INSTALLATION MANUAL – BSH-4011 Security Camera Housing
WARNING: Before beginning installation of this product, carefully review the safeguards and
precautions found on page 2 of this manual.
Unpacking
Unpack carefully. This is electromechanical
equipment and should be handled with care. If an
item appears to have been damaged in shipment,
replace it properly in its carton and notify the shipper.
If any items are missing, notify Broadsight Systems,
Inc. The shipping carton is the safest container in
which the unit may be transported. Save it for
possible future use.
Service
If the unit ever needs repair service, the customer
should contact Broadsight Systems, Inc. for a return
materials authorization (RMA) and shipping
instructions.
Care and Maintenance
Perform routine maintenance to keep the unit dust
free and clean the viewing window using a mild
detergent solution and Kimwipe™ brand delicate task
wipes or similar.
Model Designation
BSH-4011 Outdoor housing
BSH-4011-2 Outdoor housing with heater
BSH-4011-24 Outdoor housing with heater/blower
Accessories
BSH-4011SS Sunshield for BSH Housings
BWM-4011 Wall Mount, adjustable head
BWM-4011J Ceiling/overhang mount, adjustable
head
BPA-1 Pole adapter for BWM-4011 Mount
Description
The BSH-4011 Series Camera Housings are outdoor
rated enclosures with optional heater and blower
features as well as a sunshield accessory to improve
the camera’s performance in hot or cold climates.
Cable entry is possible through the rear cap and the
mounting foot. The accessory mount permits cable
concealment when the cables are routed through the
mount. The housing is sized to fit a range of
cameras and lenses, and includes a generic camera
mounting bracket for attaching it to the housing.
Hardware Kit
2 x ¼-20 x 3/8” Hex Cross Recessed Head Screws
1 x ¼” Flat Washer
1 x ¼” Lock Washer
Tools Required
•#2 Cross Recessed Screwdriver (Phillips)
•1/8” Width Flat Blade Screwdriver
•3/4” Open End Wrench
•General Purpose Wire Stripper with Cutter
•Optional: Adjustable Wrench
Materials required
•Outdoor Rated Cables for Power and Video
Cables must be round in shape with an outer jacket
diameter of 0.170” minimum to 0.310” maximum.
Certification
Installation should be performed by a licensed
professional and conform to the National Electrical
Code (NEC) and any applicable local codes.
Installation
Installation instructions begin on Page 3.
www.broadsightsystems.com
1124 Louise Road
Winston-Salem, NC 27107
Service: 1-336-837-1272

Page 2of 3
IMPORTANT SAFEGUARDS
1. Read Instructions - All the safety and operating instructions should be read before the unit is operated.
2. Retain Instructions - The safety and operating instructions should be retained for future reference.
3. Heed Warnings - All warnings on the unit and in the operating instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Unplug the unit from the outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards.
7. Accessories - Do not place this unit on an unstable stand, tripod, bracket, or mount. The unit may fall, causing serious injury to a person and serious
damage to the unit. Use only with a stand, tripod, bracket, or mount recommended by the manufacturer or sold with the product. Any mounting of the
unit should follow the manufacturer's instructions and should use a mounting accessory recommended by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
8. Ventilation - Openings in the enclosure, if any, are provided for ventilation, to ensure reliable operation of the unit, and to protect it from overheating.
These openings must not be blocked or covered. This unit
should not be placed in a built-in installation unless proper ventilation is provided or the manufacturer's instructions have been adhered to.
9. Power Sources - This unit should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power
supply you plan to use, consult your appliance dealer or local power company. For units intended to operate from battery power or other sources, refer
to the operating instructions.
10. Grounding or Polarization - This unit may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This
plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If
the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
Alternatively, this unit may be equipped with a 3-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-
type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the grounding-type plug.
11. Power Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords and plugs, convenience receptacles, and the point where they exit from the appliance.
12. Power Lines - An outdoor system should not be located in the vicinity of overhead power lines or other electric light or power circuits or where it can fall
into such power lines or circuits. When installing an outdoor system, extreme care should be taken to keep from touching such power lines or circuits as
contact with them might be fatal. U.S.A. models only - refer to the National Electrical Code Article 820 regarding installation of CATV systems.
13. Overloading - Do not overload outlets and extension cords as this can result in a fire or electric shock.
14. Object and Liquid Entry - Never push objects of any kind into this unit through openings, as they may touch dangerous voltage points or short out parts
that could result in a fire or electric shock. Never spill liquid of any kind on the unit.
15. Servicing - Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
16. Damage Requiring Service - Unplug the unit from the outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled or objects have fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions,
as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the unit to
its normal operation.
e. If the unit has been dropped or the cabinet has been damaged.
f. When the unit exhibits a distinct change in performance--this indicates a need for service.
17. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or
have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.
18. Safety Check - Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in
proper operating condition.
19. Coax Grounding - If an outside cable system is connected to the unit, be sure the cable system is grounded. U.S.A. models only--Section 810 of the
National Electrical Code, ANSI/NFPA No.70-1981, provides information with respect to proper grounding of the mount and supporting structure,
grounding of the coax to a discharge unit, size of grounding conductors, location of discharge unit,connection to grounding electrodes, and requirements
for the grounding electrode.
20. Lightning - For added protection of this unit during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the cable system. This will prevent damage to the unit due to lightning and power line surges.
FCC NOTICE
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's
instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class B computing
device in accordance with Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Relocate the monitor away from the TV/radio receiver.
Plug the monitor into a different wall outlet so that the console is on a different branch circuit.
Re-orient the TV/radio antenna.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions.
NOTE: Changes or modifications to the unit may void FCC compliance.

Page 3of 3
Installation
1. Choose desired location for camera housing
installation. Verify mounting structure and
surface is capable of supporting the camera and
no obstacle or interference is present from
existing installed devices or wiring.
2. Open housing by loosen the 2 Phillips head
screws located on the rear cap. Do not remove
the lower two screws on the rear cap.
3. Holding the housing base securely, grasp front
cap and cover, pull forward sliding the cover off
the base.
4. Remove camera mounting bracket by loosen two
retaining screws. Slide and lift bracket.
5. Attach camera and lens to bracket using ¼-20
screw. The position of the camera can be
adjusted by flipping the bracket. The lens must
not extend more than ¾” (0.750”) beyond the
front edge of the bracket.
6. Choose cable entry path for power and video.
Using ¾” wrench, install cable gland fittings
either in the rear cap or mounting foot depending
on the entry point chosen. Install plugs in the
holes not used for cable entry.
7. Attach power to connector terminal block. Block
mounting plate can be removed for ease of
installation by loosening two screws to slide and
lift the plate. Power must be connected to
terminals 2 and 3. Ground can be connected to
terminal 4 or optional installation by crimping
ground to ring terminal on the grounding stud.
Attach terminal block plate to housing base and
tighten screws.
8. Position camera into housing and attach black
and white wires to camera power terminal as
recommended by the camera manufacturer.
9. Attach video cable to camera or other device as
specified by the camera or device manufacturer.
10. Position cables to relieve excess stress and
tighten the cable gland fittings using ¾” wrench.
11. Slide cover into place, tighten two Phillips head
screws to secure.
12. If using sunshield accessory, attach sunshield
according to the instructions included with the
sunshield.
13. Attach housing to mounting bracket and set
position according to the instructions included
with the mount.
Grasp Here
Slide
Loosen
Screws
Do Not
Remove
