Bryant Legacy Series User manual

Legacyt Non−ProgrammableOwner’s
Manual

1
YOU WILL LOVE THIS THERMOSTAT.
This Legacyt non−programmable thermostat is an easy to use model that provides
the most sought−after features for keeping your home comfortable. And with a slim
profile, it is designed to be as smart – and smart−looking – as any of the other
electronics in your home. Let this manual show you how easy it is to enjoy the
newest experience in home comfort.
Designed and Assembled in the U.S.A.
NOTE: Read the entire instruction manual before starting the installation.

2
TABLE OF CONTENTS
BUTTON IDENTIFICATION 4........................................
ON−SCREEN INDICATORS 6........................................
OPERATING THE THERMOSTAT
Setting the temperatures for heating and cooling 8........................
Using the fan 9...................................................
Using emergency heat (heat pump systems only) 10......................
Installing or replacing the batteries 11..................................
Using the thermostat to turn the heating and cooling system off 14...........
Auto changeover 14...............................................
ADVANCED OPTIONS
Advanced options display codes chart 15...............................
Changing from Fahrenheit to Celsius 16................................
Turning on the continuous backlighting 17..............................
Keypad lockout 18................................................
Unlocking the keypad 19........................................

3
TABLE OF CONTENTS
WHAT IF . . .
The battery icon is displayed 20......................................
“Aux heat on” is displayed (heat pump systems only) 20...................
“Em heat” is displayed (heat pump systems only) 20......................
There is a power outage 21..........................................
You get a system error message 21....................................
COMMON TERMS AND WHERE TO FIND THEM
Auto changeover 22...............................................
Auxiliary heat (heat pump systems only) 22.............................
Backlighting 22...................................................
Emergency heat (heat pump systems only) 22...........................
Mode 22........................................................
WARRANTY 23....................................................

4
BUTTON IDENTIFICATION
b
a
c
d

5
BUTTON IDENTIFICATION
a. FAN Selects whether the fan operates continuously (on) or only when
needed for heating or cooling (auto)
b. MODE Selects whether thermostat is set for heating, cooling, emergency
heat (heat pump system only), auto (heat and cool as needed), or off
c. UP Increases the temperature or adjusts the screen selection up when
setting advanced features
d. DOWN Decreases the temperature or adjusts the screen selection down
when setting advanced features

6
ON−SCREEN INDICATORS
actual temp
o
Em
heat
aux
heat
on
fan
auto
fan
on
F
C
cool
on
2
set at
4
2
3
1
5
7
6
8
9
10

7
ON−SCREEN INDICATORS
1. Fan mode – on or auto
2. System is in auxiliary (supplemental) mode
3. Current temperature
4. Thermostat mode is either off or using emergency heat
5. Fahrenheit
6. Keypad is locked (no padlock means unlocked)
7. Celsius
8. Battery strength indicator
9. Selected cooling set point; “on” indicates system is in cooling mode
10. Second stage of cooling is active

8
OPERATING THE THERMOSTAT
Setting the temperatures for heating and cooling
Your thermostat is installed with the heating set at 68°F and the cooling set at 72°F.
You can use these or change them so your home is as warm or as cool as you would
like it to be. These steps will hold the temperature where you set it.
1. To change the heating temperature, press the mode but-
ton on the left until the screen says heat.
2. Press the up or down button located on the right side of
the display until you reach the desired temperature.
3. To change the cooling temperature, press the mode but-
ton on the left until the screen says cool.
4. 4. Press the up or down button located on the right side of the display until
you reach the desired temperature.

9
OPERATING THE THERMOSTAT
Using the fan
When the fan is on, it helps distribute air throughout your home for a more even
temperature in all spaces. You can set the thermostat so that the fan runs only
during your heating and cooling cycles (auto mode) or to run continuously.
The thermostat is set at the factory to run automatically as needed. Here’s how to
change the setting so it runs continuously.
1. Press the fan button on the left. The display message will change from auto
fan to fan on.
2. To return the fan to auto mode, press the fan button
again. You will see fan auto on the display.

10
OPERATING THE THERMOSTAT
Using emergency heat (heat pump systems only)
Emergency heat is useful when the automatic auxiliary heat system can’t keep up
with demand. (Systems with heat pumps use “auxiliary heat” when it’s too cold
outside for the heat pump to heat the house without help. The display indicator for
this is aux heat on.)
If the heat pump compressor that works with auxiliary heat fails, or if the heat pump
isn’t working at all, you can turn on the emergency heat for that extra help. (You’ll
know there’s a problem if the house can’t seem to get warm when it’s very cold
outside.) You want to avoid using emergency heat, though, because it’s the most
expensive option. And, of course, if you suspect a problem with your heat pump,
call your heating and cooling dealer immediately.
Here’s how to set your thermostat to use emergency heat.
1. Press the mode button repeatedly until you see Em heat
in the upper left of the display.
2. To turn off emergency heat, press the mode button again
to select heat, cool or auto.

