California Instruments MX Series User manual

7003-960 Rev AY www.programmablepower.com
MX Series
AC and DC Power Source
User Manual
Series I / Series II

User Manual – Rev AY AMETEK Programmable Power
MX Series 2
User's Manual
California Instruments - AC Power Source
By AMETEK Programmable Power.
Models:
• MX30-1
• MX30-3
• MX30-3Pi
• MX45-1
• MX45-3
• MX45-3Pi
• MX60-3
• MX60-3Pi (-MB)
• MX90-3
• MX90-3Pi (-MB)
• MX135-3
• MX135-3Pi (-MB)
• MX180-3
• MX180-3Pi (-MB)
• MX225-3
• MX225-3Pi (-MB)
• MX270-3
• MX270-3Pi (-MB)
Note: For MX15-1, MX15-1Pi, see user manual P/N 7005-960.

User Manual – Rev AY AMETEK Programmable Power
MX Series 3
About AMETEK
AMETEK Programmable Power, Inc., a Division of AMETEK, Inc., is a global leader in the design and
manufacture of precision, programmable power supplies for R&D, test and measurement, process control,
power bus simulation and power conditioning applications across diverse industrial segments. From bench
top supplies to rack-mounted industrial power subsystems, AMETEK Programmable Power is the proud
manufacturer of Elgar, Sorensen, California Instruments and Power Ten brand power supplies.
AMETEK, Inc. is a leading global manufacturer of electronic instruments and electromechanical devices with
annualized sales of $2.5 billion. The Company has over 11,000 colleagues working at more than 80
manufacturing facilities and more than 80 sales and service centers in the United States and around the
world.
Trademarks
AMETEK is a registered trademark of AMETEK, Inc. California Instruments is a trademark owned by AMETEK,
Inc. Other trademarks, registered trademarks, and roduct names are the ro erty of their res ective owners
and are used herein for identification ur oses only.
Notice of Copyright
MX Series User Manual © 2015 AMETEK Programmable Power, Inc. All rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, AMETEK PROGRAMMABLE POWER, INC. (“AMETEK”):
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR
OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER
SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE
USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S
RISK, AND
(c) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH, ALTHOUGH STEPS
HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE TRANSLATION, THE ACCURACY CANNOT BE
GUARANTEED. APPROVED AMETEK CONTENT IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION,
WHICH IS POSTED AT WWW.PROGRAMMABLEPOWER.COM.
Date and Re ision
March 2015 Revision AY
Part Number
7003-960
Contact Information
Telephone: [phone] (toll free in North America)
858 450 0085 (direct)
Fax: [phone]
Email: sales. [email protected]
service. [email protected]
Web: www. rogrammable ower.com

User Manual – Rev AY AMETEK Programmable Power
MX Series 4
Important Safety Instructions
Before applying power to the system, verify that your product is configured properly for your particular
application.
WARNING
Hazardous voltages may be present when covers are removed. Qualified
personnel must use extreme caution when servicing this equipment.
Circuit boards, test points, and output voltages also may be floating above
(below) chassis ground.
WARNING
The equipment used contains ESD sensitive parts. When installing
equipment, follow ESD Safety Procedures. Electrostatic discharges might
cause damage to the equipment.
Only qualified personnel who deal with attendant hazards in power supplies, are allowed to perform installation
and servicing.
Ensure that the AC power line ground is connected properly to the Power Rack input connector or chassis.
Similarly, other power ground lines including those to application and maintenance equipment must be grounded
properly for both personnel and equipment safety.
Always ensure that facility AC input power is de-energized prior to connecting or disconnecting any cable.
In normal operation, the operator does not have access to hazardous voltages within the chassis. However,
depending on the user’s application configuration, HIGH VOLTAGES HAZARDOUS TO HUMAN SAFETY may
be normally generated on the output terminals. The customer/user must ensure that the output power lines are
labeled properly as to the safety hazards and that any inadvertent contact with hazardous voltages is eliminated.
Guard against risks of electrical shock during open cover checks by not touching any portion of the electrical
circuits. Even when power is off, capacitors may retain an electrical charge. Use safety glasses during open
cover checks to avoid personal injury by any sudden component failure.
Neither AMETEK Programmable Power Inc., San Diego, California, USA, nor any of the subsidiary sales
organizations can accept any responsibility for personnel, material or inconsequential injury, loss or damage that
results from improper use of the equipment and accessories.
SAFETY SYMBOLS

