Cannon sampford IXL User manual
THERMOSTAT
USER MANUAL
Phone: 1300 727 427
Faxsimile: 1300 727 425
A/M OK
UP
TP
DOWN
PWR
ROOM
TIME
Cannon
F3197
ISSUE 2 JAN 2009.
No user serviceable components are within the heater thermostat.
contact SampfordIXL for any required maintenance.
Ph: 1300 727 421 Fax: 1300 727 425
Page 18.
NOTES.
For Service
CONTENTS
Quick start guide. 2
Safety warnings 3
Features 4
Thermostat LCD 5
Functions 6 -7
Button functions
Programming button functions
Initial setup 8
On / Off
Time and day of the week
Manual mode 9
Automatic mode 9
Programming 11 -10
Programming screen displays 12
Program mode 13
Factory default settings
Your settings
Settings 14
Change between C° and F°
Restore factory default settings
Teaching the thermostat ID code
to the control unit
Frequently asked questions 15
Quick reference table 16
Back Up Switch 17
Service 18
Battery type: 2 X AA batteries
Battery life : approximately 12 months
Transmission frequency: 433.92 Mhz
Dimensions: 140MM x 80mm x 20mm
Page 1.
A/M OK
UP
TP
DOWN
PWR
ROOM
TIME
Cannon
Fitzroy Inbuilt
Model shown.
Red LED flashes twice approximately every
3 seconds to indicate that power is available.
When heater is operating in Back Up mode
the LED is on continuously.
In the rare instance of the Hand Held Unit failing to operate, the heater can
be operated manually by pressing the Back Up Switch button (once).
The switch is located where shown above.
For this Back Up Switch to operate correctly the batteries must be removed
from the Hand Held Unit.
In this Back Up mode, the heater will start up on Low Fire and Low Speed
Fan and then after approximately 3 minutes it will increase to High Fire and
Medium Speed Fan. (Speed 2)
Turn off the heater, press the Back Up Switch (once), the fire will extinguish
and then reduce to Low Speed and operate for approximately 3 minutes to
assist with cooling down the heater.
In this mode there is no temperature control operating.
Back Up Switch.
Page 17.
QUICK START GUIDE
This Remote Thermostat is a room thermostat and to function correctly it
should be located in the same room as the heater within personal
comfort zone.
The thermostat is factory set with the default settings shown below and
will operate at settings indicated. If you wish to change these times or
temperatures see the Programming section later in manual.
Automatic Factory default settings
Factory default settings
Time Period Start Time Heat Temperature (°C)
Wake up. 6.00 am 20 °C
Away. 8.30 am 7 °C
Coming home. 5.00 pm 21 °C
Sleep. 10.30 pm 7 °C
The room will be maintained at set temperature during set period.
21°C
7°C
20°C
6.00AM 6.00AM
8.30AM 5.00PM 10.30PM
At any time during the automatic program period, the temperature can be
increased or decreased by pressing the “UP” or “DOWN” buttons.
To start heater.
Select “PWR” and “OK” buttons and press them together (then release).
Select Auto or Manual by pressing “A/M” button (then release).
The heater will only operate if the actual room temperature is lower
than the required temperature.
Manual Mode:
Press “A/M” Button to select “Manual” mode.
The required temperature can be selected by using ‘UP ’ or ‘DOWN ’
buttons.
Room temperature is shown at top of screen.
Selected temperature shown at mid screen.
Automatic Mode
Press “A/M” Button to select “Auto” mode.
Set current time and date. (See setting time and date later in manual.)
Page 2.
Features of your thermostat model heater:
If the controller is turned on and there is a requirement for heating, the
heater will start up on Low Fire and Low Fan and operate for approximately
3 minutes.
The heater will then go to your preset desired temperature functions on
the remote controller
Once the selected room temperature has been reached, the heater will
go to Low Fire and Low Fan.
The full description on the operation of the heater is described in more
detail in the following section.
SAFETY WARNINGS
Do not place clothing or other flammable material on or near the heater.
Keep curtains, clothing, furniture and other flammable materials at least
900mm from front and sides of the heater.
At the owners discretion curtain clearances can be less than 900mm as
long as they are restrained from the front, top and sides of the heater.
The manufacturer takes no responsibility if curtain clearance is less than
900mm and not restrained.
For full safety warning information, Refer to Heater User Instructions.
Page 3.
CAUTION: The thermostat has already been programmed with a
unique code. Do not attempt to teach the RF Thermostat ID code
unless instructed by the manufacturer.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for safety. Children should be supervised to ensure that
they do not play with the appliance.
This heater features a safety interlock mode to prevent accidental or
inappropriate activation of the hand held remote control unit. It requires
both “PWR”and “OK” buttons be pressed at the same time to turn on the
controller.
Page 16.
Quick reference table
Function Action Page
Switch on/off
Change
between
manual and
automatic
mode.
Increase /
decrease
temperature.
Set the clock
and day of
the week.
Program the
thermostat
Press and release ‘A/M ‘ button.
Press and release ‘UP ‘ or ‘DOWN ‘ button.
With the thermostat off, press and hold the ‘T’
button until the time, hour and AM/PM flash.
Press and release the ‘UP ’ or ‘DOWN ’ buttons
to increase or decrease the hour setting.
