TTOOLLIIGGHHTTTTHHEEHHEEAATTEERR
1) Switch on electrical supply.
2) (fig. 1) With all hot taps closed, light the heater by turning the gas control knob to
the position marked « ». If the pilot, which can be seen through the window,
does not light, leave the knob in the « » position (horizontally) for a few
moments. Return the knob to the vertical «I» position and repeat.
3) When the pilot is alight, wait 10 seconds then turn the gas control knob slowly to
the full gas position « » (fig. 2).
The heater is now ready for use, and will light when a hot tap is opened.
If the pilot goes out, repeat operations 1 and 2. When the control knob is turned
back to the «off» position, it may not be possible to turn it immediately to the pilot
position - if so, wait 30 seconds for the safety device to reset itself.
TTOOTTUURRNNOOFFFFTTHHEEPPIILLOOTT
If the heater is not required to be used for some time, the pilot can be turned off.
Turn the control knob clockwise to the « » position as shown in fig. 3.
Switch off at electrical supply.
UUSSIINNGGTTHHEEHHEEAATTEERR
Light the pilot as previously describeb and turn the gas control knob to the position
shown in fig. 2. Turn on a hot water tap.
Adjust the lower control knob on the water heater to the required temperature.
Turning it anti-clockwise to the position shown in fig. 4 will give a lower water tempe-
rature.
FFRROOSSTTPPRREECCAAUUTTIIOONNSS
If there is any risk of freezing, the heater should be drained.
1) Turn off the pilot and electrical supply.
2) Turn off the cold water supply to the heater with the tap fitted below (A) (fig. 5).
3) Open an adjacet hot water tap.
4) Remove the drain plug (B) (fig. 5), and drain the water into a basin.
To restart the heater replace the drain plug and open the cold water supply tap.
Check that water flows through the heater before lighting the pilot.
CCLLEEAANNIINNGG
The surface of the heater may be cleaned using soap, water and a soft cloth or a
non-abrasive cleaner.
SSEERRVVIICCEE
To ensure that the heater continues to work efficiently and has a long life, it is impor-
tant that it is serviced annually. Ask your installer or BRISTISH GAS for details of a
regular service scheme, or your local Chaffoteaux & Maury service centre.
This water heater has been tested and approved by British Gas to the relevant British
Standards.
This water heater is suitable for use with showers and automatic washing machines.
For further information, ask your installer or contact MTS (GB) Limited.
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
