Burmester 111 Musiccenter User manual
Operating Instructions
iPad is a registered trademark of Apple Inc., registered in the U.S.A. and other countries.
HIGHRESAUDIO is a registered trademark.
The usability of third-party services (Internet radio, music streaming services) with the
111Musiccenter is subject to any terms of use of third-party suppliers, as well as the technical
requirements of the user and third parties (Internet access, service availability) on which Burmester
Audiosysteme GmbH has no influence.
Software version 2.30
Dear Audiophile,
Congratulations on your excellent choice. We sincerely appreciate your trust in us.
You have selected an audio component which excels in musical fidelity and combines
uncompromising manufacturing quality with technical innovation and the highest degree of
operating flexibility.
We urge you to read this owner’s manual in its entirety at least once so you will be able to make full
use of all capabilities of this outstanding audiophile instrument.
However, should you have additional questions, please contact your dealer or call us directly.
You will be the judge of our uncompromising commitment to manufacture true high-end stereo
components and to offer a service that is commensurate with the highest quality standards.
Please, talk to us about customization – even if it seems a little far-fetched to you. We gladly accept
any technically reasonable challenge.
Enjoy the music.
Your Burmester team
111 Musiccenter
3
C
W D M C O M
H D I U I
Symbols and text labels used 6
Meaning of warning symbols and words 7
I S I
Opening the device 7
Power supply 7
Set-up 8
Operating during thunderstorms 8
Backup 8
W D I H O D U S
Packaging 8
Supplied items 9
Setting up the device 9
H D I C D
Installing the storage battery 10
Connecting analog signal sources 11
Connecting digital signal sources 11
Connecting a power amplifier 12
Connecting a tape recorder, headphones, and digital output 12
Connecting a network cable and USB components 13
Connecting the remote control components 14
Connecting the Wi-Fi antennas 15
Connecting the power cord 16
W O D E A T
W F D R C O
H D I S D
W O D I H O M
Operating the music center using the buttons on the device panel or the remote control 20
Operating the Musiccenter via the iPad app 20
Operating the Musiccenter via a web browser 20
4
H I
H D I O M W N
H D I E W-F C
H D I C NM
H D I P CD
H D I P C USB S
H C I C () CD I M
H D I P A D S S D
H I P C H D (P)
H D I P C I (I R)
H D I O M P D S (SM)
H D I Q S N D V
H D I P S U
Performing a software update via the Internet 33
Performing a software update using a USB stick 34
M, R C
D
W
A
The back side of the device at a glance 37
Remote control of the device via BURLINK 38
G
T D
Connectors 42
Components 42
General data 42
WHAT OPTIONS DOES THE MUSICCENTER OFFER ME?
111 Musiccenter
5
W O D M O M
The Musiccenter combines multiple premium components into one device, providing
different options to play music in the highest quality:
Preamplifier
Connect your analog and digital signal sources on the reference preamplifier and
choose designations for the connected devices.
CD drive
Play CDs directly or copy them to the internal hard disk drive (ripping).
Internal hard disk drive
Save tracks on the 3 terabyte hard disk drive and optimize the sound quality during the
saving process.
If a connection to the Internet exists, the CD cover and information on the album and
artist are automatically downloaded and saved.
Play the saved music. Convenient options for selecting tracks by name, artist, album,
and genre are at your disposal. You can also take advantage of the search function.
Home network
Connect the Musiccenter to your home network. Thanks to the DLNA/UPnP standard,
the Musiccenter can make music saved on the hard disk available to other network
devices.
Music download and Internet radio1
Via an established Internet connection, you can download high-resolution music from
providers such as HIGHRESAUDIO and access a variety of Internet radio stations.
Operation via the iPad app
You can conveniently operate the Musiccenter on an Apple iPad using the
BurmesterMC app:
• Select the connected signal source.
• Start ripping a CD to the internal memory.
• Scroll through the covers of saved albums or display information on the albums and
artists.
• Create and play playlists.
Note: Please see the separate document “Instructions for Operation via the iPad App” for
more information on installing and operating the iPad app.
Operation via a web browser
You can access the Musiccenter using any standard web browser, even without an iPad.
In addition to playback of albums, tracks, and playlists, the web browser interface offers
a variety of further functions:
• Import audio files in the formats flac, m4a, aif, wav, mp3, aac, and ogg.
• Edit album and track information.
• Export audio files to a USB stick.
• Call up device-specific information.
• Change device settings.
Note: Please see the separate document “Instructions for Operation via a Web Browser” for
more information on how to operate the Musiccenter via a web browser.
