X-mini HAPPY Capsule Speaker User manual

Instruction Manual English
Manual de instrucciones Spanish
Manuel d'instruction French
Handleiding Dutch
Manuale di istruzioni Italiano
Bedienungsanleitung German
Manual de instruções Portuguese
Εγχειρίδιο οδηγιών Greek
取扱説明書 Japanese
Инструкция Russian
설명서 Korean
Please visit our website to register your product warranty http://www.x-mini.com/register/

X-mini™ HAPPY
CE Certicate
Declaration of Conformity
X-mini™ HAPPY Capsule Speaker™
EC-Declaration of Conformity to the essential requirements of the
applicable 89/336/EEC as last amended by EC Directive 93/68/EEC
We, (Xmi Pte Ltd), declare under our sole responsibility as author-
ized representative that the following product
Brand Name: X-mini™
Model Name: X-mini™ HAPPY Capsule Speaker™
Model No.: XAM5
Is fully in conformity with the essential requirement of the European
Council Directive 93/68/EEC.
This declaration is based on the full compliance of the product with
the following European standards:
EN 55022: 2006 + A1: 2007
EN 55024: 1998 + A1: 2001 + A2: 2003
English |
2

Introduction
Congratulations onyour purchase of an X-mini™ product. Xmi Pte Ltd in-
troduces the latest evolution of its Capsule Speaker™ genus, the X-Mini™
HAPPY. The newest addition to the X-Mini™ series has protean capa-
bilities and is equipped with an MP3 player and in-built SD/SDHC card
slot. The X-Mini™ HAPPY Capsule Speaker™ is the rst Portable Mu-
sic Player (PMP) to be developed by the multi-award-winning company.
Safety Rules
1) Please follow the rules depicted in this manual closely to ensure
your safety. Before using the speaker, we would strongly encourage
you to read through this user manual.
2) Be wary of any edges, uneven surfaces, metal parts, accessories
and its packaging so as to prevent any possible injury or damage.
3) Keep this speaker out of reach of children. Take note that this
speaker is not edible and should not be placed in your mouth.
4) Do not modify, repair or dismantle the speaker. Doing so may
result in res, electric shocks, complete breakdown of the speaker,
etc All of which, are not covered under warranty.
5) Do not use any diluents or volatile liquid to clean the speaker.
Keep in mind that the surface of the speaker should only be wiped
with a clean dry cloth.
6) Do not use this speaker in locations where there are high-temper-
atures or high humidity levels (For instance, bathrooms); ideally,
the speaker should be used in a location free of dust and exposure to
direct sunlight.
7) Do not insert foreign objects, such as pins, into this speaker.
8) Do not touch this speaker when your hands are wet as this may
result in electric shocks.
9) Turn down the volume before/while using this speaker as sudden
loud sounds may damage it.
10) Refrain from dropping the speaker as well as avoid any collision
with other objects.
11) Do not use this speaker when in hazardous locations.
12) Should any abnormal situations or problems occur while using
the speaker, discontinue use of speaker immediately.
X-mini™ HAPPY
English |
3

Package Contents
The Package will contain the following:
1 x X-mini™ HAPPY Capsule Speaker™
1 x User Manual
1 x USB Charging Cable
1 x Protection Pouch
1 x microSD card
1 x Earphone
X-mini™ HAPPY
English |
4
*The earphone image is for illustration purposes only, the actual earphone may differ.

Connection Diagram
X-mini™ HAPPY
English |
5

Buddy-Jack™
This all new feature enables you to connect one X-mini™ HAPPY
Capsule Speaker™ to another to form a self-powered, bass-enhanced
portable speaker system with a virtually endless “daisy chain” of
speakers. With this feature, you can now combine your X-mini™
HAPPY Capsule Speaker™ together with your friends’. You may
also connect previous generations of X-minis™ or even earphones
into the “Buddy-Jack™” to expand on volume or multi-functionality
X-mini™ HAPPY
English |
Connect other X-mini™ series into the Buddy-Jack™
to create jaw-dropping audio!
6

