Cadillac 2009 CTS User manual

Seats and Restraint System ............................. 1-1
Head Restraints ......................................... 1-2
Front Seats ............................................... 1-4
Rear Seats .............................................. 1-13
Safety Belts ............................................. 1-14
Child Restraints ....................................... 1-33
Airbag System ......................................... 1-55
Restraint System Check ............................ 1-71
Features and Controls ..................................... 2-1
Keys ........................................................ 2-3
Doors and Locks ...................................... 2-17
Windows ................................................. 2-23
Theft-Deterrent Systems ............................ 2-27
Starting and Operating Your Vehicle ........... 2-31
Mirrors .................................................... 2-53
Object Detection Systems .......................... 2-54
OnStar
®
System ...................................... 2-57
Universal Home Remote System ................ 2-61
Storage Areas ......................................... 2-65
Sunroof .................................................. 2-66
Instrument Panel ............................................. 3-1
Instrument Panel Overview .......................... 3-4
Climate Controls ...................................... 3-24
Warning Lights, Gages, and Indicators ........ 3-30
Driver Information Center (DIC) .................. 3-49
Audio System(s) ....................................... 3-80
Driving Your Vehicle ....................................... 4-1
Your Driving, the Road, and the Vehicle ....... 4-2
Towing ................................................... 4-26
Service and Appearance Care .......................... 5-1
Service ..................................................... 5-4
Fuel ......................................................... 5-6
Checking Things Under the Hood ............... 5-12
All-Wheel Drive ........................................ 5-53
Rear Axle ............................................... 5-54
Headlamp Aiming ..................................... 5-55
Bulb Replacement .................................... 5-58
Windshield Wiper Blade Replacement ......... 5-61
Tires ...................................................... 5-63
Appearance Care ................................... 5-109
Vehicle Identification ............................... 5-118
Electrical System .................................... 5-119
Capacities and Specifications ................... 5-133
Maintenance Schedule ..................................... 6-1
Maintenance Schedule ................................ 6-2
Customer Assistance Information .................... 7-1
Customer Assistance and Information ........... 7-2
Reporting Safety Defects ........................... 7-16
Vehicle Data Recording and Privacy ........... 7-18
Index ................................................................ 1
2009 Cadillac CTS/CTS-V Owner Manual M

GENERAL MOTORS, GM, the GM Emblem, CADILLAC,
the CADILLAC Crest & Wreath, and the name CTS
are registered trademarks, and the name CTS-V
is a trademark, of General Motors Corporation.
Music recognition technology and related data
are provided by Gracenote
®
. Gracenote is the
industry standard in music recognition technology
and related content delivery. For more information,
visit www.gracenote.com.
DTS AND DTS Digital Surround are registered
trademarks of Digital Theater Systems, Inc.
Dolby
®
is manufactured under license from Dolby
®
Laboratories. Dolby
®
and the double-D symbol
are trademarks of Dolby
®
Laboratories.
Litho in U.S.A.
Part No. 25795635 B Second Printing
©
2008 General Motors Corporation. All Rights Reserved.
ii

This manual includes the latest information at the time it
was printed. GM reserves the right to make changes
after that time without notice. For vehicles first sold
in Canada, substitute the name “General Motors
of Canada Limited” for Cadillac Motor Car Division
wherever it appears in this manual.
This manual describes features that may or may not be
on your specific vehicle.
Read this manual from beginning to end to learn about
the vehicle’s features and controls. Pictures, symbols,
and words work together to explain vehicle operation.
Keep this manual in the vehicle for quick reference.
Canadian Owners
A French language copy of this manual can be obtained
from your dealer/retailer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
www.helminc.com
Propriétaires Canadiens
On peut obtenir un exemplaire de ce guide en français
auprès de concessionnaire ou à l’adresse suivante:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
www.helminc.com
Index
To quickly locate information about the vehicle, use the
index in the back of the manual. It is an alphabetical
list of what is in the manual and the page number where
it can be found.
iii

Safety Warnings and Symbols
A circle with a slash
through it is a safety
symbol which means
“Do Not,” “Do not do this,”
or “Do not let this happen.”
A box with the word CAUTION is used to tell about
things that could hurt you or others if you were to ignore
the warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
Cautions tell what the hazard is and what to do to avoid
or reduce the hazard. Read these cautions.
A notice tells about something that can damage the
vehicle.
Notice: These mean there is something that could
damage your vehicle.
Many times, this damage would not be covered by the
vehicle’s warranty, and it could be costly. The notice
tells what to do to help avoid the damage.
There are also warning labels on the vehicle which use
the same words, CAUTION or Notice.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along
with the text describing the operation or information
relating to a specific component, control, message,
gage, or indicator.
M:This symbol is shown when you need to see your
owner manual for additional instructions or information.
*:This symbol is shown when you need to see a
service manual for additional instructions or information.
iv

