Brocade Communications Systems LS-STK User manual

53-1002187-01
18 February 2011
®
DRAFT: BROCADE CONFIDENTIAL
Brocade FastIron LS and
LS-STK
Hardware Installation Guide
Supporting Release 07.2.02

DRAFT: BROCADE CONFIDENTIAL
Copyright © 2011 Brocade Communications Systems, Inc. All Rights Reserved.
Brocade, the B-wing symbol, BigIron, DCX, Fabric OS, FastIron, IronPoint, IronShield, IronView, IronWare, JetCore, NetIron,
SecureIron, ServerIron, StorageX, and TurboIron are registered trademarks, and DCFM, Extraordinary Networks, and SAN Health
are trademarks of Brocade Communications Systems, Inc., in the United States and/or in other countries. All other brands,
products, or service names are or may be trademarks or service marks of, and are used to identify, products or services of their
respective owners.
Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning
any equipment, equipment feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to
this document at any time, without notice, and assumes no responsibility for its use. This informational document describes
features that may not be currently available. Contact a Brocade sales office for information on feature and product availability.
Export of technical data contained in this document may require an export license from the United States government.
The authors and Brocade Communications Systems, Inc. shall have no liability or responsibility to any person or entity with
respect to any loss, cost, liability, or damages arising from the information contained in this book or the computer programs that
accompany it.
The product described by this document may contain “open source” software covered by the GNU General Public License or other
open source license agreements. To find-out which open source software is included in Brocade products, view the licensing
terms applicable to the open source software, and obtain a copy of the programming source code, please visit
http://www.brocade.com/support/oscd.
Brocade Communications Systems, Incorporated
Document History
Corporate and Latin American Headquarters
Brocade Communications Systems, Inc.
130 Holger Way,
San Jose, CA 95134
Tel: [phone]
Fax: [phone]
E-mail: inf[email protected]
Asia-Pacific Headquarters
Brocade Communications Systems China HK, Ltd.
No. 1 Guanghua Road
Chao Yang District
Units 2718 and 2818
Beijing 100020, China
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
European Headquarters
Brocade Communications Switzerland Sàrl
Centre Swissair
Tour B - 4ème étage
29, Route de l'Aéroport
Case Postale 105
CH-1215 Genève 15
Switzerland
Tel: [phone]
Fax: [phone]
E-mail: emea-i[email protected]
Asia-Pacific Headquarters
Brocade Communications Systems Co., Ltd. (Shenzhen WFOE)
Citic Plaza
No. 233 Tian He Road North
Unit 1308 – 13th Floor
Guangzhou, China
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Title Publication number Summary of changes Date
Brocade FastIron LS and LS-STK
Hardware Installation Guide
53-1002187-01 New document February 2011

Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide iii
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL
Contents
About This Document
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Supported hardware and software . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Document conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Text formatting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Command syntax conventions . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Notes, cautions, and danger notices . . . . . . . . . . . . . . . . . . . . .viii
Notice to the reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Getting technical help or reporting errors . . . . . . . . . . . . . . . . . . . . . . ix
Web access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
E-mail and telephone access . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Chapter 1 Product Overview
Hardware features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FLS624, FLS648, FLS624-STK, FLS648-STK . . . . . . . . . . . . . . . 1
Control features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Fiber optic modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Power supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 2 Installing an FLS or FLS-STK device
Unpacking a system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Package contents for standalone FLS devices . . . . . . . . . . . . . . 9
Package contents for FLS-STK devices . . . . . . . . . . . . . . . . . . . . 9
General requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Summary of installation tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installation precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
General precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Lifting precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Power precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Preparing the installation site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cabling infrastructure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Installation location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Installing the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Desktop installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Rack mount installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connecting devices in a stack. . . . . . . . . . . . . . . . . . . . . . . . . . .15

