INSTRUCTION MANUAL
MEDIFRIDGE DISPLAY FRIDGE
MEDO220GD-NR
MEDO374GD-NR

CONTENTS
Note: Bromic Refrigeration reserves the right to make changes to specifications, parts, components and equipment without prior notification.
This Installation, operation and service manual may not be reproduced in any form with prior written consent from Bromic Refrigeration.
1. PREFIX
4
2. IMPORTANT NOTES & WARNINGS
5
3. PRODUCT OVERVIEW
7
4. INSTALLATION
8
5. OPERATION
10
6. PRODUCT LOADING AND STORAGE
12
7. MAINTENANCE
13
8. TROUBLESHOOTING
14
9. ENVIRONMENTAL & DISPOSAL NOTES
15
10. WARRANTY
16

4
1300 276 642bromicrefrigeration.com.au
1. PREFIX
This manual contains important information about the installation, operation, and maintenance
of Bromic MediFridge
TM
. Please pay close attention to the important safety information
shown throughout this instruction manual. Any safety information will be accompanied by the
following safety alert symbols:
DANGER, WARNING, IMPORTANT
• READ THIS MANUAL CAREFULLY before installing or
servicing this product.
• Improper installation, operation, or maintenance can result
in death, severe injury, or property damage.
• This appliance is intended for 230-240 Volt power supply.
• Installation MUST be carried out by a licensed and
authorised technician in accordance with local electrical
codes.
!
!
!
!
IMPORTANT
This Bromic MediFridge unit is intended for the storage of vaccine products under strict con-
trol. Refer to the “National Vaccine Storage Guidelines : Strive for 5” for more information on
vaccine storage and handling or contact your local state of territory health department.
(https://www.health.gov.au/resources/publications/national-vaccine-storage-guide-
lines-strive-for-5)
MIXING OF VACCINE PRODUCTS WITH OTHER PRODUCT TYPES IS NOT RECOMMENDED.
The loading procedure of fridges containing vaccines can be adversely aected by fluctua-
tions in temperature. All product stored shall be pre-chilled prior to loading and door opening
duration minimised.
Refer to instructions and guidelines under “Section 4. Installation guidelines” and “Section 6.
Product Loading and Storage” for important information about the correct setup and use.
The manufacturer is not responsible for any damage that could happen from improper use.
The manufacturer emphasises that this appliance should be used in a responsible manner and
that all procedures, warnings, and safety instructions contained in this booklet be followed
strictly.

5
1300 276 642 bromicrefrigeration.com.au
• Read all instructions before installing or using this appliance.
• Retain this manual for future reference.
• Use this appliance only as described in this manual. Any other use not recommended by the manufacturer
may cause fire, electric shock or injury.
• Improper installation, adjustment or alteration and failure to follow the warnings and instructions in this
manual could result in severe personal injury, death or property damage.
• The manufacturer is not responsible for any damage that could happen from improper use. The manufacturer
emphasises that this appliance should be used in a responsible manner and that all procedures, warnings,
and safety instructions contained in this booklet be followed strictly.
• Check for damage to the appliance regularly. If damage to the appliance is suspected, discontinue use
immediately and contact the supplier or qualified person to repair.
• This appliance is not intended for use by people (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible of their safety.
• Keep packaging material out reach of children.
• Children should be carefully supervised to ensure that they do not play with the appliance.
• Do not attempt to alter the appliance in any manner.
• Please pay attention to the maximum load limit when filling the baskets.
• All work on electrical equipment must be carried out by a qualified and licensed technician only.
• Do not perform maintenance until the appliance has been turned o and power disconnected.
• Never detach any cover except where specifically instructed in this manual. Doing so might expose live
electrical parts.
• Do not operate the appliance with panels, covers or guards removed.
• Keep the air intake and outlets free of obstructions.
• Do not use the appliance outdoors.
• If the supply cord becomes damaged, it must be replaced by an authorised service agent or similarly
qualified person in order to avoid a hazard.
• If the appliance has not been used, or will not be used for a long period of time, disconnect
power supply.
• Electrical equipment should not be placed under the unit or where refrigerant could gather in the event of a
leak.
• Always use original spare parts supplied by the manufacturer
• When contacting Bromic Customer Service, ensure that you have the Model, Serial Number available. The
information can be found from the rating plate which is located outside the appliance.
• Unplug the appliance before cleaning or moving it to avoid electric shock.
• Never use steam cleaner or wet cloths to clean the control panel, lighting and vent grills. This may damage
the appliance or cause electric shock.
• The power plug must be accessible at all times while the appliance is running.
• The power supply must be properly earthed, consult a qualified electrician if unsure.
• Do not use extension cord or power adapter with this appliance.
• Do not use this appliance in an area with high humidity or subject to water damage
2. IMPORTANT NOTES AND WARNINGS