User Manual – Rev AY AMETEK Programmable Power
MX Series 5
Product Family: MX Series AC Power Source
Warranty Period: 1 Year
WARRANTY TERMS
AMETEK Programmable Power, Inc. (“AMETEK”), provides this written warranty covering the Product stated
above, and if the Buyer discovers and notifies AMETEK in writing of any defect in material or workmanship
within the applicable warranty period stated above, then AMETEK may, at its option: repair or replace the
Product; or issue a credit note for the defective Product; or provide the Buyer with replacement parts for the
Product.
The Buyer will, at its expense, return the defective Product or parts thereof to AMETEK in accordance with the
return procedure specified below. AMETEK will, at its expense, deliver the repaired or replaced Product or
parts to the Buyer. Any warranty of AMETEK will not apply if the Buyer is in default under the Purchase Order
Agreement or where the Product or any part thereof:
• is damaged by misuse, accident, negligence or failure to maintain the same as s ecified or
required by AMETEK;
• is damaged by modifications, alterations or attachments thereto which are not authorized by
AMETEK;
• is installed or o erated contrary to the instructions of AMETEK;
• is o ened, modified or disassembled in any way without AMETEK’s consent; or
• is used in combination with items, articles or materials not authorized by AMETEK.
The Buyer may not assert any claim that the Products are not in conformity with any warranty until the Buyer
has made all payments to AMETEK provided for in the Purchase Order Agreement.
PRODUCT RETURN PROCEDURE
Request a Return Material Authorization (RMA) number from the re air facility (must be done in the
country in which it was purchased):
• In the USA, contact the AMETEK Re air De artment rior to the return of the roduct to
AMETEK for re air:
Tele hone: 800-733-5427, ext. 2295 or ext. 2463 (toll free North America)
858-450-0085, ext. 2295 or ext. 2463 (direct)
• Outside the United States, contact the nearest Authorized Service Center (ASC). A full listing
can be found either through your local distributor or our website,
www. rogrammable ower.com, by clicking Su ort and going to the Service Centers tab.
When requesting an RMA, have the following information ready:
• Model number
• Serial number
• Descri tion of the roblem
NOTE: Unauthorized returns will not be accepted and will be returned at the shipper’s expense.
NOTE: A returned product found upon inspection by AMETEK, to be in specification is subject to an
evaluation fee and applicable freight charges.

User Manual – Rev AY AMETEK Programmable Power
MX Series 6
Table of Contents
1. Introduction................................................................................................................................... 11
1.1 General Description ........................................................................................................................11
1.2 Manual organization and format...................................................................................................... 11
1.3 Different Model Series.....................................................................................................................12
2. Specifications................................................................................................................................ 13
2.1 Electrical ......................................................................................................................................... 13
2.2 Mechanical......................................................................................................................................23
2.3 Environmental.................................................................................................................................24
2.4 Regulatory.......................................................................................................................................24
2.5 Front Panel Controls....................................................................................................................... 24
2.6 Special Features and Options.........................................................................................................25
2.7 Supplemental Specifications...........................................................................................................34
3. Unpacking and Installation............................................................................................................ 40
3.1 Unpacking.......................................................................................................................................40
3.2 Power Requirements....................................................................................................................... 40
3.3 Mechanical Installation.................................................................................................................... 41
3.4 AC Input Connections and Wiring...................................................................................................41
3.5 AC On/Off Circuit Breaker on MX Series front panel. .....................................................................44
3.6 Output Connections ........................................................................................................................46
3.7 Connectors - Rear Panel.................................................................................................................60
3.8 Multiple Cabinet System Configurations (incl. –MB).......................................................................68
3.9 Multiple Cabinet Power Up/Down Procedures ................................................................................ 70
3.10 Clock and Lock Configurations ....................................................................................................... 71
3.11 Basic Initial Functional Test ............................................................................................................74
3.12 Remote Inhibit / Remote Shutdown ................................................................................................76
3.13 Junction Box Accessory.................................................................................................................. 77
3.14 Output Filter Box Accessory............................................................................................................ 78
3.15 Fuse Box Accessory ....................................................................................................................... 79
4. Front Panel Operation .................................................................................................................. 80
4.1 Tour of the Front Panel...................................................................................................................80
4.2 Menu Structure................................................................................................................................ 87
4.3 Output Programming..................................................................................................................... 125
4.4 Waveform Management [3Pi Controller only] ...............................................................................127
4.5 Standard Measurements...............................................................................................................132
4.6 Advanced Measurements [3Pi Controller only]............................................................................. 134
4.7 Transient Programming.................................................................................................................143
5. Principle of Operation................................................................................................................. 150
5.1 General ......................................................................................................................................... 150
5.2 Overall Description........................................................................................................................150
5.3 Controller Assembly...................................................................................................................... 152
5.4 System Interface Board.................................................................................................................156
5.5 Current / Voltage Sensor Board....................................................................................................156
5.6 Low Voltage Power Supply ........................................................................................................... 156
5.7 Power Module ............................................................................................................................... 157
6. Calibration................................................................................................................................... 162
6.1 Recommended Calibration Equipment ......................................................................................... 162
6.2 Front Panel Calibration Screens................................................................................................... 163
6.3 Routine Measurement Calibration.................................................................................................166
6.4 Routine Output Calibration............................................................................................................170
6.5 Non-Routine Calibration................................................................................................................ 178
7. Service........................................................................................................................................ 183

User Manual – Rev AY AMETEK Programmable Power
MX Series 7
7.1 Cleaning........................................................................................................................................ 183
7.2 General ......................................................................................................................................... 183
7.3 Basic operation ............................................................................................................................. 183
7.4 Advanced Troubleshooting. ..........................................................................................................185
7.5 Factory Assistance........................................................................................................................ 187
7.6 Fuses ............................................................................................................................................ 188
7.7 Firmware Updates......................................................................................................................... 189
8. Top Assembly Replaceable Parts............................................................................................... 192
9. Options ....................................................................................................................................... 195
9.1 Introduction ................................................................................................................................... 195
9.2 Option -HV: Additional AC Voltage Range.................................................................................... 196
9.3 Option –160: RTCA/DO-160 Tests................................................................................................197
9.4 Option –411: IEC 61000-4-11 Voltage Dips and Interruptions...................................................... 211
9.5 Option –413: IEC 61000-4-13 Interharmonics Test ......................................................................219
9.6 Option –704: MilStd704 Tests....................................................................................................... 230
9.7 Option –ABD: Airbus ABD0100.1.8 Test.......................................................................................242
9.8 Option –AMD: Airbus AMD24C Test............................................................................................. 242
9.9 Option –787: Boeing B787-0147 Test..........................................................................................242
9.10 Option –WHM: Watt Hour Measurement...................................................................................... 243
9.11 Option –SNK: Current Sink........................................................................................................... 245
9.12 Option - EXTD: External drive ……………………………………………………………………. 248
10. Error Messages .......................................................................................................................... 250
Index.................................................................................................................................................. 255