iv Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL
Installing a redundant power supply . . . . . . . . . . . . . . . . . . . . . . . . . 17
About the RPS2-EIF redundant power supply . . . . . . . . . . . . . . 17
Installing a redundant power supply . . . . . . . . . . . . . . . . . . . . . . . . . 19
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Selecting a site. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Equipment checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Connecting devices to the redundant power supply . . . . . . . . .22
Ports pin-out (RPS2-EIF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Installing an optional module in the device . . . . . . . . . . . . . . . . . . .25
Installing an SFP transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Powering on the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Verifying proper operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Attaching a PC or terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Wiring map for serial cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Chapter 3 Stacking EEPROM and Memory Upgrade for FastIron LS Series
Devices
Upgrade kit contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Upgrading hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Upgrading software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Chapter 4 Connecting Network Devices and Checking Connectivity
Assigning permanent passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Recovering from a lost password . . . . . . . . . . . . . . . . . . . . . . . .38
Configuring IP addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Devices running layer 2 software . . . . . . . . . . . . . . . . . . . . . . . .39
Devices running base layer 3 software . . . . . . . . . . . . . . . . . . .40
Assigning an IP address to an Ethernet port . . . . . . . . . . . . . . .40
Connecting network devices . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Cable specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Connecting to Ethernet or fast Ethernet hubs . . . . . . . . . . . . . .42
Connecting to workstations, servers, or routers . . . . . . . . . . . .43
Connecting a network device to a fiber port . . . . . . . . . . . . . . .44
Testing connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Observing LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Troubleshooting network connections. . . . . . . . . . . . . . . . . . . . . . . .46
Chapter 5 Maintaining the FLS and FLS-STK Hardware
Managing FastIron LS temperature settings. . . . . . . . . . . . . . . . . . .49
Using the temperature sensor . . . . . . . . . . . . . . . . . . . . . . . . . .49
Displaying the temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Changing the temperature warning and shutdown levels . . . . 51
Changing the device temperature polling interval. . . . . . . . . . .52

Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide v
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL
Displaying FastIron LS CPU usage . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Hardware maintenance schedule . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Installing or replacing a 10 Gbps Ethernet module . . . . . . . . . . . . .53
Installing an optional module in the device . . . . . . . . . . . . . . . .53
Removing a 10 Gbps Ethernet module . . . . . . . . . . . . . . . . . . .54
Replacing a fiber optic module . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Installing a new fiber optic module. . . . . . . . . . . . . . . . . . . . . . .55
Cabling a fiber optic module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Cleaning the fiber optic connectors. . . . . . . . . . . . . . . . . . . . . . . . . . 56
Digital optical monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Chapter 6 Troubleshooting
Diagnosing device indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Power and cooling problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
In-band access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Chapter 7 Hardware Specifications
FastIron LS and LS-STK specifications . . . . . . . . . . . . . . . . . . . . . . .59
Physical dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Environmental considerations . . . . . . . . . . . . . . . . . . . . . . . . . .59
Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Regulatory compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Pinouts and signaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Cable specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
AC power supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Power cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Redundant power supply specifications . . . . . . . . . . . . . . . . . . . . . .66
Key features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Physical dimensions and weight. . . . . . . . . . . . . . . . . . . . . . . . .67
Input connector specifications . . . . . . . . . . . . . . . . . . . . . . . . . .67
Regulatory compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Appendix A Regulatory Statements
USA (FCC CFR 47 Part 15 Warning) . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Industry Canada statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Europe and Australia (CISPR 22 Class A Warning) . . . . . . . . . . . . . . 71
Japan (VCCI). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Japan power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Russia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Regulatory compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

vi Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL
Appendix B Caution and Danger Notices
Caution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Danger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide vii
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL
About This Document
Audience
This document is designed for system administrators with a working knowledge of Layer 2 and
Layer 3 switching and routing.
If you are using a Brocade Layer 3 device, you should be familiar with the following protocols if
applicable to your network – IP, RIP, OSPF, BGP, ISIS, IGMP, PIM, DVMRP, and VRRP.
Supported hardware and software
Although many different software and hardware configurations are tested and supported by
Brocade Communications Systems, Inc., documenting all possible configurations and scenarios is
beyond the scope of this document.
The following hardware platforms are supported by this release of this guide:
•FLS 624 with option for up to three 1-port 10 Gbps Ethernet modules
•FLS 648 with option for up to two 1-port 10 Gbps Ethernet modules
•FLS 624-STK stackable device with option for up to three 1-port 10 Gbps Ethernet modules
•FLS 648-STK stackable device with option for up to two 1-port 10 Gbps Ethernet modules
Document conventions
Text formatting
The narrative-text formatting conventions that are used are listed below.
Command lettercase is usually all lowercase. This manual specifically notes cases where a
command is case sensitive.
bold text Identifies command names
Identifies the names of user-manipulated GUI elements
Identifies keywords
Identifies text to enter at the GUI or CLI
italic text Provides emphasis
Identifies variables
Identifies document titles
code text Identifies CLI output

