Information about the product
Proper usage
The iSolar DL3 is connected to controllers via the
VBus®interface. It enables logging of system data and
parameterisation of a solar thermal system.
• Use in dry interior rooms only.
• Avoid ambient temperatures lower than 0 °C or
higher than 40 °C.
• Do not expose to strong electromagnetic fields.
Improper use excludes all liability claims.
CE Declaration of conformity
The product complies with the relevant di-
rectives and is therefore labelled with the
CE mark. The Declaration of Conformity is
available upon request, please contact the
manufacturer.
Note
Strong electromagnetic fields can impair the
function of the device.
ÎMake sure the device as well as the sys-
tem are not exposed to strong electro-
magnetic fields.
Disposal
• Dispose of the packaging in an environmentally
sound manner.
• Dispose of old appliances in an environmentally
sound manner. Upon request we will take back your
old appliances bought from us and guarantee an en-
vironmentally sound disposal of the devices.
Subject to technical change. Errors excepted.
Safety advice
Please pay attention to the following safety advice
in order to avoid danger and damage to people and
property.
Instructions
Attention must be paid to the valid local standards,
regulations and directives!
Target group
These instructions are exclusively addressed to au-
thorised skilled personnel.
Only qualified electricians should carry out electrical
works.
Description of symbols
WARNING! Warnings are indicated with a warn-
ing triangle!
ÎThey contain information
on how to avoid the danger
described.
Signal words describe the danger that may occur,
when it is not avoided.
• WARNING means that injury, possibly life-threat-
ening injury, can occur.
• ATTENTION means that damage to the appli-
ance can occur.
ÎArrows indicate instruction steps that should be
carried out.
Note
Notes are indicated with an information symbol.
Cross reference
A book symbol indicates a cross reference
to another chapter.
Contents
1 Overview................................................... 3
2 Included..................................................... 4
3 About this manual.................................... 4
4 Installation ................................................ 4
4.1 Wall mounting .........................................................5
4.2 Electrical connection..............................................6
4.3 Connecting the VBus®cable .................................6
4.4 Connecting the sensors ........................................6
4.5 Connecting the network cable............................6
5 Operating controls, menu and
connections............................................... 7
5.1 Operating control LED .........................................7
5.2 Buttons......................................................................7
5.3 Selecting options / menu points and
adjusting values........................................................7
5.4 Display.......................................................................7
5.4.1 Status display............................................................8
5.4.2 Network display......................................................8
5.4.3 VBus®display ...........................................................8
5.4.4 Sensor display ..........................................................8
5.5 Configuration...........................................................9
5.5.1 Language ...................................................................9
5.5.2 Date and time..........................................................9
5.5.3 VBus...........................................................................9
5.5.4 Sensors......................................................................9
5.5.5 Logging ....................................................................10
5.5.6 Network .................................................................10
5.5.7 Erase ........................................................................11
5.5.8 Version ....................................................................11
5.6 LAN connector.....................................................11
5.7 USB interface.........................................................11
5.8 SD memory card slot ..........................................12
5.9 Power supply connection....................................12
5.10 VBus®connection.................................................12
6 Firmware update with SD card ............ 13
7 Data export ............................................ 13
7.1 Data export over SD card..................................13
8 Accessories ............................................. 13
9 Spare parts.............................................. 13
© 20120524_11201741_Caleffi_DL3_Kurzanleitung.monus.indd

en
3
1 Overview
Be it solar thermal, heating or DHW heat exchange
controllers – with the DL3 you can easily and con-
veniently log system data of up to 6 controllers. Get a
comprehensive overview of all controllers connected
with the large full graphic display.Transfer data with an
SD memory card, or use the LAN interface to view
and process data on your PC.
• Data logging and parameterisation of up to 6 VBus®
master devices
• Temperature measurements and logging via inte-
grated sensor /impulse inputs possible
• Current loop interface 0 (4) - 20 mA
• BACnet functionality for BACnet-conform trans-
mission and reception of data
• Data logging onto SD card
Technical data
Housing: plastic, PC-ABS and PMMA
Protection type: IP 20 / EN 60529
Protection class: III
Ambient temperature: 0 ... 40 °C
Dimensions: 144 x 208 x 43 mm
Mounting: Wall mounting
Display: Full graphic display for status visualisation
and operating control LED
Operation: via three push buttons
Inputs: for 3 temperature sensors (Pt1000, Pt500
or KTY), can optionally be used as impulse inputs, 1
current loop interface 0(4)-20 mA
Interfaces: 6 x VBus®(slave), 1 x SD memory card
slot, 1 x LAN (10/100), 1 x USB master
Power supply: 12 V / 1 A (external mains adapter)