User Manual – Rev AY AMETEK Programmable Power
MX Series 8
List of Figures
Figure 2-1: MX30-3 Voltage / Current Rating Chart for 150/300 V AC Ranges. .....................................................................17
Figure 2-2: MX45-3 Voltage / Current Rating Chart for 150/300 V AC Ranges – Max Rating..................................................17
Figure 2-3: Voltage / Current Rating Chart for 150/300 V AC Ranges – Derated....................................................................18
Figure 2-4: MX30-3 Voltage / Current Rating Chart for 200/400 V DC Ranges.......................................................................19
Figure 2-5: MX45-3 Voltage / Current Rating Chart for 200/400 V DC Ranges – Max. Rating ................................................19
Figure 2-6: Voltage / Current Rating Chart for 200/400 V DC Ranges – Derated....................................................................20
Figure 2-7: MX30-3 Voltage / Current Rating Chart, -HV Option............................................................................................29
Figure 2-8: MX45-3 Voltage / Current Rating Chart, -HV Option – Max. Rating. .....................................................................29
Figure 2-9: Voltage / Current Rating Chart, -HV Option – Derated..........................................................................................29
Figure 2-10: -HF Option Voltage Frequency Rating 300V range.............................................................................................31
Figure 2-11: -HF Option Voltage Frequency Rating 150V range.............................................................................................31
Figure 2-12: MX output filter option schematic........................................................................................................................36
Figure 2-13: MX45 Output Noise 10 KHz – 1 MHz..................................................................................................................37
Figure 2-14: MX45 Output Noise 10 KHz - 1 MHz with optional Filter.....................................................................................38
Figure 3-1: The MX45 Power Source......................................................................................................................................40
Figure 3-2: Location of AC Input Fuse Block and Chassis Ground Connection - Front View, Access Panel Removed..........42
Figure 3-3: MX Series AC Input Connection Diagram (Rear view)..........................................................................................43
Figure 3-4: Rear Panel ...........................................................................................................................................................45
Figure 3-5: External sense cable shield connection to chassis ground...................................................................................46
Figure 3-6: Location of Output Terminals (Front view)............................................................................................................49
Figure 3-7: MX30-1 / MX45-1 Output Wiring (Rear view)........................................................................................................50
Figure 3-8: MX30-3 / MX45-3 Output Wiring (Rear view)........................................................................................................51
Figure 3-9:MX60, MX60-MB, MX90 or MX90-MB Output Wiring (Rear view)..........................................................................52
Figure 3-10: Two MX's in Clock and Lock mode Output Wiring (Rear view)............................................................................53
Figure 3-11: MX135 or MX135-MB Output Wiring (Rear view)................................................................................................55
Figure 3-12: Three MX's in Clock and Lock mode - Output Wiring (Rear view).......................................................................56
Figure 3-13: MX180, MX225 or MX270 Output Wiring (Rear view) ........................................................................................58
Figure 3-14: Ship kit Terminal Block dimensions....................................................................................................................59
Figure 3-15: RS232C Cable for PC Connection wiring diagram – MX without USB. ...............................................................64
Figure 3-16: USB Connector pin orientation. ..........................................................................................................................65
Figure 3-17: Emergency Switch (ES Option) shut off inter connect on -MB systems..............................................................67
Figure 3-18: Multi-Cabinet DIP Switch Location and Setting...................................................................................................69
Figure 3-19: Functional Test Setup.........................................................................................................................................75
Figure 3-20: 7003-416-1 Output Junction Box ........................................................................................................................77
Figure 3-21: 7003-424-1 Output noise filter box......................................................................................................................78
Figure 3-22: 7003-426-1 Output Fuse Box..............................................................................................................................79
Figure 4-1: Shuttle Knob.........................................................................................................................................................82
Figure 4-2: FUNCTION Keypad.............................................................................................................................................83
Figure 4-3: Entering Values from the Decimal Keypad...........................................................................................................85
Figure 4-4: Cursor UP Key Movement....................................................................................................................................85
Figure 4-5: Cursor DOWN key Movement ..............................................................................................................................86
Figure 4-6: Main Menu 1 Screen.............................................................................................................................................86
Figure 4-7: Menu 1 through 3 .................................................................................................................................................87
Figure 4-8: PROGRAM Menu.................................................................................................................................................91
Figure 4-9: MEASUREMENTS Screen, Single Phase and Three Phase Modes.....................................................................93
Figure 4-10: HARMONICS/TRACE ANALYSIS Screen..........................................................................................................95
Figure 4-11: TRANSIENTS Menu...........................................................................................................................................98
Figure 4-12: VOLTAGE SURGE/SAG SETUP Screen ...........................................................................................................99
Figure 4-13: VOLTAGE SWEEP/STEP SETUP Screen.......................................................................................................101
Figure 4-14: FREQUENCY SWEEP/STEP SETUP Screen..................................................................................................103
Figure 4-15 VOLTAGE/FREQUENCY SWEEP/STEP SETUP Screen................................................................................104
Figure 4-16:START/VIEW TRANSIENT SEQUENCE Screen ..............................................................................................105
Figure 4-17: WAVEFORMS Menu........................................................................................................................................106
Figure 4-18: APPLICATIONS Menus....................................................................................................................................109
Figure 4-19: SETUP REGISTERS Menu..............................................................................................................................110
Figure 4-20: UTILITY Menus ................................................................................................................................................111
Figure 4-21: GPIB/RS232 SETUP Menu..............................................................................................................................114
Figure 4-22: VOLTAGE/CURRENT CONTROL SETUP Menu .............................................................................................115
Figure 4-23: INITIAL SETUP Menus.....................................................................................................................................116
Figure 4-24: LIMIT SETUP Menu .........................................................................................................................................118
Figure 4-25: CONFIGURATION SETUP Menus...................................................................................................................119
Figure 4-26: OUTPUT IMPEDANCE Menu...........................................................................................................................122
Figure 4-27: MEASUREMENT CAL FACTORS Menu (Series I only) ...................................................................................123
Figure 4-28: MEASUREMENT CAL FACTORS Menu (Series II only) ..................................................................................123
Figure 4-29: OUTPUT CAL FACTORS Menu (Series I only) ................................................................................................124
Figure 4-30: OUTPUT CAL FACTORS Menu (Series II only) ...............................................................................................124
Figure 4-31: Selecting a Waveform ......................................................................................................................................127