viii Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL
.Command syntax conventions
Command syntax in this manual follows these conventions:
Notes, cautions, and danger notices
The following notices and statements are used in this manual. They are listed below in order of
increasing severity of potential hazards.
NOTE
A note provides a tip, guidance or advice, emphasizes important information, or provides a reference
to related information.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you or cause
damage to hardware, firmware, software, or data.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or extremely
hazardous to you. Safety labels are also attached directly to products to warn of these conditions
or situations.
Notice to the reader
This document may contain references to the trademarks of the following corporations. These
trademarks are the properties of their respective companies and corporations.
These references are made for informational purposes only.
command and
parameters
Commands and parameters are printed in bold.
[ ] Optional parameter.
variable Variables are printed in italics enclosed in angled brackets < >.
... Repeat the previous element, for example “member[;member...]”
| Choose from one of the parameters.
Corporation Referenced Trademarks and Products
Phillips Screw Company, Inc Phillips

Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide ix
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL
Related publications
The following Brocade documents supplement the information in this guide:
•FastIron Configuration Guide
•IronWare MIB Reference
NOTE
For the latest edition of these documents, which contain the most up-to-date information, see
Product Manuals at kp.foundrynet.com.
Getting technical help or reporting errors
Brocade is committed to ensuring that your investment in our products remains cost-effective. If
you need assistance or find errors in the manuals, contact Brocade using one of the following
options.
Web access
The Knowledge Portal (KP) contains the latest version of this guide and other user guides for the
product. You can also report errors on the KP.
Log in to my.Brocade.com, click the Product Documentation tab, then click on the link to the
Knowledge Portal (KP). Then click on Cases >Create a New Ticket to report an error. Make sure you
specify the document title in the ticket description.
E-mail and telephone access
Go to http://www.brocade.com/services-support/index.page for the latest e-mail and telephone
contact information.

x Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL

Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide 1
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL
Chapter
1
Product Overview
Hardware features
The FastIron LS and LS-STK Series includes the following models:
•FastIron LS 624 with option for up to three 1-port 10 Gbps Ethernet modules
•FastIron LS 648 with option for up to two 1-port 10 Gbps Ethernet modules
•FastIron LS 624-STK stackable device with option for up to three 1-port 10 Gbps Ethernet
modules
•FastIron LS 648-STK stackable device with option for up to two 1-port 10 Gbps Ethernet
modules
All models support an optional external redundant AC power supply that can power up to four units.
The following sections describe the physical characteristics of the FastIron LS and LS-STK models.
For more details about physical dimensions, power supply specifications, and pinouts, see Chapter
7, “Hardware Specifications”.
FLS624, FLS648, FLS624-STK, FLS648-STK
FastIron LS and LS-STK devices provide high 10/100/1000 Mbps RJ45 port density and 10 Gbps
Ethernet uplinks in a compact form factor:
•The FLS624 has 20 10/100/1000 Mbps RJ45 ports and four 100/1000 SFP slots, a front
panel slot for an optional 10 Gbps CX4 module, two rear-panel 10 Gbps uplink module slots,
and a redundant power socket.
•The FLS648 has 44 10/100/1000 Mbps RJ45 ports and four 100/1000 SFP slots, two
rear-panel 10 Gbps uplink module slots, and a redundant power socket.
•The FLS624-STK has 20 10/100/1000 Mbps RJ45 ports and four 100/1000 SFP slots, one
front-panel slot for an optional 10 Gbps CX4 module, two rear-panel 10 Gbps uplink modules
and a redundant power socket.
•The FLS648-STK has 44 10/100/1000 Mbps RJ45 ports and four Gbps SFP slots, two
rear-panel 10 Gbps uplink module slots, and a redundant power socket.
The following figures show the front and rear panels of the FastIron LS and LS -STK models.
FIGURE 1 FastIron LS 624 and FastIron LS 624-STK front panel
FLS 624
Fastlron LS 624