1 The Internet connection and music downloads result in use-dependent costs.
HOW DO I USE THESE INSTRUCTIONS?
6
H D I U T I
These operating instructions describe the set-up, connection, and operation of your
111Musiccenter, hereinafter referred to as the “Musiccenter”. Please refer to the
enclosed quick guide operating instructions for information on a quick start-up and
descriptions of some basic functions.
To be able to use all the functions of the Musiccenter, you need the supplied Apple
iPad, which is described in separate operating instructions. After connecting and
starting up the Musiccenter, you will generally only use the iPad and occasionally the
remote control. The convenient format of the iPad instructions helps facilitate
operation.
Please note the following:
►Read and follow the information given, in particular the safety information and
warnings.
►Save these operating instructions.
Symbols and text labels used
3Requirement
Designates a requirement which must be fulfilled before a subsequent action
can be taken.
►Action step
Designates an individual action step.
1.
2.
3.
Sequence of actions
Designates a sequence of action steps which have to be performed in the given
order.
ªResult
Designates the outcome of an action.
Meaning of warning symbols and words
This document uses the following warning symbols and words:
The general danger symbol, in conjunction with the warning words
CAUTION, WARNING, and DANGER, serves to warn against the risk
of severe injuries. Follow all subsequent
instructions to prevent serious or fatal injuries.
The lightning symbol, in conjunction with the warning word
DANGER, serves to warn against a lethal electrical voltage.
NOTICE The warning word NOTICE indicates a danger that can lead to
damage to or destruction of the device.
CAUTION The warning word CAUTION indicates a danger that poses a low or
medium risk of injury.
WARNING The warning word WARNING indicates a danger that can lead to
death or severe injuries.
DANGER The warning word DANGER indicates a danger which can directly
lead to death or severe injury.
IMPORTANT SAFETY INFORMATION
111 Musiccenter
7
I S I
Opening the device
Do not open the device. The device does not contain any parts that can be maintained
by the user. Fuses inside the device may only be replaced by authorized staff, such as
your specialist dealer.
Power supply
Use the supplied 3-wire power cord for power supply. The protective earth contact
must not be rendered ineffective. Furthermore, the device may only be connected to
an outlet with a functioning protective conductor connection.
The device has a power supply unit that automatically adjusts to the power supply. As a
result, the device can be operated with all common power supplies.
Lay the power cord in a way that prevents it from being damaged. Do not use a
damaged power cord. Instead, switch the device off and contact your specialist dealer.
Set-up
When selecting an installation location, please note the following:
• Avoid direct sunlight, excessive heat, cold, moisture, and dust.
• Ensure sufficient ventilation. Do not place the device in a closed rack.
• Do not cover the slots and openings on the device. They serve as a means of
ventilation.
• Do not expose the device to dripping water or spray water and do not place any
containers holding liquids on your device. Do not place any open ignition sources,
such as burning candles, on the device.
Operating during thunderstorms
During thunder and lightning storms, disconnect the device from the power supply by
unplugging the power cord from the unit or from the power socket. Switching off the
mains switch on the back side of the device is not sufficient. For good measure, also
disconnect all connected components from the power supply.
Backup
Burmester recommends backing up audio data saved in the Musiccenter to USB drives
via the web interface. Backups should be performed every six months or after ripping a
certain number of CDs. Please see the separate document “Instructions for Operation
via a Web Browser” for more information on creating a backup.
WHAT DO I HAVE TO OBSERVE DURING UNPACKING AND SETUP?
8
W D I H O D U
S
CAUTION
Heavy device
The device is very heavy and may cause injury if it falls.
►Allow a second person to help you during unpacking and set-up if need be.
►Pay attention to any possible sharp edges.
►Place the box on the floor and remove all accessories and the device.
►An operating temperature that is too low or too high may lead to errors in the
device. For this reason, after unpacking the device, leave it standing for some time
before connecting it and turning it on.
Packaging
The packaging is designed for re-use as long as it has not been damaged during
previous transportation. For this reason, do not throw the packaging away and use the
original packaging for any further transportation.
Supplied items
►Make sure the package contents are complete:
— 111 Musiccenter
— RCA to XLR adapter (4 in total – 2 pairs)
— 005 remote control
— Power cord
— Network cable
— Battery
— Allen wrench
— Operating instructions (OI): Quick Guide OI, OI for the Musiccenter, Instructions
for Operation via the iPad App, Instructions for Operation via a Web Browser
— Wi-Fi antennas (2)
— Wi-Fi antenna block
— iPad
— Warranty documents
►Please contact your specialist dealer if anything is missing or the supplied content is
damaged.