6
1300 276 642bromicrefrigeration.com.au
• WARNING: The refrigerant (R600a Iso-Butane) used in this appliance is flammable, use caution during
handling, servicing and disposal of the appliance.
• WARNING: Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
• WARNING: Keep clear of obstruction all ventilation openings in the appliance enclosure or in the structure
for building-in.
• WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than
those recommended by the manufacturer.
• WARNING: Ensure that the tubing of the refrigerant circuit is not damaged during transportation and
installation, consult Authorised Personnel is unsure
• WARNING: If the refrigeration circuit becomes damaged. Avoid open flames and other source of ignition.
Immediately disconnect the appliance from power supply. Ventilate the room and call Service Hotline.
• WARNING: Leaking refrigerant may cause eye injuries or could ignite.
• WARNING: The room for installing the appliance must be at least 1m³ per 8g of refrigerant. The amount of
refrigerant in the appliance can be found on the rating plate attached to the appliance.
• WARNING: Do not use electrical appliances inside the food/ice storage compartments unless they are of the
type recommended by the manufacturer.
• WARNING: In order to reduce flammability hazards, all service work of this appliance must only be carried
out by an Authorised Service Person. In Queensland, the Authorised Service Person must hold a Gas Work
Authorisation to service appliances containing Hydrocarbon refrigerant including removal of covers.
Warning: Risk of fire /
Flammable materials

7
1300 276 642 bromicrefrigeration.com.au
3. PRODUCT OVERVIEW
MED0220GD-NR
3736217-NR
MED0374GD-NR
3736218-NR
Feature Unit, Brand, Description Data Data
External Dimension
Height, mm 1310 1840
Width, mm 595 595
Depth, mm 598 598
Internal Dimension
Height, mm 1025 1555
Width, mm 505 505
Depth, mm 462 462
Capacity Litres 215 372
Weight Kg 63 81
Air Circulation Fan-Forced Fan-Forced
Climate Class 44
Temperature
Range +2°C to 8°C +2°C to 8°C
Min/Max Temp Recorder Yes
Yes
Display Digital Digital
Exterior Material Powder coated sheet metal Powder coated sheet metal
Electrical
Voltage, V 240 240
Frequency, Hz 50 50
Input Power, W 235 350
Current, A 1.18 1.23
Door
Solid or Glass Low-E Glass + Argon Gas Low-E Glass + Argon Gas
Shape Flat Flat
Self-Closing Yes Yes
Door Lock Yes Yes
Door Switch Yes Yes
Shelves
Qty 4 6
Type Open rung shelf Open rung shelf
Depth, mm 400 400
Adjustable Ye s Ye s
Capacity, kg 20 20
Internal Lighting Internal Light Yes Yes
Alarms
Temperature Yes Yes
Audible Yes Yes
Compressor Refrigerant R600a R600a
Charge, g 70 70
Defrost
Type O Cycle O Cycle
Manual/Automatic Automatic Automatic
Plug Type 3-pin AU plug 10A 3-pin AU plug 10A
Feet/Wheels Type 2 rollers at rear, 2 feet at front 2 rollers at rear, 2 feet at front

