INSTRUCTION MANUAL
Model# 19524
UPC 671424 605678
Fire pit fountain
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
PLEASE READ THE FOLLOWING
Thank you for purchasing your new fountain fire pit.
Carefully check all packaging materials before discarding.
Do not assemble if there are missing pieces.
Should you encounter problems after following all the steps contained in the instructions
please contact our Customer Care Center at 1-866-231-8893 email: [email protected]

Fire Pit fountain
Model# 19524
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
WARNING:Foroutdoor use only.
Installation and service must be performed by a qualified installer,
service agency, or gas supplier.
WARNING:Improperinstallation,adjustment,
alteration,service
ormaintenancecan causeinjuryor
propertydamage. Read the
installation, operating,
and maintenance instructions thoroughly
before
installing or servicing this equipment.
WARNING
Do not store or use gasoline, or other
flammable vapors and liquids, in the
vicinity of this or any other appliance.
A LP-cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
DANGERIfyousmellgas:
1. Shutoff gas to the appliance
2. Extinguish any open flame
3. Ifodorcontinues,keepaway fromthe appliance
and immediately call your gas supplier or fire
department.
Failure to follow these instructions could result in
fire or explosion, which could cause property
damage, personal injury, or death.
WARNING
ChemicalsknowntotheStateof California
tocausecancer,birthdefects, or other
reproductive harm are created by the
combustion of propane.
WARNING
By products of the combustion of
propanecontainchemicalsknown to the
State of California to cause canceror
other reproductive harm.
DANGER
CARBON MONOXIDE HAZARD
Thisappliancecanproducecarbon
monoxidewhichhasno odor.Using it in
an enclosed space cankill you.Never
usethis appliancein an enclosedspace
suchasa campe r, tent, car, orhome.

TABLE OF CONTENTS
Parts List.................................................................................................................4
Assembly .....................................................................................................5-6
Safety Information......................................................................................8-10
Operation........................................................................................................7
Maintenance..................................................................................................7
Troubleshooting ...........................................................................................11
Warranty.........................................................................................................12

1
2
3
4
5
6
7
8
4

INSTALLATION INSTRUCTIONS
WARNING:
This item is heavy. All necessary
precautions should be taken when lifting
and assembling this fireplace.
Make certain the fireplace body always
remains upright. Do not lie on its side or
you could cause damage to the body.
Most parts of this fireplace are pre-assembled
before shipment. Please follow below assembly
instructions before you start to enjoy your
fireplace.
Step 1: Carefully unpack the product, and take
out all the components. Make sure you take out
all the packaging materials as well.
Step 2: Put the fireplace body in the final
position. It should only be put on a flat and
NON-COMBUSTIBLE floor, and there must be a
minimum of 24 inches of clearance from the
tabletop to COMBUSTIBLE walls. Make sure the
valve on the control panel is turned all the way
clockwise to the “OFF” position. (Figure 1)
Step 3: Put up the body (Figure 2), put up 1
pound gas tank’s adopter to connect valve
assembly tight it up by clockwise direction.
(Figure 3)
Now you’re ready to enjoy your pillar fireplace.
Follow the operation instructions when you’re
using this appliance
(Figure 1)
(Figure 2)
(Figure 3)
5

1. Put the basin stand on a clean level surface that cannot be damaged by water.
2. Put the pump in the fountain basin, lay the cord in the door opening.
3. Connect the hose to the pump.
4. Connect a 1LB propane tank to the metal connection inside the column.
5. Fill with clean water.
6. Start as per operating instruction.
7. Plug pump outlet into a properly grounded outlet, check the water flow.
INSTALLATION INSTRUCTIONS OF THE FOUNTAIN
6

