BSH PKM975DK1D Setup guide

Repair Instructions – Cooking
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 1 of 17
1 Concerning this document 2
1.1 Important information......................................................................................2
1.2 Explanation of symbols...................................................................................2
2 Safety 4
2.1 Qualification.................................................................................................... 4
2.2 General safety information............................................................................. 4
2.3 Product-specific safety information.................................................................5
2.4 Measures after each repair............................................................................ 6
3 Design and function 7
3.1 Direct Select 2.0 hotplate............................................................................... 7
4 Fault diagnosis 9
4.1 Malfunctions (hotplate with Direct Select 2.0)...........................................9
Fault code is displayed...................................................................................9
Appliance does not function/cannot be switched on...................................... 9
Individual heating zone does not heat up...................................................... 9
Circuit breaker (16 A) is triggered after a few minutes...................................9
Acoustic signal of the main switch cannot be turned off................................ 9
Basic settings cannot be saved after making changes................................ 10
Metal frame has come away from glass...................................................... 10
Frying sensor function not available.............................................................10
Poor frying results when using the frying sensor function............................10
4.2 Other faults (surface defects, cracks, breaks)........................................ 11
Glass ceramic damaged ............................................................................. 11
Glass ceramic outside tolerance range .......................................................11
5 Test 12
5.1 Test................................................................................................................12
6 Repairs 13
6.1 Activating the basic settings, trade fair and service programme.................. 13
6.2 Removing and installing the appliance.........................................................14
6.3 Removing and installing the glass ceramic part...........................................15
6.4 Removing and installing the heating zone................................................... 16
6.5 Removing / installing the control module..................................................... 17

Concerning this document
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 2 of 17
1.1 Important information
Read and observe chapter 2 "Safety" before performing any work!
1.1.1 Purpose
These repair instructions form the basis for a systematic and safety conscious
procedure for the repair of domestic appliances.
These repair instructions include information about troubleshooting and repair.
1.1.2 Target group
These repair instructions are intended for persons who are familiar with equipment
technology and were instructed by BSH or an authorised body:
• Service technicians for the repair of domestic appliances
• Pre-assemblers in the spare part stockroom when determining required spare
parts
• Call centre employees during order acceptance
1.1.3 Other applicable documents
The following documents include additional relevant repair information:
• General repair instructions
• Error codes and service programs
• Circuit diagrams
• Exploded drawings
• Parts lists
• Repair videos
1.2 Explanation of symbols
1.2.1 Danger levels
The warning levels consist of a symbol and a signal word. The signal word
indicates the severity of the danger.
Warning level Meaning
Non-observance of the warning message will result in death or
serious injuries.
Non-observance of the warning message could result in death
or serious injuries.
Non-observance of the warning message could result in minor
injuries.
Non-observance of the warning message could result in dam-
age to property.
Table 1: Danger levels
1.2.2 Hazard symbols
Hazard symbols are symbolic representations which give an indication of the kind
of danger.
The following hazard symbols are used in this document:
Hazard symbol Meaning
General warning message
Danger from electrical voltage
Risk of explosion

Concerning this document
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 3 of 17
Hazard symbol Meaning
Danger of cuts
Danger of crushing
Danger from hot surfaces
Danger from strong magnetic field
Danger from non-ionizing radiation
Table 2: Hazard symbols
1.2.3 Structure of the warnings
Warnings in this document have a standardised appearance and a standardised
structure.
Type and source of danger!
Consequences of ignoring the warning.
► Actions to protect from danger.
The following example shows a warning that warns against electric shock due to
live parts. The measure for avoiding the danger is mentioned.
Risk of electric shock due to live parts!
► Disconnect the appliance from the mains at least 60 seconds
before starting the work .
1.2.4 General symbols
The following general symbols are used in this document:
Gen. symbol Meaning
Identification of a special tip (text and/or graphic)
Identification of a key or button
Identification of a material number
Identification of a condition (if ..., then ...)
Identification of a simple tip (only text)
Table 3: General symbols

Safety
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 4 of 17
2.1 Qualification
In Germany, only qualified electricians trained by BSH or an authorised body may
perform any repair work.
In other countries, only similarly trained qualified personnel is permitted to perform
the repair work.
Appliances must only be repaired by persons that are qualified, approved and
trained by BSH or an authorised body as instructed.
2.2 General safety information
2.2.1 All domestic appliances
Risk of electric shock due to live parts!
• Disconnect the appliance from the mains for at least 60 seconds before starting
work.
• Do not touch the housing, components and cables.
• For tests on an energised system, use a residual current circuit breaker.
• Discharge high-voltage capacitors.
Risk of injury from sharp edges!
• Wear protective gloves.
Risk of injury when dealing with harmful substances!
• Observe the associated safety data sheet!
Risk to the appliance's safety / function!
• Only use original spare parts.
Risk of damage to electrostatically sensitive components (ESDs)!
• Before touching ESDs, use an electrostatic protection system (wristband with
earth safe plug).
• Do not touch connections and conductor paths of the modules.
• Only transport ESDs in conductive materials or original packaging.
• Keep ESDs clear of electrostatically chargeable materials (i.e. plastic).