7
X-mini™ HAPPY
English |
Mode of Usage
MP3 playback mode
1 Insert supplied SD card into the SD slot
(Store your favourite songs!)
2 Turn on the X-mini™ HAPPY Capsule
Speaker™ at the Multi-function Jog Dial
(Press down and hold for few seconds)
3 Hold onto the top of the speaker and twist
anti-clockwise to reveal the BXS resonator
External Storage Mode
1 Insert supplied SD card into the SD slot
2 Connect one end of the supplied USB cable
to X-mini™ HAPPY Capsule Speaker™ mini USB port and the
other end to the USB port located on your computer

Mode of Usage
X-mini™ HAPPY
English |
External Source playback mode
1 Ensure the SD card is ejected from SD slot
2 Turn on the X-mini™ HAPPY Capsule Speaker™
with the Multi-function Jog Dial
(Press down and hold for few seconds)
3 Take out the built-in audio cable from the bottom of
the X-mini™ HAPPY Capsule Speaker™ and connect
it into any multimedia device with a 3.5mm audio port
4 Hold onto the top of the speaker and twist anti-
clockwise to reveal the Bass Xpansion System™
(BXS™) resonator
8

Earphone Mode
X-mini™ HAPPY
English |
1 Insert supplied SD card into the SD slot
(Store your favorite songs!)
2 Plug-in supplied ear-
phone or your favorite
earphone to the 3.5mm
jack located on the speaker
3 Turn on the X-mini™ HAPPY Capsule Speaker™
at the Multi-function Jog Dial
(Press down and hold for few seconds)
4 Press the “MUTE” button to turn on music on the
X-mini™ HAPPY Capsule Speaker™ and continue
to enjoy your favorite tunes through the earphones
9

10
X-mini™ HAPPY
English |
Connection
1 Connect part 1 to 2 (mini-USB plug connects to X-mini™ HAPPY
Capsule Speaker™)
2 Connect part 3 (USB Adaptor) to a free USB port located on your
computer
3 Speaker will go into External Storage mode
4 LED indicator will ash Red and Blue
5 LED will turn Purple to indicate that the speaker is fully charged
LED Indications:
Purple – Fully Charged
Red and Blue (alternate ashing) – Charging mode
Purple (ashing) – Read/Write to SD card
Red (ashing) – On MP3 playback mode, playing audio le
Red – On MP3 playback mode, paused playback
Blue (ashing) – Playing through the 3.5mm audio cable or SD card
has been ejected

Technical Specication
X-mini™ HAPPY
X-mini™ HAPPY Capsule Speaker™
Dimension(L×W×H) : 60mm×49.1 mm (closed resonator)
Net Weight : 88g
Speaker : Magnetically Shielded 40mm(4Ω)
Loudspeaker Output : 2.5W
Frequency Response : 230Hz~20K Hz
Signal-to-Noise : ≥70dB
Distortion : ≤5.0%
Playback Time : Up to 12 hours
(Audio playback through 3.5mm jack)
Battery Voltage/Capacity : 550mAh
Battery Charging Voltage : 5V/+0.5V
Battery Charge Time : 5V - 2.5 hours
MP3 Player Specs
Storage Capacity : Supporting up to 8GB High Capacity
class4 SD card
Battery Life : Up to 5 hours
(MP3 Playback through SD/SDHC Card)
Audio Playback Format : MP3 and WMA
USB Interface : High Speed USB 2.0
Operating System : Microsoft Windows Vista, XP SP2,
Mac OS 10x
11
English |