Press and hold for the hour to increase or
decrease 1 hour every 0.5 seconds.
Press ‘OK ’ and set the minute setting similarly.
Press ‘OK ’ and press and release the ‘UP ’ or
‘DOWN ’ buttons to change the day of the week.
With the thermostat off, press and hold
the ‘P’ button. Program 1 can now be set.
To select Monday press ‘OK ’, or press and
release ‘UP ’ or ‘DOWN ’ to change the day of
the week, or to switch to the weekday or
weekend setting.
To set the period starting time, set the hour and
minute setting similarly to setting the clock.
Press ‘OK ’. Press and release the ‘UP ’ or
‘DOWN’ button to increase or decrease the
temperature setting by 1°C.
Press ‘OK ’. Program 2 can now be set.
Repeat the programming process for the 4
periods.
8
9
9
8
10
Press ‘PWR’ &‘OK’ buttons at same time
(then release)
Frequently asked questions
Question Corrective actions
Heater comes on
at the wrong time.
Check the programmed period start and finish
times are correct.
Check that AM or PM is correctly set.
Check the programmed period temperature
setting is correct.
Check that °C or °F is correctly specified.
Reset the time and day of the week as was
required in the initial set up. Ref page 8.
Once the default settings have been reset, the
thermostat must be reprogrammed.
See page 8. for initial set up and pages 9-11 for
programming the automatic mode.
Check that the batteries are in place correctly.
Replace the batteries with new batteries and
see if thermostat display appears.
Check safety interlock mode
The back light will only appear when the
thermostat is on.
Heater comes on
at the wrong
temperature.
The time or day of
the week is wrong.
Factory default
settings have been
lost.
The thermostat won’t
turn on or the display
is blank.
The screen back light
is not working.
Page 15.
Normal operation:
If there is a request for heating, the heater will start up on Low Fire and
Low Fan operation for approximately 3 minutes after which the heater
will operate as necessary according to the selected temperature.
When the heater is turned off, the flame will extinguish and the fan will
continue to operate on Low speed for approximately 3 minutes to assist
with cooling the heater.
The heater will not
start.
Check safety interlock mode
Page 4.
Features of your thermostat model heater:
Auto mode cycle.
The heater on start will operate on Low Fire and fan for approx 3 minutes.
The heater will then go to your preset desired settings on Remote Thermostat.
(Auto or Manual)
The heater on start will operate on Low Fire and fan for approx 3 minutes.
The heater will then go to your preset desired settings on remote thermostat.
As the preset temperature is reached, the heater will go to Low Fire and
Low Fan. If the preset temperature is exceeded, the burner is
extinguished and the fan will run on at low setting for approximately 3 min.
If room temperature is still higher than preset temperature, the heater will
stop. Once room temperature drops below preset temperature, the heater
will resume operation and continue the program cycle..
This feature is dependant upon the preset programmed temperature and
where the thermostat is located in the room. (See diagram below)
As the preset temperature is reached, the heater will go to Low Fire and
Low Fan. When the heater preset temperature is exceeded, the burner is
extinguished and the fan will run on at low setting for approximately 3 min.
If room temperature is still higher than preset temperature the heater will
stop. Once room temperature drops below preset temperature, the heater
will resume operation and continue the program cycle..
When heater is shut down, fan will continue to operate on low for a further
period of 3 - 4 min to assist cooling down of the heater (common to Manual
and Auto cycles).
Thermostat should be located within the personal comfort zone of the room.
(This is dependant on room layout and heater positioning.)
The remote can also be wall mounted using the bracket supplied.
Heater
Personal comfort zone
Manual mode cycle
The heater can be set with your personal settings including temperature,
start and stop times and days of week.
(see programming section for setting temperatures and operating times.)
2 screws.
(Not supplied)
Wall bracket.
(Supplied)
Avoid locating remote
thermostat directly in front
of the heater
Page 5.
Thermostat LCD
Full display
ROOM
TIME
AM
MO
ROOM
SET
TIME
AM
PM
SU MO TU WE TH FR SA
PROG MANUAL AUTO
LCD Display features.
1. Temperature of Room in (C or F)
2. Transmitting indicator
3. Battery low indicator
4. Fan operating and speed
5. Fire indicator(low, medium or high)**
6. Selected Temperature in C or F)
7. Time of day (in AM or PM)
8. Day of week
9. Programming mode
10. Manual mode
11. Automatic mode
** Although a medium Fire is displayed it is not
available on this heater, it is actually operating
on High Fire when displayed.
Initial Display on set up.
The display when the thermostat is
initially turned on or when batteries are
replaced shows;
Current room temperature;
default clock display;
Default day of the week display.
1
45
6
7
8
910 11
3
Page 14.
Settings
Change between °C and °F
Teaching RF thermostat ID code to control unit.
CAUTION: The thermostat has already been programmed with a
unique code. Do not attempt to teach the RF Thermostat ID code
unless instructed by the manufacturer.
The LCD display will show ‘CL’ (Code Learn) for 2 seconds then return to
the normal OFF state display. During this time a special code will be
transmitted by the Thermostat to the Control Unit, causing the Control
Unit to learn its ID.
With the thermostat off, press the following sequence of buttons:
‘P ’, ‘T ’, ‘T ’,‘UP ’.
