C4L6400-EoC- Transceiver Field Application
C4L6400-EoC-P transceivers are used to extend the Ethernet IP signals via coax cable in the existing
coax network in building.
C4L6400-EoC-P transceiver could reduce the cabling costs to upgrade from the installed analog video
cameras to Mega-pixel grade IP cameras with the existing coax cables.
For the other field applications, C4L6400-EoC-P transceivers could be applied to connect, distribute and
convert the IP devices(IPTV, VOIP Phone, Wireless AP, etc.) signals via the coax cable with 128bit AES
Encryption and guaranteed QoS for loss sensitive application.
C4L6400-EoC- Transceiver
Quick Start Guide
• Both transceivers are now in Joining mode. They will find each
other and establish encrypted communication. In about 10 seconds,
the BNC LEDs on both transceivers will illuminate (blinking or steady
on), indicating a successful Join.
C4L6400-EoC- connection diagram
C4L6400-EoC- Installation Steps
Step 1. Hardware Check and reparation
• Please check the product physical defects. If you find the defects, do not operate the product.
• Prepare 1) Network cable, 2) Legacy coax cable, ) 48VDC Power supply to C4L6400-EoC-P
units. (Please check the cable short, Spec. and connection status)
Step 2 . Installation
• Use one C4L6400-EoC-P transceiver at each end of the coax. Up to four remote transceivers and
coax runs may be connected to a fifth transceiver at the control room using BNC “T” adaptors.
• Connect a 48V DC power supply into one of the transceivers to provide power to the entire system,
including the cameras.
• Single camera loads up to 40 watts, or four 10 watt cameras are supported by the 48VDC 60W
power supply.
• All transceivers are in Join Mode. They will find each other and establish basic level encrypted
communication.
If you use more than 1 master unit or large installation site, you should
follow the Un-joining and Joining steps as below.
Un-Joining and Joining Transceivers for Encrypted communication(Optional)
If you want to build enhanced encrypted communication Network Group to another, it must be returned
to an un-joined state.
Step 1.Un-Joining mode to build enhanced encrypted network
• Do this by applying 48VDC power, and pressing the small push-button (Grp) for 10 seconds until
the BNC and PoE LEDs illuminate and then go out, about one seconds. The transceiver is now
ready to be joined to build encrypted Network Group.
Step 2. Joining mode
• For more transceivers in an enhanced encrypted network, disconnect the joined transceiver from
grouped coax cable and connect the new un-joined transceiver.
• On transceiver number 1, using the straightened paper-clip, momentarily depress the small push-
button (Grp). The PoE LED will blinking.
• Depress the same small push-button(Grp) on the second transceiver.
Step 3. Adding Transceivers (if required)
• Disconnect one of the transceivers and replace it with a new un-joined transceiver.
• Repeat step two to add additional transceivers to the same Network Group.
ower over Ethernet ( oE) Function
• C4L6400-EoC-P support IEEE 802. af. and 802. at. PoE.
• C4L6400-EoC-P support 40Watt local PoE for IP camera power supply.
C4L6400-EoC Installation Warnings
• Do not use the transceiver near the harsh (temperature, humidity, cabling quality) installation site.
• If transceiver flooded by water or other liquid materials, please turn off the power source and
disconnect all of cables from transceiver. And request to C4Line technical team for after service
asap.
• Do not use transceiver over 120℉ (50℃) temperature condition for transceiver’s operation
performance and lifetime.
• Do not disassemble transceiver at a person’s service.
