Cairn FOG 3 User manual

OWNER’S
MANUAL
FOG 3 CD Player
When digital becomes human
cairn
FOG3

Introduction
cairn
Congratulations, you own a unique device!
Cairn & Ezo staff wish you will spend a pleasant time using
The CD Player is easy to use. This startup guide gives you the necessary elements to set it up in
a few seconds. We recommend you to refer to the owner’s manual to take full advantage of all the
features. You will also discover how to build your system around
FOG3
FOG3.
FOG 3
CE Declaration of conformity
FCC notice
Cairn declare that this product is in conformance with the Low Voltage Directive 73/23/EEC.
The conformity of the designated product with the provisions of directive number 73/23/EEC (LVD) is
proved by full compliance with the following standards:
Standard EN60065 (1993) test type: Marking, ionizing, heating under normal conditions, shock hazards
under normal operating instructions, insulation requirements, fault conditions, mechanical strength,
parts connected to the mains supply, components, terminal cords, electrical connections and
mechanical fixings.
The conformity of the designated product with the provisions of directive number 89/336/EEC (EMC) is
proved by full compliance with the following standards:
Standard number Date of issue Test type
EN55013 2001 Conducted emissions
EN55013 2001 Absorbed emissions
EN60555-2 1994 Hamonics
EN60555-3 1994 Voltage fluctuations
EN55020 2002 Immunity
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designated to provide reasonable protection
Release 1.04
-Before removing mains supply, take care to turn the device in sleep mode because overvoltage
could damage it.
-Do not use extension lead between the outlet and the device.
-Unauthorised opening of the device cancel the manufacturer warranty.
-Do not cover the air cooling
-Put the device far from source.
-Do not introduce anything into the device.
DO NOT REMOVE THE COVER, SHOCK HAZARD.
THE DEVICE IS DELIVERED WITH A POWER CORD MATCHING WITH THE ELECTRICAL STANDARDS OF THE
COUNTRY OF DESTINATION.
THE DEVICE NOT CONTAIN ANY COMPONENT THE USER CAN REPARE HIMSELF.
IN CASE OF TROUBLESHOOTING, PLEASE CONTACT YOUR REGISTERED DEALER.
USE THE SAME TYPE OF FUSE AS THE ORIGINAL.
DO NOT EXPOSE TO MOISTURE..
Maintenance
WARNING
grid.
warmth
DOES
First, unplug your product from the AC plug. A chamois leather slightly moistened with water is sufficient
for cleaning your CD player. Do not use cleaning agents containing moistened airits, ammoniac or
abrasives. Do not try to clean the inside of the product.
Care considerations

cairn
Unpacking
Unpacking - Connections - FunctionsUnpacking - Connections -Functions
Place your in a dry place, with no direct sun exposure.Sun rays could damage the device.FOG3
List of supplied furnitures: -Power cord (Europa or U.S.)
-Remote control unit 33 keys
-Cells 2x1.5V AAA size (in the remote control unit)
Connections
-Ensure that the device is
-Connect your to your analog input of your preamplifier or of your integrated amplifier.
-Connect to mains supply.
totally disconnected from mains.
FOG3
FOG3
Startup
-Make a short push on the button #13 to turn on the device, or a long push to turn it off.
-Just after the startup, a default screen appears.
- Make a lond push on the button #1 to open the tray, insert your disc and make a short push to
close the tray.
- Make a short push on the button #6 to play, if you want to access to another track make
several short push on the button #9.
I
A
B
C
D
E
F
G
H
I
Left and Right Analog OUT
Left and Right balanced Analog OUT
Optical Digital IN
Coaxial Digital IN
Coaxial Digital OUT
Optical Digital OUT
“Slave” Communication
to NITRO or 4810
or to your computer for update
AC mains connector
Mains fuse
12 3 4 6 7 8 9
10 11
12 13
5
ABC D F G HE
2
3
4
5
6
1Tray
PLAY / STOP information
Track time
Track number
Total track number
STOP OPEN/CLOSE
Total track number
7ENTER NAVIGATION ESCAPE
ROTATION, selected item is highlight
8
9
10
11
12
13
Remote control IR receiver
PLAY PAUSE
NEXT FAST FORWARD
ON OFF
24-bit.192kHz SOFT inside
SOFT filter number

Navigation
If you have connected some options or a to , you will notice that the
corresponding sources have been created.
E.g. If a was detected, a source named “Fog CD” was created and associated with analog connector “An1”.
You can afterwards edit it, or create other ones to match perfectly your system.
MULTI SOLUTIONS 4810/ nITROFOG3
FOG3
Navigation
Knob :
Short push= (validate an action)
Long push= (escape)
Rotation=
navigate through a menu, modify a parameter)
Enter
Esc
Navigation
(
Esc
Enter
0.0 dB
Source
SOURCE SETUP
:01 00:00
:CD AUDIO
Goto
0.0 dB
Source
SOURCE SETUP
:CD AUDIO
Goto :01 00:00
0.0 dB
Source
SOURCE SETUP
:01 00:00
:CD AUDIO
Goto
You can go down
You can go up
Up and down possible
While you navigate, you will see arrows
on the upper left corner of the screen.
It illustrates your position in a menu.
0.0 dB
Source
SOURCE SETUP
:01 00:00
:CD AUDIO
Goto
0.0 dB
Source
SOURCE SETUP
:01 00:00
:CD AUDIO
Goto
Automated source setup
A source setup consists in associating
a name (the name of the source) with
an audio connector of .FOG3
Keep the left button pushed until
you see this screen:
0.0 dB
Source
SOURCE SETUP
:01 00:00
:CD AUDIO
Goto
0.0 dB
Source
SOURCE SETUP
:01 00:00
:CD AUDIO
Goto
Navigate to “Factory settings” menu
You should see:
Make a short push to enter
the menu “Restore sources”
is highlighted
A confirmation screen
appears:
Just validate by a short push
Select “YES” and validate
by a short push
cairn

Remote controlRemote control
cairn
Remote Control
POWER : (short push) ON
(long push) OFF
DISPLAY : (short push, display on) Informations scroll
(short push, display off) Display turns on
(long push) Display turns off
1 à 9 : Access to Track 1 to 99
Example: Track 23 press 2 then 3
LEVEL-/+ : Output level adjustment
minimal level = minimal quality
maximal level = maximal quality
: (short push) Previous track
(long push) Fast backward
: (short push) Next track
(long push) Fast forward
: push while disc playing Stop playing
push while disc stopped Eject the disc
: push while disc stopped Play
push while disk playing Pause
FILTER : Digital filter adjustment
REPEAT : Repeat traks
Consecutive pushs 1 track all tracks
no repeat
VOL+/- : Volume adjustment
IN+/- : Source selection
CH+ Next source
CH- Previous source
BALANCE : (short push) Right +
(long push) Right -
MUTE : consecutive pushs Mute
Unmute
TAPE : consecutive pushs Monitoring
No monitoring
MONO : consecutive pushs Mono
Stereo
PRESET +/- : Next/Previous station in the list
FREQ+ : (short push) next frequency
(long push) station scan
FREQ- : ( ) previous frequencyshort push
(long push) station scan
STORE : Store urrent frequency in the first empty position in the list
