Capital MAESTRO SERIES User manual

USE AND CARE MANUAL
MAESTRO SERIES
30” WARMING DRAWER
MODEL:
MWD301ES

- -
1
A SPECIAL MESSAGE TO CUSTOMERS
Dear Valued Customer,
Congratulations on making a smart choice! You have joined an elite group of cooking
enthusiasts who demand only the very best from their appliances. A Capital Cooking appliance
promises years of enjoyment and maximum performance, allowing cooks everywhere to create
culinary memories that last a lifetime.
Because of the unique features found in our appliances, we urge you to read this manual
thoroughly before installation and use. Please RETAIN THIS MANUAL FOR FUTURE
REFERENCE; it is an invaluable guide to help you better understand your Capital Cooking
appliance.
Since your satisfaction is our topmost priority, please feel free to contact our service experts.
You may reach us toll free at [phone], or dial the factory direct at [phone]. You
can fax us a list of your concerns, comments, and/or compliments at [phone], or drop
us an e-mail at [email protected]. Feel free to also write us at:
13211 East Florence Ave.
Santa Fe Springs, CA 90670
Our products are proudly designed and manufactured in America and we trust that our strict
adherence to the highest quality assurance standards will provide you with years of trouble
free gourmet cooking.
Happy Cooking!
Chairman
Capital Cooking Equipment, Inc.

- -
2
TABLE OF CONTENTS
A SPECIAL MESSAGE TO CUSTOMERS............................................................................................................... 1
TABLE OF CONTENTS............................................................................................................................................. 2
WARNINGS AND GENERAL SAFETY..................................................................................................................... 3
WARMING DRAWER CONTROL FUNCTIONS....................................................................................................... 4
WARMING DRAWER LEGEND................................................................................................................................ 4
WARMING DRAWER FEATURES DEFINED........................................................................................................... 5
USE OF YOUR WARMING DRAWER...................................................................................................................... 6
INITIAL WARMING DRAWER SETUP................................................................................................................. 6
WARMING DRAWER USE ....................................................................................................................................... 6
PREPARATION..................................................................................................................................................... 6
POSITIONING FOOD IN THE WARMING DRAWER ..........................................................................................6
SETTING THE WARMING DRAWER................................................................................................................... 7
ADJUSTING TEMPERATURE PRESETS ....................................................................................................... 7
SETTING THE TIMER...................................................................................................................................... 7
CONTINUOUS ON MODE................................................................................................................................ 7
TURNING THE WARMING DRAWER OFF.......................................................................................................... 7
TIPS........................................................................................................................................................................... 8
General ............................................................................................................................................................. 8
CARE AND MAINTENANCE..................................................................................................................................... 8
CLEANING CHART:......................................................................................................................................... 8
TROUBLESHOOTING............................................................................................................................................... 9
SERVICE INFORMATION......................................................................................................................................... 9
WARRANTY............................................................................................................................................................ 10
NOTES: ................................................................................................................................................................... 11

- -
3
WARNINGS AND GENERAL SAFETY
WARNING
Do not install or use this product near water or outdoors, for example, near a kitchen sink, in a wet basement or
near a swimming pool.
GENERAL SAFETY PRECAUTIONS:
To reduce the risk of fire, electric shock, serious injury or death when using your appliance, follow basic safety
precautions, including the following:
1. Read the provided use and care manual before operating this appliance.
2. Keep packaging materials away from children. Plastic sheets and bags can cause suffocation.
3. If your warming drawer is found to be damaged upon receipt, contact your dealer or builder
immediately. Do not install or use a damaged appliance or if the conduit is damaged.
4. This warming drawer must be properly installed and grounded by a qualified installer according to
these installation instructions prior to use. The installer must show the customer the location of the
circuit breaker panel or fuse box so that they know where and how to turn off electric power to the
Warming Drawer. Capital Cooking Equipment is not responsible for service required to correct a faulty
installation. The owner is responsible to make sure this appliance is properly installed.
5. To avoid electric shock hazard, do not install this appliance outside or near water. Do not install or use
this appliance if it has been exposed to water.
6. Do not install, repair or replace any part of the warming drawer yourself unless specifically
recommended in the literature accompanying it. All other service must be performed by a qualified
service technician.
7. Electric power to the warming drawer must be turned off at the circuit breaker or fuse box prior to
performing any type of service or installation.
8. This product is to be used only for tasks expected of a home appliance. This product is not intended for
commercial use.
9. Do not climb or sit on any part of the appliance.
10. Do not leave children or pets alone or unattended in the area around the warming drawer. Do not allow
children to play with the controls, pull on the handle or touch other parts of the warming drawer.
11. Do not store items of interest to children inside or above the warming drawer. Children can be burned
or injured while climbing on the appliance.
12. Do not tamper with the controls. Do not adjust or alter any part of the warming drawer unless
specifically instructed to do so by this manual.
13. Secure the warming drawer to the cabinet using the recommended mounting screws to prevent injury
due to the unit tipping forward,
14. Only use dry pot holders to prevent steam burns when moving items in or out of the warming drawer.
15. Do not use water on grease fires. Smother any flames with a lid, cookie sheet, or flat tray. Use baking
soda or a foam fire extinguisher to extinguish flaming grease.
16. Keep flammable items, such as paper, cardboard, plastic and cloth away from hot surfaces. Do not put
such items in the Warming Drawer. Do not allow pot holders to touch hot surfaces.
17. Do not use the Warming Drawer for storage.
18. Do not touch the interior surfaces of the warming drawer during use or immediately after use. Allow
surfaces sufficient time to cool before touching them.
19. Do not heat unopened food containers (baby food jars, and cans), or whole eggs. Pressure can build
up and may cause the container to burst and cause injury.
20. Never use the appliance for Warming or Heating the room.
21. Only clean parts as listed in the Use and Care Manual.

