CAMERA LINK VT Series User manual

VT Camera Link series
Page 2 of 88 VW40-161-001
Revision History
Version
Date
Description
1.0
2016-03-04
First Release
1.1
2017-05-10
Added the following models:
VT-3K7C-E100
VT-3K7C-H100
VT-4K5C-E100
VT-4K5C-H100
VT-6K3.5C-E100
VT-6K3.5C-H100
1.2
2017-09-07
Added the STROBE tab
Updated camera mechanical dimensions (Added a connector for
Strobe Controller)
Added the Trigger Statistics feature
Added the Lookup Table feature
1.3
2018-05-31
Added the supported Pixel Data Format values depending on the Tap
setting

VT Camera Link series
Page 3 of 88 VW40-161-001
Contents
1Precautions .......................................................................................................................6
2Warranty ..........................................................................................................................8
3Compliance & Certifications............................................................................................8
3.1 FCC Compliance .........................................................................................................................8
3.2 CE: DoC.......................................................................................................................................8
3.3 KC................................................................................................................................................8
4Package Components ......................................................................................................9
5Product Specifications...................................................................................................10
5.1 Overview....................................................................................................................................10
5.2 Specifications.............................................................................................................................11
5.3 Camera Block Diagram..............................................................................................................14
5.4 Spectral Response ....................................................................................................................15
5.5 Mechanical Specification...........................................................................................................16
5.5.1 Camera Mounting and Heat Dissipation..........................................................................................17
6Connecting the Camera..................................................................................................18
6.1 Precaution to Center the Imaging Sensor..................................................................................18
6.2 Controlling the Camera..............................................................................................................18
7Camera Interface.............................................................................................................19
7.1 General Description...................................................................................................................19
7.2 Camera Link Connector.............................................................................................................19
7.3 Power Input Receptacle.............................................................................................................23
7.4 Control I/O Receptacle ..............................................................................................................24
7.5 Trigger / Direction Input Circuit..................................................................................................25
7.6 Strobe Output Circuit.................................................................................................................25
8Acquisition Control.........................................................................................................26
8.1 Line Start Trigger.......................................................................................................................26
8.1.1 Trigger Mode ...................................................................................................................................26
8.1.2 Using an External/CC1 Trigger Signal.............................................................................................29
8.1.3 Rescaler Mode.................................................................................................................................30
8.1.4 Trigger Statistics..............................................................................................................................31
8.2 Maximum Allowed Line Rate .....................................................................................................32

VT Camera Link series
Page 4 of 88 VW40-161-001
9Camera Features.............................................................................................................33
9.1 Operation Mode.........................................................................................................................33
9.2 TDI Stages.................................................................................................................................34
9.3 Direction.....................................................................................................................................36
9.4 Region of Interest ......................................................................................................................37
9.4.1 Setting the ROI................................................................................................................................37
9.5 Binning.......................................................................................................................................39
9.6 Data Bit......................................................................................................................................40
9.7 Gain and Black Level.................................................................................................................41
9.8 LUT............................................................................................................................................42
9.9 Dark Signal Non-uniformity Correction......................................................................................44
9.9.1 Generating and Saving User DSNU Correction Values ..................................................................45
9.10 Photo Response Non-uniformity Correction..........................................................................47
9.10.1 Generating and Saving User PRNU Correction Values ..................................................................48
9.11 Reverse X .............................................................................................................................49
9.12 Camera Link Output..............................................................................................................50
9.13 Strobe Mode..........................................................................................................................51
9.14 Temperature Monitor.............................................................................................................52
9.15 Status LED............................................................................................................................52
9.16 Test Image.............................................................................................................................53
9.17 Pre-emphasis (M72 / M95 based VT Series Only)................................................................55
9.18 Camera Link Pixel Clock (M42 based VT Series Only).........................................................55
9.19 Field Upgrade........................................................................................................................55
10 Camera Configuration....................................................................................................56
10.1 Setting Commands................................................................................................................56
10.2 User Set Control....................................................................................................................58
10.2.1 Factory Default Setting Values........................................................................................................59
10.3 Command List.......................................................................................................................60

