Safety Instructions
Please read this section carefully and
follow all the instructions given. This will
help to ensure reliable operation and
extend the service life of your device.
Keep the packaging and the user
instructions for future reference or
inquiries. If you pass the article on to
another person, you must pass on these
instructions, too.
• Never open up the housing of the device
or the AC adaptor. These do not
contain any serviceable parts. If the
housing is opened there will be danger
to life from electric shock.
• Do not place any objects on the device
and do not exert any pressure on the
display. Otherwise there is a danger
that the screen will break.
• To avoid damages, do not touch the
screen with sharp objects. Use only
the stylus provided.
• There is a risk of injury if the display
breaks. If this should occur, use
protective gloves to pack the broken
parts and contact customer support to
arrange for disposal. Then wash your
hands with soap, since there is a
possibility that chemicals may have
escaped.
• Never allow children to play with
electrical equipment unsupervised.
Children may not always correctly
recognise possible danger.
• Remove the AC adaptor from the outlet,
switch off the device immediately, or
do not actually switch it on, and contact
customer service......if the AC adaptor
or the attached plug become scorched
or damaged.
...if the housing of the device or the
AC adaptor becomes damaged or fluids
leak into it. Components must be
checked by customer service in order
to avoid damage!
Data Security
• Every time you update your data, make
backup copies on an external storage
medium. The supplier does not assume
liability for data loss or damage to data
storage units, and no claims can be
accepted for damages resulting from
the loss of data or for consequential
damages.
Operating Environment
• Keep your navigation system and all
connected devices away from moisture
and avoid dust, heat and direct sunlight,
especially in the car.
• Make sure to protect your device
against getting wet (e.g. from rain and
hail). Please note that moisture can
even build up in a protective bag
because of condensation.
• Avoid heavy vibrations and
shaking.
• Make sure that the device cannot
releasing itself from its holder, for
example when braking. Install the device
as vertically as possible.
Failure to follow these instructions may
cause damages to your device.
Ambient Temperature
The device is most reliably operated at
an ambient temperature of between 41°F
to 104°F (5°C to 40°C) and at a relative
humidity of between 10% to 90%.
• In the powered down state the device
can be stored at between 32 °F to 140
°F (0 °C to 60 °C).
• Always store the device in a safe place to
avoid high temperatures (e.g. when parking
or from direct sunlight).
Electromagnetic Compatibility
• When connecting additional or other
components the "Electromagnetic
Compatibility Directive" (EMC) must be
adhered to. Please also note that only
screened cable (maximum 10 ft.) should
be used with this device.
For optimal performance, maintain a
distance of at least 10 ft. from sources
of high-frequency and magnetic
interference (televisions, loudspeaker
systems, mobile telephones and so on).
This will help to avoid malfunctions and
loss of data.
Battery Operation
Your device is operated with a battery.
In order to prolong the life and efficiency
of your battery and to ensure safe
SAFETY INFORMATION

