Carlos Santana SANTANA SAMBA User manual

SAMBA
20 WATT WATERPROOF
HIGH POWER SPEAKER
OVERVIEW
STEREO PAIR FUNCTION
OPERATION
Thank you for purchasing the Samba 20 Watt Waterproof High Power
Speaker. Please read these instructions carefully for proper operation
and save for future reference.
Turning ON/OFF
Power on: Press the Power ON/OFF button for 1 second
until the white Power LED illuminates.
Power off: Press the Power ON/OFF button until the white
Power LED turns off.
Connecting with Bluetooth
To play audio from a Bluetooth device, you need to pair the
device with your speaker.
1.
Power on the speaker. The blue Pairing LED blinks,
indicating the speaker is ready to connect with your
Bluetooth device.
2. Turn on Bluetooth mode on your device.
3. Select “Santana Samba” to initiate pairing, and the
speaker will automatically connect with your
Bluetooth device, indicated by the steady blue Pairing
LED. Some devices ask you to input the PIN “0000” as
the password.
Note: Generally, there is a 3 minute maximum to pair the
speaker with your Bluetooth device, otherwise retry steps 1
to 3 to pair again.
TF Card Mode
1. Insert a TF Card into the TF Card slot on the speaker.
2. Press the MODE button (M) to switch between Bluetooth
mode and Card mode. A voice prompt will indicate the
current mode.
AUX Mode
1.
Insert a 3.5mm audio cable into the Aux Input on the
speaker.
2. Press the MODE button (M) to switch between Bluetooth
mode and AUX mode. A voice prompt will indicate the
current mode.
VOLUME (+)
CHARGING PORT MIC
AUX INPUT
TF CARD
SLOT
Power
LED
Pairing
LED
Power ON/OFF
MFB
Play/Pause
Answer Call
End Call
MODE
VOLUME (–)
If you’ve purchased 2 Samba speakers, you can play music from
a stereo pair. Follow these instructions to take advantage of this
feature.
1. Disconnect Samba from all Bluetooth devices.
2. Power on both speakers.
3.
Hold the MODE button for 2 seconds on one speaker, and
release when the voice prompt says “Speaker Searching”.
4. The speakers will connect to each other indicated by the
voice promt “Speakers Connected”. The Pairing LED on
 onespeakerwillashblue;itwillbesteadyblueontheother
speaker.
5. Turn on the Bluetooth device, and select Santana Samba.
6. Once connected, both Pairing LEDs will be steady blue.

USING THE SPEAKER CHARGING THE SAMBA
Answering a Call
When a call is incoming, you will hear a ring tone.
Press the MFB button once to accept the call, or
answer the call via your mobile phone.
Rejecting a Call
Hold the MFB button to reject the incoming call.
Ending a Call
Press the MFB button once to end the call, or hang
up via your mobile phone.
Music Play / Pause
Press the MFB button once to play/pause music.
Volume Adjustment / Skip Track
Short press the Vol(+) or Vol(-) to adjust volume.
Long press the Vol(+) to select next track.
Long press the Vol(-) to select previous track.
Voice Assistant
Hold the MFB button for 2 seconds to activate voice
assistant.
IMPORTANT:
Activate your warranty at SantanaSounds.com
1. Before charging, make sure the speaker has been
switched off.
2. Plug the USB cable into the charging port of
speaker;plugtheothersideoftheUSBcableinto
a USB charger or other charging device. Charging
will start, and the red light remains illuminated on
the speaker.
3. A full charge takes approximately 2 hours, and
then the red light will turn blue when fully charged.
Warning: You must use the original cable to charge
the Bluetooth speaker, otherwise it may damage the
speaker. Proper charger voltage must be 5V with a
current rated at 115mA.
This speaker uses a non-detachable built-in
rechargeable battery. In order to prevent damage to
the speaker, please do not remove the battery.
Note: The voice prompt “Low Battery” will notify you
when the speaker need to be recharged.
Product Name: Samba Charging Time: 2 hours
Product Type: Speaker Sensitivity(SPL): 80±3dB
Wireless Range: 33ft Impedance:4Ω
Standby Time: 180 hours Rated Input Power: 10mW
Playtime: 20 hours Distortion:≤1%
SPECIFICATIONS
ATTENTION
1. Try to avoid prolonged and continuous uses at high volume which can damage your hearing.
2. Avoid placing the speaker in prolonged sun exposure, high temperature or dusty and humid
environments, which may affect the normal use.
3. Clean your speaker with a soft cloth, moistened only with mild soap and water. Stronger cleaning
agents can damage the surface of the unit.
WARRANTY
What is covered: Any defect in materials and workmanship.
For how long: 1 year from date of purchase.
What we will do: lf your product is defective and returned within 30 days after the date it was purchased,
we will replace it at no charge to you. lf returned after 30 days but within 1 year of the date of purchase
we will repair it or, at our option, replace it at no charge to you. If we repair your product, we may use new
or reconditioned replacement parts. lf we choose to replace your product we may replace it with a new or
reconditioned one of the same or similar design. The repair or replacement will be warrantied under our
standard one year warranty.
Limitations: Impliedwarranties,includingthoseoftnessforaparticularpurposeandmerchantability(an
unwrittenwarrantythattheproductistforordinaryuse),arelimitedto1yearfromthedateofpurchase.We
will not pay for loss of time, inconvenience, loss of use of your product or property damage caused by your
product or its failure to work, or any other incidental or consequential damages including personal injury. Some
states do not allow limitations on how long an implied warranty lasts or the exclusion of limitation of incidental
or consequential damages, so the above exclusions or limitations may not apply to you.
What we ask you to do: To get warranty service for your product you must provide proof of the date of
purchase. Within 30 days of the date it was purchased, return your product to your place of purchase for
immediate replacement. After 30 days, but before the end of the 1 year warranty period, you may contact us
at SantanaSounds.com to issue a return authorization. We suggest that you retain your original packaging
material in the event you need to ship your product. When sending your product include your name, address,
phone number, proof of date of purchase, and a description of the operating problem. After repairing or
replacing your product we will ship it to your home within four weeks.
What this warranty does not cover: Among other things this warranty does not cover defects resulting
fromaccidents,unauthorizedrepair,failuretofollowdirections,misuse,re,oods,andactsofGod.lfyour
protection is not covered by our warranty, contact us at SantanaSounds.com to determine whether we will
repair your product and other repair information, including charges. We, at our option, may replace rather than
repair your product with a new or reconditioned one of the same or similar design, the repair or replacement
will be warrantied for one year. This limited warranty is the only one we give on your product, and it sets forth
all our responsibilities regarding your product. There are no warranties that extend beyond the description set
forth above.
State law rights:Thiswarrantygivesyouspeciclegalrightsandyoumayalsohaveotherrightswhichmay
vary from state to state.
FCC/BLUETOOTH STATEMENT
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Santana Sounds, LLC is under license. Other trademarks and trade names are
those of their respective owners.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
V1.0