VT Camera Link series
Page 5 of 88 VW40-161-001
11 Configurator GUI.............................................................................................................66
11.1 Camera Scan........................................................................................................................66
11.2 Menu.....................................................................................................................................67
11.2.1 File...................................................................................................................................................67
11.2.2 Start-Up ...........................................................................................................................................68
11.2.3 Tool..................................................................................................................................................69
11.2.4 About ...............................................................................................................................................70
11.3 Tab ........................................................................................................................................71
11.3.1 VIEW Tab.........................................................................................................................................71
11.3.2 MODE/EXP Tab...............................................................................................................................72
11.3.3 VIDEO Tab.......................................................................................................................................73
11.3.4 STROBE Tab...................................................................................................................................74
11.3.5 LUT Tab ...........................................................................................................................................75
12 Troubleshooting..............................................................................................................76
Appendix A Field Upgrade.................................................................................................77
A.1 MCU...........................................................................................................................................77
A.2 FPGA.........................................................................................................................................80
Appendix B LUT Download ...............................................................................................81
B.1 Gamma Graph Download..........................................................................................................81
B.2 CSV File Download....................................................................................................................83
Appendix C Correction Control.........................................................................................85
C.1 Adjusting and Saving Additional DSNU Correction Value..........................................................86
C.2 Adjusting and Saving Additional PRNU Correction Value..........................................................87

VT Camera Link series
Page 6 of 88 VW40-161-001
1 Precautions
General
Do not drop, disassemble, repair or alter the device. Doing so may damage the camera
electronics and cause an electric shock.
Do not let children touch the device without supervision.
Stop using the device and contact the nearest dealer or manufacturer for technical
assistance if liquid such as water, drinks or chemicals gets into the device.
Do not touch the device with wet hands. Doing so may cause an electric shock.
Make sure that the temperature of the camera does not exceed the temperature range
specified in 5.2 Specifications. Otherwise the device may be damaged by extreme
temperatures.
Installation and Maintenance
Do not install in dusty or dirty areas –or near an air conditioner or heater to reduce the risk
of damage to the device.
Avoid installing and operating in an extreme environment where vibration, heat, humidity,
dust, strong magnetic fields, explosive/corrosive mists or gases are present.
Do not apply excessive vibration and shock to the device. This may damage the device.
Avoid direct exposure to a high intensity light source. This may damage the imaging
sensor.
Do not install the device under unstable lighting conditions. Severe lighting change will
affect the quality of the image produced by the device.
Do not use solvents or thinners to clean the surface of the device. This can damage the
surface finish.
Power Supply
Applying incorrect power can damage the camera. If the voltage applied to the camera is
greater or less than the camera’s nominal voltage, the camera may be damaged or operate
erratically. Please refer to 5.2 Specifications for the camera’s nominal voltage.
※Vieworks Co., Ltd. does NOT provide power supplies with the devices.
Make sure the power is turned off before connecting the power cord to the camera.
Otherwise, damage to the camera may result.

VT Camera Link series
Page 7 of 88 VW40-161-001
Cleaning the Sensor Surface
Avoid cleaning the surface of the camera’s sensor if possible. If you have dust or foreign matter on the sensor
surface, use a soft line free cotton bud dampened with a small quantity of high quality lens cleaner. Because
electrostatic discharge (ESD) can damage the sensor, you must use a cloth (e.g. cotton) that will not generate
static during cleaning.
Avoid dust or foreign matter on the sensor surface.
The camera is shipped with a protective plastic seal on the camera front. To prevent collecting
dust or foreign matter on the camera sensor, make sure that you always put the protective seal
in place when there is no lens mounted on the camera. In addition, make sure to always point
the camera downward when there is no protective seal on the camera front or no lens mounted.
Procedures for Cleaning the Sensor
If you have dust or foreign matter on the sensor surface, follow the procedures below to wipe off.
1. Remove a contaminant by using an ionizing air gun.
If this step does not remove the contaminant, proceed to the next step.
2. Clean the contaminant of the sensor using one drop of lens cleaner on a non-fluffy cotton bud.
3. Wipe the cotton bud gently in only one direction (either left to right or right to left).Avoid wiping back and
forth with the same cotton bud in order to ensure that the contaminants are removed and not simply
transferred to a new location on the sensor surface.
4. Mount a lens, set the lens at a smaller aperture (e.g. F8), and then acquire images under bright lighting
conditions. Check the images on the monitor for dark spots or stripes caused by the contaminant. Repeat
the steps above until there is no contaminant present.
If sensor is damaged due to electrostatic discharge or the sensor surface is scratched during
cleaning, the warranty is void.