User Manual – Rev AY AMETEK Programmable Power
MX Series 9
Figure 4-32: Selecting Waveforms for Single Phase or All Phases.......................................................................................127
Figure 4-33: Custom Waveform Creation with GUI Program ................................................................................................128
Figure 4-34: Waveform Crest Factor Affects Max. rms Voltage............................................................................................130
Figure 4-35: Waveform Frequency Domain View Mode........................................................................................................131
Figure 4-36: Scrolling Through Tabular FFT Data.................................................................................................................135
Figure 4-37: Scrolling through bar chart FFT Data................................................................................................................135
Figure 4-38: Scrolling Through Acquired Waveform Data.....................................................................................................137
Figure 4-39: SET VOLT Trigger Source Acquisition..............................................................................................................139
Figure 4-40: Positive Trigger Delay (Post Trigger Data)........................................................................................................141
Figure 4-41: Negative Trigger Delay (Pre-Trigger Data)........................................................................................................142
Figure 4-42: Pulse Transients...............................................................................................................................................144
Figure 4-43: List Transients..................................................................................................................................................145
Figure 4-44: Switching Waveforms in a Transient List..........................................................................................................148
Figure 4-45: START/VIEW TRANSIENT SEQUENCE Menu................................................................................................149
Figure 5-1: MX Series Functional Block Diagram..................................................................................................................150
Figure 5-2: MX Series Detailed Block Diagram.....................................................................................................................154
Figure 5-3: Power Module Detailed Block Diagram...............................................................................................................155
Figure 5-4: Power Module Layout.........................................................................................................................................157
Figure 5-5: Amplifier Board Layout ....................................................................................................................................... 159
Figure 6-1: Calibration Setup MX45-1 (Rear view)................................................................................................................164
Figure 6-2: Calibration Setup MX30-3Pi, MX45-3Pi or MX30-3, MX45-3 (Rear view)............................................................165
Figure 6-3: Current Measurement Calibration Setup (Rear view)..........................................................................................166
Figure 6-4: DC offset AC filter...............................................................................................................................................170
Figure 6-5: -413 Option Aux Generator Adjustments ............................................................................................................176
Figure 9-1: Application Menu................................................................................................................................................198
Figure 9-2: DO160 Main Menu..............................................................................................................................................199
Figure 9-3: Normal State ......................................................................................................................................................199
Figure 9-4: Voltage Modulation.............................................................................................................................................201
Figure 9-5: Frequency Modulation........................................................................................................................................202
Figure 9-6: Power Interrupt...................................................................................................................................................203
Figure 9-7: Power Interrupt for Group 2 and 3 ......................................................................................................................204
Figure 9-8: Emergency Screen.............................................................................................................................................205
Figure 9-9: Abnormal Screen................................................................................................................................................206
Figure 9-10: DO-160 DC Main Menu ....................................................................................................................................208
Figure 9-11: Normal State ....................................................................................................................................................208
Figure 9-12: Abnormal State.................................................................................................................................................209
Figure 9-13: Application Menu..............................................................................................................................................213
Figure 9-14: IEC1000-4-11 Menu .........................................................................................................................................213
Figure 9-15: IEC Dips and Interrupts ....................................................................................................................................214
Figure 9-16: Voltage Variation Screen..................................................................................................................................216
Figure 9-17: EN 61000-4-11 Voltage Variation specification- Edition 1.0..............................................................................217
Figure 9-18: EN 61000-4-11 Voltage Variation specification- Edition 2.0..............................................................................217
Figure 9-19: IEC 61000-4-11 GUI screen. ............................................................................................................................218
Figure 9-20: Application Setup Menus..................................................................................................................................220
Figure 9-21: IEC1000-4-13 Menu .........................................................................................................................................220
Figure 9-22: IEC 1000-4-13 FCURVE...................................................................................................................................222
Figure 9-23: IEC 1000-4-13 OSWING ..................................................................................................................................222
Figure 9-24: IEC 1000-4-13 SWEEP....................................................................................................................................223
Figure 9-25: IEC 1000-4-13 Harmonics ................................................................................................................................223
Figure 9-26: IEC 1000-4-13 INTERHARMONICS.................................................................................................................224
Figure 9-27: IEC 61000-4-13 Meister Curve .........................................................................................................................224
Figure 9-28: IEC 61000-4-13 Test Flowchart Class 1 and 2..................................................................................................226
Figure 9-29:IEC 61000-4-13 Test Flowchart Class 3 ............................................................................................................227
Figure 9-30: MENU 2 SCREEN............................................................................................................................................229
Figure 9-31: INTERHARMONICS SCREEN.........................................................................................................................229
Figure 9-32: Application Menu..............................................................................................................................................232
Figure 9-33: MIL704 Menu....................................................................................................................................................233
Figure 9-34: Steady State Menu...........................................................................................................................................233
Figure 9-35: Transient Menu.................................................................................................................................................235
Figure 9-36: Emergency Menu .............................................................................................................................................236
Figure 9-37: Abnormal Screen..............................................................................................................................................237
Figure 9-38: MIL704 DC Menu..............................................................................................................................................238
Figure 9-39: Steady State DC...............................................................................................................................................238
Figure 9-40: Transient Menu.................................................................................................................................................239
Figure 9-41: Abnormal Test Screen......................................................................................................................................240
Figure 9-42: Emergency Test ...............................................................................................................................................241
Figure 9-43: Application Screen............................................................................................................................................243
Figure 9-44: Watt-Hour Meter Screen...................................................................................................................................243
Figure 9-45: WH-Meter Screen with Function Active ............................................................................................................243
Figure 9-46: REGENERATE CONTROL screen...................................................................................................................246