Vehicle Symbol Chart
Here are some additional symbols that may be found on
the vehicle and what they mean. For more information
on the symbol, refer to the index.
9:Airbag Readiness Light
#:Air Conditioning
!:Antilock Brake System (ABS)
g:Audio Steering Wheel Controls or OnStar
®
$:Brake System Warning Light
":Charging System
I:Cruise Control
B:Engine Coolant Temperature
O:Exterior Lamps
#:Fog Lamps
.:Fuel Gage
+:Fuses
i:Headlamp High/Low-Beam Changer
j:LATCH System Child Restraints
*:Malfunction Indicator Lamp
::Oil Pressure
}:Power
/:Remote Vehicle Start
>:Safety Belt Reminders
7:Tire Pressure Monitor
F:Traction Control
M:Windshield Washer Fluid
v

✍NOTES
vi

Head Restraints ...............................................1-2
Front Seats ......................................................1-4
Manual Seats ................................................1-4
Power Seats ..................................................1-5
Power Lumbar ...............................................1-6
Power Lumbar and Side Bolsters ......................1-6
Heated and Ventilated Seats ............................1-7
Memory Seat, Mirrors and Steering Wheel .........1-8
Reclining Seatbacks ......................................1-10
Rear Seats .....................................................1-13
Split Folding Rear Seat .................................1-13
Safety Belts ...................................................1-14
Safety Belts: They Are for Everyone ................1-14
How to Wear Safety Belts Properly .................1-19
Lap-Shoulder Belt .........................................1-27
Safety Belt Use During Pregnancy ..................1-32
Safety Belt Extender .....................................1-32
Child Restraints .............................................1-33
Older Children ..............................................1-33
Infants and Young Children ............................1-36
Child Restraint Systems .................................1-39
Where to Put the Restraint .............................1-41
Lower Anchors and Tethers
for Children (LATCH) .................................1-43
Securing a Child Restraint in a
Rear Seat Position ....................................1-49
Securing a Child Restraint in the
Right Front Seat Position ............................1-52
Airbag System ...............................................1-55
Where Are the Airbags? ................................1-57
When Should an Airbag Inflate? .....................1-60
What Makes an Airbag Inflate? .......................1-61
How Does an Airbag Restrain? .......................1-61
What Will You See After an Airbag Inflates? .....1-62
Passenger Sensing System ............................1-63
Servicing Your Airbag-Equipped Vehicle ...........1-69
Adding Equipment to Your
Airbag-Equipped Vehicle .............................1-70
Restraint System Check ..................................1-71
Checking the Restraint Systems ......................1-71
Replacing Restraint System Parts
After a Crash ............................................1-72
Section 1 Seats and Restraint System
1-1

Head Restraints
The vehicle’s front seats have adjustable head restraints
in the outboard seating positions.
The vehicle’s rear seats have head restraints in the
outboard seating positions, but they are not adjustable.
{CAUTION:
With head restraints that are not installed and
adjusted properly, there is a greater chance that
occupants will suffer a neck/spinal injury in a
crash. Do not drive until the head restraints for
all occupants are installed and adjusted properly.
Adjust the head restraint so that the top of the restraint
is at the same height as the top of the occupant’s head.
This position reduces the chance of a neck injury in a
crash.
1-2

Pull the head restraint up
to raise it. To lower the
head restraint, press the
button, located on the top
of the seatback, and push
the restraint down.
Push down on the head restraint after the button is
released to make sure that it is locked in place.
The vehicle’s head restraints are not designed to be
removed.
Active Head Restraint System
On vehicles with an active head restraint system in the
front outboard seating positions, the head restraints
automatically tilt forward to reduce the risk of neck injury
if the vehicle is hit from behind.
1-3

Front Seats
Manual Seats
{CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver’s seat while the vehicle is
moving. The sudden movement could startle and
confuse you, or make you push a pedal when you
do not want to. Adjust the driver’s seat only when
the vehicle is not moving.
To move a manual seat forward or rearward:
1. Lift the bar to unlock
the seat.
2. Slide the seat to the
desired position and
release the bar.
Try to move the seat with your body to be sure the seat
is locked in place.
1-4