Restore factory default settings.
The automatic mode factory default settings can be restored to those
found on page 10.
With the thermostat off, press the following sequence of buttons:
‘P ’, ‘T ’, ‘T ’,‘DOWN ’.
The thermostat temperature display can be set to°C or °F. The default is °C.
With the thermostat off, press the following sequence of buttons:
‘P ’, ‘T ’, ‘T ’ ,‘A/M ’.
Please note, thermostat settings need to be actioned within a period
of 2 seconds total.
An additional feature of your heater is the ‘Back up Switch’
This allows the heater to be in operation in a basic functional manner
without the remote control.
It operation is fully described on page 17.
2
Page 13.
Program mode
Your Settings
After programming, record your personal settings weekday and weekend
settings here for future reference.
Weekdays
Weekend
Factory default settings
Time Period Start Time Heat Temperature (°C)
Wake up. 6.00 am 20 °C
Away. 8.30 am 7 °C
Coming home. 5.00 pm 21 °C
Sleep . 10.30 pm 7 °C
Time Period Start Time Heat Temperature (°C)
Wake up. °C
Away. °C
Coming home . pm
°C
Sleep. pm °C
Time Period Start Time Heat Temperature (°C)
Wake up. °C
Away. °C
Coming home . °C
Sleep. pm °C
The room will be maintained at set temperature during set period.
pm
AM
ROOM
SET
SU MO TU WE TH FR SA
PROG
MANUAL
AUTO
Feature Symbol Description
Time of day
Day of
week
Temperature
display
Room set
indicator
Transmit
indicator
Battery low
indicator
Programming
mode
indicator
Automatic /
manual mode
indication
Flame
indicator
Fan
indicator
Displays the time of day in hours and
minutes, AM or PM. The time is displayed
when the thermostat is on or off.
Displays the current day of the week. The
day is displayed when the thermostat is on
or off.
Displays the current temperature. C° is the
default but F° is available. The temperature
range is 7°C to 32°C.
When the thermostat is on, the
programmed (set) temperature will be
displayed. When the thermostat is off, only
the room temperature will be displayed.
Indicates that the thermostat is transmitting
to the receiver, the symbol will appear on
the LCD for 1 second.
Indicates that battery power is below an
acceptable level. The symbol will flash to
indicate that the batteries need replacing.
The thermostat will remain functional for
approximately another 5 days before
shutting down.
Indicates that the thermostat is in
programming mode.
Indicates whether the thermostat is in
manual or automatic mode.
Indicates the flame height:
HIGH FIRE
MEDIUM FIRE*
LOW FIRE
*Medium Fire is not a function of this heater
Indicates the fan speed.
The fan ranges are graduated
settings: 1, 2, 3.
Page 6.
Period 4.
SET
TIME
PM
MO
PROG
SET
TIME
PM
MO
PROG
SET
TIME
AM
MO
PROG
ROOM
SET
TIME
AM
SU MO TU WE TH FR SA
PROG
ROOM
SET
TIME
AM
MO
PROG
ROOM
SET
TIME
AM
MO
PROG
SET
TIME
AM
MO
PROG
Set period day.
Days of week flash.
Set temperature.
Set and temperature
flash.
Period 2.
Period 1. Period 3.
Set hours.
Time and hours flash.
Set minutes.
Time and minutes flash.
Page 12.
Page 7.
Programming button function
T
P
T
P
Time
Program
Indicates time and day of the week
programming (must press and hold for 2
or more seconds when thermostat is off).
Indicates the programming mode (must
press and hold for 2 or more seconds
when thermostat is off).
Functions
Button Function Description
PWR
OK
UP
DOWN
PWR
UP
DOWN
OK
Switches the thermostat on.
If the thermostat is off, pressing and
releasing the PWR and OK button
together will turn the thermostat on to
the most recently selected working mode.
On
Accepts the current function and
advances the next function.
Increment hours, minutes, day or
temperature.
Decrement hours, minutes, day or
temperature.
Enter
Button Functions
PWR OK
A / M Automatic
/ Manual
Toggles between automatic and manual
mode.
A/M
PWR Off Switches the unit off.
Initial Setup
If the ‘PWR ’is off, the heater will not start.
Press and release the ‘PWR ’ and ‘OK’ buttons together, pressing
and releasing ‘PWR ’ and ‘OK’ buttons will turn the thermostat on to the most
recently selected working mode or the factory default setting if not previously
programmed.
Note small Red LED Display light will be displayed constantly while heater is
on.Will
flash intermittently when unit is not in operation.
Press and release the ‘PWR ’ will shut unit down.
Setting the day of the week and time.
Setting the hour function.
Press and release the ‘UP ’ or ‘DOWN ’ button to increase or decrease the
hour setting by 1 hour.
Press and hold the ‘UP ’ or ‘DOWN ’ button for 2 seconds or longer to
increase or decrease the hour setting by 1 hour every 0.5 seconds.
Press ‘OK ’ to accept and select the minute.
Setting the minute function.
Press and release, or press and hold down the ’UP ’ or ‘DOWN ’ button to
increase or decrease the minute setting by 1 minute similarly to the hour
setting.
Press ‘OK ’ to accept and select the day of the week.