Safety
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 5 of 17
2.3 Product-specific safety information
2.3.1 Microwave ovens
Risk of scalding due to explosive escape of liquids in case of delayed
boiling!
• Before heating place a metal spoon in the liquid.
Health hazard due to non-ionising radiation!
• After any work on the appliance, check the tightness with leak rate
measurement.
2.3.2 Induction appliances
Induction appliances fulfil the relevant regulations for safety and electromagnetic
compatibility (EN 50366).
Danger to life due to magnetic fields!
• People with pacemakers should stay clear during repairs on an open
appliance!
Health hazard due to magnetic fields!
• People with medical devices (for example insulin pump / hearing aid) should
stay clear of the opened appliance!
2.3.3 Gas appliances
Explosion hazard due to escaping gas!
• Cut off the gas supply before working on gas carrying connections.
• Check tightness following work on connections carrying gas.
• Only repair gas appliances with original parts that were tested and released for
such use.
If you smell gas!
• Do not press any electrical switches.
• Extinguish / keep clear of open flames.
• Ensure that room is well ventilated.
• Close the gas isolating equipment.
2.3.4 Refrigerators and freezers
Risk of burns caused by refrigerants!
• Wear protective gloves and goggles.
Explosion hazard due to refrigerants!
• Do not solder pipe connections, only use Lokring connections.
• Do not press any electrical switches.
• Keep clear of thermal appliances.
• Extinguish / keep clear of open flames.
• Ensure that room is well ventilated.
2.3.5 Dryer with heat pump
Risk of burns caused by refrigerants!
• Wear protective gloves and goggles.
Explosion hazard due to refrigerants!
• Do not solder pipe connections, only use Lokring connections.
• Do not press any electrical switches.
• Keep clear of thermal appliances.
• Extinguish / keep clear of open flames.
• Ensure that room is well ventilated.

Safety
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 6 of 17
2.4 Measures after each repair
If the appliance is functional:
• Check according to VDE 0701 or country-specific regulations.
• Check external appearance, function and tightness.
• Document repair work, measured values and functional reliability.
If the appliance is not functional:
• Identify the appliance as “not functionally reliable”.
• Warn customers of commissioning and notify them in writing .

Design and function
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 7 of 17
3.1 Direct Select 2.0 hotplate
3.1.1 Cooking zones, operation and display
The hotplate is operated independently. It features a TouchControl with integrated
controls and display, in addition to its own mains connection.
The hotplate primarily consists of:
• Glass ceramic part with glued metal frame
• Heating zones
• TouchControl with controls and display
• Wiring
• Mains terminal box
• Hob cover
Fig. 1: Top-down view - example PKM975DK1D.
3.1.2 Components of the hotplate
Fig. 2: Hotplate (wiring not shown)
1 Metal frame (glued to glass ceramic part) 5 Heating zones
2 Seal 6 Hob cover
3 Glass ceramic part 7 Mains terminal box
4 TouchControl
The glass ceramic part and the metal frame glued to it comprise the bearing
element of the hotplate.
A circumferential seal prevents moisture from entering the gap between the
hotplate and the worktop when the hotplate is installed.
Internally, the heating zones, TouchControl and mains terminal box are laid out on
the glass ceramic part and are mounted on the frame.

Design and function
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 8 of 17
The electrical components are connected to each other by means of pluggable
cables.
The hob cover seals the hotplate so that it can be touched, and additionally
presses the heating zones and the TouchControl onto the glass ceramic parts.
3.1.3 "Smartkii" capacitive sensors
The "Smartkii" sensor integrates a capacitive sensor and an illuminated symbol into
one control.
The user operates the appliance by directly touching the illuminated symbol.
Fig. 3: "Smartkii" sensor
3.1.4 Direct Select 2.0 control module (YL238)
For further information regarding the available functions in the control module, view
the appliance's instruction manual.
Fig. 4: YL238 Direct Select 2.0 control module with "Smartkii" sensors
3.1.5 Important information on use and operation
Hot pots/pans may damage the frame!
► Never place hot pots and pans onto the frame.
Hot pots/pans may damage the electronics!
► Never place hot pots and pans onto the control panel or the display area.

