6301C KEYBOARD USER'S GUIDE
Product Overview
This document describes the functional specification of standard USBkeyboard and standard USB
Hubkeyboard. Its function is fully compatible withthe Universal Serial Bus Specification Revision
1.1 as well as the Human Interface Devices(HID) class specification 1.1.
USB Interface Features:
ØUSB is a "must-have" feature in the current market.
ØThe instant way to expand your PC. You never to open your PC and you don't need to worry
about add-in cards, DIP switch setting or IRQs.
Ø"Hot-swapping" feature: You don't even need to shut down and restart your PC to attach or
remove a peripheral. Just plug it in and go!
The ACPI Power Management Keys and Their Functions
System requirement:
ØMicrosoftWindows98 Windows®ME, Windows® 2000 or Windows® XP operating system.
ØThe system supporting ACPI or APMII.
ØATX motherboard and ATX power supply.
The functions of the power management are specified and performed by Windows98 operating
system, no vendor-specified driver is needed to use them, but the Windows98 operating system is
necessary. There could be one or two or three ACPI power management keys on the keyboard, those
functions are as follows.
Power off key: Power down the system.
Sleep key: Put the system to sleep.
Wake up key: Wake up or powers up the system.
Power key: (Single key with three functions above)
ØPress this key and hold over four seconds to power down the system.
ØPress this key and release it within four seconds to put the system to sleep.
ØWhen the system is asleep or powered down, press this key and release it within four
seconds to wake up or power up the system.
USB Cable, Plug Contact Numbering & Ports
USB keyboard has a cable for sub-channel device and a series A plug, which fully comply withthe
USBspecification 1.1.
Contact
Number
Signal Name Comment
1VCC Cable power
2-Data
3+ Data
4Ground Cable ground
UUSSBBpplluugg

3100504463 Version 1.0 August 1999 Printed in China
PS/2 Keyboard Connector Contact Numbering & Port (if equipped)
Contact Number Signal Name
1data
2Reserved
3Ground
4Reserved
5+ 5VDC
6clock