User Manual – Rev AY AMETEK Programmable Power
MX Series 10
List of Tables
Table 3-1: Suggested Input Wiring Sizes for each MX Cabinet * ............................................................................................44
Table 3-2: Suggested Output Wiring Sizes *...........................................................................................................................47
Table 3-3: Output Terminal connections.................................................................................................................................48
Table 3-4: System Interface Connectors.................................................................................................................................61
Table 3-5: Analog Interface Connector...................................................................................................................................61
Table 3-6: BNC Connectors....................................................................................................................................................62
Table 3-7: BNC Connectors....................................................................................................................................................62
Table 3-8: External Sense Connector.....................................................................................................................................62
Table 3-9: RS232 Connector pin out – MX with RS232 and USB. ..........................................................................................63
Table 3-10: RS232C Connector pin out – MX with RS232 but no USB...................................................................................63
Table 3-11: USB Connector pin out........................................................................................................................................65
Table 3-12: RJ45 LAN Connector pin out. ..............................................................................................................................66
Table 3-13: Clock and Lock Configuration settings.................................................................................................................71
Table 3-14: Clock and Lock Initialization settings ...................................................................................................................72
Table 3-15: Remote Inhibit Mode Settings..............................................................................................................................76
Table 6-1: Calibration Load Values.......................................................................................................................................167
Table 6-2: Measurement Calibration Table...........................................................................................................................169
Table 6-3: Output Calibration Table – MX Series I................................................................................................................177
Table 6-4: Output Calibration Table – MX Series II...............................................................................................................177
Table 6-5: Current Limit Calibration......................................................................................................................................180
Table 6-6: Programmable Z adjustment pots........................................................................................................................182
Table 6-7: Formulas to calculate R and L.............................................................................................................................182
Table 7-1: Basic Symptoms..................................................................................................................................................183
Table 7-2: MX Fuse Ratings.................................................................................................................................................188
Table 7-3: Flash Down load Messages.................................................................................................................................191
Table 8-1: Replaceable Parts ...............................................................................................................................................193
Table 8-2: Fuses ..................................................................................................................................................................194
Table 9-1: Normal Voltage and Frequency Minimum...........................................................................................................200
Table 9-2: Normal Voltage and Frequency Maximum ...........................................................................................................200
Table 9-3: Normal Voltage Unbalance..................................................................................................................................200
Table 9-4: Normal VoltageSurge Sequence..........................................................................................................................204
Table 9-5: Normal Frequency Transient Sequence...............................................................................................................205
Table 9-6: Normal Frequency Variation Sequence ...............................................................................................................205
Table 9-7: Emergency Voltage and Frequency Minimum......................................................................................................206
Table 9-8: Emergency Voltage and Frequency Maximum.....................................................................................................206
Table 9-9: Emergency Voltage Unbalance............................................................................................................................206
Table 9-10: Abnormal Voltage Minimum...............................................................................................................................207
Table 9-11: Abnormal Voltage Maximum..............................................................................................................................207
Table 9-12: Abnormal Frequency Transient..........................................................................................................................207
Table 9-13: Normal Voltage Minimum ..................................................................................................................................208
Table 9-14: Normal Voltage Maximum..................................................................................................................................209
Table 9-15: Voltage Surge....................................................................................................................................................209
Table 9-16: Abnormal Voltage Surge....................................................................................................................................210
Table 9-17: Phase mapping..................................................................................................................................................212
Table 9-18: IEC 61000-3-34 Table C.2.................................................................................................................................212
Table 9-19: Dips and Interruptions Tests Performed During RUN ALL ................................................................................214
Table 9-20: Voltage Variations Test Performed During RUN ALL.........................................................................................216
Table 10-1: Error Messages .................................................................................................................................................254