Manual Leg Extension
On vehicles with this feature, adjust the manual leg
extension by reaching under it, in the pocketed area.
Press the release button and pull or push to lengthen
or shorten it. Release the button to lock it in place.
Power Seats
On vehicles with power seats, the controls are located
on the outboard side of the seats.
•Move the seat forward or rearward by sliding the
horizontal control forward or rearward.
•Raise or lower the front part of the seat cushion by
moving the front of the horizontal control up or down.
1-5

•Raise or lower the rear part of the seat cushion by
moving the rear of the horizontal control up or down.
•Raise or lower the entire seat by moving the entire
horizontal control up or down.
The vertical control is used for reclining the seatback.
See “Power Reclining Seatbacks” under Reclining
Seatbacks on page 1-10 for more information.
Power Lumbar
The vehicle may have
this feature. The driver
and passenger seatback
lumbar support can be
adjusted by moving the
control located on the
outboard side of the
seat cushions.
To increase or decrease support, hold the control
forward or rearward. Adjust the seat as needed.
Power Lumbar and Side Bolsters
A. Seat Cushion Bolster Adjustment Switch
B. Lumbar Support Control Switch
C. Seatback Bolster Adjustment Switch
1-6

Power Lumbar
On vehicles with this feature:
•Press and hold the top of the control (B) to increase
support to the top of the seatback and decrease
support to the bottom of the lumbar.
•Press and hold the bottom of the control to
decrease support to the top of the seatback and
increase support to the bottom of the seatback.
•Press and hold the front or rear of the control to
increase or decrease support to the entire seatback.
Side Bolster
On vehicles with this feature:
•Press the top or bottom of control (A) to increase or
decrease support in seat cushion bolsters.
•Press the top or bottom of the control (C) to
increase or decrease support in the seatback
bolsters.
Heated and Ventilated Seats
On vehicles with this feature, the buttons are located on
the climate control panel.
z(Heated Seat and Seatback): Press to heat the
seat and seatback.
{(Ventilated Seat): Press to ventilate the seat.
A light bar in the climate control display shows the
setting; high, medium, or low.
Press either button to start that feature at the highest
setting. Each press of the button, decreases the setting.
To turn the feature off, press the button until the light
turns off.
The heated or ventilated seats shut off when the vehicle
is turned off.
1-7

Memory Seat, Mirrors and Steering
Wheel
On vehicles with the memory package the controls
are located on the driver door. This feature is used to
program and recall memory settings for the driver seat,
outside mirror, and the steering wheel position if the
vehicle has the power tilt wheel and telescopic steering
feature.
1: Saves the seating position for driver 1.
2: Saves the seating position for driver 2.
S:Recalls the easy exit position.
To save your positions in memory:
1. Adjust the driver seat, seatback recliner and
lumbar, both outside mirrors, and the steering
wheel to a comfortable position.
2. Press and hold button 1 until two beeps sound
through the driver side front speaker to let you
know that the position has been stored.
3. Repeat the procedure for a second driver using
button 2.
To recall memory positions, the vehicle must be in
P (Park) for an automatic transmission or the parking
brake applied for a manual transmission. Press and
release either button 1 or button 2. A single beep will
sound. The seat, outside mirrors, and steering wheel will
move to the position previously stored for the identified
driver.
If the Remote Keyless Entry (RKE) transmitter is used to
enter the vehicle and the remote recall memory feature is
on, automatic seat and mirror movement occur.
On vehicles with the Keyless Access System, automatic
adjustment occurs when the driver door is opened.
To stop recall movement of the memory feature at any
time, press one of the power seat controls, memory
buttons, power tilt wheel control, or power mirror
buttons.
1-8

If something has blocked the driver seat or the steering
column while recalling a memory position, the recall may
stop. Remove the obstruction, then press the appropriate
control for the area that is not recalling for two seconds.
Try recalling the memory position again by pressing the
appropriate memory button. If the memory position is
still not recalling, see your dealer/retailer for service.
Easy Exit Recall
S:With the vehicle in P (Park) for an automatic
transmission or the parking brake applied for a manual
transmission, press the exit button to recall the exit
position.
If the easy exit seat feature is on in the DIC, automatic
seat and power telescopic steering column movement
occurs when the key is removed from the ignition.
On vehicles with the Keyless Access System, automatic
adjustment occurs when the ignition is turned to OFF
and the driver door is opened.
A single beep sounds. The driver seat moves back, and
if the vehicle has the power tilt wheel and telescopic
steering feature, it moves up and forward.
See “EASY EXIT RECALL” under DIC Vehicle
Customization on page 3-71 for more information.
For more programming information, see DIC Vehicle
Customization on page 3-71.
1-9