4
operation follow the instructions below:
• Warning: Danger of explosion if
rechargeable batteries are not charged
properly.
• Batteries cannot withstand heat. Avoid
the device and the integrated battery
becoming overheated. Failure to
comply with this instruction may lead
to damage to and even explosion of
the battery.
• Only use either the original AC adaptor
or the car adaptor from the optional
navigation kit to charge the battery.
• The batteries are special category
waste. When disposing of the device
ensure that this is done correctly. For
more details, please contact customer
service.
Care of the Display
• Avoid scratching the display surface
as this is easily damaged. It is strongly
recommended to use a display
protection foil to avoid scratches. Please
ask your nearest dealer for this
accessory. The foil on the display at
delivery is solely for protection during
transportation!
• Ensure that no traces of water remain
on the screen. Water can cause
irreversible discoloration.
• Only use a soft, lint-free cloth to clean
the screen.
• Do not expose the screen to either
strong sunlight or ultraviolet radiation.
Transport
If you wish to transport the device, please
follow the instructions below:
• After transporting the device wait until
the unit has acclimatised before using
it.
• In case of wide fluctuations in
temperature or humidity, condensation
or moisture may form inside the device
which can cause an electrical short-
circuit.
• In order to protect the device from dirt,
shock and scratching, use a protective
case.
• Before travelling, make sure that you
are informed about the power and
communications provision at your
destination. Before travelling obtain any
power or communications adaptors
(modem, LAN, etc.) that may be needed.
• When shipping your device, only use
the original packaging and advise the
carrier accordingly.
• When passing through the hand luggage
control at airports, it is recommended
that you pass the device and all
magnetic storage media (e.g. external
hard drives) through the X-ray system
(the machine on which you place your
bags). Avoid the magnetic detector
(the structure through which you pass)
or the magnetic wand (the hand device
that the security staff use), since this
may corrupt your data.
Connection
When connecting your device, please
make sure to follow the instructions below
very carefully:
• The outlet must be near the device and
must be easily accessible.
• Only connect the AC adaptor to
grounded sockets operating at 100-
240V~AC, 50/60Hz. If you are unsure
about the mains supply to the place of
use, ask the relevant energy supplier.
• Only use the original AC adaptor
provided with your device.
• For additional safety, we recommend
the use of a surge protector in order to
protect your device from voltage spikes
or lighting strikes on the mains supply.
Power Through Car Adaptor
• The car adaptor should only be
connected to the cigarette lighter socket
Cabling
• Arrange cables in such a way that no-
one can tread on them or trip over them.
• Do not place any objects on the cable.
WARNING
When the unit is not in use for a long time,
please recharge the battery every now
and then, otherwise the battery lifetime
would be shortened.
SAFETY INFORMATION

5
The following instructions guide you step
by step through the initial setup of the
navigation system.
Firstly, remove the foil for protecting the
device during transportation from the
display.
Switch on the navigation system.
Set the battery switch (15) on the bottom
of the device to the ON position.
Attention: Always leave the battery switch
on the ON position, unless you want to
perform a new reinstallation. If the switch
is set to the OFF position, all data will be
lost and you will have to perform the initial
installation again.
The initial installation of the navigation
system is started automatically. The brand
logo appears and after a few seconds
your device displays the application
screen.
Date and time are set by means of the
Setting button (4) and the date/time
control button. Set the applicable time
zone, if available.
Attention: According to the charging
status of the installed battery it is
necessary for the device to be charged
before the initial setup can be performed.
Charging the Battery of the Navigation
System
Note: When charging the battery, please
ensure that the battery switch is set to
the ON position. During charging the
battery charge indicator lights red.
You have different possibilities to charge
the battery of your navigation system:
• By means of the AC adaptor.
• By means of the car charger.
• The battery charge indicator lights red
until the navigation system is fully
charged, then the battery indicator turns
green. Do not interrupt the charging
process before the battery is fully
charged, which will take a few hours.
• Note: You can use the navigation
system during the charging process,
but the power supply must not be
interrupted during initial setup.
• Leave the AC adaptor connected to
the navigation system until the battery
is fully charged.
• You can leave the AC adaptor
connected, which is very convenient
for continuous operation. Please note
that the AC adaptor also consumes
power even if it is not charging the
battery of the navigation system.
Slide the connector converter into the
guide on the right side of the AC adaptor.
Plug the AC adaptor (2) in an outlet that
is easily accessible.
Connect the cable of the AC adaptor (1)
to the AC adaptor port of the navigation
system.
Working with Memory Cards
Your navigation system supports SD
(Secure Digital) memory cards.
Inserting memory cards:
1.Carefully take the memory card out of
its packaging (if included). Make sure
not to touch or dirty the contacts.
2. Push the memory card carefully into
the card slot. The labelled side of the
memory card must point upwards. The
memory card should slightly lock in
place.
Removing Memory Cards
• Do not remove the memory card while
it is accessed. This could result in loss
of data.
1. To remove the card lightly press it into
the device the upper edge until it ejects.
2. Pull out the card without touching the
contacts.
3. Store the memory card in the packaging
or in another safe place.
• Memory cards are very fragile. Take
care not to dirty the contacts and not
to force the card.
INSTALLATION
2
1