Fault diagnosis
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 9 of 17
4.1 Malfunctions (hotplate with Direct Select 2.0)
Fault Possible cause Troubleshooting
Fault code is displayed --- -See wiring diagram "Fault codes and service programs (ASP)".
No mains voltage ► Check house fuse connection.
► Check cooker connection socket.
► Check power cord.
► Advise customer:
In the event of this fault, please always check the house fuse connection first.
Appliance connected incorrectly -Observe the connection diagram.
-Observe the wiring diagram.
► Connect the appliance correctly.
Power supply voltage (230/400 V) for the
electronics is not present
-Observe the wiring diagram.
► Check connections.
► Check the wiring.
Electronics incorrectly installed ► Install the electronics so that the sensor elements make correct contact with the
glass ceramic parts (the contact surfaces must be clean and dry).
Appliance does not function/cannot be
switched on
Electronics defective ► Replace defective electronics.
Heating zone defective ► Check the heating resistor visually for breaks
► Measure the heating resistance
Wiring and/or connections defective ► Check wiring and connections
Individual heating zone does not heat up
Electronics defective ► Check electronics visually (burnt areas, broken strip conductors)
► Replace defective control parts
Circuit breaker is defective (when operat-
ing above nominal value).
-To achieve shorter cooking/roasting times (from more powerful heating zones), the
tripping characteristics of circuit breakers are fully exploited for some appliances.
At 1.13x nominal current (18.1 A), a circuit breaker is expected to hold for at least
1 hour, at 1.45x nominal current (23.2 A), it is expected to trip within an hour.
Responsible operation of the appliances over the nominal value of the circuit
breaker is approximately 1.13x the nominal current.
► Replace the defective circuit breaker.
Circuit breaker (16 A) is triggered after a
few minutes
Operation of an additional consumer on
the same phase.
► Connect additional consumer to another phase.
Acoustic signal of the main switch cannot
be turned off
Not a fault. ► Advise customer:
The confirmation signals (acoustic signals) can be configured in the basic settings
(see instruction manual).
Exception: The acoustic signal of the main switch cannot be switched off (as
specified by a European standard).

Fault diagnosis
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 10 of 17
Fault Possible cause Troubleshooting
Basic settings cannot be saved after
making changes
Not a fault. -In the basic settings, the customer can adjust the appliance to his own
requirements within the specified framework (see instruction manual). Occasionally,
the customer may find that he/she is unable to permanently save the altered basic
settings.
► Advise customer:
Proceed as follows in order to saved the altered basic settings:
- Press and hold the "key" symbol for 4 seconds (example: this will switch the
display c2 "up" (for example to c7)).
- Please do not let this confuse you: to save, press the "key" firmly with your finger
and hold it down for the full 4 seconds!
- The new setting will be saved.
Metal frame has come away from glass Soiling of the glued joint by detergent
when glued joint was established.
Boiled-over food or other similar soiling
which reacts with the adhesive over a
longer period of time and causes it to sep-
arate from the frame.
-Solution: replace the defective glass ceramic part.
-Starting one month after installation of the appliance, an eFSB with good-quality
photos must be created for this fault in order for a decision on repair costs to be
made.
Frying sensor function not available Function not present. ► Advise customer:
Only certain appliances feature the frying sensor function.
Poor frying results when using the frying
sensor function
Frying sensor function not used correctly. -Use BSH pans for the frying sensor function wherever possible: ([ HZ390210]
- 15 cm / [ HZ390220] - 19 cm / [ HZ390230] - 21 cm / [ HZ390240] - 28 cm
diameter)
► Advise customer:
The following procedure should be implemented in order to use the frying sensor
function correctly:
- Select a suitable temperature setting.
- Preheat an empty frying pan (without oil or butter).
- The initial temperatures of the frying pan and the cooking zone should be as close
as possible. If the cooking zone is hotter than the frying pan (or vice versa), the
temperature sensor will not be activated correctly when using the frying sensor
function.
- The size and position of the frying pan on the cooking zone must match.
- Do not cover the frying pan with a lid. Otherwise, the function will not work
properly. You can use a protective screen to prevent splashing.

Fault diagnosis
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 11 of 17
4.2 Other faults (surface defects, cracks, breaks)
Fault Possible cause Troubleshooting
Glass ceramic damaged --- -See instructions in the repair manual "Damage to the glass ceramic".
Glass ceramic outside tolerance range --- -See general repair manual regarding glass ceramics in "Cooking (radiation)".