en
4
2 Included 3 About this manual
This document is a short manual for the iSolar DL3.
This short manual contains information about the fol-
lowing topics:
• Installation
• Electrical connection
• Operating controls
• Menu
• Using the SD card
A detailed manual with the complete information
about the web interface can be found on the included
CD.
4 Installation
ATTENTION!
ESD damage!
Electrostatic discharge can lead to
damage to electronic components!
ÎTake care to discharge prop-
erly before touching the in-
side of the device.To do so,
touch a grounded surface
such as a radiator or tap!
ATTENTION!
Short circuit!
A short circuit can lead to damage
to electronic components!
ÎClose the housing before
establishing the mains con-
nection!
Initial installation must be effected by the system in-
staller or qualified personnel named by the system
installer.
If one of the items mentioned below is missing or de-
fective, please contact your distributor:
1 iSolar DL3
2 Mains adapter
3 Interchangeable mains adapter plugs
(EURO, UK, USA,AUS)
4 VBus®cable
5 Network cable (CAT5e, RJ45), 1 m
6 Wall plugs and screws
7 Terminal block for extending the VBus®cable
8 USB adapter cable
9 CD with ServiceCenter software and detailed
manual
10 Short manual
(picture similar to original product)
11 SD card
1
2
38
5
67
9
10
4
11

en
5
4.1 Wall mounting
The unit must only be located in dry interior rooms.
It is not suitable for installation in hazardous locations
and should be protected against electromagnetic
fields.
Please pay attention to separate routing of sensor ca-
bles and mains cables.
ÎChoose a mounting location.
ÎUnscrew the crosshead screw from the cover
and remove the cover.
ÎMark the upper fastening point on the wall. Drill
and fasten the enclosed wall plug and screw leav-
ing the head protruding.
ÎHang the housing from the upper fastening point
and mark the lower fastening points (centres
180 mm)
ÎDrill 2 holes (Ø 6 mm) and insert the wall plugs.
ÎFasten the housing to the wall with the lower fas-
tening screw and tighten.
ÎCarry out the electrical connection according to
the terminal allocation.
ÎReattach the cover and fasten it using the cross-
head screws included.
Crosshead
screw
Cover
Cable conduits with
strain relief
12.5
180
180
100 144
208
16.75
43.3
Upper fastening
Lower fastening
In order to run cables through
the cable glands, break off the
corresponding flaps!

en
6
4.2 Electrical connection
Note
Connecting the device to the power sup-
ply must always be the last step of the in-
stallation!
Carry out the connection of the Datalogger
(pos. 1) to other modules in the order de-
scribed below:
ÎConnect the data cable (VBus®, pos. 4) to the
controller (pos.12) and the DL3 (pos. 1).If neces-
sary, extend the cable using the terminal block
included (pos. 7) and a common two-wire cable.
ÎConnect the mains adapter (pos. 2 / 3) to the DL3
and to a mains socket.
ÎFor a direct connection to a router or a PC, con-
nect the Datalogger to a router or a PC using
the network cable (included with the DL3,pos. 5).
Power supply is carried out via an external mains
adapter.The supply voltage of the mains adapter must
be 100 ... 240V~ (50 ... 60 Hz).
The mains adapter and a VBus®cable are included
with the DL3.
112 12
4
4
4.3 Connecting the VBus®cable
The iSolar DL3 is connected to one or several con-
trollers via VBus®cables. The corresponding terminal
allocation is described in the controller manual.
The VBus®cable can be extended using the terminal
block included and a common two-wire cable.
VBus®connection at the terminals:
1 / 2 = VBus®connection 1 (slave)
3 / 4 = VBus®connection 2 (slave)
5 / 6 = VBus®connection 3 (slave)
7 / 8 = VBus®connection 4 (slave)
9 / 10 = VBus®connection 5 (slave)
11 / 12 = VBus®connection 6 (slave)
To the VBus®connections 1 ... 6, master devices (con-
trollers) can be connected.
4.4 Connecting the sensors
Connect the temperature sensors to the following
terminals with either polarity:
•
⊥
/ S1 ... S3 = Temperature sensors S1 to S3
Connect the sensor using a 0(4)-20 mA signal as spec-
ified by the manufacturer to the following terminals:
•
⊥
/ CL = Current loop interface 0(4)-20 mA
4.5 Connecting the network cable
The iSolar DL3 can be connected to a computer or a
router by using a network cable (CAT5e, RJ45).
ÎConnect the network cable included to the net-
work adapter of the computer or the router.
ATTENTION!
VBus®network malfunction!
Separating the device from the pow-
er supply while theVBus®is still con-
nected can lead to a VBus®network
malfunction!
ÎSeparate VBus®connections
before separating the device
from the power supply!
12
VBus 1
3456 910
VBus 2 VBus 3 VBus 4
78
VBus 5
11 12
Master/Slave
VBus 6
12V
1A max.
LAN USB S1 S2 S3
0(4)-20 mA
current loop
IP 20
CALEFFI
NORTH AMERICA, Inc.
Milwaukee,WI 53208