2 Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide
53-1002187-01
Hardware features
1
DRAFT: BROCADE CONFIDENTIAL
FIGURE 2 FastIron LS 648 and FastIron LS 648-STK front panel
FIGURE 3 FastIron LS 624 and 648 rear panel
FIGURE 4 FastIron LS 624 or FastIron LS 624-STK front panel with optional module installed
FIGURE 5 FastIron LS 624-STK and FastIron LS 648-STK rear panel
Control features
The front panel on each device includes the following control features:
•Serial management interface (the port labeled Console)
•Reset button
Serial management interface (Console port)
The serial management interface allows you to configure and manage the device using a
third-party terminal emulation application on a directly connected PC. A straight-through EIA or TIA
DB-9 serial cable (M or F) ships with the device. The serial management interface (the Console
port) is located in the right corner of the front panel.
Reset button
The reset button allows you to restart the system without removing power or using the CLI or Web
Management Interface. The button is located to the left of the serial management interface and is
recessed to prevent it from being pushed accidentally.
FastIron LS and LS-STK network interfaces
FLS and FLS-STK devices provide the following interfaces:
•10/100/1000 Mbps ports with RJ45 copper connectors
•100/1000 Mbps ports with mini-GBIC slots for SFP MSA-compliant fiber transceivers
45 484746
Fastlron LS 648
FLS 648
RPSDCIn12V 13A
100-240V~
50-60Hz 2A
FLS 624
Fastlron LS 624
RPSDCIn12V 13A
100-240V~
50-60Hz 2A

Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide 3
53-1002187-01
Hardware features 1
DRAFT: BROCADE CONFIDENTIAL
•Optional 10 Gbps uplink modules (not available for FastIron LS 648-STK models)
For information about the type of fiber optic modules supported, see “Fiber optic modules” on
page 7.
FastIron LS and LS-STK 10/100/1000BASE-T ports
FLS and FLS-STK devicees contain 24 or 48 ports that operate at 10 Mbps or 100 Mbps, half or full
duplex, or at 1000 Mbps, full duplex. Because all ports on these devicees support automatic
MDI/MDI-X operation, you can use straight-through cables for all network connections to PCs or
servers, or to other devicees or hubs. (Refer to “Pinouts and signaling” on page 63.) It is best to use
MDIX cable for device-to-device connections.
Each of these ports support auto-negotiation, so the optimum transmission mode (half or full
duplex), and data rate (10, 100, or 1000 Mbps) can be selected automatically. If a device
connected to one of these ports does not support auto-negotiation, the communication mode of
that port can be configured manually.
Network interfaces
Table 1 describes the network interfaces supported on FastIron LS devices.
TABLE 1 Supported network interfaces
Interface Show media description
1000Base-BX-D M-GBXD
1000Base-BX-U M-GBXU
1000Base-LHA M-LHA
1000Base-LHB M-LHB
1000Base-LX M-LX
1000Base-SX M-SX
1000Base-SX2 M-SX2
1000Base-T C
100Base-BX M-FBX
100Base-FX M-FX
10GBase-CX4 XG-ER
10GBase-CX4 (XFP) XG-ER
10GBase-ER XG-ER
10GBase-LR XG-LR
10GBase-LRM XG-LRM
10GBase-SR XG-SR
10GBase-ZR XG-ZR
10GBase-ZRD XG-ZRD
1310-MMF 10GbE 1310-NM

4 Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide
53-1002187-01
Hardware features
1
DRAFT: BROCADE CONFIDENTIAL
10 Gbps Ethernet module slots for standalone devices
FLS 624 and FLS 648 standalone devices include two slots on the rear panel for single-port
10GBASE uplink modules with XFP transceivers, and a single port CX4 module. The 10GBASE
transceivers operate at 10 Gbps full duplex with support for asymmetric flow control (that is, the
port honors incoming pause frames, but does not originate pause frames).
10 Gbps Ethernet module slots for stacking devices
FLS 624-STK and FLS 648-STK devices include two 10 Gbps Ethernet CX4 modules on the rear
panel (the stacking ports). The FLS 624-STK has an additional slot on the front panel that supports
an optional 10 Gbps CX4 module.
10 Gbps CX4 ports
The single-port CX4 module is installed in the FLS 624 and FLS 648 (shown in Figure 6). You can
order the FastIron LS with a single-port CX4 module pre-installed, or you can upgrade your device at
a later time. This module is a 10 GbE-CX4 Ethernet uplink card, capable of performing data
transmission directly through copper links to 15m (extended 30m) in length.
Single-port CX4 uplink for 10 Gbps is supported.
Link and Activity LEDs on the module faceplates indicate operational status:
•If the Link LED is on, the port is connected. If the Link LED is off, no connection exists, or the
link is down.
•If the Act LED is on or blinking, traffic is being transmitted and received on the port. If the Act
LED is off, no traffic is being transmitted or received on the port.
FIGURE 6 Single-port 10 Gbps Ethernet CX4 module
Cable specifications
The following cable specifications apply to the CX4 port in the 10GbE interface module (FLS-1XGC):
•Support for 802.3ak or 10 Gbps Ethernet CX4 standard
•Support for cables up to 15m in length
•Requires latch-style receptacle or SFF-8470 plug
•Recommended CX4 cable is manufactured by WL Gore, part number IBN6600-15, CX4
Assembly - 26AWG SPC 15.0m
NOTE
The recommended CX4 cable can also be used with a Small Form Factor Pluggable (XFP)
MSA-compliant optical transceiver (part number FLS-1XGC).
Figure 7 shows the CX4-grade cable.

Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide 5
53-1002187-01
Hardware features 1
DRAFT: BROCADE CONFIDENTIAL
FIGURE 7 CX4 transceiver cable
FIGURE 8 CX4 slide-in transceiver
Port, system, and module status LEDs
FastIron LS and LS-STK devices include key system and port indicators to simplify installation and
network troubleshooting. These LEDs, located on the front panel for easy viewing, are shown in
Figure 9 and described in the following tables.
FIGURE 9 Port status LEDs
1 Port status LED
TABLE 2 Port status LEDs
LED Status Status
Link/
Activity or Speed
On or Flashing Amber Port has a valid link at 10 or 100 Mbps. Flashing indicates activity.
On or Flashing Green Port has a valid link at 1000 Mbps. Flashing indicates activity.
Off The link is down.
1

6 Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide
53-1002187-01
Hardware features
1
DRAFT: BROCADE CONFIDENTIAL
FIGURE 10 System status LEDs
1SystemstatusLED
TABLE 3 System status LEDs
LED Condition Status
Power Green Internal power is operating normally.
Amber Internal power supply failure.
Off Power off or failure.
Diag Green System self-diagnostic test successfully completed.
Amber System self-diagnostic test has detected a fault.
RPS Green Redundant power supply is providing power.
Amber Primary power supply is active, RPS is on standby.
Off Redundant power supply is off or not plugged in.
Stack Active
controller
Green Device is the Active Controller of the stack. State may include topology
discovery, IP assignment, or normal operations.
Flashing Green Device is the Active Controller of the stack, system is initializing.
Amber Device is operating as a Standby Controller in the stack.
Flashing Amber System in Active Controller arbitration or election state.
Off System in standalone mode.
Stack Link Green Uplink and downlink operating normally.
Flashing Green Uplink has failed.
Flashing Amber Downlink has failed.
Off No stacking link present.
Module Green An expansion module is installed and operating normally.
Amber An expansion module is installed but has failed.
Off There is no module installed.
Stack ID 1-8 Indicates the device stack ID.
The Active Controller is numbered 1. (Note that If the Active Controller
fails and a backup unit takes over, the stack IDs do not change.)
The Standby Controller is numbered 2. The remaining stack members
are numbered 3-8.
0 A standalone device. A device with a stack ID of 0 cannot act as part
of a stack.
1
FLS 624
Fastlron LS 624

Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide 7
53-1002187-01
Hardware features 1
DRAFT: BROCADE CONFIDENTIAL
FIGURE 11 Module Link/Activity LED
Fiber optic modules
A list of the types of fiber optic modules supported on Layer 2 Compact devicees can be found in
“Cable specifications” on page 64
NOTE
Some older SFP modules (mini-GBICs for Gbps Ethernet ports) have latching mechanisms that are
larger than the newer parts. These latches could interfere with one another when inserted side by
side in the same module. These older modules are identified by the number PL-XPL-00-S13-22 or
PL-XPL-00-L13-23 above the serial number. All newer mini-GBICs do not have this limitation.
DANGER
All fiber optic interfaces use Class 1 lasers.
Power supplies
There are two power receptacles on the rear panel of each device. The standard power receptacle
is for the AC power cable. The receptacle labeled “RPS” is for the optional redundant power supply.
Optional redundant power supply
The device supports an optional redundant power supply (RPS), that can supply power in the event
the internal power supply fails.
Power supply receptacles
There are two power receptacles on the rear panel of each device. The standard power receptacle
is for the AC power cable. The receptacle labeled “RPS” is for the optional redundant power supply.
1 Link/Activity LED
TABLE 4 Module Link/Activity LED
LED Condition Status
Link or Activity On Port has a valid link at 10 Gbps.
On or Flashing Green Flashing indicates activity.
Off The link is down.
1