OPERATION INSTRUCTIONS
Lighting and Setting Control for Gas
Before lighting, make sure the valve knob is in the “OFF” position.
1. From the OFF position, push in and turn control knob anti-clockwise to the LOW position.
2. Always perform a leak test before lighting the burner. See page 4
3. Hold a lit match within 1/4” to the lava logs as shown on below picture, until the burner is lit. If burner fails to
light, turn to OFF. Wait 5 minutes before attempting to re-light.
4. Turn control knob to desired heat setting, LOW or HIGH.
Shut-down for Gas
1. Turn the control knob gently to “OFF” position.
2. Disconnect and remove the gas tank when the gas fireplace is not in use.
MAINTENANCE INFORMATION
1. The flames should look like those in the figure below. Adjust the control knob to reach different height for flame.
2. If in raining day, burner should be turned off and store indoor.
3. It is recommended that the fireplace be stored indoors in freezing temperatures. Thecylinder must be
disconnected and removed from theappliance before theappliance can be stored indoors.
4. The propane canister must be stored outdoors and never close to the operating unit.
7

SAFETY INFORMATION
Before you assemble or operate this unit, please carefully read this entire manual. Failure to
do so may result in a fire explosion, injury, or death.
WARNING
• The installation of this unit must adhere to local codes or either the National Fuel Gas Code, ANSI Z223. 1/
NFPA54, OR CAN/CGA-B149.1, National gas and Propane Installation Code.
• THISUNIT IS INTENDED FOR OUTDOORUSE ONLY! This product shall be used outdoors, in a ventilated space
and shallnot be used in any enclosed area.
• This unit is to be used with propane gas only!
• Do not attach a remote gas supply to this unit.
• This unit is not intended for natural gas.
• Converting this unit to natural gas is dangerous and not recommended. The conversion of this unit will void
the manufacturer warranty.
• Do not use any solid fuel or charcoal with this unit.
• When igniting this unit, stay away from the burner as the flame may light up and may cause injury.
• If the propane gas tank is leaking gas, you may hear, see, or smell a hiss. Do the following: 1. Disconnect the
propane gas tank. 2. Do not attempt to fix the problem yourself. 3. Contact your gas supplier or fire
department for help.
• Applying too much propane may result in gas pooling and will not burn. Allow fresh air into the unit so that
the remaining gas may escape.
• Do not use a flame to check for gas leaks.
• Gas supplythe manifold pressure “__11_ in wc (_2.74_ kPa).”
• Use LP propane tanks with the following dimensions: diameter 12in, height 18in, capacity 20lbs.
• You must use a propane tank that has a collar to protect the gas valve.
• DO NOT fill one lb's tank over 80 percent full.
• Discontinue use if any part of the propane tank is damaged. Rust and dents may be hazardous and should
be inspected by a gas supplier.
• Do notburn anything other than the provided materials for this fire table.
• Do not operate unit until all parts are fully assembled.
• Do notpaint or color any part of this heating unit.
• Unit may be hot while in use, do not attempt to move it while in use.
• Never leavethisheatingunit unattended while in use.
• This unit is not intended for cooking.
• Keep any flammable items away and do not use any other fireplace cover for this unit.
• Keep a safe distance to avoid burning skin or clothing.
• Do not sit or rest hands or feet on this heating unit.
• Never place hands or fingers on upper portion of this unit while in use.
• Keep all electrical cords and fuel supply hose away from heated surfaces.
8