en
7
5 Operating controls, menu and
connections
The following elements are featured on / in the hous-
ing of the iSolar DL3:
3 push buttons (1)
1 SD memory card slot (2)
1 LAN socket (3)
1 power supply socket (4)
3 sensor inputs (Pt1000, Pt500 or KTY) (5)
1 current loop interface 0(4)-20 mA (6)
6 VBus®connections (7)
12
VBus 1
3456 910
VBus2VBus 3VBus 4
78
VBus 5
11 12
Master/Slave
VBus 6 12V
1A max.
LANUSB S1 S2 S3
0(4) -20 mA current loop
1
2
3
4
5
6
7
Positions of the operating controls and connections
5.1 Operating control LED
The operating control LED indicates the operating
status of the iSolar DL3 by issuing flashing signals.
Red/green flashing: The device is booting
Green: The device is ready for operation /
SD card can be removed
Green flashing: Do not remove the SD card! Data
are being copied onto the SD card
Red flashing: An error has occurred.The error will
be indicated on the display
LED off: No power supply
5.2 Buttons
The device is operated via the three push buttons
next to the display.The push buttons have the follow-
ing functions:
• Button 1: Scrolling upwards
• Button 3: Confirming
• Button 2: Scrolling downwards
3
1
2
5.3 Selecting options / menu points and
adjusting values
Values and adjustments can be changed in different
ways:
An option can be selected by pressing buttons 1 and
2 and then confirming by pressing button 3. Now the
option can be activated: By pressing buttons 1 and 2,
Ye s can be selected to activate, No to deactivate the
option. The selection can be confirmed by pressing
button 3.
Numeric values can be adjusted by means of a slide
bar. The minimum value is indicated to the left, the
maximum value to the right. The number above the
slide bar indicates the current adjustment. By pressing
buttons 1 and 2, the upper slide bar can be moved to
the left or to the right.
Only after the adjustment has been confirmed by
pressing button 3 will the number on the right-hand
side above the slide bar indicate the new value. The
new value will be saved if it is confirmed by pressing
button 3 again.
If only one item of several can be selected, they will
be indicated with "radio buttons".When one item has
been selected, the radio button in front of it is filled.
If more than one item of several can be selected, they
will be indicated with checkboxes.When an item has
been selected, an xappears inside the checkbox.
5.4 Display
During normal operation, the iSolar DL3 indicates the
status display (see fig. page 8). Buttons 1 and 2 can
be used to switch between the displays.
If no button has been pressed within a couple of min-
utes, the display illumination is switched off.
ÎPress any key to reactivate the display illumination.