Setting the day of the week function.
Press and release the ‘UP ’ or ‘DOWN ’ button to change the day of the
week to the following or previous day. Press and hold the ‘UP ’ or ‘DOWN ’
button for 2 seconds or longer to increase or decrease the day of the week
by 1 day every 0.5 seconds.
Press ‘OK ’ to complete setting.
The time and day of the week is now set.
Page 8.
Note: Use the outer edge of buttons to toggle through functions.
Back up Switch.
In the event that Thermostat remote is in operative ie Flat batteries or
damaged unit can still be used but only on the one factory setting of high fire
Medium fan. Unit will start as per normal 3 minutes on Low Fire and Fan,
but them will go to High Fire, Medium Fan. This switch is only for use in the
event of failure of Remote Thermostat.
With the thermostat off, press and hold the ‘T’ button for 2 seconds or
longer to initiate programming the time. Time, the hour setting and the
AM / PM will flash.
Page 11.
Setting the period starting time.
The hour and AM / PM settings will now flash. To set the P1 starting time,
press and release the ‘UP ’ and ‘DOWN ’ button to increase or decrease
the hour setting. Press and hold the ‘UP ’ or ‘DOWN ’ button for 2 seconds
or longer to increase or decrease the hour setting by 1 hour every 0.5
seconds.
The hour function is in 12 hour time, so please ensure that AM or PM is
set correctly.
To accept the hour press ‘OK ’.
The minute setting will flash. Adjust the minute setting similarly using ‘UP ’
or ‘DOWN ’ buttons.
To accept the minute press ‘OK ’.
Setting the temperature.
The temperature setting will now flash. Press and release the ’UP ’ or
‘DOWN ’ button to increase or decrease the temperature setting by 1°C.
Press and hold th ‘UP ’ or ‘DOWN ’ button for 2 seconds or longer to
increase or decrease the temperature setting by 1°C every 0.5 seconds.
To accept the temperature press ‘OK ’.
Period 1 is now set for the day/s of the week that you have chosen. The
LCD will display P2 to indicate that period 2 can now be set for the same
day/s of the week.
Repeat the programming process for periods 3 and 4.
After program 4 is set, press ‘OK ’ and the program for the selected day/s
will be set.
The thermostat will now automatically turn off.
Repeat the programming process for any other periods/days that are
required.
ON
OFF
Manual mode.
The manual mode allows setting the temperature at any level.
To select Manual mode, firstly the thermostat must be turned on, then press
and release the ‘A/M’ button until MANUAL appears on the display.
Flame height and Fan speed.
The flame height and fan speed are not manually adjustable. The flame
height and fan speed are set by the thermostat according to the
difference between the set temperature and the current temperature.
The flame height (Low or High Fire) or Fan Speeds are not manually
adjustable.
They are automatically controlled by the thermostat in the program cycle.
This will vary according to the selected temperature and the actual room
temperature.
The display may show a Medium Fire symbol during operation however
this function is not available with this heater and the heater will be operating
on High Fire when Medium fire symbol is displayed.
Adjusting the temperature.
In the manual mode, adjust the set temperature by pressing or releasing
the ‘UP’ or ‘DOWN’ buttons. Press and hold the ‘UP’ or ‘DOWN’ buttons
to increase or decrease the temperature by 1°C every 0.5 seconds..
Automatic mode.
The automatic mode allows the temperature to be regulated according to a
programmed level and time.
With the thermostat on, press and release the ‘A/M ’ button until the word
AUTO appears on the LCD.
To correctly operate in automatic mode, the time and day of the week
must be set.
The thermostat will now operate according to the program set for the
current time period. Programming instructions are found on page 10.
Manually overriding the set program.
At any time, the temperature or fan speed may be adjusted up or down
similar to operating in manual mode.
However, whenever the thermostat changes to a new time period, the
temperature will be reset automatically according to that period’s setting.
Page 9.
Programming
Each day of the week can be programmed individually for periods P1, P2,
P3, and P4, making a total of 28 programmed periods.
Alternatively, a weekday program can be set, so the same program is used
for Monday to Friday. Similarly, a weekday program can be set for Saturday
- Sunday. The entire week can also have the same program.
Alternatively, a weekday or weekend program can be set with individual
programs for the remaining days.
The suggested period settings for each day/s are:
Period 1 - morning (Wake up)
Period 2 - daytime (Away)
Period 3 - evening (Coming home)
Period 4 - night time. (Sleep)
To begin programming.
With the thermostat off, press and hold the ‘P’ button for 2 seconds or longer
to initiate programming. The LCD will display PROG, Pd and the time at
which the thermostat is currently set MO will flash.
Period 1 can now be set.
Setting the day of the week.
You must choose which day/s of the week you wish to program.
Press and release the ‘UP ’ or ‘DOWN ’ button to change the day of the week
to the following or previous day. Press and hold the ‘UP ’ or ‘DOWN ’ button
for 2 seconds or longer to increase or decrease the day of the week by
1 day every 0.5 seconds.
The order that you can scroll through the days is as follows:
MO>TU>WE>TH>FR>MO TU WE TH FR>SA>SU>SU SA>MO TU WE TH FR SA SU
To accept the selected day/s of the week press ‘OK ’.
Page 10.
Manual mode.