F.A.Q
X-mini™ HAPPY
1. Why was there no power when the Jog Dial was held for few sec-
onds?
Ans: Ensure that the battery has been charged for up to 4 hours. Please
refer to Pg10 on how to charge the speaker.
2. There is no sound when playing music under the MP3 mode?
Ans: Check to see if the volume is too low. If it is too low, turn it
up. Check that the SD card is has been inserted correctly. Check that
the SD card has stored supported media les in it. Ensure the SD card
is not HC class 6 and above.
3. The bass production is missing.
Ans: The vacuum might be punctured. If so, please check warranty
coverage.
4. Is this a USB Storage device?
Ans: Yes. The mini-USB port functions as a charging port and for
data transfer. Use the attached 3.5mm stereo plug for audio inputs on
external source playback mode.
5. How do I know that the speaker has been fully charged?
Ans: When the indicator LED turns to purple, it has been fully
charged.
6. After connecting the speaker to the computer, I cannot nd the
“Removable Disk” or locate the SD card contents.
Ans: (a) Check if USB cable is connected correctly between Computer
and the speaker’s USB port
(b) Try to unplug and plug the USB cable into your computer’s USB
port
(c) Try plug into another USB port located on your computer
12
English |

F.A.Q
X-mini™ HAPPY
7. Why can I not delete or overwrite the data in the SD card under
External Storage mode?
Ans: (a) Please ensure the SD card is not in write-protected mode by
checking for a switch or button on the side of the micro SD card or
adapter. It might have a lock/unlock symbol on it. Move the switch to
the “Unlocked” position to remove write protection
(b) Ensure the data or le is not in use when trying to delete or
overwrite
8. What type of les can be stored in the SD card?
Ans: The SD card behaves like any other hard drive and supports
storage
of all types of les as long as it can be supported by the operating
system
9. Can I play and listen to my music les directly from the X-mini™
HAPPY Capsule Speaker™ through the computer?
Ans: Yes, under External Storage mode, you can open all types of
les as long as it can be supported by the operating system
13
English |

X-mini™ HAPPY
Warranty
If within 12 months of purchase this device or any part thereof
is proven to be defective by reason of faulty workmanship or
defects in materials, we will at our option repair or replace the
same free of charge of labor or materials on the conditions that:
1) This Limited Warranty is valid only if the original proof of
purchase
of this product issued by an Xmi Pte Ltd Authorized Dealer specify-
ing the date of purchase, is presented with the product to be repaired
or replaced.
2) Xmi Pte Ltd reserves the right to refuse warranty service if the
original
proof of purchase has been removed, changed or missing.
3) This Limited Warranty does not cover wear and tear of a re-
chargeable battery. The nature of a rechargeable battery is that it can
be charged and discharged more than a hundred times so its eventual
wear out is normal and this is not a defect.
4) This Limited Warranty does not cover Product failures which have
been caused by the use of accessories or other peripheral devices
which are not X-mini™ branded original accessories intended for use
with the Product.
5) This Limited Warranty does not cover any damage caused by
dropping or hitting of the product or misuse or neglect of the product.
6) This Limited Warranty does not cover Product failures caused by
modications, repair or disassembly by any person not authorized by
the manufacturer.
7) Any defective unit or part or Product shall become property of the
manufacturer.
14
English |

X-mini™ HAPPY
Spanish |
Certicado CE
Declaración de Conformidad
X-mini™ HAPPY Capsule Speaker™
Declaración de Conformidad EC con los requisitos esenciales de las
normas aplicables 89/336/EEC con las últimas reformas por parte de
las Directivas EC 93/68/EEC
Nosotros (Xmi Pte Ltd), declaramos bajo nuestra única responsabili-
dad como representantes autorizados que el siguiente producto
Nombre de la Marca comercial: X-mini™
Modelo: X-mini™ HAPPY Capsule Speaker™
Número de Modelo: XAM5
Cumple totalmente con los requisitos esenciales de las Directivas del
Consejo Europeo 93/68/EEC.
Esta declaración se basa en la compatibilidad total del producto con
las Normas Europeas:
EN 55022: 2006 + A1: 2007
EN 55024: 1998 + A1: 2001 + A2: 2003
15

