Broan VTTOUCHW Guide

CAUTION
Failure to comply with the following can cause erratic operation of the control and/or unit:
• Never install more than one main wall control per ventilation unit.
• Keep control low voltage wiring at least 1 foot (305 mm) away from motors, lighting balast, light dimming circuit
and power distribution panel. Do not route control wiring alongside house power wiring.
• Ensure the wires are securely connected.
Unplug the ventilation unit.
VC0255
Using the mounting plate, mark the
hole opening and screw locations at
the desired height on the wall.
VC0217
VC0219
Unscrew the screw located on the
underside of the wall control.
Separate the front module from the
mounting plate by lifting its bottom
part.
VC0244A
Ø 3/16", typ.
Cut the hole opening using the mark
previously drawn (1/8"outside the
mark is recommended). Drill both
screw holes (3/16" Ø) in wall and insert
the wall anchors (included).
Fix the mounting plate to the wall using the screws provided.
12V D- D+ Gnd
Strip the end of the cable to access
the 4 wires (about 3"). Strip the end of
each wire (about 1/4"). Connect the
wires to the terminals, regardless of
the wire color. Note which wire color
has been chosen for each terminal.
VC0218
Install the front module on the
mounting plate. Fix both parts by
screwing the screw on the underside
of the wall control.
Be careful not to pinch wires when reinstalling the front
module on the mounting plate.
CAUTION
Plug the ventilation unit in power source.
INSTALLATION AND USER Instructions FOR ADVANCED TOUCHSCREEN CONTROL
The illustrations in this document are generic; your control appearance may be slightly different from the ones shown.
Electrical wiring must be done by qualied personnel in accordance with all applicable codes and standards.
Before connecting wires, unplug the unit or switch power off at service panel and lock service disconnecting means
to prevent power from being switched on accidentally. Always wear safety glasses and gloves while performing
these instructions.
WARNING
!
This control is compatible with all AI series units.
Perform the electrical connection to the terminal connector
of the unit, as shown below. For more details, refer to the
installation manual of the ventilation unit.
12V D- D+ Gnd
VC0232
NOTE: To avoid miswiring, refer to the notes taken at step 
to match the wire color with the right terminal.
WALL CONTROL REAR VIEW
READ AND SAVE THESE INSTRUCTIONS
NOTE: If the control is to be installed in an electric box, do
not perform steps 3 and 4.
If ducts have to go through an unconditioned space (e.g.: attic), always use insulated ducts to prevent condensation
formation inside and outside ducts, which could cause material damage and/or mold growth. Moreover, if fresh air
to building duct and/or stale air from building duct goes/go through an unconditioned space, the unit must be set
to operate continuously in cold conditions (below 10°C/50°F). Continuous air movement inside ducts will prevent
condensation formation. The unit can be stopped temporarily for maintenance and/or repair purposes in such
conditions. (Refer to section 2.2 from unit User and Installer Manual for more details.)
CAUTION

TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE(S)SOLUTION(S)
The screen is not powered The ventilation unit is not powered Plug the ventilation unit
Miswiring/Damaged wire/Contact between wires Check wall control wiring
The connector J15a is not connected properly Check J15a connector connection
The wall control is not operational or defective Check if it uses the same isolated power circuit as
the unit on the electronic board
Replace the electronic assembly
The screen is powered but
displays error E50
Miswiring/Broken wire Check wall control wiring
The touch screen does not
work for all the keys
Defective control Replace the electronic assembly
NAVIGATION KEYS
To access next screen
To access previous screen
To confirm
To exit screen without saving
To get more information on the action(s) to perform on the corresponding screen
NOTES: Some features
may not be available on
all units. The temperature
displayed on ADVANCED
TOUCHSCREEN wall control
may vary by 5ºC (9ºF)
(more or less) compared to
the outside temperature
since the temperature
sensor is located inside the
unit to ensure a reading
that optimizes Virtuo Air
TechnologyTM algorithms.
AVAILABLE MODES
VC0247A
VC0249A
VC0248A,F
VC0251A
VC0252A
VC0250A
VC0253A
To access the Settings screen
Countdown for temporary modes To select the blower speed
To enable/disable humidity function and adjust set point
Will appear when RH exceeds selected set point
Will appear if maintenance is required or if an error triggered
Select the Smart* mode
Indicates the current mode
To access the Information screen
VC0254A
Select the Away
mode
VC0245A
PRELIMINARY SETTINGS
VC0246A
Set the Language and the Day and time
screens following your preferences.
* The SMART mode uses indoor
relative humidity level and
outdoor temperature to manage
the air exchange with the
outdoors, in order to enhance
comfort in the house. See graph
below.
From -35°C
to -25°C
From -25°C
to -15°C
From -15°C
to -5°C
From -5°C
to 5°C
From 5°C
to 15°C
From 15°C
to 25°C
From 25°C
to 35°C
80%
70%
60%
50%
30%
20%
40%
CONT
TURBO
*
