Calibre PCI93 I2C User manual

Calibre UK Ltd 2007
CALIBRE
PCI93 I2C Communications Adapter
Issue 1.1
06/03/2007

CALIBRE
Issue 1.1 Page i
06/03/2007
Welcome to the Calibre PCI93 adjustable voltage I2C adapter. This adapter provides full I2C bi-
directional compatibility as either a master or slave from within a Windows 95/98 or Windows
NT or Windows 2000 or Windows XP environment.
If you have any queries relating to this or any other I2C product supplied by Calibre please visit
our web site www.calibreuk.com.
For technical support please e-mail [e-mail] or send your queries by fax to
(44) 1274 730960, for the attention of our I2C Technical Support Department.
COPYRIGHT
This document and the software described within it are copyrighted with all rights reserved. Under
copyright laws, neither the documentation nor the software may be copied, photocopied, reproduced,
translated, or reduced to electronic medium or machine readable form, in whole or in part, without
prior written consent of Calibre UK Ltd ("Calibre"). Failure to comply with this condition may result in
prosecution.
Calibre does not warrant that this software package will function properly in every
hardware/software environment. For example, the software may not work in combination with
modified versions of the operating system or with certain network adapter drivers.
Although Calibre has tested the software and reviewed the documentation, CALIBRE MAKES
NO WARRANTY OR REPRESENTATION, EITHER EXPRESS OR IMPLIED, WITH RESPECT TO
THIS SOFTWARE OR DOCUMENTATION, THEIR QUALITY, PERFORMANCE,
MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE. THIS SOFTWARE AND
DOCUMENTATION ARE LICENSED 'AS IS', AND YOU, THE LICENSEE, BY MAKING USE
THEREOF, ARE ASSUMING THE ENTIRE RISK AS TO THEIR QUALITY AND PERFORMANCE.
IN NO EVENT WILL CALIBRE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO
USE THE SOFTWARE OR DOCUMENTATION, even if advised of the possibility of such damages.
In particular, and without prejudice to the generality of the foregoing, Calibre has no liability for any
programs or data stored or used with Calibre software, including costs of recovering such programs or
data.
Copyright Calibre UK Ltd
(c) 2007 Cornwall House, Cornwall Terrace
Bradford, BD8 7JS. UK.
E-mail: [email protected]
Web site www.calibreuk.com
All World-wide Rights Reserved
Issue 1.1 06/03/2007
All trade marks acknowledged
Calibre operates a policy of continued product improvement, therefore specifications are subject to
change without notice as products are updated or revised.
E&OE.

CALIBRE
Issue 1.1 Page ii
06/03/2007
Contents
INTRODUCTION 1
1.1. General Introduction 1
1.2. Packing List 1
1.3. Configuring the Adapter 1
1.4. Bus Termination and Protection 1
1.5. Connecting the Adapter to your System 2
1.6. Bus Capacitance Limitations/Cable Choice 2
1.7. Variable Voltage Bus Power Supply 2
INSTALLING THE ADAPTER UNDER WINDOWS 9x 3
2.1. Introduction 3
2.2. Installing the Adapter 3
2.3. Windows 95 Versions 950 and 950a 3
2.4. Windows 95 Versions 950b and 950c 3
2.5. Windows 98 3
2.6. Plug and Play Does Not Find Hardware 4
2.7. Windows 9x File Location 4
INSTALLING THE ADAPTER UNDER WINDOWS NT4 5
3.1. Introduction 5
3.2. Installing the Adapter 5
3.3. Installing the Device Driver 5
3.4. WinNT4 File Location 5
INSTALLING THE ADAPTER UNDER WINDOWS 2000 and XP 6
4.1. Introduction 6
4.2. Installing the Adapter 6
4.3. Installing the Device Driver 6
LIBRARIES FOR PROGRAMMING IN MICROSOFT WINDOWS ENVIRONMENTS 7
5.1. Introduction 7
5.2. Function Prototypes 7
5.3. Function Description 7
5.3.1. setup 7
5.3.2. sendaddress 8
5.3.3. writebyte 8
5.3.4. readbyte 8
5.3.5. sendstop 9
5.3.6. restart 9
5.3.7. getstatus 10
5.3.8. recover 10
5.3.9. slavelastbyte 10
The Real-Time Bus Monitor 11
Appendix A I2C Communications Adapter Status Codes 12
THE MOST COMMONLY ASKED I2C QUESTIONS 13
General Questions 13
Windows Questions 13