User Manual – Rev AY AMETEK Programmable Power
MX Series 11
1. Introduction
This instruction manual contains information on the installation, operation, calibration and
maintenance of all power systems that use the MX Series power sources with the programmable
controller.
1.1 General Description
The MX Series AC and DC power source systems are high efficiency, floor standing AC and DC
power sources that provide a precise output with low distortion. Available voltage ranges are 150 Vac,
300 Vac and 400 Vac in AC mode and 200 Vdc and 400 Vdc in DC mode. The MX30-3Pi and MX45-
3Pi can operate in either single or three-phase mode. The MX30 and MX45 is also available in just
single or three-phase mode. All other models always operate in three-phase mode.
Models with a -1 or -3 designation provide full front panel operation but do not include certain features
such as arbitrary waveform generation unless added as an option at the time of order. Models with
the Pi controller offer several additional standard features, including the RS232C, USB, LAN (option)
and IEEE-488 interfaces, arbitrary waveform generation, dual voltage ranges and additional
measurement functions.
The MX Series units are contained in a compact floor standing enclosure on casters. This allows the
units to be moved around more easily.
Read the installation instructions carefully before attempting to install and operate the MX Series
power systems.
1.2 Manual organization and format
All user documentation for California Instruments power sources is provided on CDROM in electronic
format. (Adobe Portable Document Format) The required Adobe PDF viewer is supplied on the same
CDROM. This manual may be printed for personal use if a hardcopy is desired. To request a
hardcopy from AMETEK Programmable Power, contact customer service at
[e-mail]. There will be an additional charge for printed manuals.
This manual contains sections on installation, normal use, maintenance and calibration. If the MX
system is equipped with a GPIB, RS232C, USB or LAN interface, refer to the MX Programming
manual for information on using the remote control interfaces and command syntax. The
programming manual is provided on the same CDROM as this user manual.

User Manual – Rev AY AMETEK Programmable Power
MX Series 12
1.3 Different Model Series
There are two versions of the MX Series product, Series I and Series II. This user manual covers both
MX model series with top level assembly part numbers 7003-400 (Series I) and 7003-422 (Series II).
The difference between the Series I and the Series II is the controller used. The Series II uses a
newer controller design but retains backward compatibility with the Series I products. The part number
is shown on the model / serial number tag on the back of the MX series. All Series II will have a
firmware revision of 4.0 or higher. The firmware revision is displayed briefly at power up on the LCD
display and can also be queried over the bus by using the *IDN? command.
Differences between the two model series are restricted to:
•Reduced number of measurement calibration coefficients on Series II.
•Increased measurement sampling rate on Series II.
•Maximum DC offset range in AC+DC mode is 250Vdc on Series I, 220Vdc on Series II
Where relevant, differences are highlighted throughout the user manual.

User Manual – Rev AY AMETEK Programmable Power
MX Series 13
2. Specifications
Specifications shown are valid over an ambient temperature range of 25 ±5°C and apply after a 30
minute warm-up time. Unless otherwise noted, all specifications are per phase for sine wave output
into a resistive load. For three phase configurations or mode of operation, all specifications are for
Line to Neutral (L-N) and phase angle specifications are valid under balanced load conditions only.
Note: Specifications for input and output current and power on MX180, MX225 and MX270
configurations are 4, 5 and 6 times those of MX45-3 and are not separately listed.
2.1 Electrical
2.1.1 Input
Parameter MX30 MX45 MX60 MX90 MX135
Line Voltage:
(3 phase, 3
wire + ground
(PE))
208 V
LL
±10%
230 V
LL
±10%
400 V
LL
±10%
480 V
LL
±10%
Line VA: 37 KVA 53 KVA 74 KVA 106 KVA 159 KVA
Line Current: 116 A
RMS
@
187 V
LL
105 A
RMS
@
207 V
LL
60 A
RMS
@
360 V
LL
50 A
RMS
@
432 V
LL
175 A
RMS
@
187 V
LL
157 A
RMS
@
207 V
LL
90 A
RMS
@
360 V
LL
75 A
RMS
@
432 V
LL
Each MX30
chassis
requires its
own AC
service.
Total Line
currents are
2 x MX30
Each MX45
chassis
requires its
own AC
service.
Total Line
currents are
2 x MX45
Each MX45
chassis
requires its
own AC
service.
Total Line
currents are
3 x MX45
Line
Frequency: 47-63 Hz
Efficiency: 85 % (typical) depending on line and load
Power Factor: 0.95 (typical) / 0.99 at full power.
Inrush Current: 230 A
pk
@ 208 V
LL
220A
pk
@ 230 V
LL
132A
pk
@ 400 V
LL
110A
pk
@ 480 V
LL
Each MX30
chassis
requires its
own AC
service.
Total Peak
currents are
2 x MX30
Each MX45
chassis
requires its
own AC
service.
Total Peak
currents are
2 x MX45
Each MX45
chassis
requires its
own AC
service.
Total Peak
currents are
3 x MX45
Hold-Up Time: > 10 ms
Isolation
Voltage: 2200 VAC input to output
1350 VAC input to chassis