6
Accessing Memory Cards
• Your device only supports memory
cards in the FAT16/32 file format. If you
insert a card formatted with a different
format (e.g. in cameras, MP3 players),
your navigation system may not
recognise it and will ask you to format
it again.
Warning: Formatting the memory card
irretrievably wipes out all data.
• Likewise you cannot just copy files to
the memory card. In some cases they
must be converted by the Microsoft
ActiveSync programme.
Data Exchange via Card Reader
You can transfer or synchronise data via
ActiveSync. Particularly, this is the correct
method if files to be transferred must be
converted into a system your navigation
system can read.
However, if you wish to copy large
quantities of data (e.g. navigation maps)
to the memory card, these can also be
stored directly to the memory card.
Many computers already have memory
card devices. Just insert the card into it
and copy the data directly to the card.
Due to the direct access significantly faster
transfer will be achieved.
Resetting the Navigation System
There are two options for resetting the
navigation system.
Soft Reset
This option restarts the navigation system,
without reinstallation being necessary. A
soft reset is often used in order to
reorganise the memory. In doing so all
programmes that are running are
interrupted and the working memory is
reinitialised.
Choose this option if your navigation
system is not responding or working
properly.
Perform the soft reset as follows: Carefully
press the top of the stylus-pen into the
reset opening on the lower side of your
device.
Hard Reset
Warning: A hard reset deletes all data on
your device and causes a new initial
installation. It is, however, unnecessary
to install the software on your
synchronisation computer again.
Perform the hard reset as follows:
Initially, slide the battery switch on the
bottom of the device to the OFF position
and back to ON after two seconds.
Safety Instructions for Navigation
The supplied product CD contains a
comprehensive instruction manual.
Tips for Navigation
• Do not manipulate the navigation
system while driving to protect yourself
and others from accidents!
• In the event that you do not understand
the voice instructions or if you are in
any doubt about what to do at the next
intersection, then the map or arrow
display will provide you with a quick
orientation. Only look at the display
when you are in a safe driving situation!
• Attention: The actual road conditions
and driving rules take precedence over
the instructions of the navigation
system. Only follow the instructions
when circumstances and driving rules
permit it! The navigation system will
guide you to your destination even if
you have to deviate from your planned
route.
• The direction instructions given by the
navigation system do not release the
driver of the vehicle from his or her duty
of care or personal responsibility.
• Plan routes before you leave. If you
want to calculate a new route whilst on
the road, please stop driving.
• In order to receive the GPS signal
correctly remove all metal objects that
may interfere with reception. Attach the
navigation system onto the inside of
the windscreen or near the windscreen
with the suction plate. Try out different
positions in your vehicle in order to find
the best possible reception.
Notes for Using the Device in a Vehicle
• When installing the car holder, make
sure that the it does not present any
risk to safety, even in the case of an
accident.
• Ensure that the cable does not obstruct
INSTALLATION

7
any safety components.
• The display of your navigation system
may show “light reflexions”. Please
make sure of not being “blinded” during
operation.
• Do not mount the components within
the airbag deployment zones.
• Check the secure adherence of the
suction cup at regular intervals.
• The power plug will consume power,
even if no device is connected. Remove
it when not in use to avoid draining the
battery.
• Check all safety equipment in your car
after installation.
Additional Notes for Using the
Navigation System on a Bike
• Make sure during installation that the
ability to steer is not impaired.
Mounting the Navigation Set in a Car
Attention! Only fix the holder for the
navigation system to the windscreen, if it
does not impede the view. Should this
not be possible, then mount the holder
with the enclosed suction plate in any
way that will allow peril-free and safe
operation.
Installing the Car Holder
• Note: If you want to fix the car holder
to the windscreen, you can skip step 1
and 2.
1. Remove the protective foil from the
sticky side of the suction plate.
2. Fix the suction plate to a suitable
position on the dashboard. Take care,
that the surface of the dashboard is
clean and press the suction plate
strongly onto the surface.
• To obtain a strong and secure hold the
suction plate should not be used for 24
hours.
3. Mount the car holder to the flexible
neck. Note the labels on the flexible
neck. The arrow labelled CLOSE must
point to the direction of the fixture. The
connection locks in with a noticeable
clicking sound.
1. Place the holder with the suction head
onto the suction plate (or directly onto
the windscreen) and press the lever on
the suction head downwards. The
suction head will stick itself firmly to
the suction plate.
2. Set the navigation system into the car
holder by placing it initially in the lower
noses and then pressing it down gently
until the holder clicks in.
Connecting the Car Adaptor
When the battery is low, you can recharge
the device in the car:
1. Connect one end of the car charger to
connector at the bottom of your
navigation system.
2. Now insert the power adaptor into the
cigarette lighter socket and ensure that
it will not lose contact while driving.
This could cause a malfunction.
• Note: Remove the car adaptor from
the cigarette lighter socket when ending
a trip or when parking the car for an
extended period of time.
INSTALLATION
Suction
Plate
Flexible
Neck
Suction
head
Car
Holder
Holder