CALIBRE
Issue 1.1 Page 1
06/03/2007
INTRODUCTION
1.1. General Introduction
The I2C Communications Adapter is a PCI bus PC interface card designed to fit any IBM PC compatible.
Based on the Philips PCF8584 bus controller, it features full I2C bi-directional compatibility as either a
master or slave. I2C connections are made via a 9 way “D” socket. This product complies with the
requirements of EEC Directive 89/336 for EMC and is CE marked.
1.2. Packing List
Your I2C Communications Adapter is supplied with the following items:-
A. I2C CD ROM
B. The PCI93 plug-in card (the actual adapter)
1.3. Configuring the Adapter
NOTE
MANY COMPONENTS ON THE ADAPTER CARD ARE STATIC SENSITIVE. OBSERVE NORMAL
STATIC SENSITIVE PRECAUTIONS WHEN HANDLING THE CARD!
The adapter is supplied in a standard configuration which should suit most applications. However, some
features are link selectable. Read the following section to change the configuration.
1.4. Bus Termination and Protection
In 2006 the PCI I2C adapters were redesigned so that they complied with the RoSH Directive PCBs
earlier than 2.1 are not RoHS compliant version 2.1 and later are. At this time improvements were made
to the manufacturability of the product and to the output protection. None of the changes made to the
I2C adapters in anyway functionally alters the product, but the jumper settings are different this section
details both settings please check the PCB to determine which version of PCB you have. If you are
unsure please contact you sales representative.
PCB Issue up to and including 2.0
Normally the system to which the I2C Communications Adapter is to be connected should already have
master pull up resistors fitted to the SCL and SDA lines. If this is not the case, LK10 and LK12 can be
used to connect 4K7 pull up resistors to the 5V supply on these lines. The standard configuration is with
these resistors disconnected.
The SCL and SDA lines are protected by 100R series resistors before exiting the adapter via the 9 way
“D” socket. Upstream of the series resistors, the SCL and SDA lines are pulled up with high value
resistors (10K). These resistors can be linked out via links 9 and 11 although to ensure that the I2C Bus
is in a defined state even if no other devices are connected the links should be left on. This is the
standard configuration.
LK13 and LK14 connect optional protection diodes to the SCL and SDL lines. When selected, these
lines are clamped to the 0V and +5V lines giving protection against transients. If these diodes are
connected, the external I2C system will not function if the adapter is connected but not powered up. The
standard configuration is with these diodes disconnected.
PCB Issue 2.1 and later
Normally the system to which the I2C Communications Adapter is to be connected should already have
master pull up resistors fitted to the SCL and SDA lines. If this is not the case, LK5 and LK6 can be
used to connect 4K7 pull up resistors to the 5V supply on these lines. The standard configuration is with
these resistors disconnected.
The SCL and SDA lines are protected by 100R series resistors before exiting the adapter via the 9 way
“D” socket. Upstream of the series resistors, the SCL and SDA lines are pulled up with high value
resistors (10K). These resistors can be linked out via links 3 and 4 although to ensure that the I2C Bus is
in a defined state even if no other devices are connected the links should be left on. This is the standard
configuration.

