C. Crane SOFTSPEAKER 3K Manual

Power Button - Press briefly to turn ‘ON’ the Amp for one hour.
Extend time by holding the power button longer: (1 light = 1
hour), (2 lights = 4 hours), (3 lights = 8 hours). The sleep timer is
always set to save batteries and only works with AMP ‘ON’.
Indicator Lights - Shows the sleep timer hours when the POWER
(A) button is held. It also shows approximate battery level when
BATTERY (D) button is held.
Volume Control - Changes volume when dial is rotated.
Battery Tester - Press and hold to check battery life: (1 indicator
light = 1% - 33%), (2 lights = 34% - 66%), (3 lights = 67% - 100%)
TONE Switch - Changes tone between ‘VOICE’ (up position) and
‘Music’ (down position). The ‘Voice’ setting is tuned for listening
to audio books and talk radio. The ‘Music’ setting provides full
range audio with a boost but consumes about 50% more power.
AMP Switch – When AMP is “ON” you should receive approxi-
mately 80 hours of amplified volume. When the batteries become
low, switch the AMP to “OFF”
for low volume (non-amplified) operation. This gives you 100+
additional hours. The TONE switch is disabled when AMP switch
is “OFF”.
Batteries - Requires 2 AAA (Alkaline or NiMH) batteries. See
battery orientation in diagram on this page. Battery life is about
80 hours when using the ‘Voice’ tone setting.
Battery Compartment Cover - Push indented arrow and slide
down to remove cover.
CONTROLS AND FUNCTIONS
PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE.
Lorem ipsum
Lorem ipsum
Rev. R3 7-13-2021

1. Make indent in your pillow
2. Place SoftSpeaker on indented area with pocket side down
3. Connect plug to standard 1/8” (3.5mm) headphone jack on
audio source (Radio, Phone, Tablet, TV, Computer, etc.)
Washing Instructions:
To remove the speaker before washing, gently separate the cover at
its center opening and slide the speaker out. Hand or machine wash
cover in cold water, gentle cycle. Wash with dark colors, Dry cool.
CAUTION! - Continuous use at high volume may damage hearing.
Specifications:
Sensitivity: 115 dB
Frequency: 20-20,000 Hz
Impedance: 32 Ohm
Cable length: 78”
Driver unit: 38mm
Warranty: 1 Year
Copyright 2021 by C. Crane, Fortuna, CA 95540 All rights reserved. No part of the booklet may be reproduced, in any form or means whatsoever, without permission in writing from C. Crane.
USAGE AND SPECIFICATIONS
Specifications are subject to change without notice.