en
8
5.4.1 Status display
During normal operation, the iSolar DL3 indicates the
status display with the following information:
• Data memory progress bar (fill level)
• Remaining logging time in days
• VBus®devices connected
• Sensors connected
The data memory progress bar is divided into 10 seg-
ments. Each segment represents 10% of the memory
capacity.
Data memory progress bar
• Segment filled:The memory capacity of this seg-
ment is fully occupied.
• Segment flashing:The memory capacity of this seg-
ment is partly occupied.
The arrow above the data memory progress bar indi-
cates the remaining logging time in days.
In the bottom left-hand area of the status display, each
VBus®device connected with a functioning VBus®
communication is indicated by a corresponding filled
checkbox.
In the bottom right-hand area of the status display,
each sensor connected is indicated by a correspond-
ing filled checkbox.
5.4.2 Network display
In the network display, information about the network
connection is displayed.
In the centre, the IP address of the DL3 is displayed.
When the DL3 is connected to the Local Area Net-
work (LAN), a house is indicated on the left-hand side
of the display.
When the DL3 is also connected to the Internet, a
globe is indicated on the right-hand side of the display
(the house is not indicated any more in that case).
If the DL3 has not been assigned with an IP address,none
of the symbols are indicated, the line remains empty.
Note:
If a static IP address has been assigned to
the DL3, the IP address and the house/globe
symbol appear as soon as the network cable
has been connected.
5.4.3 VBus®display
In the VBus®display, VBus®information about the
VBus®devices connected is indicated.
In the left-hand area of the display, the number of bytes
received (Rx) is indicated. In the right-hand area of the
display, the number of bytes transmitted (Tx) is indicated.
A VBus®device connected with a functioning VBus®
communication is indicated by a corresponding filled
checkbox in the bottom area of the display.
Each VBus®device has its own display. The connec-
tions VBus®1 to VBus®6 are displayed each in their
own display.
ÎIn order to leave the status level and access the
VBus®displays, press button 2.
ÎThe display indicates information about theVBus®
device.
ÎIn order to access information about further
VBus®devices, scroll down by pressing button 3.
5.4.4 Sensor display
In the sensor display, information about the sensors
connected is indicated.
In the left-hand area of the display, the resistance value
of the corresponding sensor is indicated. In the right-
hand area of the display, the temperature value of the
corresponding sensor is indicated in °C.
A sensor connected is indicated by a corresponding
filled checkbox in the bottom area of the display.
Each sensor has its own display.The data of the inputs
CL and S1 to S3 are displayed each in their own display.
ÎIn order to leave the status level and access the
sensor displays, press button 2.
ÎPress button 2 to scroll down through theVBus®
displays until the sensor displays appear.
ÎIn order to access information about further sen-
sors, scroll down by pressing button 2.

en
9
5.5 Configuration
In the Configuration menu, different adjustments
can be made.
ÎIn order to access the menu, press button 3 for
approx. 3 s.
Menu structure
The menu consists of the following sub-menus:
• Language
• Time
• VBus
• Sensors
• Logging
• Network
• Erase
• Version x.x
ÎIn order to access the adjustment mode of a sub-
menu, select the desired sub-menu by pressing
buttons 1 and 2, and confirm with button 3.
5.5.1 Language
In the Language sub-menu, the menu language can
be selected.
ÎSelect the desired language by pressing buttons
1 and 2.
ÎBriefly press button 3 to confirm the selection.
ÎIn order to get back to the Configuration menu,
select Back and confirm by pressing button 3.
5.5.2 Date and time
In the Time sub-menu, the date and time can be ad-
justed.
ÎTo adjust the date, select the menu item Date in
the Time sub-menu.
ÎAdjust the year by pressing buttons 1 and 2, and
confirm with button 3.
Now the month is displayed, too. As soon as it has
been adjusted and confirmed, the day appears as well.
ÎAdjust and confirm the current month and day as
described above.
ÎTo adjust the time, select the menu item Time in
the Time sub-menu.
ÎAdjust the hours by pressing buttons 1 and 2, and
confirm with button 3.
ÎAdjust the minutes by pressing buttons 1 and 2,
and confirm with button 3.
5.5.3 VBus
In the VBus sub-menu, the monitoring of the VBus®
connections can be activated.
ÎSelect the desired VBus®connection by pressing
buttons 1 and 2, and confirm with button 3.
ÎTo activate the monitoring of the VBus®connec-
tion, select Ye s . To deactivate the monitoring of
the VBus®connection, select No.
If an error occurs in aVBus®connection, the operating
control LED flashes and the message VBus (1... 6)
no signal appears on the display.
5.5.4 Sensors
In the Sensors sub-menu, the sensor type and an off-
set can be adjusted for each sensor input.
Sensor type
For the sensor inputs S1... S3, the following sensor
types are available:
• None
• Pt1000
• Pt500
• Impulse
• KTY
The selection Offset is not available when
the sensor type Impulse has been selected.
In order to adjust the sensor type, proceed as follows:
ÎSelect the desired sensor by pressing buttons 1
and 2, and confirm with button 3.
ÎSelect the menu item Type and confirm by press-
ing button 3.
ÎSelect the right sensor type and confirm by press-
ing button 3.
If the sensor type Impulse has been selected, the
impulse rate can be adjusted. In order to adjust the
impulse rate, proceed as follows:
ÎSelect the desired sensor by pressing buttons 1
and 2, and confirm with button 3.
ÎIn the corresponding sensor menu, select the
menu item Vol./Imp.
ÎAdjust the desired value by pressing buttons 1
and 2, and confirm with button 3.
Sensor offset
In order to adjust an offset for the sensor inputs S1... S3,
proceed as follows:
ÎSelect the desired sensor by pressing buttons 1
and 2, and confirm with button 3.
ÎSelect the menu item Offset and confirm by
pressing button 3.
ÎAdjust the desired value by pressing buttons 1
and 2, and confirm with button 3.