8
1300 276 642bromicrefrigeration.com.au
4. INSTALLATION
Locating the Cabinet
Ensure the following instructions are observed as this is vital for proper and trouble-free operation.
• Do not install the cabinet outdoors.
• Locate the appliance in a dry and well ventilated place.
• The unit is a commercial designed product, Do not install in noise sensitive areas.
• The unit must be positioned on a level surface.
• Do not install in the vicinity of heating radiators or other heat sources.
• Do not install the appliance where it is exposed to direct sunlight.
• Do not install the appliance where it is exposed to warm draughts or open doors.
• Keep the air intake and outlets free of obstructions.
• Adequate allowance should be made for door openings.
Ventilation
Ensure the following instructions are observed as this is vital for proper and trouble-free operation.
• Allow 150mm clearance between walls and the appliance.
• Ensure that the condenser fan is free to take in ambient air from the room.
• Adherence to minimum clearances is necessary
NOTE: The maximum ambient temperature for the refrigerator is 30°C. Conditions
outside this temperature will result in cabinet temperatures outside the required 2
to 8°C range. Bromic recommends that the refrigerator is installed at an ambient
temperature of 20 to 25°C and relative humidity of 55%.

9
1300 276 642 bromicrefrigeration.com.au
Power Supply
• The appliance must not be plugged into a multiple outlet power board.
• The appliance is supplied with a flexible power cord fitted with a 3-pin plug.
• The socket used must be properly earthed and fuse protected.
• See the rating label inside the cabinet for supply voltage, frequency and current draw.
• Power cable is rated 70°C. It is recommended that the cable should not come into contact
with parts over 50°C.
• Do not turn o power before consulting the person responsible.
• Mark the power source clearly, so the refrigerator is not unplugged or turned o
accidentally.
Before Operating
• If the appliance has been sharply tilted or transported in the horizontal position, it must
be left to stand in the upright position and not plugged in for 1 hour.
• Remove all the packaging material before using the appliance.
• Start the appliance only if it has been installed as described.

10
1300 276 642bromicrefrigeration.com.au
5. OPERATION
Start-up
• Connect the appliance to the mains power supply and check that the compressor,
electronic controller, lighting and all fans are functioning correctly.
• The compressor and condenser fan should operate should operate 3 minutes after the unit
has been connected to the power supply.
• The evaporator fan should operate after the unit has been plugged in.
• The electronic controller will display the current cabinet temperature after the unit has
been connected to the power supply.
• The LED indicates that refrigeration circuit is operating.
• During the start-up delay (3 minutes), the LED is flashing
Setting the temperature
NOTE: The controller is factory set at 4°C. The controller is programmed to control cabinet
temperatures between 2 to 8°C.
Controller settings are locked to maintain correct temperature conditions for vaccine products and
can only be changed by Bromic authorised service agents.
Operating the light
i. Set the 0-1 switch to the ‘1’ position.

11
1300 276 642 bromicrefrigeration.com.au
Controller Alarms
If alarms persist, contact the manufacturer or an approved service agent.
Code Alarm Type Corrective Action
HA Cabinet high temperature alarm
• Check Installation and operation of unit
as per instructions
• Check if there is adequate ventilation
• Check if there is free circulation of air
inside the cabinet
• Check and clean condenser coil and fan
• Check if door is shut
LA Cabinet low temperature alarm
P1 Cabinet probe failure • Unplug the unit for 1 minute then
reconnect to power
MAX/MIN temperature recording
IMPORTANT: Record the maximum and minimum temperatures two (2) times a day.
Recordings should be taken before the first door opening of the day.
MIN Temperature
i. Press the arrow key.
ii. The ‘Lo’ message will be displayed followed by the minimum temperature recorded.
iii. Press the arrow key again or wait 5 seconds – the normal display will be displayed.
MAX Temperature
i. Press the arrow key.
ii. The ‘Hi’ message will be displayed followed by the maximum temperature recorded.
iii. Press the arrow key again or wait 5 seconds – the normal temperature will be
displayed.
Reset MAX/MIN temperature recorded
i. While the MAX or MIN temperature recorded is displayed – press the key for more
than 3 seconds. The ‘rSt’ message will be displayed.
ii. The ‘rSt’ message will start blinking and the normal temperature will be displayed.