HOW DO I CONNECT THE DEVICE?
111 Musiccenter
9
Setting up the device
NOTICE
Heat or moisture
The device can be damaged if exposed to excessive heat or moisture.
►Protect the device from direct sunlight.
►Avoid setting the system up near sources of heat, such as heaters, ovens, or above
devices that generate a large amount of heat (such as power amplifiers).
►Avoid moisture and dust.
►Ensure sufficient ventilation.
1. Place the device on a stable, level surface.
CAUTION! In particular, note the weightiness of the Musiccenter.
2. Connect the device as described in the following.
H D I C D
This chapter describes all options for connection. Please see the appendix at the end
of these operating instructions for an overview of the connections on the rear side of
the device.
CAUTION
Connecting devices that are on
Connecting devices that are on can lead to damage.
►Before connection, shut off the Musiccenter and all other components belonging
to your system.
►Do no switch the components back on until they have been connected completely
and correctly.
Installing the storage battery
The Musiccenter is equipped with a rechargeable battery that allows the system to shut
off safely in the event of a power failure. The battery is enclosed separately and has to
be installed before initial device start-up.
If the battery has already been installed by your specialist dealer, you can skip the
following installation instructions.
NOTICE
Operation without a storage battery
The device is also fully functional without the battery inserted, but cannot safely shut
off in the event of a power failure. Possible consequences include data loss or even
damage to the operating system.
►Insert the storage battery or ask your specialist dealer to do so for you.
Note: In the event of a power failure, the display shuts off immediately, even if a storage
battery is inserted. The system is still shut off safely in the background.
HOW DO I CONNECT THE DEVICE?
10
To install the storage battery:
1. Unscrew the four screws and remove the service plate.
2. Connect the battery cable to the connection cable in the UPSBATTERY slot.
3. Insert the battery into the compartment until it clicks into place.
4. Position the service plate and tighten the four screws (finger tight).
Connecting analog signal sources
►Connect analog signal sources to the INPUT1/2/3 inputs using a balanced LF cable.
►Connect unbalanced cables to the enclosed XLR to RCA adapters.
HOW DO I CONNECT THE DEVICE?
111 Musiccenter
11
Connecting digital signal sources
►Connect electrical digital signal sources, such as a CD player, to RCA inputs
INPUT4/6/8.
►Connect optical digital sources, such as a DAB tuner, to TOSLINK inputs
INPUT5/7/9.
Connecting a power amplifier
►For the best sound, connect the BALANCED sockets to the inputs on your amplifier
using a balanced LF line.
►Use the UNBAL outputs and a cinch line if your amplifier only features unbalanced
cinch inputs.
HOW DO I CONNECT THE DEVICE?
12
Connecting a tape recorder, headphones, and digital output
1 Tape recorder (TAPE)
For connecting an analog recording device, for example.
2 Headphones (PHONES)
For connecting headphones.
3 Optical digital output (DIGITAL OUT)
For connecting e.g. a preamplifier via an optical digital cable (TOSLINK).
4 Electrical digital output (DIGITAL OUT)
For connecting e.g. a preamplifier via an electrical digital cable (RCA).
Tape recorder (TAPE)
This connection outputs an analog signal with a fixed level.
►Here, you can connect an analog recording device, for example.
NOTICE! Do not connect any devices that could be damaged by the fixed level (such as a power
amplifier).
Headphones (PHONES)
This connection outputs an analog signal with an adjustable level.
►Connect headphones here.
Digital output (DIGITAL OUT)
These connections are for digital output signals.
►Use an electrical or optical digital cable.
21 3 4
HOW DO I CONNECT THE DEVICE?
111 Musiccenter
13
Connecting a network cable and USB components
ETHERNET
►Here, you can plug in an Ethernet network cable and connect it to your home
network router.
Please see the section “How Do I Operate the Musiccenter as a Pure Data Server
(ServerMode)?” on page31 and the “Instructions for Operation via the iPad App” for
more information on operation on a network.
USB 1 − 4
The USB slots allow you to connect USB components, such as
• An external hard disk to create a backup
(see “Instructions for Operation via a Web Browser”)
• A USB stick to install an update
(see “Performing a software update using a USB stick” on page34)
• A USB stick to play music
(see “How Do I Play Content from a USB Stick?” on page25)
►Insert the USB component.
ªIt should be detected automatically and ready for operation after a brief
configuration phase. Please see the corresponding sections for more detailed
information.