Reclining Seatbacks
Manual Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver’s seat while the vehicle is
moving. The sudden movement could startle and
confuse you, or make you push a pedal when you
do not want to. Adjust the driver’s seat only when
the vehicle is not moving.
{CAUTION:
If either seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatbacks to be sure they
are locked.
If the front passenger seat has a manual reclining
seatback, the lever used to operate it is located on the
outboard side of the seat.
1-10

To recline the seatback:
1. Lift the recline lever.
2. Move the seatback to the desired position, then
release the lever to lock the seatback in place.
3. Push and pull on the seatback to make sure it is
locked.
To return the seatback to an upright position:
1. Lift the lever fully without applying pressure to the
seatback and the seatback will return to the upright
position.
2. Push and pull on the seatback to make sure it is
locked.
Power Reclining Seatbacks
If the seats have power reclining seatbacks, use the
vertical power seat control located on the outboard side
of each seat.
•To recline the seatback, press the control toward
the rear of the vehicle.
•To raise the seatback, press the control toward the
front of the vehicle.
1-11

{CAUTION:
Sitting in a reclined position when your vehicle is
in motion can be dangerous. Even if you buckle
up, your safety belts cannot do their job when you
are reclined like this.
The shoulder belt cannot do its job. In a crash,
you could go into it, receiving neck or other
injuries.
The lap belt cannot do its job either. In a crash
the belt could go up over your abdomen. The belt
forces would be there, not at your pelvic bones.
This could cause serious internal injuries.
For proper protection when the vehicle is in motion,
have the seatback upright. Then sit well back in the
seat and wear your safety belt properly.
Do not have a seatback reclined if the vehicle is
moving.
1-12

Rear Seats
Split Folding Rear Seat
The vehicle may have a split folding rear seat.
To lower one or both of the rear seatbacks:
1. Pull forward on the tab,
located on the outboard
side of the seatback,
to unlock the seatback.
Notice: Folding a rear seat with the safety belts
still fastened may cause damage to the seat or
the safety belts. Always unbuckle the safety belts
and return them to their normal stowed position
before folding a rear seat.
2. Fold the seatback down. This allows access to
the trunk.
See Trunk on page 2-20 for more information.
To return the seatback to the upright position:
{CAUTION:
If either seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatbacks to be sure they
are locked.
1. Lift the seatback up and push it back into place.
2. Make sure the seatback is locked into place
by pushing and pulling on it.
3. Repeat Steps 1 and 3 for the other seatback.
When the seatback is not in use, it should be kept in
the upright, locked position.
1-13

Safety Belts
Safety Belts: They Are for Everyone
This section of the manual describes how to use
safety belts properly. It also describes some things
not to do with safety belts.
{CAUTION:
Do not let anyone ride where a safety belt cannot
be worn properly. In a crash, if you or your
passenger(s) are not wearing safety belts, the
injuries can be much worse. You can hit things
inside the vehicle harder or be ejected from the
vehicle. You and your passenger(s) can be
seriously injured or killed. In the same crash, you
might not be, if you are buckled up. Always fasten
your safety belt, and check that your passenger(s)
are restrained properly too.
{CAUTION:
It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed. Do not allow people to ride in any
area of your vehicle that is not equipped with seats
and safety belts. Be sure everyone in your vehicle is
in a seat and using a safety belt properly.
This vehicle has indicators as a reminder to buckle the
safety belts. See Safety Belt Reminders on page 3-34
for additional information.
In most states and in all Canadian provinces, the law
requires wearing safety belts. Here is why:
You never know if you will be in a crash. If you do have
a crash, you do not know if it will be a serious one.
A few crashes are mild, and some crashes can be so
serious that even buckled up, a person would not survive.
But most crashes are in between. In many of them,
people who buckle up can survive and sometimes walk
away. Without safety belts, they could have been badly
hurt or killed.
After more than 40 years of safety belts in vehicles,
the facts are clear. In most crashes buckling up does
matter... a lot!
1-14
