GENERAL INFORMATION
Thank you for urchasing our roduct and wish you will enjoy it.
The trolling motors are designed and develo ed by rofessional engineering teams. With years of efforts. The ower of
trolling motor has widely covered from 18LBS to 150LBS in order to fit various costumers’ requirements and rovide
different ex eriences.
Please read and retain this manual before using this electrical motor. The manual contains information that describes the
rocedure for safe o eration and daily maintenance of your trolling motor. Safe o eration will revent from ersonal
injury and roduct damage.
HANDLE
MOUNTING BRACKET
ENGINE
BATTERY INDICATOR
PROPELLER
FIN
ADJUSTABLE DEPTH FEATURE

BRUSHLESS OUTBOARD X series USER MANUAL（2022）
FIRST TIME RUNNING
FIN INSTALLMENT (A)
Take out the lastic fin out of the accessory box. Loosen off the screws. Find the screw holes on front endbell. Kee the
fin and screw holes aligned. Insert the fin and re-tighten the screws.
Make sure the screws are ro erly tightened to revent the fin from loosening.
HANDLE INSTALLMENT (B)
Turn the handle 90 degrees along the axis, cli it into the rear control box.
Kee the handle in horizontal and start to use.
Note: Do not fold the handle after installment, other-wise the self-lock could be damaged.
When need to re air, remove the sticker, inch out the self-lock button, and fold the handle to save ackage size.
(A) (B)
BATTERY CONNECTION METHOD
Before connecting the motor’s cables to the battery terminals, ensure all switches are in the OFF osition. Stand clear of
the ro eller. Connect the red cable to the ositive (+) terminal and the black cable to the negative (-) terminal. Make
sure the terminals are clean before Connecting. A clean connection will minimize ower wastage and give the maximum

BRUSHLESS OUTBOARD X series USER MANUAL（2022）
ower from the battery. (C)
Kee the battery in a well-ventilated location. Place a dee cycle marine battery is recommended for o timum
erformance.
The 3 indicator lights on the control box indicate 100%, 60%, 30% of battery status res ectively.
Make sure the battery is fully charged before use.
AUDIO PATTERN
AUDIO PATTERN CONDITION
5 Beep System eady
Continuous 2 beep System eady but handle is not on the neut al position
Continuous 3 beep High/low-voltage, high cu ent condition, MOS p oblem
Continuous long beep Moto stop ope ation, wait the handle back to neut al position
(C) (D)
REPLACE THE PROPELLER (D)
Hold the ro eller blade and loosen the ro eller knob. It can be done counter clock-wise manually without tools. Pull
the ro eller straight off. If ro is stuck, gras one blade with one hand and ta on the backside of the o osite blade
lightly with a rubber mallet, until the ro eller comes off. If the ro eller in is bent, re lace it. Align the new ro eller
with the ro eller in. Re-install the ro eller knob and tighten firmly by hand clock-wise.
ATTACHING THE MOTOR TO YOUR BOAT (E)
Attach the motor to the stern of the boat and tighten both mounting bolts securely while taking care not to over-tighten.
To adjust the angle of the motor after attachment, hold the motor head with one hand and de ress the ositioning in at
the to of the mounting bracket with your other hand.
Press and hold the ositioning in until the desired angle has been reached next release the in and ensure the
mechanism locks securely.
Wa ning: Befo e the installation, make su e the a ea between column and b acket is clea .
DEPTH ADJUSTMENT (F)

BRUSHLESS OUTBOARD X series USER MANUAL（2022）
Hold the motor shaft with one hand, loosen the de th adjustment screw and set the motor to the desired de th, then
retighten the adjusting screw securely.
(E) (F)
STEERING
To adjust steering counter-force, sim ly loosen or tighten the counter force bolt. The ideal setting is one where the
counter force bolt is just tight enough so that the boat will steer in the direction you are aiming without need for
continual correction.
SPEED CONTROL(G)
Align the arrow to the control of the handle to become neutral status. Make the handle to neutral osition every-time
before restart the motor.
Turn the handle anticlockwise the motor goes forward, turn the handle clockwise the motor goes reverse. The more you
turn from 0, the faster motor will be.
(G)
TROUBLESHOOTING
POSSIBLE CAUSE/SOLUTION
S eed loss 1: Check for line or weed on ro eller.
2: Check battery status.
3: Check terminals on battery.
Motor noise/shake 1: Check ro eller for line or weed.
2: Check to see ro eller is secure and not damaged.
3: Check shaft to ensure it is not bent. Detach ro eller and run
motor visually to ensure shaft is not shaking. If shaft is damaged
contact your retailer.

BRUSHLESS OUTBOARD X series USER MANUAL（2022）
Loss of s eed setting 1: Check all wiring connections.
2: Switch in motor may be burned, contact your retailer.
Tight steering 1: Loosen counter-force screw, a ly lubricant and readjust.
MAINTENANCE
At the end of the day, wi e the motor down with a cloth soaked in warm water and then rinse unit with light s ray from
hose. Always check the ro eller is clear of line or weed, regularly check all nuts, bolts and screws and lubricate all
moving arts with an aerosol lubricant. Clean terminal connections regularly and check for frayed wires or loose
connections.
STORAGE
When storing the motor, lubricate all moving arts and screws and store in a well-ventilated, dry area. Do not leave the
motor outside in winter for long eriods, as this will damage the ermanent magnet in the unit.
WARRANTY
According to vendor’s general condition of sale.
The motors are covered by a legal Euro ean warranty of 2 years (excluding defects in use).