HOW DO I CONNECT THE DEVICE?
14
Connecting the remote control components
BURLINK
BURLINK (BURmester LINK) is an interface to control Burmester components via a set of
remote control commands developed by Burmester.
►Connect the Musiccenter and control system using an RS-232 cable.
Note: Please see the section “Symbols and text labels used” on page6 for more
information on using BURLINK.
REMOTE
Connecting the DCOUT socket on a separate device to the DCIN socket on a
Burmester device switches this device on and off along with the Musiccenter.
Correspondingly, connecting the DCIN socket to the DC-OUT socket on a Burmester
device switches the Musiccenter on and off whenever the connected device is turned
on or off.
►Connect the Musiccenter and a second Burmester device using a remote cable.
Burmester power amplifiers include an appropriate remote cable, which can also be
purchased from your specialist dealer.
IR IN
IRIN allows you to connect an additional infrared receiver. This infrared receiver can,
for example, be set up in a different room, enabling remote control of the Musiccenter
without direct visual contact with the device itself.
Connecting an external infrared receiver deactivates the internal receiver.
►Connect the infrared receiver’s connection cable to the IRIN socket.
Note: You can get additional infrared receivers directly from Burmester. There, the connection
cable is made based on your desired length.
HOW DO I CONNECT THE DEVICE?
111 Musiccenter
15
Connecting the Wi-Fi antennas
The connection between the iPad and Musiccenter is established via the Wi-Fi
antennas. You can either mount the two antennas directly to the connections on the
device or connect them via the antenna block. The antenna block and connecting cable
allow you to position the antennas higher, enabling a larger range.
To mount the antennas directly to the device:
1. Straighten the antenna hinges and screw the antennas onto the connection threads.
Make sure that the antennas do not tilt and the threads are not damaged.
2. The antennas feature a rotary, hinged base. After attachment, move the antennas
into the desired position and fold them upward.
Connecting the antennas via the antenna block:
1. Screw the two plugs onto the connection thread on the device. Make sure that the
plugs do not tilt and the threads are not damaged.
2. Straighten the antenna hinges and screw the antennas onto the connection threads
on the antenna block. Make sure that the antennas do not tilt and the threads are
not damaged.
3. Place the antenna block in a slightly elevated position above the Musiccenter.
HOW DO I CONNECT THE DEVICE?
16
Connecting the power cord
DANGER
Improper network cables or sockets
Network cables without a protective earth contact or sockets without a functional
protective earth connection can result in a life-threatening electric shock.
►Use only the supplied 3-wire power cord for power supply. The protective earth
contact must not be rendered ineffective.
►Connect the device only to an outlet with a functioning protective conductor
connection.
Connecting the power cord:
3The MAINS switch is set to OFF.
1. Plug in the supplied power cord and connect it to the power socket.
2. Switch the MAINS switch to ON.
ªNow, the POWER LED on the front of the device (see “What Operating and
Display Elements Are There?” on page17, point 8) will light up in green for
about 2seconds. At this moment, the device measures and adjusts to the power
supply. After this process is completed successfully, the POWER LED goes out.
Note: The device is disconnected from the power supply via the MAINS power switch. For this
reason, only switch MAINS to OFF when the device is in stand-by mode (POWER LED is
lit in orange) or if the POWER switch has been turned off (LED is not lit).
WHAT OPERATING AND DISPLAY ELEMENTS ARE THERE?
111 Musiccenter
17
W O D E A T
1 2 3 54 8
6 7
1 Rotary knob for selecting menu functions
• Turn to mark a menu item
• Press to select a menu item
2 Left bank of buttons for selecting functions
The respective button function is shown on the display.
3 CD drive
4 Infrared receiver
The IR receiver receives the remote control signals.
Do not place objects in front of the receiver.
5 Right bank of buttons for selecting functions
The respective button function is shown on the display.
6 Volume control
• Turn to change the volume
• Press to mute playback of the analog outputs
7 ON/OFF switch (POWER)
• OFF: The device is switched off. It cannot be switched on with the remote control. The LED is
not lit.
• STBY: The device is in stand-by mode and can be switched on using the remote control. The
LED lights up in orange.
• ON: Briefly pushing the switch upward switches on the device. The switch returns to the
center position. The LED lights up in red. Pushing the switch upward again returns the device
to standby mode.
• SERVER MODE: When the LED is lit in green, the Musiccenter is in server mode. For more
details, please see“How Do I Operate the Musiccenter as a Pure Data Server (ServerMode)?”
on page31.