X-mini™ HAPPY
Spanish |
Introducción
¡Felicitaciones por comprar un producto X-mini™! Xmi Pte Ltd
presenta la más reciente evolución de su Capsule Speaker™ genus,
el X-Mini™ HAPPY. La adición más reciente de la serie X-Mini™
tiene capacidades versátiles y está equipado con reproductor MP3 y
ranura de tarjetas SD/SDHC integrada. El X-Mini™ HAPPY Cap-
sule Speaker™ es el Primer Reproductor Portátil de Música (PMP)
desarrollado por una compañía ganadora de múltiples premios.
Normas de Seguridad
1) Por favor siga estrictamente las normas descritas en este manual para garantizar
su seguridad. Antes de usar el altavoz, le sugerimos rotundamente que lea com-
pletamente el manual del usuario.
2) Tenga cuidado con los bordes, supercies irregulares, partes metálicas, acceso-
rios y su empaque para prevenir cualquier lesión o daño.
3) Mantenga este altavoz fuera del alcance de los niños. Tenga en cuenta que este
altavoz no es comestible y por lo tanto no debe ponerlo en su boca.
4) No modique, repare ni desarme el altavoz. Hacerlo puede desencadenar
incendios, descargas eléctricas, daño completo del altavoz, etc. Todo lo anterior no
está cubierto por la garantía.
5) No use ningún disolvente o líquido volátil para limpiar el altavoz. Tenga
presente que la supercie del altavoz solamente la debe limpiar con un trapo
limpio y seco.
6) No use este altavoz en lugares con altas temperaturas o niveles de humedad
altos. (Por ejemplo, los baños); idealmente, el altavoz se debería usar en lugares sin
polvo y sin exposición directa a los rayos solares.
7) No inserte objetos extraños, tales como pasadores en el altavoz.
8) No toque el altavoz con sus manos mojadas porque puede ocasionar descargas
eléctricas.
9) Baje el volumen antes/mientras usa este altavoz porque los sonidos altos
repentinos pueden dañarlo.
10) Absténgase de dejar caer el altavoz así como también evite colisiones con
otros objetos.
11) No use este altavoz en lugares peligrosos.
12) Si se presentan situaciones anormales o problemas mientras use este altavoz,
deje de usarlo inmediatamente.
16

X-mini™ HAPPY
Spanish |
Contenido del paquete
El paquete contiene lo siguiente:
1 X-mini™ HAPPY Capsule Speaker™
1 Manual del usuario
1 Cable USB para carga
1 Bolsita de protección
1 Tarjeta microSD
1 juego de auriculares
17
*A imagem dos auscultadores é apenas ilustrativa, podendo diferir do original.

X-mini™ HAPPY
Spanish |
Diagrama de conexiones
18

X-mini™ HAPPY
Spanish |
Buddy-Jack™
Todas las funciones nuevas le permiten conectar un X-mini™
HAPPY Capsule Speaker™ con otro para formar un sistema de al-
tavoz, portátil, auto generador de energía, con bajos mejorados y
con virtualmente innita “cadena de margarita” de los altavoces.
Con esta función, usted puede combinar su X-mini™ HAPPY
Capsule Speaker™ con los de sus amigos. También puede conec-
tar versiones anteriores de X-minis™ o incluso auriculares en el
“Buddy-Jack” para expandir el volumen o la multi-funcionalidad.
Conecte otra serie de X-mini™ en el Buddy-Jack™ para crear audio
¡sorprendente!
19

X-mini™ HAPPY
Spanish |
Modo de uso
Modo de reproducción MP3
1 Tarjeta SD suministrada en la ranura para tarjetas SD
(¡Guarde sus canciones favoritas!)
2 Encienda el X-mini™ HAPPY Capsule Speaker™
con el selector táctil multifuncional
(Presione y sostenga durante algunos segundos)
3. Sostenga la parte superior del altavoz y gire
en sentido antihorario para revelar el resonador BXS
Modo de almacenamiento externo
1 Inserte la tarjeta SD suministrada en la ranura para
tarjetas SD
2 Conecte un extremo del cable USB suministrado al mini puerto
USB del X-mini™ HAPPY Capsule Speaker™ y el otro extremo al
puerto USB ubicado en su ordenador.
20