VT Camera Link series
Page 8 of 88 VW40-161-001
2 Warranty
Do not open the housing of the camera. The warranty becomes void if the housing is opened.
For information about the warranty, please contact your local dealer or factory representative.
3 Compliance & Certifications
3.1 FCC Compliance
This equipment has been tested and found to comply with the limits for a Class Adigital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expenses.
3.2 CE: DoC
EMC Directive 2014/30/EU
EN 55032:2012 (ClassA), EN 55024:2010
Class A
3.3 KC
KCC Statement
Type
Description
Class A
(Broadcasting Communication
Device for Office Use)
This device obtained EMC registration for office use (Class A), and may be
used in places other than home. Sellers and/or users need to take note of
this.

VT Camera Link series
Page 9 of 88 VW40-161-001
4 Package Components
Package Components
VT-4K7C / VT-4K14C / VT-9K7C / VT-12K5C / VT-18K3.5C Camera with M72 0.75 mount
VT-3K7C / VT-4K5C / VT-6K3.5C Camera with M42 mount

VT Camera Link series
Page 10 of 88 VW40-161-001
5 Product Specifications
5.1 Overview
VT series, Time Delay & Integration (TDI) line scan cameras, provides faster line rates and higher sensitivity
than existing line scan cameras. Hybrid imaging sensor technology based on a combination of CCD and CMOS
circuits allows image captures with up to 128 higher sensitivity using the M72 mount based VT-9K7C camera.
Even superior resolution and sensitivity, up to 256 greater sensitivity can be achieved using the VT-18K3.5C
camera. Its robust Camera Link interface supports transmitting image data at up to 125 ㎑using the VT-4K7C
and VT-4K14C cameras. The VT-3K7C, VT-4K5C and VT-6K3.5C cameras which are supporting the M42 mount
feature up to 100 ㎑with 256higher sensitivity. Featured with high speed and high resolution, VT series is
ideal for demanding applications such as flat panel display inspection, wafer inspection, printed circuit board
inspection, and high-performance document scanning.
Main Features
Hybrid Line Scan
Max. 17824 256 Pixel Resolution
Bidirectional Operations with up to 256 TDI Stages
Exposure Control
Anti-blooming
Trigger Rescaler and Strobe Output Control
Camera Link Full Interface up to 120
Advanced PRNU and DSNU Correction
Area Scan Mode for CameraAlignment
Applications
Flat Panel Display Inspection
Printed Circuit Board Inspection
Wafer Inspection
High Performance Document Scanning