- -
4
WARMING DRAWER CONTROL FUNCTIONS
SET Button: The SET button is used for three main functions:
1) Activates Warming Drawer
2) Activates Warming Drawer Temperature Set selection mode.
3) Activates Warming Drawer Timer Set selection mode.
UP Button: Used to increase Temperature or Timer settings when the mode is active.
DOWN Button: Used to decrease Temperature or Timer settings when the mode is active.
WARMING DRAWER LEGEND
1. Warming Drawer
Control
2. Set Button
3. Up Button
4. Down Button
5. Control Display
6. Heater ON LED
7. Timer ON LED
8. Cabinet Mounting
Holes
9. Heating Element
10. Hinge Receptacle
11. Warming Drawer Heat
Vent
12. Door Gasket
13. Temperature Sensor
14. Serial Number Label
1
2
12
10
11
14

- -
5
WARMING DRAWER FEATURES DEFINED
1. Control SET Button:
a. The SET button activates the Warming Drawer and activates the Temperature set mode when
pressed once if it is in and Idle (Off) state, when pressed a second time the SET button activates
the Timer set mode, when pressed a third time the SET button turns the Warming Drawer OFF.
2. Control UP Button
a. The UP button is used to increase the Temperature or Timer setting.
b. A quick press of the UP button when in the Temperature mode will increase the setting to the
next preset level.
c. Pressing and holding the UP button when in Temperature mode will allow the preset to be
adjusted to your custom setting. This setting will be retained for future uses as one of the four
preset temperatures.
d. A quick press of the UP button when in the Timer mode will increase the Timer setting to the next
15 minute increment.
e. Settings are available from 15 minutes to 4 hours or the Warming Drawer may be set to be
continuously On.
3. Control DOWN Button
a. The DOWN button is used to decrease the Temperature or Timer setting.
b. A quick press of the DOWN button when in the Temperature mode will decrease the setting to the
next preset level.
c. Pressing and holding the DOWN button when in Temperature mode will allow the preset to be
adjusted to your custom setting. This setting will be retained for future uses as one of the four
preset temperatures.
d. A quick press of the DOWN button when in the Timer mode will decrease the Timer setting to the
next 15 minute increment.
e. Settings are available from 15 minutes to 4 hours or the Warming Drawer may be set to be
continuously On.
4. Moist Slider
a. The Moist slide opens and closes vents in the drawer front.
b. When the vents are closed moisture evaporated from food will be retained within the drawer and
reduce drying of heated foods.
c. When vents are open moisture is allowed to escape from the drawer.
5. Cabinet Mounting Holes
a. Mounting holes are located on the Front Stainless Panel and are used to secure the Warming
Drawer to the cabinet.
6. Door Gasket
a. The Door Gasket is used to retain heat and moisture within the Warming Drawer.
7. Heating Element
a. A Heating Element is located above the drawer interior.
8. Temperature Sensor
a. The temperature sensor reads the Warming Drawer interior temperature.
9. Serial Number Label
The serial number is required for any service or warranty calls.