12
1300 276 642bromicrefrigeration.com.au
6. PRODUCT LOADING AND STORAGE
Start-up
• Clean the interior surface with a soft cloth and warm water before loading.
• Position top and bottom shelves at marked locations to maintain correct air flow in unit.
• Recommend placement of product on centre of shelves or evenly distributed on shelfs with
minimum 30mm air gap between containers or use of perforated baskets.
• Never stack containers and do not load unit excessively whereby air flow across the cabinet is
restricted.
• Do not load product above the top shelf load line marked on the side of the cabinet.
• Do not block the evaporator fan.
• Use cold mass (i.e. 300ml saline water bottles) on unused shelves and ensure containers are
separated by 30mm on all sides. This is essential for maintaining correct storage temperature
during door openings.
• Avoid partial shelf loading, use cold mass on unused space
• Use cold mass (i.e. water bottle) on unused shelves.
• Keep refrigerator door openings to a minimum. Limit door opening durations to less than
30seconds. Wait 10 minutes for product and cabinet temperature to stabilise before opening
door again.
• Ensure products and materials are between 2 and 8°C before loading – if there is a breach in the
cold-chain, isolate the aected products. Do not use or discard until advice is given.
• Some products are sensitive to ultraviolet (UV) light, please see storage guidelines from the
manufacturer before removing from packaging.
• Do not store food and other goods in the refrigerator.
• Do not change controller settings. This is essential for maintaining correct storage temperature.
• Maximum recommended shelf load is 20kg.
NOTE: Bromic cannot be responsible for loss of stock or damage to stock.
Please refer to the ‘National Vaccine Storage Guidelines: Strive for 5’ for more information on
vaccine storage and handling or contact your local state or territory health department.
(https://www.health.gov.au/resources/publications/national-vaccine-storage-guidelines-strive-for-5)
WARNING: Failure to follow the guidelines below will result in cabinet
temperatures below 2°C and above 8°C
IMPORTANT: Run the refrigerator for at least 2 hours before loading.

13
1300 276 642 bromicrefrigeration.com.au
Extended Defrosting
The evaporator (cooling) coil of the refrigerator may build up a layer of ice over time. This will
reduce the performance of the unit – inspect the evaporator coil for ice build-up regularly.
For extended defrosting, turn o the unit with the door opened for a period of 24 hours.
Condenser Coil
IMPORTANT: The condenser coil must be cleaned with a vacuum or brush once a
month. The condenser coil must be cleaned regularly to maintain the performance
and minimise power consumption. A poorly maintained condenser coil can lead to
failure of the unit and cabinet temperatures above 8°C.
7. MAINTENANCE
Cleaning the Cabinet
• Remove the products and transfer to a suitable location prior to cleaning the inside of the
cabinet.
• Do not use any aggressive or abrasive cleaning agents.
• Never use a water hose or a high-pressure jet to clean.
• Do not use sharp or pointed objects for cleaning.
• Clean the inside and outside of the appliance with a clean damp cloth or with a neutral
cleanser.
• Dry all surfaces with a dry cloth.
WARNING: Disconnect the appliance from the power supply before performing any
maintenance. Never unplug the appliance by pulling on the cord. Always grasp the
plug firmly and pull straight out of the outlet.
WARNING: Exposure to significant water ingress will void warranty and cause
potential safety issues. If the unit should be exposed to water, please contact the
manufacturer immediately.
IMPORTANT: Warranty may be void if there is no evidence of preventative
maintenance is performed on the appliance.

14
1300 276 642bromicrefrigeration.com.au
8. TROUBLESHOOTING
IMPORTANT: Repairs on the unit must be carried out by an authorised and licensed
person only. Contact the manufacturer or an approved service agent for any repairs
needed.
Symptom Possible Cause(s)
Unit does not work A. No power supply A. Check power supply
Cabinet
Temperature
Too High
A. Ambient temperature too high
B. Inadequate ventilation
C. Wall clearances below minimum
distance
D. Dirty condenser coil
E. Ice build-up on evaporator coil
A. Relocate unit
B. Keep ventilation slots free
C. Adjust to minimum clearance
D. Clean
E. Perform extended defrosting
Cabinet
Temperature
Too Low
A. Set temperature too low A. Adjust set temperature
Cabinet lights
not working
A. Light not switched on
B. Light is faulty
A. Switch on
B. Replace light
Drip tray
overflowing
A. Extreme operating condition A. Relocate unit
Odour inside
cabinet
A. Cabinet dirty A. Clean
Cabinet too noisy A. Move cabinet to an area that is
not noise sensitive