VT Camera Link series
Page 11 of 88 VW40-161-001
5.2 Specifications
Technical specifications for VT Camera Link series are as follows:
Specification
VT-4K7C-H120
VT-4K14C-H120
VT-9K7C-H80
Active Image (H ×V)
4096 ×128
4096 ×64
8912 ×128
Sensor Type
Hybrid TDI Line Scan
Pixel Size
7.0 ㎛×7.0 ㎛
14.0 ㎛×14.0 ㎛
7.0 ㎛×7.0 ㎛
Interface
Camera Link (Base/Medium/Full)
Pixel Data Format
8 bit (2/4/8/10 Tap) / 10 bit (2/4 Tap) / 12 bit (2/4 Tap)
TDI Stage
32 / 64 / 96 / 128
16 / 32 / 48 / 64
32 / 64 / 96 / 128
TDI Direction
External Control Port or Programmable
Trigger Synchronization
Free-Run, External Trigger Signal, Camera Link CC1
Programmable Line Rate and Trigger Polarity
Max. Line Rate
125 ㎑
94 ㎑
Min. Line Rate
1 ㎑
Camera Link Pixel Clock
85 ㎒
Video Output
2, 4, 8 or 10 Tap
Throughput
0.51 Gpix/s
0.83 Gpix/s
Gamma Correction
User Defined LUT (Look Up Table)
Black Level
Adjustable (-255 ~ 255 at 8 bits)
Gain Control
Analog Gain: 1, 2, 3, 4 / Digital Gain: 1.0 ~ 8.0
External Trigger
External, 3.3 V –5.0 V
Power
Adapter
10 ~ 30 V DC
Dissipation
Typ. 12 W
Environmental
Ambient Operating: 0℃~ 40℃(Housing: 10℃~ 50℃), Storage: -40℃~ 70℃
Mechanical
90 ㎜×90 ㎜×38 ㎜, 500 g
Configuration Software
Configurator
Optical Interface
Lens Mount
M72 ×0.75
Sensor to Camera Front
10.10 ㎜(Optical Distance)
Sensor Alignment
Flatness
x
y
z
±25 ㎛
±0.15 ㎜
±0.15 ㎜
±0.1 ㎜
Table 5.1 Specifications of M72 mount based VT Camera Link Series (VT-4K7C/VT-4K14C/VT-9K7C)

VT Camera Link series
Page 12 of 88 VW40-161-001
Specification
VT-12K5C-H60
VT-18K3.5C-H40
Active Image (H ×V)
12480 ×256
17824 ×256
Sensor Type
Hybrid TDI Line Scan
Pixel Size
5.0 ㎛×5.0 ㎛
3.5 ㎛×3.5 ㎛
Interface
Camera Link (Base/Medium/Full)
Pixel Data Format
8 bit (2/4/8/10 Tap) / 10 bit (2/4 Tap) / 12 bit (2/4 Tap)
TDI Stage
64 / 128 / 192 / 256
TDI Direction
External Control Port or Programmable
Trigger Synchronization
Free-Run, External Trigger Signal, Camera Link CC1
Programmable Line Rate and Trigger Polarity
Max. Line Rate
67 ㎑
47 ㎑
Min. Line Rate
1 ㎑
Camera Link Pixel Clock
85 ㎒
Video Output
2, 4, 8 or 10 Tap
Throughput
0.83 Gpix/s
Gamma Correction
User Defined LUT (Look Up Table)
Black Level
Adjustable (-255 ~ 255 at 8 bits)
Gain Control
Analog Gain: 1, 2, 3, 4 / Digital Gain: 1.0 ~ 8.0
External Trigger
External, 3.3 V –5.0 V
Power
Adapter
10 ~ 30 V DC
Dissipation
Typ. 12 W
Environmental
Ambient Operating: 0℃~ 40℃(Housing: 10℃~ 50℃), Storage: -40℃~ 70℃
Mechanical
90 ㎜×90 ㎜×38 ㎜, 500 g
Configuration Software
Configurator
Optical Interface
Lens Mount
M72 ×0.75
Sensor to Camera Front
10.10 ㎜(Optical Distance)
Sensor Alignment
Flatness
x
y
z
25
0.15
0.15
0.1
Table 5.2 Specifications of M72 mount based VT Camera Link Series (VT-12K5C/VT-18K3.5C)