SAFETY INFORMATION
• Minimum fire pit clearances from combustible materials: 24" from the sides and rear and at least 48" from ceiling.
• If the flame goes out while burning, turn the gas valve off. Wait 5 minutes before repeating the initial lighting
procedure. Once you have a flame started, hold down the control knob for 1 minute.
• Do not use this appliance if any part has been under water. Immediately call a qualified service technician to
inspect the appliance and replace any part of the control system and any gas control which has been under
water.
• Do not disconnect any part while unit is in use.
• Do not store a spare propane tank on or near this unit.
• If the unit is stored indoors, detach the propane tank and leave outdoors.
• Do not operate on a boat or vehicle. This unit must be used on a flat surface and outdoors ONLY.
• Always remove protective cover before operating (if applicable).
• Check for leaks after not using the unit for long periods of time.
• Children should never operate this unit. Children must be supervised while near this unit.
• Keep gas tank at least 5 ft away from unit when lit. (if external tank)
• Max inlet pressure: 100PSI; Min inlet pressure: 10PSI.
• All installation and repair should be done by a qualified professional. This unit should be inspected annually
and cleaned regularly.
• Inspect all elements of this heating unit before each use. If there is damage, the burner must be replaced.
• Keep the hose out from any pathways to eliminate any accidental damage. (if external tank)
• Be aware of the hazards of high temperatures and stay away from the unit to avoid any burns or injury.
• The gas supply tank should be constructed and marked with the specifications for the LP gas tanks of the
U.S. Department ofTransportation or the National Standard of Canada CAN/CSA-B339, LP gas tanks, spheres
and tubes for Transportation of Dangerous Goods; and Commission.
• The LP gas tank must have a listed overfilling prevention device (CGA810) LP gas tank connection.
• This unit should not be used on plastic or artificial wood decks.
• Instructions to keep the appliance away from and free from combustible materials, gasoline, and other
• flammable vapors and liquids.
• Do not use the unit without inspecting the hose. Prior to use if there are any signs of wear or
• abrasion you must replace the hose.
• Children and adults should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns or clothing ignition.
• children Young should be carefully supervised when they are in the area of the appliance.
• Clothing or other flammable materials should not be hung from appliance or placed on, in, or near the
appliance.
• Any guard or other protective device removed for servicing the appliance shall be replaced prior to
operating the appliance.
• Installation and repair should be done by a qualified service person. The appliance should be inspected
before use at least annually by a qualified service person. More frequent cleaning may be required as
necessary. It is imperative that the control compartment, burners, and circulation air passageways of the
appliance are kept clean.
9

SAFETY INFORMATION
NOTE: You must follow all steps to properly assemble this heating item. Make sure the gas valve is
turned "OFF" before assembling. Do NOT attempt to assemble without proper tools.
IF APPLICABLE:
• Allow unit to cool completely before placing on the protective cover
• DO NOT use the item while covered.
NOTE: You must follow all steps to properly assemble this heating item. Make sure the gas valve
is turned "OFF" before assembling. Do NOT attempt to assemble without proper tools.
Note:
Combustible material should not
be within 48 in of the top of the unit,
or within 24 in around the entire unit.
Combustible materials could be and
are not limited to any items that may
catch fire such as dry vegetation, wood,
branches,leaves,plants,buildings,
structures, fabrics, clothing, sawdust,
all chemicals, and all flammable liquids.
10
48in. (121.9 cm)
24 in. (60.96 cm) 24 in. (60.96 cm)

TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Unit won't
light using
the igniter
pin
Igniterpinandburnerarewet Dry off with a soft cloth.
Igniter battery is incorrectly inserted Check which direction the battery is inserted.
Igniter pin is broken
Contact CTM International for a
replacement part.
Electrodewireisloose
or disconnected.
Reconnectwiretotheigniterboxlocated insidethetablebehindtheigniterbox.
Electrode wire is shorting
between valve and igniter pin
Contact CTM International
for a replacement part.
Burner won't li ght
while using a match
No gas flow Check that the gas tank isn't empty.
Burner ports are clogged
Turn all gas flow connections off. Insert an
opened paper clip (or similar item) into each
of the burner ports to clear them out.
Unit emits a lot of
black smoke
Flame is obstructed at burner ports
Check that all burner ports are free of
anysmalllavarocks/pumicestone/
Glass
Sudden drop
in gas flow
No gas flow
Check that the gas tank isn't empty.
Excessflowsafetyvalve
hasbeenactivated
Turn the control knob to the 'off' position.
Closethe tank valve and disconnect propane
gas tank. Turn the control knob to 'high'; wait
1 minute. Turn the control knob back to the
'off' position. Reconnect propane gas tank.
Light the fire unit as indicated in the 'To Light'
section of this manual.
Flameblows
out easily
Highorgustingwinds
Increaseflameto'high'.
No gas flow
Check that the gas tank isn't empty.
Excessflowsafetyvalve
hasbeenactivated
See'suddendropingasflow' above.
11

WARRANTY
The manufacturer warranty will be voided by, and manufacturer disclaims any
responsibility for, the following actions:
• Modification ofthe unitand/or componentsincludingthe gas valveassembly.
• Use of any component part not manufactured or approved by CTM International.
• Use and installation other than what is listed in this manual.
Please contact the manufacturer for replacement parts.
12