The manual mode allows setting the temperature at any level.
To select Manual mode, firstly the thermostat must be turned on, then press
and release the ‘A/M’ button until MANUAL appears on the display.
Flame height and Fan speed.
The flame height and fan speed are not manually adjustable. The flame
height and fan speed are set by the thermostat according to the
difference between the set temperature and the current temperature.
The flame height (Low or High Fire) or Fan Speeds are not manually
adjustable.
They are automatically controlled by the thermostat in the program cycle.
This will vary according to the selected temperature and the actual room
temperature.
The display may show a Medium Fire symbol during operation however
this function is not available with this heater and the heater will be operating
on High Fire when Medium fire symbol is displayed.
Adjusting the temperature.
In the manual mode, adjust the set temperature by pressing or releasing
the ‘UP’ or ‘DOWN’ buttons. Press and hold the ‘UP’ or ‘DOWN’ buttons
to increase or decrease the temperature by 1°C every 0.5 seconds..
Automatic mode.
The automatic mode allows the temperature to be regulated according to a
programmed level and time.
With the thermostat on, press and release the ‘A/M ’ button until the word
AUTO appears on the LCD.
To correctly operate in automatic mode, the time and day of the week
must be set.
The thermostat will now operate according to the program set for the
current time period. Programming instructions are found on page 10.
Manually overriding the set program.
At any time, the temperature or fan speed may be adjusted up or down
similar to operating in manual mode.
However, whenever the thermostat changes to a new time period, the
temperature will be reset automatically according to that period’s setting.
Page 9.
Programming
Each day of the week can be programmed individually for periods P1, P2,
P3, and P4, making a total of 28 programmed periods.
Alternatively, a weekday program can be set, so the same program is used
for Monday to Friday. Similarly, a weekday program can be set for Saturday
- Sunday. The entire week can also have the same program.
Alternatively, a weekday or weekend program can be set with individual
programs for the remaining days.
The suggested period settings for each day/s are:
Period 1 - morning (Wake up)
Period 2 - daytime (Away)
Period 3 - evening (Coming home)
Period 4 - night time. (Sleep)
To begin programming.
With the thermostat off, press and hold the ‘P’ button for 2 seconds or longer
to initiate programming. The LCD will display PROG, Pd and the time at
which the thermostat is currently set MO will flash.
Period 1 can now be set.
Setting the day of the week.
You must choose which day/s of the week you wish to program.
Press and release the ‘UP ’ or ‘DOWN ’ button to change the day of the week
to the following or previous day. Press and hold the ‘UP ’ or ‘DOWN ’ button
for 2 seconds or longer to increase or decrease the day of the week by
1 day every 0.5 seconds.
The order that you can scroll through the days is as follows:
MO>TU>WE>TH>FR>MO TU WE TH FR>SA>SU>SU SA>MO TU WE TH FR SA SU
To accept the selected day/s of the week press ‘OK ’.
Page 10.
Initial Setup
If the ‘PWR ’is off, the heater will not start.
Press and release the ‘PWR ’ and ‘OK’ buttons together, pressing
and releasing ‘PWR ’ and ‘OK’ buttons will turn the thermostat on to the most
recently selected working mode or the factory default setting if not previously
programmed.
Note small Red LED Display light will be displayed constantly while heater is
on.Will
flash intermittently when unit is not in operation.
Press and release the ‘PWR ’ will shut unit down.
Setting the day of the week and time.
Setting the hour function.
Press and release the ‘UP ’ or ‘DOWN ’ button to increase or decrease the
hour setting by 1 hour.
Press and hold the ‘UP ’ or ‘DOWN ’ button for 2 seconds or longer to
increase or decrease the hour setting by 1 hour every 0.5 seconds.
Press ‘OK ’ to accept and select the minute.
Setting the minute function.
Press and release, or press and hold down the ’UP ’ or ‘DOWN ’ button to
increase or decrease the minute setting by 1 minute similarly to the hour
setting.
Press ‘OK ’ to accept and select the day of the week.
Setting the day of the week function.
Press and release the ‘UP ’ or ‘DOWN ’ button to change the day of the
week to the following or previous day. Press and hold the ‘UP ’ or ‘DOWN ’
button for 2 seconds or longer to increase or decrease the day of the week
by 1 day every 0.5 seconds.
Press ‘OK ’ to complete setting.
The time and day of the week is now set.
Page 8.
Note: Use the outer edge of buttons to toggle through functions.
Back up Switch.
In the event that Thermostat remote is in operative ie Flat batteries or
damaged unit can still be used but only on the one factory setting of high fire
Medium fan. Unit will start as per normal 3 minutes on Low Fire and Fan,
but them will go to High Fire, Medium Fan. This switch is only for use in the
event of failure of Remote Thermostat.
With the thermostat off, press and hold the ‘T’ button for 2 seconds or
longer to initiate programming the time. Time, the hour setting and the
AM / PM will flash.
Page 11.
Setting the period starting time.
The hour and AM / PM settings will now flash. To set the P1 starting time,
press and release the ‘UP ’ and ‘DOWN ’ button to increase or decrease
the hour setting. Press and hold the ‘UP ’ or ‘DOWN ’ button for 2 seconds
or longer to increase or decrease the hour setting by 1 hour every 0.5
seconds.