en
10
If no firmware update is found on the memory card,
the query Copy data? appears.
ÎTo copy the data logged in the internal memory,
select Ye s and confirm by pressing button 3; to
cancel the function, select No and confirm by
pressing button 3.
5.5.6 Network
In the Network sub-menu, the following adjustments
can be made:
• VBus.net
• LAN
VBus.net can be used to access the iSolar DL3 over
the Internet without adjusting the router . In order to
activate VBus.net, proceed as follows:
ÎSelect VBus.net by pressing buttons 1 and 2,and
confirm with button 3.
ÎSelect the menu item Log in and confirm by
pressing button 3.
ÎTo register the iSolar DL3 for VBus.net, select
Ye s and confirm by pressing button 3.
ÎSelect the menu item Log-in code by pressing
buttons 1 and 2, and confirm with button 3.
The iSolar DL3 generates a 6-digit code and registers
its address with the server.To access the data, a user
account at VBus.net is required. In order to register
with the server, proceed as follows:
ÎOpen a user account at www.vbus.net.
ÎChoose a user name and password.
ÎEnter the code generated by the DL3 in the user
account.
In the LAN sub-menu, the following adjustments can
be made for accessing the Datalogger over LAN:
• Auto configuration
• Address
• Mask
• Recover IP
If the current loop interface is used, the type can be
adjusted.The following types are available:
• None
• 0 - 20 mA
• 4 - 20 mA
• Si-420TC
In order to adjust the type, proceed as follows:
ÎSelect the menu item Current loop by pressing
buttons 1 and 2, and confirm with button 3.
ÎSelect the Type sub-menu.
ÎSelect the right type and confirm by pressing but-
ton 3.
If an error occurs in a sensor connection, the op-
erating control LED flashes and the message Input
(1 ... 4) no signal appears on the display.
5.5.5 Logging
In the Logging sub-menu, the following adjustments
can be made:
• Interval
• Logging type
• SD card (only if an SD card has been inserted into
the SD card slot)
When Interval has been selected, the logging interval
can be adjusted. In order to adjust the interval, pro-
ceed as follows:
ÎSelect the number of minutes by pressing buttons
1 and 2, and confirm with button 3.
ÎSelect the number of seconds by pressing buttons
1 and 2, and confirm with button 3.
In the menu item Log. type, one of the following log-
ging types can be selected:
• linear
• cyclic
When linear is adjusted in the Logging type ad-
justment channel, data logging will stop if the capacity
limit is reached. If cyclic is adjusted, the oldest data
logged into the internal memory will be overwritten
as soon as the capacity limit is reached.
When Log. type has been selected, the logging type
can be adjusted. In order to adjust the logging type,
proceed as follows:
ÎSelect the desired logging type by pressing but-
tons 1 and 2, and confirm with button 3.
In the menu item SD card, the following adjustments
can be made:
• Backup
• Format card
• Update
When Backup has been activated, the data logged
over the previous day will be copied onto the SD card
at midnight (00:00), using the VBus®data format.The
data remain in the internal memory as well.
When Format card has been selected, the SD card
will be formatted.In order to format the SD card, pro-
ceed as follows:
ÎSelect the menu item Format card by pressing
buttons 1 and 2, and confirm with button 3.
ÎTo format the card, select Ye s and confirm by
pressing button 3.
During the formatting process, the message Please
wait... is indicated. When formatting has been com-
pleted, the message Successful! appears. Press any
key to leave the menu item.
When an SD card with a firmware update is inserted,
the enquiry Update? is indicated on the display.
ÎTo run the update, select Ye s and confirm by
pressing button 3 (see chap. 6 Firmware up-
date with SD card, page 13).