User Manual – Rev AY AMETEK Programmable Power
MX Series 14
2.1.2 Output
Note: All specifications are for AC and DC unless otherwise indicated.
Output Parameter MX30 MX45 MX60 MX90 MX135
Modes
Std
Controller AC, DC
Pi
Controller AC, DC, AC+DC
Voltage:
Ranges (L-N):
AC Mode Low: 0 - 150 V / High: 0 - 300 V
DC Mode Low: 0 - 200 V / High: 0 - 400 V
AC+DC Mode AC: Low: 0 - 150 V / High: 0 - 300 V
DC Offset: Low Vrange: 0 - 150 V
High Vrange: 0 - 220 V (Series II) / High; 0 – 250 V (Series I).
Note: On MX units with standard controller, only one voltage range is available
unless the -R range change option is installed.
Resolution:
AC Mode 0.1 V
DC Mode 0.1 V
AC+DC Mode AC: 0.1 V
DC Offset:
Series I 0.01 V < 2.5 V
0.1 V 2.5 - 25 V
1 V > 25 V
Series II 0.01 V
Accuracy: ± 0.3 V AC mode
± 1 V DC mode
Distortion THD
1
:
(Resistive full
load)
MX units shipped before 2009
< 1 % @ 16 - 66 Hz
< 2 % @ 66 - 500 Hz
< 3 % @ > 500 Hz
MX units shipped as of 2009
< 0.5 % @ 16 - 66 Hz
< 1.00 % @ 66 - 500 Hz
< 1.50 % @ > 500 Hz
Load Regulation: 0.25 % FS @ DC - 100 Hz
0.5 % FS @ > 100 Hz
Line Regulation: 0.1% for 10% input line change
DC Offset Voltage: < 20 mV
1
The distortion specification for the MX Series is valid for pure (inductance < 12 uH) resistive load conditions and using a
30 KHz LP filter on distortion meter.

User Manual – Rev AY AMETEK Programmable Power
MX Series 15
Output Parameter MX30 MX45 MX60 MX90 MX135
Output Noise:
(20 kHz to 1 MHz) < 2 V
RMS
low V Range
< 3 V
RMS
high V Range
Output Coupling DC coupled
Except on optional -HV or -XV Voltage range output, which is AC coupled.
Power (total power for all phases, either range, at full scale voltage, maximum ambient T = 35° C)
AC Mode 30 KVA 45 KVA 60 KVA 90 KVA 135 KVA
DC Mode 20 KW 30 KW 40 KW 60 KW 90 KW
AC+DC Mode The maximum power and current in the AC+DC mode is equal to that in the
DC mode
Current
Note: Current, maximum amps indicated per phase available between 50 and 100 % of voltage
range. Maximum ambient temperate for full power operation at full-scale voltage is 35° C.
Constant Power Mode:
Operation at higher currents but constant power is possible from 80% of Voltage range
(125% of max. current) declining to 100% of maximum current at 100 % of voltage range
for short periods of time or at reduced ambient temperatures. (< 15 mins @ 30° C). See
Figure 2-3 and Figure 2-4. (Requires firmware revision 0.27 or higher.)
For MX30-3Pi model, constant power mode is supported at max ambient temperature.
AC Mode MX30-1
V Lo: 200 A
V Hi: 100 A
MX30-3, per
phase
V Lo: 66.7 A
V Hi: 33.3 A
MX45-1
V Lo: 300 A
V Hi: 150 A
MX45-3, per
phase
V Lo: 100 A
V Hi: 50 A
MX60-3, per
phase
V Lo: 133 A
V Hi: 66.7 A
MX90-3, per
phase
V Lo: 200 A
V Hi: 100 A
MX135-3, per
phase
V Lo: 300 A
V Hi: 150 A
DC Mode
AC+DC Mode MX30-1 V Lo: 100 A
V Hi: 50 A
MX30-3, per
phase
V Lo: 33.3 A
V Hi: 16.7 A
MX45-1
V Lo: 150 A
V Hi: 75 A
MX45-3, per
phase
V Lo: 50 A
V Hi: 25 A
MX60-3, per
phase
V Lo: 66.7 A
V Hi: 33.3 A
MX90-3, per
phase
V Lo: 100 A
V Hi: 50 A
MX135-3, per
phase
V Lo: 150 A
V Hi: 75 A
Note: Current derates linearly from 50% of voltage range to 20% of specified current at 5% of
voltage range
Current Limit mode Programmable, CC or CV mode
Repetitive Peak Current
Note: Maximum Peak Current shown. Value shown reflects absolute peak current protection level. This level
may not be reached under all load conditions. Depending on load conditions, peak current may max out at lower
levels due to amplifier output impedance.
Note: As of firmware revision 4.52, a repetitive peak current limit function is provided which will generate a fault
and shut off the power supply if the peak current drawn by the load exceeds the maximum level for more than 30
seconds. During this time, the amplifier will limit the peak current at a somewhat level above the maximum level but
it is not allowable to run in this mode indefinitely. This should provide sufficient time to ride through any
startup/inrush load conditions.
AC Mode MX30-1 / MX30-3Pi 1Phs /
MX45-1 / MX45-3Pi 1Phs
V Lo: 900 A
V Hi: 450 A
MX30-3 / MX30-3Pi / MX45-3
/ MX45-3Pi, per phase
MX60-3 / MX90-3, per
phase
MX135-3, per
phase