The hour function is in 12 hour time, so please ensure that AM or PM is
set correctly.
To accept the hour press ‘OK ’.
The minute setting will flash. Adjust the minute setting similarly using ‘UP ’
or ‘DOWN ’ buttons.
To accept the minute press ‘OK ’.
Setting the temperature.
The temperature setting will now flash. Press and release the ’UP ’ or
‘DOWN ’ button to increase or decrease the temperature setting by 1°C.
Press and hold th ‘UP ’ or ‘DOWN ’ button for 2 seconds or longer to
increase or decrease the temperature setting by 1°C every 0.5 seconds.
To accept the temperature press ‘OK ’.
Period 1 is now set for the day/s of the week that you have chosen. The
LCD will display P2 to indicate that period 2 can now be set for the same
day/s of the week.
Repeat the programming process for periods 3 and 4.
After program 4 is set, press ‘OK ’ and the program for the selected day/s
will be set.
The thermostat will now automatically turn off.
Repeat the programming process for any other periods/days that are
required.
ON
OFF
Period 4.
SET
TIME
PM
MO
PROG
SET
TIME
PM
MO
PROG
SET
TIME
AM
MO
PROG
ROOM
SET
TIME
AM
SU MO TU WE TH FR SA
PROG
ROOM
SET
TIME
AM
MO
PROG
ROOM
SET
TIME
AM
MO
PROG
SET
TIME
AM
MO
PROG
Set period day.
Days of week flash.
Set temperature.
Set and temperature
flash.
Period 2.
Period 1. Period 3.
Set hours.
Time and hours flash.
Set minutes.
Time and minutes flash.
Page 12.
Page 7.
Programming button function
T
P
T
P
Time
Program
Indicates time and day of the week
programming (must press and hold for 2
or more seconds when thermostat is off).
Indicates the programming mode (must
press and hold for 2 or more seconds
when thermostat is off).
Functions
Button Function Description
PWR
OK
UP
DOWN
PWR
UP
DOWN
OK
Switches the thermostat on.
If the thermostat is off, pressing and
releasing the PWR and OK button
together will turn the thermostat on to
the most recently selected working mode.
On
Accepts the current function and
advances the next function.
Increment hours, minutes, day or
temperature.
Decrement hours, minutes, day or
temperature.
Enter
Button Functions
PWR OK
A / M Automatic
/ Manual
Toggles between automatic and manual
mode.
A/M
PWR Off Switches the unit off.
Page 13.
Program mode
Your Settings
After programming, record your personal settings weekday and weekend
settings here for future reference.
Weekdays
Weekend
Factory default settings
Time Period Start Time Heat Temperature (°C)
Wake up. 6.00 am 20 °C
Away. 8.30 am 7 °C
Coming home. 5.00 pm 21 °C
Sleep . 10.30 pm 7 °C
Time Period Start Time Heat Temperature (°C)
Wake up. °C
Away. °C
Coming home . pm
°C
Sleep. pm °C
Time Period Start Time Heat Temperature (°C)
Wake up. °C
Away. °C
Coming home . °C
Sleep. pm °C
The room will be maintained at set temperature during set period.
pm
AM
ROOM
SET
SU MO TU WE TH FR SA
PROG
MANUAL
AUTO
Feature Symbol Description
Time of day
Day of
week
Temperature
display
Room set
indicator
Transmit
indicator
Battery low
indicator
Programming
mode
indicator
Automatic /
manual mode
indication
Flame
indicator
Fan
indicator
Displays the time of day in hours and
minutes, AM or PM. The time is displayed
when the thermostat is on or off.
Displays the current day of the week. The
day is displayed when the thermostat is on
or off.
Displays the current temperature. C° is the
default but F° is available. The temperature
range is 7°C to 32°C.
When the thermostat is on, the
programmed (set) temperature will be
displayed. When the thermostat is off, only
the room temperature will be displayed.
Indicates that the thermostat is transmitting
to the receiver, the symbol will appear on
the LCD for 1 second.
Indicates that battery power is below an
acceptable level. The symbol will flash to
indicate that the batteries need replacing.
The thermostat will remain functional for
approximately another 5 days before
shutting down.
Indicates that the thermostat is in
programming mode.
Indicates whether the thermostat is in
manual or automatic mode.
Indicates the flame height:
HIGH FIRE
MEDIUM FIRE*
LOW FIRE
*Medium Fire is not a function of this heater
Indicates the fan speed.
The fan ranges are graduated
settings: 1, 2, 3.
Page 6.
Page 5.
Thermostat LCD
Full display
ROOM
TIME
AM
MO
ROOM
SET
TIME
AM
PM
SU MO TU WE TH FR SA
PROG MANUAL AUTO
LCD Display features.
1. Temperature of Room in (C or F)
2. Transmitting indicator
3. Battery low indicator
4. Fan operating and speed
5. Fire indicator(low, medium or high)**
6. Selected Temperature in C or F)
7. Time of day (in AM or PM)
8. Day of week
9. Programming mode
10. Manual mode
11. Automatic mode
** Although a medium Fire is displayed it is not
available on this heater, it is actually operating
on High Fire when displayed.
Initial Display on set up.