VT Camera Link series
Page 13 of 88 VW40-161-001
Specification
VT-3K7C-
E100
VT-3K7C-
H100
VT-4K5C-
E100
VT-4K5C-
H100
VT-6K3.5C-
E100
VT-6K3.5C-
H100
Active Image (H ×V)
3200×32
3200×128
4640×64
4640×256
6560×64
6560×256
Sensor Type
Hybrid TDI Line Scan
Pixel Size
7.0 ㎛×7.0 ㎛
5.0 ㎛×5.0 ㎛
3.5 ㎛×3.5 ㎛
Interface
Camera Link (Base/Medium/Full)
Pixel Data Format
8 bit (2/4/8/10 Tap) / 10 bit (2/4 Tap) / 12 bit (2/4 Tap)
TDI Stage
32
32/64/96/
128
64
64/128/192
/256
64
64/128/192
/256
TDI Direction
External Control Port or Programmable
Trigger Synchronization
Free-Run, External Trigger Signal, Camera Link CC1
Programmable Line Rate and Trigger Polarity
Max. Line Rate
100 ㎑
100 ㎑
100 ㎑
Min. Line Rate
1 ㎑
Camera Link Pixel Clock
40 / 60 / 80 / 85 ㎒
Video Output
2, 4, 8 or 10 Tap
Throughput
0.32 Gpix/s
0.46 Gpix/s
0.66 Gpix/s
Gamma Correction
User Defined LUT (Look Up Table)
Black Level
Adjustable (-255 ~ 255 at 8 bits)
Gain Control
Analog Gain: 1, 2, 3, 4 / Digital Gain: 1.0 ~ 8.0
External Trigger
External, 3.3 V –5.0 V
Power
Adapter
10 ~ 30 V DC
Dissipation
Typ. 3.5 W
Typ. 4.0 W
Typ. 4.5 W
Environmental
Operating: 0℃~ 50℃, Storage: -40℃~ 70℃
Mechanical
60 ㎜×60 ㎜×36 ㎜, 223 g
Configuration Software
Configurator
Optical Interface
Lens Mount
M42
Sensor to Camera Front
10.10 ㎜(Optical Distance)
Sensor Alignment
Flatness
x
y
z
±25 ㎛
±0.15 ㎜
±0.15 ㎜
±0.1 ㎜
Table 5.3 Specifications of M42 mount based VT Camera Link Series (VT-3K7C/VT-4K5C/VT-6K3.5C)

VT Camera Link series
Page 14 of 88 VW40-161-001
5.3 Camera Block Diagram
VT series consists of three printed circuit boards (PCB), and its block diagram is shown below.
Figure 5.1 Camera Block Diagram

VT Camera Link series
Page 15 of 88 VW40-161-001
5.4 Spectral Response
The following graph shows the spectral response for VT series.
Figure 5.2 Quantum Efficiency (Monochrome)

VT Camera Link series
Page 16 of 88 VW40-161-001
5.5 Mechanical Specification
The camera dimensions in millimeters are shown in the following figure.
Figure 5.3 M72 mount based VT CL Series Mechanical Dimension

VT Camera Link series
Page 17 of 88 VW40-161-001
Figure 5.4 M42 mount based VT CL Series Mechanical Dimension
5.5.1 Camera Mounting and Heat Dissipation
You must mount the camera on a heat dissipation structure to maintain the temperature of the camera housing
at 50℃or less. Given the low power consumption of the VT series camera, its housing temperature during
operation will generally stay within the specified limits. However, overheating can occur if heat dissipation is
restricted or if the camera is mounted on a severe environment. It is recommended to follow the general
guidelines below when you mount the camera.
In all cases, you should monitor the temperature of the camera housing and make sure that the temperature
does not exceed 40℃. You can monitor the internal temperature of the camera by using the ‘gct’ command.
If your camera is mounted on a metal component in your system, this may provide sufficient heat
dissipation.