en
11
When Auto configuration has been activated, the
IP address and IP net mask are indicated, but cannot
be adjusted. If Auto configuration has been deacti-
vated, the IP address and IP net mask must be adjust-
ed. In order to make adjustments, proceed as follows:
ÎSelect Auto configuration by pressing buttons
1 and 2, and confirm with button 3.
ÎTo deactivate Auto configuration, select No and
confirm by pressing button 3.
ÎAdjust the IP address by pressing buttons 1 and 2,
and confirm with button 3.
ÎAdjust the IP net mask by pressing buttons 1 and
2, and confirm with button 3.
The menu item Recover IP can be used to automati-
cally retrieve a new IP address for the DL3 in the case
that the previous one is lost. In order to adjust the au-
tomatic IP address configuration, proceed as follows:
ÎSelect the menu item Recover IP by pressing
buttons 1 and 2, and confirm with button 3.
ÎTo activate Recover IP, select Ye s and confirm by
pressing button 3.
Now the interval for the automatic IP address con-
figuration can be adjusted. In order to do so, proceed
as follows:
ÎSelect the menu item Interval by pressing but-
tons 1 and 2, and confirm with button 3.
ÎAdjust the interval by pressing buttons 1 and 2,
and confirm with button 3.
If Recover IP has been activated, the IP address con-
figuration can be carried out immediately. In order to
do so, proceed as follows:
ÎSelect the menu item Recover now by pressing
buttons 1 and 2, and confirm with button 3.
5.5.7 Erase
In the Erase sub-menu, the following adjustments can
be made:
• Erase data
• Reset
The menu item Erase can be used to erase all logged
data from the internal memory of the iSolar DL3. In
order to erase the data, proceed as follows:
ÎSelect the menu item Erase data by pressing
buttons 1 and 2, and confirm with button 3.
ÎTo erase all data, confirm the security enquiry
Erase? by selecting Ye s and confirming by press-
ing button 3.
The menu item Reset can be used to erase all logged
data from the internal memory of the iSolar DL3 and
to reset all adjustments made in the DL3 back to their
factory settings.
To erase all data and reset all adjustments to their
factory settings, proceed as follows:
ÎSelect the menu item Reset by pressing buttons
1 and 2, and confirm with button 3.
ÎTo erase all data and reset all adjustments, con-
firm the security enquiry Erase? by selecting Ye s
and confirming by pressing button 3.
5.5.8 Version
In order to display the software version, proceed as
follows:
ÎSelect the menu item Version by pressing but-
tons 1 and 2, and confirm with button 3.
The current software version is displayed.
5.6 LAN connector
Seriennummer
12
VBus 1
3456 910
DL3
DE-45527 Hattinge n
VBus2VBus3VBus 4
78
VBus 5
11 12
Master /Slave
VBus 6
Made in Germany
12V
1A max.
LA
NUSB S1 S2 S3
0(4)-20 mA current loop
Datalogger DL3
The integrated LAN connector is located on the
terminal strip of the device.The LAN connector sup-
ports transfer rates of up to 100 MBit per second.
5.7 USB interface
Seriennummer
12
VBus 1
3456 910
DL3
DE-45527 Hattinge n
VBus2VBus3VBus 4
78
VBus 5
11 12
Master /Slave
VBus 6
Made in Germany
12V
1A max.
LANUSB
S1 S2 S3
0(4)-20 mA current loop
Datalogger DL3
The DL3 is equipped with a USB interface to which
the USB adapter cable can be connected.
In order to connect the USB adapter cable to the
DL3, proceed as follows:
ÎConnect the USB adapter cable to the interface
marked USB.
Presently, the firmware of the device does not
support external USB devices.As soon as USB
support becomes possible, it will be made
available via an automatic iSolar DL3 firmware
update.

