Candy GO W 485 D ALISE Installation instructions

User instructions
EN GO W 485 D

2
EN
OUR COMPLIMENTS
With the purchase of this Candy household appliance, you
have shown that you will not accept compromises: you want
only the best.
Candy is happy to present their new washing machine, the
result of years of research and market experience through
direct contact with Consumers.You have chosen the quality,
durability and high performance that this washing machine
offers.
Candy is also able to offer a vast range of other household
appliances: washing machines, dishwashers, washer-dryers,
cookers, microwave ovens. Traditional ovens and hobs,
refrigerators and freezers.
Ask your local retailer for the complete catalogue of Candy
products.
Please read this booklet carefully as it provides important
guide lines for safe installation, use and maintenance and
some useful advise for best results when using your washing
machine.
Keep this booklet in a safe place for further consultation.
When contacting Candy
or a Customer Services Centre always refer to the Model,
No., and G number (if applicable of the appliance see
panel).

CHAPTER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
3
EN
INDEX
Introduction
General points on delivery
Guarantee
Safety Measures
Technical Data
Setting up and Installation
Control Description
Table of Programmes
Selection
Detergent drawer
The Product
Washing
Drying cycle
Automatic washing/Drying cycle
Cleaning and routine maintenance
Faults Search

EN
CHAPTER 2
GUARANTEE
The appliance is supplied with a guarantee certificate
which allows free use of the Technical Assistance Service.
4
EN
CHAPTER 1
GENERAL POINTS ON DELIVERY
On delivery, check that the following are included with the
machine:
A) INSTRUCTION MANUAL
B) CUSTOMER SERVICE ADDRESSES
C) GUARANTEE CERTIFICATES
D) CAPS
E) BEND FOR OUTLET TUBE
KEEP THEM IN A SAFE PLACE
Check that the machine has not incurred damage during
transport. If this is the case, contact your nearest Candy
Centre.
E
AB
C
D

5
EN
CHAPTER 3
SAFETY MEASURES
IMPORTANT:
FOR ALL CLEANING AND MAINTENANCE WORK
●Remove the plug
●Turn off the water inlet tap.
●All Candy appliances are earthed. Ensure that the main
electricity circuit is earthed. Contact a qualified electrician
if this is not the case.
Appliance complies with European Directives
73/23/EEC and 89/336/EEC, replaced by 2006/95/EC and
2004/108/EC, and subsequent amendments.
●Do not touch the appliance with wet or damp hands or
feet.
●Do not use the appliance when bare-footed.
●Extreme care should be taken if extension leads are used
in bathrooms or shower rooms. Avoid this where possible.
WARNING:
DURING THE WASHING CYCLE, THE WATER CAN
REACH A TEMPERATURE OF 90°C.
●Before opening the washing machine door, ensure that
there is no water in the drum.

6
EN
● Do not use adaptors or multiple plugs.
● This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
● Do not pull the mains lead or the appliance itself to
remove the plug from the socket.
● Do not leave the appliance exposed to atmospheric
agents (rain, sun etc.)
● In the case of removal, never lift the appliance by the
knobs or detersive drawer.
● During transportation
do not lean the door against the trolley.
Important!
When the appliance location is on carpet floors, attention
must be paid so as to ensure that there is no obstruction to
the bottom vents.
● Lift the appliance in pairs as illustrated in the diagram.
● In the case of failure
and/or incorrect operation,turn the washing machine off,
close the water inlet tap and do not tamper with the
appliance. Contact a Candy Technical Assistance Centre for
any repairs and ask for original Candy spare parts.
Avoidance of these norms may compromise the safety of the
appliance.
● Should the supply cord (mains cable) be demaged, this is
to be replaced by a specific cable available from the after
sales service centre.

7
EN
CHAPTER 4
MAXIMUM WASH
LOAD DRY
NORMAL WATER LEVEL
POWER INPUT
ENERGY CONSUMPTION
(PROG. 90°C)
POWER CURRENT FUSE
AMP
SPIN
r.p.m.
WATER PRESSURE
SUPPLY VOLTAGE
TECHNICAL DATA
kg 5
6÷15
2150
1,8
13
min. 0,05
max. 0,8
220 - 240
l
W
kWh
A
SSEEEERRAATTIINNGGPPLLAATTEE
MPa
V
8
Washing Drying
54 cm
60 cm
85
cm

8
EN
CHAPTER 5
SETTING UP INSTALLATION
Move the machine near its permanent position without the
packaging base.
Carefully cut the securing strap that holds the main cord and
the drain hose.
Remove the 3 fixing screws marked (A) and remove the 3
spacers marked (B)
Remove the screw (C).
A spacer will fall inside the machine.
By tilting the machine, remove the above mentioned spacer.
Cover the 4 holes using the caps provided in the instruction
booklet pack.
WARNING:
DO NOT LEAVE THE PACKAGING IN THE REACH OF
CHILDREN AS IT IS A POTENTIAL SOURCE OF DANGER.

9
min 50 cm
max 85 cm
+2,6 mt max
max 100 cm
min 4 cm
EN
Fix the sheet of corrugated material on the bottom as shown
in picture.
Connect the fill hose
to the tap.
The appliance must be connected to the water mains using
new hose-sets.The old hose-sets should not be reused.
IMPORTANT:
DO NOT TURN THE TAP ON AT THIS TIME.
Position the washing machine next to the wall. Hook the
outlet tube to the edge of the bath tub, paying attention
that there are no bends or contractions along the tube.
It is better to connect the discharge hose to a fixed outlet of
a diameter greater than that of the outlet tube and at a
height of min. 50 cm. If is necessary to use the plastic sleeve
supplied.
The appliance must not be installed behind a lockable door,
a sliding door or a door with a hinge on the opposite side to
that of the washer dryer.

10
EN
Use the 4 feet to level the machine with the floor:
a) Turn the nut clockwise to release the screw adjuster of
the foot.
b) Rotate foot to raise or lower it until it stands firmly on the
ground.
c) Lock the foot in position by turning the nut anti-clockwise
until it comes up against the bottom of the machine.
Ensure that the knob is on the “OFF” position and the load
door is closed
Insert the plug.
ATTENTION:
should it be necessary to replace the supply cord, connect
the wire in accordance with the following colours/codes:
BLUE - NEUTRAL (N)
BROWN - LIVE (L)
YELLOW-GREEN - EARTH ( )
After installation, the appliance must be positioned so that
the plug is accessible.
A
B
C