8
Note: After installation, protect your
navigation system from dust and dirt by
using the storage pocket. The storage
pocket, however, does not protect against
rain or moisture. Make sure that the
navigation system is not exposed to
moisture. This may damage the electronic
parts.
When you use the navigation system,
make sure that it is mounted in an upright
position so that the GPS antenna (13) will
receive a strong signal. If the signal is too
weak, please adjust the direction of the
GPS antenna to receive the best possible
signal.
INSTALLATION

9
Front View
VIEWS
1. Sleep/Wake Button Press it to switch on/off the unit.
2. Battery Charge Indicator When the battery is charging the indicator lights red
When the battery is fully charged, the indicator turns
green.
3. Back Button Press it to return to the previous menu.
4. Setting Button Press it to enter into the setting menu.
5. Navigation Pad Moves up/down/left/right by pushing the corresponding
area of the pad.
6. Enter Button Press it to enter into the selected item.
7. Press it to enter into the main menu.
8. Touch Screen Displays the output of your device. Touch the screen
with the stylus to select menu commands or enter
information.
9. Button to zoom out.
10. Button to zoom in.
2 8 3 1 4
7 9 10 6 5

10
Back View
VIEWS
11. Stylus Pen Pull the stylus pen out of its compartment in order
to use it. Store it in this slot when not in use. The
stylus pen is required for operating the touch screen.
12. Loudspeaker Plays back voice instructions and warnings.
13. GPS Antenna Receives the signals of the GPS satellites.
14. External Antenna Jack Interface for an optional second antenna.
11 12 13 14

11
Bottom View
VIEWS
15.Battery Switch Separates the device completely from the battery
(also hard reset).
20. Reset Button Press it to reset the unit.
1520
RESET ON OFF
BATTERY
19
18
17
16
16.SD/MMC Slot Accepts an optional SD (Secure Digital) Card for
removable storage.
17.USB Interface Interface for connecting to a PC by means of the Sync-
cable (for data synchronisation).
18.Headphone Jack Connects to a pair of stereo headphones (optional).
19. AC Adaptor Port Connection to external power supply.
Left View Right View