CALIBRE
Issue 1.1 Page 2
06/03/2007
1.5. Connecting the Adapter to your System
All external connections are made via a 9 way “D” socket:
Pin Normal Mode
1 0V
2 0V
3 0V
4 0V
5 NC
6 SDA (Bi-directional)
7 +V (variable voltage)
8 SCL (Bi-directional)
9 NC
1.6. Bus Capacitance Limitations/Cable Choice
The maximum allowable capacitance on the I2C bus in normal mode depends on the value of the SCL
and SDA master pull-ups, but never exceeds 400pF. Refer to Phillips Technical Handbook Book 4 Parts
12a and 12b for further details. Care should be taken in choosing a length and type of interconnecting
cable, which will not exceed this limit.
For most systems with a distance of a few metres between the I2C Communications Adapter and the
target system, screened cable is NOT recommended, as it is likely to introduce too much capacitance.
However, the EMC performance of an unscreened cable is always potentially poorer than a screened
one. The Adapter's EMC performance even with an unscreened cable is good - but this may not be true
of the target system! If you are in any doubt at to the best way to connect up your system with EMC in
mind please contact your supplier or Calibre for advice.
1.7. Variable Voltage Bus Power Supply
Pin 7 on the “D” connector is connected to the variable bus voltage power rail. Power for external
circuitry can be drawn from here, but care should be taken never to short it to 0V or to exceed 250mA
loading. It is short circuit and overload protected by a self-resetting thermal fuse but prolonged shorting
could cause the PCI93 to generate an excessive amount of heat inside your computer.
When shipped to you, the bus voltage was pre-set at 3.3V for use with low voltage memories. You can
adjust the voltage between 2V and 6V by inserting a small screwdriver through the hole in the card
mounting bracket. As you adjust the voltage (you can monitor it by connecting a meter to pin 7 of the
bus connector) the bus logic levels will track, keeping at 30% / 70% of supply for low and high level
thresholds respectively.
Your PCI93 has been factory set for use on 3.3V I2C bus systems. Use on 5V I2C bus systems
without adjusting the voltage control WILL CAUSE PERMANENT DAMAGE to the PCI93. The
fault is factory detectable and you WILL BE CHARGED FOR THE REPAIR.

CALIBRE
Issue 1.1 Page 3
06/03/2007
INSTALLING THE ADAPTER UNDER WINDOWS 9x
2.1. Introduction
This section details the installation of the PCI93 I2C communications adapter under Windows 95® /
98®.
The appearance of the dialog boxes during the installation of new hardware varies depending on the
version of Windows 95 and Windows 98. Consequently this section is slit into 3 parts
Windows 95 versions 950 and 950a
Windows 95 version 950b and 950c
Windows 98
Which version of Windows you have installed on your machine by click on the My Computer icon with
the right mouse button and then selecting Properties.
2.2. Installing the Adapter
Turn off your computer and disconnect it from the mains power supply. Remove the PC cover and then
a PCI slot blanking plate.
Insert the card into the PCI slot, ensure that it is fully home and screw the adapter panel into the PC.
Replace the PC cover and reconnect the PC to the mains power supply. Turn the PC on.
2.3. Windows 95 Versions 950 and 950a
When Windows 95 restarts it should detect the new hardware (if this is not so see section 2.6), select
“Driver from disk provided by hardware manufacturer” then click OK
When you see the Install from Disk screen, insert the CD_ROM into the drive. Select the drive letter
appropriate to your CD – ROM drive (usually D) browse the CD for the \cd_pci directory. The click OK,
Windows will install the drivers for the adapter.
NOW SHUTDOWN YOUR PC
On restarting you PC click on the My Computer icon with the right mouse button and then selecting
Properties. Select Device Manager, expand the CaDrv and the select I2C Driver for PCI Devices
Click on Properties is the installation was successful the Device Status will say “This device is
working properly”.
2.4. Windows 95 Versions 950b and 950c
When Windows 95 restarts it should detect the new hardware (if this is not so see section 2.6), and the
Driver Wizard should be displayed.
Insert the CD_ROM into the drive. Follow the wizard instructions, if the wizard fails to find the driver
select Other Location. Then follow the wizard instructions to install the unknown device from the CD
ROM.
NOW SHUTDOWN YOUR PC
On restarting you PC click on the My Computer icon with the right mouse button and then selecting
Properties. Select Device Manager, expand the CaDrv and the select I2C Driver for PCI Devices
Click on Properties is the installation was successful the Device Status will say “This device is
working properly”.
2.5. Windows 98
When Windows 98 restarts it should detect the new hardware (if this is not so see section 2.6), and the
Driver Wizard should be displayed.
Select Search for the best driver for your device and click Next.
When the next screen is displayed select CD-ROM drive and Specify a location. Browse the CD for
the \cd_pci directory, select the CaDrv.inf file and click Next.
The next screen tells you that Windows has found the driver click Next. On the final screen click Finish.

