SPARE PARTS FOR KE-430Ｃ-1
NAME P/NO. Q'TY
SCREW 3.57 144458001 2
COUPLING HUB 8 S37942100 2
COUPLING HUB 6.35 S37943100 2
COUPLING SPACER S37944000 5
SET SCREW,SOCKET(CP)SM5.95 014760622 8
WORK CLAMP(R) 152777001 1
WORK CLAMP(L) 152778001 1
FEED PLATE S49698001 1
SNAP PIN S37968001 7
THREAD WIPER(A) 156206001 1
SCREW, PAN SM3.57-40X5 062670512 1
SHUTTLE RACE THREAD GUIDE S02429101 1
SCREW, PAN SM3.18-40X4 062660412 2
DRIVER 152681201 1
LARGE SHUTTLE HOOK (A) 152682101 1
SHUTTLE RACE RING A 152685903 1
BOBBIN CASE ASSY (A) 159610101 1
BOBBIN 159613001 4
TENSION SPRING 154339001 1
SCREW 154341001 1
ANTI-SPIN SPRING 159612001 1
SPRING 145519001 1
TENSION SPRING 104525001 1
RUBBER RING 120448001 1
MOVABLE KNIFE (N) ASSY S49988001 1
SCREW 4.37 S10209101 1
FIXED KNIFE S10210201 1
SCREW, SM2.38 111140002 2
SCREW, FLAT SM4.37 100032004 2
SCREW, SM4.37 153208002 2
NEEDLE HOLE PLATE(FM) S49980001 2
SCREW, FLAT SM2.38 100360003 2
TOTAL 61
SPARE PARTS FOR KE-430Ｃ-2
NAME P/NO. Q'TY
SCREW 3.57 144458001 2
COUPLING HUB 8 S37942100 2
COUPLING HUB 6.35 S37943100 2
COUPLING SPACER S37944000 2
SET SCREW,SOCKET(CP)SM5.95 014760622 4
WORK CLAMP(R) 153608101 1
WORK CLAMP(L) 154527001 1
FEED PLATE S49697001 1
SNAP PIN S37968001 3
THREAD WIPER(A) 156206001 1
SCREW, PAN SM3.57-40X5 062670512 1

SHUTTLE RACE THREAD GUIDE S02429101 1
SCREW, PAN SM3.18-40X4 062660412 2
DRIVER S55215001 1
SHUTTLE RACE RING (B) 152686101 1
INNER ROTARY HOOK(B) BOX ASSY SA1882101 1
BOBBIN CASE ASSY (B) 152690401 1
TENSION SPRING 154340101 1
SCREW 154341001 1
ANTI SPIN SPRING 154342001 1
BOBBIN 159613051 4
SPRING 144588001 1
TENSION SPRING 107606001 1
RUBBER RING 120448001 1
MOVABLE KNIFE (N) ASSY S49988001 1
SCREW 4.37 S10209101 1
FIXED KNIFE S10210201 1
SCREW, SM2.38 111140002 2
SCREW, FLAT SM4.37 100032004 2
SCREW, SM4.37 S11244001 2
NEEDLE HOLE PLATE(E) S10212101 1
SCREW, FLAT SM2.38 100360003 2
TOTAL 49
SPARE PARTS FOR KE-430Ｃ-5
NAME P/NO. Q'TY
SCREW 3.57 144458001 2
COUPLING HUB 8 S37942100 2
COUPLING HUB 6.35 S37943100 2
COUPLING SPACER S37944000 5
SET SCREW,SOCKET(CP)SM5.95 014760622 8
WORK CLAMP(R) 152779001 1
WORK CLAMP(L) 152780001 1
FEED PLATE S49698001 1
SNAP PIN S37968001 7
THREAD WIPER(A) 156206001 1
SCREW, PAN SM3.57-40X5 062670512 1
SHUTTLE RACE THREAD GUIDE S02429101 1
SCREW, PAN SM3.18-40X4 062660412 2
DRIVER 152681201 1
LARGE SHUTTLE HOOK (A) 152682101 1
SHUTTLE RACE RING A 152685903 1
BOBBIN CASE ASSY (A) 159610101 1
BOBBIN 159613001 4
TENSION SPRING 154339001 1
SCREW 154341001 1
ANTI-SPIN SPRING 159612001 1
SPRING 145519001 1
TENSION SPRING 104525001 1
RUBBER RING 120448001 1

MOVABLE KNIFE (N) ASSY S49988001 1
SCREW 4.37 S10209101 1
FIXED KNIFE S10210201 1
SCREW, SM2.38 111140002 2
SCREW, FLAT SM4.37 100032004 2
SCREW, SM4.37 153208002 2
NEEDLE HOLE PLATE(FM) S49980001 2
SCREW, FLAT SM2.38 100360003 2
TOTAL 61
SPARE PARTS FOR KE-430Ｃ-7
NAME P/NO. Q'TY
SCREW 3.57 144458001 4
COUPLING HUB 8 S37942000 4
COUPLING HUB 6.35 S37943100 4
COUPLING SPACER S37944100 5
SET SCREW,SOCKET(CP)SM5.95 014760622 8
WORK CLAMP(R) S49695001 2
WORK CLAMP(L) S49694001 2
FEED PLATE S49696001 2
SNAP PIN S37968001 7
THREAD WIPER(A) 156206001 2
SCREW, PAN SM3.57-40X5 062670512 2
SHUTTLE RACE THREAD GUIDE S02429101 2
SCREW, PAN SM3.18-40X4 062660412 4
DRIVER 152681201 2
LARGE SHUTTLE HOOK (A) 152682901 2
SHUTTLE RACE RING A 152685902 2
BOBBIN CASE ASSY (A) 159610101 2
BOBBIN 159613001 8
TENSION SPRING 154339001 2
SCREW 154341001 2
ANTI-SPIN SPRING 159612001 2
SPRING 145519001 2
TENSION SPRING 104525001 2
RUBBER RING 120448001 2
MOVABLE KNIFE (N) ASSY S49988001 2
SCREW 4.37 S10209101 2
FIXED KNIFE S10210201 2
SCREW, SM2.38 111140002 4
SCREW, FLAT SM4.37 100032004 4
SCREW, SM4.37 153208002 4
NEEDLE HOLE PLATE S10211001 4
SCREW, FLAT SM2.38 100360003 4
TOTAL 102
