SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Page 20
9 ft 9 inches
2 inches
(width x length) 10 ft 3 inches x 9 ft 4 inches (Lift), 10 ft 3 inches x 13 ft (Pull)
3Point Cat. II & III Standard & Quick Hitch, Center Pull Self Leveling or Semi-Mount Cat. II & III
2 to 12 inches
11 gauge
7 gauge x 10 inches
40 PTO (Pull), 60 PTO (Lift)
ASAE Category 4
Rubber Element
120 Main and 90 Outboard
540/1000 RPM
4 Plate PTO Slip Clutch
Choice of Manual Height Bundle or Hydraulic Cylinder
Round Pans
1/2 x 4 inches - Corner Uplift
15,778 FPM/540 RPM; 15,708 FPM/1000 RPM
Laminated Tire on Lift and Semi-Mount Models, Laminted Tire or 15 inch Automotive Wheel on Pull Models, Used Aircraft Tires on Pull Type Only
Adjustable Axle Arms for Row Spacing, Choice of Single or Dual Axles on Pull Models
Standard Front Belting and Rear Bands (Chains Optional)
Standard for Pull Models
1922 lbs (Lift), 2177 lbs (Pull), 1929 lbs (Semi-Mount)
Single Row Chain Deflectors for Front and Rear
1 year limited warranty with a 5 year gearbox limited warranty
•Rear Sloped Deck • High blade tip speeds • Deep sidebands • Quick detach gearbox shields