CALIBRE
Issue 1.1 Page 4
06/03/2007
NOW SHUTDOWN YOUR PC
On restarting you PC click on the My Computer icon with the right mouse button and then selecting
Properties. Select Device Manager, expand the CaDrv and the select I2C Driver for PCI Devices
Click on Properties is the installation was successful the Device Status will say “This device is
working properly”.
2.6. Plug and Play Does Not Find Hardware
From the Control Panel select Add New Hardware. Follow the instruction and when prompted choose
Other Devices and Have Disk. Browse the CD for the \cd_pci directory select the Cadrv.inf then
continue to follow the displayed instruction.
When the installation is complete SHUTDOWN THE PC.
On restarting you PC click on the My Computer icon with the right mouse button and then selecting
Properties. Select Device Manager, expand the CaDrv and the select I2C Driver for PCI Devices
Click on Properties is the installation was successful the Device Status will say “This device is
working properly”.
2.7. Windows 9x File Location
If you are going to use the dynamic link library to write your I2C protocol software click on the
PCI_UTILS follow the instructions to unzip the files (if you do not have an unlock code please contact
[email protected] ). Then
1)Copy the Cali2c32.Lib from the \lib directory into your compilers \lib
2)Copy the cali2c32.Dll from the \lib directory into \WINDOWS\SYSTEM

CALIBRE
Issue 1.1 Page 5
06/03/2007
INSTALLING THE ADAPTER UNDER WINDOWS NT4
3.1. Introduction
This section details the installation of the PCI90 I2C communications adapter under Windows NT4.
3.2. Installing the Adapter
Turn off your computer and disconnect it from the mains power supply. Remove the PC cover and then
a PCI slot blanking plate.
Insert the card into the PCI slot, ensure that it is fully home and screw the adapter panel into the PC.
Replace the PC cover and reconnect the PC to the mains power supply. Turn the PC on.
3.3. Installing the Device Driver
TO INSTALL A DRIVER YOU MUST HAVE ADMINISTRATOR PRIVILAGES.
Copy all the following files from the CD (located in the \cd_pci directory, to c:\winnt\system32\drivers
1) CaDrv.sys - The device driver
2) CaDrv.ini - The device driver initialisation file
3) Regini.exe - This a Microsoft registration program
From a DOS window, change the directory to the \system32\drivers (usually c:\winnt\system32\drivers).
Then type regini cadrv.ini <CR> this will register the driver.
NOW SHUTDOWN YOUR PC
3.4. WinNT4 File Location
If you are going to use the dynamic link library to write your I2C protocol software click on the
PCI_UTILS follow the instructions to unzip the files (if you do not have an unlock code please contact
[email protected] ). Then
1)Copy the Cali2c32.Lib from the \lib directory into your compilers \lib
2)Copy the cali2c32.Dll from the \lib directory into \WINNT\SYSTEM

