BSJ VT02 Operational manual

1
Vehicle terminal device
Product Name: vehicle positioning terminal
Product model: VT02
Manual number: SPKM - 02
Document No.: BSJ－S0052
Version: A/1
Date: 2016. 8.25
Product User Manual

2
Content
І. Product composition................................................................................................. 1
1.1 Product overview................................................................................................... 1
1.2 Product picture....................................................................................................... 1
1.3 Product configuration list.......................................................................................2
1.3.1 Standard list...................................................................................................2
1.4 Device wiring diagram...........................................................................................2
1.5 Definition Of Product Indicator.............................................................................3
II. Parameters Of Device And Function Instructions.................................................. 4
2.1 Parameter List Of The Device............................................................................... 4
2.2 Function List Of The Device................................................................................. 4
2.3 Installation Process Of Product..............................................................................5
2.3.1 Installation.....................................................................................................5
2.3.2 SMS Setting format.......................................................................................6
Ш. Analysis of Common Problems and After-sales Service...................................... 6
3.1 Analysis Of Common Problems............................................................................ 6
3.2 Attention.................................................................................................................6
3.3 After-sale service................................................................................................... 7

1
І. Product composition
1.1 Product overview
Product Name: Wired vehicle positioning terminal
Product model: VT02
Product specifications: L83mm*W23mm*H12.5mm
1.2 Product picture

2
1.3 Product configuration list
1.3.1 Standard list
No
Name
Quantity
Unit
Remark
1
VT02 host
1
PC
2
User manual、warranty card、certification
1
PC
Three in one
3
Package box
1
PC
4
Power cable
1
PC
Note: The above is a standard configuration list of the whole set of products, and accessories
outside the above range are subject to additional fees.
1.4 Device wiring diagram
No
Colour
Interface definition
1
Yellow
Fuel -
2
Orange
ACC
3
Black
Power GND
4
Red
Power +

3
If u need to connect to reply, please check as below:
1.5 Definition Of Product Indicator
Indicator
GSM (Red)
Flash fast: GSM is in initialization
Flash slowly: GSM signals is normal
Bright always: GPRS On Line
Not Light: Not yet received the GSM signal/Not Insert
Sim Card
GPS (Yellow)
Fast Flash: Searching GPS signal
Bright always: GPS has been positioning
Not Light: GPS is in dormancy/Not working

4
II. Parameters Of Device And Function Instructions
2.1 Parameter List Of The Device
No
Item
Specifications
Remark
1
Material
Plastic
2
Working Voltage
DC 9V - 36 V
3
Working Current
25mA @12V(static current10mA)
4
Standby Battery
0.5 hours (3.7V/50mAH lithium
battery
5
Positioning accuracy
<10 Meters (This data is for reference
only, and the positioning accuracy is
related to factors such as the terrain
and time of the vehicle)
Test Data
6
Size
L83*W23*12.5mm
7
Positioning way
GPS
8
Working Temperature
-25℃+75℃
9
Storage Temperature
-40℃+85℃
10
GPS chip
MTK2503
11
Communication
Network
GPRS
GSM :850/900/1800/1900 MHz
12
Net Weight
25g
13
Gross weight
140g
14
Communication ways
TCP
15
Warranty
1 year
16
OEM&ODM Service
Provided

5
2.2 Function List Of The Device
Function
Description
Real-time tracking
Upload the longitude and latitude information according to the time
interval.
ACC on/off status
Uploaded data include the ACC on/off status each time
Power down alarm
Turn on backup battery, when the vehicle voltage is lower than 5v, the
device upload a alarm to the server
Over speed alarm
Set the maximum speed limit value on the platform or SMS, when the
GPS speed is more than the value, the device will upload a alarm to the
server
Fuel checking
Cut off/supply fuel remotely through server or SMS
Blind area data
uploading
The data is stored up to 300pcs. if the terminal is located and not online,
upload this data when the signal is good
Inflection data
uploading
When the angle of the vehicle turns is more than a certain angle, the
device will upload a position information to the platform to optimize
the trajectory.
Upgrade remotely
Need assistance of factory
Static mode
The 3D triaxial acceleration sensor detects vibration status of vehicle in
real time, when the car is moving, the device is in motion mode; the
device will change to static mode after 5 minutes without vibration,
close the GPS module, when vibration is detected, the device
automatically changes to motion mode.
SMS command to get
location
Send “where” through SMS or platform to get latitude and longitude,
current time, speed, direction, current voltage value, ACC status,
Google Maps link
2.3 Installation Process Of Product
2.3.1 Installation
Check Device
Check whether the appearance of the device is good and whether the related accessories are
complete.
Install SIM card
Open the device SIM card into the card slot. Please avoid overexertion is damaged, please
make sure that a SIM card with Internet access, only at the same time satisfy the electricity and
insert SIM card terminal can work normally.
The position requirements of terminal installation
A. Waterproof: choose place which is not easy to fill the position, kept terminal dry, pay
attention to be far away from the air-conditioning outlet in case of the changes of

6
temperature.Have condensed water accumulated inside the terminal seriously affect the service
life of the product.
B. Shock: terminal can't hang up installed in strong vibration position for a long time.
C. Tamper-proof: terminal should be away from the car video intercom and electronic
equipment, such as to prevent conduction and radiation.
2.3.2 SMS Setting format
Exactly format:
Set IP Online:
<SPBSJ*P:BSJGPS*T:120.025.232.237,7788*A:CMNET*N:13288888888*C:0030>
SPBSJ: Header
P: Password (Default Password: BSJGPS)
T: TCP IP and Port
A: APN
N: Device Number
C: Time Interval (Seconds)
Ш. Analysis of Common Problems and After-sales Service
3.1 Analysis Of Common Problems
Question
Reason
Solution
Online tracking
offline
SIM card not enough credit
Charge credit or change
SIM card contact problem
Install SIM card again or change
Online tracking parameter
setting error
Reset Parameters with correct format according
to user manual
Vehicle in underground car
parks or tunnels, signal
weak.
Go to good signal area
Cannot
positioning
Vehicle in underground car
parks or tunnels
Leave that area
GPS Antenna side is not up
to sky
Make the GPS antenna side up to sky

7
3.2 Attention
1. Electronic product please note waterproof.
2. Please keep the backup battery is enough.
3. When the temperature of the environment is more than the normal work of the terminal
temperature range, advice without electricity.
4. When the vehicle in an underground parking lot, tunnel or garage, will influence the
positioning signal. And possible communication network signal blind area lead to equipment can't
monitor; after the vehicle out of the above areas, equipment will automatically return to normal
work.
5. In abnormal situation, please do not repair itself. By linking the original attachment or unplug
the connection between the various components damage, manufacturer is not liable.
3.3 After-sale service
1. During the one-year warranty, please feel free to contact us if there is any problem or
damage not caused by human factors.
2. Not maintenance:
(1) Client dismantled privately
(2) Force majeure (floods, accidents, etc.)
3. More than one year damage or faulty maintenance will need to pay for raw material.
4. Free to provide customers with the purchase, use, installation and other consultation and
technical services.