en
12
Adjustment channel Adjustment range / selection Factory setting
Language English, Deutsch, Français
Time
-Date 01.01.2001 ... 31.01.2050
-Time 00:00 ... 23:59
VBus
-VBus 1 ...VBus 6 Yes, No No
-Sensors
--S1 ... S3
--Type None, Pt1000, Pt500, KTY, Impulse None
--Offset -15.0 ... +15.0 K 0.0 K
--Vol./Imp. 0.1 ... 100.0 l/Imp 1.0 l/Imp
-Current loop
--Type None, 0-20 mA, 4-20 mA,
Si-420TC
Logging
-Interval 00:01 ... 20:00 (mm:ss)
-Log. type linear, cyclic cyclic
Network
-VBus.net Yes, No No
-LAN
--Auto configuration Yes, No Ye s
--Address
--Mask
--Recover IP Yes, No No
--Interval 00:10 ... 24:00
--Recover Now
Erase
-Erase data Yes, No No
-Reset Yes, No No
Version
5.8 SD memory card slot
SD memory card slot
The SD memory card slot is located at the front of
the device. By means of the SD memory card slot,
logged data can be transferred onto an SD card.
The memory of an SD card in the slot is used
for data transfer only. It will not enlarge the
memory of the iSolar DL3.
5.9 Power supply connection
Power supply is carried out via an external mains
adapter. The connection terminals are located inside
the housing of the iSolar DL3.
5.10 VBus®connection
The iSolar DL3 is connected to one or several con-
trollers viaVBus®cables.The connection terminals are
located inside the housing of the iSolar DL3.
Menu structure

en
13
6 Firmware update with SD card
New firmware versions extend the functional range
and enhance the operation.
In order to run a firmware update over the SD mem-
ory card slot, proceed as follows:
ÎFormat the SD card using the FAT 32 format.
ÎInsert the SD card into an external SD card slot
and create a folder named „DL3“.
ÎCopy the firmware update file into the folder cre-
ated before and extract if necessary.
ÎRemove the SD card from the external SD card
slot.
ÎInsert the SD card into the SD card slot of the
DL3.
The operating control LED starts flashing and the
message Do not remove SD card! appears.Wait until
the operating control LED is permanently green.
The firmware update is being run.
When the firmware update is completed, the DL3 au-
tomatically reboots.
7 Data export
There are 2 different ways to export logged data from
the iSolar DL3:
1. Export logged data onto an SD memory card.The
data are stored as a VBus®format file and can be
read out on a computer using the ServiceCenter
software.
2. Export logged data onto a computer over the
web interface. Different file formats can be se-
lected.
7.1 Data export over SD card
In order to copy data onto an SD card, proceed as
follows:
ÎInsert the SD card into the SD card slot
The operating control LED flashes (green):
The card has been recognised and data are being
transferred.
The operating control LED is permanently green:
The transfer is completed.The card can be removed.
8 Accessories
Temperature sensors
The product range includes high-precision platinum
temperature sensors, flatscrew sensors, outdoor
temperature sensors, indoor temperature sensors,
cylindrical clip-on sensors, also as complete sensors
with immersion sleeve.
Sensor / VBus®extension cable,
100 m coil
Art. no.: 280 051 00
SD card
Art. no.: 180 007 40
9 Spare parts
Mains adapter 100 ... 240V~ (12 V , 1A max)
Art. no.: 720 004 60
VBus®cable, 1.50 m
Art. no.: 750 012 15
USB cable with 5-pole port
Art. no.: 750 000 92

en
14
Note

en
15
Note

en
16
Distributed by: CALEFFI NORTH AMERICA, Inc.
3883 W. Milwaukee Rd.
Milwaukee,WI 53208
Tel.: [phone]
Fax: [phone]
www.caleffi.us
sales@caleffi.com
Important note
The texts and drawings in this manual are correct to the best of our knowledge.As
faults can never be excluded, please note:
Your own calculations and plans, under consideration of the current standards and
directions should only be basis for your projects.We do not offer a guarantee for
the completeness of the drawings and texts of this manual - they only represent
some examples.They can only be used at your own risk. No liability is assumed for
incorrect, incomplete or false information and / or the resulting damages.
Note
The design and the specifications can be changed without notice.
The illustrations may differ from the original product.
Imprint
This mounting- and operation manual including all parts is copyrighted. Another
use outside the copyright requires the approval of CALEFFI NORTH AMERICA,
Inc.This especially applies for copies, translations, micro films and the storage into
electronic systems.
Editor: CALEFFI NORTH AMERICA, Inc.