8LED
• LED not lit: The device is switched off.
• LED lights up in orange: The device is in stand-by mode and can be switched on using the
remote control.
• LED lights up in red: the device is in operation.
• LED lights up in green: The device is in server mode. For more details, please see“How Do I
Operate the Musiccenter as a Pure Data Server (ServerMode)?” on page31.
WHAT FUNCTIONS DOES THE REMOTE CONTROL OFFER?
18
W F D R C
O
The remote control allows you to quickly access some frequently used functions, such
as device power on/off, volume control, as well as CD drive control. All additional
functions, however, are only available using the iPad.
The available functions:
POWER Switch the device on or into standby mode.
STOP Stop CD playback.
Start or pause CD playback.
Skip to the beginning of the track/previous/next CD track
MODE Gradually turn on the screen backlight
DIM Gradually dim or switch off the screen completely
VOLUME − / + Lower/increase the volume
HOW DO I SWITCH THE DEVICE ON?
111 Musiccenter
19
H D I S D
1. Move the POWER switch on the front side of
the device to the center position.
ªThe LED lights up in orange and the device
is in stand-by mode.
2. Briefly push the POWER switch upward or
press the POWER button on the remote
control.
ªThe LED lights up in red and the system
initiates. This process takes about one
minute.
The first time the system has been started, the
SetupWizard opens and guides you through the
basic settings.
3. Press the Start button.
You can now choose whether to operate the
device with or without a network connection.
4. To operate the device without a network
connection: Disconnect the network cable and
press the Stand-alone button.
To operate the device with a network
connection: Press the Standard button.
5. Press the Next button.
Note: You can change these settings at a later point in time.
Please see the section “How Do I Operate the Musiccenter as a Pure Data Server
(ServerMode)?” on page31 and the iPad operating instructions for more information
on operation on a network.
To switch the device into stand-by mode:
►Briefly push the POWER switch on the device upward or press the POWER button
on the remote control.
ªAfter the system is shut down, the device switches to standby mode.
Switching the device off completely:
►Press the POWER switch downward into the OFF position.
ªAfter the system is shut down, the device switches off. It can no longer be
switched on with the remote control.
Note: The device is disconnected from the power supply via the MAINS power switch on the
back side of the device. Only switch MAINS to OFF when the device is in stand-by
mode (STBY, LED is lit in orange) or if the POWER switch has been turned off (OFF, LED
is not lit).
WHAT OPTIONS DO I HAVE FOR OPERATING THE MUSICCENTER?
20
W O D I H O
M
The different options for operating the Musiccenter are described below.
Operating the Musiccenter using the buttons on the device
panel or the remote control
The easiest way to operate the Musiccenter is using the buttons on the device panel or
the remote control. You do not need a Wi-Fi connection to the Musiccenter or a
connection between the Musiccenter and your home network. However, only the basic
functions are available. Please see sections “What Operating and Display Elements Are
There?” on page17 and “What Functions Does the Remote Control Offer?” on
page18 for a more precise description of the buttons and functions.
Operating the Musiccenter via the iPad app
Using the Apple iPad and the BurmesterMC app, you can conveniently operate the
Musiccenter and use all its functions:
• Select the connected signal source.
• Start ripping a CD to the internal memory.
• Scroll through the covers of saved albums or display information on the albums and
artists.
• Create and play playlists.
• Listen to Internet radio or download high-resolution music from a provider (results in
use-dependent costs),
Note: Operating the system using the iPad app requires a Wi-Fi connection between the iPad
and the Musiccenter. Please see chapter “How Do I Establish a Wi-Fi Connection?” on
page22 for more information on how to establish a Wi-Fi connection.
Please see the separate document “Instructions for Operation via the iPad App” for
more information on installing and operating the iPad app.
Operating the Musiccenter via a web browser
You can also operate the Musiccenter without the app using a standard web browser
on any computer (tablet, PC, Mac). This is possible thanks to a graphic web interface
saved on the Musiccenter that can be started on the computer used. Operation offers
interested users advanced options for managing music and device settings.
Operation via a web browser requires the following:
• A computer (tablet, PC, Mac) with a web browser installed
• A LAN or Wi-Fi connection between the computer and the Musiccenter
Note: Please see chapter “How do I connect the music center to my home network?” on
page21 for more information on how to establish a LAN connection.
Please see the separate document “Instructions for Operation via a Web Browser” for
more information on how to operate the Musiccenter via a web browser.
Other manuals for 111 Musiccenter
2
Table of contents