8 Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide
53-1002187-01
Hardware features
1
DRAFT: BROCADE CONFIDENTIAL
FIGURE 12 Power supply receptacles
1 Redundant Power Socket
2 Power Socket
RPS DC In 12V 13A
100-240V~
50-60Hz 2A
1 2

Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide 9
53-1002187-01
DRAFT: BROCADE CONFIDENTIAL
Chapter
2
Installing an FLS or FLS-STK device
Unpacking a system
DANGER
The procedures in this manual are intended for qualified service personnel.
This chapter describes how to physically install a FastIron LS or FastIron LS-STK device.
For information about configuring IP addresses and connecting network devices, see Chapter 4,
“Connecting Network Devices and Checking Connectivity”.
For information about configuring an IronStack using FLS624-STK and FLS648-STK devices, see
the FastIron Configuration Guide.
Brocade FLS and FLS-STK devices ship with all of the items listed below. Please review this list and
verify the contents of your shipping container. If any items are missing, please contact the place of
purchase.
FLS624-STK and FLS648-STK devices come with a 0.5 meter 10GBASE CX4 cable.
Package contents for standalone FLS devices
Package contents for standalone FLS devices include:
•FastIron LS device
•115V AC power cable (for AC devices)
•Rack mount brackets
•Warranty card
Package contents for FLS-STK devices
Package contents for FLS-STK devices included:
•FastIron LS-STK device
•115V AC power cable (for AC devices)
•Rack mount brackets
•Warranty card
•10GBASE CX4 (FLS624-STK only)
•0.5m CX4 cable

10 Brocade FastIron LS and FastIron LS-STK Hardware Installation Guide
53-1002187-01
Summary of installation tasks
2
DRAFT: BROCADE CONFIDENTIAL
General requirements
To manage the system through a serial connection, you will need the following items:
•A management station, such as a PC running a terminal emulation application.
•A straight-through EIA or TIA DB-9 serial cable (F/F). The serial cable can be ordered separately
from Brocade. If you prefer build your own cable, see the pinout information in “Attaching a PC
or terminal” on page 27.
Use the serial connection to perform basic configuration tasks, including assigning an IP address
and network mask to the system. This information is required to manage the system using the Web
management interface or IronView or using the CLI through Telnet.
Summary of installation tasks
Follow the steps listed below to install your FastIron LS or LS-STK device. Details for each step are
provided in this chapter and in the following chapter.
TABLE 5 Installation tasks
Task
number
Task Where to find more information
1 Ensure that the physical environment that will host
the device has the proper cabling and ventilation.
“Preparing the installation site” on page 13
2 Install any required optional modules into the device. “Installing an optional module in the device”
on page 25
3 Install the Brocade device on a desktop, in an
equipment rack.
“Installing the device” on page 13
4 Connect stackable devices in an IronStack topology. “Connecting devices in a stack” on page 15
5 Once the device is physically installed, plug the
device into a nearby power source that adheres to
the regulatory requirements outlined in this manual.
“Powering on the system” on page 26
6 Verify that the system LEDs are registering the proper
LED state after power-on of the system.
“Verifying proper operation” on page 27
7 Attach a terminal or PC to the Brocade device. This
will enable you to configure the device through the
Command Line Interface (CLI).
“Attaching a PC or terminal” on page 27
8 No default password is assigned to the CLI. For
additional access security, assign a password.
“Assigning permanent passwords” on
page 37
9 Before attaching equipment to the device, you need
to configure an interface IP address to the subnet on
which it will be located. Initial IP address
configuration is performed using the CLI with a direct
serial connection. Subsequent IP address
configuration can be performed using the Web
management interface.
“Configuring IP addresses” on page 39
10 Once you power on the device and assign IP
addresses, the system is ready to accept network
equipment.
“Devices running base layer 3 software” on
page 40