VT Camera Link series
Page 18 of 88 VW40-161-001
6 Connecting the Camera
The following instructions assume that you have installed a Camera Link frame grabber in your computer
including related software. For more information, refer to your Camera Link frame grabber user manual.
To connect the camera to your computer, follows the steps below.
1. Make sure that the power supply is not connected to the camera and your computer is turned off.
2. Plug one end of a Camera Link cable into the Camera Link1 connector on the camera and the other end of
the Camera Link cable into the Base connector on the Camera Link frame grabber.
3. Plug one end of a Camera Link cable into the Camera Link2 connector on the camera and the other end of
the Camera Link cable into the Medium/Full connector on the Camera Link frame grabber.
4. Connect the plug of the power adapter to the 6-pin power input receptacle on the camera.
5. Plug the power adapter into a working electrical outlet.
6. Verify all the cable connections are secure.
Precautions for using Camera Link Medium/Full Configuration
VT CL cameras support Camera Link Base, Medium and Full configurations. To operate the
camera in the medium or full Camera Link configuration, you must connect the camera to the
Camera Link frame grabber using two Camera Link cables. At this time, you must connect both
Camera Link1 (Base) and Camera Link2 (Medium/Full) connectors on the camera to their
respective connectors on the Camera Link frame grabber.
6.1 Precaution to Center the Imaging Sensor
Users do not need to center the imaging sensor as it is adjusted as factory default settings.
When you need to adjust the center of imaging sensor, please contact your local dealer or factory
representative for technical assistance.
6.2 Controlling the Camera
You can control the camera by using Configurator.
You can download the latest Configurator at http://www.vieworks.com.
Please refer to your Camera Link frame grabber user manual.

VT Camera Link series
Page 19 of 88 VW40-161-001
7 Camera Interface
7.1 General Description
As shown in the figure below, four types of connectors and a status indicator LED are located on the back of the
camera and have the functions as follows:
①Status LED: displays power status and operation mode.
②26 pin Camera Link1 Connector Base): controls video data transmission and the camera.
③26 pin Camera Link2 Connector (Medium/Full): transmits video data.
④6 pin Power Input Receptacle: supplies power to the camera.
⑤4 pin Control I/O Receptacle: provides access to the camera’s I/O lines.
Figure 7.1 M72 mount (left) and M42 mount (right) based VT Camera Link Series Back Panel
7.2 Camera Link Connector
CAMERA LINK 1
1
13
26 14
Figure 7.2 Camera Link Connector

VT Camera Link series
Page 20 of 88 VW40-161-001
Camera Link connectors comply with Camera Link Standard and the following list shows the pin assignments of
the connector.
PAIR List
Pin
Signal Name
Type
Description
PAIR 0
1
Ground
Ground
Cable Shield
14
Ground
Ground
Cable Shield
PAIR 1
2
-X0
LVDS - Out
Camera Link Transmitter
15
+X0
LVDS - Out
Camera Link Transmitter
PAIR 2
3
-X1
LVDS - Out
Camera Link Transmitter
16
+X1
LVDS - Out
Camera Link Transmitter
PAIR 3
4
-X2
LVDS - Out
Camera Link Transmitter
17
+X2
LVDS - Out
Camera Link Transmitter
PAIR 4
5
-XCLK
LVDS - Out
Camera Link Transmitter
18
-XCLK
LVDS - Out
Camera Link Transmitter
PAIR 5
6
-X3
LVDS - Out
Camera Link Transmitter
19
+X3
LVDS - Out
Camera Link Transmitter
PAIR 6
7
+ SerTC
LVDS - In
Serial Data Receiver
20
- SerTC
LVDS - In
Serial Data Receiver
PAIR 7
8
- SerTFG
LVDS - Out
Serial Data Transmitter
21
+ SerTFG
LVDS - Out
Serial Data Transmitter
PAIR 8
9
- CC 1
LVDS - In
Software External Trigger
22
+ CC 1
LVDS - In
Software External Trigger
PAIR 9
10
N/C
N/C
N/C
23
N/C
N/C
N/C
PAIR 10
11
N/C
N/C
N/C
24
N/C
N/C
N/C
PAIR 11
12
N/C
N/C
N/C
25
N/C
N/C
N/C
PAIR 12
13
Ground
Ground
Cable Shield
26
Ground
Ground
Cable Shield
Table 7.1 Pin Assignments for Camera Link1 Connector