The display when the thermostat is
initially turned on or when batteries are
replaced shows;
Current room temperature;
default clock display;
Default day of the week display.
1
45
6
7
8
910 11
3
Page 14.
Settings
Change between °C and °F
Teaching RF thermostat ID code to control unit.
CAUTION: The thermostat has already been programmed with a
unique code. Do not attempt to teach the RF Thermostat ID code
unless instructed by the manufacturer.
The LCD display will show ‘CL’ (Code Learn) for 2 seconds then return to
the normal OFF state display. During this time a special code will be
transmitted by the Thermostat to the Control Unit, causing the Control
Unit to learn its ID.
With the thermostat off, press the following sequence of buttons:
‘P ’, ‘T ’, ‘T ’,‘UP ’.
Restore factory default settings.
The automatic mode factory default settings can be restored to those
found on page 10.
With the thermostat off, press the following sequence of buttons:
‘P ’, ‘T ’, ‘T ’,‘DOWN ’.
The thermostat temperature display can be set to°C or °F. The default is °C.
With the thermostat off, press the following sequence of buttons:
‘P ’, ‘T ’, ‘T ’ ,‘A/M ’.
Please note, thermostat settings need to be actioned within a period
of 2 seconds total.
An additional feature of your heater is the ‘Back up Switch’
This allows the heater to be in operation in a basic functional manner
without the remote control.
It operation is fully described on page 17.
2
Frequently asked questions
Question Corrective actions
Heater comes on
at the wrong time.
Check the programmed period start and finish
times are correct.
Check that AM or PM is correctly set.
Check the programmed period temperature
setting is correct.
Check that °C or °F is correctly specified.
Reset the time and day of the week as was
required in the initial set up. Ref page 8.
Once the default settings have been reset, the
thermostat must be reprogrammed.
See page 8. for initial set up and pages 9-11 for
programming the automatic mode.
Check that the batteries are in place correctly.
Replace the batteries with new batteries and
see if thermostat display appears.
Check safety interlock mode
The back light will only appear when the
thermostat is on.
Heater comes on
at the wrong
temperature.
The time or day of
the week is wrong.
Factory default
settings have been
lost.
The thermostat won’t
turn on or the display
is blank.
The screen back light
is not working.
Page 15.
Normal operation:
If there is a request for heating, the heater will start up on Low Fire and
Low Fan operation for approximately 3 minutes after which the heater
will operate as necessary according to the selected temperature.
When the heater is turned off, the flame will extinguish and the fan will
continue to operate on Low speed for approximately 3 minutes to assist
with cooling the heater.
The heater will not
start.
Check safety interlock mode
Page 4.
Features of your thermostat model heater:
Auto mode cycle.
The heater on start will operate on Low Fire and fan for approx 3 minutes.
The heater will then go to your preset desired settings on Remote Thermostat.
(Auto or Manual)
The heater on start will operate on Low Fire and fan for approx 3 minutes.
The heater will then go to your preset desired settings on remote thermostat.
As the preset temperature is reached, the heater will go to Low Fire and
Low Fan. If the preset temperature is exceeded, the burner is
extinguished and the fan will run on at low setting for approximately 3 min.
If room temperature is still higher than preset temperature, the heater will
stop. Once room temperature drops below preset temperature, the heater
will resume operation and continue the program cycle..
This feature is dependant upon the preset programmed temperature and
where the thermostat is located in the room. (See diagram below)
As the preset temperature is reached, the heater will go to Low Fire and
Low Fan. When the heater preset temperature is exceeded, the burner is
extinguished and the fan will run on at low setting for approximately 3 min.
If room temperature is still higher than preset temperature the heater will
stop. Once room temperature drops below preset temperature, the heater
will resume operation and continue the program cycle..
When heater is shut down, fan will continue to operate on low for a further
period of 3 - 4 min to assist cooling down of the heater (common to Manual
and Auto cycles).
Thermostat should be located within the personal comfort zone of the room.
(This is dependant on room layout and heater positioning.)
The remote can also be wall mounted using the bracket supplied.
Heater
Personal comfort zone
Manual mode cycle
The heater can be set with your personal settings including temperature,
start and stop times and days of week.
(see programming section for setting temperatures and operating times.)
2 screws.
(Not supplied)
Wall bracket.
(Supplied)
Avoid locating remote
thermostat directly in front
of the heater
Features of your thermostat model heater:
If the controller is turned on and there is a requirement for heating, the
heater will start up on Low Fire and Low Fan and operate for approximately
3 minutes.
The heater will then go to your preset desired temperature functions on
the remote controller
Once the selected room temperature has been reached, the heater will
go to Low Fire and Low Fan.
The full description on the operation of the heater is described in more
detail in the following section.
SAFETY WARNINGS
Do not place clothing or other flammable material on or near the heater.
Keep curtains, clothing, furniture and other flammable materials at least
900mm from front and sides of the heater.
At the owners discretion curtain clearances can be less than 900mm as
long as they are restrained from the front, top and sides of the heater.
The manufacturer takes no responsibility if curtain clearance is less than
900mm and not restrained.
For full safety warning information, Refer to Heater User Instructions.
Page 3.
CAUTION: The thermostat has already been programmed with a
unique code. Do not attempt to teach the RF Thermostat ID code
unless instructed by the manufacturer.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for safety. Children should be supervised to ensure that
they do not play with the appliance.