- -
6
USE OF YOUR WARMING DRAWER
INITIAL WARMING DRAWER SETUP
WARNING: Verify that the Warming Drawer is secured to the cabinet via screws in the front face plate to
prevent tipping when the drawer is opened.
WARMING DRAWER USE
WARNING: Always use clean, dry pot holders when food is being placed into or removed from the warming
drawer.
WARNING: To prevent unnecessary odors, always clean large spills or food particles from the warming
drawer prior to and after use.
WARNING: To reduce condensation build up on the interior of the drawer, always pre-heat the warming
drawer prior to use. Hot foods placed into a cool drawer will cause moisture to form on the interior
of the drawer.
PREPARATION
Before you place items in the warming drawer:
•Check temperature limits for containers or lids to prevent damage.
•Always preheat the Warming Drawer to prevent excess condensation.
•Check the temperature setting with the final cooking temperature of foods. If the set temperature is higher
than the final internal cooking temperature of the food, it will continue to cook and become overdone.
•Always keep food safety in mind. The food safe temperature to prevent bacterial growth is 140° F. The
preset temperature of 145° F has been established to maintain food safe conditions and is the lowest
recommended temperature for long term storage of food.
POSITIONING FOOD IN THE WARMING DRAWER
WARNING: The Warming Drawer maintains temperature up to 200° F and can reach temperatures of 220°,
To prevent damage to plates, containers or other items placed in the Warming Drawer, verify the
maximum recommended temperatures prior to use. If unsure of the maximum temperature use a
material with known properties.
•Always preheat the Warming drawer to prevent excess condensation.
•Place foods and containers evenly within the drawer.
•The heating element is at the top of the drawer. Do not allow items to exceed the height of the drawer to
prevent contact with the heating element.
•Use of covers, lids, foil or wraps will help retain moisture in foods if desired.

- -
7
SETTING THE WARMING DRAWER
1. Pressing the SET button when is the control is off will actuate the Temperature Set mode.
2. Pressing the SET button a second time when the control is active will actuate the Timer Set mode.
3. Pressing the SET button a third time will turn the Warming Drawer Timer to CONTINUOUS. This will turn
the drawer ON until it is turned OFF by the user.
4. Four temperature settings are available and adjustable. The preset Temperatures are 110, 145, 170, and
200.All MODE icons will illuminate.
ADJUSTING TEMPERATURE PRESETS
1. After entering the Temperature SET mode, press the UP or DOWN arrow button to adjust the
temperature preset.
2. After changing a temperature preset the temperature will be retained in memory and will be used as a
preset until changed.
3. Once a temperature preset has been changed the drawer will maintain that temperature.
SETTING THE TIMER
1. After entering the Timer SET mode, press the UP or DOWN arrow button to adjust the temperature
preset.
2. The Timer will adjust in 15 minute increments from 15 minutes up to 4 hours.
3. The Timer can be reset or increased at any time by pressing the SET button to enter the Timer mode and
pressing the UP or DOWN buttons to adjust the Timer setting.
CONTINUOUS ON MODE
1. When the SET button is pressed for a fourth time when active, “Cont” will be displayed.
2. Cont indicates the Warming Drawer is operating in Continuous ON mode. This mode will maintain the
temperature setting until the Warming Drawer is turned OFF by the user.
TURNING THE WARMING DRAWER OFF
1. To turn the Warming Drawer OFF, press the SET button until the display turns OFF.

- -
8
TIPS
General
•ALWAYS PRE-HEAT THE WARMING DRAWER. This will prevent excess condensation from forming
inside the drawer while the drawer heats.
•Always center your containers within the drawer from front to back and side to side to ensure even
heating.
•Open the warming drawer only when required to keep foods hot. Opening the door allows heat to escape
and requires the warming drawer to recover.
•Food continues to cook even after removing from the oven. To prevent overcooking, remove the food
when the internal temperature is slightly below the desired temperature. Allow the food to rest and
monitor temperature for doneness.
CARE AND MAINTENANCE
WARNING: Do not touch the interior surfaces of the warming drawer during use. After use, make sure these
surfaces have had sufficient time to cool before touching them.
CLEANING CHART:
•Always start by selecting the mildest cleaner according to the kind of soil and the material soiled. To
prevent marring the stainless steel finish, always apply the cleaners in the direction of the grain. Rinse
and dry immediately to avoid water marks.
•Use clean applicators, i.e. soft cloths, sponges, or paper towels for cleaning and scouring.
•The use of brand names in the chart is intended only to indicate a type of cleaner. This does not
constitute an endorsement. The omission of any brand name does not imply its inadequacy.
•The brands listed on the chart are suggested as examples of a type of cleaner, such as non-abrasive,
powder, cream, etc., use all products in accordance with the manufacturer’s instructions.
PART /
MATERIAL / SOIL
CONDITION SUGGESTED CLEANERS IMPORTANT REMINDERS
Abrasive cleaners may leave scratches
over time
Outer glass
surfaces Non-Abrasive window cleaner, all purpose cleaners Always use clean dry cloths for best
results
Non-abrasive cleaners; hot water and
detergent, diluted ammonia, Fantastic®,
Formula 409®. Rinse and dry
immediately
Exterior Stainless
Steel Cleaner polish. Stainless Steel Magic®
to protect the finish form staining and
pitting; enhances appearance
Always rub lightly in the direction of the
grain lines
Non-abrasive cleaners; hot water and
detergent, diluted ammonia, Fantastic®,
Formula 409®. Rinse and dry
immediately
Interior Stainless
Steel Cleaner polish. Stainless Steel Magic®
to protect the finish form staining and
pitting; enhances appearance
Always rub lightly in the direction of the
grain lines