Test
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 12 of 17
5.1 Test
No extensive test sequences are currently required for this
appliance.
Simple test steps can be found in the chapter “Fault diagnosis”.
►

Repairs
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 13 of 17
6.1 Activating the basic settings, trade fair and
service programme
.
"Activating the basic settings" is described in the following
document:
• Circuit diagram "Fault codes and service programmes
(ASP)"
.
"Activating the trade fair programme" is described in the
following document:
• Circuit diagram "Fault codes and service programmes
(ASP)"
.
"Activating the service programme" is described in the
following document:
• Circuit diagram "Fault codes and service programmes
(ASP)"

Repairs
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 14 of 17
6.2 Removing and installing the appliance
Depending on the type of construction, the appliances are mounted differently in
the cut-out of the worktop.
The following types of mounting system are used:
• Installation rails which are mounted on the left and right of the worktop cut-out,
in conjunction with locking catches on the appliance
• Spring clips on the left and right of the appliance
• Mounting straps (screwed in place) below the appliance
There is a danger that the glass ceramic will crack if not removed
correctly!
► Observe the following instructions for installation and removal.
6.2.1 Removing the appliance
Required tools:
?483196 Installation lever (angled spatula)
Prerequisite:
• Appliance is disconnected from power supply.
• Appliance is accessible from below.
In principle, the appliances must be pushed out of the worktop
from below.
Only if the time required for this is unjustifiable may they be
removed from above using the installation lever (angled spatula).
1. 0If the appliance is mounted using installation rails and locking catches,
► Push the appliance out of the worktop from underneath at the left and
right.
2. 0If the appliance is mounted at the left and right using spring clips,
► Push the appliance out of the worktop from underneath - several times
at the left and right alternately.
3. 0If the appliance is mounted to the worktop from underneath using mounting
straps which are screwed in place,
1) Loosen the mounting straps and turn towards the centre of the
appliance.
2) Push the appliance out of the worktop from underneath at the left and
right.
6.2.2 Installing the appliance
The worktop may be damaged if a defective seal is used for the glass
ceramic!
► Check the seal. Replace the seal if defective.
► Install the appliance in reverse sequence.

Repairs
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 15 of 17
6.3 Removing and installing the glass ceramic part
6.3.1 Removing the glass ceramic
Prerequisite:
• Appliance is disconnected from the mains.
• Appliance has been removed.
1. Place the appliance onto a soft, non-abrasive underlay with the glass ceramic
surface facing downwards.
2. Remove the screws from the hob cover.
3. Remove the hob cover and place to one side.
4. The heating zones are mounted on the frame of the glass
ceramic part using various retaining clips.
In order to be able to correctly position the heating zones on
the new glass ceramic parts, the following things are helpful:
• Marking the location of the retaining clips on the heating
zones
• Making a note of which heating zone is mounted using
which retaining clips
Removing screws for the electronics (optional), the heating zones, the residual
heat indicator (optional) and the terminal box (optional).
5. Lift all components out of the glass ceramic, including all cables.
6. Dispose of the old glass ceramic parts.
6.3.2 Installing the glass ceramic parts
1. Place the new glass ceramic parts onto the soft, non-abrasive underlay.
2. Place all components, including the cables, into the new glass ceramic parts.
3. Screw electronics (optional), heating zones, residual heat indicator (optional)
and terminal box in place.
4. Place the hob cover on top and screw it in place.

Repairs
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 16 of 17
6.4 Removing and installing the heating zone
6.4.1 Removing the heating zone
Prerequisite:
• Appliance is disconnected from the mains.
• Appliance has been removed.
1. Place the appliance onto a soft, non-abrasive underlay with the glass ceramic
surface facing downwards.
2. Remove the screws from the hob cover.
3. Remove the hob cover and place to one side.
.The heating zones are mounted on the frame of the glass
ceramic parts using various retaining clips.
It is helpful to mark the location of the retaining clips on the
new heating zone in relation to the old heating zone, in order to
be able to position the new heating zone correctly.
5. Remove the screws on the retaining clips of the heating zone.
6. Remove the retaining clips.
7. Remove the heating zone.
.The leads of the heating zones are not labelled.
It is helpful to mark the leads of the heating zones before
pulling them out in order to be able to connect the new heating
zone correctly.
9. Pull out the leads.
6.4.2 Installing the heating zone
1. Connect the leads.
2. Position the heating zone on the glass ceramic part.
3. Attach the retaining clips.
4. Screw the retaining clips in place.
5. Place the hob cover on top and screw it in place.

Repairs
2016-10-28 / DIS 820_58300000190984_ara_en_c Copyright by BSH Hausgeräte GmbH Page 17 of 17
6.5 Removing / installing the control module
6.5.1 Removing the control module.
Prerequisite:
• Appliance has been disconnected from the mains.
• Appliance has been removed.
• Rotary knob has been removed (optional, only applies for appliances with
rotary knobs).
1. Place the appliance onto a soft, non-abrasive underlay with the glass ceramic
surface facing downwards.
2. Remove the screws from the hob cover.
3. Remove the hob cover and place to one side.
4. Remove the screws from the control module.
5. Remove the control module.
.The cables of the control module are not labelled.
It is helpful to mark the cables of the control module before
pulling them out in order to be able to connect the new control
module correctly.
7. Pull out the cables.
6.5.2 Installing the control module
1. Connect the cables.
2. Insert control module.
3. Tighten the control module screws fully.
4. Place the hob cover on top and tighten the screws fully.