12
GPS is a satellite-based system for
determining your position. With the help
of more than 24 satellites revolving around
the earth, it is possible to determine your
position on earth with an accuracy of a
few meters. The satellite signals are
received by the antenna of the integrated
GPS receiver, which must have a “line of
sight” to at least 4 satellites.
• Note: By limited line of sight access
(e.g. in tunnels, between houses, in
woods or also in vehicles with metal-
coated windows) it is impossible to
determine the position. The satellite
reception automatically picks up again
as soon as the obstacle has been
passed and the line of sight is
established again.
The GPS receiver consumes additional
power. This is especially of concern when
running on batteries. To save power do
not switch on the GPS receiver
unnecessarily.
You can also switch off the device by
means of the sleep/wake button in case
of a shorter interruption to your journey.
Pressing the same button again will
perform a restart. At the same time, the
GPS receiver will also be reactivated if
the navigation software is still running.
Here, it can take a short time for the
position to be updated, according to the
reception situation.
• Note: Please note that your device is
preset not to shut down automatically
after a few minutes without activity. You
can change this default in the settings
mode.
• If the GPS receiver has not been active
for some hours, it must orientate itself
again. This process may take some
minutes.
Memory Card Quick Installation
This option will only be available to you
if your navigation system is equipped with
a prepared memory card. In this case,
you will be able to use the navigation
function of your device after a short time,
without carrying out the pre-installation
on a PC.
• In any case, the initial setup must be
performed as described on page 15.
• The following installation limits the
navigation to the area which is pre-
installed on your memory card.
You must perform these steps to put the
navigation into operation in your car:
1.Read and adhere to the safety
instructions on page 2 and the following.
2.Install the remaining components of the
navigation system.
3.Press the sleep/wake button to start
your navigation system. If the
instructions of Step 1 have not yet been
performed, then do it now. The battery
should be charged. If necessary, charge
the battery by means of the car power
supply.
• Insert the pre-installed memory card in
the navigation system. The installation
of the navigation software starts
automatically. Follow the instructions
on the screen.
NOTES:
• The memory card must always be
inserted in the device during the use of
the navigation system. A soft reset will
have to be performed to restart the
navigation system if the memory card
is removed during its use, even for a
short time.
• After a hard reset, the software will
have to be installed again.
• Perform a hard reset initially, if you want
to reinstall the navigation software.
Now set date and time by means of the
settings button and the date/time control
button if this has not yet been done. Set
the applicable time zone if available.
GPS (GLOBAL POSITIONING SYSTEM)

13
Starting Navigation
1.Switch on your navigation system.
2.The navigation software starts
automatically or after tapping the
navigation control button, depending
on the product version.
3.Tap the button to enter the destination
and the address of your navigation
destination. Then start the navigation
by tapping Navigate. After a short time
- if the satellite reception is adequate
- you will receive the route information
on the screen, augmented by voice
instructions.
For further operation of the navigation
software, please refer to the
comprehensive user handbook on the
navigation CD.
In addition, brief help is available to you
on your navigation system. You can reach
it by tapping the Options/ Destination
Entry button and then selecting the help
function.
Note: When the GPS-receiver is used for
the first time, it will require some minutes
for initialization. Even if GPS signal
reception is indicated, the navigation could
be imprecise. In all future instances it will
only take about 30-60 seconds until a
correct GPS signal is available; this,
however, requires a sufficient “sight” of
the satellites.
Installing Software on Your PC
In order to be able to use self-defined
maps on your navigation system you must
install the corresponding navigation
software on your PC.
1.Before installing the navigation software
ensure that ActiveSync is installed and
your navigation system is connected
to your PC via the ActiveSync cable.
2.Insert CD 1 with the navigation software
in your CD-ROM drive. The installation
starts automatically.
3.Follow the instructions on the screen.
Content of the Navigation CDs
It may be possible that several CDs are
supplied, depending on your product
version.
Content of the CDs:
CD 1 contains the PC application,
digitalised map material and data for fast
restoring the content of the memory card.
Additional material on the card is stored
on CD 2 (optional). The PC application
will be installed on the computer and used
to set up your own map details. Apart
from this, it will support the recreation of
data on the memory card.
Installing Microsoft ActiveSync
To transfer your data between your PC
and your navigation system you need the
Microsoft ActiveSync programme.
The purchase of the navigation system
includes a license for this programme,
which can be found on the support CD.
Attention: Important files can be
overwritten or changed during software
installation. You should create a hard disk
backup, in order to be able to have access
to the original files in case of possible
problems following the installation.
You must have administrator rights to
install the software under Windows
2000/XP.
Attention: You should not connect the
navigation system to your computer yet.
1.Insert the support CD and wait until the
programme starts automatically.
Note: If it does not start automatically,
the Auto Run function is probably
deactivated. Then you have to start the
setup programme on the CD manually.
2.Choose the language, then click on
Install ActiveSync and follow the
instructions on the screen.
3.While the connection options are
checked, use the ActiveSync cable to
connect the navigation system to your
computer. To do this, plug the USB
connector into the USB port of your
computer.
The hardware installation assistant now
recognises a new device and installs a
suitable driver, which can take some
minutes. Repeat the connection search
if it fails the first time.
4.Follow the instructions on the screen.
The programme will now set up a
partnership between your PC and the
device.
GPS (GLOBAL POSITIONING SYSTEM)