User Manual – Rev AY AMETEK Programmable Power
MX Series 16
Output Parameter MX30 MX45 MX60 MX90 MX135
V Lo: 300 A
V Hi: 150 A V Lo: 600 A V Hi: 300 A V Lo: 900 A V Hi: 450 A
Frequency
Range: Standard: 16 Hz - 819.0 Hz (for –HV option range, 45 Hz – 819.0 Hz)
-LF option: 16 Hz - 500.0 Hz
-HF option: 16 Hz – 905 Hz
Resolution: 0.01 Hz from 16.00 to 81.91 Hz
0.1 Hz from 82.0 to 819.0 Hz
Accuracy: ± 0.01 %
±0.25 % for –FC option
Phase (3 phase mode)
Range: Phase B/C relative to phase A
0.0 to 360.0°
Resolution: 0.1°
Accuracy: 16 Hz - 100 Hz: < 1.5°
100 Hz - 500 Hz: < 2°
> 500 Hz: < 4°
±0.25 % for –FC option
Ext. Sync Mode (not available with -FC option)
Input: Isolated TTL input for external frequency control. Requires 5V at 5 mA for
logic high.
Accuracy: Ext. Sync to phase A with fixed Ext. Sync Frequency input:
16 Hz - 100 Hz: < 2°
100 Hz - 500 Hz: < 3°
> 500 Hz: < 4°
±0.25 % for –FC option
Programmable Output Impedance (available on MX30-3Pi and MX45-3Pi in three phase mode only)
Range: R: 1 – 200 mOhm
L: 15 – 200 uH N/A N/A N/A
Resolution: R: 1 mOhm
L: 1 uH N/A N/A N/A
Accuracy: 10 % FS N/A N/A N/A
Note: Output specifications apply below the Current / Voltage rating lines shown in the V/I
rating chart below.

User Manual – Rev AY AMETEK Programmable Power
MX Series 17
Figure 2-1: MX30-3 Voltage / Current Rating Chart for 150/300 V AC Ranges.
Current
(RMS)
Voltage (RMS)
75 300
100
60
80
40
20
50 A
150
Low V Range
High V Range
100 A
7.5 15
Figure 2-2: MX45-3 Voltage / Current Rating Chart for 150/300 V AC Ranges – Max Rating.

User Manual – Rev AY AMETEK Programmable Power
MX Series 18
Figure 2-3: Voltage / Current Rating Chart for 150/300 V AC Ranges – Derated.

User Manual – Rev AY AMETEK Programmable Power
MX Series 19
Figure 2-4: MX30-3 Voltage / Current Rating Chart for 200/400 V DC Ranges
Figure 2-5: MX45-3 Voltage / Current Rating Chart for 200/400 V DC Ranges – Max. Rating
Current
(DC)
Voltage (DC)
100 400
50
30
40
20
10
25 A
200
Low V Range
High V Range
50 A
20 40

User Manual – Rev AY AMETEK Programmable Power
MX Series 20
2.1.3 AC Measurements
Measurement specifications apply to MX30-3 / MX30-3Pi / MX45-3 or MX45-3Pi in three-phase mode.
See notes for other models and configurations.
Parameter Range Accuracy (±) Resolution
Frequency 16.00 - 820.0 Hz 0.01% + 0.01 Hz 0.01 to 81.91 Hz
0.1 to 500 Hz
RMS Voltage 0 - 400 Volts 0.05V + 0.02%, <100 Hz
0.1V + 0.02%, 100-820 Hz 0.01 Volt
RMS Current 0 - 150 Amps 0.15A + 0.02%, <100 Hz
0.3A + 0.02%, 100-820 Hz 0.01 Amp
Peak Current 0 - 400 Amps 0.15A + 0.02%, <100 Hz
0.3A + 0.02%, 100-820 Hz 0.01 Amp
VA Power 0 - 15 KVA 30 VA + 0.1%, <100 Hz
60 VA + 0.1%, 100-820 Hz 10 VA
Real Power 0 - 15 KW 30 W + 0.1%, <100 Hz
60 W + 0.1%, 100-820 Hz 10 W
Power Factor
(>0.2kVA) 0.00 - 1.00 0.01, <100 Hz 0.02, 100-820 Hz 0.01
Note: Accuracy specifications are valid above 100 counts. For current and power measurements,
specifications apply from 2% to 100% of measurement range. Current and Power range and accuracy
specifications are times three for MX45-1, MX60, MX90 and MX135 or MX30-3Pi / MX45-3Pi in single-
phase mode.
Note: Power factor accuracy applies for PF > 0.5 and VA > 50 % of max.
Current
(DC)
Voltage (DC)
60
50
40
30
20
10
0
20 40 100 150 200 300 400
62.5 A
31 A
25 A
Full
Power
Full
Power
Figure 2-6: Voltage / Current Rating Chart for 200/400 V DC Ranges – Derated