CALIBRE
Issue 1.1 Page 6
06/03/2007
INSTALLING THE ADAPTER UNDER WINDOWS 2000 and XP
4.1. Introduction
This section details the installation of the PCI90 I2C communications adapter under Windows 2000 and
XP. The drivers for these operating systems are located in the \CD_PCI\W2k Drivers and \CD_PCI\XP
DRIVERS folders on the CD. You MUST use the driver appropriate to you operating system DO NOT try
to us the Windows NT or Windows 98 drivers these will not work.
Both these operating systems are plug and play you must NOT run the regini applications on these
operating systems.
4.2. Installing the Adapter
Turn off your computer and disconnect it from the mains power supply. Remove the PC cover and then
a PCI slot blanking plate.
Insert the card into the PCI slot, ensure that it is fully home and screw the adapter panel into the PC.
Replace the PC cover and reconnect the PC to the mains power supply. Turn the PC on.
4.3. Installing the Device Driver
TO INSTALL A DRIVER YOU MUST BE THE ADMINISTRATOR.
Wait for the wizard to find the new hardware, if the operating system does not recognise new hardware
select add new hardware via the control panel.
VERY IMPORTANT: Sometimes the wizard selects an unsuitable driver option found a
c:\windows\inf\oem1.inf this file is nothing to do with Calibre and MUST NOT be used.
The solution is to select the "Display list" option. From the next page select Have Disk select the
CAWDM13.INF file located on the CD in \CD_PCI

CALIBRE
Issue 1.1 Page 7
06/03/2007
LIBRARIES FOR PROGRAMMING IN MICROSOFT WINDOWS ENVIRONMENTS
5.1. Introduction
Each utility is documented in a standard format which lists its name, usage, function and effect on the
adapter is given. The adapter should be setup prior to any data transfer.
5.2. Function Prototypes
If you are using ‘C’ or ‘C++’ copy the file CALI2C32.H into the directory containing your project and add
the line:
#include "CALI2C32.H"
The following functions are implemented in the windows libraries:-
extern __declspec(dllimport) int WINAPI setup (int, int, int);
extern __declspec(dllimport) int WINAPI sendaddress (int, int, int);
extern __declspec(dllimport) int WINAPI writebyte(int, int);
extern __declspec(dllimport) int WINAPI readbyte(int, int);
extern __declspec(dllimport) int WINAPI sendstop(int);
extern __declspec(dllimport) int WINAPI restart (int, int, int);
extern __declspec(dllimport) int WINAPI getstatus(int);
extern __declspec(dllimport) int WINAPI recover(int);
extern __declspec(dllimport) int WINAPI slavelastbyte(int);
extern __declspec(dllimport) int WINAPI dllissue(void);
If you are using Visual Basic copy the file CALI2C32.BAS into the directory containing your project and
add the file CALI2C32.BAS to your project:
The following functions are implemented in the windows libraries:-
Public Declare Function setup% Lib "cali2c32.dll" (ByVal Board%, ByVal
OwnAddress%, ByVal Sclk%)
Public Declare Function sendaddress% Lib "cali2c32.dll" (ByVal Board%, ByVal
slaveaddress%, ByVal Setnack%)
Public Declare Function restart% Lib "cali2c32.dll" (ByVal Board%, ByVal
slaveaddress%, ByVal Setnack%)
Public Declare Function writebyte% Lib "cali2c32" (ByVal Board%, ByVal
wrdata%)
Public Declare Function readbyte% Lib "cali2c32.dll" (ByVal Board%, ByVal
Setnack%)
Public Declare Function sendstop% Lib "cali2c32.dll" (ByVal Board%)
Public Declare Function getstatus% Lib "cali2c32.dll" (ByVal Board%)
Public Declare Function recover% Lib "cali2c32.dll" (ByVal Board%)
Public Declare Function slavelastbyte% Lib "cali2c32.dll" (ByVal Board%)
Public Declare Function dllversion% Lib "cali2c32.dll" ()
NOTE A type is defined in cali2c32.bas to help passing parameters to the DLL, if you do not
wish to use this local variables MUST be declared as static
5.3. Function Description
5.3.1. setup
Function specification int setup(int board, int ownaddress, int sclk)
Parameters are: int board
This parameter .is reserved for future use and should always be set to zero (0).
int ownaddress
This is the I2C address to which the adapter is to respond in slave mode. This
forms the upper 7 bits of the 8 bit address, the lowest bit being the read(1) or
write(0) bit. This means that if ownaddress = 57H the card will respond to a
write address of AEH and a read address of AFH.
int sclk
This is the clock rate (bit rate for the I2C serial bus) when operating as a
master.