- -
9
TROUBLESHOOTING
Before calling for service, reference the following table for common problems that may enable self diagnosis or
can resolve the problem:
SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION
Power is off Check breaker or GFI
Does not turn On or
heat Wiring improperly connected Call electrician to properly connect wiring
Drawer is set to a low
temperature Check drawer temperature setting
Drawer safety device
actuated Call Capital Service
Drawer is not heating
but control is On Timer or temperature have
not been set correctly Check control settings and reset.
Items in drawer are too high Clear interior interference.
Drawer will not open Drawer slides are
improperly installed Check drawer slide alignment and reinstall
Condensation build-up Drawer not preheated Preheat drawer prior to inserting food
SERVICE INFORMATION
If none of the above has occurred, contact our customer service department at [phone].
Before you call for service, please have the following information available:
•Model Number
•Serial Number
•Date of Installation
•Copy of Receipt or Invoice
•A brief description of the problem
Your satisfaction is our top priority. If the problem persists or is not resolved to your satisfaction by our service
consultant, please write to us or fax us a letter at:
Capital Cooking Equipment, Inc.
Attn: Customer Service Manager
13211 Florence Ave.
Santa Fe Springs, CA 92670
USA
Fax Number: [phone]
Email: [e-mail]

- -
10
WARRANTY
•One (1) year full parts and labor, covers the entire unit.
WILL PAY FOR:
All repair labor and parts found to be defective due to material or workmanship for on (1) full year (from date of
purchase) “in home” WARRANTY. This does not apply if the unit was subjected to other than normal household
use. An Authorized Factory Agency must provide Service during normal working hours. No charges will be made
for repair or replacement at the location of original installation or factory for parts returned pre-paid, through the
dealer and claimed within the warranty period, and found to be defective by Capital Cooking. Call claims,
regardless of warranty or non-warranty must be documented with photos and detailed description and/or narrative
of the problem.
This warranty shall not apply, nor can we assume responsibility for damage that might result from failure to follow
manufacturer’s instructions or local codes where the appliance has been tempered with or altered in any way or
which, in our judgment, has been subjected to misuse, negligence, or accident. Implied warranty shall not extend
beyond the duration of this written warranty. This warranty is in lieu of all warranties, expressed or implied and all
other obligations or liability in connection with the sale of this product.
WILL NOT PAY FOR:
•Installation or start-up
•Shipping damage
•Service by an unauthorized agency
•Use of unauthorized parts
•Service during hours other than normal working hours
•Improper installation
•Service visit to teach you how to operate the appliance, correct the installation, reset circuit
breakers or replace fuses.
•Repair other than normal household use
•Damage caused by accident, abuse, alteration, misuse, incorrect installation or installation not in
accordance with local codes
•Unit installed in non-residential applications
This warranty applies to appliances used in residential application only. It does not cover their
use in commercial situations. This warranty is for products purchased and retained in the 50
States of the U.S.A., the District of Columbia and Canada. This warranty applies even if you
should move during the warranty period. Should the original purchaser sell the appliance during
the warranty period, the new owner continues to be protected until the expiration date of the
original purchaser’s warranty period.

- -
11
NOTES:

- -
12
THESE SPECIFICATIONS ARE FOR PLANNING PURPOSES ONLY.
CONSULT WITH AN AUTHORIZED TECHNICIAN FOR YOUR SPECIFIC INSTALLATION DETAIL
REQUIREMENTS. FOR THE MOST UP TO DATE INFORMATION, CONTACT CAPITAL COOKING
EQUIPMENT, INC. INDICATING THE MODEL NUMBER.
WE RESERVE THE RIGHT TO CHANGE THESE SPECIFICATIONS OR DESIGN WITHOUT NOTICE.
THE POWER OF PERFORMANCE TM
Capital Cooking Equipment, Inc.
13211 E. Florence Ave.
Santa Fe Springs, CA 90670 USA
866.402.4600 Toll Free
562.903.1167 Fax
MADE IN USA
www.capital-cooking.com
Part #: 87094-03