11
OPERATING THE THERMOSTAT
Installing or replacing the batteries
You can install batteries in your thermostat so that if the power goes out, the display
will still show the indoor temperature.
In some situations, batteries are also the power source. Then, two AA batteries
should last about one year. When the batteries have lost about one−third of their
power, a battery icon appears on the display. Two−thirds of it will be black. As the
batteries get weaker, the icon goes down to one black bar and then none. When the
icon is empty, you will begin to lose thermostat functions when it is battery
powered. When the batteries are completely dead, you won’t be able to use the
thermostat.
When using batteries for power, we recommend that you replace the batteries at the
one bar level with two AA alkaline batteries. They’re in the back of the thermostat,
so you’ll have to remove it from the wall.
Here’s how to both install and replace batteries.
1. Locate the latch at the top of the thermostat. It’s at the
center of the top rim.

12
OPERATING THE THERMOSTAT
2. Press it down. This will disconnect the thermostat from the
top of the wall plate.
3. Remove the thermostat from the wall bracket com-
pletely by bringing it slightly toward you and lifting it up
and off the lip on the lower edge of the wall bracket.
4. Set the thermostat face down on a flat surface. You will
see the batteries in the lower right corner.
5. Remove and discard the old batteries.
6. Install new batteries by matching the “plus” and “minus”
ends of the batteries with the “plus” and “minus” indicat-
ors you’ll see outside the two white battery shapes in the
space where the batteries sit.
7. Snap the batteries into place.
8. Put the thermostat back on the wall bracket by lining up
the slot on the bottom edge of the back of the thermostat
with the lip on the wall bracket. You will feel the slot fit
over the lip.

13
OPERATING THE THERMOSTAT
9. With the bottom of the thermostat attached to the bottom
of the wall bracket, bring the thermostat back to the
wall. Line up the latch at the top of the thermostat with
the corresponding lip on the wall bracket.
10. Lightly push the thermostat toward the wall. When the
latch and lip are lined up properly, you will hear the
thermostat snap into place.
11. Close the door.

14
OPERATING THE THERMOSTAT
Using the thermostat to turn the heating and cooling system off
To use the thermostat to turn the heating and cooling system
off, press the mode button on the left repeatedly until the
display shows off in the upper left.
Auto changeover
The thermostat uses one of five modes: heat, cool, Em heat (heat pump version
only), auto, and off. When the mode selection is auto, the thermostat is in auto
changeover mode. This allows the system to switch from heating to cooling – or
from cooling to heating – to maintain the temperatures you’ve set. It does this
automatically.

15
ADVANCED OPTIONS
Advanced options display codes chart
You can customize a few features of your thermostat. This chart shows which
features you can change and the codes associated with them. The codes will be
shown on the display when you follow the instructions.
Feature Configuration
Code
Change Indication
Fahrenheit to Celsius U1 F or C
backlighting U2 On or Of
keypad lockout U3 Of, On, padlock

16
ADVANCED OPTIONS
Changing from Fahrenheit to Celsius
Your thermostat is preset to display the temperature in degrees
Fahrenheit. You can change this to Celsius.
1. Press and hold the mode button for about three seconds.
The display will show U1 and the letter F in the center.
2. Press the up or down button on the right to change it
from F(Fahrenheit) to C(Celsius).
3. Press the fan button on the left to exit this screen.

17
ADVANCED OPTIONS
Turning on the continuous backlighting
The thermostat display lights up for a few seconds after you press any button. This
is backlighting. It will go dark after a few seconds.
If the thermostat is powered by electricity, it is possible to have a constant low level
amount of backlighting until you press any button, which increases the lighting
temporarily. Here’s how to turn on the constant backlight when your thermostat is
powered by electricity.
1. Press and hold the mode button for about three seconds.
The display will show U1 and the letter Fin the center.
2. Press the mode button twice. The display will show U2
and Off.
3. Press the up or down button on the right to change it
from Off to On.
4. Press the fan button on the left to exit this screen.

18
ADVANCED OPTIONS
Keypad lockout
The keypad lockout feature lets you “lock” the thermostat so nobody can change
the temperature – or make any other changes – by pressing buttons. Keypad
lockout is not activated when the thermostat is installed. Here’s how to activate it.
1. Press and hold the mode button for about three
seconds. The display will show U1 and the letter Fin
the center.
2. Press the mode button until the display shows U3 and
Of.
3. Press the up or down button on the right to change it
from Of to On. You will also see a padlock, which indic-
ates the keypad is locked.
4. Press the fan button on the left to exit this screen.
