
the EWH and prevents overheating.
Burst/leak Detection
Depending on what components are installed, the device can provide burst/leak
detection and mitigation. The drip detection sensor in the drip tray can detect the
presence of water. Upon detection of water, the online platform then notifies the user
of a potential leak or burst. Note that your Geasy must have power and an internet
connection for the notification to be sent.
To open the water supply and turn the EWH on again, the device typically has to be reset.
Page 10 of 17

If there is still water present in the drip tray, the device will trigger a burst event again.
It is therefore required that the user ensures that there is no burst or leak and removes
the water from the drip tray before resetting the device.
User Interface
The user can manage their device via the BridgIoT (RF) (Pty) Ltd online web-app, found
at app.bridgiot.co.za. Please sign up on this web interface, by clicking the “Sign up”link
on the landing page as shown below, in order to access your device data and settings.
The user interface will typically include the following functionality (although functionality
may be added (or subtracted) from time to time):
1. Switching the EWH heating ON and OFF.
2. Schedule heating of the EWH.
3. Power consumption.
Page 11 of 17

4. Burst/leak detection notifications (optional).
App Usage
Once logged in you will see all of the devices linked to your profile and some information
regarding those devices on the landing page, similar to the image below.
Selecting your Geasy from the list will take you to a status display similar to the one
below, where you can see some basic information and settings regarding your Geasy.
Page 12 of 17

Page 13 of 17

Clicking on the ‘View more’button under ‘USAGE’will take you to a display similar to the
one below, where a summary of the electricity and water measured by your Geasy is
available.
From the status display screen, clicking on the ‘View more’button under ‘TODAY’S
LARGEST EVENTS’will take you to a screen similar to the one below where water usage
events can be seen. This view gives you an indication of how much water is used during
specific water usage events making it easy to compare between your own shower and
that of your spouse.
Page 14 of 17

From the status display screen, clicking on the ‘More options’button under ‘HEATING
CONTROL’will take you to a screen similar to the one below where your geyser can be
switched on/offor on timer control for scheduling. Additionally, the boost functionality
can be used to turn your geyser on, and heat to the thermostat maximum temperature,
for 60 minutes.
Page 15 of 17

From the heating control screen given above, clicking on the ‘View’next to ‘Timer control’
will take you to a screen similar to the one below where a schedule of the current heating
times and temperatures are given. The minimum scheduling temperature has been
limited to 51 °C in order to prevent legionella growth in the geyser and piping.
From here any number of schedules can be create by any of the users associated with
this geyser controller and all of them will be visible here.
For the more data driven individuals, there is an analytics view, where the heating and
water usage data (if water meters have been installed) is available as time series data.
This view helps to identify usage patters as well as quantities of power and water usage
over different time periods1.
1Hint: Each column is clickable, which makes navigation and closer inspection of data more user
friendly.
Page 16 of 17

BridgIoT (RF) (Pty) Ltd Website
https://www.bridgiot.co.za/
Company Registration Number
2015/284421/07
Office Contact Details
General [phone]
info bridgiot.co.za
Finance finance bridgiot.co.za
Sales sales bridgiot.co.za
Support [phone]
support bridgiot.co.za
Physical address Business address Postal address
LaunchLab
Hammanshand Road 15 de Beer Street PO Box 3135
Stellenbosch, 7600 Stellenbosch, 7600 Matieland, 7602
Western Cape Western Cape Western Cape
South Africa South Africa South Africa
Page 17 of 17