This heater features a safety interlock mode to prevent accidental or
inappropriate activation of the hand held remote control unit. It requires
both “PWR”and “OK” buttons be pressed at the same time to turn on the
controller.
Page 16.
Quick reference table
Function Action Page
Switch on/off
Change
between
manual and
automatic
mode.
Increase /
decrease
temperature.
Set the clock
and day of
the week.
Program the
thermostat
Press and release ‘A/M ‘ button.
Press and release ‘UP ‘ or ‘DOWN ‘ button.
With the thermostat off, press and hold the ‘T’
button until the time, hour and AM/PM flash.
Press and release the ‘UP ’ or ‘DOWN ’ buttons
to increase or decrease the hour setting.
Press and hold for the hour to increase or
decrease 1 hour every 0.5 seconds.
Press ‘OK ’ and set the minute setting similarly.
Press ‘OK ’ and press and release the ‘UP ’ or
‘DOWN ’ buttons to change the day of the week.
With the thermostat off, press and hold
the ‘P’ button. Program 1 can now be set.
To select Monday press ‘OK ’, or press and
release ‘UP ’ or ‘DOWN ’ to change the day of
the week, or to switch to the weekday or
weekend setting.
To set the period starting time, set the hour and
minute setting similarly to setting the clock.
Press ‘OK ’. Press and release the ‘UP ’ or
‘DOWN’ button to increase or decrease the
temperature setting by 1°C.
Press ‘OK ’. Program 2 can now be set.
Repeat the programming process for the 4
periods.
8
9
9
8
10
Press ‘PWR’ &‘OK’ buttons at same time
(then release)
Fitzroy Inbuilt
Model shown.
Red LED flashes twice approximately every
3 seconds to indicate that power is available.
When heater is operating in Back Up mode
the LED is on continuously.
In the rare instance of the Hand Held Unit failing to operate, the heater can
be operated manually by pressing the Back Up Switch button (once).
The switch is located where shown above.
For this Back Up Switch to operate correctly the batteries must be removed
from the Hand Held Unit.
In this Back Up mode, the heater will start up on Low Fire and Low Speed
Fan and then after approximately 3 minutes it will increase to High Fire and
Medium Speed Fan. (Speed 2)
Turn off the heater, press the Back Up Switch (once), the fire will extinguish
and the Fan will reduce to Low Speed and operate for approximately
3 minutes to assist with cooling down the heater.
In this mode there is no temperature control operating.
Back Up Switch.
Page 17.
QUICK START GUIDE
This Remote Thermostat is a room thermostat and to function correctly it
should be located in the same room as the heater within personal
comfort zone.
The thermostat is factory set with the default settings shown below and
will operate at settings indicated. If you wish to change these times or
temperatures see the Programming section later in manual.
Automatic Factory default settings
Factory default settings
Time Period Start Time Heat Temperature (°C)
Wake up. 6.00 am 20 °C
Away. 8.30 am 7 °C
Coming home. 5.00 pm 21 °C
Sleep. 10.30 pm 7 °C
The room will be maintained at set temperature during set period.
21°C
7°C
20°C
6.00AM 6.00AM
8.30AM 5.00PM 10.30PM
At any time during the automatic program period, the temperature can be
increased or decreased by pressing the “UP” or “DOWN” buttons.
To start heater.
Select “PWR” and “OK” buttons and press them together (then release).
Select Auto or Manual by pressing “A/M” button (then release).
The heater will only operate if the actual room temperature is lower
than the required temperature.
Manual Mode:
Press “A/M” Button to select “Manual” mode.
The required temperature can be selected by using ‘UP ’ or ‘DOWN ’
buttons.
Room temperature is shown at top of screen.
Selected temperature shown at mid screen.
Automatic Mode
Press “A/M” Button to select “Auto” mode.
Set current time and date. (See setting time and date later in manual.)
Page 2.
No user serviceable components are within the heater thermostat.
contact SampfordIXL for any required maintenance.
Ph: 1300 727 421 Fax: 1300 727 425
Page 18.
NOTES.
For Service
CONTENTS
Quick start guide. 2
Safety warnings 3
Features 4
Thermostat LCD 5
Functions 6 -7
Button functions
Programming button functions
Initial setup 8
On / Off
Time and day of the week
Manual mode 9
Automatic mode 9
Programming 11 -10
Programming screen displays 12
Program mode 13
Factory default settings
Your settings
Settings 14
Change between C° and F°
Restore factory default settings
Teaching the thermostat ID code
to the control unit
Frequently asked questions 15
Quick reference table 16
Back Up Switch 17
Service 18
Battery type: 2 X AA batteries
Battery life : approximately 12 months
Transmission frequency: 433.92 Mhz
Dimensions: 140MM x 80mm x 20mm
Page 1.
A/M OK
UP
TP
DOWN
PWR
ROOM
TIME
Cannon
THERMOSTAT
USER MANUAL
Phone: 1300 727 427
Faxsimile: 1300 727 425
A/M OK
UP
TP
DOWN
PWR
ROOM
TIME
Cannon
F3197
ISSUE 2 JAN 2009.
Table of contents
Other Cannon Thermostat manuals