15
1300 276 642 bromicrefrigeration.com.au
9. ENVIRONMENTAL AND DISPOSAL NOTES
These refrigerated cabinets are designed to high standards of environmental protection and
recycling convenience. Cyclopentane, an environmentally friendly foaming agent, has been
used. Cyclopentane is distinguished by zero ozone depletion potential (ODP) and zero global
warming potential (GWP). The refrigerant used and contained within a hermetically tight
circuit is environmentally friendly and does not contain chlorine and zero ODP.
The device must be disposed of in accordance with applicable regulations. The WEEE
regulations must be observed.
In the interest of preventing environmental nuisance and promoting re-use of the high quality
materials employed, used commercial refrigeration equipment must be collected for expert
disposal and recycling. Therefore, observe the following disposal regulations:
• The cabinet must not be discarded with regular waste.
• The refrigeration circuit must not be damaged.
• Before disposal, make it unserviceable by disconnecting the power plug and cutting o
the power cable.
• Consult your local authorities or authorised dealers for details of collection and disposal
facilities.
• Children are often unable to recognise the dangers associated with commercial
refrigeration equipment. Proper supervision must be maintained and children must be
prevented from playing with discarded refrigerated cabinets.
• The refrigerant used in this appliance is flammable. The refrigeration circuit must not be
damaged.
Warning: Risk of fire /
Flammable materials

16
1300 276 642bromicrefrigeration.com.au
10. WARRANTY
Read all relevant documentations before operating the refrigerator and storage of any stock.
Failure to follow instructions may result in loss of or damage to stock.
Please refer to the ‘National Vaccine Storage Guidelines: Strive for 5’ for more information on vaccine
storage and handling or contact your local state or territory health department.
(https://www.health.gov.au/resources/publications/national-vaccine-storage-guidelines-strive-for-5)
BROMIC CANNOT BE RESPONSIBLE FOR THE LOSS OF OR DAMAGE TO STOCK
All Bromic products are manufactured
to the highest quality standard and are
supported by our Extra Care Service Warranty,
including guarantees against any material or
workmanship defects; guarantees that cannot
be excluded under Australian Consumer Law.
Warranty Terms vary across the range. Please ensure you are familiar with the Terms and Conditions
that apply to the purchase of your Bromic product by referring to the Warranty Policy included with
your purchased product.
Alternatively, you can also download the Warranty Policy at
www.bromicgroup.com/warranty-information

17
1300 276 642 bromicrefrigeration.com.au
HOW TO PLACE A SERVICE REQUEST
• Please call 1300 276 642 to place a warranty service request and let the operator know whether
you need Priority A or B service. More information can be found below.
• Ensure you have the serial number of your product ready before contacting us.
• The serial number of your product can be found on a compliance plate located on the inside right
and at the rear of your cabinet.
Compliance Plate Example 1
SERVICE REQUEST PRIORITY
A
B
PRIORITY ASERVICE
PRIORITY BSERVICE
SERVICE CALL PLACED BEFORE MIDDAY
SERVICE CALL PLACED AFTER MIDDAY
When the unit is NOT performing its primary function such as
cooling or heating, or presents an OH&S or food safety risk
When the unit is performing its primary function, and presents
no OH&S or food safety risk. i.e. lights, gaskets. locks, door
adjustment
Priority A - Technician to attend site within 4 hours
Priority B - Technician to attend site within 8 business hours
Priority A - Technician attends site before midday on the
following business day
Priority B - Technician attends site before 4pm on the
following business day

NOTES

10 Phiney Place, Ingleburn
NSW 2565 Australia
T: AU 1300 276 642
F: ([phone]
E: [e-mail]
SYDNEY HEAD OFFICE & SHOWROOM
BROMIC REFRIGERATION
10 Phiney Place, Ingleburn (Sydney)
NSW 2565 Australia
T. 1300 276 642
For further product information
bromicrefrigeration.com.au
BROMIC REFRIGERATION
10 Phiney Place, Ingleburn (Sydney)
NSW 2565 Australia
T. 1300 276 642
For further product information
bromicrefrigeration.com.au
